MJX F47, F647 Instruction Manual

ITEM NO.F47/F647

1

Thank you for purchasing this product. Please read this manual carefully
before use and retain it for future reference.

Technical parameter of the helicopter

Introduction

With single-rotor design and built-in gyro, the helicopter is more flexible
and much stronger.
New designed structure makes assembly and maintainance easier.
Adopting 2.4G auto connection technology, scores of helicopters can be
played at the same time.
With high power capacity of 3.7V 380mAh li-polymer battery, flight time is
about 8 minutes.
LCD remote control is included.

Safety Guidelines

This product is not a toy. It is not applicable for children who are under
14 years old.
Please read this instruction manual carefully before playing and operate
the product according to the manual.
The users are in full charge of proper operating the helicopter. The
manufacturer and dealers disclaim all responsibility for the damage
caused by misuse.
Keep the small accessories away from the kids to avoid accident.
Keep batteries away from fire or high temperature environment.
When flying the helicopter, keep it 1~2 meters away from user or others
to avoid injury due to collision.
Not to decompose or modify the product which may cause malfunction
or accident.
Fly the helicopter within your eye vision for easy and safety control.
Need adult supervision when this helicopter is being played by children.
Only batteries of the same or equivalent type as recommended are to be
used.
Insert batteries with correct polarity.
Non rechargeable batteries are not to be charged; the transmitter need
4XAA batteries for work.
Do not mix old and new batteries.

Gross Weight: about 49g

Motor: N30

Tail Rotor Diameter: 50MM

Battery: Li-polymer 3.7V

Fuselage Length:235MM

Overall height: 80MM

Gear Ratio: 8:1 Charging Time: about 70 minutes

Main Rotor Diameter: 225MM

2

The LCD Remote controller

Remote Controller

(Transmitter)

2.4G, LCD reomote control, scores of helicopters can be played at the
same time.
Control function:upward,downward, forward, backward,leftward,
rightward, turning left and turning right.
Throttle control stick can be freely switched according to player's habit.

1

2

Product/spare parts included in this packaging

Description

Left stick

Right stick

3 Trimmer A

In stick Mod 2 and 4, this button is null.
In stick Mod 1and 3, it helps to tune the helicoper's
forward and backward flight.

Helicopter 1

1
2

1

2

Remote controller

Rotor blade

Manual

3.7V 380mAh li-polymer battery

Qty(pc)

Description

Qty(pc)

1. Left stick

11. Throttle changing
button (Left)

11. Throttle changing
button (Right)

7. Power switch

8. Antenna

9. Power indicator

2. Right stick

3. Trimmer A

4. Trimmer B

5. Trimmer C

10.Throttle limit knob

12.flight mode

changing button

13.aileron/rudder
changing button

6. Trimmer D

No. Function switch Function description

Main features of the remote controller

Sketch and function switches of the remote controller

Tail Rotor 1

USB charger 1

POWER

STICK MOD2:upward/downward,turn left/turn right;
STICK MOD4:upward/downward,leftward/rightward.
STICK MOD1:forward/backward,turn left/turn right;
STICK MOD3:forward/backward,leftward/rightward.

STICK MOD1: upward/downward,leftward/rightward;
STICK MOD3: upward/downward, turn left/turn right;
STICK MOD2: forward/backward,leftward/rightward;
STICK MOD4: forward/backward,turn left/turn right.

3

4

In stick Mod 3 and 4, it helps to tune the helicopter's
sideward flight.
In stick Mod 1 and 2,it helps to tune the helicopter's
left and right direction turning speed.

In stick Mod 3 and 4, it helps to tune the helicopter's
left and right direction turning speed.
In stick Mod 1 and 2,it helps to tune the helicopter's
sideward flight.

In stick Mod 1 and 3, this button is null.
In stick Mod 2 and 4, it helps to tune the helicoper's forward
and backward flight.

It controls the power source of the transmitter.Slide
the power switch to the “ON” position, the transmitter
is powered on; slide the power switch to the “OFF”
position, the transmitter is powered off.

No. Function switch Function description

Trimmer B

5 Trimmer C

6 Trimmer D

7

8

Power switch

Antenna

9

Power
indicator

Transmits wireless signal.

The indicator light keeps blinking slowly: the transmitter
is not activated.
The indicator light keeps flashing rapidly: the transmitter
is sending out connectional signal to the helicopter.
The indicator light keeps on without blinking: the
transmitter is ready for controlling the flight.

10

Throttle limit

knob

The throttle of the helicopter can be adjuted by this button,
player can use this button to increase or decrease the
helicopter's upward/downward speed.

11

12

13

Throttle

changing button

Slide down or slide up the 2 buttons at the same time
to select the throttle control stick

There are 3 flight modes of the helicopter: low speed, medium
speed and maximum speed.

aileron/rudder

changing button

Also named Stick Mode changing button.Press this button
to change the control stick mode.

flight mode

changing button

Remote controller’s setting

Select the throttle control stick

There is 1 throttle button on either side of the remote controller.
Slide both of the 2 buttons to "R", the right stick is the throttle control stick.
Slide both of the 2 buttons to "L", the left stick is the throttle control stick.

Tip: both of the 2 buttons should be either on the position of "R" or "L",
otherwise, the remote controller can not be activated.

4

STICK MOD:1 STICK MOD:2

POWER

Pic.3

Pic.4

Forward /

Backward

control

Forward /

Backward

control

Forward /

Backward

control

Forward /

Backward

control

Throttle

control

Throttle

control

Throttle

control

Throttle

control

Left/Right

turning

control

Left/Right

turning

control

Left/Right

turning

control

Left/Right

turning

control

Leftward/

Rightward

control

Leftward/

Rightward

control

Leftward/

Rightward

control

Leftward/

Rightward

control

STICK MOD:3 STICK MOD:4

PUSH

EXIT/
LIGHT

MENU/
OK

POWER

Pic.5

Pic.6

There are 3 flight mode available: low speed, medium speed and maximum
speed.Player can select the flight speed by pressing the flight mode button.

Stick Mode Selection

Flight mode selection

Pic.1 Pic.2

Activate the LCD remote controller

Slide the power switch to "ON" position after throttle control stick selection

is done.To activate the remote controller, slowly push up the throttle control
stick to the top and then push it down to the bottom. The remote controller
is activated once a beep sound is heard. Then, the indicator light keeps
flashing while the remote controller is sending out connectional signal. It
takes about 10 seconds to finish the signal transmission process. After
signal transmission is completed, the indicator light keeps constant "on”.
User can turn either the left stick or the right stick to skip the signal
transmission process and enter into the start-up interface directly.

There are 4 flight modes available for selection: Stick Mod 1 (Pic.3)
Stick Mod 2 (Pic.4) Stick Mod 3 (Pic.5) Stick Mod 4 (Pic.6)

5

This is the low speed icon. This is the medium speed icon. This is the maximum speed icon .

Pic.8

Pic.7 Pic.8 Pic.9

How to charge the helicopter

CH

STICK MOD

00

1

2

CH

STICK MOD

00

1

2

CH

STICK MOD

00

1

2

The helicopter

This helicopter is included with USB charger.
Before charging, please disconnect the battery power plug from
helicopter PBC cable plug.Then, connect the battery power plug to the
USB cable and insert the USB interface to any equipment which is with
USB interface.
When the battery is underpowered, the charging light of the USB is off;
when the battry is full charged, the charging light of the USB is on.Full
charge taks about 70 minutes.

connector

stabilizer bar

Tail motor

rotor blade

battery connector

battery compartment

landing gear

Computer

6

Turn on the remote control. To activate the remote controller,slowly
push up the throttle stick to the top and then push it down to the bottom.
The remote controller is activated once you hear a beep sound.Then, the
indicator light flashes rapidly while the remote controller is sending out
connectional signal.

Connect the battery plug to the helicopter battery cable,the indicator
light of the helicopter will keep slowing flashing,set the helicopter down
to a platform. Once the helicoter receives the connecting signal,the
indicator light of the helicopter will keep flashing rapidly to check the

Preparation for flight

gyro,then,push up the throttle stick slowly to takes off the helicopter.
If the helicopter is flying slightly to one side, please use the trimmer

button to tune it to balance.

Check and regulate the swashplate of the helicopter

(1) If the swashplate is slightly inclined, it is okay to regulate the trimmer
button of the remote control to get the swashplate retain horizontal.
(2) If the swashplate is greatly inclined, then, it should be better to
regulate the length of the servo connecting bar to get the swashplate
parallel to the ground. The operation instruction are specific as follow:

The swashplate of the helicopter should be kept horizontal, otherwise, the
helicopter will fly forward/backward/leftward/rightward automatically even
though no control signal is given. Hence, it is very important to check and
confirm that the swashplate is horizontal before flying the helicopter. To
get the swashplate horizontal, there are two ways available for regulation.

7

A.When the helicopter is hovering but still
keeping flying forward automatically,
please take out the elevator servo
connecting bar, then, clockwise rotate
the bar for one circle(360°). How many
circle should be regulated will depend
on the tilt angle of the swashplate.
Generally, rotate the bar for one or two
circles for one regulation.(Pic 10)
B.When the helicopter is hovering but still
keeping flying backward automatically,
please take out the elevator servo
connecting bar, then, counter-clock wise
rotate the bar for one circle (360°). How
many circle should be regulated will
depend on the tilt angle of the swashplate.
Generally, rotate the bar for one or two
circles for one regulation. (Pic 10)
C.When the helicopter is hovering but still
keeping flying leftward automatically,
please take out the aileron servo connecting bar, then,
clockwise rotate the bar for one circle(360°). How many circle should be
regulate, will depend on the tilt angle of the swashplate. Generally, rotate
the bar for one or two circles for one regulation.(Pic 11)
D.When the helicopter is hovering but still keeping flying rightward
automatically, please take out the aileron servo connecting bar , then,
counter-clockwise rotate the bar for one circle(360°). How many circle
should be regulate, will depend on the tilt angle of the swashplate.
Generally, rotate the bar for one or two circles for one regulation. (Pic 11)

swashplate

the elevator servo
connecting bar

the aileron servo
coneecting bar

Pic9

Pic11

screw the aileron
servo connecting
bar clockwise
or counter
clockwise

Pic10

screw the elevator
servo connecting
bar clockwise or
counter clockwise

Parallel

the bottom plane of the
swashplate

Extension line
of the helicopter

Pic12

Tips

8

Trimmer Functions

STICK MOD 2 or 4:

STICK MOD 1 or 3:

If the helicopter keeps moving forward/backward even there is no control
signal given, users may adjust the elevator trim to keep the helicopter
balanced.

If the helicopter keeps moving
backward, push up Trimmer A
until it gains balance.

If the helicopter keeps moving
forward, push down Trimmer A
until it gains balance.

If the helicopter keeps moving
backward, push up Trimmer D
until it gains balance.

If the helicopter keeps moving
forward, push down Trimmer D
until it gains balance.

STICK MOD 3 or 4:

If the helicopter keeps moving leftward/rightward even there is no control
signal given, users may adjust the aileron trim to keep the helicopter
balanced.

If the helicopter keeps moving
leftward, turn right of Trimmer B
until it gains balance.

If the helicopter keeps moving
righttward, turn left of Trimmer B
until it gains balance.

9

STICK MOD 1 or 2:

STICK MOD 3 or 4:

If the helicopter keeps spinning even there is no control signal given,
users may adjust the rudder trim to keep the helicopter balanced.

If the helicopter keeps spinning
counterclockwise in the air,turn
right of Trimmer B until it gains
balance.

If the helicopter keeps spinning
clockwise in the air,turn left of
Trimmer B until it gains balance.

If the helicopter keeps spinning
counterclockwise in the air,turn
right of Trimmer C until it gains
balance.

STICK MOD 1 or 2:

If the helicopter keeps moving
leftward, turn right of Trimmer C
until it gains balance.

If the helicopter keeps moving
righttward, turn left of Trimmer C
until it gains balance.

Operating

Upward

Push up the throttle control stick, the
rotation speed of the mains rotors are
increasing and the helicopter ascends
accordingly.

If the helicopter keeps spinning
clockwise in the air,turn left of
Trimmer C until it gains balance.

10

Trouble shooting

Problem

No reaction

from the

helicopter

1.The helicopter is underpowered. 1.Get the battery of the helicopter charged

2.The indicator light of the helicopter
flashing rapidly, and the gyo is in
the testing statement

2.Set the helicopter down to a platform, until the
indicator light turn to constant ”ON” without
blinking.

3.Repeating the connection procedure.

3.the helicopter and the transmitter
is out of radio connection

Reason Solution

Downward

Turn left

Turn right

Forward

Push down the throttle control stick,
the rotation speed of the mains rotors
are decreasing and the helicopter
descends accordingly.

Turn the left/right turning control stick
to the left,the helicopter will left.

Turn the left/right turning control stick
to the right,the helicopter will right.

When the helicopter is flying, push up
the forward/backward control stick, the
helicopter will move forward.

Backward

When the helicopter is flying, push
down the forward/backward control
stick, the helicopter will move backward.

Leftward flight

Turn the sideward flight control stick to
the left side,the helicopter will fly
leftward.

Rightward flight

Turn the sideward flight control stick to
the right side,the helicopter will fly
rightward.
