Modern 6002A Users Manual

CR6002A

Revolution

Instruction Manual

910-101011-0020-200

www.crosleyradio.com

General

Transporting

To safely transport your Revolution, follow the
steps below to prevent damage to your unit.

1 Place protective needle cover over needle.
2 Place the 45rpm adapter on the revolution as

shown below

3 Move the TONE ARM from the ARM REST

and position it over the 45rpm adapter and
align the TONE ARM with the grooves in the
45rpm adapter as shown below.

4 Gently press TONE ARM into grooves on

45rpm adapter.

Troubleshooting

There is no Power

1 Make sure unit is plugged in correctly.
2 Replace batteries
3 The unit is not turned on: press the POWER

button to ON Position.

There is no Sound

1 Slide the VOLUME CONTROL to raise volume.
2 Check to make sure headphones are not

plugged into the unit.

No signal on FM Transmitter

1 Make sure TRANSMITTER SWITCH is on the

ON position.

2 Make sure the unit and the FM tuner are set

to the same frequency.

3 Check that the distance between the two is 20

feet or less.

4 Remove obstructions to minimize interference.
5 Try moving the Revolution closer to the FM

tuner to reduce signal interference.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lighting flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert user to
the presence of uninsulated
"dangerous voltage" within
the product's enclosure
that may be of sufficient
magnitude to constitute
risk of electric shock
to persons.

CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO
USER - SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.

Specification

Power source : AC Adaptor AC120V/DC 9V 600mA
Power Consumption : 6W
Antenna : Built-in antenna for FM
Speed : 33 1/3,45 RPM
Speaker : 28 x 40 mm 8ohm 2W
Audio output : 600mW
Replacement Needle : NP4
FM

Transmtter Frequency : 88.1MHz / 89.9MHz

* DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

The exclamation point
within an equilateral
triangle is intended to
alert user to the
presence of important
operating and
maintenance (servicing)
instruction in the
literature accompanying
the appliance.

TRANSMTTER

5 Close the LID and check to make sure it is

secure.

9
