Mobility Sound BH-P100 User Manual

BH-P100

Bluetooth Speaker

Microphone

User Manual

1. Introduction to the product

2. Pairing with your Bluetooth
Speaker Microphone

Power button

3.5mm

charging hole

1. Press the power button down
and hold it for 5 seconds.

2. The LED blue and red light
flashing alternately.

3. Release button then headset
will go into pairing mode.

PTT Clip

Press the power

button

Blue LED light Red LED light

3. Pairing with your Bluetooth Radio

Press and hold and power on radio

for 3 seconds till the LED is 2

flashes per second

MobilitySound Technology LTD.

www.mobilitysound.com
[e-mail]

How to - LED status

Turn on Press Power button for approx. 2 sec. (while BH-P100 is off) Blue LED blinking

Turn off Press Power button for approx. 5 sec. (while BH-P100 is on) Red LED blinking 3 times then off

Pairing Mode Press Power button for approx. 2 sec. (while BH-P100 is off) Red & Blue LED flashing alternately

PTT Press PTT button while BH-P100 paired with BT Dongle Red LED on when button pressed
