Mobotix Mx-M26A-6D016, Mx-M26A-6N Installation

1.2

–90°

+20°

Mounting to a Wall

360°

Mounting to a Ceiling

Ethernet USB MxBus

Click!

Variants

Mx-M26A/B*

B036 – B500

Mx-M26A/B*

B016

*Variant Mx-M26B supports MOBOTIX MxBus modules

M26 Allround

Quick Install

32.818-003_EN_04/2018

Standard Delivery M26

1.15

1.14

1.13

1.10, 1.11, 1.12

1.9

1.8

1.1

1.3

1.7

1.4

1.6

1.5

Item Count Part Name

1.1 1 Camera in weatherproof housing, incl. VarioFlex wall mount

1.2 1 Ceiling mount

1.3 1 Sealing for wall and ceiling mount

1.4 1 Lens, installed (standard M14 or B016)

1.5 2

1.6 1 Lens wrench B016 (only for D016/N016)

1.7 2 Allen wrench 5 mm, Allen wrench 2.5 mm

1.8 1 Special Ethernet cable 0.5 m/20", installed

1.9 4 Screw caps for stainless steel fastening screws

1.10 4 Stainless steel wood screws 6x50 mm

1.11 4 Stainless steel washers 6.4 mm dia.

1.12 4 Dowel S8

1.13 2

1.14 1 MicroSD card installed

1.15 1 MiniUSB plug

Lens cover, 1 installed, 1 replacement (not available for lens
B016, cover for B500 not shown, no replacement cover for B500)

Cable lock with bayonet catch (Ethernet patch cable, MiniUSB)

Connection and Initial Operation of the M26

For information on connecting the M26, please see the M25 Camera Manual, section «Network and Power Connection, Additional Cables» (PDF, available
on www.mobotix.com > Support > Download Center > Documentation > Manuals).

Please note that the boot options of this camera have changed compared to its predecessor (see «Boot Options of the M26» on page 2) and the camera
only has one key ("R"). Regarding the rest of the initial operation of the M26 please see the M25 Camera Manual in Chapter 3, «Initial Operation»

Rear (without weatherproof housing)

Wall Mount

Weatherproof

Microphone

Power/Status

Key R

housing

Lens and lens
cover

Recording

Speaker

Ethernet

USB

Pressure vent

MxBus

Retaining screws

Mounting Options of the M26

1. Mounting to a Wall

When installing the M26 on a wall, for example, simply aix the pre-installed

and VarioFlex wall mount included in the delivery with the four supplied
screws and washers.

The camera can be turned or tilted 180° horizontally and 110° vertically
(from –90° to +20°).

2. Mounting to a Ceiling

By exchanging the wall mount for the separately supplied ceiling mount,
the M26 is ready to be mounted to ceilings in just a few easy steps thanks
to the VarioFlex system.

The camera can be turned or tilted 360° horizontally and 110° vertically
(from –90° to +20°).

3. Mounting to Poles (With Accessories)

If you want to mount the camera to a pole with a diameter from 60 to 180 mm,
you should consider using the Pole Mount (MX-MH-SecureFlex-ESWS) made
from white powder-coated stainless steel.

Just like when mounting to a wall, the camera can be turned 180° hor­izontally and tilted 110° vertically (from –90° to +20°).

Installing the M26

1. Drill the holes for the dowels (if required)

Use the drilling template for this step (see
below). Mark the holes for dowels or screws

(blue circles in gure). If required, drill the holes

for the dowels, push them in and cut the cut­out for the cables. Guide the Ethernet cable
and any other cables that are to be connected
through the cut-out.

2. Connect the cables

If you want to connect additional cables
(USB, MxBus), remove the weatherproof
housing as shown in Section «Removing/
Installing the Weatherproof Housing», con­nect the cabling as required and again install
the housing. Plug the pre-installed Ether­net cable into a network socket (e.g., of an
MX-Overvoltage-Protection-Box).

3. Install the camera

Press the wall/ceiling mount and the wall sealing against the mounting
position and align the holes with the holes for the dowels/screws. Insert
the screws with washers and tighten them using a torque of 0.4 Nm. Finally,
press the white covers onto the screw heads.

Removing/Installing the Weatherproof Housing

For certain tasks (e.g., connecting additional wires, exchanging the SD card), you need to remove the weatherproof housing and install it again once you

are nished.

1. Remove the fastening screws at the back

Start by removing the two rubber plugs that
protect the fastening screws. Next, unscrew
the two fastening screws of the weatherproof
housing using the supplied Allen wrench 5 mm
(item 1.7), but do not remove the screws

2. Remove camera from weatherproof hous­ing

Press the camera from the housing by gently
applying pressure on the screws in alternating
fashion from the rear using the long shank of
the Allen wrench. Unscrew the fastening screws
once the camera is free from the housing

3. Complete the tasks

Follow the procedures for the work inside the
housing as described in the M25 Camera Manual
in Chapter 2, «Installation» (e.g., connecting
additional wires, exchanging the SD card).

4. Insert the camera into the weatherproof housing

Start by inserting the camera into the weath­erproof housing. Press the camera back into
the housing and take care not to squeeze and
damage any wires inside the housing.

5. Tighten the retaining screws

Aix the camera in the weatherproof housing

using the two retaining screws.

Finally, push in the two rubber plugs that
protect the retaining screws.

Inserting/Exchanging the SD Card

All camera models can use the integrated MicroSD card (SDHC) to record video data. In order to exchange the MicroSD card, please proceed as outlined
in the following instruction. For information on reliable SD cards, please see the MOBOTIX website www.mobotix.com > Support > Download Center >
Documentation > White Lists in the document MicroSD Card Whitelist for MOBOTIX Cameras.

When replacing the SD card, make sure that recording has been deactivated in the browser (Admin Menu > Storage > Storage on External File Server /

Flash Device; activate recording again in the same dialog aer exchanging the card).

1. Remove the SD Card

Open the camera (see «Removing/Installing the Weath­erproof Housing» ), remove all connectors in the cover
of the inner housing, then remove the cover. Remove

the four screws from the back plate and li o the

back plate. Gently push on the MicroSD card in the
card slot of the camera. The card is released from the
slot and can be removed from the camera.

2. Insert the SD Card

Push the MicroSD card into the card slot as shown,
until an audible and perceptible click indicates it is in
place

. Replace the back plate of the camera housing.

§

§

Initial Operation of the M26

The initial operation starts with connecting the power supply (see section «Network and Power Connection, Additional Cables» in the M25 Camera Manual).

The rst access follows the procedure described in the same manual in the «Initial Operation of the Camera» section. All other tasks require access to the

camera's user interface in the browser. Enter the camera’s IP address in the address bar of the browser (user "admin", password "meinsm"; password must

be changed upon rst login – camera soware V5.1.x and higher).

1. Set installed lens (only when exchanging)

Open the Admin Menu > Hardware Congura-
tion > Lens Conguration dialog and select the
installed lens. This step is required to select the
proper special functions of the installed lens (e.g.,
for wide-angle lenses).

2. Adjust lens focus (if required)

This step is only necessary if the lens has been

installed for the rst time or exchanged. In cameras

with a MX-B016 ("Hemispheric") lens, the lens has
been focused at the factory. Remove the dome
before proceeding.

Check the live image from the camera in the browser. Activate the focusing
aid in the browser (Focusing Aid quick control, Activated value).

Boot Options of the M26

By default, the camera starts as DHCP client and automatically tries to get

an IP address from a DHCP server. To start the camera in a mode dierent

from the default mode, you can activate the boot menu of the camera.

1. Preparing the Camera

• Disconnect the camera's power supply.

• Make sure that you have suitable item such as a paper clip at hand,

but never use sharp or pointed objects!

• Reconnect the power supply of the camera.

2. Activating the Boot Menu

The right LED lights up red 5 to 10 seconds aer

establishing the power supply and will stay on for

10 seconds. Briey press the key by inserting the paper

clip into the hole indicated by the red circle in the

gure. The camera enters the boot menu, ready for

selecting one of the boot options.

The LED now ashes once and repeats the ash signal aer pausing for
one second (the number of ashes indicates the current boot option). To
go to the next boot option, briey press the key again (< 1 sec). Aer the
last boot option, the camera returns to the rst option (LED ashes once).

Carefully turn the lens by hand in clockwise or counter-clockwise direction
until the red area of the focusing aid is as small as possible.

Once the focus is adjusted properly, deactivate the focusing aid again
(Focusing Aid quick control, Disabled value).

3. Save the conguration

In the live image of the browser, select the Manage Settings quick control
and set Store Entire Conguration as value. The camera stores the con-

guration in the permanent camera memory so that the settings will be

applied at the next camera reboot.

LED

ashes

*Only on cameras with audio option and installed speaker.

1 x —

2 x

3 x

4 x

Boot
Option

Factory
Defaults

Automatic
IP Address

Recovery
System

Meaning

This option is not used on this camera
model.

Starts the camera with factory defaults
(factory default IP address, users and
passwords will not be reset).

Starts the camera as DHCP client and
tries to obtain an IP address from a DHCP
server. If a DHCP server cannot be found
or no IP address can be obtained, the
camera starts with its factory default
address.

Starts the camera with the recovery sys­tem, e.g., in order to recover from a failed

update of the camera soware.

Audio

Conrmation*

—

Boing

Boing Boing

Alarm Sound

3. Selecting a Boot Option

Press the paper clip longer (> 2 sec) into the hole. The camera conrms the
selection by ashing rapidly three times. You can now remove the paper
clip. Aer 20 sec, the camera will conrm the selection by playing a sound

according to the table above.

If nothing is selected, the camera will resume its normal boot process

aer a certain time.

Important Notes

Safety Warnings

Notes on Installing:

• This product must not be used in locations exposed to
the dangers of explosion.

• Make sure that you install this product as outlined in Chapter 2,
«Installation» of the corresponding manual. A faulty installation can
damage the camera!

• When installing this product, make sure that you are only using gen­uine MOBOTIX parts and MOBOTIX connection cables.

• Only install this product on suitable, solid materials that provide for

a sturdy installation of the xing elements used.

Electrical installation: Electrical systems and equipment may

only be installed, modied and maintained by a qualied

electrician or under the direction and supervision of a quali-

ed electrician in accordance with the applicable electrical guidelines.

Make sure to properly set up all electrical connections.

Electrical surges: MOBOTIX cameras are protected against

the eects of small electrical surges by numerous measures.

These measures, however, cannot prevent the camera from
being damaged when stronger electrical surges occur. Special care should
be taken when installing the camera outside of buildings to ensure proper
protection against lightning, since this also protects the building and the
whole network infrastructure.

Max. power consumption of attached extension modules:
The power consumption of all attached MxBus modules must
not exceed 2,5 W. When attaching modules to the MxBus
connector and the USB socket, the power consumption of all attached
modules must not exceed 3 W, if the camera is powered by PoE class 3.
If PoE class 2 is used, the power consumption of all attached modules

must not exceed 1 W!

Never touch the lens: Due to the high performance of the
M26, the area of the image sensor can get quite hot, especially
when the ambient temperature is also high. This does not

aect the proper functioning of the camera in any way. For this reason,

the product must not be installed within the reach of persons without the
lens cover.

Network security: MOBOTIX products include all of the nec­essary conguration options for operation in Ethernet net­works in compliance with data protection laws. The operator
is responsible for the data protection concept across the entire system.

The basic settings required to prevent misuse can be congured in the
soware and are password-protected. This prevents unauthorized parties

from accessing these settings.

Legal Notes

Legal aspects of video and sound recording: You must com­ply with all data protection regulations for video and sound
monitoring when using MOBOTIX products. Depending on
national laws and the installation location of the M26, the recording of
video and sound data may be subject to special documentation or it may
be prohibited. All users of MOBOTIX products are therefore required to
familiarize themselves with all valid regulations and comply with these
laws. MOBOTIX AG is not liable for any illegal use of its products.

1. Disposal

Electrical and electronic products contain many valuable
materials. For this reason, we recommend that you dispose of
MOBOTIX products at the end of their service life in accordance
with all legal requirements and regulations (or deposit these
products at a municipal collection center). MOBOTIX products must not be
disposed of in household waste! If the product contains a battery, please
dispose of the battery separately (the corresponding product manuals

contain specic directions if the product contains a battery).

2. Disclaimer

MOBOTIX AG does not assume any responsibility for damages,
which are the result of improper use or failure to comply to the
manuals or the applicable rules and regulations. Our General
Terms and Conditions apply. You can download the current version of the
General Terms and Conditions from our website at www.mobotix.com by
clicking on the COS link at the bottom of every page.

Power o before opening the camera: Make sure the power
supply to the camera is disconnected before opening the
camera housing (e.g., when inserting or exchanging lenses,
lens units and SD cards).

Technical Specications M26

Model Versions

Lens Options MX-B016 bis MX-B500, 180° to 8° horizontal angle of view

Sensitivity

Image Sensor 1/1.8“ CMOS, 6MP (3072x2048), progressive scan

Max. Image Size 6MP (3072x2048)

Image Formats

Max. Frame Rate

Video Codec

ONVIF ONVIF-S (camera soware V5.2.x and higher, 2

DVR

Soware MxManagementCenter

Image Processing

PTZ Digital pan/tilt/zoom; max. zoom 8x (continuous)

Mx-M26A/B* (all Day/Night image sensors)

*Variant Mx-M26B supports MOBOTIX MxBus modules

Color sensor (day): 0,1 lx @ 1/60s; 0,005 lx @ 1s

BW sensor (night): 0,02 lx @ 1/60s; 0,001 lx @ 1s

Freely congurable format 4:3, 8:3, 16:9 or customized format (image

cropping), like 2592x1944 (5MP), 2048x1536 (QXGA), 1920x1080
(Full-HD), 1280x960 (MEGA)

MxPEG: 42@HD(1280x720), 34@Full-HD, 24@QXGA, 14@5Mp, 12@6MP

M-JPEG*: 25@HD(1280x720), 13@Full-HD, 9@QXGA, 5@5Mp, 4@6MP

H.264: 25@Full-HD, 20@QXGA

MxPEG, M-JPEG, JPEG (max. output size 6MP)

H.264 (max. output size QXGA, bandwidth limitation applicable)

On internal MicroSD card (SDXC, SDHC pre-installed)

External on USB device

External on NAS

Full image recording regardless of live image zoom

MxFFS

Pre-alarm and post-alarm images

DVR monitoring with error notication

MxLEO, backlight compensation, automatic white balance, image
distortion correction

nd

half of 2018)

Temperature sensor, shock detector (with rmware version 5.0.1 and

Alarm/Events

Intelligent Video Analysis MxActivitySensor, video motion analysis, MxAnalytics

Audio

Interfaces

Security

Certications

Power Supply Power over Ethernet (IEEE 802.3af)

Power Consumption Typ. 4 W

Power Consumption of
External Devices

Protection Classes

Ambient Temperature –30 to 50 °C/–22 to 122 °F

Dimensions/Weight W x H x D: 140 x 189 x 220 mm; weight: about 350 g

Standard Delivery

higher), microphon, other sensors/IOs via MxMessageSystem, noti

cation via e-mail, FTP, IP telephony (VoIP, SIP), visual/sound alarms,
pre- and postalarm images

Microphone/ loudspeaker, both 16bit/16kHz (HD-Wideband-Audio))

Lip-synchronous audio, audio recording

VoIP/SIP, two-way communication, remote controlling using key
codes

Ethernet 100Base-T, MiniUSB, MxBus*;
inputs/outputs and RS232 via accessories

*Only variant Mx-M26B

User/Group management, SSL, IP address lter, IEEE802.1x, intrusion

detection, digital imge signature, MxFFS

EN55032:2012; EN55022:2010; EN55024:2010; EN50121-4:2015;
EN61000-6-1:2007; EN 61000-6-2:2005; EN61000-6-3:2007+A1:2011;
EN61000-6-4:2007+A1:2011; AS/ NZS CISPR22:2009+A1:2010; CFR47
FCC part15B

At MxBus: max. 2,5 W, at USB: max. 2.5 W, total max. 3 W

The power consumption of the camera will increase accordingly!

IP66
IK10

Housing (high-resistance composite, PBT), white, conversion set for
ceiling mount, mounting supplies, wrenches, 50 cm patch cable,

soware, MicroSD card (installed)

-

Dimensions/Drilling Template

1. Dimensions—Wall Mount

106.5 mm/4.19 in

106.5 mm/4.19 in

39 mm/1.54 in

189 mm/7.44 in

140.5 mm/5.53 in

72 mm/2.83 in

222 mm/8.74 in

112 mm/4.41 in

–90°

+20°

115.5 mm/4.55 in

80 mm/3.15 in

2. Dimensions—Ceiling Mount

106.5 mm/4.19 in

59 mm/2.32 in

156 mm/6.14 in

140.5 mm/5.53 in

106.5 mm/4.19 in

27 mm/

1.06 in

72 mm/2.83 in

137 mm/5.39 in

–90°

+20°

115.5 mm/4.55 in

75 mm/2.95 in

Interface Box

Wall/ceiling mount M26

Further information on www.mobotix.com:

• Products > Indoor Cameras > M26 Allround

• Support > Download Center > Documentation > Certicates & Declarations of Conformity

MOBOTIX, the MX logo, MxPEG and MxActivitySensor are trademarks of MOBOTIX AG registered in the Euro­pean Union, the U.S.A., and other countries • Information subject to change without notice • MOBOTIX does
not assume any liability for technical or editorial errors or omissions contained herein • All rights reserved •
© MOBOTIX AG 2017

0.59 in

15 mm/

80 mm/3.15 in
