Moda flame GF101300 User Manual

1

Moda Flame Epila Wall Mounted Ethanol Fireplace ©
Instruction Manual

Epila Wall Mounted Ethanol Fireplace

User’s Manual

Model: GF101300

2

Moda Flame Epila Wall Mounted Ethanol Fireplace ©
Instruction Manual

Part List:

A. Fireplace Flame 1pc
B. Firebox base 1pc
C. Tempered Glass 1pc
D. 1.5L double-layer Burner 2pc
E. Mounting bar unit 1pc
F. Control tool 1pc
G. Screws (5*30mm) 2pcs
H. Wall plugs (φ8*40mm) 2pcs
I. Screw (M6*10) 4pcs
J. Screw cap 4pcs
K. Stainless steel stud 4pcs
L. Instruction manual and safety instructions.

A. B.

C. D.

3

Moda Flame Epila Wall Mounted Ethanol Fireplace ©
Instruction Manual

E. F.

G. H.

I. J.

K.

4

Moda Flame Epila Wall Mounted Ethanol Fireplace ©
Instruction Manual

Assembly Instructions:

Unpack the fireplace and accessories. Check the content for completeness and
any damages incurred in transit. Keep children away from the packing.

The fireplace must only be installed on a solid wall of non-flammable material

1. Assemble the fireplace base and glass onto the back plate with solid studs
