JT1076
USER’S GUIDE
DISCOBALL BLUETOOTH & CDG
KARAOKE
V 1.0
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
0
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULL Y INSERT.
WARNING: To reduce the risk of fire or electric
shock,do not expose this apparatus to rain or
moisture.
AVERTISSEMENMTY: Pour réduire le risque
d’incendie ou de choc électrique, ne pas exposer cet
appareil sous la pluie et l’humidité.
CAUTION: Use of controls or adjustments or
performance of procedures other than those
specifed may result in hazardous radiation exposure.
WARNING: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit
and surface to protect the surface
WARNING: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit
and surface to protect the surface.
WARNING: Use of this unit near florescent lighting
may cause interference regarding use of the remote.
If the unit is displaying erratic behavior move away
from any florescent lighting, as it may be the cause.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the same or
equivalent type.
PRÉCAUTION: Danger d’explosion si les piles sont
remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
WARNING: There is a danger of explosion if you
attempt to charge standard Alkaline batteries in the
unit. Only use rechargeable NiMH batteries.
WARNING: The remote control’s button cell battery
contains mercury. Do not put in the trash, instead
recycle or dispose of as hazardous waste.
Warnings and Precautions
WARNING: Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices
in your area. They should never be incinerated since
they might explode.
WARNING: Shock hazard - Do Not Open.
AVIC: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains plug is used as disconnect device and it
should remain readily operable during intended use.
In order to disconnect the apparatus from the
mains completely, the mains plug should be
disconnected form the mains socket outlet
completely.
La prise du secteur est utilisé pour déconnecter le
système.
La prise du secteur ne doit pas être obstruée ou doit
être facilement accessible pendant son utilisation.
Pour
être complètement déconnecté de l’alimentation
d’entrée, la prise doit être débranchée du secteur.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning fash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated "dangerous
voltage" within the product's enclosure
that may be of suffcient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
This product utilizes a Class 1 laser to
read Compact Discs. This laser
Compact Disc Player is equipped with
safety switches to avoid exposure
when the CD door is open and the
safety interlocks are defeated. Invisible
laser radiation is present when the CD
Player’s lid is open and the system’s
interlock has failed or been defeated. It
is very important that you avoid direct
exposure to the laser beam at all
times. Please do not attempt to defeat
or bypass the safety switches
.
1
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has t wo blades
and a third grounding prong. The wide blade
or the third prong are provided for your safet y.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specifed
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
"This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your body."
Important Safety Instructions
FCC Warning
NOTE: This equipment has been tested and found to
comply or has
Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to rad i o
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help .
Additional Warning
The apparatus shall not be exposed to dripping
or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the
cart/apparatus combination to
avoid injury from tip-over.
or splashing and that no objects flled with liquids,
such as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux
écoulements ou aux éclaboussures et aucun
objet ne contenant de liquide, tel qu’un vase, ne
doit être placé sur l’objet.
Main plug is used as disconnect device and it
should remain readily operable during intended
use. In order to disconnect the apparatus from
the mains completely, the mains plug should be
disconnected form the mains socket outlet
completely.
La prise du secteur ne doit pas être obstruée ou
doit être facilement accessible pendant son
utilisation. Pour être complètement déconnecté
de l’alimentation d’entrée, la prise doit être
débranchée du secteur.
Battery shall not be exposed to excessive heat
such as sunshine, fire or the like.
Les piles ne doivent pas être exposées à de forte
chaleur, tel qu’à la lumière du soleil, au feu ou
autres choses de semblable.
Caution marking is located at the rear or back of
the apparatus.
Attention marquage est situé à l’arrière ou à
l’arrière de l’appareil.
The marking information is located at the rear or
back of apparatus.
Les informations de marquage est situé à
l’arrière ou à l’arrière de l’appareil.
been dropped with the limits for a
2
Contents
Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Feature / Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- Features
- Included
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Placing Tablet / Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- Connect Power Adapter
- Battery Operation
Connect Ext. Device & Sound From Main Unit Speaker . . . . . . .
- LINE IN (AUX In / AUDIO In)
Using CD+G , CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- Loading a Disc
1
2
3
4
5
6
7
8
8
9
- Playing a Disc
- Repeat Function
- Programming a Disc up to 20 tracks
Connecting Bluetooth to Your Smartphone / Tablet. . . . . . . . . .
Connecting to a Television / DVD / Ext. Device
. . . . . . . . . . . .
- Composite Video Output
- RCA Audio Output
Using Microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using AVC and ECHO . . . . . . . … . . . . . . . . . . . . . . . . . . . . . . .
- AVC
- ECHO
Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
10
99
11
12
12
3
Feature
Feature / Included
• CD player: Plays CD+G, CD, CD-R/RW Discs
• Disco ball Lights On The Top and The Handle
• Bluetooth wireless stereo audio streaming
• Support A2DP Profiles for most smart phones / laptops
• Microphone Volume Controls
• Echo Control
• AVC (Auto Voice Control) Control
• Red LED display
• Microphone Jacks, 6.3mm x2·
• Composite video output
• RCA audio output
• Line in jack 3.5mm (Aux input / Audio input)
• Built-in speakers
• Power: Requires AC power adapter
Included
• Discoball Bluetooth & CDG Karaoke Unit
• Microphones
• RCA audio/video cable
• AC power adapter
• User Manual
• CDG disc
Discoball bluetooth & CDG Karaoke Unit
4
FRONT VIEW
Introduction
DISPLAY & INDICATOR
REAR VIEW
5
1. CRADLE: Place mobile phone
2. MIC Inputs : Mic 1 and Mic 2 input jack
3. SOURCE: Slide to select Line in / BT mode, CDG (DISC) mode and unit off.
4. MIC VOLUME Dial: Rotate to adjust the volume from the MIC input.
5. ECHO Dial: Rotate to adjust echo sound effect.
6. CD DOOR
7. OPEN: CD door open area. Open the door to install disc
8. A.V.C Dial: Turn to adjust the Voice control.
9. MASTER VOLUME Dial: Rotate to adjust the main volume sound level.
10. DISC LIGHT Switch: Slide this switch to turn on / off Disco Ball Lights.
11. MIC HOLDER: Place Microphone
12. SPEAKER: Unit Speaker location
13. STOP Button: Press to stop a disc playing.
14. PROGRAM Button: Press to program a loader disc to play tracks in
specified order.
15. REPEAT Button: Press repeatedly to set the current track or entire disc to
repeat
16. DISPLAY: Show disc tracks number and current operation.
17. SKIP/SEARCH(Forward): Press to skip next tracks on loader disc. Press
and hold to fast-forward the current track on a loader disc.
18. PLAY / PAUSE / PAIR Button:
In CD mode, press to play or pause a loader disc.
In BT mode, press to connect another BT device.
19. SKIP/SEARCH(Back): Press to skip previous tracks on loader disc. Press
and hold to fast-rewind the current track on a loader disc.
20. ON Indicator: Will be light when unit turn on.
21. REPEAT Indicator: Will be flash / light when REPEAT function turn on.
22. PROG(Program) Indicator: Will be light / flash when program mode turn on.
23. PLAY/PAUSE Indicator: Will be light / flash when disc playing.
24. DC INPUT Jack: Connect power adapter for AC power.
25. VIDEO OUT Jack: Connect to TV video input.
26. AUDIO OUT R (Line out / Aux out) Jack: Connect to external device audio
input R.
27. DISCO BALL: Different LED light effect.
28. AUDIO OUT L (Line out / Aux out) Jack: Connect to external device audio
input L.
29. LINE IN (Aux in / Audio in): Connect to external device audio output.
6
Placing Tablet / Mobile
7
)
Connect Power Adapter
Setup Power
Plug the included AC adapter into the standard AC power outlet to power the
UNIT. Connect small end to DC INPUT jack of main unit. After adapter
connection, Slide the SOURCE selector to LINE IN / BT or CD+G position to turn
on the unit and put the OFF position to turn off the unit.
Connect Ext. Device & Sound From Main Unit Speaker
LINE IN (AUX In / AUDIO In
To connect a MP3 Player or other Audio Device you will need a 3.5mm Auxiliary
Cable.
1. Connect a 3.5 mm Auxiliary Cable to the LINE IN jack at the rear side of unit
and to the Audio Output or Phones on the audio device you wish to play.
2. Slide the SOURCE selector of the Unit to LINE IN position.
3. Turn on both units.
4. After the connection, the external device will
sound from speakers of your unit.
Please note:-
unplug it
.
If not use this function, please
8
Loading a Disc
1. Power on by slide the SOURCE Selector to CD+G position.
2. Pull out the CD DOOR by DOOR OPEN AREA.
3. Load a disc into the compartment with the printed side facing you.
4. Gently close the CD DOOR. The CDG PLAYER begins to read the disc.
The Display will display the total number of tracks.
5. Press PLAY/PAUSE button to play disc. (If no disc is loaded, “No” will be
displayed).
Using CD+G, CDs
Playing a Disc
1. Follow the instructions for Loading a Disc.
2. Press the PLAY/PAUSE button to begin playing the loaded disc. The
PLAY/PAUSE indicator will light.
3. Rotate the MASTER VOLUME dial to select the sound level.
4. To temporarily stop playing, press the PLAY/PAUSE button once (PAUSE
indicator will light). To resume play, press the PLAY/P AUSE button one more.
5. Press SKIP/SEARCH buttons to skip between next or previous tracks.
6. Hold the SKIP / SEARCH buttons to fast search through the track.x
Please note:-
7. Connect the VIDEO OUT jack to TV, the lyrics text will show on TV.
8. Press the STOP button to stop playing.
The fast-forward / fast-rewind functions will not work for CDG discs
.
Repeat Function
1. Follow the instructions for Loading a Disc and Playing a Disc.
2. When disc installed, press the REPEAT button once and
the
REPEAT
indicator flash. The unit will play the current track repeatedly.
3. When disc installed, press the REPEAT button twice and REPEAT indicator
will be light. The unit will play the entire disc repeatedly.
4. To cancel the repeat function: press the REPEAT button repeatedly the
REPEAT indicator light off or press the STOP button twice to stop.
tracks
1. When disc playing, press the STOP button to stop mode.
2. Press the PROGRAM button and the program (PROG SET) indicator will
light.
3. Press the SKIP / SEARCH buttons to select the track from the loaded disc
you wish to play first.
4. Press the PROGRAM button to confirm.
5. Repeat steps 3 and 4 to program to play in a specified order.
6. Press the PLAY button to start the program playing.
7. Press the STOP button twice to cancel a program.
9
Connecting Bluetooth to Your Smartphone / Tablet
1. Slide the SOURCE button to BT position to connect your external Bluetooth
device and the display will show Bt and flash.
2. Set the Bluetooth function of your external device to ON and begin
searching for devices.
Note: The effective distance between your external device and this
apparatus is 10 meters (30 feet).
3. Once “Karaoke” appears on the paired device list of your external device,
select it.
Notes: If cannot connect, press PAIR button to reconnect again.
4. If you are asked for a password, enter “0000”
5. When both devices are successfully connected (BLUETOOTH indicator will
light), now you are ready to play music wirelessly from your device.
6. Press the PLAY button of external Bluetooth device to start music
playback.
7. Press the NEXT / PREV of the unit or external Bluetooth device to switch
between music tracks.
Note: After initial pairing, the unit will stay paired unless unpaired manually
by the user or erased due to a reset of the device. If your device should
become unpaired of your find it is unable to connect, repeat the above
steps or press & hold the PAIR button again.
Composite Video output
Connecting to a Television / DVD / Ext. Device
Require an RCA video cable.
1. Plug the included RCA audio/video cable into the VIDEO OUT and a
composite video input on a television.
2. Adjust the television to the correct input setting.
3. When playing CDG discs, the UNIT will output written lyrics to the
connected television
RCA Audio Output
Requires an RCA audio cable.
1. Plug the included RCA audio/video cable into the AUDIO OUT and a
RCA audio input on a television or stereo system.
2. Adjust the television or stereo system to the correct input setting.
3. When playing the disc, the Unit will output audio to the connected
television or stereo system. Use the external device to control the output
sound level.
10
Using Microphone
Requires a microphone (included)
1. Plug the microphone (see below figure) into the MIC 1 INPUT or MIC 2
INPUT.
2. Slide the ON /OFF switch of
3. Use the MIC
VOLUME
dial of KARAOKE UNIT to adjust the volume of audio
MICROPHONE
,
sound from the microphone.
11
Using A VC and ECHO
AVC
The AVC (Automatic Voice Control) can be activated by the A.V.C button. The
vocals on the multiplex recording will be muted when the singer starts to sing
through the microphone. When the singer stops singing the vocals will resume
to normal.
ECHO
Adjust the ECHO dial of Karaoke System to enhance your voice for a concert
hall effect.
AC Power
Adapter Connect DC Jack
CD Player
Specification
Use included adapter
AC~ Input 120 / 60 Hz , DC Output 5V , 1.5A
Support
CDs and CDG disc
Master Power Output
Loud Speakers Spec
Specifications are typical, individual units might vary. They are subject to continuous
improvement without notice and without incurring any obligation.
2W x 2 RMS
3 Inch, 3 Watt , 4 Ohm
12
Loading...
