Page 1
DAH-1800
User’s Manual
Please read this user’s manual carefully before getting started.
Recharge the built-in battery using a USB cable before getting started.
Page 2
Safety Precautions / Special Features /
Specifications / Accessories /
Parts Designations / Buttons /
LCD / Power/ System Requirement/ Recharge/
Connection with PC/ Disconnection
Getting Started
Power On-Off / Modes/
Navigation (Folder search in ‘Play’)/
Menus/ Hold/ Clock
Music
Listening to Music/ Selection/ EQ/
Section Repeat/ Folder ‘Play’/
Lyrics/ Bookmark
Convenient Functions
M3U Playlist/ Delete-File/
Copy-File/ View-Text/ Stopwatch
Video/ View-Image/ Music-background/ Avatar
Images/
Video
Recording
Voice Recording/ Music Recording
FM Radio
Listening to FM Radio/ Region /
Frequency-search & save/Preset Mode/
Preset Delete / Recording FM Radio/
Quality / Rec. Booking
Program
Transcoder Installation/ Initial Page
Option Setting/ File Conversion /
Specified Field Conversion in a File/
Deleting File List/ File Information
Play in Multimedia Player / File Download-Upload
Format
Basic Functions
Page 24
Page 3
Page 30
Page 38
Page 44
Page 50
Page 54
Page 88
Support
This may not be a trouble! /
FCC RF INTERFERENCE STATEMENT /
Warranty Card
Page 106
Menus
Menu List/ Menu Buttons/ Setting/ Recording/
Display/ Timer/ Watch/ Play/ EQ/ SRS/ About
Page 66
Page 3
4
Safety Precautions
Getting Started
Safety Precautions
Special Features
Specifications
Accessories
Parts Designations
Buttons
LCD
Power
System Requirement
Recharge
Connection with a PC
Disconnection
4
7
9
10
11
13
15
17
19
20
21
22
The user may be in danger of death or a major injury if
he/she does not use the device in conformity with the
provisions stated in this mark.
The user may be subject to a major injury if he/she does
not conform to the provisions disclosed in this mark.
The user may be subject to a minor injury or property
damage when he/she does not conform to the
provisions of this mark.
Carefully read this part before using the product.
The Safety Precautions are classified into three categories; Danger,
Warning and Caution.
We are not responsible for any damage or loss if the device is not used
in conformity with these precautionary provisions.
Getting Started
Page 4
6
Safety Precautions
Getting Started
Safety Precautions
Getting Started
Don’t disassemble or
modify the device on
your own discretion.
Don’t put the
product close to
any heating device
or in direct sunlight. It
may explode.
Don’t touch the
device with a wet
hand.
Continuous recharge after
the completion of battery
recharge may damage the
product.
Use only the AC
adapter supplied with
the product.
Never use any chemical or
cleanser to clean
the device this
may damage
the surface of
the device.
The manufacturer is not
responsible for any damaged
data stored in the device if
the device error was
caused by the user’s
carelessness. The data
stored in the device may
be damaged during A/S.
Avoid humidity and dusty
areas.
Immediately reset
the device when it
generates excessive
heat or if there is
a burning smell,
and then contact our
A/S agent for repair.
D
A
NG
ER
DANGER
Listening to sound
sources with a high
volume may cause a
hearing disorder.
Keep the produce away
from children. Parental
attention is advised for
children’s use.
Avoid that headphone or
earphone is not jammed
between doors.
Page 5
Special Features
Getting Started
8
Special Features
Getting Started
10.Voice Recording
The built-in high performance microphone enables you to use many functions
of a professional voice recorder. With the aid of VOR function, this also
enables you to only activate the recording when there is at least more than
one sound source found in the peripheral area to save the memory space.
11.Music Recording
The device is also equipped with the Direct Encoding Function which enables you
to record sound sources from a FM radio, CD player, Walkman and other external
audio players with a simple one-touch button.
12. FM Radio Recording
FM radio recording will allow you to repeatedly listen to stored radio programs
and to send them to your PC.
13.Auto/Manual Lyric Streaming
You can simply create the lyrics for your favorite songs and they will appear
on the display. This device supports an easy lyric creating function with the
aid of the Auto Lyric system. You may also edit lyrics as per your need.
14.Language-learning Aid
With all convenient and essential functions for language-learning such as
section-repeat, sectional FF/REW, resumption, bookmark and others, the
device enables you to study languages very effectively.
15.Firmware Upgrade
You may update your device for additional or improved functions by
downloading the newest firmware in the Hyunwon’s website. One of the
leading MP3 player manufacturers, Hyunwon, is always a click away to
support you with continuously updated firmware.
Page 6
10
Getting Started
Accessories
Specifications
Getting Started
FM Tuner
Audio
USB
FM Frequency Range
Headset Output
S/N Ratio
Antenna
Frequency Characteristics
Headset Output
S/N Ratio
Supporting file types
Bit Rate
Download speed
30Mbps (USB Ver 2.0)
Audio : 15hours
Video : 5hours
-5
~70
Li-Polymer
87.5MHz ~ 108.0MHz
Max. 7mW (16 ) at Max.Volume
50dB
Headset/ earphone code antenna
20Hz ~ 20KHz
Max. 15mW (16 )at Max. Volume
90dB
MP3, WMA, OGG, JPEG, TXT,
PIX
MP3 : 8~320Kbps,
WMA : 32~192Kbps
OGG : Q0~ Q10
SpecificationsItems
Recording period
Max. Playback hours
Operating Temperature
Size (W
H D)
Weight (battery inclusive)
Battery (built-in)
FM radio 1040 minutes (with
256MB/ at 48Kbps recording mode)
USB Cable
Line-in Cable
Earphone
Program CD User’s Manual
The depicted images of below accessories may look slightly
different to their actual looks.
The actual looks of below lineup can be changed without prior
notice.
Portable Case
70mm x 30mm x 13mm
35g
Neck Strap
Page 7
12
Location of Controls
Getting Started
Location of Controls
Getting Started
Side
Top/ Bottom
LCD
FF
Volume
HOLD
Power/ Play/ Pause
Mode/ Lyric-view
(Background image)
Time
Earphone Port
USB Port/ Reset
EQ/ Bookmark
Record/
Section-repeat
Play-folder Change
Neck Strap
Hook
Page 8
14
Buttons
Getting Started
Buttons
Getting Started
Power ON/ OFF
Play/ Pause
View lyrics in ‘Music Play’
View background image in ‘Music Play’
View the time in ‘Pause/Stop’
EQ/SRS setting
Bookmark
Voice recording, Music recording, FM Radio recording
A-B section repeat in ‘Music Play’
Play-folder change
Cancel button
Enter Navigation/Menu
Save & Enter
Volume +/Search
Move up/ down in Menu/ Navigation
Move to the previous/next file
Search in the file
Search
- Move up/down in Menu/Navigation
Hold
Connection via USB (when switching ON after the
connection between the device and a PC)
Page 9
Display
Getting Started
16
Display
Getting Started
I: EQ
J: Bitrate
K: ‘Play’ elapsing time
L: ‘Play’ mode
M: Total number of files/ the
file number currently in
‘Play’
N: Graphic EQ
O: ‘Play’ file format
Recording Mode
FM Mode
A: Recording status
(in recording/ pause)
B: Alarm
C: Hold
D: Battery capacity
E: Folder name
F: File name
G: Sound source
(voice/ line-in/ FM)
H: VOR/ Auto Sync
I: Bitrate
J: ‘Recording’ elapsing time
K: Remaining time for further record
L: Process bar
A: Signal receiving/ ready
B: Alarm
C: Hold
D: Battery capacity
E: On-Air/ Mute
F: Frequency
G: Stereo/Mono
H: Channel No.
I: Preset mode
Page 10
18
Power
Getting Started
Power
Getting Started
(High) (Mid) (Low)
Lithium Polymer
Battery Type
Playback Hours
15hours (580mA)
Built-in Battery
Don’t use damaged built-in battery or AC adaptor.
Avoid excessive recharge longer than specified hours to prevent
fire.
Fully recharge the battery when trying to use it for the first time or
after a long-term disuse.
When the ‘hours of use’ of the battery gets shorter in comparison
with recharging hours, replace the battery.
Since the battery supplied with the product is consumable the
using hours of it slowly gets reduced.
The built-in battery can be recharged (from full discharge to full
charge) for about five hundreds times
Avoid any metal part from contacting DC converter or built-in
battery to avoid unexpected fire or electric shock.
Disposal
The product includes a built-in Lithium-polymer battery. The
battery is recyclable so please return it to nearest ‘recycle center’
when you dispose the product. Don’t disassemble the product at
disposal.
Page 11
System Requirement
Getting Started
Recharge
Getting Started
1.Connect the device into a
PC using the USB cable
supplied in the package.
2.Recharge is in process while
downloading or uploading files.
4.Disconnect the USB cable at the completion of the
recharge. (See Page 21)
It takes approximately 3 hours to completely recharge a fully consumed
battery.
“Complete” will display if you press at the completion of the recharge.
Recharge the device using the USB cable when the display is not
activated.
If the Hold key is activated in recharge process, the USB connection is also
activated to down/upload the files.
3.Press shortly in
‘Pause/Stop’ to check
the recharge process.
System Requirement
Page 12
Getting Started
Getting Started
Connection with a PC
2.
Connect the product with
a PC using a USB cable
3.
The screen displays the icon on the left if the
connection is correctly made.
Disconnection
1.Double click on the green arrow on the right-bottom part of the
initial Window screen.
2.Click on Stop and OK (enter) consecutively after selecting “USB
Mass Storage Device”
Double Click
3.Click on OK (enter) on the “Safety removal of the hardware”
message bar followed by cable removal.
Click
Click
Click
Page 13
Getting Started
Disconnection
Click
Power On-Off
Modes
Navigation
Menus
Hold/ Clock
Basic Functions
25
26
27
28
29
Page 14
Power ON/OFF
Basic Functions
26
Modes
Basic Functions
Press and hold to turn the power on.
There are altogether 6 modes programmed in the device; Music play,
Voice recording, Music recording, Radio, Playlist and Stopwatch.
Different functions are available for each mode.
Press
and hold
move to
‘Radio’ mode
Press
‘Radio’ mode
to enter
‘Radio’ mode
Press and hold to turn the power off.
Page 15
28
Basic Menu Operation
Basic Functions
Navigation (Folder search in playing)
Basic Functions
to move to the
folder “Hyun”
Press
Press
to enter “Hyun”
to move to
“Bye Bye.mps”
to move back to
the upper level
to get out of the
Navigation mode.
Press
See Page 69 for menu details.
to enter the menu
Press
and hold
or
Press
to enter the lower
folder level
to move to another
menu and to adjust
the set value
Press
to move back to the
upper folder level
Press
to return to the main
screen
Press
Press
Press
to play
“Bye Bye.mp3”
or
Page 16
Listening to Music
Selection
EQ/Section Repeat
Folder ‘Play’
Lyrics
Bookmark
31
32
33
34
35
36
Music
Hold/ Clock
Basic Functions
1.Place the button on the side of
the device to arrowed direction to
hold all functions
2.No button is functioning in Hold
status.
Press
Time check
In Stop/ Pause mode…
Press any button while checking
the time to cancel ‘View time.’
Page 17
Listening to Music
Music
32
Selection
Music
In Stop or Pause status
Press
to play the file
In Play status
Press
to pause the file
Press
to adjust the sound volume
Moving to another files
Searching a part in the file
In Stop, Pause or Play status
Press
to move to the previous/next file
Press and hold in Stop/Pause status to fast search the
file you desire
In Play status;
Press and hold
to fast search a certain part in the
file (FF/REW)
Press to get back to the initial part of the file when the play
elapsing time is within 5 seconds.
Page 18
34
Music
In Play status;
Press
and hold
the folders are changing as
follows; current folder – all
folders – playlist – bookmark
Current folder : The device only plays the files (repeat,
random repeat and play ‘initial part’) in the
current folder.
All folders : All files stored in the device are played.
Playlist : The files added to the playlist only will be played
Bookmark : The files registered in the bookmark only will be
played.
The play modes (repeat, random repeat and play ‘initial part’)
can be set by entering ‘Menu’ mode. (See Page 82)
EQ/ Section repeat
Music
Press
to change the setting from Normal – Live – Dance –
Rock – Jazz – Classic – Pop through to SRS in
sequence.
Press
Press
EQ
to set “A”
to set the
section “A-B”
Setting for a folder to play
Page 19
36
Bookmark
Music
Lyrics
Music
Setting for bookmark
Playing the bookmarked file
Press
and hold
In ‘Play’ status;
Press
and hold
In Stop or Pause status;
to play.
Press
Bookmark setting is not possible in Stop or Pause status.
Press
bookmark list
Press
to move to the
file you desire
to display ‘Music Play’ screen.
Page 20
M3U Playlist
Delete-File
Copy-File
View-Text/ Stopwatch
39
41
42
43
Convenient Functions
Page 21
M3U Playlist
Convenient Functions
40
M3U Playlist
Convenient Functions
What is the M3U file?
This is a file format which only has the location
information of a file group.
The M3U file can be written in PC Players such as Winamp, Windows and
Media Player.
‘The M3U file can be only created with the music files stored in the product.
The M3U file will not be played if you paste the file into the product after
writing the file with music files stored in the PC.
The file name for the M3U file format should be always “Playlist,”
otherwise, the device can not play the file. In this case, the M3U file can be
only played when the product is connected with the PC.
If there is an existing file stored in the device, the new M3U file will
overwrite it..
The original files for a M3U file will not be deleted at the deletion of the
M3U file.
The language set in “Menu Setting Language” in the device should
correspond to that of Windows OS.
Writing the Playlist using a PC Player
1.Connect the device with a PC using a USB cable. (See Page 20)
2.Run ‘PC Player’ to write a M3U file.
3.Save the files stored in the device into “Playlist.M3U” following the Playlist edit
in the PC Player.
4.Perform the ‘Safety Removal’ of the device from the PC. (See Page 21)
5.You can play the M3U file by entering the Navigation mode.
to move to
“Bye Bye.mp3”
Press
to display a
popup window
move to
“Palylist”
Press
to complete
the playlist.
Press
Page 22
42
File “Copy”
Convenient Functions
File ‘Delete’
Convenient Functions
move to
“Bye Bye.mp3”
Press
to display the
popup window
move to
“Delete”
Press
to display the
popup window
move to
“Yes”
Press
to delete
“Bye Bye.mp3”
You can change the location of the files in the device with the aid of this
function.
Press
In ‘Music Play’
mode;
move to
“Bye Bye,mp3”
For example; when copying “Bye Bye,mp3” file into the FM folder.
Press
to display the
popup window
move to
“Copy”
Press
to display all folders in
the device
move to
“FM” folder
Press
Press
to enter the
“FM” folder
The original files copied to other folders will not be deleted.
A certain period time is required to copy a file into another folder.
A file can not be copied into ‘ROOT.’
The files having the extensions such as mp3, wma, ogg, jpg and txt can
be copied and pasted into other folders.
to complete
the copy.
Page 23
View-Video
View-Image
Music-background
Avatar
45
46
48
49
Images/ Video
Text ‘View’/ Stopwatch
Convenient Functions
to move to
“Stopwatch”
Press
to enter
“Stopwatch” mode
to start the
function
Press
Press
Page 24
Images/ Video
Video ‘View’
Images/ Video
Image ‘View’
You can search for a image file while you are enjoying the music file
“Lighting period” will be set to “Always” automatically if you view
the images.
It may take longer to display the big sized files.
Press
In ‘Music Play’
mode;
to move to
‘Sky.jpg’
For example; when playing ‘Sky.jpg’
Press
to open
‘Sky.jpg’
Press
to search the
previous/next file
Press in image ‘view’ mode to return to the Navigation mode.
to move to
‘Sky.PIX’
Press
to open
‘Sky.PIX’
File Search
Press
Play next/previous file
Press
and hold
Search FW/RW in the currently
playing file
Press
Move one step forward/backward
Press
and hold
Continuous moving forward/backward
Page 25
Images/ Video
Background Image
Images/ Video
Background Image
Background Image
Press
Press in playing the music file marked with a ‘Lyric’ to change
the mode; Lyric view Background image Music play.
The size of the image can be adjusted in “Menu Display Image
Size”
It may takes relatively long to load the image data for the background
image.
Recommended image size for the background image is 680 * 480
pixels/ 30kb.
In Music
Play status;
to view the
Press
to cancel the function
Page 26
Images/ Video
Avatar
Voice Recording
Music Recording
51
52
Recording
Page 27
52
Music recording (Line - in)
Recording
Voice Recording
Recording
to move to
“Voice’
Press
to enter
“Voice”
to start
recording
to stop the
recording
Connect the device into the external audio player with the Line-in cable
supplied in the package.
Analog sound signals can be converted to digital sound by
recording the external audio sources with the Line-in cable
supplied in the package.
With the aid of earphone, you may listen to the music which is
being recorded to the device (Loop back).
When there is no sound source detected for more than
1.5seconds in the recording, the device will get ready for another
file recording. (See Page 75)
Press Press
Press
Record
elapsing
time
Record
remaining
time
Page 28
Music recording (Line - in)
Recording
FM Radio
Listening to FM Radio
Region
Frequency-search & save
Preset Mode
Deleting Frequencies
Recording FM Radio
Tone quality
Programmed Recording
55
56
57
59
60
62
63
64
to move to
“Line-in”
Press
to enter
“Line-in” ”
to start the
recording
to stop the
recording
Press
Press Press
Record
elapsing
time
Record
remaining
time
Page 29
Listening to FM Radio
FM Radio
56
Region
FM Radio
to move the “FM
Radio” mode
Press
to receive the radio
signals.
This function helps you set the correct frequency ranges which are
variable according to the countries.
Press
and hold
to move the
“Region”
Press
to move to
“Korea”
Press
to set for
“Korea”
Korea : from 87.5 to 108.0MHz with100Khz intervals
Japan : from 76.0 to 108.0MHz with 50Khz intervals
Worldwide : from 87.5 to 108.0MHz with 50Khz intervals
Press
Press
Press
At the change of the country, the preset values for previous
country will be initialized.
Page 30
Frequency search/ save
FM Radio
58
Frequency save
FM Radio
Press
to increase or decrease by 0.1MHz
Press and hold
to continuously increase or decrease
the frequency
Press
move to
“CH03”
Press
Auto Preset
Press
and hold
to move the
“ON”
Press
to save the
frequencies
automatically.
Press in auto frequency search to halt the process.
The mode will be automatically changed to the ‘Preset’ mode at
the completing of the search.
to move to
“Auto Preset”
Press
Press
Press
Page 31
60
Preset Delete
FM Radio
Preset Mode
FM Radio
In Preset mode;
to increase/decrease the channel number
Press
and hold
to move the
“Preset Delete”
Press
you can delete all or
a part of channels
Move to
“ ALL”
Press Press
delete all
stored
channels.
When deleting all frequencies
move to
“Yes”
to enter ‘Preset’
Page 32
62
Recording FM Radio
FM Radio
Preset Delete
FM Radio
Press
move to
“99.3MHz”
Press
delete
99.3MHz from
CH03
Recording FM Radio
In FM receiving status
Press
to start the
recording
Press
to stop the
recording
Press in recording to pause the recording and press again
to resume.
Recorded sound source is saved in MP3 format in FM folder in the
following sequence; F001.MP3, F002.MP3…..
You can listen to the recorded file by entering “Music Play” – “FM”
folder
Page 33
Quality
FM Radio
64
Rec. Booking
FM Radio
to move to
“Record Tone
Quality”
Press
to move the
“Rec. Booking”
Press
Press
Press
Press
Press
You can set ‘programmed recording’ for any FM Radio program
you desire by setting the date and time for the program.
On/Off
Press
and hold
to move the
“On/Off”
Press
to move to
“Rec. Booking”
Press
Press
Press
Press
Press
On : Setting the recording for pre-designated date and time
Off : Setting is not available.
Page 34
Rec. Booking
FM Radio
Menus
Menu List
Menu Buttons
Setting
Recording
Display
Timer
Watch
Play
EQ
SRS
About
67
69
70
74
76
79
81
82
85
86
87
to move to
“Setting”
Press
to move the
“Rec. Booking”
Press
Press
Press
Move to another items:
setting value adjustment :
Press
Press
Page 35
68
Menu List
Menus
Menu List
Menus
Main menu Sub menu
Set menu
Page 36
Menu Buttons
Menus
70
Setting
Menus
Press and hold
Press
or
Press
to change the values
to save the value
Press
Press
Resume
Select “Setting” from the main menu.
This function fully recovers all previous settings for the last song’s
volume, EQ, Playlist and all others when you turn the power on
again.
On : fully recovers all previous setting information
Off : The setting values are not saved
Defualt
You can reset all settings you made into the originally set values.
Yes: All information will be initialized
No: The settings you made will be saved.
Page 37
72
Setting
Menus
Setting
Menus
Beep sound
It sounds at pressing buttons.
Fade in
This function slowly increases the volume up to the set volume level.
On: The volume of the file is increased until the preset level.
Off: The file starts with the set volume level.
On: It sounds at pressing Play and FF/REW.
Off: The function is not available.
Page 38
74
Recording
Menus
Setting
Menus
Language
Select “Recording” from the main menu
Voice – Bitrate
Bit rates for the recording can be selected among 32, 64, 96 and
128kbps.
Voice – VOR
This enables you to only activate the recording when there is at
least more than one sound source found in the peripheral area to
save the memory space.
Off : the function is not available
Library : you can select this option when recording the sounds in a
silent area.
Office : select this option when recording the sounds in the area with
the slight noises.
Street : select this option when recording the sounds in a noisy area.
Page 39
Recording
Menus
76
Screen Setting
Menus
Contrast
You can set the brightness of LCD within the range from 1 to 10.
Select “Display” from the main menu
Screen Saver – On/Off
It is activated when the device is not in use for the preset time period
(from Off to 10seconds)
Page 40
Screen Setting
Menus
78
Screen Setting
Menus
LCD Pivot
On: It activates the function
Off: Basic setting for the LCD
Graphic EQ
This enables you to display four different types of images on the LCD;
wave, stereo, progression, clock)
Image Size
You can select different image sizes for ‘Background Image’
Standard : The background image along with the file information is
displayed on the screen.
Full : The pre-selected image is displayed on the full screen while the
music file is played.
Page 41
80
Timer
Menus
Timer
Menus
Auto Hold
Sleep Mode
This function automatically turns off the power of the device for your
sleep after a preset period of time; Off/10min/20min/30min/60min.
Page 42
82
Playback
Menus
Watch
Menus
Watch
Alarm – Setting
Select “Play” from the main menu
Play Folder
You can select the range of playback.
Current Folder : All files in the current folder are played.
Folder All : All files in all folders are played
Playlist : Only the files added into the playlist are played
Bookmark: Only the files added into the ‘Bookmark’ are played.
Repeat
You can repeatedly play music files by setting this function.
ALL : All music files within the preset range will be repeatedly played.
ONE : Only the file you desire will be repeatedly played.
OFF : All music files within the preset range will be played once.
Move to another items:
Set value adjustment :
Set value adjustment :
Page 43
Play
Menus
84
Play
Menus
on : All music files within the preset
range are played randomly.
off : All music files within the preset
range are played in sequence.
Intro
On : The function is activated.
Off : The whole file will be played.
Study Mode
When trying to search a certain part in a file using FF/REW in
play mode, this function enables you to skip for a preset interval
(Off to 180).
Sound Balance
You can set the left/right volumes of the earphone balanced within
the following range: - 20 to 20.
When it gets closed to 20 the left volume increases while it gets
to -10 to increase right volume.
Page 44
86
SRS
Menus
EQ
Menus
EQ Reset
Press
Press
Select “SRS” from the main menu.
SRS
You can set the 3D surround within the range from 1 to 10.
TruBass
This function enhances the bass within the range from 1 to 10.
Headphone Select
You can select either headphone or speaker for SRS.
User-select EQ
Audible
frequency band
Page 45
Programs
Transcoder Installation
Initial Page
Option Setting
File Conversion
Specified Field Conversion in a File
Deleting File List
File Information
Play in Multimedia Player
File Download-Upload
Format
About
Menus
Page 46
90
Transcoder Installation
Programs
Transcoder Installation
Programs
Input
Output
Multimedia Transcoder
PIX
The program will automatically run at the insertion of the program
CD into the CD-ROM.
USB driver installation program for Windows98SE users.
(File downloading/ uploading is freely available to those who
use Windows ME/ 2000/ XP OS systems without USB driver
installation)
The program converts video files (WMV, ASF, MPG, AVI) into
PIX.
The program enables you to write lyrics in the music file. (See
attachment for its use)
Click
Page 47
Transcoder Installation
Programs
Transcoder Installation
Programs
Click on “Finish”
to complete the installation.
An icon
“Multimedia Transcoder” will be created on the desktop at
the completion of the installation.
Select the program
folder and click on
“Next.”
Click
Click
Click
Click
Click
Page 48
Option Setting
Programs
Initial Page
Programs
You can set the option for the file to be converted.
Double click on the icon on the desktop and Press
You can set the image quality with this function.
Most of DivX movies have
the size of 720 X 480.
If you convert a movie which
has longer width, the image
looks vertically longer.
In this case, select Wide
Screen to adjust the image
for correct vertical/horizontal
ratio.
F : File List
G : File Field Setting
H : Conversion Start/
Conversion Completed
I : File Conversion Status
select High, Middle, Low
Default
Page 49
File Conversion
Programs
Option Setting
Programs
Double click on the icon on desktop Press
to select an Input File.
Press It automatically stops and saves the
file at the completion of conversion.
[In the process of conversion]
Click
Output file
directory setting
Bit-rate setting
Page 50
Deleting File List
Programs
Specified Field Conversion in a File
Programs
press to play the file move the file scan
to set the end point press to select
[Selecting a field to be converted]
Select the file you want to cancel in the file list click on
right mouse button select “Delete Selected List,” “Delete
All List” to delete the file.
Start point
End point
Page 51
Play in Multimedia Player
Programs
Programs
The converted file can be played in Multimedia Player.
Double click on the icon from the desktop – press
to select the file you want to play – press to start playing
[in the process of Play]
Page 52
File Download/ Upload
Programs
File Download/ Upload
Programs
2.Click on “Paste” to paste the copied file into the ‘Removable Disk’
window using the right mouse button.
PC recognizes the product as a removable disk newly found in
“My Computer.”
Don’t remove the USB cable while transferring the files. It may
cause a fatal error in PC or the product.
Click
xls, hwp…) taking the role as a removable disk as well as a
Click
Page 53
Programs
Programs
File Download/ Upload
Format
1.Choose “format” in the removable disk folder using the right
mouse button.
The removed files through the format can not be recovered!
Click
Page 54
Programs
Format
Check if file system is set for FAT32
Be very careful at formatting!
Click
Click
Click
Support
This may not be a trouble!
FCC RF INTERFERENCE STATEMENT
Warranty Card
107
109
Page 55
108
This may not be a trouble!
Support
This may not be a trouble!
Support
Check battery capacity. Recharge the battery
with a USB cable.
Check if the device is in HOLD.
Check if the device is in HOLD.
Check if any foreign material is applied on the
earphone tip, If yes, remove it.
Completely push the earphone tip into the
device.
Check if the file is damaged.
Check the volume.
Check if the earphone is completely inserted into
the jack. It functions as an antenna.
Use the device away from peripheral electric
devices
4.Too much noise interference with interrupted FM receiving?
Check the connection of the USB cable.
Check the availability of the memory capacity.
Check the LCD brightness setting. Menu
Display Contrast
Check the battery. Recharge it with a USB
cable if needed.
5.If there is trouble with file downloading?
6.LCD is not activated?
Page 56
FCC RF INTERFERENCE STATEMENT
Support
You need to present this Warranty Card with the date of purchase written thereon
when required in order to receive satisfactory services. Please keep this card in a
secure place.
The design and size of the product are subject to change without prior notice in order
to improve product quality.
1. The warranty service for the product shall be provided based on the
information contained in this Warranty Card.
2. The warranty service is available effective from the date of purchase, so
please put the date of purchase on this Warranty Card. (If the date of
purchase is not identified in the card, the effective warranty period will start
from the date 6 months from the date of manufacture.)
3. This Warranty Card can not be reissued
Warranty Card
Product Name:
Model:
Date of Purchase: (m) (d) (y)
Name of Customer Telephone Number:
Address:
Name of Agent: Telephone Number:
Address:
1 year from
the date of
purchase
Loading...
