Mobidick Supertooth Light User Manual

Bluetooth Handsfree Kit

For Bluetooth Mobile Phones

Product Description

SUPERTOOTH LIGHT is a Bluetooth handsfree kit that supports headset or
handsfree profile phones. Its special features include Full DSP Noise
Cancellation/Echo Cancellation, thus, it provides an advanced audio quality. It is
designed for easy handsfree operation and superior performance.

Don't forget: Drive safely and within the law.

Check if the national or local legislation into force in your country does limit the
use of mobile phones while driving. It is up to the user of this product to respect
the said legislation in the area where he lives.

Product Overview

1 Accept Button

2 End/Reject Button

3 Bluetooth Indicator

4 Charge Indicator

5 Microphone Shaft

*Press-and-release to Switch On
*Push-in to Switch Off

6 Speaker

7 Volume Down

8 Volume Up

9 Charger Port

10 Magnets

2

Charging

When the Bluetooth Indicator (3) turns red, the battery of the kit is low. Charge
the unit.

1. Connect the charger’s plug into the Charger Port (9)
of the SUPERTOOTH LIGHT. Connect the charger to
an external power source.

Charge Indicator (4) Status:

Steady red: Charging
Steady green: Full Charge

2. When fully charged, disconnect the charger.

Power On/Off

Power On: Press-and-release the Microphone Shaft (5).

Power Off: Push the Microphone Shaft (5) in.

Pairing to your Bluetooth Mobile Phone

Pair the SUPERTOOTH LIGHT to your Bluetooth mobile phone to create the link
or audio connection between the two. This has to be done only at the first
connection to a new phone.

1. From OFF, press and hold the Accept Button (1).

2. While holding the Accept Button (1), switch the kit on (Press-and-release

the Microphone Shaft (5)).

3. When the Bluetooth Indicator (3) turns blinking red/blue, release the
Accept Button (1). The kit is now in pairing mode.

3
