Mobo Monza User Manual

MOBO$USA$CORP$

Brand$Name:$MOBO$

$

Model$No:$MONZA$

FCC$ID:$ZOJMONZA$

$

$

GSM$Mobile$Phone$

$

User$Manual$

CONTENT

1. SAFETY PRECAUTIONS ..... 5

2.PHONE OVERVIEW ............ 11

3. GETTING ST ARTED ........... 13

4.TEXT ENTRY ........................ 20

5.CALLING ............................... 21

6. MENUS .................................. 25

6.1CAMERA ........................... 26

6.2FILE MANAGER .............. 26

1

6.3PHONEBOOK ....................... 26

6.4GAMES ................................ 29

6.5EXTRA ................................ 30

6.6CALL CENTER ..................... 31

6.6.1. Call history ................ 31

6.6.2. Call settings .............. 33

6.7MESSAGES .......................... 38

6.7.1. W rite message ........... 38

6.7.2. Inbox ......................... 39

6.7.3. Drafts ........................ 39

6.7.4. Outbox ....................... 39

6.7.5. MMS .......................... 40

6.7.7.SMS settings ............... 41

6.8 MULTIMEDIA ...................... 42

6.9SERVICES ............................ 45

6.10ORGANIZER ....................... 47

6.11SETTINGS .......................... 48

6.11.1.Dual SIM switch ....... 48

6.11.2.Dual SIM settings ..... 48

6.11.3.Phone settings .......... 48

6.11.4.Network settings ....... 51

6.11.5. Security settings ....... 52

6.11.6Conncetivity ............... 53

6.11.7Restore factory settings

3

............................................ 54

6.12USER PROFILES ................. 54

6.13WLAN .............................. 55

LARM ............................. 55

6.14A

Points for attention

Disassembly T card, the appropriate force.
Avoid excessive force and battery contacts metal
deformation caused by a collision of normal use.

1. Safety Precautions

Information for parents

Please read the operating instructions and safety

5

precautions carefully before use.

Explain the content to your children and the hazards
associated with using the phone.

Remember to comply with legal
requirements and local restrictions when
using the phone, for example, in aero
planes, petrol stations, hospitals or while
driving.

Mobile phones can interfere with the
functioning of medical devices such as
hearing aids or pacemakers. Keep at least
20 cm(9inches)distance between the phone
and pacemaker. When using the mobile

phone hold it to the ear which is furthest
away from the pacemaker. For more
information, consult your doctor.

Always keep the phone and accessories
out of reach of small children.

Small parts such as the SIM card, dust cap,
lens ring and lens cap as well as the micro
SD card can be dismantled and swallowed
by small children.

Do not place the phone near to
electromagnetic data carriers such as credit
cards and floppy disks. Information stored
on them could be lost.

Do not look directly into the LED (such as
flash LED) with optical magnifiers
because of radiation.

This product complies with IEC/EN

60825-1 “Safety of Laser Products” for
LED Class 1M products; such products
are safe under reasonably foreseeable
operating conditions.

Permanent hearing loss may occur if you

7

use earphones or headphones at high
volume. You can adapt over time to a
higher volume, which may sound normal
but can be damaging to your hearing. Set
your volume to a safe level. If you
experience discomfort or buzzing in your
ears, reduce the volume or discontinue use
of your earphones or headphones.

Ring tones, info tones and hands free
talking are reproduced through the
loudspeaker. Do not hold the phone to the
ear when it rings or when you have

switched on the hands free function.
Otherwise you risk serious permanent
damage to your hearing.

The mains voltage (V) specified on the
power supply unit must not be exceeded.
Otherwise the charging device may be
damaged.

The power supply must be plugged into an

easily accessible AC mains power socket

when charging the battery. The only way
to turn off the charging device after
charging the battery is to unplug it.

You may only open the phone to replace
the battery, SIM and micro SD card. You
must not open the battery under any
circumstances. All other changes to this
device are strictly prohibited and will

invalidate the guarantee.

The phone may cause interference in the
vicinity of TV sets, radios and PCs.

Dispose of unwanted batteries and phones
as permitted by the laws in your countries.

9

Only use original batteries and charging
devices. Otherwise you risk serious
damage to health and property. The
battery could explode, for instance.

All batteries can cause property damage,
injury or burns if a conductive material
such as jewelry, keys or beaded chains
touch exposed terminals. The material
may complete an electrical circuit and
become quite hot. Exercise care in
handling any charged battery, particularly
when placing it inside your pocket, purse
or other container with metal objects.

Do not dispose of batteries in fire as they
may explode.

Improper use will invalidate the guarantee! These safety
instructions also apply to original accessories.

As mobile devices offer a range of functions, they can be
used in positions other than the head, such as directly on
the body. In this case, the limits are met too.

2.Phone Overview

Communication control keys

SIM1/SIM2 calling keys

SIM1/SIM2 calling key is used to make a call after a
number has been entered or selected from the phone book,
or to answer an incoming call. In idle screen, press
SIM1/SIM2 calling key to show call logs of SIM1 card or
SIM2 card.

End key

End key is used to end a call during calling or conversation,
or to quit the menu and return to idle screen. Press and hold
the ending key for about two seconds to turn on/off the
phone.

Direction keys

11

Go to Settings > Phone settings > Dedicated key to set
direction keys.

Center key

In idle screen, press center key to open the main menu. In
lists and menus, press the center key to start an
application/function.

Left and right soft keys

In idle screen, press the left soft key to open the main menu.
In idle screen, press the right soft key to directly access the
phone book list. During menu operation, the current
functions of the left and right soft keys are shown in the
bottom line of the screen, and they are closely related to the
current status of the phone.

Number keys

Press number keys (0-9) to enter numbers.
.

You can also use number keys to select menus. If a number
is shown before an option in menu list, you can select the
option quickly by pressing the corresponding number key.

What is a SIM card

When registering your mobile phone number, you will have
a SIM card (Subscriber Identity Module) provided by the
network operator.

The SIM card has information reserved for your use. It
includes your phone number, PIN (Personal Identification
Number), PIN2, PUK (password to unlock PIN), PUK2
(password to unlock PIN2), IMSI (International Mobile
Subscriber Identity) number, network information, phone
book data, SMS data and so on. If it is lost, contact your
network operator immediately for help.

PIN code

PIN is the password provided by your network operator. It
is usually 4 digits. When you input the PIN code, the screen
displays “*” to replace the number entered.

PIN is used to access the SIM card. If the PIN protection
function is enabled, the screen will display “Enter PIN”
each time the phone is switched on. You can deactivate this
feature but you risk unauthorized use of the phone. Some
network operators do not permit deactivating the control.

3. Getting Started

13

PIN2 code

PIN2 is required for some specific functions provided by
the network, such as the charge information.

Note: If you enter the PIN incorrectly three times in a row,
the SIM card will be locked. Please contact your network
operator immediately for decoding. Attempting to decode
by yourself may result in the permanent failure of the SIM
card.

PUK code

PUK (Personal Unblocking Key, 8-digit) unlocks a locked
PIN. If you enter the PUK incorrectly ten times in a row,
the SIM card will become invalid. Please contact your
network operator for a new SIM card.

Installing the SIM card

1. Press and hold the ending key to turn off the phone.

2. Remove the battery cover and then the battery.

3. Insert the SIM card into the card holder. Ensure that

the cut corner is at the top left and the metal
contacts face the phone.

4. Re-install the battery. Place the battery cover onto

the back of your phone and slide it forward until the
latch catches the cover.

Note: A SIM card can be easily damaged if its metal
contacts become scratched. Therefore, take special care
when holding or inserting it and keep it away from small
children.

Charging the battery

The battery is not fully charged when first unpacked. It
takes three charging-discharging cycles for the battery to
reach its peak performance. The battery can be ch arged and
discharged hundreds of times. However, the capacity of the
battery will be reduced each time it is charged/emptied, and
it will eventually wear out. When the talk time and the
standby time are noticeably shorter than normal, replace the
battery. Use original batteries and charging devices only.

Unplug the charger from the outlet and the phone when not
in use. Do not leave a fully-charged battery connected to a
charger because overcharging may shorten the lifetime of
the battery. If unused, a fully-charged battery will lose its
charge over time.

If the battery is completely discharged, the charging may
not start immediately when you plug in the connector. Wait
10 to 15 minutes for the phone to begin charging.

15

Use the battery only for its intended purpose. Never use any
charger or battery that is damaged.

Do not short-circuit the battery. An accidental short circuit
may occur when a metallic object such as a coin, clip or pen
causes the direct connection of the positive (+) and negative
(-) terminals of the battery, for example, when you carry a
spare battery in your pocket or purse. Short circuit may
damage the battery and the connecting object.

Storage at too high or low temperatures will result in a
gradual capacity loss. As a result the operating time of your
mobile phone may be considerably reduced, even after the
battery is fully charged.

Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Dispose of
unwanted batteries and phones as permitted by the laws in
your countries.

Battery
type

Li-ion
battery

Capacity Standby

1800
(1500)MAH

time

600
HOURS

Call
duration

10 HRS

Note: The actual operation time of a battery varies based on
the operation mode, network settings and call settings.

Charge a battery according to the following steps:

1. Connect the charger to the connection jack of the

phone in proper direction, and connect the charger
to a main socket.

2. The phone displays "Charger Connected!" and starts

charging after properly connected. The battery icon
dynamically displays the charging process. In
switch-off state, the phone dynamically displays the
charging process.

3. When the battery is fully charged, the charging

process stops automatically, and the battery icon
indicates full grid on the screen. After the battery is
fully charged, remove the charger from the phone
and socket as soon as possible.

Note:

z After the phone has run out of battery, we

recommend that you recharge the battery in time. If
you do not recharge the battery in two days, the
phone may enter the slow charging mode. When you
recharge the battery, there may be no display
temporarily. After about 10 minutes, the charging
indicator icon is displayed on the screen of the

17

phone. If you do not recharge the battery more than
two days, the battery may enter the over discharge
protection state. Thus, in order to get the battery into
normal charging mode quickly, we recommend that
you charge the battery on an adapter to activate the
battery for charging, and then charge the battery with
the phone. Alternatively, you can charge the battery
with the adapter.

z Do not change the parts and accessories of the

battery by yourself or take off the battery cover for
safety.

z Use only original batteries and charging devices.

Otherwise you risk serious damage to health and
property.

z The temperature range for charging a battery is

-10°C to +50°C. Do not charge the battery in too
high or too low temperature.

z Do not use the phone while charging.
z It takes approximately four hours to fully charge a

battery. Remove the charger quickly after the battery
is fully charged.

z The phone has small battery for clock operation so

after pulling out the main battery, system date and
time will not be reset to default values (factory
settings).

Memory

Phone Memory

This phone has 250.5k inbuilt memory to keep user data
safe in memory. All the multimedia options access phone
memory as default storage. User can change this storage
option from phone memory to T-flash card memory through
storage option in multimedia options.

T-Flash card

T-Flash card is a kind of multimedia memory to keep your
data safe in the memory. You can access your T-flash card
memory through File manager.

Note: This phone can support 8 GB T-flash card memory,
but it is recommended that to use 2 GB T-flash card
memory for best performance of the phone. Some times it
may hang or slow down the performance of the phone
because of high memory processing by processor.

Switching the phone on

Press and hold the end key to turn the phone on. The phone
will automatically search for the network, if there is no
password protection for the SIM card and the phone. After
the phone is registered on the network, the name of the
service provider will be displayed on the idle screen. Then
you can make or answer a call.

19

After the phone is switched on, if a password is required,
enter the correct PIN code and press the left soft key or the
center key for confirmation. After unlocked, the phone will
display the name of the registered network and the signal
strength. Contact your network operator if you do not know
the PIN code. The default password to lock/unlock phone is
“0000”.

After the phone is switched on, if it displays “Insert SIM
Card” on the screen, press and hold the ending key to turn
the phone off, and check whether the SIM card is properly
inserted.

Switching the phone off

Press and hold the end key to turn the phone off. After the
switch-off animation is displayed on the screen, the phone
will be switched off.

Note: Do not attempt to turn the phone off by directly
taking out the battery.

When the text editing screen is displayed, the current text
input method is indicated in the upper left corner of the
display. To have more options to enter text, do one of the

4.Text Entry

following ways to select the desired input methods:

z Go to Settings > phone settings > Preferred input

method.

z In text editing screen, select Options > Input

method.

Making a call

In idle screen, enter a phone number and press the
SIM1/SIM2 calling key to make a call by SIM1 card, or
SIM2 card.

Press the end key to end the conversation.

Correcting a dialed number

Press the right soft key to clear the last number on the
display. Use direction key to select the appropriate number.
Press and hold the RSK to clear all entered numbers.

5.Calling

21

Making a call from phone book

1. In idle screen, press the right soft key to enter

Phonebook list, or enter the menu and select
Phonebook.

2. Press the SIM1/SIM2 calling key to make a call by

the SIM1 card, or SIM2 card.

Dialing a previous number from call history

1. In idle screen, press the SIM1 calling key to display

call logs of SIM1, or press SIM2 calling key to
display the call logs of SIM2. Press the up and down
direction keys to select a desired number.

2. Press the SIM1/SIM2 calling key to make a call by

the SIM1 card, or SIM2 card

Dialing a speed dial number

In idle screen, press and hold the corresponding number
(2-9) in the speed dial list to make a call, please enable the
Speed dial function first. Please note that the number key 1
is reserved for the voice mail number.

To set speed dial,

1. Go to Phonebook > Phonebook settings > Speed

dial > Enable speed dial to enable the function.

2. Set the speed dial numbers in Phonebook >

Phonebook settings > Speed dial > Set number >
Edit. Select the desired number from the phonebook

to make it speed dial on the specific number key

Listening the voice mail

Press and hold number key 1 to enter directly in the Voice
mail server function.

You need to set the voice mail number and store it on your
SIM card. To set the number, go to Messages >SIM1 /
SIM2 Voice mail server, select Options and then Edit.

Answering a call

z Press the calling key.
z Press the center key, or select Options and Answer.

23

Ending a call

Press the end key to end the conversation.

Rejecting a call

z Press the end key to reject the call.

z Select Reject by right soft key.

Call options

Press Options during a call for more options. Options vary
depending on the current situation.

Hold single call Hold the current call.
End single call End the current call.
New call Add a new call and talk with

Phonebook Use Phonebook to search for

Messages Read/write a message during a

more than one party at a time.

numbers.

call.

DTMF Enter tone sequences (number)

6. Menus

6.1Camera

The phone supports the photographing. Pictures are
saved in phone memory or T-flash card memory. The file is
in the *.jpg format. You can send the pictures taken by
Bluetooth function provided by the phone.

While in camera mode, press the left soft key to set the
camera. Then save the settings. Aim the camera lens at the
place/object, and then press the center key to take a photo.
Keep the camera lens steady for a while for the image

6.2File manager

The file manager including the phone memory and
T-flash card if you insert into the T-flash card ,you can save
different kinds of documents which depends on the memory
space in the file manager. The phone support 8G memory
card which is the largest, but 2GT-flash card is best.

for remote inquiries to an
answering machine.

25

6.3PhoneBook

The phone provides two kinds of storage media: SIM
card and phone. The phone can store 200 entries. The
capacity of the phone book on your SIM card depends on
the type of SIM card provided by your network operator.

Enter a number in idle screen and press the OK to save the
number in the phonebook. Select the storage location & edit
the name of the contact. If To SIM1 or To S IM2 is selected,
you can edit the name and number only. If To phone is
selected, you can edit the items that you set in the settings
of phone book, including the name, number.

In idle screen, press the right soft key to directly access the
phonebook.

The small icon on the left of the phone book list indicates
whether the record is stored on the SIM1 card, the SIM2
card. Select an entry from the phonebook & choose the
following options.

View View the detailed information of the

Call Dial the designated phone number.
IP dial IP call the selected number.

record.

b

Edit Edit the options included in a phone

Delete Delete the record.
Copy Copy the record from the current

Move Move the record from the current

Send
business
card

Add to
black list

There are the following options if you access the phone
book from menu.

ook record.

storage to the other storage.

storage to the other storage.
Send contact by SMS/MMS

/Bluetooth or save it to file.

Add to black list

27

r

p

Search
contact

1. Enter the full name to find the
contact or the first word. Select the
option to find, you can find the
contact.

2. If you are not sure to find the
name, directly on the options,
select the option to find, identify
and directly into the phonebook.

Add new
contact

Copy all Copy the records from SIM1 to

Delete You can choose to delete all the

Add a new phone number to SIM1,
SIM2 o

hone.

phone, from phone to SIM1, from
SIM2 to phone, from phone to
SIM2, from SIM1 to SIM2, and
from SIM2 to SIM1.

records from the SIM1 card, SIM2
card or phone, or delete them one
by one. Note: If you want to delete
all records at once, the phone
password is required, which is
"1234" by default.

Extra
numbers

Phonebook
settings

6.4Fun&Games

1 .MRP Store

2.MSN

3.Yahoo

4.Facebook

5.Skype

Set the SIM1 owner number and
SIM2 owner number, SIM1 service
dialing number and SIM2 service
dialing number, and SOS number.

View the memory status. Set
the preferred storage of new
numbers. Select the items in Fields
option required to be added when
adding new numbers to the phone.
Edit and send your own vCard.
Select vCard version. Phonebook
backup. Save contact notify.

29

6.Twitter

7.Games

Mahjong

Puzzle

Magic Sushi

VSMJ

Games settings

8.Java

9.Java setting

10.Java default security

6.5Extra

1. Bluetooth

You can activate the Bluetooth function with this

function, can connect the antenna of the phone with the
other Bluetooth in the wireless and exchange data, call in
hand-free way or remotely control the phone with these

device.

2. Calculator

Select into the calculator, use it can do the simple
arithmetic. up, down, left, right direction keys to determine
the key corresponding to the +,-,×，÷，=. Press the right
function key return to the higher interface or back. Left key
can delete the input content or results.

3.Ebook reader

6.6Call Center

6.6.1. Call history

In idle screen, press the SIM1calling key to directly access
the call logs of the SIM1 card, and press SIM2 calling key
to directly access the dialed call logs of the SIM2 card.

1. SIM1 call history
Viewing Call History
In main menu go to Call center > Call history > SIM1 call

history > SIM1 all calls/ SIM1 dialed calls / SIM1
missed calls / SIM1 received calls, to view the call logs.

31

Select a call from the list. When the call is displayed, press
the SIM1/SIM2/SIM2 calling key to make a call from the
SIM1 card, or SIM2 card. You can press the OK key to
view the details of the call. Select Options for more
following options.

View View the details

Delete Call Delete the select number from the

Send text
message

Send
multimedia
message

IP dial IP dial the contact from the call

list. Dial the selected number.

Send a short message to the
record.

Send MMS to the selected contact.

center

Save to
Phonebook

Save the selected number to the
SIM1 card, the SIM2 card or the
SIM2 card or the phone.

Add to black
list

Edit before call Edit before call
Delete Delete the call history

Delete SIM1 call logs: Delete missed calls, dialed calls or

received calls, or delete all call logs on the SIM1 card.

SIM1 call timers: View Last call time, Total dialed calls

2. SIM2 call history

For the detailed information of SIM2 call history, please
refer to the content in “SIM1 call history”.

6.6.2. Call settings

1. SIM1/SIM2 call setting

Add to black list

33

p

¾ Call waiting

Activate If activated, an incoming call is

Deactivate Cancel the call waiting function.

signaled by a call waiting tone when
you are on another call. The
number/name of the incoming call is
displayed.

Query
status

¾ Call divert

You can specify the conditions under which calls should be
diverted to your voice mail box or another number.

Divert all
voice calls

Divert if
unreachabl
e

Divert if no
answer

Divert if
busy

Inquire the current status from the
network.

All calls are diverted.

A call is diverted if the phone is
switched off or is out of range.

A call is diverted if not answered.

A call is diverted if another call is in

rogress.

Divert all
data calls

Cancel all
diverts

¾ Call barring

Restrict the dialing or receiving of certain call s. To activate
or cancel call barring, you have to enter the network
password provided by your network operator.

All data calls are diverted.

Cancel all call divert settings.

Outgoin
g calls

If All calls is activated, no calls can be
made. If International calls are
activated, no international calls can be
made. If International calls except to
home PLMN is activated, only local
calls or calls to the home country (that
is, the country to which the network
operator belongs) can be made.

35

Incomin
g calls

If All calls is activated, no calls can be
received. If When roaming is
activated, you may not receive calls
when you are outside your home
network.

Activate
all

Cancel
all

Change
barring
passwor
d

Note: Above call settings Call waiting, Call divert & Call
barring are separate for SIM1 card & SIM2 card” You can
switch between SIM1 or SIM2 call settings through left &
right navigation key.

¾ Line Switching

Activate all

Cancel all restrictions to calls.
Password from your network operator is
required.

Change barring password. The original
barring password is required.

The switch between line 1 and 2.

Note: If you choose line 2, is able to devote the phone
and network operator.

¾ Advance settings

1. Black list

The phone can not receive the call from this number if this
number was added to the black list of the phone.

2. Auto redial

Once activated, the phone will automatically redial, if there
is no answer for a number you have dialed.

3. IP dial

Dial the contact number with IP

.

5. Call time reminder

37

If activated, the phone beeps at the interval time you set
during a call

6.7Messages

The phone supports Short Messaging Service (SMS).
You can send text messages and manage the messages that
you sent and received.

If the memory for short messages is not full, short messages
will be directly saved in the SIM card.

6.7.1. Write message

Create a new short message.

1. Enter text.

2. Press the left soft key (Options) and select the

required items, including Use templates, Insert

object, Text format, Insert number, Insert
name,Insert bookmark and Input method.

3. Press the left soft key (Options) and select SIM1

done or SIM2 done for send options.

Send
only

Save and
send

Save Save the short message in Outbox.

Send to
many

6.6.2. Inbox

Incoming short messages are saved in inbox. Press center
key to view the message.

You cannot view new messages if the memory for messages
is full. Delete unnecessary messages.

6.7.3. Drafts

6.7.4. Outbox

Short messages successfully sent, not sent and to be
sent are saved here.

Send the short message to the
corresponding recipient.

Save the short message in Outbox and
send it to the corresponding recipient at
the same time.

Send the short message to several
recipients.

39

6.7.5. MMS

Write MMS and Received the MMS

6.7.6.Broadcast message

Broadcast messages are messages that your network
operator broadcasts to all users within a particular area,
such as weather forecast and transportation conditions.

Receive
mode

Read
messages

Languages Set languages for cell broadcast

Channel
settings

Enable or disable the function.

Scroll to read broadcast messages.

information. Only information in
the set language can be received.

Select the channel of cell broadcast.

For more information about available channels and the
information they provide, contact your network operator.

6.7.7.SMS settings

Set the following settings of short messages.

Profile
settings

Set profile name, SC address, validity
period and message type.

Commo
n
settings

Preferre
d
storage

Memory
status

Enable or disable the delivery report
and reply path of short messages.

Set to save short messages to the SIM
card or to the phone.

View the SMS storage memory status
of the SIM1/SIM2 card and phone for
short messages.

41

6.8 Multimedia

¾ TV

In the multimedia menu, select to confirm access
to TV interface，press the left soft key to access the
options menu, you can do the following:

Set Region: Select a different city, can search the
city related to TV channel. Eg China or
HongKong……

Input channel：Find TV channels and search
Program list：show the list
Scan：auto scan the channels
Full Screen：watch the TVby full screen.

Press “o”and “p” to change the volume.

¾ camera

The phone supports the photographing. Pictures are
saved in phone memory or T-flash card memory. The file is
in the *.jpg format. You can send the pictures taken by
Bluetooth function provided by the phone.

While in camera mode, press the left soft key to set the

camera. Then save the settings. Aim the camera lens at the
place/object, and then press the center key to take a photo.
Keep the camera lens steady for a while for the image

¾ Image viewer

Browse photos, press the OK button to preview,
press the left function key to view the Options

The phone supports the photographing. Pictures are
saved in phone memory or T-flash card memory. The file is
in the *.jpg format. You can send the pictures taken by
Bluetooth function provided by the phone.

While in camera mode, press the left soft key to set the
camera. Then save the settings. Aim the camera lens at the
place/object, and then press the center key to take a photo.
Keep the camera lens steady for a while for the image

¾ Video recorder

Record the video

¾ Video player

43

Video player allows you to browse or play the
video recording files. It only plays the file stored in
video folder in memory.

¾ Audio player

Audio player allows you to play audio files.

The phone supports T-Flash memory card. You
need to save downloaded music files to directory
my music, so that they can be played normally.

Audio player have List, Settings & Refresh list
option to make a playlist & player settings.

Following are the playlist options.

Play Play the music files

Details Check the details of music files

Refresh list Update the play list.

Settings Settings include Pre. play list, List

auto gen., Repeat, Shuffle,
Background play, and lyrics
display.

¾ Sound recorder
¾ FM Radio

This option allows you to listen to FM radio. You
should plug in an earphone before accessing the
application.

Channel list Edit channel list.

Manual input Input the channel manually.
auto search Set automatic searching for

Settings Set Background play, Loud

6.9Services

Select access to the Internet interface, press the up and
down keys to select menu.

Home page: press ENTER to enter the SIM card after
selecting the interface to select and open the URL parsing

Bookmark: Add a bookmark, press the left soft key to

channels.

speaker,

45

bookmark. Press the OK key to select the SIM card and
then connection， select the bookmark has been added.

Recent pages: The examination had glanced over the
homepage, presses the left functional key to carry on the
operation to the historic record; Presses the definite key
choice “the connection”, the choice current chooses the
record homepage to carry on the operation.

Input address: press the OK key to access the editing
interface, enter the URL to confirm, enter the SIM card
selection interface, select the SIM card after parsing and
open the corresponding Web site.

Service inbox:
Setting:
Brower options:
Service messages settings:
Clear cache:
Clear cookies:
Note: in the Internet Options menu in the bottom part of the

window, you can refresh the page, forward, backward,
Favorites, set up a home page, viewing history, save the file
and exit your browser.

6.10Organizer

¾ Torch

Press ok key to open or close.

¾ Calendar

In the calendar interface, press the up and down
direction keys to scroll to different weeks, and press the left
and right direction keys to scroll to different days.

Jump to date Enter a specific date to be

Go to weekly
view

¾ Tasks
¾ Alarm

You can set five types of alarm clock time if required.
Then the alarm icon will be displayed on the idle screen.

Scroll to an alarm and select Edit for settings. You can
set whether to enable the alarm, the ring time, ring mode,

located and the cursor will jump to
the date quickly.

Go to weekly view

47

audio options, snooze minutes and alert type.

¾ Word clock
¾ Notes

6.11Settings

6.11.1.Dual SIM switch

Manually selected by user，Automatically decided by SIM
cards

6.11.2.Dual SIM settings

Set Dual SIM open, Only SIM1 open, Only SIM2 open

6.11.3.Phone settings

1. Time and date

Set home city Set your time zone.

Set time/date Set the time and the date.

Set format Set the format for the time and

Update with

time zone

the data.
Update with time zone

Auto update
time

2. Schedule power on/off

Set the time to power on/off the phone automatically.
Warning: In specific areas where the use of phone is

prohibited (such as in aero planes), please remember to
disable the automatic switch-on function before entering the
areas to prevent unexpected accidents.

3. Language

Select the language for your handset.

4. Preferred input methodSelect the input method for text
entry.

5.Encoding

Update with time

49

6.Display setting

Wallpaper Set the standby image of the phone.
Screen

saver
Power on

display

Power off
diaplay

Show date
and time

7.Greeting text

8.Shortcuts

9.Dedicated key

10.Flight mode

When you are on a flight where the use of mobile phones is
prohibited, select flight mode so that the phone will not
connect to any network. However, alarm and calendar

Set the waiting time and image for
the screen saver.

press the up and down navigation

keys to select the animation upon
powering the phone on.

press the up and down navigation
keys to select the animation upon
powering the phone off.

If activated, date and time are
displayed on the idle screen.

reminder will remain on. You can still use the entertainment
features such as audio player and camera in flight mode.

11.Speaker output setting

12. LCD backlight

Set the time and brightness of LCD backlight. LCD
backlight will be automatically off if the phone is not
operated within a specific time period

6.11.4.Network settings

This is network supported function.
The network that your phone uses is configured

automatically. When turned on, the phone automatically
connects to the designated network, or automatically
connects to a roaming network when you are outside the
coverage of your regular network. When outside the
coverage of your regular network, you can manually select
the local network system.

1. Network selection

51

Automatic The phone will scan for the available

Manual The phone will list all networks for you

2. Preferrences

Select the preferred network operator. The default is the
network of your SIM card.

Note: The network setup is separate for SIM1 & SIM2. Use
left & right navigation key to switch between SIM1 or
SIM2 network setup.

6.11.5. Security settings

The phone provides several codes to protect your phone
against misuse.

1. SIM security settings

network when you are outside the
home network.

to choose from when you are outside
the home network.

SIM1/SI
M2securit
y

Change
Password

2. Phone lock

If the phone lock is activated, the phone lock password is
requested after the phone is switched on. The default
password is "1234". If the phone is locked, only emergency
calls can be made.

3. Auto keypad lock

Keypad lock prevents the inadvertent phone usage.
However, you can still be called and you can make
emergency calls.

6.11.6Conncetivity

1.Data account

The function is used to set account information.

The SIM1/SIM2cardis protected
against misuse by the PIN code.
SIM1/SIM2 card lock may be set after
you enter the PIN code correctly.

Set new password, including
SIM1/SIM2PIN1andSIM1/SIM2 PIN

53

GSM
data

GPRS Press Edit to set Account name,

6.11.7Restore factory settings

Reset the phone to default values (factory settings).
The phone password is required, which is "1234" by

default.

6.12User profiles

allow the operations of the phone to best suit the
environment you are in. The profiles are General, Meeting,
Outdoor and My style .The phone will automatically enter
the headset profile if you connect the headset.

Note: There is an extra silent mode which cannot be
accessed here. To activate that profile, go back to the idle
screen, press and hold the pound key (ctrl) until the phone
gives you a prompt.

Press Edit to set Account name,
Number, User name, Password, Line
type, Speed and DNS.

APN, User name, Password, Auth. Type
and DNS.

The phone provide seven pre-defined user profiles that

You can customize the following options for new profiles.

Tone
setup

Volume Set volume for Ringtone and key tone.
Alert

type

Ring type Four types of Single, Repeat, and

Extra
tone

6.13WLAN

First：Turn on WLAN first，You can search the AP
in the Wlan interface. In the options menu：
Connect：Connect the AP surf the internet

Set SIM1 incoming call, SIM2
incoming call, Alarm, SIM1 message
tone, SIM2 incoming call message tone
andKeypad tone.

Four types of Ring only, Vibration
only, Vibration and ring and Vibration
then ring are available for your
selection.

Ascending are available options for
your selection.

You can select one or more extra tones.
The options are Warning, Error, Camp
on andConnect.

55

Ad Hoc function is supported but not able to operate on non-US frequencies.

Add: add to a account of AP
Define account point:
Wlan status:select the single wlan status
Disable wlan
Refresh：Refresh the list of Ap

6.14Alarm

You can set five types of alarm clock time if required.
Then the alarm icon will be displayed on the idle screen.

Scroll to an alarm and select Edit for settings. You can
set whether to enable the alarm, the ring time, ring mode,
audio options, snooze minutes and alert type.

57

FCC RF EXPOSURE INFORMATION:

WARNING!! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with its
action in Report and Outer FCC ZGRCOM adopted an updated safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters.
Those guidelines are consistent with the safety standard previously set by both U.S. and
international standards bodies. The design of this phone complies with the FCC guidelines and
these international standards. Use only the supplied or an approved antenna. Unauthorized
antennas modifications, or attachments could impair call quality, damage the phone, or result in
violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result. Please contact your local
dealer for replacement antenna.

BODY-WORN OPERATION:

This device was tested for typical body-worn operations with the back of the phone kept 1.5cm
from the body. To comply with FCC RF exposure requirements, a minimum separation distance
of 1.5cm must be maintained between the user's body and the back of the phone, including the
antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories
containing metallic components shall not be used. Body-worn accessories
that cannot maintain 1.5cm separation distance between the user’s body and the back of the
phone, and have not been tested for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When
it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for
hand-held wireless phones. Those guidelines are consistent with the safety standards previously
set by both U.S. and international standards bodies:

<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)

Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available body of research to develop
the ANSI Standard (C95.1). Nevertheless, we recommend that you use a hands-free kit with
your phone (such as an earpiece or headset) to avoid potential exposure to RF energy. The
design of your phone complies with the FCC guidelines (and those standards).

Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC regulations.

NORMAL POSITION:

Hold the phone as you would any other telephone with the antenna pointed up and over your
shoulder.

TIPS ON EFFICIENT OPERATION:
For your phone to operate most efficiently:

• Extend your antenna fully.

• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna
affects call quality and may cause the phone to operate at a higher power level than otherwise
needed.

℃

RF

FCC RF Exposure requirements: The highest SAR value reported under this standard
during product certification for use next to the body with the minimum separation

distance of 1.5cm is 1.330

must not be collocated or operating in conjunction with any other antenna or transmitter.

This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver

-Consult the dealer or an experienced radio/TV technician for help

Do not use the device with the environment temperature which below minimum -10℃
or up maximum 50 .the device may not work.

Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Exposure Information:

W/kg

, next to the head is 0.751

is connected.

W/kg.

This transmitter
