VOICE ACTIVATED CLOCK
WITH AMAZON ALEXA
User’s Guide for Model ICWFV428 v2055-01
ICWFV428-2055-01-IB.indd 3
10/05/2018 11:15:31 AM
SAFETY WARNINGS
• WARNING: To prevent fire or shock
hazards, do not expose this unit to rain
or moisture.
• Clean only with a dry cloth. Do not clean
with liquid cleaners or damp cloth.
• Do not use with devices that should not be
used unsupervised.
• CAUTION: TO REDUCE THE RISK OF
ELECTRIC SH OC K, U S E ONLY INDOORS.
• Do not use in a bathroom or other location
where it may come into contact with water
or splashing.
• WARNING: Where the mains plug
or appliance coupler is used as the
disconnect device, such disconnect
device shall remain readily operable.
• Risk of electric shock. Grounding
continuity must be maintained.
• Only use the included power supply or a
UL/ETL certified power supply of the same
power output specifications.
WARNING: This product can
expose you to chemicals including
lead, which is known to the State of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to: www.
P65Warnings.ca.gov This product
meets and complies with all Federal
regulations.
FCC WARNINGS
WARNING: To assure continued operation,
follow the attached installation instructions and
use only shield cables when connecting to
other devices. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
WARNING: This equipment complies with
FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20cm between the radiator
& your body.
NOTE: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference in a residenti al installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
3
ICWFV428-2055-01-IB.indd 4
10/05/2018 11:15:31 AM
TABLE OF CONTENTS
Introduction
Features
Includes
Overview
Speaker Controls & Inputs - 6
Mode/Connection/Alexa Indicator Light - 7
Setup
1. Power - 8
2. Download the Alexa App - 9
3. Download the iLive Wi-Fi App - 9
4. Connect to Wi-Fi - 10
5. Connect to Your Amazon Account - 13
6. Things to Try with Alexa - 15
Setting Alarms
Set Alarms Using Amazon Alexa - 16
View Alarms in the iLive App - 17
iLive Wi-Fi App
Music Player Screen - 18
Menu Screen - 19 Device
List Screen - 20 Multiroom Play - 21
Multi-channel Play with Multiple Speakers - 21
Internet Music Services - 22
Spotify Connect
How to use Connect
Other Ways to Play
Bluetooth Wireless
Troubleshooting
Customer Support - 26
Contact Information
International Support
Warranty Information
- 5
- 23
- 24
- 25
4
ICWFV428-2055-01-IB.indd 5
10/05/2018 11:15:31 AM
INTRODUCTION
Make your home smarter with the Voice Activated Clock with Amazon Alexa. Link
Amazon Alexa with the clock and ask Alexa to play music, read the news, check
weather, control your smart home and more.
Features
» Voice-activated Amazon Alexa cloud-based voice service
» Multi-room and multi-user capable
» Free iLive Wi-Fi app download
» Built-in Wi-Fi - ran ge 98 ft.
» Supports Bluetooth Wireless - range 33 ft.
» Built-in microphones
» 1.2” white LED display
» Auto clock sync with Amazon Alexa
» Night light with dimm er/ on/ off control
» Micro-USB port for battery recharge
Includes
» AC/DC power adapter
» User’s Guide
» Warranty
Specifications, software updates, and third party content are subject to change without prior notice.
5
ICWFV428-2055-01-IB.indd 6
10/05/2018 11:15:32 AM
19 20
DC IN
USB CHARGER
21 15 13
PM
ALARM
16
WPS
14 17 18 1 4 5 6 7 8 2 9 3 10 11 12
OVERVIEW
Speaker Controls & Inputs
6
ICWFV428-2055-01-IB.indd 7
10/05/2018 11:15:32 AM
1.
Power/Source
2.
WPS/Pair
3.
Play/Pause/Dimmer
4.
Skip Track
5.
Ambient Light Level
6.
Mode/Connection/
Alexa Indicator Light
7.
Microphone OFF
Indicator Light
8.
Microphone/Alexa Mute
9.
Volume −/+
10.
Alexa On
Mode/Connection/Alexa Indicator Light
» Alexa Indicators
Off - Speaker ON, Amazon Alexa standing by
Alternating Light & Dark Blue - Amazon Alexa listening/responding
Red - Amazon Alexa and microphones muted
» Mode/Connection Indicators
Flashing White (slow) - Wi-Fi Standby Mode
Flashing White (fast) - Connecting to Wi-Fi
Solid White - Connected to Wi-Fi
Flashing Blue (slow) - Bluetooth Standby Mode
Flashing Blue (fast) - Pairing Bluetooth
Solid Blue - Paired to Bluetooth device
11.
Microphones (x2)
12.
Snooze/Sleep
13.
PM Indicator
14.
1.2” White LED Display
15.
Sleep Alarm Indicator
16.
Bluetooth Indicator
17.
Wi-Fi Connected Indicator
18.
Ambient Light Ring
19.
Speaker
20.
USB Charging Port (5V 1A)
21.
DC Power Input
7
ICWFV428-2055-01-IB.indd 8
10/05/2018 11:15:32 AM
SETUP
1.
Power
Use an AC/DC Power adapter (included) to connect to a standard wall outlet.
You can charge mobil e devi c es with the USB port on the back of the clock. Use a
USB power cable (not included) to connect to your device. The power output of
the USB port is 5V 1A.
Charging
Power
Power ports on the back of the clock
8
ICWFV428-2055-01-IB.indd 9
10/05/2018 11:15:33 AM
2.
Download the Alexa App
Download the Amazon Alexa app to your device by scanning the appropriate QR
code below or search for the Amazon Alexa app in the Google Play™ Store, or
Apple App Store®.
Android
Apple
The Amazon Alexa app connects your clock to Alexa’s voice services. It’s also
where you can see an overview of your requests and manage your contacts, lists,
news, m usic , and settings.
Once downloaded, open the Alexa app and log into your Amazon account. If you
do not already have an Amazon account, choose “Create a new Amazon account”
and enter the requested info. Once logged in, the app will prompt you for setup.
You can add th ese d etai ls now by choosing “Get Started,” or skip these steps and
complete the process later. You cannot use Alexa Voice Services if yo u aren’t
logged into an Amazon account.
3.
Download the iLive Wi-Fi App
Download the iLive app to your device by scanning the QR codes below or search
for the iLive Wi-Fi app in the Google Play™ Store, or Apple App Store®.
Android
Apple
The iLive Wi-Fi app lets you play music and audio from streaming services like
Spotify, iHeartRadio and others. It also controls the speaker’s other functions,
such as Multi-room play, Multi-channel play, etc.
Note: This app is designed for mobile devices only, such as
smartphones or Wi-Fi enabled tablets. It is not available for use on
regular desktop or laptop computers.
9
ICWFV428-2055-01-IB.indd 10
10/05/2018 11:15:33 AM
SETUP
4.
Connect to Wi-Fi
To use the clock’s Wi-Fi features, the clock and your mobile device must both be
connected to a Wi-Fi network. The app will guide you through the process, just
follow the on-screen instructions and have your network password ready.
After the initial connection, the speaker will remember the Wi-Fi network and
automatically connect to it when it is in Wi-Fi Mode. If the speaker should become
disconnected or will not connect normally, repeat the steps below.
Initial Wi-Fi Connection
Note: If you have a dual band wireless router, be sure to connect to the 2.4GHz
band, not the 5GHz band.
Note: Please make sure that the WPS indicator is On when Wi-Fi connected.
1. Press the Power b utton to power on the clock. The Mode/Connection LED
will flash multiple colors after first powering on. This is normal, please
wait for the Mode/Connection LED to begin slowly flashing white, indicating the
speaker is in Wi-Fi Standby Mode.
2. Open the iLive Wi-Fi app on your device and press “Search”, then “Add Device”
(Image A, B, below).
A.
B.
10
ICWFV428-2055-01-IB.indd 11
10/05/2018 11:15:33 AM
3. From the drop down menu, select the ICWFV428 speaker, then press “Connect
Speaker” (Image C, below).
4. The app will direct you to your mobile device’s Wi-Fi Settings Menu to connect
directly to the speaker. Press “Settings” (Image D, below) to go to your mobile
device’s Wi-Fi settings menu, then select ICWFV428_XXXX and return to the
app when you are connected.
Setup instructions continued on the next page.
C.
D.
11
ICWFV428-2055-01-IB.indd 12
10/05/2018 11:15:37 AM
SETUP
4.
Connect to Wi-Fi
Initial Wi-Fi Connection (continued)
5. Once you have returned to the app, select your Wi-Fi network/router and enter
the password, then press “Continue”. This will connect your mobile device and
the speaker to your Wi-Fi (Image E, below).
6. The app will display its progress as it configures the speaker and your Wi-Fi
network. When this is complete, a voice will announce the successful connection
and the Mode/C o nn ection LED will t u r n solid white. Press “Next” to proceed
to Amazon Alexa Setup (Image F, below).
E.
F.
12
ICWFV428-2055-01-IB.indd 13
10/05/2018 11:15:39 AM
5.
Connect to Your Amazon Account
1. When the Wi-Fi connection is complete, the app will prompt you to link the
speaker with the Amazon Alexa app on your device (Image G, below). If you do
not have the Amazon Alexa app on your de vic e, re fer to the instructions
on pg. 9. NOTE: If you do not want to login to your Amazon account and link
Alexa to the speaker at this time, press “Cancel”. You can complete it later by
following the steps on the next page.
2. Enter your Amazon account information to complete setup and begin
Amazon Alexa with your speaker (Image H, below).
using
G.
H.
13
ICWFV428-2055-01-IB.indd 14
10/05/2018 11:15:40 AM
H.
Swipe right
S
creen
SETUP
5.
Connect to Your Amazon Account
Amazon Alexa Manual Setup
1. From the Music Player Screen, swipe right to access the Menu Screen.
2. Select Amazon Alexa from the list (Image I, below).
3. Sign into your Amazon account wh en prompted.
I.
for Menu
14
ICWFV428-2055-01-IB.indd 15
10/05/2018 11:15:41 AM
6.
Things to Try with Alexa
Now that you’re connected, try interacting with Alexa. Start by saying “Alexa,”
followed by a command or question. Here are some examples:
» “Alexa, tell me a joke.”
» “Alexa, what’s in the news?”
» “Alexa, what can you do?”
While the speaker is on (in Wi-Fi mode) and the Mode/Connection LED is white,
Alexa is in standby mode, awaiting a command or question from you. All you need
to do is say “Alexa...”, within range of the speaker’s microphones and she will
respond. When Alexa is listening and responding to your commands, the Mode/
Connection LED on the speaker will change from white to blue. You can also press
the button on the speaker to manually activate Alexa.
You can mute Alexa and disable the microphones by pressing the button. The
Mode/Connection LED will change to red while muted. In this mode, the speaker’s
audio functions will still work normally.
15
ICWFV428-2055-01-IB.indd 16
10/05/2018 11:15:41 AM
SETTING ALARMS
Set Alarms Using Amazon Alexa
You can add alarms, schedules, and reminders by telling Alexa to set them for you.
To set a simple, one time alarm, just say:
“Alexa, set an alarm for (the specific time of your choosing).”
To set recurring or more complicated alarms and schedules, you’ll need to give
Alexa some sp ecifics to work with. If you want to wake up in the morning to your
favorite musical artist, you could say:
“Alexa, wake me up to (artist’s name), every weekday, at 7:00 am.”
Or if you wanted to hear your favorite podcast on the weekend, you’d say:
“Alexa, play (podcast name), every Sunday, at 6:30 pm.”
For more ideas and possibilities, consult the table below.
ALEXA, WAKE TO... DATE
Musical
Genre, Save
P
laylist, Specific Artist
or Song, Game, News
P
odcast, etc
d
,
Specific Date,
Weekends, First
of the
Month, et
Weekdays
Mondays
c.
TIME
,
Specific Time (
a
m, 6:45 pm, etc.)
8:00
16
ICWFV428-2055-01-IB.indd 17
10/05/2018 11:15:41 AM
View Alarms in the iLive App
Note: Please make sure that the Alarm indicator is On when alarm set.
1. Access the Device List Screen.
2. Select the Settings icon in the ICWFV428 listing (Image J, below).
3. Select Alexa Clock (Image K, below). Current alarms will be displayed here.
Speak to Alexa to set new or remove unwanted alarms.
J.
K.
17
ICWFV428-2055-01-IB.indd 18
10/05/2018 11:15:42 AM
1
2
on
t
o
or Wi-Fi
Swipe right for
Menu Scr
een
Swipe right
Menu
3 4 5 6 7
ILIVE WI-FI APP
Music Player Screen
This is the default screen when you open the iLive app.
Press ic
o switch
t
Bluetoot
h
for Device
1.
Music Directory
2.
Connection Mode
3.
Add to Favorites
4.
Current Playlist
5.
Repeat/Shuffle
6.
Volume
7.
Play Controls
18
ICWFV428-2055-01-IB.indd 19
10/05/2018 11:15:43 AM
1 2
3 4
5
6
Menu Screen
1.
Search
Search for songs, albums and artists.
2.
Favorites
Open songs, artists, albums, or
stations that you have saved.
3.
My Music
Open music that is stored on your
mobile device.
4.
Internet Music Services
Available third-party musi c apps.
5.
Amazon Alexa
Sign in to Amazon Alexa and adjust
settings for Alexa and iLive Wi-Fi app.
6.
Add more Services
Press to add more third-party apps.
19
ICWFV428-2055-01-IB.indd 20
10/05/2018 11:15:43 AM
ILIVE WI-FI APP
Device List Screen
1.
Add Device/Refresh List
Add more speakers or refresh the list
of available devices.
2.
Speaker Settings
Rename a speaker, set preset
stations, and find additional
information on a speaker.
1
2
3
3.
Audio Channel
Press to set audio channels for the
speaker: L / R / LR (left/right/stereo).
4.
Play All
Play music on all connected
speakers.
20
4
ICWFV428-2055-01-IB.indd 21
10/05/2018 11:15:43 AM
Multi-room Play
Using Wi-Fi, users can pair up to six multi-room speakers throughout their home
for multi-room audio. Place speakers in any room and use the app to play music
from the speaker of your choice. You can play different songs from different
speakers, set individual volume levels, or you can link all of the speakers to play
the same song.
Use the iLive Wi-Fi app along with any of the following iLive products: ISWFV387,
ISWF476, ISWF576 ISWF776, ICWFV428 (this unit), ITWFV678, IKBFV378.
Multi-mode
» In the Device List, press and hold a device icon for two seconds, then drag
Solo-mode
» Press and hold the device icon, then drag downwards past the dotted line.
towards another device to link the speakers together.
Multi-channel Play with Multiple Speakers
You can use two or more speakers in one room for a surround sound effect by
setting the Audio Channel selector to “LR” (stereo) for all of the speakers.
You can also use two speakers at once for stereo play by setting the Audio
Channel selector to “L” and “R” for the “left” and “right” speaker respectively.
21
ICWFV428-2055-01-IB.indd 22
10/05/2018 11:15:43 AM
ILIVE WI-FI APP
Internet Music Services
The iLive Wi-Fi app supports and can play songs from Spotify, iHeartRadio, and
others. Similar to the setup process for Alexa, some of these third-party services
will prompt you to log in and link your account with the iLive Wi-Fi app so that it
can access media you already have saved with that service.
22
ICWFV428-2055-01-IB.indd 23
10/05/2018 11:15:43 AM
SPOTIFY CONNECT
How to use Connect
You’ll need Spotify Premium to use Connect, see details overleaf.
1. Add your new device to the same Wi-Fi network as your phone, tablet or PC (see
product user instructions for details).
2. Open the Spotify app on your phone, tablet or PC, and play any song.
3. If you’re using the app on a phone - tap the song image in the bottom left of the
screen. For tablet and PC move to step 4.
4. Tap the Connect icon
5. Pick your device from the list. If you can’t see it, just check it’s connected to the
same Wi-Fi network as your phone, tablet or PC.
All done! Happy listening.
Licences
The Spotify Software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
23
ICWFV428-2055-01-IB.indd 24
10/05/2018 11:15:43 AM
OTHER WAYS TO PLAY
Bluetooth Wireless
Note: After powering on the speaker, the Mode/Connection LED will flash
multiple
colors. This is normal, please wait for the Mode/Connection LED to
begin slowly
play mode.
flashing white before pressing the Mode button to switch to another
Initial Bluetooth Connection
» Power on the speaker (see note above) and press the Power/Source button
to switch to Bluetooth Mode, indicated by a slowly flashing blue light from the
Mode/Connection LED and a voice prompt from the speaker.
» Press and hold the Pair button to be gin pairing. The Mode/Connection LED
will begin quickly flashing blue as it searches for a device. When pairing, remain
within 3 ft. of your device.
» On your Bluetooth device, open the Bluetooth Settings and select ICWFV428
from the list of available devices. It may take a moment before your device
detects the speaker and is available in the list. You may also need to scan for
Bluetooth devices manually from your mobile device.
» When successfully paired, the M ode/Connect io n LE D on the speaker will turn
solid blue and a voice will announce the connection. Audio from the connected
device will now be played through the speaker.
» Use the controls on your device to select and begin playing audio. Use the
controls on the device or the speaker to play, pause, and adjust the volume.
Previously Connected Devices
The speaker can remember multiple Bluetooth devices and will always try to
reconnect to the last device it was paired with.
To reconnect to a different device, turn off Bluetooth on unwanted devices, then
access the Bluetooth Settings on the device you wish to use and select ICWFV428
to reconnect to the speaker.
Bluetoot h C o nnec t io n Problems
If the speaker should become unpaired or will not connect normally, try the below
suggestions to re-establish a connection.
» On your device, open the Blue to oth S etti n gs and turn Bl uetooth off and on again.
Select the speaker from the list of available devices.
» On your device, open the Bluetooth Settings and delete the speaker (”Forget this
device”), then perform the initial connection steps again.
24
ICWFV428-2055-01-IB.indd 25
10/05/2018 11:15:44 AM
TROUBLESHOOTING
PROBLEM
C
annot complete
W
i-Fi network setup
Intermittent au
do
esn’t play
Bluetooth
fa
ils to co
White noise/Speaker w
not function properly
dio/Au
won’t play o
nnect
POSSIBLE SOLUTION
» Make sure the
» Make sure you are connecting
W
i-Fi network.
» If using a dual band wir
use the 2.4GHz band.
» Be sure
» T
est your inter
a
web
may
» Uninstall then reinstall the app, power the speaker
OFF, then ON, and r
» Make sure the volume on the
dio
connected device is turned up
» Interference or weak W
interrupting
micr
system
» Stop other applications that may be str
media
» Make sure the volume on your Bluetooth device is
r
turned up
» Make sure the
» Make sure
Bluetooth mode.
» Stay within
» Power the
ill
» Hold
the speaker
clock
to
enable W
net connection by loading/r
page. If you cannot load the page, you
need
to restart your r
reception (possible sources could be
owaves, cell phone signals, etc.). Move the
to
another location
from
the inter
to an
audible level.
clock
both
the
3
ft. of the speaker when pairing.
clock
OFF, then ON again.
down
the
button
.
has power
to
eless r
outer, be sure
i-Fi on your mobile device.
outer
.
estart setup.
clock
to an
i-Fi signal may be
to
test.
net.
has power
clock
and your device are in
for
10
.
the corr
and your
.
seconds
ect
to
eloading
audible level.
eaming
to
reset
25
ICWFV428-2055-01-IB.indd 26
10/05/2018 11:15:44 AM
CUSTOMER SUPPORT
Contact Information
Website: www.iLiveElectronics.com
Email Support: prodinfo@dpiinc.com
Email Parts: partsinfo@dpiinc.com
Phone Support: 1-888-999-4215
International Support
To download this User’s Guide in English, Spanish, or French, or to get answers to
frequently asked questions, visit the support section at:
www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para
obtener respuestas a preguntas frecuentes, visite la sección de apoyo en:
www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour
obtenir des réponses à des questions fréquemment posées, consultez la rubrique:
www.iLiveElectronics.com
Warranty Information
For Warranty Information and the most
up-to-date version of this User’s Guide,
go to www.iLiveElectronics.com.
Mad
Gre
e
en
Copyright © 2018 Digital Products International (DPI, Inc.)
Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates.
All other trademarks appearing herein are the property of their respective owners.
Protect for Today
Sustain for Tomorrow
26
ICWFV428-2055-01-IB.indd 28
10/05/2018 11:15:44 AM
NOTES
27
Loading...
