WARNING
TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
EXTENSION
HAZARD,
FULLY
The Caution Marking is located at the back enclosure of the apparatus.
The Rating plate is located at the back enclosure of the apparatus
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructio ns.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpos e of the polarized or grou nding-type plug. A polarized plug
has two blades with one wider than the other. A grou nding type pl ug has two bl ades and a
third grounding prong. The wide blade or the third prong is provided for yo ur safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particular ly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. When a cart i s used, use caution
when moving the cart/apparat us com bination to avoid injury from t ip-over .
13. Unplug this apparatus dur ing light ning storms or when unus ed for a lon g
period of time.
14. Refer all servicing to qualified service p ersonnel. Servicing is required when the ap paratus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid ha s
been spilled or objects have fallen into the apparat us, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
1
15. This appliance shall not be expos ed to dripping or splashing water and that no objec t filled
with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated .
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
19. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your home,
consult your product dealer or local p ower company. For products intended to oper at e f rom
battery power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this prod uct through open in gs
as they may touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product f rom the wall outlet and refe r servicing to
qualified service personnel un de r the following con di tions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will oft en require ext ensive work
by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for
service.
22. Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnec t the apparatus from the mains complete ly, the mains
plug should be disconnected from the mains socket outlet completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
25. Minimum distances of 4 inches around the apparatus for sufficient ventilation.
26. The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
27. No naked flame sources, such as lighted candles, should be placed on the apparatus.
28. The use of apparatus in moderate climates.
29. Attention should be drawn to the environmental aspects of battery disposal.
SAVE THESE INSTRUCTIONS
2
COMPLIANCE WITH FCC REGULATIONS
FCC ID: 2ANH76961401USB
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
As the laser beam used in this com pact disc player is harmf ul to the eyes, do not att empt to
disassemble the casing.
Stop operation immediately if any liquid or solid object should fall into the cabinet.
Do not t ouch the lens or pok e at it. If you do , you may damage th e lens and the player ma y
not operate properly.
Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD door
is still open.
3
If the unit is not to be used for a lo ng period of time, make sure that all power s ources are
disconnected from the unit. Remove all batteries from the battery compartment.
This unit employs a laser. The use of controls or adjustment or performance of procedures
other than those specified here may result in exposure to hazardous radiation.
Caution:
- Any use of the controls or performing any of the procedures in a way other than those specified herein
may result in hazardous radiation exposure.
- This unit should not be adjusted or repaired by anyone except qualified service personnel.
ON PLACEMENT
Do not use the unit in places which are extremely hot
Place the unit on a flat and even surface.
Do not restrict the air-flow of the unit by placing it in a pla ce with poor ventilation, by covering it
with a cloth or by placing it on a carpet.
ON CONDENSATION
When left in a heated room where it is warm and damp, water droplets or condensation may form
inside the unit.
When there is condensation inside the unit, the unit may not func tion normally. Let it stand for 1 to
2 hours before turning the power on, or gradually heat the room up and dry the unit before use.
cold, dusty or humid.
,
Should any trouble occur, disconnect the AC Adapter and refer servicing to qualified
personnel.
PROTECT YOUR FURNITURE
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving
when
specially
types of oil based
rubber ‘feet’ to soften, and
To prevent any damage to your furniture we strongly recommend that you purchase small
selfeverywhere
product on fine
you
operate the controls. These ‘feet’ are made from non-migrating rubber material
formulated
to avoid leaving any marks or stains on your furniture. However certain
furniture
polishes, wood preservatives, or cleaning sprays may cause the
leave
mark s or a rubber res idu e on the
furniture.
adhesive felt pads, available at hardware stores and home improvement centers
and
apply these pads to the bottom of the rubber ‘feet’ before you place the
wooden furniture.
4
DEAR STUDEBAKER® CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the start of your
musical enjoyment. Now it's time to consider how you can maximize the fun and excitem ent your
equipment offers. This manufacturer and the Electronic Industries Association's Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion and, most
importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time your
hearing "comfort level" adapts to higher volumes of sound. So what sounds "normal" can actually be
loud and harmful to your hearing. Guard against this by setting your equipment at a safe level
BEFORE your hearing adapts.
To establish a safe level:
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufac turer and
the Electronic Industries Association's Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise.
Customer's Record:
The serial number of this product is found on its back cover. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to aid in
identification in the event of theft of loss.
Model Number: SB2149 Serial Number:
CONTENTS OF YOUR PRODUCT
Main Unit X 1
AC adaptor (DC 12V 1.5A ) X 1
Car-Boat Adaptor X 1
User Manual X 1
5
LOCATION OF CONTROLS
1 MASTER VOLUME 17
SKIP/FAST BACKWARD
BUTTON
2 TREBLE KNOB 18 REPEAT/PROGRAM BUTTON
3 BASS KNOB 19
CD/USB MODE; PLAY/PAUSE
BLUETOOTH PAIR BUTTON
4 BALANCE KNOB 20
LIGHT SHOW /
BUTTON
5 FM TELESCOPIC ANTENNA 21 SKIP/FAST FORWARD
BUTTON
6 POWER INDICATOR 22 DIAL POINTER
7 CHARGE INDICATOR 23 USB PORT
8 BT INDICATOR 24 HEADPHONE JACK
6
;
9 FM ST. INDICATOR 25 TWEETER
10 FUNCTION SWITCH 26 MULTI COLOR LIGHT SHOW LED
11 BAND SWITCH 27 WOOFER
12 AUX IN JACK 28 CD COMPARTMENT
13 TUNING KNOB 29 CARRYING HANDLE
14 LED DISPLAY 30 DC INPUT JACK
15 POWER BUTTON 31 CD DOOR LATCH
16 +10 BUTTON
POWER SOURCE
This unit can be operated using either AC power, the built-in Li-Polymer rechargeable battery
or Car-boat adaptor power.
AC POWER OPERATION
An AC-DC Adaptor with the output of DC 12V, 1.5A (included) is required for operating the
main unit when using AC power mode. To connect the AC-DC Adaptor to the unit and 120V~
60Hz AC Outlet:
1. Firmly and securely insert the DC plug of the adaptor into the DC Jack on the back of the
unit.
2. Plug the AC Adaptor plug into the 120V AC outlet. CHARGE LED will be lighting Red
during battery charging. Connecting this unit to any other power source may cause damage
to the system
3. Press the POWER button on the top panel to turn on the unit, the POWER INDICATOR will
light.
Note: When the unit is not operated for long periods of time, unplug the AC adapter from the
unit and wall outlet.
BUILT-IN RECHARGEABLE BATTERY OPERATION
1. This unit will also operate using the built-in Lithium rechargeable battery. Fully charge the
built-in rechargeable battery before first use, the CHARGE INDICATOR will turn from Red
to Green when the built-in battery is fully charged.
2. Unplug the DC INPUT jack of main unit. The unit will enter Battery Operating mode
automatically.
7
LOW BATTERY INDICATION
1. When the build-in battery power remains around 5%, the CHARGE INDICATOR will light
Red and flas h , please connect the unit to AC adaptor for charging.
2. After prolonged use, the battery voltage may discharge and operation might become
intermittent. When this happens, please recharge the internal battery.
CAR-BOAT ADAPTOR OPERATION
A Car-Boat Adaptor is required for operating the main unit when using DC 12V car battery
power mode. To connect the Car-Boat Adaptor to your car:
1. Firmly and securely insert the DC plug of the adaptor into the DC Jack on the back of the
unit.
2. Plug the Car-Boat Adaptor plug into the 12V DC outlet of your car battery. CHARGE LED
will be lighting Red during battery charging. Connecting this unit to any other power source
may cause damage to the system
3. Press the POWER button on the top panel to turn on the unit, the POWER INDICATOR will
light.
Note: When the unit is not operated for long periods of time, unplug the Car-Boat Adaptor from
the unit and your car.
CHARGING INSTRUCTIONS
CHARGING THE BATTERY WITH THE INCLUDED AC ADAPTOR
1. Charge the built-in Lithium battery a minimum of 5 hours prior to first use. Firmly and
securely insert the DC plug of the adaptor into the DC Jack on the back of the unit.
2. Plug the AC Adaptor plug into the 120V AC outlet. Connecting this system to any other
power source may cause damage to the system.
3. When the AC power is connected, the battery charging indicator will light solid Red showing
that the internal battery is being charged.
4. After the battery is fully charged, the charging indicator will turn to solid Green.
Notes:
1.) Charging time will vary if you are listening to music while charging the internal battery. We
recommend you place the unit in Power off mode during the charging process or until
SB2149 batteries are fully charged.
2.) To prolong the life of a rechargeable battery, it is recommended to completely discharge it
before fully charging it again.
3.) Rechargeable batteries need to be cycled for maximum performance and longer battery life.
If you don’t use the player that often, be sure to recharge the battery at least once a month
in order to keep the internal battery working properly.
Battery Note and Care
Do not burn or bury batteries.
Do not puncture or crush.
Do not disassemble.
Recycle Lithium batteries. Do not dispose of in the trash.
Use only chargers rated for Lithium cells. Be sure the charger’s voltage and current
settings are correct for the battery pack being charged.
Charge batteries on a fireproof surface away from flammable items or liquids.
Batteries should NEVER be left unattended while charging. Only adults should charge the
batteries.
8
Follow t he manufacturer’s instruc tions for charging the product and do not charge lo nger
than recommended. Unplug the charger when the battery is charged or not in use.
NOTE:
These speakers are not magnetically shielded and may cause color distortion on the
screen of some TVs or video monitors. To avoid this, you may need to move the
speakers further away from the TV or monitor if unnatural color shifts or image distortion
occurs.
RADIO OPERATION
1. Press the POWER button on unit top panel to turn on the unit power, the unit will be "On"
and power LED indicator lights.
2. Slide the FUNCTION switch to RADIO position.
3. Select the desire AM/FM band by switch the AM/FM/FM ST. BAND SELECTOR.
4. Tune to your desired station with the TUNING knob. If FM STEREO mode is selected and
you tune to a FM Stereo station, the FM STEREO LED Indicator will light.
5. Adjust the MASTER VOLUME knob to obtain the desired sound level.
FM & FM-STEREO RECEPTION
Set the BAND SELECTOR to “FM” position. Stations will now be received in MONO mode.
When a FM station is weak or distorted, listening is usually improved by switching the band
selector to the FM (mono) position.
Set the band selector to “FM-ST” position to receive stereo broadcasts. The FM-Stereo
LED indicator will light up to show a FM stereo station is detected.
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the position of
the unit until the internal antenna picks up the strongest signal.
FM - If a stereo broadcast program is being received, the FM STEREO INDICATOR will light.
During FM Stereo reception, always keep the FM TELESCOPIC ANTENNA fully
extended for best performance. However, if FM reception is weak, try repositioning the
unit near an open window until you get the best reception.
CD OPERATION
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs. They
will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for playback
to start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or the
compatibility of the CD compilation software. Manufacturer is not responsible for the playback
quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a malfunction.
1. Press the POWER button to turn on the unit power. Slide the FUNCTION SWITCH to CD
position, the display will show “- - -“ briefly. If no CD has been loaded in the CD
compartment, LED display will change to show “
no”.
2. Grip the “OPEN” mark on the CD Door and pull gently to open it.
3. Carefully load an audio CD with its label side outward in the CD compartment then gently
close the CD door.
4. The player will start reading TOC of the disc, total number of tracks on the CD will appear
on the LED DISPLAY after a few seconds.
9
5. Press the PLAY/PAUSE
button to start playing.
6. Adjust the MASTER VOLUME knob to obtain the desired sound.
7. To temporarily stop playing, press the PLAY/PAUSE
be flashing. To resum e pl ayin g, p res s the PLA Y/PA USE
Button. The play/pause indicator will
Button again. The play/pause
indicator will be solid on.
8. You can sk ip up or down to a sp ecific track n umber by pressin g the SKIP B ACKWARD
button or SKIP FORWARD
button. The LED Display will indicate the correct track
number selected.
9. To locate a particular section within a track, press and hold the
/ button until the
section is found.
10. To stop playing, press the STOP
button
11. Press the POWER button to turn off the unit after listening.
+10 button control
Press the +10 button once to advance the music search by increment of 10 tracks.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT/PROGRAM BUTTON once, the REPEAT
INDICATOR will flash in LED display. The track will continue to play until the repeat function is
turned off.
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.
PROGRAM OPERATION
This function allows the tracks to be played in a programmed sequence.
NOTE: Programs can only be set in STOP mode.
1. In CD stop mode, press REPEAT/PROGRAM button, the PROG indicator will light and
Program Number “P01” will show on LED display.
2. Press the SKIP
or button to select the desired track. The track number “1” (001
for MP3 CD) will blink on the LED display to prompt for input.
3. Press the PROGRAM button to confirm the selection. Program Number advances to “P02”.
4. Repeat step 2 to 3 to program up to maximum of 20 tracks.
5. When maximum of 20 tracks have been programmed, the LED display will show “FUL” to
indicate program is full.
6. When you have completed programming, press the PLAY/PAUSE
button to start
playing. Both PROG and Play/Pause indicators are lighting steadily.
7. To cancel programmed play, press the STOP
button twice. PROG indicator goes off.
USING TREBLE/BASS/BALANCE CONTROL KNOBS
TREBLE: Adjust TREBLE level of music playback.
BASS : Adjust BASS level of music playback.
BALANCE : Adjust BALANCE for balance left and right speaker.
10
USB OPERATION
The unit is designed to play MP3 files stored in the USB flash-drive. If the files on the USB
device do not conform to the standard, they may not be played.
1. Slide the FUNCTION switch to CD/USB position. Press and hold the CD/USB/PAIR/
button until USB mode indication “USB” shows on LED display and USB indicator flashing.
2. Insert your USB flash-drive into the USB port, unit st ar ts to read the USB flash-drive.
Notes:
1.) USB supports flash drive capacity up to 32 GB maximum.
2.) Due to various USB flash drives in the market, please always fold down the carrying
handle before insert USB flash drive into the USB port.
3.) When carrying this unit, be sure your USB flash drive is not taller than the space under
the carrying handle to a v oid da ma gi ng .
3. After reading the USB flash-drive, the unit will display the total number of files on the flashdrive.
USB playback
After reading the USB flash-drive, press the PLAY/PAUSE
button once, the first track/file
on the USB flash-drive will be played back. The “USB” and “PLAY/PAUSE” indicators will be
solid on during playback.
Play/Pause Control
To temporarily stop playing, press the
PLAY/PAUSE indicator will be blinking. Press the
button, music playback will be paused and the
button again to resume playback.
Stop playback
To stop playback, press the STOP
button on the unit. The total number of tracks/files on the
USB flash-drive will be shown on the LED display.
Skip track
During playback, press the SKIP backward
or forward buttons to skip to the previous
or next track/file.
High-speed music search
During playback, press and hold the SKIP forward
or backward buttons to search
through the current track/file at high speed in forward or backward directions. When the SKIP
buttons are released, normal playback speed will be resumed immediately.
+10 control
Press and hold the +10 button to advance the music search by increments of 10 tracks.
Press the +10 button once to advance to the next folder on the USB flash-drive.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT/PROGRAM BUTTON once, the REPEAT
INDICATOR will flash in LED display. The track will continue to play until the repeat function is
turned off.
11
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.
Programmed USB playback
This unit can be programmed to play up to 20 tracks/files in USB mode.
1. Plugged in your flash-drive into USB port, make sure unit is in stop mode.
2. Press REPEAT/PROGRAM button, the PROGRAM Indicator will light and program
Channel Number "P01" will show on the LED DISPLAY.
3. Press
or button to select the track to be programmed. The track number “001”
will blink on the LED DISPLAY to prompt for input.
4. Press the PROGRAM button again to store selection. The Program Channel Number will
change to “P02”.
5. You may repeat steps 2 - 3 to program as many as 20 tracks. When the memory full, “FUL”
will show on the LED DISPLAY.
6. Press the PLAY/PAUSE
7. Press STOP
8. Press the
button once to stop playback.
button to resume programmed play.
9. To cancel programmed play, press the STOP
button to start the programmed play.
button twice.
BLUETOOTH OPERATION
PAIRING A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
The Bluetooth feature enables you to stream and play the digital music on your Bluetooth
enabled device to your unit.
1. In power on mode, slide the FUNCTION switch to Bluetooth
indicator will flash.
2. The unit will start in auto connection mode and search for a previously paired device that is
active and in range (30 feet/10 meters). If found, a brief welcome melody will be heard and
Bluetooth indicator will change to solid on. If no active device is found, the unit will switch
to interactive pairing mode and the Bluetooth indicator keeps flashing.
3. To establish a new link, turn on the Bluet ooth funct ion of your Bluetooth enabled device
and enable the search or scan feature to find “SB2149” in the list of discoverable
Bluetooth devices. Select the “SB2149” from your available device list when it appears on
its screen and a brief welcome melody will be heard if pairing and connection is
successful. If you are asked fo r a pa s swor d , e n te r “0 000”.
4. If no successful pairing and connection is made within 5 minutes, the unit may enter
manual pairing mode. You need to press and hold the PAIR button until Bluetooth indicator
flashes to initiate a pairing/connecting request to a new or old Bluetooth enabled device.
Follow step #3 to complete the process.
5. After successfully pairing and connecting your device with SB2149, the unit will emit a brief
welcome melody and the Bluetooth indicator will change to solid on. You can now play
music from your Bluetooth enabled device wirelessly to the SB2149.
6. If you want to connect the SB2149 to another new external Bluetooth enabled device while
paired with another device, press and hold the PAIR
disconnect the existing connection. The unit will emit two short beeps and Bluetooth
12
position, the Bluetooth
button for few seconds to
indicator will change to flash. Repeat steps #3 to #4 above to make a new link.
7. Rotate the VOLUME CONTROL on the top panel to increase the listening volume
gradually until a comfortable listening level is reached.
8. Press the PLAY/PAUSE
9. Press the SKIP FORWARD
BUTTON to control play/pause.
BUTTON to skip to next song and SKIP BACKWARD
BUTTON to skip to previous song.
Notes:
I f you cannot pair the unit with your Bluetooth enabled device, try solving the problem by
turning the unit power off, then power on, and then starting the pairing process again.
The Bluetooth function of the unit will remain paired unless the paired device goes out of
range of 30 feet (10 meters). If the broken link is re-established within 20 seconds, the
SB2149 will reconnect to the current paired device automatically. Otherwise you will need
to make a manual connection again later.
You may need to turn off the Bluetooth function of the paired external device first before
make a new link.
Refer to manual of your smartphone or external Bluetooth enabled device for correct
Bluetooth operation instructions since it may vary from model to model.
If your Bluetooth enabled device does not support A2DP , it will not play the music through
the SB2149 system even after it is paired and connected successfully.
If you are pairing and connecting your personal computer to the SB2149 using Bluetooth,
you may need to set the SB2149 as your computer’s default sound device.
RE-LINKING TO A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
Even if your smartphone or Bluetooth device is already paired with the SB2149 and with both
Bluetooth functions turned on, they can become unlinked at some point due to intentional
manual disconnection or undesirable external signal interferences or over-range for more than
10 seconds. If this happens, the unit will emit two short beeps. You can re-link them and
resume play by:
1. Select “SB2149” from the device list on your smartphone or Bluetoot h device. The SB 2149
should re-link to your Bluetooth enabled device within 5 seconds.
2. Tap the play button of the music player on your Bluetooth enabled device to resume
playback.
AUX IN OPERATION
You can play other m usic sources (iPod, MP3 or other digital audio pl ayers) through the
speakers of the unit by connec ti ng the AU X IN J AC K to your ext er nal p la yer ’s audio out j ack or
headphone jack.
1. Plug one end of a 3.5mm audio cable (not included) into the AUX IN JACK and the other end
of the cable to the headphone jack of your digital audio player.
2. Slide the FUNCTION switch to the AUX IN position.
3. Turn on and start playing the external device you plugged into the AUX IN JACK.
4. Slowly adjust both the volume controls of your unit and the external device until you reach a
comfortable listening level.
5. Turn off both the external audio pla yer and this unit after use. Unplug the audio cable from
AUX IN jack
Notes:
13
• If you connect the unit to the Line-Out Jack of your external device, you only need to
adjust the VOLUME CONTROL of your unit. If you connect to the Headphone Jack of your
external device, you may need to adjust both the volume controls of your external device
and the unit to obtain the desirable listening level.
• Remember to turn off the unit when you have finished listening. Don't forget to switch off
the power of your external audio device as well.
USE HEADPHONES (NOT INCLUDED)
Inserting the plug of your stereo headphones (not included) into the headphone jack locates on
the top panel will enable you to listen in private. When using headphones, the speakers will be
disconnected.
Read this Important Information before Using Your Headphones
1.) Avoid extended play at very high volume as it may impair your hearing.
2.) If you experience ringing in your ears, reduce the volume or shut off the unit.
3.) Keep the volume at a reasonable level even if your headset is an open-air type designed to
allow you to hear outside sounds. Please note that excessively high volume may still block
outside sounds.
LED LIGHT SHOW
- To turn off the LED light show, press and hold the LIGHT SHOW button.
- To turn on the LED light show, press and hold LIGHT SHOW button again.
Note: If the brightness is glaring, turn on room lights or turn off LED light show.
RESETTING THE UNIT
In case of malfunction due to electrostatic discharge, reset the unit by press and hold POWER
button 8 seconds to reset the unit. The unit will power down and power up to normal mode.
CARE AND MAINTENANCE
1. Do not subject the unit to excessive force, shock, dust or extreme temperature.
2. Do not tamper the internal components of the unit.
3. Clean your unit with a dry cloth. Solvent or detergent should never be used.
4. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
Keep your unit away from heating appliances and sources of electrical noise such as
5.
fluorescent lamps or motors.
If drop-outs or interruptions occur in the music during CD play, or if the
6.
CD fails to play at all, its bottom surface may require cleaning. Before
playing, wipe the disc fr om the center
cloth.
CLEANING THE UNIT
To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning.
The finish on the unit may be cleaned with a dust cloth and cared for as other furniture,
Use caution when cleaning and wiping the plastic parts.
If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or
polish sprays on the cabinet.
If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a soft
cloth slightly dampened with a mild soap and water solution. Never use abrasive cloths or
polishes as these will damage the finish of your unit.
outwards wit h a good sof t cleaning
14
r
g
rscr
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
TROUBLE SHOOTING GUIDE
Symptom
The unit does not
respond (no power)
Possible Caus
The unit is disconnected from
the AC outlet.
e Solution
Reconnect to the AC o utlet.
Unit is ON but there is
low or no volume
AM/FM no sound
Bluetooth No Sound
Noise or sound
distorted on FM
broadcast
The AC outlet has not power.
Volume set too low.
Unit not in Radio mode.
Unit is not linked w it h your
Bluetooth enabled device.
Unit placement out of range.
Your Bluetooth enabled device
Volume set too low.
Station not tuned p
operly. Fine tune the FM broadcast
FM: telescopic antenna is not
fully extended.
AM: Internal antenna is not
positioned correctly.
Try the unit on anot her
outlet.
Slowly rotate the MASTER
VOLUME knob to increase
the volume level.
Slide FUNCTION switch to
select RADIO.
Go through “Bluetooth
Operations” proc ess to link
the speakers.
Relocate the unit within
Bluetooth operating
range (30 feet)
Increase Volume level of
your Bluetooth enabled
device.
station.
Fully extend the FM
telescopic antenna.
Reposition the unit until the
best reception is obtained.
USB player will not
play
CD player will not
play
CD skips while
playing
Unit not in USB function mode.
Can’t read USB data
Unit not in CD function mode.
CD is installed incorrectly.
If the CD is self-compiled, the
media used may not be
compatible with the player.
Disc is dirty o
atched.
15
Slide FUNCTION switch to
CD/USB and long press the
CD/USB/PAIR/
button
until USB indicator is
flashing.
USB flash drive fault,
chan
e another good one.
Slide FUNCTION switch
to select CD.
Insert CD with label side
outward.
Use better quality blank
media and retest .
Wipe CD with clean cloth or
use another disc.
r
mittent sound
Inte
from CD Player
Dirty or defective disc.
Dirty pick up lens.
Player is subject to excessive
shock or vibration.
Clean or replace the
defective disc.
Use a CD-lens cleaning
disc to clean the lens.
Relocate the player away
from shock or vibration.
Sound is distorted Volume level is set
Decrease the volume.
too high.
Sound source is distorted. Try a different sound
source.
If you are using an
external sound source
like older generation of
iPod, try reducing the
output volume on the
device itself. Also try
turning bass boost OFF
or change the EQ setting.
Unit gets warm
after extended
This is normal.
Turn the unit off for a period
of time or lower volume
play at high
volume
SPECIFICATION
Radio Frequency Range : AM: 530 – 1710KHz
FM: 88 – 108 MHz
Audio Output Power : 2 X 5W (RMS)
Tweeter : 2 x 1.5 inch / 6 ohms
Woofer : 2 x 4 inch / 6 ohms
Bluetooth : V4.2 + EDR
USB : Support USB device up to 32GB
Power Source :
AC Adapter : Input AC 120V~ 60Hz
Output DC 12V
Built-in Rechargeable Lithium Battery : DC 7.4V
, 2200mAh
Due to continuing improvement, the features and the design are subject to change without
notice.
1.5A
16
Loading...
