Mobiq worldphone User Manual
WorldPhone
USER’S MANUAL
148 x 195 mm
RADIATION WARNING
High levels of radio frequency radiation are considered health hazardous. Although no single value of
“safe radiation level” has been agreed upon by all
countries, the American National Standards Institute
(ANSI/LEEE C95.1-1992) recommends that people
should not be exposed to radiation stronger than
1 milliwatt per square centimetre at the frequencies
used in the WORLDPHONE terminal. Accordingly,
RADIO FREQUENCY RADIATION
HAZARD - KEEP CLEAR
1 METRE MINIMUM
the operator of the terminal should ensure that the
area extending 1 metre from the front of the antenna
be kept clear of personnel when the terminal is transmitting.
OBTAINING LICENSING FOR INMARSAT TERMINALS
Under rights given under ITU Radio Regulations, local telecommunications
administrations establish and enforce national rules and regulations governing
types of emissions, power levels, and other parameters that effect the purity of
signal, which may be radiated in the various frequency bands of the radio spectrum.
To legally operate an Inmarsat terminal, it is necessary to obtain permission from
the local telecommunications regulatory authorities of the country you are operating within. Using your terminal in any country without permission causes you to
run the risk of confiscation of the terminal or legal action from local authorities.
Normal practice for taking telecommunications into another country is to apply for
a license before travel. If a license has not been obtained before travel, the
equipment may be put into storage by local authorities until such time as a license is obtained.
All specifications are subject to change without notice.
Chapter 1. Getting Started
Introduction ................................................................................ 1.1
Telephone Unit (TPU) .............................................................. 1.3
WorldPhone Portable ............................................................... 1.6
WorldPhone Provident ............................................................ 1.12
WorldPhone Marine ................................................................. 1.13
WorldPhone Voyager .............................................................. 1.16
Chapter 2. Operation
Introduction ................................................................................ 2.1
Making a call ............................................................................ 2.2
Call from telephone .................................................................. 2.8
Special calls ..............................................................................2.9
Receiving a call ....................................................................... 2.10
Functions .................................................................................2.13
Last number redialing ..............................................................2.15
Phone book ............................................................................. 2.16
Key lock ...................................................................................2.18
Selecting default Net service provider .....................................2.19
User access ............................................................................. 2.20
Data/printer port setup ............................................................. 2.23
Phone setup ............................................................................ 2.26
Setting default contrast and ringing volume ......................... 2.27
Setting date and time ...........................................................2.28
Setting key lock .................................................................... 2.29
Language setup .................................................................... 2.30
Language reset ....................................................................2.31
Mailbox access numbers ......................................................2.32
Call charge setup ................................................................. 2.33
Traffic log ................................................................................. 2.34
Precharge ................................................................................2.37
Precharge on SIM card ........................................................ 2.42
Advanced functions:
Access control ......................................................................... 2.44
Restricted dialing ..................................................................2.45
Restricted dialing setup ........................................................ 2.46
Access code ......................................................................... 2.47
Access code setup ............................................................... 2.48
Restricted SIM usage ........................................................... 2.49
Checking SIM restrictions .....................................................2.50
Setting SIM restrictions ......................................................... 2.51
Satellite setup ..........................................................................2.52
Net service provider and terrestrial network .........................2.52
S/A operator and terrestrial network .....................................2.52
Configuration ........................................................................... 2.53
Port configuration ................................................................. 2.53
Net service providers ............................................................ 2.54
Power conservation ..............................................................2.55
Set diagnostics ..................................................................... 2.55
Storing of Preferred/Allowed Net service provider
and Stand Alone operator on the SIM Card ......................... 2.56
Charge tone .......................................................................... 2.58
Information available ............................................................... 2.59
IMN numbers ........................................................................2.59
Misc. version ID information ................................................. 2.60
Oscillator compensation ....................................................... 2.60
Network status ......................................................................2.60
Installation ............................................................................... 2.61
Paid functions .......................................................................2.61
Phone name setup ............................................................... 2.61
Chapter 3. Telefax Service
Setting up ................................................................................. 3.1
Using telefax with the WorldPhone .......................................... 3.2
Chapter 4. Data Service
Setting up ................................................................................. 4.1
Chapter 5. Appendices / Index
Appendix A
Telephone country codes ...................................................... A-1
Service address codes .......................................................... A-5
Appendix B
Installation of Marine Antenna ............................................... B-1
Installation of Voyager Antenna ............................................. B-9
Installation of Provident Antenna ......................................... B-16
Optional antenna cable ....................................................... B-21
Connecting up optional equipment ...................................... B-22
Appendix C (WorldPhone Portable/Provident only)
Battery charging .................................................................... C-1
Charger ................................................................................. C-2
Battery replacement .............................................................. C-3
Appendix D
AT commands ........................................................................D-1
DTE interface ...................................................................... D-17
Appendix E
Secure voice (option) ............................................................ E-1
Aero functions (option) .......................................................... E-2
Appendix F
Character map ....................................................................... F-1
Appendix G
List of terms ........................................................................... G-1
Appendix H
System description ................................................................ H-1
Appendix I
Troubleshooting ...................................................................... I-1
1. Getting Started
2. Operation
3. Telefax Service
4. Data Service
5. Appendices
WorldPhone – User’s Manual
Doc. No. QLZB 911084-2 Rev.B Copytema 04/99
Contents
Introduction................................................................................. 1.1
Telephone Unit (TPU)................................................................. 1.3
WorldPhone Portable ................................................................. 1.6
WorldPhone Provident.............................................................. 1.12
Chapter 1. Getting Started
GETTING STARTED
WorldPhone Marine.................................................................. 1.13
WorldPhone Voyager ............................................................... 1.16
The design and specifications of the
equipment may be changed without notice.
WorldPhone – User’s Manual
Chapter 1. Getting Started
General
The WorldPhone communication terminal provides access to the
international dial-up telephone, facsimile and data networks via the
INMARSAT satellite system.
• The terminal Telephone Unit
(TPU)
the below six
• WorldPhone Portable antenna with
RF transceiver built into the lid.
can be operated with any of
Introduction
Introduction
WorldPhone antennas:
The antenna also allows semi- or fixed
mounting on a flat surface, or tripod.
• WorldPhone Marine, a tracking
antenna designed for use on marine
crafts, leisure yachts and work boats
alike.
• WorldPhone Voyager, a tracking
antenna designed for use on vehicles,
trains or riverboats.
WorldPhone – Chapter 1. Getting Started 1.1
Introduction cont’d
• WorldPhone Provident, a fixed
mounted antenna designed to provide
telecommunication services for remote
villages, farms, businesses, construc-
Introduction cont’d
tion sites etc.
• WorldPhone Expander, which allows
simultanous operation of up to six
WorldPhone Telephone Units through a
one meter parabolic dish antenna.
See separate information.
• WorldPhone Aero, intended
for use on the small to medium
size aircraft.
See separate information.
Note!
It is advisable to turn off the equipment prior to switching antenna.
WorldPhone – Chapter 1. Getting Started1.2
Connector panel (rear wall)
Telephone keypad
ON/OFF key
Telephone handset
NT in AOR–E
Dial 00 + country code + subscriber no
0
7
4
1!/?
4ghi 5jkl
7pqr 8stu 9vwx
*
B
Esc
2abc 3def
6mno
0yz
Telephone Unit (TPU)
Loudspeaker
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
Help
for handsfree
Function keys
Arrow keys
operation
Telephone Unit (TPU)
SIM card
HELP key
Net service provider
and satellite
Instruction
Battery indicator
DC replaces symbol
when adapter/power
Signal strength
NIMS/mail alert
Shows that SIM
card is inserted
ON/OFF key
Escape key
8 lines x 40 character display
20 Sep 1998 15: 20
Telenor in AOR–E
Dial 00 + country code + subscriber no
470
SIM
Book Last Menu Seek
Varying
functions
Function
keys
HELP
key
Figure 1.1 WorldPhone Telephone Unit (TPU).
WorldPhone – Chapter 1. Getting Started 1.3
Number/letter keys Arrow keys
Mail Message
Telephone Unit (TPU) cont’d
SIM card
The SIM card (Subscriber Identity Module) carries subscription information from your Inmarsat Service Provider (ISP) or Net service provider on
an integrated circuit. The WorldPhone used with the SIM card assumes
the identity of the SIM card.
The SIM card has its own set of numbers on which the user can be
Telephone Unit (TPU) cont’d
contacted irrespective of the WorldPhone used. All outgoing calls will be
billed to the owner of the SIM card.
The SIM card is protected by means of a lock code. When buying a SIM card
you will receive a Personal Identification Number (PIN) that will contain up to
8 digits. Contact your dealer if you do not have your PIN code.
If the PIN code entered does not match the PIN code on the SIM
card, operation with that particular SIM card will lock-up after three
failed attempts. You must then use the SIM un-block code (PUK
code) provided by your ISP to un-lock the card. Contact your dealer if
you do not have the PUK code.
Note! When using the PUK, the SIM PIN is set to 1 2 3 4.
PIN code
To change or disable the PIN code, see "User access" in chapter 2.
Operation.
The SIM card can store miscellaneous information, f.ex.:
•PIN code (Personal Identification Number)
•Last number list (previously called numbers)
•Phone book
•Allowed and preferred Net service providers
Note! When using SIM card, the accessibility of the functions described in this manual will depend on the card supplier.
The user is prompted for the 4-8 digit Personal Identification Number
each time the WorldPhone is switched on:
•SIM PIN? (with SIM card).
•Phone PIN? (without SIM card).
Be aware that the PIN protection may have been disabled, see "User
access" in chapter 2. Operation.
Mail service
The Internet Messages Service (NIMS) allows a message of maximum 1024 characters to be sent to the WorldPhone from a website,
or from the WorldPhone to an e-mail address or another WorldPhone.
NIMS messages are addressed to a response NIMS IMN number.
See also appendix G.
WorldPhone – Chapter 1. Getting Started1.4
Telephone
Telephone Unit (TPU) cont’d
A DTMF telephone, cordless base station or PABX may be connected
to the WorldPhone. This additional telephone is assigned a separate
incoming call number.
Telefax service
The Telefax facility supports Group 3 fax transmission at a rate of
2.4 Kbps. The telefax is assigned a separate incoming call number.
Data service
The built in Data Transmission Service is capable of transferring
data at 2.4 Kbps. It allows the WorldPhone to interface with a PC
without the aid of a modem or data card.
The Asynchronous Data (ASD) system provides data transfer between two WorldPhones, or between a WorldPhone and the fixed
international network.
The data facility is assigned a separate incoming call number.
1 6 1 6
Telephone Unit (TPU) cont’d
5 4 3 2 1
TEL
6 7 8 9
TEL:
2-wire RJ11
connector
for
telephone,
cordless
base
station or
PABX
DATA
ANT
DATA:
9-pin RS232
Hayes AT
compatible port
for 2.4 Kbps data
communication,
output to printer
or software
download
ANT:
connection
of coax
cable from
antenna
10-32VDC:
WorldPhone Portable:
input for simultaneous
powering and charging
(min.12V) of internal
battery pack.
Polarity independent.
WorldPhone
Marine&Voyager:
10-32VDC
FAX
FAX:
2-wire RJ11
connector
for telefax.
Can be
reconfigured
for telephone
input from Power
Supply
Figure 1.2 Telephone Unit connector panel
WorldPhone – Chapter 1. Getting Started 1.5
operation Function keys SIM card HELP key Arrow keys
FAX TEL DATA ANT.
WorldPhone Portable
General
The WorldPhone Portable terminal consists of two main units housed
in a lightweight and portable carrying case:
•The antenna and RF transceiver integrated into the lid.
•The Telephone Unit (and battery pack) that is detachable and rain
WorldPhone Portable
resistant.
The WorldPhone uses a coax cable to link the two units together. The
case is equipped with a handle for transport. The screw socket in the
lid allows the antenna to be tripod mounted, or attached to a window
using a suction fitting. The total weight of the WorldPhone is 2.7kgs
(including battery pack).
The Telephone Unit can easily be shifted for operation with any of
the other WorldPhone antennas, see "Introduction" in this chapter.
Universal AC adapter Car lighter cable Coax
cable
Carrying
handle/
antenna
support
Case folded
E
–
R
O
A
in
T
N
o
c
+
0
l 0
ia
D
0
7
4
Esc
1!/?
2abc 3def
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
Lid w/antenna
and RF units
Antenna coax cable
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
o
r n
e
rib
c
s
b
u
s
+
e
d
o
c
try
n
u
6mno
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
Help
Telephone Unit
Universal AC adapter
Figure 1.3 WorldPhone Portable, complete.
WorldPhone – Chapter 1. Getting Started1.6
Internal battery
The battery indicator on the display
indicates the internal charge level:
The amount of shading represents
the current charge level.
WorldPhone Portable cont’d
A completely shaded indicator indicates a fully charged battery.
As the battery charge level decreases the amount of shading on the
battery indicator will also decrease.
A flashing battery indicator indicates that the battery level is low.
Case lock
Compass
Flat antenna
RF units
Antenna coax
cable
Bag with
antenna cable
Telephone lock
(2)
Antenna
connector
WorldPhone Portable
cont’d
N
u
o
c
+
0
l 0
ia
D
0
7
4
Esc
1!/?
2abc 3def
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
n
6mno
+
e
d
o
c
y
tr
k
o
o
B
o
n
r
e
ib
r
c
s
b
u
s
L
k
e
e
S
u
n
e
M
t
s
a
Help
Battery pack
TELEPHONE
UNIT
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
E
–
R
O
A
in
T
Lock tab (2)
Figure 1.4 WorldPhone Portable, identification.
WorldPhone – Chapter 1. Getting Started 1.7
WorldPhone Portable cont’d
The WorldPhone turns off automatically once the battery has discharged, to avoid damaging the cells. It must now be powered from
an external source for operation and recharging of the battery.
The WorldPhone may be connected to an AC source using the Universal AC Adapter, or directly to a 12-32 V rated DC source.
WorldPhone Portable
cont’d
The battery is charged even if the WorldPhone is turned off.
The indicator shading increases as the battery re-charges.
For charging and replacement of the battery, see appendix C.
Warning! Problems with the transmission may occur when the battery
charge level is low.
Avoid exposing the WorldPhone to extreme heat or cold. Very high or
low temperatures reduce the battery capacity.
Punchout holes for
fixed mounting of
antenna
Punchout opening
for charging with
antenna/lid closed
Telephone Unit with
support feet lowered
Figure 1.5 WorldPhone Portable connected up.
Antenna tightening
screws (coin size slots)
WorldPhone – Chapter 1. Getting Started1.8
Standard
tripod
mount
Antenna set up with
handle used as support
Setting up
WorldPhone Portable cont’d
1 Open the WorldPhone.
2 If needed, release the
telephone and lift it out.
Check that the antenna coax
cable is properly connected.
Swing out the handle in the lid
for antenna support.
The coax cable permits the
antenna to be placed up to
3 metres away from the
Telephone Unit.
3 Insert the SIM card
(if SIM operated).
4 Press and hold
the ON/OFF key
for 2 seconds.
The display should light up.
–
R
O
A
in
T
N
o
c
+
0
l 0
ia
D
0
7
4
Esc
1!/?
2abc 3def
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
WorldPhone Portable
cont’d
6
9
9
1
c
e
D
3
6
0
9
9
1
3
c
4
.
e
3
D
0
.
3
4
0
1
3
4
.
3
0
.
4
1
E
E
R–
–
R
O
AO
A
in
NT in
T
N
o
c
+
0
0
l
ia
D
Dial 00 + cou
0
7
4
0
7
4
Esc
Esc
1!/?
2abc 3def
1!/?
2abc 3def
4ghi 5jkl
4ghi 5jkl
7pqr 8stu 9vwx
7pqr 8stu 9vwx
0yz
0yz
*
*
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
E
o
n
r
e
ib
r
c
s
b
u
s
+
e
d
o
c
y
r
t
n
u
6mno
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
Help
o
n
r
e
rib
er no
c
s
b
u
s
+
e
d
+ subscrib
o
c
ry
t
n
u
ntry code
6mno
6mno
k
e
e
S
u
n
e
k
M
e
e
t
s
S
a
L
u
n
k
e
o
M
o
B
t
s
a
L
k
o
o
B
Help
Help
5 Check for sufficient battery capacity.
If low, connect the WorldPhone for recharging from external source,
see appendix C
.
6a Enter the SIM
PIN code, and
press Ok:
If necessary,
adjust display
brightness
:
SIM PIN:
Press "Help" for an introduction.
470
When selecting another display language,
Eng appears for easy restoring of English,
see "Phone setup: Language setup and
Language reset" in chapter 2. Operation.
WorldPhone
Del Eng Ok
6b If no SIM card is inserted, the "Phone PIN" will be prompted for.
Default Phone PIN: 1 2 3 4 5 6
WorldPhone – Chapter 1. Getting Started 1.9
WorldPhone Portable cont’d
7 During the satellite search, beep tones will be heard from the
loudspeaker (provided the Tone is ON,
WorldPhone Portable
cont’d
8 To find the correct
vertical angle to the
satellite, try with the
antenna adjusted to 60°,
30° or 0° as indicated.
9 Aim the antenna/lid
towards the estimated
position of satellite
with free line of
sight.
see next page
):
slow intermittent tones when
searching for any satellite.
rapid intermittent tones when
searching for a specific satellite
(faster when searching for a single
satellite).
30°60° 0°
Free line of
sight to satellite
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
E
–
R
O
A
n
i
r
o
n
e
l
e
T
o
n
r
e
b
i
r
c
s
b
u
s
+
e
d
o
c
y
r
t
n
u
o
c
+
0
0
l
a
i
D
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
0
7
4
Esc
Help
1!/?
2abc 3def
6mno
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
Or make a slow
scan across the
hemisphere.
When receiving a
satellite signal, a short tone
will sound. If it is an Inmarsat
satellite, a continuous tone will sound with varying frequency
(provided the Tone is ON, see next page)
.
The WorldPhone always starts with Tone off and "any satellite"
search. See step 10.
When closing in on a satellite, turning the antenna/lid horizontally and
adjusting its vertical angle, the tone should increase in frequency.
WorldPhone – Chapter 1. Getting Started1.10
WorldPhone Portable cont’d
10 A shaded signal strength bar will appear in the display.
The longer the signal bar or higher the signal strength indicator value,
the better the signal quality. The bar becomes solid when the signal
strength value reaches 400.
The maximum marker indicates the highest signal strength achieved
during the current search.
Satellite search
Found AOR-E. Accept this satellite?
Maximum marker
WorldPhone Portable
cont’d
Low high signal strength
470 SIM
Signal strength indication
Pressing Mute turns OFF the search tone.
(Mute Tone).
"Volume" indicator appears when the Tone is ON.
Adjust level with arrow keys.
Mute Seek New Ok
Volume
11 Pressing the Seek function key starts the search again.
New allows selec-
tion of a specific
satellite:
Found AOR-E. Accept this Satellite?
Satellite search
Scroll down to
desired satellite
and select:
470 SIM
Pressing Selct
enters chosen satellite
Note! Searching for a New satellite
should be done under special circumstances only.
Searching for any satellite is the normal mode of operation (default).
New search satellite
All
AOR-W
AOR-E
POR
IOR
Selct
12 Pressing Ok initializes the system.
13 The equipment is
ready for use when the
Main window appears:
Battery indicator
Replaced by DC symbol
when adapter power only
WorldPhone – Chapter 1. Getting Started 1.11
20 Sep 1998 15: 20
Telenor in AOR–E
Dial 00 + country code + subscriber no
470 SIM
Book Last Menu Seek
WorldPhone Provident
General
WorldPhone Provident comprises:
Outdoor Equipment – ODE
•
including fixed mounted antenna and RF transceiver.
Indoor Equipment – IDE
•
WorldPhone Provident
including Telephone Unit and Power Supply.
A single coax cable links the ODE and IDE.
For installation, see appendix B.
For operation of the Telephone Unit, see "WorldPhone Portable:
Setting up" step 1 through 6.
Antenna Unit
Antenna coax cable
Telephone Unit
N
o
c
+
0
0
l
a
i
D
0
7
4
Esc
1!/?
2abc 3def
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
t
n
u
6mno
r
e
b
i
r
c
s
b
u
s
+
e
d
o
c
y
r
u
n
e
M
t
s
a
L
k
o
o
B
Help
c
e
D
3
0
3
4
.
3
0
.
4
1
E
–
R
O
A
n
i
T
Figure 1.6 WorldPhone Provident terminal.
WorldPhone – Chapter 1. Getting Started1.12
6
9
9
1
o
n
k
e
e
S
General
WorldPhone Marine
WorldPhone Marine comprises:
Above Deck Equipment – ADE
•
including stabilized antenna and RF transceiver.
Below Deck Equipment – BDE
•
including Telephone Unit and Power Supply.
A single coax cable links the ADE and BDE.
For installation, see appendix B.
WorldPhone Marine
ADE
BDE
7pqr
1!/?
4ghi
8stu
0yz
NT in AOR–E
Dial 00 + country code + subscriber no
4
7
0
Esc
2abc
3def
5jkl
6
m
n
o
9vwx
Antenna Unit
Antenna
coax cable
1
4
.
0
3
.
4
3
0
3
D
e
c
B
o
H
1
o
k
e
l
p
9
9
6
L
a
s
t
M
e
n
u
S
e
e
k
Telephone Unit
Power Supply
Figure 1.7 WorldPhone Marine terminal.
WorldPhone – Chapter 1. Getting Started 1.13
WorldPhone Marine cont’d
Setting up
1Insert the SIM card
2Switch ON
the power supply:
WorldPhone Marine
cont’d
3Press and hold the
telephone ON/OFF
key for 2seconds:
The display should light up.
4a Enter the SIM
PIN code, and
press Ok:
Adjust display
brightness
(if SIM operated):
ON/OFF
N
T
i
n
D
ia
A
l
O
0
R
0
–
4
7
E
+
0
c
o
1
u
4
n
.
0
t
r
3
y
.
4
3
c
o
d
0
e
3
+
D
e
s
c
B
u
1
b
o
E
s
c
1
!
/
?
2
a
b
c
4
g
h
3
i
d
e
f
5
j
k
l
7
p
q
6
r
m
n
o
8
s
t
u
9
v
w
x
0
y
z
9
o
s
9
k
c
6
r
i
b
L
e
a
r
s
t
n
o
M
e
n
u
S
e
e
k
Help
WorldPhone
SIM PIN:
Press "Help" for an introduction.
:
470 DC
Del Eng Ok
When selecting another display language,
Eng appears for easy restoring of English,
see "Phone setup: Language setup and
Language reset" in chapter 2. Operation.
4b If no SIM card is inserted, the
"Phone PIN" will be prompted for.
5 A shaded signal strength bar will appear in the display.
The longer the signal bar or higher the signal strength indicator value,
the better the signal quality. The bar becomes solid when the signal
strength value reaches 400.
The maximum marker indicates the highest signal strength achieved
during the current search.
Satellite search
Maximum marker
Low high signal strength
Signal strength indication
Found AOR-E. Accept this satellite?
470 DC SIM
Tone Seek New Ok
6Pressing Ok initializes the system with the displayed satellite.
WorldPhone – Chapter 1. Getting Started1.14
WorldPhone Marine cont’d
7 Pressing the Seek function key starts the search again.
New allows selection of a specific satellite:
Scroll down to
desired satellite
and select:
Note! Searching
for a New satellite
should be done under
special circumstances only.
Satellite search
Found AOR-E. Accept this Satellite?
470 DC SIM
Pressing Selct
enters chosen satellite
New search satellite
All
AOR-W
AOR-E
POR
IOR
Selct
Searching for any satellite is the normal mode of operation (default).
8 The equipment is
ready for use when the
Main window appears:
Telenor in AOR–E
Dial 00 + country code + subscriber no
470 DC SIM
Book Last Menu Seek
20 Sep 1998 15: 20
WorldPhone Marine
cont’d
WorldPhone – Chapter 1. Getting Started 1.15
WorldPhone Voyager
General
The WorldPhone Voyager comprises:
Outdoor Equipment – ODE
•
including Antenna Unit and magnetic mounting bracket.
Indoor Equipment – IDE
•
WorldPhone Voyager
Setting up
including Telephone Unit and Power Supply.
A single coax cable links the ODE and IDE.
For installation, see appendix B.
Apply the setting up and satellite search procedure described for
WorldPhone Marine.
See previous pages.
Antenna Unit
Antenna
coax cable
Power cable
N
T
i
n
D
i
a
A
l
O
0
R
0
–
4
7
E
+
0
c
o
1
u
4
n
.
0
t
r
3
y
.
4
3
c
o
d
0
e
3
+
D
e
c
s
B
u
1
o
E
b
9
o
s
s
c
1
!
/
?
2
a
b
c
4
g
h
3
i
d
e
f
5
j
k
l
7
p
q
6
r
m
n
o
8
s
t
u
9
v
w
x
0
y
z
9
k
c
6
r
i
b
L
e
a
r
s
t
n
o
M
e
n
u
S
e
e
k
H
e
lp
Telephone Unit
Power Supply
Figure 1.8 WorldPhone Voyager terminal.
WorldPhone – Chapter 1. Getting Started1.16
Contents Chapter 2. Operation
Introduction .................................................................................................. 2.1
Making a call ................................................................................................ 2.2
Call from telephone ..................................................................................... 2.8
Special calls ................................................................................................. 2.9
Receiving a call ......................................................................................... 2.10
Functions ................................................................................................... 2.13
Last number redialing ................................................................................ 2.15
Phone book ............................................................................................... 2.16
Key lock ..................................................................................................... 2.18
Selecting default Net service provider ....................................................... 2.19
User access ............................................................................................... 2.20
Data/printer port setup ............................................................................... 2.23
Phone setup .............................................................................................. 2.26
Setting default contrast and ringing volume ........................................... 2.27
Setting date and time ............................................................................. 2.28
Setting key lock ...................................................................................... 2.29
Language setup ...................................................................................... 2.30
Language reset ...................................................................................... 2.31
Mailbox access numbers ........................................................................ 2.32
Call charge setup ................................................................................... 2.33
Traffic log ................................................................................................... 2.34
Precharge .................................................................................................. 2.37
Precharge on SIM card .......................................................................... 2.42
OPERATION
Advanced functions:
Access control ........................................................................................... 2.44
Restricted dialing .................................................................................... 2.45
Restricted dialing setup .......................................................................... 2.46
Access code ........................................................................................... 2.47
Access code setup ................................................................................. 2.48
Restricted SIM usage ............................................................................. 2.49
Checking SIM restrictions ....................................................................... 2.50
Setting SIM restrictions .......................................................................... 2.51
Satellite setup ............................................................................................ 2.52
Net service provider and terrestrial network ........................................... 2.52
S/A operator and terrestrial network ....................................................... 2.52
Configuration ............................................................................................. 2.53
Port configuration ................................................................................... 2.53
Net service providers .............................................................................. 2.54
Power conservation ................................................................................ 2.55
Set diagnostics ....................................................................................... 2.55
Storing of Preferred/Allowed Net service provider
and Stand Alone operator on the SIM Card ........................................... 2.56
Charge tone ............................................................................................ 2.58
Information available ................................................................................. 2.59
IMN numbers .......................................................................................... 2.59
Misc. version ID information ................................................................... 2.59
Installation ................................................................................................. 2.60
Paid functions ......................................................................................... 2.60
Phone name setup ................................................................................. 2.60
The design and specifications of the
equipment may be changed without notice.
WorldPhone – User’s Manual
Chapter 2. Operation
General
The display and all controls on the WorldPhone are accessible via the
front telephone panel. See figure 1.1.
The light in the display and the screen picture may be timed for automatic
switching off for power saving. Pressing any key turns the display on again.
The display contrast can be altered using the arrow keys when the PIN
window or main window appears. See "Phone setup" for further details.
Function keys
Introduction
Help
PIN code
The text in the display
shows the function
currently assigned to
each function key:
Telenor in AOR–E
Dial 00 + country code + subscriber no
470
SIM Book Last Menu Seek
20 Sep 1998 15:20
Whenever needed, Example with window above displayed:
press the
key for assistance.
To make a call:
Dial 00 + country code + subscriber
number; press "Call" and wait for
answer.
(For an example, press )
470
Keys
Press Keys to go direct to the explanation
of the various tasks performed by the four function keys.
The user is prompted for the 4-8 digit Personal Identification Number
each time the WorldPhone is switched on:
•SIM PIN? (with SIM card).
•Phone PIN? (without SIM card).
Be aware that the PIN protection may have been disabled, see "User
access" in this chapter.
Introduction
Keying letters
The three letters on each number key are accessible when on display
lines requiring letters. Press the desired key for the first letter, and
continue rapid selection of following letters/numbers:
WorldPhone – Chapter 2. Operation 2.1
абвгдежз
Variants of letters on the key
For complete
character map,
see appendix F.
Making a call
Procedure
1
Dial 00 and the country code, followed by the subscriber number
(max. 22 digits).
For explanation of call numbers and list of country codes, see appendix A.
Handsfree Volume Del Escape
Making a call
Key in:
See also
"Call via alternative
Net service provider
or terrestrial network".
2
Pressing the Del
Number:004767244700
Net provider: Telenor
Terrestrial network: 00
470 SIM
function key deletes the
digit to the left of cursor:
3
Pressing the Call function
key sends the dialed number:
(or press the -key)
4
If the subscriber is listed
in the phone book, enter the
short number in the Number
field and press Short
to make the call:
Del Call Short
The Short function key is only visible when less
than 3 digits have been entered (max short number).
5
Lift handset and wait for answer.
Handsfree mode with handset in place.
6
Pressing the Esc key restores number
field (if edited), or reverts to main window.
7
Use up/down
arrow keys to adjust
Volume during
the call.
Calling 004767244700
via Telenor in AOR-E
Status : Call setup
Handset
470 SIM
on Mute Menu Clear
WorldPhone – Chapter 2. Operation2.2
Volume
Handsfree Volume Menu Book Clear Call to WorldPhone
Making a call cont’d
The call duration
is displayed when
connected.
For handsfree mode,
and use of loudspeaker
Calling 004767244700
via Telenor in AOR-E
Status : Connected
Handset
470 SIM
Alt.: Handsfree,
Loudspeaker
etc, see "Modes of operation".
8Pressing Menu
displays IMN numbers:
IMN numbers
Handset:762420510
Phone: 762420511
Fax: 762420512
Data: 762420513
(ESC returns to previous window.)
470 SIM
00:07:15
Volume
on Mute Menu Clear
Making a call cont’d
Book
Book then opens
phone book, allowing
selection
of subscriber:
Edit allows editing
subscriber data.
New allows entering new data:
See Phonebook
9To disconnect the call, put down the handset.
In Handsfree mode, press Clear.
To call the WorldPhone
Dial the international prefix (normally 00) followed by
87X IMN number, f.ex. 00 871 762420510.
Depends on which satellite the WorldPhone is currently using:
1 – AOR-E (Atlantic Ocean Region East)
2 – POR (Pacific Ocean Region)
3 – IOR (Indian Ocean Region)
4 – AOR-W (Atlantic Ocean Region West)
Nera SatCom AS
Phone book
102Nera Ltd Croydon
470 SIM
New Edit
Note! Some Net service providers support the common Ocean Region
access no. 870, which connects the call to the dialed WorldPhone
regardless of the Ocean Region the user currently communicates through.
WorldPhone – Chapter 2. Operation 2.3
Making a call cont’d
Modes of operation
Call with handset lifted
When in handset
mode, placing
handset down
terminates the
call.
4
1!/?
4ghi 5jkl
7pqr 8stu 9vwx
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
E
–
R
O
A
n
i
T
N
o
n
r
e
b
i
r
c
s
b
u
s
+
e
d
o
c
y
r
t
n
u
o
c
+
0
0
l
a
i
D
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
0
7
Esc
Help
2abc 3def
6mno
0yz
*
The WorldPhone switches to handsfree
mode if the handset is put down with the
loudspeaker on (loudspeaker mode).
Calling 004767244700
via Telenor in AOR-E
Status : Call setup
Handset
470 SIM
Loudspeaker
when monitoring
Volume
on Mute Menu Clear
Making a call cont’d
Handsfree call mode
E
–
R
O
A
n
i
T
N
n
u
o
c
+
0
0
l
a
i
D
0
7
Handset
in place
4
Esc
1!/?
2abc 3def
4ghi 5jkl
7pqr 8stu 9vwx
0yz
*
6mno
Loudspeaker on / off
Pressing Clear
Microphone muted/active (Mute/Mic)
terminates call
Calling 004767244700
via Telenor in AOR-E
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
o
n
r
e
b
i
r
c
s
b
u
s
+
e
d
o
c
y
r
t
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
Help
Status : Call setup
Handsfree
470 SIM
Volume
Mute Menu Clear
Loudspeaker permanently On
Microphone muted/active (Mute/Mic)
WorldPhone – Chapter 2. Operation2.4
Pressing Clear
terminates call
Terrestrial network
Call via an alternative Net service provider
or terrestrial network
Although default settings normally can be used, a different Net service
provider, or an other terrestrial network, may be selected as follows:
Alternative Net service provider:
Note! The WorldPhone must have been commissioned by the
selected provider; the call may otherwise be rejected.
1
Dial subscriber number.
Number:004766844700
Net provider: Telenor
Terrestrial network: 00
Making a call cont’d
470 SIM
2
Scroll down to Net provider and key in reference number,
Del Call
or press right arrow to display list of accessible Net service
providers:
3
Scroll up/down
to wanted
Net:
4
and press Selct:
Number:004766844700
Net provider: NT
Terrestrial network: 0
470 SIM
Net service providers
Default net
001CMC
002BT
003KDD
Selct
Alternative terrestrial network:
1
Scroll down to terrestrial network and key in reference
number.
Number:004766844700
Making a call cont’d
Continue with "Making a call", step 3
NB! A Net service provider may also be specified by starting the
telephone number with its reference code, e.g. BT:
WorldPhone – Chapter 2. Operation 2.5
Net provider: Telenor
Terrestrial network: 00
470 SIM
Del Call
Out box Sending NIMS message
Making a call cont’d
6
9
9
1
c
e
D
3
0
3
4
.
3
0
.
4
1
E
–
R
O
A
n
i
T
N
+
0
0
l
a
i
D
0
7
4
Es
1!/
2ab 3de
4gh 5jk
7pq 8st 9vw
0y
*
Note!
Sending and receiving
NIMS messages is
only possible through
service providers that
support the NIMS
service.
o
n
r
e
b
i
r
c
s
b
u
s
+
e
d
o
c
y
r
t
n
u
o
c
k
e
e
S
u
n
e
M
t
s
a
L
k
o
o
B
Hel
6mn
Sending NIMS message
20 Sep 1998 15:20
Telenor in AOR–E
Dial 00 + country code + subscriber no
470 SIM
Press Menu
and then Mail
to open Mail manager.
Function menu
001Set default Net provider
Set access level
Data/printer port setup
Phone setup menu
Traffic log
470 SIM
Book Last Menu Seek
Lock Mail Selct Quit
Making a call cont’d
Example:
You have received 6 messages,
3 are not read
One message is not sent
Pressing In opens In Box,
see Receiving a call:
Receiving NIMS message.
Indicates that the
message is not yet Sent
Mail manager
In Box : 6mail 3unread
Out Box :2mail 1unsent
You have new mail
470 SIM
In Out Setup Quit
Out Box
001 Have a nice day
002 Happy Birthday
470 SIM
Remov Edit New Print
Remov erases
selected message.
Print outputs message to
printer.
Appears only if a
printer is enabled, see
"Data/printer port setup".
Setup for sending mail
message
details
See next page
User name : Kari Nordmann
NIMS center : 004767244445
470 SIM
Pressing Edit changes
the function keys to allow
modifications:
ABC/abc selects
lower/uppercase letters.
Save stores changes.
WorldPhone – Chapter 2. Operation2.6
Edit OkEdit Ok
Ok reverts to
mail manager
Del ABC abc Save
Loading...
