CONTENT
Introduction / 2
1. Package Contents / 3
1.1. Product Features / 3
1.2. Product Specifications / 3
1.3. D escription of Parts / 4
1.4. Charging the Battery / 4
1.5. Switching the Bluetooth Headset ON/OFF / 4
1.6. Handsfree Operations / 5 ~ 6
Troubleshooting / 7
Warranty / 7
Introduction
The Comfort Fit Bluetooth Headset is an
advanced wireless headset for Handsfree
operations. The device can be connected to
any Bluetooth phone that supports Headset or
Handsfree profile. The comfortable and soft
contoured ear piece secures the headset
along the ear wall. The Comfort Fit Bluetooth
Headset is convenient to wear and remains
comfortable even when used for extended
periods of time. With its light and elegantly
designed architecture, you can drive or walk
the streets with confidence enjoying
Handsfree. This instruction manual will get
you started!
3
1. Package Contents
Comfort Fit Bluetooth Headset
Charger Cradle
AC/DC Charger Adapter
Rubber Gel Ear Piece (2 sizes)
Phone clip and Lanyard
User’s Manual
1.1. Product Features
Bluetooth V1.2, 2.0 compliant
Supports Headset & Handsfree profiles
Unique contoured rubber gel ear piece
keeps headset secure in ear
High performance built-in speaker and
microphone
Red and blue LED indications for
Bluetooth operations, battery and charging
Up to 5 hours of talk time and 150 hours of
standby time
Simple to charge with the AC charger
cradle
Multifunction button (see 1.6)
1.2. Product Specifications
Weight – .33 oz.
Bluetooth V2.0
Range – 35 feet
Profiles Supported – HSP, HFP
Charger – Cradle with AC Adapter
Charge T im e – 2 hours
Dimensions – 1.6” x .74” x .35”
Ear Buds – two (2) sizes
4
1.3. Description of Parts
1.4. Charging the Battery
Before using the headset, charge the
battery for at least 2 hours.
To charge, first connect the charger cradle
with AC/DC charger adapter and then pl u g
the cord into power supply. Then place the
headset onto cradle and push down until
the headset gets locked with red LED on.
While charging, the headset LED will turn
red. When fully charged, the LED will turn
blue.
1.5. Switching the Bluetooth Headset ON/OFF
To power the headset on, click and hold
the MFB until Headset LED lights up blue
and flashes blue.
To switch power off, click and hold MFB
until Headset LED lights up red and then
shuts down.
MFB
(Multi-Function
Button)
VOL UP (+)
VOL DOWN ( -)
LED
(2-color)
5
1.6. Handsfree Operations
Function
Action / Tone Indicator
Pairing
Mode
Powered OFF, click and hold MFB continuously until LED alternates red and blue.
Pairing mode lasts for approx. 3 minutes. After this period the headset returns to
standby mode.
From a Bluetooth phone, search for device and establish the connection. If
prompted for pin key, enter ‘0000.’ The LED will turn OFF once connected.
Answer Call
Short click MFB to answer call. Ringer will sound from both phone and headset.
Make Call
To make a call, first dial from phone and short click MFB to switch call to headset.
Note: For some phones, call may automatically be transferred to headset.
Redial
To redial, double click MFB in idle state.
Note: When MFB is double clicked, some phones display the last number dialed
or received. Double click MFB again to redial. Some phones allow direct redialing
by double clicking MFB just once.
Voice Dial
Make sure your phone supports voice dialing and that it is activated. Ensure voice
tags have been recorded. To voice dial, press and hold MFB in idle Handsfree
mode. Follow the instructions message from your phone to complete voice
dialing.
6
Function
Action / Tone Indicator
Volume
Control
Click (+) or (-) to adjust volume during Handsfree mode. The tone will increase or
decrease while being adjusted.
End Call
To end a call first, press the MFB during ‘Talk Mode.’ If the other party ends the
call first, the headset automatically returns to Handsfree standby mode.
Reject Call To reject incoming call, press and hold MFB.
Call Transfer
During ‘Talk’ mode, if you want to transfer call from headset to phone or vice
versa, press the MFB.
Call W ait in g
To answer second call while in ‘Talk’ mode, press the MFB twice. To switch from
second call to first call, click the MFB twice. Note: This function can only be used if
user has subscribed for this service.
Microphone
Mute
For privacy reasons, if you don’t want your voice to be transmitted to the other
party, you can mute the microphone by pressing and holding the (+) and (-)
buttons together during talk mode. To cancel mute function, press and hold (+)
and (-) buttons.
Reconnect To reconnect headset with phone, press the MFB twice.
7
Troubleshooting
I hear electronic static noises –
For best sound quality always wear the headset on the same
side as your mobile phone.
I can not hear anything – Increase the volume of the headset, ensure the headset is paired with
the mobile phone.
I have problems pairing even though my phone indicates it is connected –
You may have
deleted your headset pairing connection on your phone. Follow the pairing instructions in your
phone’s user manual.
Will the Comfort Fit Bluetooth Headset work with other Bluetooth devices? – The Mobile Edge
Comfort Fit Bluetooth Headset is designed to work with Bluetooth mobile phones. It will work
with other Bluetooth devices that are compliant with Bluetooth version 1.1, 1.2 and support
Headset/Handsfree profile.
Warranty
Mobile Edge is pleased to provide the original purchaser of this accessory product a warranty for
defects in material or workmanship under normal use and service for one year from the date of
purchase. If you need to make a warranty claim, please provide the original receipt, on-line
registration, or other acceptable documentation. This limited warranty does not cover any damage
due to accident, misuse, abuse or negligence. Please contact Mobile Edge Customer Service at
info@mobileedge.com or 714-399-1400 for warranty service.
