Modern 6012A, 6012AR Users Manual

CR6012A

Audiophile USB Turntable

Instruction Manual

910-101051-0010-200

www.crosleyradio.com

General

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Troubleshooting

There is no Power

1 Make sure unit is plugged in correctly.

2 The unit is not turned on: press the POWER

button to ON Position.

No Sound on Wireless Speakers

1 Make sure Transmitter ON/OFF switch on the

back of the turntable is in the ON position

2 Make sure the wireless speakers are turned

on.

3 Check that the distance between the two is 50

feet or less and that there is a clear line of sight
between the turntable and speakers.

4 Remove obstructions to minimize interference.

5 If using batteries to power the speakers, replace

the batteries to ensure they are good.

6 Make sure the wireless speakers are turned on

by rotating the Volume ON/OFF Knob clockwise.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION

The lighting flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert user to
the presence of uninsulated
"dangerous voltage" within
the product's enclosure
that may be of sufficient
magnitude to constitute
risk of electric shock
to persons.

CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO
USER - SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.

Specification

Power source : AC Adaptor AC120V~60 Hz /
Power Consumption : 5W(Turntable),15W(Speaker/each)
Antenna : Built-in antenna for 916M TRANSMTTER

1

Speed : 33
Speaker : 4 inch 8 ohm 5W
Audio output : 3W
Replacement Needle : NP4
RF Transmtter Freq

uency : 916MHz

/3,45 RPM

The exclamation point
within an equilateral
triangle is intended to
alert user to the
presence of important
operating and
maintenance (servicing)
instruction in the
literature accompanying
the appliance.

DC 9V 400mA

* DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

9
