Model Engines MIG-15 Instruction Manual

Contents

Guarantee/Warranty .......................................................................... 2

Introduction ........................................................................................ 3

Safety Instructions for Charging and Using Li-Poly Batteries ........... 3

Safety Precautions ............................................................................ 3

General Safety Statements ............................................................... 3

Main Specications............................................................................ 4

Required but not included.................................................................. 4

Illustration of Assembly ...................................................................... 4

Preparation before ight .................................................................. 10

Recommended control throws for Mig-15........................................ 10

Check before ight........................................................................... 10

Flight Adjustment ............................................................................. 10

J Perkins Distribution Ltd declares that this remote controlled model is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the declaration of conformity can be obtained from
J Perkins Distribution Ltd, Ashford rd, Lenham, Kent. ME17 2DL

WEEE Disposal

Do not dispose of this product with other household waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equip­ment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natu­ral resources and ensure that it is recycled in a manner that protects human health and the environment. For more
information about where you can drop off your waste equipment for recycling, please contact your local council, your
household waste disposal service or the shop where you purchased the product.

Guarantee/Warranty

J. Perkins Distribution Ltd guarantee this product to be free of manufacturing and assembly defects for a period of
one year from time of purchase and Model Engines (Aust.) Pty. Ltd. is for 30 days. This does not affect your statutory
rights. This warranty is not valid for any damage or subsequent damage arising as a result of a crash, misuse, modi­cation or for damage or consequential damage arising as a result of failure to observe the procedures outlined in this
man u al. Operation of this model is carried out entirely at the risk of the operator. Please note that, whilst every effort
is made to ensure the accuracy of instructions and material included with this product, mistakes can occur and neither
J. Perkins Distribution Ltd/Model Engines (Aust.) Pty. Ltd. nor it’s distributors will be held liable for any loss or damage
arising from the use of this model or for any loss or damage arising from omissions or inaccuracies in the associated
instructions or materials included with this product.

We reserve the right to modify the design of this product, contents and manuals without prior notication.

© 2010 J Perkins Distribution Ltd, Lenham, Kent, UK ME17 2DL. www.jperkinsdistribution.co.uk
Model Engines (Aust.) Pty. Ltd., Noble Park, Victoria 3174, Australia. www.modelengines.com.au.
All rights reserved. E&OE.

2

Introduction

Thank you for purchasing the Mig-15. This model is designed for the intermediate to advanced

yer. The model is radio ready and includes everything that you need to assemble and y your

Mig-15, except for the radio transmitter and receiver. Please read the following instructions care­fully, assembly is easy and should only take an hour or so.

WARNING – THIS IS NOT A TOY! Radio controlled model aircraft are capable of inicting seri-
ous injury and/or property damage if not assembled, operated, and maintained in a competent and
safe manner. If you are not already experienced with radio controlled models, we strongly suggest

that you nd an experienced modeler to assist you.

In the UK, we recommend you observe the British Model Flying Association (BMFA) safety code at
all times, which can be found at the following address: http://www.bfma.org
In Australia, please contact your hobby retailer or the Model Aircraft Association of Australia
(MAAA)

Completely read through this manual before starting construction.

Safety Instructions for Charging and Using Li-Poly Batteries

• Do not put the battery on, or near anything, that can catch re when charging.

• Always charge the battery on a non-ammable base i.e. a metal tray.

• Do not disassemble the battery.

• Do not short-circuit the battery.

• Do not use, or leave, the battery nearby a re, stove or heated place.

• Do not immerse the battery in water or seawater, do not get it wet.

• Do not charge the battery near a re or under the blazing sunlight.

• Do not drive a nail into the battery, strike it with hammer or apply excessive weight to the battery.

• Do not impact or throw the battery.

Safety Precautions

1. Please do not change any part of the plane. You will be responsible for any damages caused by these changes.

2. Your ying area should be wide-open and free of obstacles. Never y near highways, railways, airports, power

lines or in residential areas.

3. To avoid personal injury, never y your model near or facing people, or throw the plane in their direction.

4. Do not y your model outdoors in winds over 3MPH.

5. Never dispose of batteries or parts of your model in a re as it could lead to an explosion and personal injury.

General Safety Statements

1. This aircraft is not a toy. It has been designed for the experienced modeller and pilot. You are responsible not to
cause damage to other’s personal property or cause personal injury.

2. This model is designed for use by modelers age 14 and over. This model is not recommended for unsupervised
modellers under 16 years of age.

3. Never use the model or associated electronics in damp or rainy conditions.

4. This material from which this model is made can be damaged by excessive heat. Keep your model away from

excessive heat or out of direct sunlight for extended time periods or it can become warped and affect the ight

performance of the model.

5. Never leave the battery connected while the model is unattended. Accidental operation can occur and cause
personal injury.

6. Before operating the model, make sure to turn on the radio system and check the functions before beginning

ight.

7. Always make sure the throttle at the transmitter has been moved to the low or off position before connecting the
motor battery.

3

Main Specications

Wingspan: 28” (711mm)
Fuselage length: 28” (711mm)

Flight weight: 18-1/2 oz. (524g)

64mm EDF
4300KV out-runner brushless motor.
3-cell, 11.1V, 1600mAh 20C lipo battery genuine Deans Ultra Connector
30A ESC w/ BEC and genuine Deans Ultra Connector
3pcs. 9g Servo
No Landing gear

Required but not included

Radio System with minimum 3-channel Transmitter and Receiver
Battery charger capable of charging a 3-cell Lipo battery

Illustration of Assembly

1. Open box and carefully unwrap all parts.

2. Apply a small amount of epoxy to the

right stabilizer 3. Put into position on the vertical n.

4
