SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS

TECHNICAL & SERVICE MANUAL

September 2010

No. OCH446

REVISED EDITION-B

HFC

utilized

R410A

[Model name] <Outdoor unit>

PUMY-P100VHMB PUMY-P125VHMB PUMY-P140VHMB PUMY-P100VHMB-BS PUMY-P125VHMB-BS PUMY-P140VHMB-BS PUMY-P100YHMB PUMY-P125YHMB PUMY-P140YHMB PUMY-P100YHMB-BS PUMY-P125YHMB-BS PUMY-P140YHMB-BS

[Service Ref.] PUMY-P100VHMB PUMY-P100VHMBR1 PUMY-P100VHMBR2

PUMY-P125VHMB PUMY-P125VHMBR1 PUMY-P125VHMBR2 PUMY-P140VHMB PUMY-P140VHMBR1 PUMY-P140VHMBR2 PUMY-P100VHMB-BS PUMY-P100VHMBR1-BS PUMY-P100VHMBR2-BS PUMY-P125VHMB-BS PUMY-P125VHMBR1-BS PUMY-P125VHMBR2-BS PUMY-P140VHMB-BS PUMY-P140VHMBR1-BS PUMY-P140VHMBR2-BS PUMY-P100YHMB PUMY-P100YHMBR1 PUMY-P100YHMBR2 PUMY-P125YHMB PUMY-P125YHMBR1 PUMY-P125YHMBR2 PUMY-P140YHMB PUMY-P140YHMBR1 PUMY-P140YHMBR2 PUMY-P100YHMB-BS PUMY-P100YHMBR1-BS PUMY-P100YHMBR2-BS PUMY-P125YHMB-BS PUMY-P125YHMBR1-BS PUMY-P125YHMBR2-BS PUMY-P140YHMB-BS PUMY-P140YHMBR1-BS PUMY-P140YHMBR2-BS

CONTENTS

......................................

....................................

......................................

.............................................

......................

.........................................

.....

....................................

.....................

.......................

10 26 27

OUTDOOR UNIT

Model name indication

1. TECHNICAL CHANGE

2. SAFETY PRECAUTION

3. OVERVIEW OF UNITS

4. SPECIFICATIONS

5. DATA

6. OUTLINES AND DIMENSIONS

7. WIRING DIAGRAM

9. TROUBLESHOOTING

10. ELECTRICAL WIRING

11. REFRIGERANT PIPING TASKS

12. DISASSEMBLY PROCEDURE

................................................................

NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION

PARTS CATALOG (OCB446)

Revision :

· PUMY-P100, 125, 140V/YHMBR2(-BS) are added in REVISED EDITION-B.

· Some descriptions have been modified.

· Please void OCH446 REVISED EDITION-A.

NOTE :

· This service manual describes technical data of outdoor unit. As for indoor units, refer to its service manual.

· RoHS compliant products have <G> mark on spec name plate.

· For servicing of RoHS compliant products, refer to RoHS PARTS LIST.

1 TECHNICAL CHANGE

PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMBR1(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

• THERMISTOR has been changed. (Discharge thermistor → Compressor thermistor)

• COMPRESSOR has been changed.

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P100YHMB(-BS) PUMY-P125YHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS)

PUMY-P140VHMBR2(-BS)

PUMY-P100YHMBR1(-BS) PUMY-P125YHMBR1(-BS)

• OUTDOOR CONTROLLER BOARD (C.B) has been changed. (Corresponding to the additional combination of PEFY-P·VMA-E.)

2 SAFETY PRECAUTION

2-1. CAUTIONS RELATED TO NEW REFRIGERANT

Cautions for units utilizing refrigerant R410A

Use new refrigerant pipes.

Avoid using thin pipes.

Make sure that the inside and outside of refrigerant piping is clean and it has no contaminants such as sulfur, oxides, dirt, shaving particles, etc, which are hazard to refrigerant cycle. In addition, use pipes with specified thickness.

Contamination inside refrigerant piping can cause deterioration of refrigerant oil etc.

Store the piping to be used indoors during installation, and both ends of the piping sealed until just before brazing. (Leave elbow joints, etc. in their packaging.)

If dirt, dust or moisture enters into refrigerant cycle, that can cause deterioration of refrigerant oil or malfunction of compressor.

The refrigerant oil applied to flare and flange connections must be ester oil, ether oil or alkylbenzene oil in a small amount.

If large amount of mineral oil enters, that can cause deterioration of refrigerant oil etc.

Charge refrigerant from liquid phase of gas cylinder.

If the refrigerant is charged from gas phase, composition change may occur in refrigerant and the efficiency will be lowered.

Do not use refrigerant other than R410A.

If other refrigerant (R22 etc.) is used, chlorine in refrigerant can cause deterioration of refrigerant oil etc.

Use a vacuum pump with a reverse flow check valve.

Vacuum pump oil may flow back into refrigerant cycle and that can cause deterioration of refrigerant oil etc.

Use the following tools specifically designed for use with R410A refrigerant.

The following tools are necessary to use R410A refrigerant.

Tools for R410A Gauge manifold Charge hose

Gas leak detector

Torque wrench

Flare tool Size adjustment gauge Vacuum pump adaptor

Electronic refrigerant charging scale

Handle tools with care.

If dirt, dust or moisture enters into refrigerant cycle, that can cause deterioration of refrigerant oil or malfunction of compressor.

Do not use a charging cylinder.

If a charging cylinder is used, the composition of refrigerant will change and the efficiency will be lowered.

Ventilate the room if refrigerant leaks during operation. If refrigerant comes into contact with a flame, poisonous gases will be released.

[1] Cautions for service

(1) Perform service after recovering the refrigerant left in unit completely. (2) Do not release refrigerant in the air. (3) After completing service, charge the cycle with specified amount of refrigerant. (4) When performing service, install a filter drier simultaneously.

Be sure to use a filter drier for new refrigerant.

[2] Additional refrigerant charge

When charging directly from cylinder

· Check that cylinder for R410A on the market is syphon type.

· Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)

Unit

Gravimeter

[3] Service tools

Use the below service tools as exclusive tools for R410A refrigerant.

No.

Gauge manifold · Only for R410A

Charge hose · Only for R410A

Electronic scale

Gas leak detector · Use the detector for R134a, R407C or R410A.

Adaptor for reverse flow check · Attach on vacuum pump.

Refrigerant charge base

Refrigerant cylinder · Only for R410A · Top of cylinder (Pink)

Refrigerant recovery equipment

Tool name Specifications

· Use the existing fitting

· Use high-tension side pressure of 5.3MPa·G or over.

· Use pressure performance of 5.09MPa·G or over.

· Cylinder with syphon

specifications

—

. (UNF1/2)

2-2. PRECAUTIONS FOR SALT PROOF TYPE "-BS" MODEL

Although "-BS" model has been designed to be resistant to salt damage, observe the following precautions to maintain the performance of the unit.

1. Avoid installing the unit in a location where it will be exposed directly to seawater or sea breeze.

2. If the cover panel may become covered with salt, be sure to install the unit in a location where the salt will be washed away by rainwater. (If a sunshade is installed, rainwater may not clean the panel.)

3. To ensure that water does not collect in the base of the outdoor unit, make sure that the base is level, not at angle. Water collecting in the base of the outdoor unit could cause rust.

4. If the unit is installed in a coastal area, clean the unit with water regularly to remove any salt build-up.

5. If the unit is damaged during installation or maintenance, be sure to repair it.

6. Be sure to check the condition of the unit regularly.

7. Be sure to install the unit in a location with good drainage.

Cautions for refrigerant piping work

New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is same as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working pressure of R410A is 1.6 times higher than that of R22, their sizes of flared sections and flare nuts are different.

1 Thickness of pipes

Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness shown below. (Never use pipes of 0.7 mm or below.)

Diagram below: Piping diameter and thickness

Nominal

dimensions(inch)

1/4 3/8 1/2 5/8 3/4

Outside

diameter

6.35

9.52

12.70

15.88

19.05

(mm)

Thickness

R410A R22

0.8

1.0

—

(mm)

0.8

1.0

2 Dimensions of flare cutting and flare nut

The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that, R410A is a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refrigerants. Therefore, to enhance airtightness and intensity, flare cutting dimension of copper pipe for R410A has been specified separately from the dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A also has partly been changed to increase intensity as shown below. Set copper pipe correctly referring to copper pipe flaring dimensions for R410A below. For 1/2 and 5/8 inch, the dimension B changes. Use torque wrench corresponding to each dimension.

Dimension A

Flare cutting dimensions

Nominal

dimensions(inch)

1/4 3/8 1/2 5/8 3/4

Outside

diameter

6.35

9.52

12.70

15.88

19.05

Dimension A

R410A R22

9.1

13.2

16.6

19.7

—

( )

-0.4

9.0

13.0

16.2

19.4

23.3

(mm)

Flare nut dimensions

Nominal

dimensions(inch)

1/4 3/8 1/2 5/8 3/4

Outside

diameter

6.35

9.52

12.70

15.88

19.05

3 Tools for R410A (The following table shows whether conventional tools can be used or not.)

Tools and materials Use R410A tools Can R22 tools be used? Gauge manifold

Charge hose Gas leak detector

Refrigerant recovery equipment Refrigerant cylinder Applied oil

Safety charger

Charge valve

Vacuum pump

Flare tool

Bender Pipe cutter Welder and nitrogen gas cylinder Refrigerant charging scale

Vacuum gauge or thermistor vacuum gauge and vacuum valve Charging cylinder

: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.) : Tools for other refrigerants can be used under certain conditions. : Tools for other refrigerants can be used.

Air purge, refrigerant charge and operation check Gas leak check Refrigerant recovery Refrigerant charge Apply to flared section

Prevent compressor malfunction when charging refrigerant by

spraying liquid refrigerant Prevent gas from blowing out

when detaching charge hose Vacuum drying and air purge

Flaring work of piping

Bend the pipes Cut the pipes Weld the pipes Refrigerant charge Check the degree of vacuum. (Vacuum

valve prevents back flow of oil and refrigerant to thermistor vacuum gauge) Refrigerant charge

Tool exclusive for R410A Tool exclusive for R410A Tool for HFC refrigerant Tool exclusive for R410A Tool exclusive for R410A Ester oil, ether oil and alkylbenzene oil (minimum amount) Tool exclusive for R410A

Tool exclusive for R410A

Tools for other refrigerants can be used if equipped with adopter for reverse flow check Tools for other refrigerants

can be used by adjusting flaring dimension

Tools for other refrigerants can be used Tools for other refrigerants can be used Tools for other refrigerants can be used Tools for other refrigerants can be used Tools for other refrigerants can be used

Tool exclusive for R410A

(Usable if equipped

with adopter for rever se flow)

(Usable by adjusting flaring dimension)

Dimension B

R410A R22

17.0

22.0

26.0

29.0

—

Can R407C tools be used?

Ester oil, ether oil: Alkylbenzene oil: minimum amount

(Usable if equipped

with adopter for rever se flow)

(Usable by adjusting

flaring dimension)

17.0

22.0

24.0

27.0

36.0

(mm)

OVERVIEW OF UNITS

3-1. UNIT CONSTRUCTION

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS)

Outdoor unit

Indoor unit that can be connected

Capacity

Number of units

Total system wide capacity

PUMY-P100VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

4HP 5HP 6HP

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS)

Type 15 ~ Type 125

1 ~ 8 unit

CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E

1 ~ 10 unit

50% ~130% of outdoor unit capacity

Type 15 ~ Type 140

PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

1 ~ 12 unit

Model

Capacity

100

125

140

Branching pipe components

Cassette Ceiling

4-way flow 2-way flow

PLFY-P PLFY-P PEFY-P PKFY-P PCFY-P

–

20VCM-E(2)

25VCM-E(2)

32VCM-E(2)/32VBM-E

40VCM-E(2)/40VBM-E

50VBM-E

63VBM-E

80VBM-E

100VBM-E

125VBM-E

20VLMD-E

25VLMD-E

32VLMD-E

40VLMD-E

50VLMD-E

63VLMD-E

–

80VLMD-E

100VLMD-E

125VLMD-E

–

1-way flow

PMFY-P

–

20VBM-E

25VBM-E

32VBM-E

40VBM-E

–

Branch header (2 branches)

Ceiling

Concealed

15VMS1-E

20VMS1-E/ VMA-E

25VMS1-E/ VMA-E

32VMS1-E/ VMA-E

40VMS1-E/ VMA-E

50VMS1-E/ VMA-E

63VMS1-E/ VMA-E

71VMA-E

80VMH-E/ VMA-E

100VMH-E/ VMA-E

125VMH-E/ VMA-E

140VMH-E/ VMA-E

Wall

Mounted

15VBM-E

20VBM-E

25VBM-E

32VHM-E

40VHM-E

50VHM-E

63VKM-E

–

100VKM-E

–

Branch header (4 branches)

Suspended

40VKM-E

63VKM-E

100VKM-E

125VKM-E

Decorative panel

Ceiling

–

Branch header (8 branches)

Floor standing

Exposed Concealed

PFFY-P

–

20VLEM-E/VKM-E

25VLEM-E/VKM-E

32VLEM-E/VKM-E

40VLEM-E/VKM-E

50VLEM-E

63VLEM-E

–

PFFY-P

20VLRM-E

25VLRM-E

32VLRM-E

40VLRM-E

50VLRM-E

63VLRM-E

Ceiling

Concealed

(Fresh Air)

–

80VMH-E-F

140VMH-E-F

PEFY-P

–

MA remote controller

PAR-21MAA

Remote

controller

Name

Model number

Functions

M-NET remote controller

PAR-F27MEA-E

• A handy remote controller for use in conjunction with the Melans centralized management system.

• Addresses setting is not necessary.

• Addresses must be set.

*1. PUMY-P·YHMB is connectable to Fresh Air type indoor unit.

It is possible to connect 1 Fresh Air type indoor unit to 1 outdoor unit. (1:1 system) Operating temperature range (outdoor temperature) for fresh air type indoor units differ from other indoor units. Refer to 3-2(3). *2. When the indoor unit of Fresh Air type is connected with the outdoor unit, the maximum connectable total indoor unit capacity is 110% (100% in case of heating below -5:[23˚F]).

3-2. UNIT SPECIFICATIONS

(1) Outdoor Unit

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS)



14.0

16.0

2.4

Capacity

Service Ref.

Cooling (kW)

Heating (kW)

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

11. 2

12.5

1.9

Cooling/Heating capacity indicates the maximum value at operation under the following condition.

w. Cooling Indoor : D.B. 27°C/W.B. 19.0°C Outdoor : D.B. 35°C

Heating Indoor : D.B. 20°C

Outdoor : D.B. 7°C/W.B. 6°C

PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

(2) Method for identifying MULTI-S model

Indoor unit < When using Model 80 >

Outdoor unit <When using model 125 >

P L F Y - P 80 V BM - E PU M Y - P 125 Y H M B - BS

15.5

18.0

2.9Compressor (kW)

PAC ty pe

L : Ceiling cassette K : Wall-mounted type E : Hidden skylight type C : Ceiling suspended type M : Ceiling cassette type F : Floor standing type

NEW frequency converter one-to-many air conditioners (flexible design type)

Indicates equivalent to Cooling capacity (k cal / h)

Refrigerant R407C/R22 R410A

commonness Frequency conversion controller

Sub-number

BM CM KM

M-NET

control

}

LMD

Power supply V: Single phase 220-230-240V 50Hz 220V 60Hz

Outdoor unit

MULTI-S

Indicates equivalent to Cooling capacity

(k cal / h)

(3) Operating temperature range

Cooling

Indoor-side intake air temperature

Outdoor-side intake air temperature

W.B. 15~24°C

D.B. -5~46°C

Notes D.B. : Dry Bulb Temperature W.B. : Wet Bulb Temperature w1. 10~46°C DB : In case of connecting PKFY-P15/P20/P25 type indoor unit.

Heating

D.B. 15~27°C

W.B. -15~15°C

Refrigerant R410A

Frequency conversion controller

Sub-number

M-NET control

Outdoor unit model type

Power supply

V: Single phase 220-230-240V 50Hz 220V 60Hz

Y: 3-phase 380-400-415V 50Hz

Salt proof type

■ In case of connecting fresh air type indoor unit

Capacity of Fresh

air type indoor

P80

Indoor-side and Outdoor-side intake air temperature

2. Thermo-off (FAN-mode) automatically starts if the outdoor temp. is lower than 21D.B..

3. Thermo-off (FAN-mode) automatically starts if the outdoor temp. is higher than 20D.B..

P140

Cooling

D.B.21~43+2 W.B.15.5~35

D.B.21~43 W.B.15.5~35

Heating

D.B.-10~20

D.B.-5~20

Galvanized steel sheet

MITSUBISHI ELECTRIC CORPORATION

Inverter

High pressure sensor, High pressure switch 4.15 MPa

Over-heat protection, Over-current protection

Discharge thermo protection, Over-current protection (PUMY-P·VHMB(-BS), PUMY-P·VHMBR1(-BS))

Compressor thermo protection, Over-current protection (PUMY-P·VHMBR2(-BS))

Over-heat protection, Voltage protection

Auto-defrost mode (Reversed refrigerant circle)

LEV circuit

Installation Manual

Grounded lead wire × 2

In case of connecting all fresh air type indoor unit PEFY-P-VHM-E-F, only one indoor unit can be connected with one PUMY. Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be referred to the Installation Manual.

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

1-phase 220-230-240V 50Hz, 1-phase 220V 60Hz

15 ~ 24˚C (59 ~ 75˚F)

- 5 ~ 46˚C (23 ~ 115˚F)

10 to 46˚CD.B. (50 to 115˚FD.B.) : in case of connecting PKFY-P15/P20/P25 type indoor unit.

15 ~ 27˚C (59 ~ 81˚F)

-15 ~ 15˚C (5 ~ 59˚F)

50 ~ 130% of outdoor unit capacity

11.2

9,600 38,200 10,000

3.34

15.4-14.8-14.1, 15.4

3.35

12.5 10,800 42,700

3.66

16.9-16.2-15.5, 16.9

3.42

P15 ~ P125/1 ~ 8

49/51

ø9.52 (ø3/8") Liquid

ø15.88 (ø5/8") Gas

14.0 12,000 47,800 12,500

4.32

20.0-19.1-18.3, 20.0

3.24

16.0 13,800 54,600

4.33

20.0-19.1-18.3, 20.0

3.69

P15 ~ P140/1 ~ 10

50/52

ø9.52 (ø3/8") Liquid

ø15.88 (ø5/8") Gas

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

129 (284 lb)

Inverter scroll hermetic comp.

2.2

FV50S × 2.3 L

100 1667 3532

0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

129 (284 lb)

Salt-resistant cross fin & copper tube

Inverter scroll hermetic comp.

2.9

FV50S × 2.3 L

100 1667 3532 0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

* 1 Nominal cooling conditions

Note :

Indoor :

Outdoor :

Pipe length :

Level difference :

27˚CDB/19˚CWB (81˚FDB/66˚FWB) 35˚CDB (95˚FDB)

7.5 m (24-9/16 ft) 0 m (0 ft)

* 2 Nominal cooling conditions

27˚CDB/19.5˚CWB (81˚FDB/67˚FWB) 35˚CDB (95˚FDB) 5 m (16-3/8 ft) 0 m (0 ft)

* 3 Nominal heating conditions

Unit converter

20˚CDB (68˚FDB) 7˚CDB/6˚CWB (45˚FDB/43˚FWB)

7.5 m (24-9/16 ft) 0 m (0 ft)

* Nominal conditions * 1, * 3 are subject to JIS B8615-1. * Due to continuing improvement, above specifications may be subject to change without notice.

kcal/h = kW × 860 Btu/h = kW

× 3,412

cfm = m

/min x 35.31

lb = kg/0.4536

*Above specification data is subject to rounding variation.

SPECIFICATIONS

PUMY-P125VHMB(-BS)

Model

PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS)

Power source Cooling capacity (Nominal)

Temp. range of cooling

Power input Current input COP (kW/kW) Indoor Outdoor

Heating capacity (Nominal )

Temp. range of heating

Indoor unit connectable Noise level

Diameter of refrigerant pipe

Power input Current input COP (kW/kW) Indoor temp. Outdoor temp.

Total capacity Model/Quantity

(measured in anechoic room)

Liquid (High press.)

Gas (Low press.)

External finish

External dimension H

×W×

Net weight Heat exchanger Compressor

FAN

Ty pe Manufacturer Starting method Motor output Case heater Lubricant Air flow rate

HIC circuit Protection

Defrosting method Refrigerant

Standard attachment

Optional parts

External static press. Ty pe× Quantity Control, Driving mechanism Motor output

(HIC: Heat Inter-Changer)

High pressure protection Inverter circuit (COMP./FAN) Compressor

Fan motor

Original charge

Ty pe Control

Document Accessory

Remark

kcal/h

Btu/h

kcal/h kW A

W.B . D.B .

kcal/h

Btu/h kW A

D.B . W.B .

dB <A>

mm (in.)

mm in. kg (lb)

Salt-resistant cross fin & copper tube Salt-resistant cross fin & copper tube

kW kW

/min L/s cfm

PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

15.5 13,300 52,900 14,000

5.35

24.7-23.6-22.7, 24.7

2.9

18.0 15,500 61,400

5.58

25.8-24.7-23.6, 25.8

3.23

P15 ~ P140/1 ~ 12

51/53

ø9.52 (ø3/8") Liquid

ø15.88 (ø5/8") Gas

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

129 (284 lb)

Inverter scroll hermetic comp.

3.3

FV50S × 2.3 L

100 1667 3532 0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

Galvanized steel sheet

MITSUBISHI ELECTRIC CORPORATION

Inverter

High pressure sensor, High pressure switch 4.15 MPa

Over-heat protection, Over-current protection

Over-heat protection, Voltage protection

Auto-defrost mode (Reversed refrigerant circle)

LEV circuit

Installation Manual

Grounded lead wire x 2

Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be referred to the Installation Manual.

PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

3-phase 4-wire 380-400-415V 50Hz

15 ~ 24˚C (59 ~ 75˚F)

- 5 ~ 46˚C (23 ~ 115˚F)

10 to 46˚CD.B. (50 to 115˚FD.B.): in case of connecting PKFY-P15/P20/P25 type indoor unit.

15 ~ 27˚C (59 ~ 81˚F)

-15 ~ 15˚C (5 ~ 59˚F)

50 ~ 130% of outdoor unit capacity

11.2 9,600

38,200

3.30

5.28-5.02-4.84

3.39

12.5 10,800 42,700

3.63

5.81-5.52-5.32

3.44

P15 ~ P125/1 ~ 8

49/51

ø9.52 (ø3/8") Flare

ø15.88 (ø5/8") Flare

14.0 12,000 47,800 12,500

4.27

6.83-6.49-6.26

3.28

16.0 13,800 54,600

4.29

6.87-6.52-6.29

3.73

P15 ~ P140/1 ~ 10

50/52

ø9.52 (ø3/8") Flare

ø15.88 (ø5/8") Flare

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

142 (313)

Salt-resistant cross fin & copper tube

Inverter scroll hermetic comp.

1.9

FV50S × 2.3 L

100 1667 3532 0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

142 (313)

Salt-resistant cross fin & copper tube

Inverter scroll hermetic comp.

2.4

100 1667 3532 0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

* 1 Nominal cooling conditions

Note :

Indoor :

Outdoor :

Pipe length :

Level difference :

27˚CDB/19˚CWB (81˚FDB/66˚FWB) 35˚CDB (95˚FDB)

7.5 m (24-9/16 ft) 0 m (0 ft)

* 2 Nominal cooling conditions

27˚CDB/19.5˚CWB (81˚FDB/67˚FWB) 35˚CDB (95˚FDB) 5 m (16-3/8 ft) 0 m (0 ft)

* 3 Nominal heating conditions

Unit converter

20˚CDB (68˚FDB) 7˚CDB/6˚CWB (45˚FDB/43˚FWB)

7.5 m (24-9/16 ft) 0 m (0 ft)

* Nominal conditions * 1, * 3 are subject to JIS B8615-1. * Due to continuing improvement, above specifications may be subject to change without notice.

kcal/h = kW × 860 Btu/h = kW

× 3,412

cfm = m

/min × 35.31

lb = kg/0.4536

*Above specification data is subject to rounding variation.

Model

Power source Cooling capacity (Nominal)

Temp. range of cooling

Heating capacity (Nominal)

Temp. range of heating

Indoor unit connectable

Noise level

(measured in anechoic room)

Diameter of refrigerant pipe

External finish

External dimension H

×W×

Net weight Heat exchanger Compressor

FAN

HIC circuit

(HIC: Heat Inter-Changer)

Protection

Defrosting method

Refrigerant

Standard attachment Optional parts

Remark

Power input Current input COP (kW/kW) Indoor Outdoor

Power input Current input COP (kW/kW) Indoor temp. Outdoor temp.

Total capacity Model/Quantity

Liquid (High press.)

Gas (Low press.)

Ty pe Manufacturer Starting method Motor output Case heater Lubricant Air flow rate

External static press. Ty pe

Quantity Control, Driving mechanism Motor output

High pressure protection Inverter circuit (COMP./FAN) Compressor

Fan motor

Ty pe

Original charge Control Document Accessory

kW kcal/h Btu/h kcal/h kW A

W.B . D.B .

kW kcal/h Btu/h kW A

D.B . W.B .

dB <A>

mm (in.)

mm in. kg (lb)

kW kW

/min L/s cfm

Discharge thermo protection, Over-current protection (PUMY-P·VHMB(-BS), PUMY-P·VHMBR1(-BS))

PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS)

PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

15.5 13,300 52,900 14,000

5.32

8.51-8.09-7.80

2.91

18.0 15,500 61,400

5.32

8.51-8.09-7.80

3.38

P15 ~ P140/1 ~ 12

51/53

9.52 (ø3/8") Flare

15.88 (ø5/8") Flare

1,350 × 950 × 330

53-3/16" × 37-7/16" × 13"

142 (313)

Salt-resistant cross fin & copper tube

Inverter scroll hermetic comp.

2.9

FV50S × 2.3 L

100 1667 3532

0Pa

Propeller fan × 2

DC-control, Direct-driven by motor

0.06 × 2

Compressor thermo protection, Over-current protection (PUMY-P·VHMBR2(-BS))

R410A × 8.5kg (19 lb)

Joint: CMY-Y62-G-E

Header:CMY-Y64/68-G-E

DATA

5-1. COOLING AND HEATING CAPACITY AND CHARACTERISTICS

5-1-1. Method for obtaining system cooling and heating capacity:

To obtain the system cooling and heating capacity and the electrical characteristics of the outdoor unit, first add up the ratings of all the indoor units connected to the outdoor unit (see table below), and then use this total to find the standard capacity with the help of the tables on 5-2. STANDARD CAPACITY DIAGRAM.

(1) Capacity of indoor unit

Model 20

Model 2528Model 3236Model 4045Model 5056Model 6371Model 7180Model 8090Model 100

112

Model 125

140

Model 140

160

Model Number for indoor unit

Model Capacity

(2) Sample calculation

Model 15

1 System assembled from indoor and outdoor unit (in this example the total capacity of the indoor units is greater than that of

the outdoor unit)

• Outdoor unit PUMY-P125YHMB

• Indoor unit PKFY-P25VBM-E o 2 , PLFY-P50VLMD-E o 2

2 According to the conditions in 1, the total capacity of the indoor unit will be: 28 o 2 + 56 o 2 = 168 3 The following figures are obtained from the 168 total capacity row of the standard capacity diagram (5-2.):

Capacity (kW)

Cooling Heating Cooling Heating Cooling Heating

A 14.60 B 16.33

Outdoor unit power consumption (kW)

4.34 3.95 6.59 6.01

Outdoor unit current (A)/400V

5-1-2. Method for obtaining the heating and cooling capacity of an indoor unit:

(1) The capacity of each indoor unit (kW) = the capacity

(or B)

total model capacity of all indoor units

model capacity

(2) Sample calculation (using the system described above in 5-1-1. (2) ):

During cooling:

• The total model capacity of the indoor unit is:

2.8 o 2 + 5.6 o 2=16.8kW Therefore, the capacity of PKFY-P25VBM-E and PLFY-P50VLMD-E will be calculated as follows by using the formula in 5-1-2. (1):

Model 25=14.6 o = 2.43kW

Model 50=14.6 o = 4.87kW

2.8

16.8

5.6

16.8

• The total model capacity of indoor unit is:

3.2 o 2 + 6.3 o 2=19.0 Therefore, the capacity of PKFY-P25VBM-E and PLFY-P50VLMD-E will be calculated as follows by using the formula in 5-1-2. (1):

Model 25=16.33 o = 2.75kW

Model 50=16.33 o = 5.41kW

During heating:

3.2

19.0

6.3

19.0

5-2. STANDARD CAPACITY DIAGRAM

5-2-1. PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

)

Total capacity of indoor units*

56 5.60 6.30 1.37 1.79 6.3 8.3 6.1 7.9 5.8 7.6 57 5.70 6.41 1.39 1.82 6.4 8.4 6.2 8.1 5.9 7.7 58 5.80 6.53 1.42 1.85 6.6 8.6 6.3 8.2 6.0 7.8 59 5.90 6.64 1.44 1.88 6.7 8.7 6.4 8.3 6.1 8.0 60 6.00 6.75 1.46 1.91 6.8 8.8 6.5 8.4 6.2 8.1 61 6.10 6.87 1.49 1.94 6.9 9.0 6.6 8.6 6.3 8.2 62 6.20 6.98 1.51 1.97 7.0 9.1 6.7 8.7 6.4 8.4 63 6.30 7.09 1.54 2.00 7.1 9.2 6.8 8.8 6.5 8.5 64 6.40 7.20 1.56 2.03 7.2 9.4 6.9 9.0 6.6 8.6 65 6.50 7.32 1.59 2.06 7.4 9.5 7.0 9.1 6.7 8.7 66 6.60 7.43 1.62 2.09 7.5 9.7 7.2 9.2 6.9 8.9 67 6.70 7.54 1.64 2.12 7.6 9.8 7.3 9.4 7.0 9.0 68 6.80 7.66 1.67 2.15 7.7 9.9 7.4 9.5 7.1 9.1 69 6.90 7.77 1.70 2.18 7.9 10.1 7.5 9.6 7.2 9.2 70 7.00 7.88 1.73 2.22 8.0 10.3 7.7 9.8 7.3 9.4 71 7.10 8.00 1.76 2.25 8.1 10.4 7.8 10.0 7.5 9.5 72 7.20 8.11 1.79 2.28 8.3 10.5 7.9 10.1 7.6 9.7 73 7.30 8.22 1.82 2.31 8.4 10.7 8.1 10.2 7.7 9.8 74 7.40 8.33 1.85 2.34 8.6 10.8 8.2 10.3 7.8 9.9 75 7.50 8.44 1.88 2.37 8.7 11.0 8.3 10.5 8.0 10.0 76 7.60 8.56 1.91 2.41 8.8 11.1 8.4 10.7 8.1 10.2 77 7.70 8.67 1.94 2.44 9.0 11.3 8.6 10.8 8.2 10.3 78 7.80 8.78 1.97 2.47 9.1 11.4 8.7 10.9 8.4 10.5 79 7.90 8.89 2.00 2.50 9.2 11.6 8.8 11.1 8.5 10.6 80 8.00 9.00 2.04 2.54 9.4 11.7 9.0 11.2 8.6 10.8 81 8.10 9.10 2.07 2.57 9.6 11.9 9.2 11.4 8.8 10.9 82 8.20 9.20 2.10 2.60 9.7 12.0 9.3 11.5 8.9 11.0 83 8.30 9.30 2.14 2.64 9.9 12.2 9.5 11.7 9.1 11.2 84 8.40 9.40 2.17 2.67 10.0 12.3 9.6 11.8 9.2 11.3 85 8.50 9.50 2.21 2.70 10.2 12.5 9.8 11.9 9.4 11.4 86 8.60 9.60 2.24 2.74 10.4 12.7 9.9 12.1 9.5 11.6 87 8.70 9.70 2.28 2.77 10.5 12.8 10.1 12.2 9.7 11.7 88 8.80 9.80 2.32 2.80 10.7 12.9 10.3 12.4 9.8 11.9 89 8.90 9.90 2.35 2.84 10.9 13.1 10.4 12.6 10.0 12.0 90 9.00 10.00 2.39 2.87 11.1 13.3 10.6 12.7 10.1 12.2 91 9.10 10.10 2.43 2.91 11.2 13.5 10.7 12.9 10.3 12.3 92 9.20 10.22 2.47 2.94 11.4 13.6 10.9 13.0 10.5 12.5 93 9.30 10.33 2.50 2.97 11.6 13.7 11.1 13.1 10.6 12.6 94 9.40 10.45 2.54 3.01 11.7 13.9 11.2 13.3 10.8 12.8 95 9.50 10.56 2.58 3.04 11.9 14.1 11.4 13.4 10.9 12.9 96 9.60 10.67 2.62 3.08 12.1 14.2 11.6 13.6 11.1 13.1 97 9.70 10.79 2.66 3.11 12.3 14.4 11.8 13.8 11.3 13.2 98 9.80 10.90 2.70 3.15 12.5 14.6 11.9 13.9 11.4 13.3

99 9.90 11.02 2.75 3.19 12.7 14.7 12.2 14.1 11.7 13.5 100 10.00 11.13 2.79 3.22 12.9 14.9 12.3 14.2 11.8 13.6 101 10.10 11.24 2.83 3.26 13.1 15.1 12.5 14.4 12.0 13.8 102 10.20 11.36 2.87 3.29 13.3 15.2 12.7 14.5 12.2 13.9 103 10.30 11.47 2.91 3.33 13.5 15.4 12.9 14.7 12.3 14.1 104 10.40 11.59 2.96 3.36 13.7 15.5 13.1 14.9 12.5 14.2 105 10.50 11.70 3.00 3.40 13.9 15.7 13.3 15.0 12.7 14.4 106 10.60 11.81 3.05 3.44 14.1 15.9 13.5 15.2 12.9 14.6 107 10.70 11.93 3.09 3.47 14.3 16.0 13.7 15.3 13.1 14.7 108 10.80 12.04 3.14 3.51 14.5 16.2 13.9 15.5 13.3 14.9 109 10.90 12.16 3.18 3.55 14.7 16.4 14.1 15.7 13.5 15.0 110 11.00 12.27 3.23 3.59 14.9 16.6 14.3 15.9 13.7 15.2

Capacity(kW

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)Current(A)/220V Current(A)/230V Current(A)/240V

Total capacity of indoor units*

111 11.10 12.38 3.27 3.62 15.1 16.7 14.5 16.0 13.9 15.3 112 11.2012.503.343.6615.416.914.816.214.115.5 113 11.2212.513.353.6515.516.914.816.114.215.5 114 11.2412.533.353.6415.516.814.816.114.215.4 115 11.2612.543.363.6315.516.814.916.014.215.4 116 11.2812.553.363.6215.516.714.916.014.215.3 117 11.3012.563.363.6115.516.714.916.014.215.3 118 11.3212.573.373.5915.616.614.915.914.315.2 119 11.3412.583.373.5815.616.514.915.814.315.2 120 11.36 12.60 3.38 3.57 15.6 16.5 14.9 15.8 14.3 15.1 121 11.38 12.61 3.38 3.56 15.6 16.5 14.9 15.7 14.3 15.1 122 11.40 12.62 3.38 3.55 15.6 16.4 14.9 15.7 14.3 15.0 123 11.42 12.63 3.39 3.54 15.7 16.4 15.0 15.7 14.4 15.0 124 11.44 12.64 3.39 3.52 15.7 16.3 15.0 15.6 14.4 14.9 125 11.47 12.66 3.40 3.51 15.7 16.2 15.0 15.5 14.4 14.9 126 11.49 12.67 3.40 3.50 15.7 16.2 15.0 15.5 14.4 14.8 127 11.51 12.68 3.40 3.49 15.7 16.1 15.0 15.4 14.4 14.8 128 11.53 12.69 3.41 3.48 15.8 16.1 15.1 15.4 14.4 14.7 129 11.55 12.70 3.41 3.47 15.8 16.0 15.1 15.3 14.4 14.7 130 11.57 12.71 3.42 3.45 15.8 15.9 15.1 15.3 14.5 14.6 131 11.59 12.73 3.42 3.44 15.8 15.9 15.1 15.2 14.5 14.6 132 11.61 12.74 3.42 3.43 15.8 15.9 15.1 15.2 14.5 14.5 133 11.63 12.75 3.43 3.42 15.9 15.8 15.2 15.1 14.5 14.5 134 11.65 12.76 3.43 3.41 15.9 15.8 15.2 15.1 14.5 14.4 135 11.67 12.77 3.44 3.40 15.9 15.7 15.2 15.0 14.6 14.4 136 11.69 12.78 3.44 3.38 15.9 15.6 15.2 14.9 14.6 14.3 137 11.71 12.80 3.45 3.37 15.9 15.6 15.3 14.9 14.6 14.3 138 11.73 12.81 3.45 3.36 15.9 15.5 15.3 14.9 14.6 14.2 139 11.75 12.82 3.45 3.35 15.9 15.5 15.3 14.8 14.6 14.2 140 11.77 12.83 3.46 3.34 16.0 15.4 15.3 14.8 14.7 14.2 141 11.79 12.84 3.46 3.32 16.0 15.3 15.3 14.7 14.7 14.1 142 11.82 12.86 3.47 3.31 16.0 15.3 15.3 14.6 14.7 14.0 143 11.84 12.87 3.47 3.30 16.0 15.3 15.3 14.6 14.7 14.0 144 11.86 12.88 3.47 3.29 16.0 15.2 15.3 14.5 14.7 13.9 145 11.88 12.89 3.48 3.28 16.1 15.2 15.4 14.5 14.7 13.9

Capacity(kW

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

)

Power Consumption(kW)Current(A)/220V Current(A)/230V Current(A)/240V

5-2-2. PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

Total capacity of

indoor units*

70 7.00 7.88 71 7.10 8.00 72 7.20 8.11 73 7.30 8.22 74 7.40 8.33 75 7.50 8.44 76 7.60 8.56 77 7.70 8.67 78 7.80 8.78 79 7.90 8.89 80 8.00 9.00 81 8.10 9.10 82 8.20 9.20 83 8.30 9.30 84 8.40 9.40 85 8.50 9.50 86 8.60 9.60 87 8.70 9.70 88 8.80 9.80 89 8.90 9.90 90 9.00 10.00 91 9.10 10.10 92 9.20 10.22 93 9.30 10.33 94 9.40 10.45 95 9.50 10.56 96 9.60 10.67 97 9.70 10.79 98 9.80 10.90

99 9.90 11.02 100 10.00 11.13 101 10.10 11.24 102 10.20 11.36 103 10.30 11.47 104 10.40 11.59 105 10.50 11.70 106 10.60 11.81 107 10.70 11.93 108 10.80 12.04 109 10.90 12.16 110 11.00 12.27

111 11. 10 12.38 112 11.20 12.50 113 11.30 12.63 114 11.40 12.75 115 11.50 12.88 116 11.60 13.00 117 11.70 13.13 118 11.80 13.25 119 11.90 13.38 120 12.00 13.50 121 12.10 13.63 122 12.20 13.75 123 12.30 13.88 124 12.40 14.00 125 12.50 14.13 126 12.60 14.25 127 12.70 14.38 128 12.80 14.50 129 12.90 14.63 130 13.00 14.75

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

1.83

1.85

1.88

1.90

1.93

1.96

1.98

2.01

2.04

2.07

2.09

2.12

2.15

2.18

2.21

2.24

2.27

2.30

2.33

2.36

2.39

2.42

2.45

2.49

2.52

2.55

2.58

2.62

2.65

2.68

2.72

2.75

2.79

2.82

2.86

2.89

2.93

2.96

3.00

3.04

3.07

3.11

3.15

3.19

3.22

3.26

3.30

3.34

3.38

3.42

3.46

3.50

3.54

3.58

3.62

3.66

3.71

3.75

3.79

3.83

2.05

2.08

2.11

2.13

2.16

2.19

2.21

2.24

2.27

2.29

2.32

2.35

2.38

2.41

2.44

2.46

2.49

2.52

2.55

2.58

2.61

2.64

2.67

2.70

2.73

2.76

2.79

2.82

2.85

2.89

2.92

2.95

2.98

3.01

3.05

3.08

3.11

3.14

3.18

3.21

3.24

3.28

3.31

3.34

3.38

3.41

3.45

3.48

3.52

3.55

3.59

3.62

3.66

3.69

3.73

3.76

3.80

3.84

3.87

3.91 17.7

3.88 3.95 17.9

Current(A)/ 220V Current(A)/ 230V Current(A)/ 240V

8.4

8.6

8.7

8.8

8.9

9.0

9.2

9.3

9.4

9.5

9.7

9.8

9.9

10.1

10.2

10.3

10.5

10.6

10.8

10.9

11.0

11.2

11.3

11.5

11.6

11.8

11.9

12.1

12.2

12.4

12.6

12.7

12.9

13.0

13.2

13.4

13.5

13.7

13.9

14.0

14.2

14.4

14.5

14.7

14.9

15.1

15.3

15.4

15.6

15.8

16.0

16.2

16.4

16.5

16.7

16.9

17.1

17.3

17.5

9.5

9.6

9.7

9.8

10.0

10.1

10.2

10.3

10.5

10.6

10.7

10.8

11.0

11.1

11.2

11.4

11.5

11.6

11.8

11.9

12.0

12.2

12.3

12.5

12.6

12.7

12.9

13.0

13.2

13.3

13.5

13.6

13.8

13.9

14.1

14.2

14.4

14.5

14.7

14.8

15.0

15.1

15.3

15.4

15.6

15.7

15.9

16.1

16.2

16.4

16.5

16.7

16.9

17.0

17.2

17.4

17.5

17.7

17.9

18.0

8.1

8.2

8.3

8.4

8.5

8.6

8.8

8.9

9.0

9.1

9.3

9.4

9.5

9.6

9.8

9.9

10.0

10.2

10.3

10.4

10.6

10.7

10.8

11.0

11.1

11.3

11.4

11.6

11.7

11.9

12.0

12.2

12.3

12.5

12.6

12.8

12.9

13.1

13.3

13.4

13.6

13.7

13.9

14.1

14.2

14.4

14.6

14.8

14.9

15.1

15.3

15.5

15.6

15.8

16.0

16.2

16.4

16.6

16.7

16.9

9.1

9.2

9.3

9.4

9.5

9.6

9.8

9.9

10.0

10.1

10.3

10.4

10.5

10.6

10.8

10.9

11.0

11.1

11.3

11.4

11.5

11.7

11.8

11.9

12.1

12.2

12.3

12.5

12.6

12.7

12.9

13.0

13.2

13.3

13.4

13.6

13.7

13.9

14.0

14.2

14.3

14.5

14.6

14.8

14.9

15.1

15.2

15.4

15.5

15.7

15.8

16.0

16.1

16.3

16.5

16.6

16.8

16.9

17.1

17.3

7.7

7.8

8.0

8.1

8.2

8.3

8.4

8.5

8.6

8.7

8.9

9.0

9.1

9.2

9.4

9.5

9.6

9.7

9.9

10.0

10.1

10.3

10.4

10.5

10.7

10.8

10.9

11.1

11.2

11.4

11.5

11.7

11.8

11.9

12.1

12.2

12.4

12.6

12.7

12.9

13.0

13.2

13.3

13.5

13.7

13.8

14.0

14.1

14.3

14.5

14.7

14.8

15.0

15.2

15.3

15.5

15.7

15.9

16.0

16.2

10.1

10.2

10.3

10.4

10.5

10.7

10.8

10.9

11.0

11.2

11.3

11.4

11.6

11.7

11.8

11.9

12.1

12.2

12.3

12.5

12.6

12.7

12.9

13.0

13.2

13.3

13.4

13.6

13.7

13.9

14.0

14.1

14.3

14.4

14.6

14.7

14.9

15.0

15.2

15.3

15.5

15.6

15.8

15.9

16.1

16.2

16.4

16.5

18.2 17.1 17.4 16.4 16.7

8.7

8.8

8.9

9.0

9.1

9.2

9.4

9.5

9.6

9.7

9.8

9.9

Total capacity of

indoor units*

131 13.10 14.88 132 13.20 15.00 133 13.30 15.13 134 13.40 15.25 135 13.50 15.38 136 13.60 15.50 137 13.70 15.63 138 13.80 15.75 139 13.90 15.88 140 14.00 16.00 141 14.02 16.01 142 14.04 16.02 143 14.06 16.03 144 14.08 16.04 145 14.10 16.06 146 14.12 16.07 147 14.15 16.08 148 14.17 16.09 149 14.19 16.10 150 14.21 16.12 151 14.23 16.13 152 14.25 16.14 153 14.27 16.15 154 14.30 16.16 155 14.32 16.17 156 14.34 16.19 157 14.36 16.20 158 14.38 16.21 159 14.40 16.22 160 14.42 16.23 161 14.45 16.25 162 14.47 16.26 163 14.49 16.27 164 14.51 16.28 165 14.53 16.29 166 14.55 16.31 167 14.57 16.32 168 14.60 16.33 169 14.62 16.34 170 14.64 16.35 171 14.66 16.36 172 14.68 16.38 173 14.70 16.39 174 14.72 16.40 175 14.75 16.41 176 14.77 16.42 177 14.79 16.44 178 14.81 16.45 179 14.83 16.46 180 14.85 16.47 181 14.87 16.48 182 14.89 16.50

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

3.92 3.98 18.1 18.4 17.3

3.96 4.02 18.3 18.6 17.5

4.01 4.06 18.5 18.7 17.7

4.05 4.10 18.7 18.9 17.9

4.09 4.14 18.9 19.1 18.1

4.14 4.17 19.1 19.3 18.3

4.18 4.21 19.3 19.4 18.5

4.23 4.25 19.5 19.6 18.7

4.27 4.29 19.7 19.8 18.9

4.32 4.33 20.0 20.0 19.1

4.33 4.32 20.0 19.9 19.1

4.33 4.31 20.0 19.9 19.1

4.33 4.30 20.0 19.8 19.1

4.33 4.28 20.0

4.33 4.27 20.0 19.7 19.2

4.34 4.26 20.0 19.7 19.2

4.34 4.25 20.0 19.6 19.2

4.34 4.23 20.1 19.5 19.2

4.34 4.22 20.1 19.5 19.2

4.35 4.21 20.1 19.4 19.2

4.35 4.20 20.1 19.4 19.2

4.35 4.19 20.1 19.3 19.2

4.35 4.17 20.1 19.3 19.2

4.35 4.16 20.1 19.2 19.2

4.36 4.15 20.1 19.1 19.3

4.36 4.14 20.1 19.1 19.3

4.36 4.12 20.1 19.0 19.3

4.36 4.11 20.2

4.37 4.10 20.2 18.9 19.3

4.37 4.09 20.2

4.37 4.08 20.2 18.8 19.3

4.37 4.06 20.2 18.8 19.3

4.37 4.05 20.2 18.7 19.3

4.38 4.04 20.2 18.6 19.3

4.38 4.03 20.2

4.38 4.01 20.2 18.5 19.4

4.38 4.00 20.2

4.39 3.99 20.3 18.4 19.4

4.39 3.98 20.3

4.39 3.97 20.3 18.3 19.4

4.39 3.95 20.3 18.2 19.4

4.39 3.94 20.3

4.40 3.93 20.3 18.1 19.4

4.40 3.92 20.3 18.1 19.4

4.40 3.91 20.3

4.40 3.89 20.3 18.0 19.5

4.41 3.88 20.4

4.41 3.87 20.4 17.9 19.5

4.41 3.86 20.4 17.8 19.5

4.41 3.84 20.4 17.7 19.5

4.42 3.83 20.4

Current(A)/ 220V Current(A)/ 230V Current(A)/ 240V

17.6 16.6 16.9

17.8 16.8 17.0

17.9 17.0 17.2

18.1 17.1 17.3

18.3 17.3 17.5

18.4 17.5 17.7

18.6 17.7 17.8

18.8 17.9 18.0

18.9 18.1 18.1

19.1 18.3 18.3

19.0 18.3 18.2

19.8 19.1

19.0

18.9 18.3 18.1

18.3 18.2

18.9 18.4 18.1

18.8 18.4 18.0

18.7 18.4 18.0

18.7 18.4 17.9

18.6 18.4 17.9

18.6 18.4 17.8

18.5 18.4 17.8

18.5 18.4 17.7

18.4 18.4 17.7

18.4 18.4 17.6

18.3 18.4 17.5

18.3

18.5 17.5

18.2 18.5 17.4

19.0 19.3

18.2 18.5 17.4

18.1 18.5 17.3

18.9 19.3

18.0 18.5 17.3

18.0 18.5 17.2

17.9 18.5 17.2

17.9 18.5 17.1

17.8 18.5 17.1

18.6 19.3

17.8 18.5 17.0

17.7 18.6 17.0

18.5 19.4

17.7 18.6 16.9

17.6 18.6 16.9

18.4 19.4

17.6 18.6 16.8

17.5 18.6 16.8

17.5 18.6 16.7

18.2 19.4

17.4 18.6 16.7

17.3 18.6 16.6

18.0 19.4

17.2

18.6 16.5

17.2 18.6 16.5

17.9 19.5

17.1 18.7 16.4

17.1

18.7 16.4

17.0 18.7 16.3

17.7 19.5

16.9 18.7 16.2

4.42 3.82 20.4 17.6 19.5 16.9 18.7 16.2

5-2-3. PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

Total capacity of

indoor units*

80 8.00 9.00 2.35 2.86 10.9 13.2 10.4 12.6 10.0 12.1 81 8.10 9.10 2.38 2.90 11.0 13.4 10.5 12.8 10.1 12.3 82 8.20 9.20 2.41 2.93 11.1 13.5 10.7 13.0 10.2 12.4 83 8.30 9.30 2.44 2.96 11.3 13.7 10.8 13.1 10.3 12.5 84 8.40 9.40 2.48 2.99 11.5 13.8 11.0 13.2 10.5 12.7 85 8.50 9.50 2.51 3.03 11.6 14.0 11.1 13.4 10.6 12.8 86 8.60 9.60 2.54 3.06 11.7 14.1 11.2 13.5 10.8 13.0 87 8.70 9.70 2.57 3.09 11.9 14.3 11.4 13.7 10.9 13.1 88 8.80 9.80 2.61 3.13 12.1 14.5 11.5 13.8 11.1 13.3 89 8.90 9.90 2.64 3.16 12.2 14.6 11.7 14.0 11.2 13.4 90 9.00 10.00 2.67 3.19 12.3 14.7 11.8 14.1 11.3 13.5 91 9.10 10.11 2.71 3.23 12.5 14.9 12.0 14.3 11.5 13.7 92 9.20 10.23 2.74 3.26 12.7 15.1 12.1 14.4 11.6 13.8 93 9.30 10.34 2.77 3.29 12.8 15.2 12.2 14.5 11.7 13.9 94 9.40 10.46 2.81 3.33 13.0 15.4 12.4 14.7 11.9 14.1 95 9.50 10.57 2.84 3.36 13.1 15.5 12.6 14.9 12.0 14.2 96 9.60 10.68 2.88 3.40 13.3 15.7 12.7 15.0 12.2 14.4 97 9.70 10.80 2.91 3.43 13.5 15.9 12.9 15.2 12.3 14.5 98 9.80 10.91 2.95 3.46 13.6 16.0 13.0 15.3 12.5 14.7 99 9.90 11.03 2.98 3.50 13.8 16.2 13.2 15.5 12.6 14.8

100 10.00 11.14 3.02 3.53 14.0 16.3 13.4 15.6 12.8 15.0 101 10.10 11.25 3.05 3.57 14.1 16.5 13.5 15.8 12.9 15.1 102 10.20 11.37 3.09 3.60 14.3 16.6 13.7 15.9 13.1 15.3 103 10.30 11.48 3.13 3.64 14.5 16.8 13.8 16.1 13.3 15.4 104 10.40 11.60 3.16 3.67 14.6 17.0 14.0 16.2 13.4 15.6 105 10.50 11.71 3.20 3.71 14.8 17.1 14.1 16.4 13.6 15.7 106 10.60 11.82 3.24 3.74 15.0 17.3 14.3 16.5 13.7 15.8 107 10.70 11.94 3.27 3.78 15.1 17.5 14.5 16.7 13.9 16.0 108 10.80 12.05 3.31 3.81 15.3 17.6 14.6 16.8 14.0 16.1 109 10.90 12.17 3.35 3.85 15.5 17.8 14.8 17.0 14.2 16.3 110 11.00 12.28 3.39 3.88 15.7 17.9 15.0 17.2 14.4 16.4 111 11.10 12.39 3.43 3.92 15.9 18.1 15.2 17.3 14.5 16.6 112 11.20 12.51 3.46 3.95 16.0 18.3 15.3 17.5 14.7 16.7 113 11.30 12.63 3.50 3.99 16.2 18.4 15.5 17.6 14.8 16.9 114 11.40 12.75 3.54 4.03 16.4 18.6 15.7 17.8 15.0 17.1 115 11.50 12.88 3.58 4.06 16.5 18.8 15.8 17.9 15.2 17.2 116 11.60 13.00 3.62 4.10 16.7 18.9 16.0 18.1 15.3 17.4 117 11.70 13.13 3.66 4.13 16.9 19.1 16.2 18.3 15.5 17.5 118 11.80 13.25 3.70 4.17 17.1 19.3 16.4 18.4 15.7 17.7 119 11.90 13.38 3.74 4.21 17.3 19.5 16.5 18.6 15.8 17.8 120 12.00 13.50 3.78 4.24 17.5 19.6 16.7 18.7 16.0 18.0 121 12.10 13.63 3.82 4.28 17.7 19.8 16.9 18.9 16.2 18.1 122 12.20 13.75 3.86 4.32 17.8 20.0 17.1 19.1 16.4 18.3 123 12.30 13.88 3.90 4.35 18.0 20.1 17.2 19.2 16.5 18.4 124 12.40 14.00 3.95 4.39 18.3 20.3 17.5 19.4 16.7 18.6 125 12.50 14.13 3.99 4.43 18.4 20.5 17.6 19.6 16.9 18.8 126 12.60 14.25 4.03 4.46 18.6 20.6 17.8 19.7 17.1 18.9 127 12.70 14.38 4.07 4.50 18.8 20.8 18.0 19.9 17.2 19.1 128 12.80 14.50 4.12 4.54 19.0 21.0 18.2 20.1 17.5 19.2 129 12.90 14.63 4.16 4.58 19.2 21.2 18.4 20.2 17.6 19.4 130 13.00 14.75 4.20 4.61 19.4 21.3 18.6 20.4 17.8 19.5 131 13.10 14.88 4.24 4.65 19.6 21.5 18.7 20.6 18.0 19.7 132 13.20 15.00 4.29 4.69 19.8 21.7 19.0 20.7 18.2 19.9 133 13.30 15.13 4.33 4.73 20.0 21.9 19.1 20.9 18.3 20.0 134 13.40 15.25 4.38 4.77 20.2 22.0 19.4 21.1 18.6 20.2 135 13.50 15.38 4.42 4.80 20.4 22.2 19.5 21.2 18.7 20.3 136 13.60 15.50 4.46 4.84 20.6 22.4 19.7 21.4 18.9 20.5 137 13.70 15.63 4.51 4.88 20.8 22.6 19.9 21.6 19.1 20.7 138 13.80 15.75 4.55 4.92 21.0 22.7 20.1 21.7 19.3 20.8 139 13.90 15.88 4.60 4.96 21.3 22.9 20.3 21.9 19.5 21.0 140 14.00 16.00 4.64 5.00 21.4 23.1 20.5 22.1 19.7 21.2 141 14.10 16.13 4.69 5.03 21.7 23.2 20.7 22.2 19.9 21.3 142 14.20 16.26 4.74 5.07 21.9 23.4 21.0 22.4 20.1 21.5 143 14.30 16.40 4.78 5.11 22.1 23.6 21.1 22.6 20.3 21.6 144 14.40 16.53 4.83 5.15 22.3 23.8 21.4 22.8 20.5 21.8 145 14.50 16.66 4.87 5.19 22.5 24.0 21.5 22.9 20.6 22.0

Capacity(kW

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

)

Power Consumption(kW)Current(A)/220V Current(A)/230V Current(A)/240V

)

Total capacity of

indoor units*

146 14.60 16.80 4.92 5.23 22.7 24.2 21.7 23.1 20.8 22.2 147 14.70 16.93 4.97 5.27 23.0 24.4 22.0 23.3 21.1 22.3 148 14.80 17.06 5.02 5.31 23.2 24.5 22.2 23.5 21.3 22.5 149 14.90 17.20 5.06 5.35 23.4 24.7 22.4 23.6 21.4 22.7 150 15.00 17.33 5.11 5.39 23.6 24.9 22.6 23.8 21.6 22.8 151 15.10 17.46 5.16 5.43 23.8 25.1 22.8 24.0 21.9 23.0 152 15.20 17.60 5.21 5.47 24.1 25.3 23.0 24.2 22.1 23.2 153 15.30 17.73 5.26 5.51 24.3 25.5 23.3 24.4 22.3 23.3 154 15.40 17.86 5.31 5.55 24.5 25.6 23.5 24.5 22.5 23.5 155 15.50 18.00 5.35 5.58 24.7 25.8 23.6 24.7 22.7 23.6 156 15.51 18.01 5.35 5.57 24.7 25.7 23.7 24.6 22.7 23.6 157 15.52 18.02 5.35 5.55 24.7 25.7 23.7 24.5 22.7 23.5 158 15.54 18.04 5.36 5.54 24.8 25.6 23.7 24.5 22.7 23.5 159 15.55 18.05 5.36 5.52 24.8 25.5 23.7 24.4 22.7 23.4 160 15.57 18.06 5.36 5.51 24.8 25.5 23.7 24.4 22.7 23.3 161 15.58 18.07 5.37 5.49 24.8 25.4 23.7 24.3 22.7 23.3 162 15.60 18.09 5.37 5.48 24.8 25.3 23.7 24.2 22.7 23.2 163 15.61 18.10 5.37 5.47 24.8 25.3 23.7 24.2 22.8 23.2 164 15.62 18.11 5.37 5.45 24.8 25.2 23.8 24.1 22.8 23.1 165 15.64 18.12 5.38 5.44 24.8 25.1 23.8 24.0 22.8 23.0 166 15.65 18.14 5.38 5.42 24.9 25.1 23.8 24.0 22.8 23.0 167 15.67 18.15 5.38 5.41 24.9 25.0 23.8 23.9 22.8 22.9 168 15.68 18.16 5.38 5.39 24.9 24.9 23.8 23.8 22.8 22.8 169 15.70 18.17 5.39 5.38 24.9 24.9 23.8 23.8 22.8 22.8 170 15.71 18.19 5.39 5.36 24.9 24.8 23.8 23.7 22.8 22.7 171 15.73 18.20 5.39 5.35 24.9 24.7 23.8 23.6 22.8 22.7 172 15.74 18.21 5.40 5.34 24.9 24.7 23.9 23.6 22.9 22.6 173 15.76 18.22 5.40 5.32 24.9 24.6 23.9 23.5 22.9 22.5 174 15.77 18.24 5.40 5.31 25.0 24.5 23.9 23.5 22.9 22.5 175 15.79 18.25 5.40 5.29 25.0 24.5 23.9 23.4 22.9 22.4 176 15.80 18.26 5.41 5.28 25.0 24.4 23.9 23.3 22.9 22.4 177 15.81 18.27 5.41 5.26 25.0 24.3 23.9 23.3 22.9 22.3 178 15.83 18.29 5.41 5.25 25.0 24.3 23.9 23.2 22.9 22.2 179 15.84 18.30 5.41 5.23 25.0 24.2 23.9 23.1 22.9 22.2 180 15.86 18.31 5.42 5.22 25.0 24.1 23.9 23.1 23.0 22.1 181 15.87 18.32 5.42 5.21 25.0 24.1 24.0 23.0 23.0 22.1 182 15.89 18.34 5.42 5.19 25.1 24.0 24.0 22.9 23.0 22.0 183 15.90 18.35 5.43 5.18 25.1 23.9 24.0 22.9 23.0 21.9 184 15.92 18.36 5.43 5.16 25.1 23.9 24.0 22.8 23.0 21.9 185 15.93 18.37 5.43 5.15 25.1 23.8 24.0 22.8 23.0 21.8 186 15.95 18.39 5.43 5.13 25.1 23.7 24.0 22.7 23.0 21.7 187 15.96 18.40 5.44 5.12 25.1 23.7 24.0 22.6 23.0 21.7 188 15.97 18.41 5.44 5.10 25.1 23.6 24.0 22.6 23.0 21.6 189 15.99 18.42 5.44 5.09 25.2 23.5 24.1 22.5 23.1 21.6 190 16.00 18.44 5.45 5.07 25.2 23.5 24.1 22.4 23.1 21.5 191 16.02 18.45 5.45 5.06 25.2 23.4 24.1 22.4 23.1 21.4 192 16.03 18.46 5.45 5.05 25.2 23.3 24.1 22.3 23.1 21.4 193 16.05 18.47 5.45 5.03 25.2 23.3 24.1 22.2 23.1 21.3 194 16.06 18.49 5.46 5.02 25.2 23.2 24.1 22.2 23.1 21.3 195 16.08 18.50 5.46 5.00 25.2 23.1 24.1 22.1 23.1 21.2 196 16.09 18.51 5.46 4.99 25.2 23.1 24.1 22.1 23.1 21.1 197 16.11 18.52 5.46 4.97 25.3 23.0 24.2 22.0 23.1 21.1 198 16.12 18.54 5.47 4.96 25.3 22.9 24.2 21.9 23.2 21.0 199 16.14 18.55 5.47 4.94 25.3 22.9 24.2 21.9 23.2 20.9 200 16.15 18.56 5.47 4.93 25.3 22.8 24.2 21.8 23.2 20.9 201 16.16 18.57 5.48 4.92 25.3 22.7 24.2 21.7 23.2 20.8 202 16.18 18.59 5.48 4.90 25.3 22.7 24.2 21.7 23.2 20.8 203 16.19 18.60 5.48 4.89 25.3 22.6 24.2 21.6 23.2 20.7 204 16.21 18.61 5.48 4.87 25.3 22.5 24.2 21.5 23.2 20.6 205 16.22 18.62 5.49 4.86 25.4 22.5 24.3 21.5 23.2 20.6 206 16.24 18.64 5.49 4.84 25.4 22.4 24.3 21.4 23.3 20.5 207 16.25 18.65 5.49 4.83 25.4 22.3 24.3 21.3 23.3 20.5 208 16.27 18.66 5.49 4.81 25.4 22.3 24.3 21.3 23.3 20.4

Capacity(kW

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)Current(A)/220V Current(A)/230V Current(A)/240V

5-2-4. PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

Total capacity of

indoor units

56 5.60 6.30 1.57 1.87 2.52 3.00 2.39 2.85 2.31 2.75 57 5.70 6.41 1.59 1.90 2.55 3.05 2.42 2.89 2.34 2.79 58 5.80 6.53 1.62 1.92 2.60 3.08 2.47 2.93 2.38 2.82 59 5.90 6.64 1.64 1.95 2.63 3.13 2.50 2.97 2.41 2.86 60 6.00 6.75 1.66 1.98 2.66 3.17 2.53 3.02 2.44 2.91 61 6.10 6.87 1.69 2.00 2.71 3.21 2.58 3.05 2.48 2.94 62 6.20 6.98 1.71 2.03 2.74 3.26 2.61 3.09 2.51 2.98 63 6.30 7.09 1.74 2.06 2.79 3.30 2.65 3.14 2.56 3.02 64 6.40 7.20 1.76 2.08 2.82 3.34 2.68 3.17 2.59 3.05 65 6.50 7.32 1.78 2.11 2.85 3.38 2.71 3.21 2.61 3.10 66 6.60 7.43 1.81 2.14 2.90 3.43 2.76 3.26 2.66 3.14 67 6.70 7.54 1.83 2.17 2.93 3.48 2.79 3.31 2.69 3.19 68 6.80 7.66 1.86 2.20 2.98 3.53 2.83 3.35 2.73 3.23 69 6.90 7.77 1.89 2.22 3.03 3.56 2.88 3.38 2.78 3.26 70 7.00 7.88 1.91 2.25 3.06 3.61 2.91 3.43 2.81 3.30 71 7.10 8.00 1.94 2.28 3.11 3.66 2.96 3.47 2.85 3.35 72 7.20 8.11 1.97 2.31 3.16 3.70 3.00 3.52 2.89 3.39 73 7.30 8.22 1.99 2.34 3.19 3.75 3.03 3.56 2.92 3.44 74 7.40 8.33 2.02 2.37 3.24 3.80 3.08 3.61 2.97 3.48 75 7.50 8.44 2.05 2.40 3.28 3.85 3.12 3.66 3.01 3.52 76 7.60 8.56 2.08 2.43 3.33 3.90 3.17 3.70 3.05 3.57 77 7.70 8.67 2.11 2.46 3.38 3.94 3.21 3.75 3.10 3.61 78 7.80 8.78 2.13 2.49 3.41 3.99 3.24 3.79 3.13 3.66 79 7.90 8.89 2.16 2.52 3.46 4.04 3.29 3.84 3.17 3.70 80 8.00 9.00 2.19 2.55 3.51 4.09 3.34 3.88 3.22 3.74 81 8.10 9.10 2.22 2.58 3.56 4.14 3.38 3.93 3.26 3.79 82 8.20 9.20 2.25 2.61 3.60 4.18 3.43 3.97 3.30 3.83 83 8.30 9.30 2.28 2.64 3.65 4.23 3.47 4.02 3.35 3.88 84 8.40 9.40 2.31 2.67 3.70 4.28 3.52 4.07 3.39 3.92 85 8.50 9.50 2.35 2.70 3.76 4.33 3.58 4.11 3.45 3.96 86 8.60 9.60 2.38 2.74 3.81 4.39 3.62 4.17 3.49 4.02 87 8.70 9.70 2.41 2.77 3.86 4.44 3.67 4.22 3.54 4.07 88 8.80 9.80 2.44 2.80 3.91 4.49 3.72 4.26 3.58 4.11 89 8.90 9.90 2.47 2.83 3.96 4.54 3.76 4.31 3.63 4.15 90 9.00 10.00 2.51 2.86 4.02 4.58 3.82 4.35 3.68 4.20 91 9.10 10.10 2.54 2.90 4.07 4.65 3.87 4.42 3.73 4.26 92 9.20 10.22 2.57 2.93 4.12 4.70 3.91 4.46 3.77 4.30 93 9.30 10.33 2.60 2.96 4.16 4.74 3.96 4.51 3.82 4.34 94 9.40 10.45 2.64 3.00 4.23 4.81 4.02 4.57 3.88 4.40 95 9.50 10.56 2.67 3.03 4.28 4.86 4.07 4.61 3.92 4.45 96 9.60 10.67 2.71 3.06 4.34 4.90 4.13 4.66 3.98 4.49 97 9.70 10.79 2.74 3.10 4.39 4.97 4.17 4.72 4.02 4.55 98 9.80 10.90 2.78 3.13 4.45 5.02 4.23 4.77 4.08 4.59

99 9.90 11.02 2.81 3.17 4.50 5.08 4.28 4.83 4.12 4.65 100 10.00 11.13 2.85 3.20 4.56 5.13 4.34 4.87 4.18 4.70 101 10.10 11.24 2.88 3.24 4.61 5.19 4.39 4.93 4.23 4.75 102 10.20 11.36 2.92 3.27 4.67 5.24 4.45 4.98 4.29 4.80 103 10.30 11.47 2.96 3.31 4.74 5.30 4.51 5.04 4.34 4.86 104 10.40 11.59 2.99 3.34 4.79 5.35 4.55 5.08 4.39 4.90 105 10.50 11.70 3.03 3.38 4.85 5.42 4.61 5.15 4.45 4.96 106 10.60 11.81 3.07 3.41 4.91 5.46 4.67 5.19 4.51 5.00 107 10.70 11.93 3.11 3.45 4.98 5.53 4.74 5.25 4.56 5.06 108 10.80 12.04 3.14 3.48 5.03 5.58 4.78 5.30 4.61 5.11 109 10.90 12.16 3.18 3.52 5.09 5.64 4.84 5.36 4.67 5.17 110 11.00 12.27 3.22 3.56 5.15 5.70 4.90 5.42 4.73 5.22

111 11.10 12.38 3.26 3.59 5.22 5.75 4.96 5.47 4.78 5.27 112 11.20 12.50 3.30 3.63 5.28 5.81 5.02 5.52 4.84 5.32 113 11.22 12.51 3.31 3.62 5.30 5.80 5.04 5.51 4.86 5.31 114 11.24 12.53 3.31 3.61 5.30 5.78 5.04 5.50 4.86 5.30 115 11.26 12.54 3.32 3.60 5.31 5.77 5.05 5.48 4.87 5.28 116 11.28 12.55 3.32 3.59 5.31 5.75 5.05 5.47 4.87 5.27 117 11.30 12.56 3.32 3.58 5.31 5.74 5.05 5.45 4.87 5.25 118 11.32 12.57 3.33 3.56 5.33 5.70 5.07 5.42 4.89 5.22 119 11.34 12.58 3.33 3.55 5.33 5.69 5.07 5.40 4.89 5.21 120 11.36 12.60 3.34 3.54 5.35 5.67 5.08 5.39 4.90 5.19

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

Total capacity of Capacity(kW)

indoor units

121 11.38 12.61 3.34 3.53 5.35 5.66 5.08 5.37 4.90 5.18 122 11.40 12.62 3.34 3.52 5.35 5.64 5.08 5.36 4.90 5.17 123 11.42 12.63 3.35 3.51 5.36 5.62 5.10 5.34 4.92 5.15 124 11.44 12.64 3.35 3.50 5.36 5.61 5.10 5.33 4.92 5.14 125 11.47 12.66 3.36 3.48 5.38 5.58 5.12 5.30 4.93 5.11 126 11.49 12.67 3.36 3.47 5.38 5.56 5.12 5.28 4.93 5.09 127 11.51 12.68 3.36 3.46 5.38 5.54 5.12 5.27 4.93 5.08 128 11.53 12.69 3.37 3.45 5.39 5.53 5.13 5.25 4.95 5.06 129 11.55 12.70 3.37 3.44 5.39 5.51 5.13 5.24 4.95 5.05 130 11.57 12.71 3.38 3.43 5.41 5.50 5.15 5.22 4.96 5.03 131 11.59 12.73 3.38 3.41 5.41 5.46 5.15 5.19 4.96 5.00 132 11.61 12.74 3.38 3.40 5.41 5.45 5.15 5.18 4.96 4.99 133 11.63 12.75 3.39 3.39 5.43 5.43 5.16 5.16 4.97 4.97 134 11.65 12.76 3.39 3.38 5.43 5.42 5.16 5.15 4.97 4.96 135 11.67 12.77 3.40 3.37 5.44 5.40 5.18 5.13 4.99 4.95 136 11.69 12.78 3.40 3.36 5.44 5.38 5.18 5.12 4.99 4.93 137 11.71 12.80 3.40 3.34 5.44 5.35 5.18 5.08 4.99 4.90 138 11.73 12.81 3.41 3.33 5.46 5.34 5.19 5.07 5.00 4.89 139 11.75 12.82 3.41 3.32 5.46 5.32 5.19 5.05 5.00 4.87 140 11.77 12.83 3.42 3.31 5.47 5.30 5.21 5.04 5.02 4.86 141 11.79 12.84 3.42 3.30 5.47 5.29 5.21 5.02 5.02 4.84 142 11.82 12.86 3.42 3.29 5.47 5.27 5.21 5.01 5.02 4.83 143 11.84 12.87 3.43 3.27 5.49 5.24 5.22 4.98 5.03 4.80 144 11.86 12.88 3.43 3.26 5.49 5.22 5.22 4.96 5.03 4.78 145 11.88 12.89 3.44 3.25 5.51 5.21 5.24 4.95 5.05 4.77

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

5-2-5. PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

Total capacity of

indoor units

70 7.00 7.88 1.80 2.04 2.88 3.27 2.74 3.10 2.64 3.00

71 7.10 8.00 1.83 2.06 2.93 3.30 2.79 3.13 2.69 3.02

72 7.20 8.11 1.85 2.09 2.96 3.35 2.82 3.18 2.72 3.07

73 7.30 8.22 1.88 2.11 3.01 3.38 2.86 3.21 2.76 3.10

74 7.40 8.33 1.91 2.14 3.06 3.43 2.91 3.26 2.81 3.14

75 7.50 8.44 1.93 2.17 3.09 3.48 2.94 3.30 2.83 3.19

76 7.60 8.56 1.96 2.19 3.14 3.51 2.98 3.33 2.88 3.22

77 7.70 8.67 1.99 2.22 3.19 3.56 3.03 3.38 2.92 3.26

78 7.80 8.78 2.01 2.25 3.22 3.61 3.06 3.42 2.95 3.30

79 7.90 8.89 2.04 2.28 3.27 3.66 3.10 3.47 3.00 3.35

80 8.00 9.00 2.07 2.30 3.32 3.69 3.15 3.50 3.04 3.38

81 8.10 9.10 2.10 2.33 3.36 3.74 3.20 3.55 3.08 3.42

82 8.20 9.20 2.12 2.36 3.40 3.78 3.23 3.59 3.11 3.46

83 8.30 9.30 2.15 2.39 3.44 3.83 3.27 3.64 3.16 3.51

84 8.40 9.40 2.18 2.42 3.49 3.88 3.32 3.68 3.20 3.55

85 8.50 9.50 2.21 2.44 3.54 3.91 3.36 3.71 3.24 3.58

86 8.60 9.60 2.24 2.47 3.59 3.96 3.41 3.76 3.29 3.63

87 8.70 9.70 2.27 2.50 3.64 4.01 3.45 3.80 3.33 3.67

88 8.80 9.80 2.30 2.53 3.68 4.06 3.50 3.85 3.38 3.71

89 8.90 9.90 2.33 2.56 3.73 4.10 3.55 3.89 3.42 3.76

90 9.00 10.00 2.36 2.59 3.78 4.15 3.59 3.94 3.46 3.80

91 9.10 10.10 2.39 2.62 3.83 4.20 3.64 3.99 3.51 3.85

92 9.20 10.22 2.42 2.65 3.88 4.25 3.68 4.03 3.55 3.89

93 9.30 10.33 2.45 2.68 3.92 4.30 3.73 4.08 3.60 3.93

94 9.40 10.45 2.49 2.71 3.99 4.34 3.79 4.12 3.66 3.98

95 9.50 10.56 2.52 2.74 4.04 4.39 3.83 4.17 3.70 4.02

96 9.60 10.67 2.55 2.77 4.08 4.44 3.88 4.21 3.74 4.07

97 9.70 10.79 2.58 2.80 4.13 4.49 3.92 4.26 3.79 4.11

98 9.80 10.90 2.62 2.83 4.20 4.54 3.99 4.30 3.85 4.15

99 9.90 11.02 2.65 2.86 4.24 4.58 4.03 4.35 3.89 4.20

100 10.00 11.13 2.68 2.89 4.29 4.63 4.08 4.40 3.93 4.24 101 10.10 11.24 2.72 2.92 4.36 4.68 4.14 4.44 3.99 4.29 102 10.20 11.36 2.75 2.96 4.40 4.74 4.18 4.50 4.04 4.34 103 10.30 11.47 2.79 2.99 4.47 4.79 4.24 4.55 4.10 4.39 104 10.40 11.59 2.82 3.02 4.52 4.84 4.29 4.59 4.14 4.43 105 10.50 11.70 2.86 3.05 4.58 4.89 4.35 4.64 4.20 4.48 106 10.60 11.81 2.89 3.08 4.63 4.94 4.40 4.68 4.24 4.52 107 10.70 11.93 2.93 3.12 4.69 5.00 4.46 4.75 4.30 4.58 108 10.80 12.04 2.96 3.15 4.74 5.05 4.50 4.79 4.34 4.62 109 10.90 12.16 3.00 3.18 4.80 5.10 4.56 4.84 4.40 4.67 110 11.00 12.27 3.04 3.21 4.87 5.14 4.62 4.88 4.46 4.71

111 11.10 12.38 3.07 3.25 4.91 5.21 4.67 4.94 4.51 4.77 112 11.20 12.50 3.11 3.28 4.98 5.26 4.73 4.99 4.56 4.81 113 11.30 12.63 3.15 3.31 5.04 5.30 4.79 5.03 4.62 4.86 114 11.40 12.75 3.19 3.35 5.11 5.37 4.85 5.09 4.68 4.92 115 11.50 12.88 3.22 3.38 5.15 5.42 4.90 5.14 4.73 4.96 116 11.60 13.00 3.26 3.42 5.22 5.48 4.96 5.20 4.78 5.02 117 11.70 13.13 3.30 3.45 5.28 5.53 5.02 5.25 4.84 5.06 118 11.80 13.25 3.34 3.49 5.35 5.59 5.08 5.31 4.90 5.12 119 11.90 13.38 3.38 3.52 5.41 5.64 5.14 5.35 4.96 5.17 120 12.00 13.50 3.42 3.55 5.47 5.69 5.20 5.40 5.02 5.21 121 12.10 13.63 3.46 3.59 5.54 5.75 5.26 5.46 5.08 5.27 122 12.20 13.75 3.50 3.62 5.60 5.80 5.32 5.51 5.14 5.31 123 12.30 13.88 3.54 3.66 5.67 5.86 5.38 5.57 5.19 5.37 124 12.40 14.00 3.58 3.70 5.73 5.93 5.44 5.63 5.25 5.43 125 12.50 14.13 3.62 3.73 5.79 5.98 5.51 5.67 5.31 5.47 126 12.60 14.25 3.66 3.77 5.86 6.04 5.57 5.73 5.37 5.53 127 12.70 14.38 3.70 3.80 5.92 6.09 5.63 5.78 5.43 5.58 128 12.80 14.50 3.74 3.84 5.99 6.15 5.69 5.84 5.49 5.63 129 12.90 14.63 3.79 3.88 6.07 6.22 5.76 5.90 5.56 5.69 130 13.00 14.75 3.83 3.91 6.13 6.26 5.82 5.95 5.62 5.74

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

Total capacity of

indoor units

131 13.10 14.88 3.87 3.95 6.19 6.33 5.88 6.01 5.68 5.80 132 13.20 15.00 3.91 3.99 6.26 6.39 5.95 6.07 5.74 5.85 133 13.30 15.13 3.96 4.02 6.34 6.44 6.02 6.11 5.81 5.90 134 13.40 15.25 4.00 4.06 6.40 6.51 6.08 6.17 5.87 5.96 135 13.50 15.38 4.04 4.10 6.47 6.57 6.14 6.23 5.93 6.02 136 13.60 15.50 4.09 4.14 6.55 6.63 6.22 6.30 6.00 6.07 137 13.70 15.63 4.13 4.17 6.61 6.68 6.28 6.34 6.06 6.12 138 13.80 15.75 4.18 4.21 6.69 6.75 6.36 6.40 6.13 6.18 139 13.90 15.88 4.22 4.25 6.75 6.81 6.42 6.46 6.19 6.24 140 14.00 16.00 4.27 4.29 6.83 6.87 6.49 6.52 6.26 6.29 141 14.02 16.01 4.28 4.28 6.84 6.86 6.50 6.51 6.27 6.28 142 14.04 16.02 4.28 4.27 6.85 6.84 6.50 6.49 6.28 6.26 143 14.06 16.03 4.28 4.26 6.85 6.82 6.51 6.47 6.28 6.24 144 14.08 16.04 4.28 4.24 6.85 6.80 6.51 6.45 6.28 6.23 145 14.10 16.06 4.28 4.23 6.86 6.78 6.51 6.43 6.29 6.21 146 14.12 16.07 4.29 4.22 6.86 6.76 6.52 6.42 6.29 6.19 147 14.15 16.08 4.29 4.21 6.86 6.74 6.52 6.40 6.29 6.17 148 14.17 16.09 4.29 4.19 6.87 6.72 6.52 6.38 6.29 6.15 149 14.19 16.10 4.29 4.18 6.87 6.70 6.53 6.36 6.30 6.14 150 14.21 16.12 4.30 4.17 6.87 6.68 6.53 6.34 6.30 6.12 151 14.23 16.13 4.30 4.16 6.88 6.66 6.53 6.32 6.30 6.10 152 14.25 16.14 4.30 4.15 6.88 6.64 6.54 6.31 6.31 6.08 153 14.27 16.15 4.30 4.13 6.88 6.62 6.54 6.29 6.31 6.07 154 14.30 16.16 4.30 4.12 6.89 6.61 6.54 6.27 6.31 6.05 155 14.32 16.17 4.31 4.11 6.89 6.59 6.55 6.25 6.32 6.03 156 14.34 16.19 4.31 4.10 6.90 6.57 6.55 6.23 6.32 6.01 157 14.36 16.20 4.31 4.09 6.90 6.55 6.55 6.21 6.32 6.00 158 14.38 16.21 4.31 4.07 6.90 6.53 6.56 6.20 6.33 5.98 159 14.40 16.22 4.32 4.06 6.91 6.51 6.56 6.18 6.33 5.96 160 14.42 16.23 4.32 4.05 6.91 6.49 6.56 6.16 6.33 5.94 161 14.45 16.25 4.32 4.04 6.91 6.47 6.57 6.14 6.34 5.92 162 14.47 16.26 4.32 4.03 6.92 6.45 6.57 6.12 6.34 5.91 163 14.49 16.27 4.32 4.01 6.92 6.43 6.57 6.10 6.34 5.89 164 14.51 16.28 4.33 4.00 6.92 6.41 6.58 6.09 6.35 5.87 165 14.53 16.29 4.33 3.99 6.93 6.39 6.58 6.07 6.35 5.85 166 14.55 16.31 4.33 3.98 6.93 6.37 6.58 6.05 6.35 5.84 167 14.57 16.32 4.33 3.97 6.93 6.35 6.59 6.03 6.36 5.82 168 14.60 16.33 4.34 3.95 6.94 6.33 6.59 6.01 6.36 5.80 169 14.62 16.34 4.34 3.94 6.94 6.32 6.59 5.99 6.36 5.78 170 14.64 16.35 4.34 3.93 6.95 6.30 6.60 5.98 6.37 5.77 171 14.66 16.36 4.34 3.92 6.95 6.28 6.60 5.96 6.37 5.75 172 14.68 16.38 4.34 3.91 6.95 6.26 6.61 5.94 6.37 5.73 173 14.70 16.39 4.35 3.89 6.96 6.24 6.61 5.92 6.38 5.71 174 14.72 16.40 4.35 3.88 6.96 6.22 6.61 5.90 6.38 5.69 175 14.75 16.41 4.35 3.87 6.96 6.20 6.62 5.88 6.38 5.68 176 14.77 16.42 4.35 3.86 6.97 6.18 6.62 5.87 6.39 5.66 177 14.79 16.44 4.36 3.84 6.97 6.16 6.62 5.85 6.39 5.64 178 14.81 16.45 4.36 3.83 6.97 6.14 6.63 5.83 6.39 5.62 179 14.83 16.46 4.36 3.82 6.98 6.12 6.63 5.81 6.40 5.61 180 14.85 16.47 4.36 3.81 6.98 6.10 6.63 5.79 6.40 5.59 181 14.87 16.48 4.36 3.80 6.98 6.08 6.64 5.77 6.40 5.57 182 14.89 16.50 4.37 3.78 6.99 6.06 6.64 5.76 6.41 5.55

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

5-2-6. PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

* Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity

following the formula on 5-1-1.

Total capacity of

indoor units

80 8.00 9.00 2.34 2.73 3.75 4.37 3.56 4.16 3.44 4.01 81 8.10 9.10 2.37 2.76 3.80 4.42 3.61 4.20 3.48 4.05 82 8.20 9.20 2.40 2.79 3.84 4.47 3.66 4.25 3.52 4.10 83 8.30 9.30 2.43 2.82 3.89 4.52 3.70 4.29 3.57 4.14 84 8.40 9.40 2.46 2.86 3.94 4.58 3.75 4.35 3.61 4.20 85 8.50 9.50 2.49 2.89 3.99 4.63 3.79 4.40 3.66 4.24 86 8.60 9.60 2.53 2.92 4.05 4.67 3.85 4.45 3.71 4.29 87 8.70 9.70 2.56 2.95 4.10 4.72 3.90 4.49 3.76 4.33 88 8.80 9.80 2.59 2.98 4.15 4.77 3.94 4.54 3.80 4.37 89 8.90 9.90 2.62 3.01 4.20 4.82 3.99 4.58 3.85 4.42 90 9.00 10.00 2.66 3.04 4.26 4.87 4.05 4.63 3.90 4.46 91 9.10 10.11 2.69 3.08 4.31 4.93 4.10 4.69 3.95 4.52 92 9.20 10.23 2.72 3.11 4.36 4.98 4.14 4.74 3.99 4.56 93 9.30 10.34 2.76 3.14 4.42 5.03 4.20 4.78 4.05 4.61 94 9.40 10.46 2.79 3.17 4.47 5.07 4.25 4.83 4.10 4.65 95 9.50 10.57 2.83 3.21 4.53 5.14 4.31 4.89 4.15 4.71 96 9.60 10.68 2.86 3.24 4.58 5.19 4.35 4.93 4.20 4.75 97 9.70 10.80 2.89 3.27 4.63 5.23 4.40 4.98 4.24 4.80 98 9.80 10.91 2.93 3.30 4.69 5.28 4.46 5.02 4.30 4.84

99 9.90 11.03 2.97 3.34 4.75 5.35 4.52 5.08 4.36 4.90 100 10.00 11.14 3.00 3.37 4.80 5.39 4.57 5.13 4.40 4.95 101 10.10 11.25 3.04 3.40 4.87 5.44 4.63 5.18 4.46 4.99 102 10.20 11.37 3.07 3.43 4.91 5.49 4.67 5.22 4.51 5.03 103 10.30 11.48 3.11 3.47 4.98 5.55 4.74 5.28 4.56 5.09 104 10.40 11.60 3.14 3.50 5.03 5.60 4.78 5.33 4.61 5.14 105 10.50 11.71 3.18 3.53 5.09 5.65 4.84 5.37 4.67 5.18 106 10.60 11.82 3.22 3.57 5.15 5.71 4.90 5.43 4.73 5.24 107 10.70 11.94 3.26 3.60 5.22 5.76 4.96 5.48 4.78 5.28 108 10.80 12.05 3.29 3.63 5.27 5.81 5.01 5.53 4.83 5.33 109 10.90 12.17 3.33 3.67 5.33 5.87 5.07 5.59 4.89 5.39 110 11.00 12.28 3.37 3.70 5.39 5.92 5.13 5.63 4.95 5.43

111 11.10 12.39 3.41 3.74 5.46 5.99 5.19 5.69 5.00 5.49 112 11.20 12.51 3.45 3.77 5.52 6.03 5.25 5.74 5.06 5.53 113 11.30 12.63 3.48 3.80 5.57 6.08 5.30 5.78 5.11 5.58 114 11.40 12.75 3.52 3.84 5.63 6.15 5.36 5.85 5.17 5.63 115 11.50 12.88 3.56 3.87 5.70 6.19 5.42 5.89 5.22 5.68 116 11.60 13.00 3.60 3.91 5.76 6.26 5.48 5.95 5.28 5.74 117 11.70 13.13 3.64 3.94 5.83 6.31 5.54 6.00 5.34 5.78 118 11.80 13.25 3.68 3.98 5.89 6.37 5.60 6.06 5.40 5.84 119 11.90 13.38 3.72 4.01 5.95 6.42 5.66 6.10 5.46 5.88 120 12.00 13.50 3.76 4.05 6.02 6.48 5.72 6.16 5.52 5.94 121 12.10 13.63 3.80 4.08 6.08 6.53 5.78 6.21 5.58 5.99 122 12.20 13.75 3.84 4.12 6.15 6.59 5.85 6.27 5.63 6.04 123 12.30 13.88 3.88 4.15 6.21 6.64 5.91 6.32 5.69 6.09 124 12.40 14.00 3.92 4.19 6.27 6.71 5.97 6.38 5.75 6.15 125 12.50 14.13 3.97 4.22 6.35 6.75 6.04 6.42 5.82 6.19 126 12.60 14.25 4.01 4.26 6.42 6.82 6.10 6.48 5.88 6.25 127 12.70 14.38 4.05 4.29 6.48 6.87 6.16 6.53 5.94 6.29 128 12.80 14.50 4.09 4.33 6.55 6.93 6.23 6.59 6.00 6.35 129 12.90 14.63 4.13 4.36 6.61 6.98 6.29 6.64 6.06 6.40 130 13.00 14.75 4.18 4.40 6.69 7.04 6.36 6.70 6.13 6.46 131 13.10 14.88 4.22 4.44 6.75 7.11 6.42 6.76 6.19 6.51 132 13.20 15.00 4.26 4.47 6.82 7.15 6.48 6.80 6.25 6.56 133 13.30 15.13 4.31 4.51 6.90 7.22 6.56 6.86 6.32 6.62 134 13.40 15.25 4.35 4.54 6.96 7.27 6.62 6.91 6.38 6.66 135 13.50 15.38 4.39 4.58 7.03 7.33 6.68 6.97 6.44 6.72 136 13.60 15.50 4.44 4.62 7.11 7.39 6.76 7.03 6.51 6.78 137 13.70 15.63 4.48 4.65 7.17 7.44 6.82 7.08 6.57 6.82 138 13.80 15.75 4.53 4.69 7.25 7.51 6.89 7.14 6.65 6.88 139 13.90 15.88 4.57 4.73 7.31 7.57 6.96 7.20 6.70 6.94 140 14.00 16.00 4.62 4.76 7.39 7.62 7.03 7.24 6.78 6.98 141 14.10 16.13 4.66 4.80 7.46 7.68 7.09 7.31 6.84 7.04 142 14.20 16.26 4.71 4.84 7.54 7.75 7.17 7.37 6.91 7.10 143 14.30 16.40 4.76 4.87 7.62 7.79 7.24 7.41 6.98 7.14

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

Total capacity of

indoor units

144 14.40 16.53 4.80 4.91 7.68 7.86 7.31 7.47 7.04 7.20 145 14.50 16.66 4.85 4.95 7.76 7.92 7.38 7.53 7.11 7.26 146 14.60 16.80 4.89 4.99 7.83 7.99 7.44 7.59 7.17 7.32 147 14.70 16.93 4.94 5.02 7.91 8.03 7.52 7.64 7.25 7.36 148 14.80 17.06 4.99 5.06 7.99 8.10 7.59 7.70 7.32 7.42 149 14.90 17.20 5.04 5.10 8.07 8.16 7.67 7.76 7.39 7.48 150 15.00 17.33 5.08 5.14 8.13 8.23 7.73 7.82 7.45 7.54 151 15.10 17.46 5.13 5.17 8.21 8.27 7.81 7.87 7.53 7.58 152 15.20 17.60 5.18 5.21 8.29 8.34 7.88 7.93 7.60 7.64 153 15.30 17.73 5.23 5.25 8.37 8.40 7.96 7.99 7.67 7.70 154 15.40 17.86 5.28 5.29 8.45 8.47 8.04 8.05 7.75 7.76 155 15.50 18.00 5.32 5.32 8.51 8.51 8.09 8.09 7.80 7.80 156 15.51 18.01 5.32 5.31 8.52 8.49 8.10 8.08 7.81 7.79 157 15.52 18.02 5.32 5.29 8.52 8.47 8.10 8.06 7.81 7.77 158 15.54 18.04 5.33 5.28 8.52 8.45 8.11 8.04 7.81 7.74 159 15.55 18.05 5.33 5.27 8.53 8.43 8.11 8.01 7.82 7.72 160 15.57 18.06 5.33 5.25 8.53 8.40 8.12 7.99 7.82 7.70 161 15.58 18.07 5.34 5.24 8.54 8.38 8.12 7.97 7.83 7.68 162 15.60 18.09 5.34 5.22 8.54 8.36 8.12 7.95 7.83 7.66 163 15.61 18.10 5.34 5.21 8.55 8.34 8.13 7.93 7.83 7.64 164 15.62 18.11 5.34 5.20 8.55 8.32 8.13 7.91 7.84 7.62 165 15.64 18.12 5.35 5.18 8.56 8.29 8.14 7.89 7.84 7.60 166 15.65 18.14 5.35 5.17 8.56 8.27 8.14 7.87 7.85 7.58 167 15.67 18.15 5.35 5.16 8.56 8.25 8.14 7.85 7.85 7.56 168 15.68 18.16 5.35 5.14 8.57 8.23 8.15 7.83 7.85 7.54 169 15.70 18.17 5.36 5.13 8.57 8.21 8.15 7.80 7.86 7.52 170 15.71 18.19 5.36 5.11 8.58 8.18 8.16 7.78 7.86 7.50 171 15.73 18.20 5.36 5.10 8.58 8.16 8.16 7.76 7.87 7.48 172 15.74 18.21 5.37 5.09 8.59 8.14 8.17 7.74 7.87 7.46 173 15.76 18.22 5.37 5.07 8.59 8.12 8.17 7.72 7.87 7.44 174 15.77 18.24 5.37 5.06 8.59 8.10 8.17 7.70 7.88 7.42 175 15.79 18.25 5.37 5.05 8.60 8.07 8.18 7.68 7.88 7.40 176 15.80 18.26 5.38 5.03 8.60 8.05 8.18 7.66 7.89 7.38 177 15.81 18.27 5.38 5.02 8.61 8.03 8.19 7.64 7.89 7.36 178 15.83 18.29 5.38 5.00 8.61 8.01 8.19 7.62 7.89 7.34 179 15.84 18.30 5.38 4.99 8.62 7.99 8.19 7.59 7.90 7.32 180 15.86 18.31 5.39 4.98 8.62 7.96 8.20 7.57 7.90 7.30 181 15.87 18.32 5.39 4.96 8.63 7.94 8.20 7.55 7.91 7.28 182 15.89 18.34 5.39 4.95 8.63 7.92 8.21 7.53 7.91 7.26 183 15.90 18.35 5.40 4.94 8.63 7.90 8.21 7.51 7.91 7.24 184 15.92 18.36 5.40 4.92 8.64 7.88 8.22 7.49 7.92 7.22 185 15.93 18.37 5.40 4.91 8.64 7.85 8.22 7.47 7.92 7.20 186 15.95 18.39 5.40 4.89 8.65 7.83 8.22 7.45 7.93 7.18 187 15.96 18.40 5.41 4.88 8.65 7.81 8.23 7.43 7.93 7.16 188 15.97 18.41 5.41 4.87 8.66 7.79 8.23 7.41 7.93 7.14 189 15.99 18.42 5.41 4.85 8.66 7.77 8.24 7.39 7.94 7.12 190 16.00 18.44 5.41 4.84 8.66 7.74 8.24 7.36 7.94 7.10 191 16.02 18.45 5.42 4.82 8.67 7.72 8.24 7.34 7.95 7.08 192 16.03 18.46 5.42 4.81 8.67 7.70 8.25 7.32 7.95 7.06 193 16.05 18.47 5.42 4.80 8.68 7.68 8.25 7.30 7.95 7.04 194 16.06 18.49 5.43 4.78 8.68 7.66 8.26 7.28 7.96 7.02 195 16.08 18.50 5.43 4.77 8.69 7.63 8.26 7.26 7.96 7.00 196 16.09 18.51 5.43 4.76 8.69 7.61 8.27 7.24 7.97 6.98 197 16.11 18.52 5.43 4.74 8.70 7.59 8.27 7.22 7.97 6.96 198 16.12 18.54 5.44 4.73 8.70 7.57 8.27 7.20 7.97 6.94 199 16.14 18.55 5.44 4.71 8.70 7.54 8.28 7.18 7.98 6.92 200 16.15 18.56 5.44 4.70 8.71 7.52 8.28 7.15 7.98 6.90 201 16.16 18.57 5.44 4.69 8.71 7.50 8.29 7.13 7.99 6.88 202 16.18 18.59 5.45 4.67 8.72 7.48 8.29 7.11 7.99 6.86 203 16.19 18.60 5.45 4.66 8.72 7.46 8.29 7.09 7.99 6.84 204 16.21 18.61 5.45 4.65 8.73 7.43 8.30 7.07 8.00 6.82 205 16.22 18.62 5.46 4.63 8.73 7.41 8.30 7.05 8.00 6.79 206 16.24 18.64 5.46 4.62 8.73 7.39 8.31 7.03 8.01 6.77 207 16.25 18.65 5.46 4.60 8.74 7.37 8.31 7.01 8.01 6.75 208 16.27 18.66 5.46 4.59 8.74 7.35 8.31 6.99 8.01 6.73

Capacity(kW)

Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating

Power Consumption(kW)

Current(A)/380V Current(A)/400V Current(A)/415V

5-3. CORRECTING COOLING AND HEATING CAPACITY

5-3-1. Correcting Changes in Air Conditions

(1) The performance curve charts (Figure 1, 2) show the change ratio of capacity and input (power consumption) according to the

indoor and outdoor temperature condition when defining the rated capacity (total capacity) and rated input under the standard condition in standard piping length (5 m) as “1.0”.

• Standard conditions:

Rated cooling capacity

Rated heating capacity

• Use the rated capacity and rated input given in “5-2.”.

• The input is the single value on the side of the outdoor unit; the input on the sides of each indoor unit must be added to obtain the total input.

(2) The capacity of each indoor unit may be obtained by multiplying the total capacity obtained in (1) by the ratio between the

individual capacity at the rated time and the total capacity at the rated time.

Individual capacity under stated conditions = total capacity under the stated conditions o

(3) Capacity correction factor curve

Figure 1. PUMY-P100VHMB(-BS) PUMY-P100YHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125VHMB(-BS) PUMY-P125YHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P140YHMBR2(-BS)

Indoor D.B. 27˚C / W.B. 19˚C Outdoor D.B. 35˚C

Indoor D.B. 20˚C Outdoor D.B. 7˚C / W.B. 6˚C

individual capacity at the rated time

total capacity at the rated time

Figure 2. PUMY-P100VHMB(-BS) PUMY-P100YHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125VHMB(-BS) PUMY-P125YHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P140YHMBR2(-BS)

Cooling

Capacity

(ratio)

Cooling

Power

consumption

(ratio)

1.4

1.2

1.0

0.8

0.6

1.4

1.2

1.0

0.8

0.6

Cooling performance curve

22 20 18 16

INDOOR

<W.B. :>

20 18 16

INDOOR

<W.B. :>

Heating

Capacity

(ratio)

Heating Power consumption (ratio)

Heating performance curve

1.4

1.2

1.0

0.8

0.6

0.4

1.4

1.2

1.0

0.8

0.6

INDOOR

<D.B. :>

INDOOR

<D.B. :>

0.4

-5 0 10 20 30 40 46

Outdoor <D.B. :>

0.4

-10-15 -5 0 5 10 15

Outdoor <W.B. :>

5-3-2. Correcting Capacity for Changes in the Length of Refrigerant Piping

(1) During cooling, obtain the ratio (and the equivalent piping length) of the outdoor units rated capacity and the total in-use

indoor capacity, and find the capacity ratio corresponding to the standard piping length from Figure 3. Then multiply by the cooling capacity from Figure 1 to obtain the actual capacity.

(2) During heating, find the equivalent piping length, and find the capacity ratio corresponding to standard piping length from

Figure 3. Then multiply by the heating capacity from Figure 2 to obtain the actual capacity.

(1) Capacity CORRECTION CURVE (Figure 3)

Cooling

100

Heating

Heating P100, 125, 140 models

Cooling P100 model

Capacity ratio [%]

Cooling P125 model

Cooling P140 model

5 101520253035404550556065707580

[m]

Corrected pipe length

(2) Method for Obtaining the Equivalent Piping Length

Equivalent length for type P100·125·140 = (length of piping to farthest indoor unit) + (0.3 o number of bends in the piping) (m)

Length of piping to farthest indoor unit: type P100~P140.....80m

5-3-3. Correction of Heating Capacity for Frost and Defrosting

If heating capacity has been reduced due to frost formation or defrosting, multiply the capacity by the appropriate correction factor from the following table to obtain the actual heating capacity.

Correction factor diagram

Outdoor Intake temperature (W.B.°C)

Correction factor

6420-2-4-6-8-10

1.0 0.98 0.89 0.88 0.89 0.9 0.95 0.95 0.95

5-4. NOISE CRITERION CURVES

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

APPROXIMATE

THRESHOLD OF HEARING FOR CONTINUOUS

OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 μbar)

NOISE

63 125 250 500 1000 2000 4000 8000

BAND CENTER FREQUENCIES, Hz

MODE

COOLING

HEATING

SPL(dB)

49 51

LINE

NC-70

NC-60

NC-50

NC-40

NC-30

NC-20

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS)

APPROXIMATE

THRESHOLD OF HEARING FOR CONTINUOUS

OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 μbar)

NOISE

63 125 250 500 1000 2000 4000 8000

BAND CENTER FREQUENCIES, Hz

MODE COOLING HEATING

SPL(dB)

50 52

LINE

NC-70

NC-60

NC-50

NC-40

NC-30

NC-20

PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

APPROXIMATE

THRESHOLD OF HEARING FOR CONTINUOUS NOISE

OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 μbar)

63 125 250 500 1000 2000 4000 8000

BAND CENTER FREQUENCIES, Hz

MODE

COOLING

HEATING

SPL(dB)

51 53

LINE

NC-70

NC-60

NC-50

NC-40

NC-30

NC-20

MICROPHONE

UNIT

1.5m

GROUND

45 40

27 55

23 73 63

Rear piping hole

(Knockout)

Rear trunking hole

(Knockout)

Power supply wiring hole

(2-:27Knockout)

19 55

75 40

73 63 23

27 92

Right piping hole

(Knockout)

Right trunking hole

(Knockout)

Power supply wiring hole

(2-:27Knockout)

n92

4540

27 55

73 63

Front piping hole

(Knockout)

Front trunking hole

(Knockout)

Power supply wiring hole

(2-:27Knockout)

n92

14514522030 145

81 219

Bottom piping hole

(Knockout)

Drain hole

(5-:33)

600175 175

28 370

417

330

Installation Feet

2-12%36 Oval holes

(Foundation Bolt M10)

2-U Shaped notched holes

(Foundation Bolt M10)

1088

322

635

371

950

1350

+1 423

+1 507

Handle for moving

Ground for the power supply

("GR"marking position)

Ground for the transmission line

Ground for concentration control

Terminal block

Left·········For the power supply

Center····For the transmission line

Right·······For concentration control

( )

Less than

Over

Handle for moving

Side Air Intake

Front piping cover

Rear piping cover

Air intake

Rear Air Intake

Handle for moving

Service panel

Handle for moving

The diagram below shows a

basic example.

Explanation of particular details is

given in the installation manuals etc.

Dimensions of space needed

for service access are

shown in the below diagram.

Please secure the unit

firmly with 4 foundation (M10)

bolts.(Bolts and washers must

be purchased locally.)

Air Discharge

Rear Air Intake

Side Air Intake

Refrigerant GAS pipe connection(FLARE):15.88(5/8 inch)

Refrigerant LIQUID pipe connection(FLARE): 9.52(3/8 inch)

+1·····Indication of STOP VALVE connection location.

Example of Notes

Piping Knockout Hole Details

1 FREE SPACE (Around the unit)

2 SERVICE SPACE 3 FOUNDATION BOLTS

4 PIPING-WIRING DIRECTIONS

Piping and wiring connections

can be made from 4 directions:

front, right, rear and below.

FOUNDATION

150

500

Service space

Over 10

FREE

Over 150Over 1000

OUTLINES AND DIMENSIONS

PUMY-P100/125/140VHMB(-BS) PUMY-P100/125/140VHMBR1(-BS) PUMY-P100/125/140VHMBR2(-BS) PUMY-P100/125/140YHMB(-BS) PUMY-P100/125/140YHMBR1(-BS) PUMY-P100/125/140YHMBR2(-BS)

Unit : mm

WIRING DIAGRAM

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

63H

TH7 TH6 TH3 TH4

(WHT)

21S4

RED

BLU

GRN/YLW

CNF1

CNF2

CNDC (PNK)

X504

21S4

(GRN)

TH8

63HS

(WHT)

TRANS

t°

WHT

RED

TH7/6 (RED)

X503

141

SV2

(BLU)

P. B .

(WHT) 6 1

(WHT)

7 1

2 1

TH3

(WHT)

SV1

CNAF

CN2

CN3

(WHT)

CN5

(RED)

CN4 (WHT) TABN

TABP

SYMBOL NAME

TB1 Terminal Block <Power Supply> TB3 Terminal Block <Communication Line> TB7 Terminal Block < MC Motor For Compressor MF1,MF2 Fan Motor 21S4 Solenoid Valve<Four-Way Valve> 63H High Pressure Switch 63L Low Pressure Switch 63HS High Pressure Sensor SV1 Solenoid Valve<Bypass valve> TH3 TH4 Thermistor<Discharge/Compressor> TH6 Thermistor<Low Pressure Saturated> TH7 TH8 DCL ACTM CE Main Smoothing Capacitor P.B. Power Circuit Board

N.F. Noise Filter Circuit Board

C.B.

M-NET P.B.

Thermistor<Outdoor Pipe>

Thermistor<Outdoor> Thermistor<Heatsink> Reactor

Active Filter Module

Connection Terminal<U/V/W-Phase>

TABU/V/W TABS/T

Connection Terminal<L/N-Phase> Connection Terminal<DC Voltage>

TABP1/P2/P

Connection Terminal<DC Voltage>

TABN1/N2/N

Diode Bridge

DS2,DS3

Power Module

IPM

Connection Terminal<L-Phase>

LI/LO NI/NO

Connection Terminal<N-Phase> Connection Terminal<Ground>

EI,E2 52C

52C Relay Controller Circuit Board

SW1

Switch<Display Selection>

SW2

Switch<Function Selection>

SW3

Switch<Test Run>

SW4

Switch<Model Selection>

SW5

Switch<Function Selection>

SW6

Switch<Function Selection>

SW7

Switch<Function Selection>

SW8

Switch<Function Selection>

SWU1

Switch<Unit Address Selection, 1st digit>

SWU2

Switch<Unit Address Selection, 2nd digit>

CNLVB

Connector<To N.F. Board CN52C> (Symbol of Board is CNLVB)

Connector<Connection For Option>

CN3D

Connector<Connection For Option>

CN3S

Connector<Connection For Option>

CN3N

Connector<Connection For Option>

CN51

Connector<Connection For Option>

LED1,LED2

F1,F2 X501~505

TP1

LED<Operation Inspection Display>

LED3

LED<Power Supply to Main Microprocessor> Fuse<T6,3AL250V> Relay M-NET Power Circuit Board ConnectionTerminal<Ground>

Centralized Control Line>

MULTI. B.

MF1

MF2

X505

52C

(BLK)

TB3

RED

TO INDOOR UNIT CONNECTING WIRES DC 30V(Non-polar)

TB7

YLW

FOR CENTRALIZED CONTROL DC 30V(Non-polar)

POWER SUPPLY ~/N 230V 50Hz

TB1

Cautions when Servicing

•

WARNING: When the main supply is turned off, the voltage [340 V] in the main capacitor will drop to 20 V in approx. 2 minutes (input voltage:

230 V). When servicing, make sure that LED1, LED2 on the outdoor circuit board goes out, and then wait for at least 1 minute.

• Components other than the outdoor board may be faulty: Check and take corrective action, referring to the service manual. Do not replace the outdoor board without checking.

NOTES:

• Refer to the wiring diagrams of the indoor units for details on wiring of each indoor unit. Self-diagnosis function The indoor and outdoor units can be diagnosed automatically using the self-diagnosis switch (SW1) and LED1, LED2 (LED indication) found on the multi-controller of the outdoor unit. LED indication : Set all contacts of SW1 to OFF.

• During normal operation The LED indicates the drive state of the controller in the outdoor unit.

Bit

Indication

• When fault requiring inspection has occurred, the LED alternately indicates the inspection code and the location of the unit in which the fault has occurred.

Compressor operated

52C321S44SV15(SV2)

—

63L

t° t° t°

t°

2112

TH4

(WHT)

113

63L

(RED)

63H

(YLW)

X501

X502

SV1

12 12

(WHT)

TABP2

RED

—

BLK

IPM

RED

(WHT)

TABV

TAB U

RED

WHT

DCL

ACTM

Always lit

L1 L2

CN3D

(WHT)

131313

LED3

CNAC (RED)

CNDC

(PIN)

TAB W

BLK

CN3S

CN3N

(RED)

(BLU)

CN51

(WHT)

CN2

(WHT)

CNS2

CNS1

(YLW)

(RED)

DS3

DS2

TAB N1

BLK

TAB N2

WHT

RED

N1 N2

WHT

is the switch position.

CNLVB

(RED)

TABT

TABS

TABP1

CN4

(WHT)

SWU2 SWU1

CN41

(WHT)

BLU

WHT

RED

CN40

(WHT)

SW5

LED1

(RED)

CNAC2

(WHT)

CNAC1

SW6

SW7SW3SW4

LED2

CN102 (WHT)

L I

RED

SW2SW8SW1

WHT

52C

N I

BLU

+1 MODEL SELECT 1:ON 0:OFF

MODELS

PUMY-P100VHMB PUMY-P125VHMB PUMY-P140VHMB

[Example] When the compressor and SV1 are turned on during cooling operation.

12345678

CN2

(WHT)

CN1

(WHT)

N. F.

BLU

(BLK)

CN52C

CN5

(RED)

E I

123456 010010

010001 010011

M-NET P.B.

TP1

BLK

SW4

BLK

PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

63H

SYMBOL NAME

TB1 TB3 TB7 MC Motor For Compressor MF1,MF2 Fan Motor 21S4 Solenoid Valve<Four-Way Valve> 63H High Pressure Switch 63L Low Pressure Switch 63HS SV1 Solenoid Valve<Bypass Valve> TH3 TH4 Thermistor<Discharge/Compressor> TH6 Thermistor<Low Pressure Saturated> TH7 Thermistor<Outdoor> RS Rush Current Protect Resistor ACL1~ACL4 CB1,CB2 Main Smoothing Capacitor CK Capacitor P.B. Power Circuit Board

N.F.

CONV.B.

C.B. Controller Circuit Board

M-NET P.B.

Terminal Block <Power Supply> Terminal Block <Communication Line> Terminal Block <Centralized Control Line>

High Pressure Sensor

Thermistor<Outdoor Pipe>

Reactor

TB-U/V/W

Connection Terminal<U/V/W-Phase>

TB-L1/L2/L3

Connection Terminal<L1/L2/L3-Power Supply>

Connection Terminal

TB-P2

Connection Terminal

TB-C1

Connection Terminal

TB-N1 X52A

Relay Noise Filter Circuit Board

LO1/LO2/LO3/NO

Connection Terminal<L1/L2/L3-Power Supply>

LI1/LI2/LI3/NI

Connection Terminal<L1/L2/L3-Power Supply>

GD1,GD3

Connection Terminal<Ground> Converter Circuit Board

L1-A1/IN

Connection Terminal<L1-Power Supply>

L1-A2/OU

Connection Terminal<L1-Power Supply>

L2-A2/OU

Connection Terminal<L2-Power Supply>

L3-A2/OU

Connection Terminal<L3-Power Supply>

N-IN

Connection Terminal

CK-OU

Connection Terminal

SW1

Switch<Display Selection>

SW2

Switch<Function Selection>

SW3

Switch<Test Run>

SW4

Switch<Model Selection>

SW5

Switch<Function Selection>

SW6

Switch<Function Selection>

SW7

Switch<Function Selection>

SW8

Switch<Function Selection>

SWU1

Switch<Unit Address Selection, 1st digit>

SWU2

Switch<Unit Address Selection, 2nd digit>

Connector<Connection For Option>

CN3D

Connector<Connection For Option>

CN3S

Connector<Connection For Option>

CN3N

Connector<Connection For Option>

CN51

Connector<Connection For Option>

LED1,LED2

LED<Operation Inspection Display>

LED3

LED<Power Supply to Main Microprocessor>

F1,F2

Fuse<T6.3AL250V>

X501~X505

Relay M-NET Power Circuit Board

TP1

Connection Terminal<Ground>

+1 MODEL SELECT 1:ON 0:OFF

MODELS

PUMY-P100YHMB PUMY-P125YHMB PUMY-P140YHMB

C. B.

MF1

MF2

X505

52C

(BLK)

TB3

RED

TO INDOOR UNIT

CONNECTING WIRES

DC 30V(Non-polar)

TB7

YLW

FOR CENTRALIZED

CONTROL

DC 30V(Non-polar)

TB1

RED

WHT

BLK

BLU

POWER SUPPLY 3N~ 400V 50Hz

GRN/YLW

SW4 123456 110010 110001 110011

CNF1 (WHT)

CNF2 (WHT)

21S4

CNDC (PNK)

X504

(GRN)

21S4

N. F.

LI1

LI2

LI3

63HS

(WHT)

TRANS

TH7 TH6 TH3 TH4

141 TH7/6

TH3

(RED)

(WHT)

X503

SV2

(BLU)

SV1

P. B.

RED

BLK

Cautions when Servicing

• WARNING: When the main supply is turned off, the voltage [570 V] in the main capacitor will drop to 20 V in approx. 5 minutes

(input voltage: 400 V). When servicing, make sure that LED1 and LED2 on the outdoor circuit board goes out, and then wait for at least 5 minute.

• Components other than the outdoor board may be faulty: Check and take corrective action, referring to the service manual.

Do not replace the outdoor board without checking.

NOTES:

• Refer to the wiring diagrams of the indoor units for details on wiring of each indoor unit. Self-diagnosis function The indoor and outdoor units can be diagnosed automatically using the self-diagnosis switch (SW1), LED1 and LED2 (LED indication) found on the multi-controller of the outdoor unit. LED indication : Set all contacts of SW1 to OFF.

• During normal operation The LED indicates the drive state of the controller in the outdoor unit.

Bit

Indication

• When fault requiring inspection has occurred, the LED alternately indicates the inspection code and the location of the unit in which the fault has occurred.

Compressor operated

52C321S44SV15(SV2)6—

—

63L

t° t° t° t

2112

TH4

(WHT)

113

(RED)

63H

(YLW)

X502

SV1

12 12

(WHT)

13 CN7

(WHT)

CN4

(WHT)

CN5

(RED)

X52A

CNAC1

13 13

(WHT)

63L

X501

(WHT)

CN2

TB-P2

CN3D

CN3S

(WHT)

(RED)

131313

LED3

CNS1 (RED)

CNAC (RED)

CB1

TB-C1

CB2

CN3N

(BLU)

CN2

(WHT)

CNS2 (YLW)

CN51

(WHT)

TB-V

TB-L3

TB-L2

TB-L1

TB-W

TB-U

TB-N1

CNCT (RED)

CNAC1

(WHT)

GD3GD1

BLK

CNDC

(PNK)

WHT

[Example] When the compressor and SV1 are turned on during cooling operation.

12345678

Always lit

SWU2 SWU1

CN4

(WHT)

CN41

(WHT)

BLK WHT RED

CNL

(BLU)

WHT

is the switch position.

SW5

LED1

CN40 (WHT)

BLK

CNAC2

(RED)

LO1

LO2

LO3

SW6

SW2SW8SW1

SW7SW3SW4

LED2

CN102 (WHT)

M-NET P.B.

WHT

BLK

L3-A2

L3-OU

Conv.B.

CN7

(WHT)

L1-A1

RED

WHT

BLK

BLU

ACL4

WHT

L2-OU

L1-IN

BLU

(WHT)

L2-A2

CN2

(WHT)

CN1

RED

N-IN

TP1

L1-OU

ACL1

ACL2

ACL3

BLK

RED

L1-A2

CK-OU

BLK

NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION

8-1. TRANSMISSION SYSTEM SETUP

005

Remote

004

003

Remote

105

controller

Indoor unitIndoor unitIndoor unitIndoor unitIndoor unit

006

007

Address SWAddress SWAddress SWAddress SWAddress SW

157

Remote

controller

107

Remote

controller

Address SWAddress SW

008

Piping

For remote

051

Outdoor unit

Transmission wire

controller

Indoor unit Indoor unit Indoor unit Indoor unit Indoor unit



002

001

Address SW Address SW Address SW Address SW Address SW



connected to each refrigerant

system (outdoor and indoor).

 A transmission wire must be

 Set addresses:

102 104 154

Remote

controller

101

1111

Address SW Address SW Address SW Address SW Address SW

Remote

controller

Outdoor unit ..............051-100

Indoor unit .................001-050

Remote controller .....101-200

The address automatically become

"100" if it is set as "01~50".

 PUMY has no 100ths digit switch.

For remote

056

Outdoor unit

controller

009

010

For centralized

management

For centralized

management

8-2. REFRIGERANT SYSTEM DIAGRAM PUMY-P100VHMB(-BS) PUMY-P125VHMB(-BS) PUMY-P140VHMB(-BS)

PUMY-P100VHMBR1(-BS) PUMY-P125VHMBR1(-BS) PUMY-P140VHMBR1(-BS) PUMY-P100YHMB(-BS) PUMY-P125YHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P125YHMBR1(-BS) PUMY-P140YHMBR1(-BS)

Unit: mm <inch>

Service port

Refrigerant Gas pipe

<5/8>

Thermistor<Saturation temperature of suction pressure> (TH6)

Check valve<Low pressure>

Refrigerant Liquid pipe

<3/8>

Service port

Ball valve

Accumulator

Stop valve

Strainer

4-way valve

Solenoid valve (SV1)

Capillary tube

Strainer

Low pressure switch(63L)

Pressure sensor (63HS)

Check valve <High pressure>

Oil separator

Strainer

Compressor

High pressure switch (63H)

Discharge thermistor (TH4)

Heatsink thermistor (TH8)

Refrigerant flow in cooling Refrigerant flow in heating

Thermistor (TH7) (Outdoor temperature)

Distributor

Thermistor (TH3)

(Pipe temperature)

PUMY-P100VHMBR2(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMBR2(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMBR2(-BS)

Unit: mm <inch>

Service port

Refrigerant Gas pipe

<5/8>

Check valve<Low pressure> Thermistor<Saturation temperature of suction pressure> (TH6)

Ball valve

Accumulator

Strainer

4-way valve

Solenoid valve (SV1)

Capillary tube

Strainer

Low pressure switch(63L)

Check valve <High pressure>

Pressure sensor (63HS)

High pressure switch (63H)

Oil separator

Strainer

Compressor thermistor (TH4)

Compressor

Thermistor (TH7) (Outdoor temperature)

Distributor

Thermistor (TH3)

(Pipe temperature)

Stop valve

Refrigerant Liquid pipe

<3/8>

Service port

Strainer

Capillary tube for oil separator : :2.5 % :0.8 % L1000 Refrigerant piping specifications <dimensions of flared connector>

Capacity

Indoor unit

Outdoor unit

Item

P15, P20, P25, P32, P40, P50

P63, P80, P100

P125, P140

P100, P125, P140

Liquid piping

:6.35 <1/4>

:9.52 <3/8>

Heatsink thermistor (TH8)

Refrigerant flow in cooling Refrigerant flow in heating

Gas piping

:12.7 <1/2>

:15.88 <5/8>

8-3. SYSTEM CONTROL

8-3-1. Example for the System

• Example for wiring control cables, wiring method and address setting, permissible lengths, and the prohibited items are listed in the standard system with detailed explanation. The explanation for the system in this section : Use 1 single outdoor unit and multiple outdoor units for M-NET remote control

system. Use 1 single outdoor unit and multiple indoor units in the multiple outdoor units for the M-NET remote control system.

A. Example of a M-NET remote controller system (address setting is necessary.)

Example of wiring control cables Wiring Method and Address Setting

1. Standard operation

TB7

TB3

M1M2

SAB

• 1 remote controller for each indoor unit.

• There is no need for setting the 100 position on the remote controller.

2. Operation using 2 remote controllers

TB3

TB7

M1M2

SAB

AB AB AB AB

• Using 2 remote controllers

for each indoor unit.

101

(Main)

TB5

M1M2

101

TB5

M1M2

TB15

S12

TB15

S12

151

(Sub)

TB5

TB15

M1M2

S12

102

TB5

TB15

M1M2

S12

102

(Main)

152

(Sub)

a. Use feed wiring to connect terminals M1 and M2 on

transmission cable block (TB3) for the outdoor unit (OC) to terminals M1 and M2 on the transmission cable block (TB5) of each indoor unit (IC). Use nonpolarized 2 wire.

b. Connect terminals M1 and M2 on transmission cable

terminal block (TB5) for each indoor unit with the terminal block (TB6) for the remote controller (RC).

c. Set the address setting switch (on outdoor unit P.C.B)

as shown below.

Unit

Indoor unit (IC)

Outdoor unit

(OC)

Remote

controller (RC)

Range

001 to 050

051 to 100

101 to 150

Setting Method

— Use the smallest address of all the indoor unit plus 50. Indoor unit address plus

100.

a. Same as above. b. Same as above. c. Set address switch (on outdoor unit P.C.B) as

shown below.

Unit

Indoor Unit (IC)

Outdoor unit

(OC)

Main Remote

Controller (RC)

Sub Remote

Controller (RC)

Range

001 to 050

051 to 100

101 to 150

151 to 200

Setting Method

— Use the smallest address of all the indoor units plus 50. Indoor unit address plus

100. Indoor unit address plus

150.

3. Group operation

TB3

TB7

M1M2

SAB

• Multiple indoor units operated

TB5

M1M2

101

IC(Main)

S12

TB15

together by 1 remote controller

Combinations of 1through 3 above are possible.

TB5

M1M2

IC(Sub)

TB15

S122

a. Same as above. b. Connect terminals M1 and M2 on transmission cable

terminal block (TB5) of the IC main unit with the most recent address within the same indoor unit (IC) group to terminal block (TB6) on the remote controller.

c. Set the address setting switch (on outdoor unit P.C.B)

as shown below.

Unit

IC (Main)

IC (Sub)

Outdoor Unit

Main Remote

Controller

Sub Remote

Controller

Range

001 to 050

051 to 100

101 to 150

151 to 200

Use the smallest address within the same group of indoor units. Use an address, other than that of the IC (Main) from among the units within the same group of indoor units. This must be in sequence with the IC (Main). Use the smallest address of all the indoor units plus 50. Set at an IC (Main) address within the same group plus 100.

Set at an IC (Main) address within the same group plus 150.

Setting Method

d. Use the indoor unit (IC) within the group with the

most functions as the IC (Main) unit.

• Name, Symbol and the Maximum Remote controller Units for Connection Name Symbol Maximum units for connection

Outdoor unit OC —

Indoor unit IC 1 OC unit can be connected to 1~8 (P100)/1~10 (P125)/1~12 (P140) IC units

M-NET remote

controller

Maximum 2 RC for 1 indoor unit, Maximum 12 RC for 1 OC

Permissible Lengths Prohibited items

Longest transmission cable length (1.25 mm²) L

1 + L2, L2 + L3, L3 + L1 [ 200m

Remote controller cable length

1. If 0.5 to 1.25 mm²

1, R2 [10m

2. If the length exceeds 10 meters, the exceeding section should be

1.25 mm² and that section should be a value within the total extension length of the transmission cable and maximum transmission cable length. (L

Same as above

•

M-NET remote controller (RC) and MA remote controller (MA) cannot be used together.

• Do not connect anything with TB15 of indoor unit (IC).

TB3

M1M2

TB7

SAB

TB3

TB7

SAB

TB5

TB15

M1M2

S12

TB5

M1M2

101

TB15

S12

TB5

M1M2

TB15

S12

TB5

M1M2

TB15

S12

TB15

• Use the indoor unit (IC) address plus 150 as the sub remote controller address. In this case, it should be 152.

• 3 or more remote con-

AB AB AB AB AB

101

(Main)

151

(Sub)

102

(Main)

103

(Sub)

104

troller (RC) cannot be connected to 1 indoor unit.

Same as above

TB3

M1M2

TB7

SAB

IC(Main)

TB5

TB15

S12

M1M2

TB5

M1M2

IC(Sub)

S122

TB15

• The remote controller address is the indoor unit main address plus

100. In this case, it should be 101.

102

B. Example of a group operation system with 2 or more outdoor units and a M-NET remote controller.

(Address settings are necessary.)

Examples of Transmission Cable Wiring

L6L7

 : Group 1  : Group 3  : Group 5  : Shielded Wire  : Sub Remote Controller

( ): Address

(51)

TB3

M1M2S

M1 M2 S

TB7



(53)

TB3

M1M2 S

M1 M2 S

TB7

Power Supply

Unit

M1M2S

G-50A

M1M2S



(01)

TB5

M1 M2 S

AB AB AB

(101)

(03)

TB5

M1 M2 S

(02)

TB5

M1 M2 S

(04)

TB5

M1 M2 S

(104)





TB5

M1 M2 S

(06)

(05)

TB5

M1 M2 S

(105)

(155)



(07)

TB5

M1 M2 S

a. Always use shielded wire when making connections between the outdoor unit (OC) and the indoor unit (IC), as well

for all OC-OC, and IC-IC wiring intervals.

b. Use feed wiring to connect terminals M1 and M2 and the ground terminal on the transmission cable terminal block (TB3)

of each outdoor unit (OC) to terminals M1 and M2 on the terminal S on the transmission cable block of the indoor unit (IC).

c. Connect terminals M1 and M2 on the transmission cable terminal block of the indoor unit (IC) that has the most

recent address within the same group to the terminal block on the remote controller (RC).

d. Connect together terminals M1, M2 and terminal S on the terminal block for central control (TB7) for the outdoor unit

(OC). e. DO NOT change the jumper connector CN41 on MULTI controller board. f. The earth processing of S terminal for the centralized control terminal block (TB7) is unnecessary. Connect the termi-

nal S on the power supply unit with the earth. g. Set the address setting switch as follows.

Unit Range Setting Method

IC (Main) 01 to 00

IC (Sub) 01 to 50

Wiring Method Address Settings

Outdoor Unit 51 to 100

Main Remote Controller 101 to 150

Sub Remote Controller 151 to 200

MA Remote Controller —

Use the smallest address within the same group of indoor units. Use an address, other than the IC (Main) in the same group of indoor units. This must be in sequence with the IC (Main). Use the smallest address of all the indoor units plus 50.

*The address automatically becomes “100” if it is set as “01 - 50”. Set at an IC (Main) address within the same group plus 100.

Set at an IC (Main) address within the same group plus 150.

Unnecessary address setting (Necessary main/ sub setting)

h. The group setting operations among the multiple indoor units is done by the remote controller (RC) after the electrical

power has been turned on.

• Name, Symbol, and the Maximum Units for Connection

• Longest length via outdoor units : L1+L2+L3+L4, L1+L2+L3+L5, L1+L2+L6+L7 [ 500 meters (1.25mm²)

• Longest transmission cable length : L

• Remote controller cable length : R

1, L3+L4, L3+L5, L6, L2+L6, L7 [ 200 meters (1.25mm²)

1,R2, R2+R3, R4 [ 10 meters (0.5 to 1.25mm²)

If the length exceeds 10 meters, use a 1.25 mm² shielded wire. The length of this sec-

8) should be included in the calculation of the maximum length and overall length.

tion (L

Permissible Length

Prohibited items

 : Group 1  : Group 3  : Group 5  : Shielded Wire  : Sub Remote Controller

( ): Address

(51)

TB3

M1M2S

M1 M2 S

TB7



(53)

TB3

M1M2 S

M1 M2 S

TB7

Power Supply

Unit

M1M2S

G-50A

M1M2S



(01)

TB5

M1 M2 S

AB AB AB

(101)

(03)

TB5

M1 M2 S

TB5

M1 M2 S

TB5

M1 M2 S

(104)

(02)

(04)

TB5

M1 M2 S

(105)

TB5

M1 M2 S

(05)

(155)

(07)







(06)

TB5

M1 M2 S

• Never connect together the terminal blocks (TB5) for transmission wires for indoor units (IC) that have been connected to different outdoor units (OC).

• Set all addresses to ensure that they are not overlapped.

• M-NET remote controller and MA remote controller cannot be connected with the indoor unit of the same group wiring together.

C. Example of a MA remote controller system (address setting is not necessary.) NOTE : In the case of same group operation, need to set the address that is only main indoor unit.

Example of wiring control cables Wiring Method and Address Setting

1. Standard operation

a. Use feed wiring to connect terminals M1 and M2

on transmission cable block (TB3) for the outdoor

TB3

M1M2

TB7

M1M2

1 L2

TB5

M1M2

TB15

S12

TB5

M1M2

TB15

S12

unit (OC) to terminals M1 and M2 on the transmission cable block (TB5) of each indoor unit (IC). Use non-polarized 2 wire.

b. Connect terminals 1 and 2 on transmission cable

terminal block (TB15) for each indoor unit with the terminal block for the MA remote controller (MA).

• 1 remote controller for each indoor unit.

2. Operation using two remote controllers

TB3

TB7

M1M2

SM1M2

• Using 2 remote controllers

TB5

TB15

M1M2

S12

for each indoor unit.

3. Group operation

TB3

M1M2

TB7

M1M2

TB5

M1M2

S12

TB5

M1M2

AB AB

TB15

S12

MA MA

TB5

M1M2

MAMA

TB15

S12

a. The same as above. b. The same as above. c. In the case of using 2 remote controllers, connect

terminals 1 and 2 on transmission cable terminal block (TB15) for each indoor unit with the terminal block for 2 remote controllers.

· Set the sub remote controller position for one of MA remote controller’s main switch.

Refer to the installation manual of MA remote con-

troller.

a. The same as above. b. The same as above. c. Connect terminals 1 and 2 on transmission cable

terminal block (TB15) of each indoor unit, which is doing group operation with the terminal block the MA remote controller. Use non-polarized 2 wire.

d. In the case of same group operation, need to set the

address that is only main indoor unit. Please set the smallest address within number 01-50 of the indoor unit with the most functions in the same group.

• Multiple indoor units operated

together by 1 remote controller.

Combinations of 1 through 3 above are possible.

Permissible Lengths Prohibited items

Longest transmission cable length L

1 + L2 [ 200m (1.25 mm²)

MA remote controller cable length

1, R2 [ 200m (0.3 ~ 1.25 mm²)

Longest transmission cable length The same as above. MA remote controller cable length

3 +R4, R5 +R6 [ 200m

(0.3 ~ 1.25 mm²)

TB3

M1M2

TB7

M1M2

The MA remote controller and the M-NET remote controller cannot be used together with the indoor unit of the same group.

TB5

TB15

M1M2

S12

TB5

M1M2

TB15

S12

MAMA

3 MA remote controller or more cannot be connected with the indoor unit of the same group.

Longest transmission cable length The same as above. MA remote controller cable length

7 +R8 [ 200m (0.3 ~ 1.25 mm²)

TB3

M1M2

TB3

M1M2

TB7

M1M2

TB7

M1M2

TB5

TB15

M1M2

AB AB

S12

AB AB

TB5

M1M2

TB15

S12

MA MAMA

The second MA remote controller is connected with the terminal block (TB15) for the MA remote controller of the same indoor unit (IC) as the first remote control.

TB5

TB15

M1M2

S12

TB5

M1M2

TB15

S12

D. Example of a group operation with 2 or more outdoor units and a MA remote controller.

(Address settings are necessary.)

(51)

M1 M2 S

TB7

Examples of Transmission Cable Wiring

L6L7



(53)

M1 M2 S

TB7

Power Supply

Unit

M1M2

G-50A

M1M2

 : Group 1  : Group 3  : Group 5  : Shielded Wire  : Sub Remote Controller

( ): Address

M1M2S

TB3

M1M2S

(05)

TB15

ABABAB

MAMAMA

(07)

TB15



(06)

TB15

TB5

M1 M2 S





(01)

TB5 TB15

M1 M2 1 2S

(03)

TB15

TB5

M1 M2 S

2 2

(02)

TB15

TB5

M1 M2 S

TB5

M1 M2 S

(04)

TB5

M1 M2 S

TB15 12

TB5

M1 M2 S



a. Always use shielded wire when making connections between the outdoor unit (OC) and the indoor unit (IC), as well

for all OC-OC, and IC-IC wiring intervals.

b. Use feed wiring to connect terminals M1 and M2 and the ground terminal on the transmission cable terminal block (TB3)

of each outdoor unit (OC) to terminals M1 and M2 on the terminal S on the transmission cable block of the indoor unit (IC).

c. Connect terminals M1 and M2 on the transmission cable terminal block of the indoor unit (IC) that has the most

recent address within the same group to the terminal block on the remote controller (RC).

d. Connect together terminals M1, M2 and terminal S on the terminal block for central control (TB7) for the outdoor unit

(OC). e. DO NOT change the jumper connector CN41 on MULTI controller board. f. The earth processing of S terminal for the centralized control terminal block (TB7) is unnecessary. Connect the termi-

nal S on the power supply unit with the earth. g. Set the address setting switch as follows.

Unit Range Setting Method

IC (Main) 01 to 00

IC (Sub) 01 to 50

Wiring Method Address Settings

Outdoor Unit 51 to 100

Main Remote Controller 101 to 150

Sub Remote Controller 151 to 200

MA Remote Controller —

*The address automatically becomes “100” if it is set as “01 - 50”. Set at an IC (Main) address within the same group plus 100.

Set at an IC (Main) address within the same group plus 150.

Unnecessary address setting (Necessary main/ sub setting)

h. The group setting operations among the multiple indoor units is done by the remote controller (RC) after the electrical

power has been turned on.

• Name, Symbol, and the Maximum Units for Connection

Longest length via outdoor unit (M-NET cable): L1+L2+L3+L4 and L1+L2+L6+L7  500 m (1.25 A or more) Longest transmission cable length (M-NET cable): L1 and L3+L4 and L6 and L2+L6 and L7 200 m (1.25 A or more) Remote controller cable length: m1 and m1+m2+m3 and m1+m2+m3+m4 200 m (0.3 to 1.25 A)

Permissible LengthProhibited items

(51)

TB3

M1M2S

M1 M2 S

TB7



(53)

TB3

M1M2S

M1 M2 S

TB7

Power Supply

Unit

M1M2

G-50A

M1M2

 : Group 1  : Group 3  : Group 5  : Shielded Wire  : Sub Remote Controller

( ): Address

(01)

TB5 TB15

M1 M2 1 2S

(03)

TB5

M1 M2 S

TB15

(05)

TB15

ABABAB



(06)

TB15

TB5

M1 M2 S



(02)

TB15

TB5

M1 M2 S

TB5

M1 M2 S

MAMAMA

TB5

M1 M2 S

(04)

(07)

TB15

TB5

M1 M2 S

TB15





• Never connect together the terminal blocks (TB5) for transmission wires for indoor units (IC) that have been connected to different outdoor units (OC).

• M-NET remote controller and MA remote controller cannot be connected with the indoor unit of the same group wiring together.

9 TROUBLESHOOTING

9-1. CHECK POINTS FOR TEST RUN

9-1-1. Procedures of test run

(1) Before a test run, make sure that the following work is completed.

• Installation related : Make sure that the panel of cassette type and electrical wiring are done. Otherwise electrical functions like auto vane will not operate normally.

• Piping related :

Perform leakage test of refrigerant and drain piping. Make sure that all joints are perfectly insulated. Check stop valves on both liquid and gas side for full open.

• Electrical wiring related :

Check ground wire, transmission cable, remote controller cable, and power supply cable for secure connection. Make sure that all switch settings of address or adjustments for special specification systems are correctly settled.

(2) Safety check :

With the insulation tester of 500V, inspect the insulation resistance. Do not touch the transmission cable and remote controller cable with the tester. The resistance should be over 1.0 M". Do not proceed inspection if the resistance is under 1.0 M". Inspect between the outdoor unit power supply terminal block and ground first, metallic parts like refrigerant pipes or the electrical box next, then inspect all electrical wiring of outdoor unit, indoor unit, and all linked equipment .

(3) Before operation :

a) Turn the power supply switch of the outdoor unit to on for compressor protection. For a test run, wait at least 12 hours

from this point.

b) Register control systems into remote controller(s). Never touch the on/off switch of the remote controller(s). Refer

to “ 9-1-2. Special Function Operation and Settings (for M-NET Remote Controller)” as for settings. In MA remote controller(s), this registration is unnecessary.

(4) More than 12 hours later from power supply to the outdoor unit, turn all power switch to on for the test run. Perform test run

according to the “Operation procedure” table of the bottom of this page. While test running, make test run reports .

(5) When you deliver the unit after the test run, instruct the end user for proper usage of the system using owners’ manual and

the test run report you made to certificate normal operation. If abnormalities are detected during test run, refer to “9-1-3 Countermeasures for Error During Test Run”. As for DIP switch setting of outdoor unit, refer to “9-5. INTERNAL SWITCH FUNCTION TABLE”.

(M-NET Remote controller)

Check code indicator (see NOTE 1) Test run remaining time indicator (see NOTE 3)

Indoor unit liquid pipe temperature indicator

(see NOTE 4)

TEST RUN indicator

ON/OFF LED (Lights up in operation) ON/OFF button 

AIR DIRECTION button 

TEST RUN button 

Display panel

(Cooling/Heating) OPERATION SWITCH button ,

TEMP.

TIMER SET

1Hr.

°C

TEST RUN

ON/OFF

FILTER

CHECK TEST

LOUVER button 

Control panel

FAN SPEED button 

Operation procedure

Turn on the main power supply of all units at least 12 hours before test run. ”HO” appears on display panel for 3 min.

12 hours later, press TEST RUN button twice to perform test run. “TEST RUN “ appears on display panel.

Press OPERATION SWITCH button to make sure that air blows out.

Select Cooling (or Heating) by OPERATION SWITCH button to make sure that cool (or warm) air blows out.

Press Fan speed button to make sure that fan speed is changed by the button.

Press AIR DIRECTION button or LOUVER button to make sure that air direction is adjustable (horizontal, downward, upward, and each angle).

Check outdoor fans for normal operation.

Check interlocked devices (like ventilator) for normal operation, if any. This is the end of test run operation.

Press ON/OFF button to stop and cancel test run.

NOTE 1 : If error code appears on remote controller or remote controller malfunctions, refer to “ 9-1-3 Countermeasures for Error During Run”. NOTE 2 : NOTE 3 : During test run, the indoor liquid pipe temperature is displayed on remote controller instead of room temperature. NOTE 4 :

During test run operation, 2-hour off timer activates automatically and remaining time is on remote controller and test run stops 2 hours later.

Depending on a model, “This function is not available” appears when air direction button is pressed. However, this is not malfunction

9-1-2. Special Function Operation and Settings (for M-NET Remote Controller)

• It is necessary to perform “group settings” and “paired settings” at making group settings of different refrigerant systems (multiple outdoor unit). (A) Group settings: Enter the indoor unit controlled by the remote controller, check the content of entries, and clear entries,

etc.

(B) Paired settings: Used to set the linked operation of a Lossnay unit.

(1) Entering address: Follow the steps below to enter the addresses of the indoor unit using the remote controller.

a) Group settings

• Turning off the remote controller: Press the ON/OFF button to stop operation (the indicator light will go off).

• Changing to indoor unit address display mode: If the FILTER and k buttons on the remote controller are pressed simultaneously and held for 2 seconds, the display shown in Figure 1 will appear.

• Changing address: Press the temperature adjustment be entered.

• Entering the displayed address: Press the TEST RUN button to enter the indoor unit with the displayed address. The type of the unit will be displayed as shown in Figure 2 if entry is completed normally. If a selected indoor unit does not exist, an error signal will be displayed as shown in Figure 3. When this happens, check whether the indoor unit actually exists and perform entry again.

• Returning to the normal mode after completing entry: Press the FILTER and k buttons simultaneously and hold for 2 seconds to return to the normal mode.

buttons to change the displayed address to the address to

Figure 1. (A) Group setting display

b) Paired Settings

• Turn off the remote controller: Press the remote controller’s ON/OFF button to turn it off (the indicator light will go off).

• Put in indoor unit address display mode: Press the FILTER and k buttons on the remote controller simultaneously and hold for 2 seconds.

*The above steps are the same as when making group settings (A).

• Changing to the linked operation unit address display state: The display shown in Figure 4 will appear when the button on the remote control is pressed.

• Displaying the address of the Lossnay unit and linked indoor unit: In this situation, the indoor unit number will be the lowest address of the group. The Lossnay unit will not operate if this setting is incorrect.

* If the temperature adjustment buttons are pressed, the address may be changed to the indoor unit that are to be

linked.

* If the time setting buttons are pressed, the address of the linked units may be changed to the address where it is

desired to enter the Lossnay .

• Linking the Lossnay and the indoor unit: The display shown in Figure 5 will appear when the TEST RUN button is pressed. The indoor unit whose address is displayed and the Lossnay unit with a linked address will operate in a linked manner.

* If it is desired to display the address of the Lossnay in the indoor unit address, display the indoor unit address in the linked

unit address, and the above content will also be recorded.

* Apart from the indoor unit with the lowest address in the group, display and enter the addresses of the other indoor unit that

are to be linked with the Lossnay unit.

• Returning to the normal mode after completing entry: Press the FILTER and k buttons on the remote controller simultaneously and hold for 2 seconds to return to the normal mode.

Figure 2. Normal completion of entry

Figure 3. Entry error signal

Flashing “88” indicates entry error.Type of unit is displayed.

Figure 4. (B) Making paired settings

The addresses of indoor unit and linked units are displayed simultaneously.

Figure 5. Completing normal entry

(alternating display)

These alternating IC or LC displays will appear when entry is completed normally.

A flashing “88” will appear if there is a problem with the entry (indicating that the unit does not exist).

(2) Address check: Refer to section (1) regarding address entry.

a) In making group settings:

• Turn off the remote controller: Press the remote controller's ON/OFF button to stop operation (the indicator light will go off).

• Locate the indoor unit address display mode: Press the FILTER and k buttons on the remote controller simultaneously

and hold for 2 seconds.

• Display indoor unit address: The entered indoor units address and type will be displayed each time the button is pressed.

* When 1 entry is made, only 1 address will be displayed no matter how many times the w button is pressed.

• Returning to the normal mode after completing check: Simultaneously press the FILTER and k buttons on the remote

controller and hold for 2 seconds to return to the normal mode.

b) In making paired settings:

• Turn off the remote controller: Press the remote controller's ON/OFF button to stop operation (the indicator light will go off).

• Put in indoor unit address display mode: Press the FILTER and k buttons on the remote controller simultaneously and

hold for 2 seconds.

• Changing to the linked operation unit address display state: Press the a button on the remote control.

• Displaying the address of the indoor unit to be checked: Change the address to that of the indoor unit to be checked by pressing the temperature adjustment buttons

• Displaying the address of the linked Lossnay unit: Press the w button to display the addresses of the linked Lossnay and indoor unit in alternation.

• Displaying the addresses of other entered units: The addresses of the other entered units will be displayed in alternating fashion after resting the w button again.

• Returning to the normal mode after completing the check: Simultaneously press the FILTER and k buttons on the remote controller and hold for 2 seconds to return to the normal mode.

(3) Clearing an address: Refer to section (1) regarding the address entry and section (2) regarding checking addresses.

a) In making group settings:

• Turn off the remote controller: The procedure is same as a) in (2) Address check.

• Put in the indoor unit address display mode: The procedure is same as a) in (2) Address check.

• Displaying the indoor unit address to be cleared: The procedure is same as a) in (2) Address check.

• Clearing indoor unit address : Pressing the q button on the remote controller twice will clear the address entry of the dis-

played indoor unit, resulting in the display shown in Figure 6. The display shown in Figure 7 will appear if an abnormality occurs and the entry is not cleared. Please repeat the clearing procedure.

• Returning to the normal mode after clearing an address: The procedure is same as a) in (2) Address check.

Figure 6. Display after address has been

cleared normally

Figure 7. Display when an abnormality has

occurred during clearing

"--" will appear in the room temperature display location.

"88" will appear in the room temperature display location.

b) In making paired settings:

• Turn off the remote controller: The procedure is same as b) in (2) Address check.

• Put into the indoor unit address display mode: The procedure is same as b) in (2) Address check.

• Put into the linked unit address display mode: The procedure is same as b) in (2) Address check.

• Display the address of the Lossnay unit or the indoor unit to be cleared.

• Deleting the address of a linked indoor unit: Pressing the q button on the remote controller twice will clear the address entry of the displayed indoor unit, resulting in the display shown in Figure 8.

• Returning to the normal mode after clearing an address: The procedure is same as b) in (2) Address check.

Figure 8. Display after address has been cleared normally

"--" will appear in the unit type display location when an address has

(altenating display)

been cleared normally.

"88" will appear in the unit type display location when an abnormality has occurred during clearing.

9-1-3. Countermeasures for Error During Test Run

• If a problems occurs during test run, a code number will appear in the temperature display area on the remote controller (or LED on the outdoor unit), and the air conditioning system will automatically cease operating.

Determine the nature of the abnormality and apply corrective measures.

Check code

0403

1102 1300 1302 1500 1501 1505 2500 2502 2503 4100 4115 4220 4230 4250 4400

5101

5102

5103 5105 5106 5110 5201 5300 5701 6600

6602

6603

6606

6607

6608

6831

6832

6833

6834

7100 7101 7102 7105 7111

Trouble Remarks

Serial transmission trouble

Discharge/Compressor temperature trouble Low Pressure trouble High pressure trouble Excessive refrigerant replenishment Insufficient refrigerant trouble Vacuum operation protection Water leakage Drain pump trouble Drain sensor trouble (THd) Overcurrent trouble (Overload, compressor lock) Power synchronization signal trouble Inverter trouble Overheat protection of radiator panel Power module trouble or Overcurrent trouble Fan controller trouble (Outdoor) Air inlet sensor trouble (TH21) or Discharge/Compressor temperature sensor trouble (TH4) Liquid pipe temp.sensor trouble (TH22) or Low pressure saturated temp. sensor trouble (TH6) Gas pipe temperature sensor trouble (TH23) Piping temperature sensor trouble (TH3) Outdoor temperature sensor trouble (TH7) Heatsink temperature sensor trouble (TH8) Pressure sensor trouble (63HS) Curnent sensor trouble Contact failure of drain float switch Duplicated unit address setting Transmission error (Transmission processor hardware error) Transmission error (Transmission route BUSY) Transmission and reception error (Communication trouble with transmission processor) Transmission and reception error (No ACK error) Transmission and reception error (No response error) MA communication receive signal error (no receive signal) MA commnication send signal error (starting bit derection error) MA commnication send error (H/W error) MA commnication receive error (Synchronous recovery error) Total capacity error Capacity code error Connecting unit number error Address set error Remote controller sensor trouble

Detected unit

Indoor Outdoor

Remote controller

Outdoor unit Multi controller board ~ Power board communiation trouble Check delay code 1202 Check delay code 1400 Check delay code 1402 Check delay code 1600 Check delay code 1601

Check delay code 4350 Check delay code 4165 Check delay code 4320 Check delay code 4330 Check delay code 4350 Check delay code 4500

Check delay code 1202

Check delay code 1211

Check delay code 1205 Check delay code 1221 Check delay code 1214 Check delay code 1402 Check delay code 4310

Only M-NET Remote controller is detected.

Only M-NET Remote controller is detected. +

Only MA Remote controller is detected.

NOTE )

When the outdoor unit detects No ACK error/No response error, an object indoor unit is treated as a stop, and not assumed to be abnormal.

Self-diagnosis function The indoor and outdoor units can be diagnosed automatically using the self-diagnosis switch (SW1) and LED1, LED2 (LED indication) found on the multi-controller of the outdoor unit. LED indication : Set all contacts of SW1 to OFF. During normal operation The LED indicates the drive state of the controller in the outdoor unit.

Bit

Indication

Compressor operated

52C

21S4

SV15(SV2)

—

—8Always lit

[Example] When the compressor and SV1 are turned during cooling operation.

12345678

Display

1102

Abnormal point and detecting method

High discharge/compressor temperature

Abnormal if discharge/compressor temperature thermistor continuously for 5 minutes.

Abnormal if pressure detected by high-pressure

sensor and converted to saturation temperature

exceeds 40 during defrosting and discharge/compressor (TH4) exceeds 110.

(TH4) exceeds 125 or 110

temperature thermistor

Causes

 Over-heated compressor operation caused by shortage of refrigerant

 Defective operation of stop valve  Defective thermistor  Defective outdoor controller board  Defective action of linear expansion

valve

Check points

 Check intake super heat. Check leakage of refrigerant. Charge additional refrigerant.

 Check if stop valve is full open. Turn the power off and check if 5101

is displayed when the power is put

again. When 5101 is displayed, refer to

“Check points” for 5101.  Check linear expansion valve.

Low pressure (63L operated)

1300

Abnormal if 63L is operated (under- 0.03MPa) during compressor operation.

63L: Low-pressure switch

(1) High pressure (High-pressure switch

1302

63H operated)

Abnormal if high-pressure switch 63H operated

( + ) during compressor operation.

+ 4.15 MPa

63H: High-pressure switch

(2) High pressure

(High - pressure sensor 63HS detect)

Abnormal if high-pressure sensor detects

4.31MPa or more (or over 4.15MPa

for 3 minutes) during the compressor

operation.

1500

Superheat due to low discharge temperature

Abnormal if discharge superheat is continuously detected less than or equal to -15 even though linear expansion valve has

minimum open pulse after compressor starts

operating for 10 minutes.

 Stop valve of outdoor unit is closed during operation.  Disconnection or loose connection of connector (63L) on outdoor controller board

Disconnection or loose connection of 63L

  Defective outdoor controller board  Leakage or shortage of refrigerant  Malfunction of linear expansion valve  Short cycle of indoor unit  Clogged filter of indoor unit  Decreased airflow caused by dirt of

indoor fan

 Dirt of indoor heat exchanger  Locked indoor fan motor  Malfunction of indoor fan motor  Defective operation of stop valve

(Not fully open)

 Clogged or broken pipe  Locked outdoor fan motor

 Malfunction of outdoor fan motor  Short cycle of outdoor unit  Dirt of outdoor heat exchanger  Decreased airflow caused by defective

inspection of outside temperature thermistor (It detects lower temperature than actual temperature.)  Disconnection or contact failure of connector (63H) on outdoor controller board  Disconnection or contact failure of 63H connection

 Defective outdoor controller board  Defective action of linear expansion

valve

 Malfunction of fan driving circuit  Solenoid valve (SV1) performance

failure (High-pressure pressure cannot be controlled by SV1.)

 High-pressure sensor  High-pressure sensor input

circuit defective in multi controller board

 Disconnection or loose connection of

discharge/compressor temperature thermistor (TH4) Defective holder of discharge temperature



thermistor

defective

 Check stop valve.

Check the connector (63L) on outdoor

~ controller board.

 Correct to proper amount of refrigerant.  Check linear expansion valve. ~ Check indoor unit and repair

defectives.

 Check if stop valve is fully open.

 Check piping and repair defectives. ~ Check outdoor unit and repair

defectives.

 Check the inspected temperature of outside temperature thermistor on LED display.

Check the connector (63H) on outdoor

~ controller board.

 Check linear expansion valve.

 Replace outdoor controller board.  Check the solenoid valve performance.

Check the high-pressure sensor.

 

Check the high-pressure sensor.

 Check the installation conditions of

discharge/compressor temperature thermistor (TH4).

Display

Refrigerant shortage

1501

When the conditions of below detecting mode  or  are satisfied during the

compressor operation.

<Detecting mode > When the below conditions are satisfied completely.

1. Compressor is operating in HEAT mode.

2. Discharge super heat is 80 or more.

3. Difference of outer temperature thermistor (TH7) and outdoor piping temp. thermistor (TH3) applies to the formula of (TH7-TH3)<5.

4. High-pressure sensor is below about

2.04MPa. <Detecting mode > When the below conditions are satisfied completely.

1. Compressor is operating.

2. When cooling, discharge superheat is 80 or more. When heating, discharge superheat is 90 or more. High pressure sensor is below about 2.32MPa.

Abnormal point and detecting method

 Gas leakage, Gas shortage

Causes

 When heating operation, refrigerant shortage feeling operation (When heating, airflow or thermo OFF are mixed-operation, it cause a refrigerant shortage operation.)  Ball valve performance failure (not fully opened.)  Error detection of discharge super heat

1) High-pressure sensor defective

2) Discharge temperature thermistor defective

3) Thermistor input circuit defective and high-pressure sensor defective in multi controller board

Check points

 Check the refrigerant amount.  Check the operation condition and

refrigerant amount.

 Check the ball valve is fully opened.



1) Check the ball valve is fully opened.

2) Check the resistance of discharge temperature thermistor.

3) According to “Outdoor unit functions”, set the SW2 and check the high pressure sensor level.

According to “Outdoor unit functions”, check the discharge temp. thermistor level. When the high-pressure sensor and discharge temp. thermistor are normal, if the above mentioned detecting pressure level and temp. are very different from the actual pressure and

temp., replace the multi controller board.

Water leakage

2500

1. Suspensive Abnormality when float switch

(Float

detects to be in the water and drain pump

switch

turns on and off except during cooling or dry

model)

mode.

2. Abnormal when detecting that the drain pump turns on and off again within 1 hour after the detection of water leakage suspensive abnormality, and repeats the detection twice. <2500> is displayed.

3. The unit continues to detect abnormality while turned off.

4. To release water leakage suspensive abnormality

· When not detecting that the drain pump turns off and on within 1 hour after detecting suspensive abnormality.

· When turning to cooling operation or dry operation.

· Detected that [liquid pipe temperature – room temperature] -10deg[-18°F]

Operation mode: When drain pump turns on as float switch detects to be in the water except during cooling/dry mode

 Error detection of TH7/TH3

1) Thermistor defective

2) Thermistor input circuit defective in multi controller board

 Defective drain Clogged drain pump Clogged drain pipe Adverse flow of drain in other units  Defective moving part of float switch Foreign matter on the moving part of float switch(ex. sludge etc.)

 Defective float switch



1) Check the resistance of thermistor.

2) According to “Outdoor unit functions”, check the outdoor pipe temp. thermistor level.

3) According to “Outdoor unit functions”, check the outer temp. thermistor level.

 Check the drain function.

 Check moving part of float switch.

 Check the value of resistance with the

float switch ON/OFF.

Drain pump

Float switch

OFF

15 sec.

In the water Water leakage suspensive abnormality

15 sec.

In the air In the water In the air

Within 1 hour Within 1 hour

15 sec. 15 sec.

6 min.6 min.

15 sec.

In the water Water leakage abnormality

Display

2502

(Drain

sensor

model)

Abnormal point and detecting method

Drain pump (DP)

 Let drain sensor self-heated, and if temperature rises slightly, as suspensive abnormality operation stops and changes to protect mode of restarting in 3 minutes.  Drain pump is abnormal if the condition above is detected during suspensive abnormality. <2502> is displayed.  Malfunction of drain pipe is constantly detected during drain pump operation.

 Malfunction of drain pump  Defective drain

Clogged drain pump Clogged drain pipe

Water drops on drain sensor



• Drops of drain trickles from lead wire.

• Clogged filter is causing wave of drain.  Defective indoor controller board

Causes

Check points

 Check if drain pump works.  Check drain function.

 Check the setting of lead wire of drain

sensor and check clogs of the filter.

 Replace indoor controller board when

there is no problem in the above mentioned ~.

 The unit enters to forced outdoor unit stop when following conditions, a) and b), are satisfied (while the above mentioned detection is performed). a) The drain sensor detects to be soaked in the water 10 times in a row. b) Detected that [liquid pipe temperature – room temperature] -10deg[-18°F] for 30 minutes constantly. When the drain sensor detects to be NOT soaked in the water, the

( )

record of a) and b) will be cleared.)

+ Drain pump abnormality (above ~) is

detected before it becomes an outdoor unit

forced stop condition.

 When indoor unit detects above  condition, outdoor unit in same refrigerant sytem stops. Also, indoor unit except for Fan or OFF mode unit stop. <2502> is displayed on stopped unit.  Detection timing of forced outdoor unit stop Constantly detected during unit operation and stop  Releasing of forced outdoor unit stop Reset power supply of both abnormal indoor unit and its outdoor unit in same refrigerant system. Forced outdoor unit stop cannot be released by remote controller OFF.

detection

 Both of above mentioned ~ and the indoor linear expansion valve full-closed

failure (leakage) happens synchronistically.

(Note) Address/Attribute displayed on the remote controller shows the indoor unit which is cause of trouble.

Check whether the indoor linear expansion valve leaks or not.

NOTE ) Above-mentioned ~ and ~ are detected independently.

Display

2502

(Float switch model)

Abnormal point and detecting method

Drain pump (DP)

 Judge whether the sensor is in the water or in the air by turning the float switch ON/OFF. In the water: Detected that the float switch is ON for 15 seconds. In the air: Detected that the float switch is OFF for 15 seconds.  When the float switch remains to be turned ON for 3 minutes after detected to be in the water, the drain pump is judged to be abnormal and <2502> will be displayed.

*It takes 3 minutes and 15 seconds to detect

abnormality including the time to judge to be in the water.

 The unit continue to detect abnormality while turned off.  When the conditions below 1, 2 and forced outdoor unit stop condition are met

1. Detected that [liquid pipe temperature – room temperature]  -10deg[-18°F] for 30 minutes constantly.

2. Float switch detects to be in the water for 15 minutes constantly.

*Before Forced outdoor unit stop condition

is met, the unit always detects - above.  The indoor unit detecting above stops due to detecting abnormality the outdoor unit in same refrigerant system (compressor is inhibited to operate). The unit which stops due to detecting abnormality displays <2502>.  Detection timing of forced outdoor unit stop Constantly detected during unit operation and stop  Releasing of forced outdoor unit stop Reset power supply of both abnormal

indoor unit and its outdoor unit in same

refrigerant system. Forced outdoor unit

stop cannot be released by remote

controller OFF.

Causes

 Malfunction of drain pump  Defective drain

Clogged drain pump Clogged drain pipe  Defective moving part of float switch Foreign matter on the moving part of float switch (ex. sludge etc.)

 Defective float switch

 Defective indoor controller board  Defective driving circuit of drain pump  Defective input circuit of float switch

 Both of above mentioned ~ and the

indoor linear expansion valve full-closed failure (leakage) happens synchronistically.

(Note) Address/Attribute displayed on the remote controller shows the indoor unit which is cause of trouble.

Check points

 Check if drain pump works.  Check drain function.

 Check moving part of float switch.

 Check the value of resistance with the

float switch ON/OFF.

 Change the indoor controller board.

 Check whether the indoor linear

expansion valve leaks or not.

NOTE ) Above-mentioned ~ and ~ are

detected independently.

Drain sensor (THd, DS) abnormality

2503

When the drain sensor detects short/open while the operation.

4100

Compressor overcurrent interruption (When compressor locked)

Abnormal if overcurrent of DC bus or compressor is detected within 30 seconds after compressor starts operating.

Over current level: 27.5A (V)/18.0A (Y)

 Connector (CN31) contact failure (insertion failure)

 Thermistor wiring disconnection or half disconnection

 Thermistor defective

 Indoor controller board (detecting

circuit) failure

 Stop valve is closed.  Decrease of power supply voltage  Looseness, disconnection or converse

of compressor wiring connection

 Defective compressor

 Defective outdoor power board



Check whether the indoor controller board connector (CN31) is disconnected or not.



Check whether the thermistor wiring is disconnected or not.



Check the resistance of thermistor.



If abnormality is not found in the method of the above-mentioned from  to , it is defective of the indoor controller board.

 Open stop valve.  Check facility of power supply.  Correct the wiring (U·V·W phase) to

compressor.

 Check compressor.

 Replace outdoor power circuit board.

Display

4220

Abnormal point and detecting method

Overvoltage or voltage shortage

Abnormal if any of followings are detected

during compressor operation:

• Decrease of DC bus voltage to 310V

• Instantaneous decrease of DC bus voltage to 200V (V)/350V (Y).

• Increase of DC bus voltage to 400V (V)760V (Y).

• Decrease of input current of outdoor unit to

0.1A only if operation frequency is more than or equal to 40Hz or compressor current is more than or equal to 6A.

 Decrease of power supply voltage  Disconnection of compressor wiring

 Defective X52A (Y)/52C (V) 

Defective outdoor converter circuit board (Y)

 Disconnection or loose connection of CN5 on the outdoor power circuit board  Defective 52C drive circuit of outdoor multi controller board (V)  Disconnection or loose connection of CN2 on the outdoor power circuit board.

 Defective ACT module (V)  Disconnection or loose connection of

CNAF (V)

 Defective ACT module drive circuit of outdoor controller circuit board (V)

Causes

Check points

 Check the facility of power supply.  Correct the wiring (U·V·W phase) to

compressor. (Outdoor power circuit board)

 Replace power board (Y)/noise filter

circuit board (V).



Replace outdoor converter circuit board (Y).

 Check CN5 wiring on the outdoor power circuit board.



Replace outdoor multi controller board (V).

 Check CN2 wiring on the outdoor power circuit board.

 Replace ACT module (V).  Check CNAF wiring (V).



The 4220 error history can be confirmed

with SW1 No.189.

21345678

4230

Temperature of heatsink

Abnormal if heatsink thermistor (TH8) detects

85(V)/95(Y)

NOTE) TH8 is internal thermistor of power module on power board. (Y)

(1) Power module

4250

Check abnormality by driving power module in

case overcurrent is detected.

(2) Compressor overcurrent interruption

Abnormal if overcurrent DC bus or compressor is detected after compressor starts operating for 30 seconds.

Over current level: 27.5A (V)/18.0A (Y)

 The outdoor fan motor is locked.  Failure of outdoor fan motor  Airflow path is clogged.  Rise of ambient temperature

 Defective thermistor

 Defective input circuit of outdoor power

circuit board

 Failure of outdoor fan drive circuit

 Outdoor stop valve is closed.  Decrease of power supply voltage  Looseness, disconnection or converse

of compressor wiring connection

 Defective compressor  Defective outdoor power circuit board

 Stop valve of outdoor unit is closed.  Decrease of power supply voltage  Looseness, disconnection or converse

of compressor wiring connection

 Defective fan of indoor/outdoor units  Short cycle of indoor/outdoor units  Defective input circuit of outdoor

controller board

 Defective compressor

 Check outdoor fan.

 Check air flow path for cooling.  Check if there is something which

causes temperature rise around outdoor unit. (

Upper limit of ambient temperature is 46.

Turn off power, and on again to check if 4230 is displayed within 30 minutes.  Check thermistor <TH8> temperature by microprocessor.

 Replace outdoor power circuit board.

 Replace outdoor controller circuit board.

 Open stop valve.  Check facility of power supply.  Correct the wiring (U·V·W phase) to

compressor. (Outdoor power circuit board).

 Check compressor.  Replace outdoor power circuit board.

 Open stop valve.  Check facility of power supply.  Correct the wiring (U·V·W phase) to

compressor. (Outdoor power circuit board).

 Check indoor/outdoor fan.  Solve short cycle.  Replace outdoor controller circuit board.

 Check compressor.

 Before the replacement of the outdoor controller circuit board, disconnect the wiring to compressor from the outdoor power circuit board and check the output voltage among phases, U, V, W, during test run (SW7-1 ON). No defect on board if voltage among phases (U-V, V-W and W-U) is same. Make sure to perform the voltage check with same performing frequency.

)

Outdoor fan motor

4400

The outdoor fan motor is considered to be abnormal if the rotational frequency of fan motor is abnormal when detected during operation. Fan motor rotational frequency is abnormal if:

• 100 rpm or below detected continuously for 15 seconds at 20 or more outside air temperature

• 50 rpm or below or 1500 rpm or more detected continuously for 1 minute.



Failure in the operation of the DC fan motor



Failure in the outdoor circuit controller board

 Check or replace the DC fan motor.

 Check the voltage of the outdoor circuit

controller board during operation.

 Replace the outdoor circuit controller

board. (when the failure is still indicated even after performing the check points

above.)

Display

5101

Abnormal point and detecting method

Room temperature thermistor (TH21)

When controller detects short (high temp.)/open (low temp.) in thermistor during the operation, the operation stops and the operation changes to protect mode of restarting in 3 minutes. If the thermistor does not recover in 3 minutes, the operation stops due to detecting abnormality. In this time, <5101> is displayed. Then, if the thermistor recover in 3 minutes, it operates normally.

Short: Detected 90 or more

Open: Detected –40 or less

Discharge/Compressor temperature thermistor (TH4)



When controller detects short/open in thermistor during the operation, the outdoor unit stops once and restarts operation in 3 minutes. When the detected temperature is normal at just before of restarting, the outdoor unit restarts.



When controller detects short/open in thermistor at just before of restarting, the unit stops due to detecting abnormality. In this time, <5101> is displayed.

For 10 minutes after starting compressor,



for defrosting or for 3 minutes after recover of defrosting, above-mentioned short/open are not detected.

Short: 216or more (1k Open: 0 or less (700k)

Note) When outer temperature thermistor (TH7) is 5 or less on cooling, open detecting is not determined as abnormality.

)

Causes

 Connector (CN20) contact failure

 Thermistor wiring disconnection or

half disconnection

 Thermistor failure

 Detecting circuit failure in the

indoor controller board

 Connector (TH4) contact failure

 Thermistor wiring disconnection or

half disconnection

 Thermistor failure

 Multi controller board input circuit

failure

Check points



Check whether the connector (CN20) in the indoor controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



Check the resistance of thermistor; 0···15k

10···9.6k 20···6.3k 30···4.3k 40···3.0k



When there is no problem in above mentioned , replace the indoor controller board.



Check whether the connector (TH4) in the multi controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



Check the resistance of thermistor; When the resistance is not below value, replace the thermistor. 0··· about 700k 10··· about 410k 20··· about 250k 30··· about 160k 40··· about 104k

Set the SW1 to



When the temperature in multi controller board is not an actual temperature, replace the multi controller board.

1.3: Open

219.4: Short

21345678

Display

5102

Abnormal point and detecting method

Liquid pipe temperature thermistor (TH22)

When the thermistor detects short/open during the operation, the operation stops and the operation changes to protect mode of restarting in 3 minutes. If the thermistor does not recover in 3 minutes, the operation stops due to detecting abnormality. In this time, <5102> is displayed. Then, if the thermistor recovers in 3 minutes, it operates normally.

Short: Detected 90 or more

Open: Detected -40 or less

Causes

1) Connector (CN21) contact failure Check whether the connector (CN21)

2) Thermistor wiring disconnection or half disconnection

3) Thermistor failure



in the indoor controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



Check the resistance of thermistor;

0····15k 10···9.6k 20···6.3k 30···4.3k 40···3.0k

Check points

Low pressure saturation temperature thermistor (TH6)





When controller detects short/open in thermistor at just before of restarting, the unit stops due to detecting abnormality. In this time, <5102> is displayed.



For 10 minutes after starting compressor, heating mode, above-mentioned short/open are not detected.

Short: 90 or more

Open: -40 or less

4) Detecting circuit failure in the indoor controller board

1) Connector (TH6) contact failure Check whether the connector (TH6)

2) Thermistor wiring disconnection or half disconnection

3) Thermistor failure Check the resistance of thermistor;

4) Multi controller board input circuit failure



When there is no problem in above mentioned , replace the indoor controller board.



in the multi controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



0····15k 10···9.6k 20···6.3k 30···4.3k 40···3.0k

21345678



Set the SW1 to

When the temperature in multi controller board is not an actual temperature, replace the multi controller board.

-42.5: Open

91.9: Short

Display

5103

Abnormal point and detecting method

Gas pipe temperature thermistor (TH23)

When the thermistor detects short/open after 3 minutes-continuous thermo ON during cooling or dry operation, the operation stops and the operation changes to protect mode of restarting in 3 minutes. If the thermistor does not recover in 3 minutes, the operation stops due to detecting abnormality. In this time, <5103> is displayed. Then, if the thermistor recover in 3 minutes, it operates normally.

Short: Detected 90 or more

Open: Detected -40 or less

Causes

1) Connector (CN29) contact failure Check whether the connector (CN29)

2) Thermistor wiring disconnection or half disconnection

3) Thermistor failure Check the resistance of thermistor:



in the indoor controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



10···9.6k 20···6.3k 30···4.3k 40···3.0k

Check points

0····15k

5105

Pipe temperature/judging defrost thermistor (TH3)





When controller detects short/open in thermistor at just before of restarting, the unit stops due to detecting abnormality. In this time, <5105> is displayed.



For 10 minutes after starting compressor, for defrosting or for 3 minutes after recover of defrosting, above-mentioned short/open are not detected.

Short: 88 or more (0.4k)

Open: -39 or less (115k)

4) Detecting circuit failure in the indoor controller board

1) Connector (TH3) contact failure Check whether the connector (TH3) in

2) Thermistor wiring disconnection or half disconnection

3) Thermistor failure Check the resistance of thermistor;



When there is no problem in above mentioned , replace the indoor controller board.



the multi controller board is connected or not.



Check whether the thermistor wiring is disconnected or not.



When the resistance is not below value, replace the thermistor.

0····15k

10···9.6k 20···6.3k 30···4.3k 40···3.0k

4) Multi controller board input circuit failure

21345678



Set the SW1 to When the temperature in multi

controller board is not an actual temperature, replace the multi controller board.

-42.5: Open

91.9: Short

Display

5106

5110

Abnormal point and detecting method

Outdoor temperature thermistor (TH7)





When controller detects short/open in thermistor at just before of restarting, the unit stops due to detecting abnormality. In this time, <5106> is displayed.



For 10 minutes after starting compressor, for defrosting or for 3 minutes after recover of defrosting, above-mentioned short/open are not detected.

Short: 90 or more Open: -40 or less

Heatsink temperature thermistor (TH8)

(Internal thermistor of power module (Y)) (Heatsink thermistor (V))





When controller detects short/open in thermistor at just before of restarting, the unit stops due to detecting abnormality. In this time, <5110> is displayed.



For 10 minutes after starting compressor, for defrosting or for 3 minutes after recover of defrosting, above-mentioned short/open are not detected.

Short: 102 (V)/170 (Y) or more Open: -27 (V)/-35 (Y) or less

Causes

1) Connector (TH7) contact failure Check whether the connector (TH7) in



Check points

the multi controller board is connected or not.

2) Thermistor wiring disconnection or half disconnection

3) Thermistor failure Check the resistance of thermistor;



Check whether the thermistor wiring is disconnected or not.



When the resistance is not below value, replace the thermistor.

0····15k 10···9.6k 20···6.3k 30···4.3k 40···3.0k

21345678

4) Multi controller board input circuit failure



Set the SW1 to When the temperature in multi

controller board is not an actual temperature, replace the multi controller board.

-42.5: Open

91.9: Short



1) Connector (TH8) contact failure.

Check whether the connector (TH8) in the power circuit board. (V)



2) Thermistor wiring disconnection or half disconnection.

3) Thermistor failure

Check whether the thermistor wiring is disconnected or not. (V)



Check the resistance of thermistor; When the resistance is not below value, replace the thermistor. (V)

0 ·····180k 10 ·····105k 20 ·······63k

30 ·······39k 40 ·······25k

21345678

4) Power board input circuit failure



Set the SW1 to

When the temperature in multi controller board is not an actual temperature, replace the power board.

Display

5201

Abnormal point and detecting method

Pressure sensor (63HS)



When detected pressure in high-pressure sensor is 1 MPa or less during the operation, the compressor stops and restarts operation in 3 minutes.



When the detected pressure is 1 MPa or less at just before of restarting, the compressor stops due to detecting abnormality. In this time, <5201> is displayed.



For 3 minutes after starting compressor, for defrosting or for 3 minutes after recover of defrosting, abnormality is not determined as abnormality.

Causes

1) High-pressure sensor failure Check the high-pressure sensor.

2) Internal pressure decrease by gas leakage

3) Connector contact failure, disconnection





Check the internal pressure.

Check the high-pressure sensor.



Check points

Connection failure of float switch

5701

connector

Abnormal if detected that the float switch connector is disconnected(open) during operation

Current sensor error

5300

Abnormal if current sensor detects –1.5A to

1.5A during compressor operation. (This error is ignored in case of SW7-1 ON.)

6600

6602

Duplex address error

Detected error when transmission of unit with the same address is confirmed.

Note) Address/Attribute displayed on the remote controller shows the controller detecting abnormality.

Transmission processor H/W error

'' 1 '' shows on the transmission line though the transmission processor transmitted '' 0''.

remote controller shows the controller detecting abnormality.

4) Multi controller board input circuit failure

1) Connection failure of connecor (CN4F)

1) Disconnection of compressor wiring

2) Defective circuit of current sensor on outdoor power circuit board

1) There are 2 units or more with the same address among the outdoor unit or indoor unit or lossnay controller, remote controller.

2) When noise has occurred in the transmission signal, and the signal has changed.

1) When the wiring for either of the indoor unit, the outdoor unit or lossnay transmission line is constructed or polarity is changed with the power supply turned on, the transmission waves change in case that the transmission data collides mutually. It causes to detect error.

2) Transmission processor circuit failure

3) When the transmission data has changed by the noise.



Check the high-pressure sensor.

 Check the connection failure of connector (CN4F) on the indoor controller board.

 Correct the wiring (U·V·W phase) to compressor. (Outdoor power circuit board).

 Replace outdoor power circuit board.



Look for the unit, which is source of abnormality with the same address. When the same address is found, correct the address and turn off power supply of outdoor unit, indoor unit, and lossnay for 2 minutes or more as the same time. Then, turn on power supply.



Check the transmitted wave and the noise on the transmission line.



When the transmission wire is constructed with the current flowed, turn off power supply of outdoor unit, indoor unit and lossnay for 2 minutes or more as the same time. Then, turn on power supply.Note) Address/Attribute displayed on the



Check the transmitted wave and the noise on the transmission line.

Display

6603

Abnormal point and detecting method

Transmission bus busy error

Over error by collision



Abnormality when the state, which cannot be transmitted by collision of transmission, is consecutive for 8 to 10minutes.

Causes

1) The transmission processor cannot be transmitted since a short cycle voltage of the noise etc. mixes on the transmission line consecutively.

Check points



Check whether the transmission line of the indoor unit, fresh master, lossnay and remote controller is connected to the outdoor unit terminal board (TB7) for centralized controller or not.

The state that data cannot to be output to



the transmission line by the noise happens for 8 to 10 minutes consecutively.

Note) Address/Attribute displayed on the remote controller shows the controller detecting abnormality.

6606

Signal communication error with transmission processor

Signal communication error between unit processor and transmission processor

Note) Address/Attribute displayed on the remote controller shows the controller detecting abnormality.

2) The transmission volume increases and cannot be transmitted since the wiring method is mistaken and the routing technique to the terminal board (TB3) for the transmission line of the outdoor unit and the terminal board (TB7) for centralized control cannot be transmitted.

3) The share becomes high since the data exists together to other transmitted data by a defective repeater (function which connects and intercepts the transmission of controlling system and centralized control system), and it causes abnormal detection.

1) The data of the unit/transmission processor was not normally transmitted due to accidental disturbance such as noise and lightening surge.



Check whether the transmission line with the other refrigerant system of the indoor unit and lossnay is connected to the outdoor unit terminal board (TB3) for transmission or not.



Check whether the outdoor unit terminal board for transmission line (TB3) and for centralized controller (TB7) are connected or not.



Check the transmitted wave and the noise on the transmission line.

Turn off power supply of outdoor unit, indoor unit, and lossnay for 2minutes or more at the same time. Then, turn on power supply. It normally recovers from the malfunction that happens by chance. When same abnormality occurs again, it is defective of the controller.

2) The address transmission from the unit processor was not normally transmitted by the hardware of transmission processor defective.

Display

6607

Abnormal point and detecting method

No ACK (Acknowledgement)

Abnormality which controller of the



sending side detects when there is no answer (ACK) from other side though data was transmitted once. It is detected 6 times every 30 seconds continuously.

Note) Address/Attribute displayed on the remote controller shows the controller, which did not send back reply (ACK).

Causes

Factor that does not relate to origin

1) Since the address switch was changed with the current passed, the unit in the last address does not exist.

2) Decline of transmission voltage and signal by transmission line tolerance over

· The furthest point···200m

· Remote controller line···(12m)

(Refer to 8-3.)

3) Decline of transmission line voltage and signal by unmatched kind of line.

· Shield line-CVVS,CPEVS

Line diameter···1.25 Aor more

4) Decline of transmission line voltage and signal by a number of over-connected units.

5) Mis-operation of origin controller, which happens by chance.

6) Original controller defective

Check points



Turn off power supply of outdoor unit, indoor unit, fresh master and lossnay for 2 minutes or more at the same time. Then, turn on power supply. It recovers normally from the malfunction that happens by chance.



Check the address switch of the address which causes abnormality.



Check whether the transmission line is connected/loosen or not at origin. (Terminal board or connector)



Check whether the transmission line tolerance is over or not.



Check whether the kind of transmission line is mistaken or not.

When there is any trouble from above -, turn off power supply of outdoor unit, indoor unit and lossnay for 2 minutes or more at the same time. Then, turn on power supply.

1) When the cause of displayed address and attribute is on the outdoor unit side

(The indoor unit detects when there is no reply (ACK) on transmitting from the indoor unit to the outdoor unit.)

2) When the cause of displayed address and attribute is on the indoor unit side

1) Contact failure of outdoor unit or indoor unit transmission line

2) Indoor unit transmission connector (CN2M) disconnection

3) Sending/receiving signal circuit failure in the indoor/outdoor unit

1) When operating with multi refrigerant system indoor units, the remote controller transmits the signal to the indoor unit after the other refrigerant system outdoor unit is turned off or turned on again in 2 minutes, and detects abnormality.

2) Contact failure of remote controller or indoor unit transmission line

When there is not any trouble in single refrigerant system (1 outdoor unit) from above -, controller defective in displayed address and attribute. When there is not any trouble in different refrigerant system (2 outdoor unit or more) from above -, determine it after .



When the address which should not exist is an origin, since there is the indoor unit which memorizes the address data, cancel the unnecessary address data by the manual setting function of remote controller. However, they are limited to the system, which sets the group between different refrigerant systems, or which fresh master/lossnay are connected.

When there is not any trouble from above -, replace the displayed address/attribute controller board.

In this time, when the error does not recover to normal, the outdoor unit multi controller board (repeater circuit) defective is expected.

Check the recovery by replacing the multi controller board one by one.

(The remote controller detects when there is no reply (ACK) on transmitting from the remote controller to the indoor unit.)

3) Indoor unit transmission connector (CN2M) disconnection

4) Sending/receiving signal circuit failure in the indoor unit or remote controller.

Continued to the next page.

From the previous page.

Display

Abnormal point and detecting method

Causes

Check points

6607

3) When the cause of displayed address and attribute is on the remote controller side

(The indoor unit detects when there is no reply (ACK) on transmitting from the indoor unit to the remote controller unit.)

4) When the cause of displayed address and attribute is on the fresh master side

(The indoor unit detects when there is no reply (ACK) on transmitting from the indoor unit to the fresh master.)

1) When operating with multi refrigerant system indoor units, the indoor units transmits the signal to the remote controller after the other refrigerant system outdoor unit is turned off or turned on again in 2 minutes, and detects abnormality.

2) Contact failure of remote controller or indoor unit transmission line

3) Indoor unit transmission connector (CN2M) disconnection

4) Sending/receiving signal circuit failure in the indoor unit or remote controller

1) When synchronized operating with other refrigerant system fresh master, the indoor units transmits the signal to the fresh master after the fresh master and same refrigerant system outdoor unit is turned off or turned on again in 2 minutes, and detects abnormality.

5) When the cause of displayed address and attribute is on the lossnay side

(The indoor unit detects when there is no reply (ACK) on transmitting from the indoor unit to the lossnay.)

2) Contact failure of fresh master or indoor unit transmission line

3) Indoor unit or fresh master transmission connector (CN2M) disconnection

4) Sending/receiving signal circuit failure in the indoor unit or fresh master

1) When the lossnay power supply is off, the indoor unit detects abnormality at signal transmitting to the lossnay.

Continued to the next page.

From the previous page.

Display

6607

Abnormal point and detecting method

6) When the controller of displayed address and attribute is not recognized

Causes

2) When synchronized operating with other refrigerant system lossnay, the indoor units transmits the signal to the lossnay after the lossnay and same refrigerant system outdoor unit is turned off or turned on again in 2 minutes, and detects abnormality

3) Contact failure of lossnay or indoor unit transmission line

4) Indoor unit transmission connector (CN2M) disconnection

5) Sending/receiving signal circuit failure in the indoor unit or lossnay

1) Since the address switch was changed with the current passed, the unit in the last address does not exist.

2) Since the fresh master/lossnay address are changed after synchronized setting of fresh master/lossnay by the remote controller, abnormality is detected at transmitting from the indoor unit.

Check points

6608

No response

Though there was a replay (ACK) of having received signal from the other side, it is the abnormality when the response command does not return. The sending side detects the abnormality continuously six times every 30 seconds.

Note) Address/Attribute displayed on the remote controller shows the controller, which did not response.

1) Transmission repeats the failure by the noise etc.

2) Decline of transmission voltage and signal by transmission line tolerance over

· The furthest point···200m

· Remote controller line···(12m)

(Refer to 8-3.)

3) Decline of transmission line voltage

and signal by unmatched kind of line

· Shield wire-CVVS, CPEVS

Wire diameter···1.25A or more

4) Mis-operation of origin controller, which happens by chance.

Check the transmission wave and



noise on the transmission line.



Turn off power supply of outdoor unit, indoor unit and lossnay for 2minutes or more at the same time. Then, turn on power supply again. It normally recovers fom the malfunction that happens by chance. When same abnormality occurs again, it is defective of displayed address and attribute.

Display

6831 6834

6832 6833

7100

Abnormal point and detecting method

Signal reception (Remote controller)

Following symptoms are regarded as abnormality.

1) When the remote controller cannot receive the signal from indoor controller normally even once for 3 minutes

2) When the remote controller cannot receive the signal even once for 2 minutes

Signal transmission (Remote controller)

Following symptoms are regarded as abnormality.

1) When sub-remote controller cannot

transmit the signal to the transmission path for 6 minutes

2) When the remote controller cannot

finish transmitting the signal for 30 times on end

When connected total models of the indoor units exceed the specified level (130% of the outdoor unit models), error code <7100> is displayed.

Causes



Defect of the transmission and reception circuit of the remote controller.



Defect of the transmission and reception circuit of the indoor controller board



Noise occurs on the transmission line of the remote controller



All remote controllers are set as sub-remote controller.



Defect of the transmission and reception circuit of the remote controller



Noise occurs on the transmission line of the remote controller



There are 2 main remote controllers.

1) Connecting total models of the indoor unit exceed the specified level.

· PUMY-P100 ( ~ code 26)

· PUMY-P125 ( ~ code 33)

· PUMY-P140 ( ~ code 38)

Check points

~

Check the remote controller. According to the results, perform the following disposals.

• When "RC OK" is displayed, the remote controller is normal. Turn off the power supply and turn it on again. If "HO" or "PLEASE WAIT" is displayed for 4 minutes or more, replace the indoor controller board.

• When "RC NG" is displayed, replace the remote controller.

• When "RC 6832 or 6833" or "ERC 00-66" is displayed, these displays may be due to noise, etc.

 Set one remote controller to main

remote controller and the other to sub-remote controller.



Check the total models of connected indoor unit.



Check the model code registration switch (indoor controller board SW2) of connected indoor unit.

2) There is a mistake in the registration of model name code of the outdoor unit.

Check the model code registration switch (outdoor multi controller board SW4) of the outdoor unit.

Display

7101

Abnormal point and detecting method

Capacity code error

When the connected indoor unit models cannot be connected, <7101> is displayed.

Causes

The indoor unit models is not possible to connect.

The indoor unit of 15-140 (Code 3-28) is possible to connect.

Check points

Check the model code registration



switch (indoor controller board SW2) in the connected indoor unit.

The outdoor unit SW1 operation can



check model code of the connected indoor units.

Code of indoor unit

ON OFF

21345678

No.2

ON OFF

No.1

21345678

7102

Number of connecting unit over

When the connecting unit exceeds a number of limitations, error code <7102> is displayed.

Even if the indoor unit is not connected, <7102> is displayed.

Connecting unit exceeds a number of limitations. It is assumed abnormal excluding the following cases;

1) The indoor unit can be totally

connected up to 8 (P100)/10 (P125)/ 12

(P140) units. The indoor unit can be connected up to 8 (P100)/10 (P125)/ 12 (P140) units.

2) Ventilation unit connecting is only 1 unit.

No.3

No.5

No.7

No.9

No.11

ON OFF

21345678

No.4

No.6

No.8

No.10

No.12

ON OFF

21345678

The black square (■) indicates a switch position.

Check whether the connecting unit exceeds a number of limitations or not.

7105

Address setting error

Address setting of the outdoor unit is wrong.

Addresses mis-setting of the outdoor unit

The outdoor unit is not set in 000 or in the range of 51-100.

7111 When an old type remote controller for

Remote controller sensor

In the case of network remote controller, it is an abnormality when incapable response returns from the network remote

M-NET is used, and the remote controller sensor is specified (SW1-1 is ON).

controller during the operation.

0403

Serial communication error

Abnormal if serial communication between outdoor multi board and outdoor power board is defective.

 Breaking of wire or contact failure of connector CN2  Breaking of wire or contact failure of connector CN4  Defective communication circuit of outdoor power board  Defective communication circuit of outdoor multi board for power board

Check the address setting of the outdoor unit. The address should be set in 000 or 51-100.

When the setting is out of the range, reset it, turn off power supply of the outdoor unit, indoor unit and lossnay for 2 minutes or more at the same time, and turn on power supply again.

Replace the remote controller to net work remote controller.

 Check connection of each connector CN2, CN4.

 Replace outdoor power board.

 Replace outdoor multi board.

9-2. REMOTE CONTROLLER DIAGNOSIS

· MA remote controller is equipped with the diagnosis function

If the air conditioner cannot be operated from the remote controller, diagnose the remote controller as explained below.



First, check that the power-on indicator is lit. If the correct voltage (DC12 V) is not supplied to the remote controller, the indicator will not light. If this occurs, check the remote controller's wiring and the indoor unit.

Power on indicator



Switch to the remote controller self-diagnosis mode.

Press the

change as shown below.



Remote controller self-diagnosis result

[When the remote controller is functioning correctly]

CHECK

button for 5 seconds or more. The display content will

Press the

[When the remote controller malfunctions] (Error display 1) "NG" flashes. → The remote controller's transmitting-receiv-

FILTER

button to start self-diagnosis.

ing circuit is defective.

Check for other possible causes, as there is no problem with the remote controller.

[Where the remote controller is not defective, but cannot be operated.] (Error display 2) [E3], [6833] or [6832] flashes. → Transmission is not possible.

There might be noise or interference on the transmission path, or the indoor unit or other remote controllers are defective. Check the transmission path and other controllers.



To cancel remote controller diagnosis

Press the After approximately 30 seconds, the state in effect before the diagnosis will be restored.

CHECK

button for 5 seconds or more. Remote controller diagnosis will be cancelled, "PLEASE WAIT" and operation lamp will flash.

The remote controller must be replaced with a new one.

(Error display 3)

The number of data errors is the difference between the number of bits sent from the remote controller and the number actually transmitted through the transmission path. If such a problem is occurring, the transmitted data is affected by noise, etc. Check the transmission path.

"ERC" and the number of data errors are displayed. → Data error has occurred.

When the number of data errors is "02":

Transmission data from remote controller

Transmission data on transmission path

9-3. REMOTE CONTROLLER TROUBLE

STAND BY DEFROST

CENTRALLY CONTROLLED

CHECK

°C

TEMP.

TIMER SET

ON OFF

CLOCK

ERROR CODE

1Hr.

NOT AVAILABLE

°C

FILTER

CHECK MODE

TEST RUN FUNCTION

ON/OFF

CHECK TEST

“ ” Indicator: appears when current is carried.

FILTER

(M-NET Remote controller)

(1) For M-NET remote controller systems

Symptom or inspection code Cause Inspection method and solution

Though the content of operation is displayed on the remote controller, some indoor units do not operate.

Though the indoor unit operates, the display of the remote controller goes out soon.

( ) is not displayed on the remote controller.

(M-NET remote controller

is not fed.)

"HO" keeps being displayed or it is displayed periodically. ("HO" is usually displayed about 3 minutes after the power supply of the outdoor unit is on.)

The remote controller does not operate though ( ) is displayed.

• The power supply of the indoor unit is not on. The address of the indoor units in same group or the remote controller

•

is not set correctly.

•

The group setting between outdoor units is not registered to the remote

controller.

• The fuse on the indoor unit controller board is blown.

• The power supply of the indoor unit is not on.

• The fuse on the indoor unit controller board is blown.

• The power supply of the outdoor unit is not on.

• The connector of transmission outdoor power board is not connected.

•

The number of connected indoor unit in the refrigeration system is over the limit or the number of connected remote controller is over the limit.

•

M-NET remote controller is connected to MA remote controller cable.

• The transmission line of the indoor/outdoor unit is shorted or down.

• M-NET remote controller cable is shorted or down.

• Transmission outdoor power board failure.

• The power supply for the feeding expansion unit for the transmission

line is not on.

• The address of the outdoor unit remains "00". The address of the indoor unit or the remote controller is not set correctly.

•

• MA remote controller is connected to the transmission line of the

indoor/outdoor unit.

• The transmission line of the indoor/outdoor unit is connected to TB15.

• The transmission line of the indoor/outdoor unit is shorted, down or

badly contacted.

• Check the part where the abnormality occurs.

 The entire system  In the entire refrigerant system  In same group only  1 indoor unit only

•

Check the self-diagnosis LED

of the outdoor unit.

• Check the items shown in the left that are related to the outdoor unit.

• Check the items shown in the left that are related to the indoor unit.

(2) For MA remote controller systems

Symptom or inspection code Cause Inspection method and solution

Though the content of operation is displayed on the remote controller, some indoor units do not operate.

Though the indoor unit operates, the display of the remote controller goes out soon.

( ) is not displayed on the remote controller. (MA remote controller is not fed.)

"PLEASE WAIT" keeps being displayed or it is displayed periodically. ("PLEASE WAIT" is usually displayed about 3 minutes after the power supply of the outdoor unit is on.)

remote controller does not

The operate though ( ) is displayed.

• The power supply of the indoor unit is not on.

• Wiring between indoor units in same group is not finished.

• The indoor unit and Slim model are connected to same group.

• The fuse on the indoor unit controller board is blown.

• The power supply of the indoor unit (Master) is not on.

• In case of connecting the system controller, the setting of the system controller does not correspond to that of MA remote controller.

• The fuse on the indoor unit (Master) controller board is blown. The remote controller is not fed until the power supply of both indoor unit

and outdoor unit is on and the start-up of both units is finished normally.

• The power supply of the indoor unit is not on.

• The power supply of the outdoor unit is not on.

• The number of connected remote controller is over the limit (Maximum: 2 units) or the number of connected indoor unit that is over the limit (Maximum: 16 units).

•

The address of the indoor unit is "00" and the address for the outdoor

unit is the one other than "00".

•

The transmission line of the indoor/outdoor unit is connected to TB15.

• MA remote controller is connected to the transmission line of the indoor/outdoor unit .

• The remote controller cable is shorted or down.

• The power supply cable or the transmission line is shorted or down.

• The fuse on the indoor unit controller board is blown.

• The power supply of the outdoor unit is not on.

• The power supply of the feeding expansion unit for the transmission line is not on.

• The setting of MA remote controller is not main remote controller, but sub-remote controller.

• MA remote controller is connected to the transmission line of the indoor/outdoor unit

• The power supply of the indoor unit (Master) is not on.

• The transmission line of the indoor/outdoor unit is connected to TB15.

• The transmission line of the indoor/outdoor unit is shorted, down or badly contacted.

•The fuse on the indoor unit controller board is blown.

• Check the part where the abnormality occurs.

 The entire system  In the entire refrigerant system  In same group only  1 indoor unit only

•

Check the self-diagnosis LED

of the outdoor unit.

• Check the items shown in the left that are related to the outdoor unit.

• Check the items shown in the left that are related to the indoor unit.

9-4. THE FOLLOWING SYMPTOM DO NOT REPRESENT TROUBLE (EMERGENCY)

Symptom

Even the cooling (heating) operation selection button is pressed, the indoor unit cannot be operated. The auto vane runs freely.

Fan setting changes during heating.

Fan stops during heating operation. Fan does not stop while operation has been stopped. No setting of fan while start SW has been turned on.

Indoor unit remote controller shows “HO” or “PLEASE WAIT ” indicator for about 2 minutes when turning ON power supply. Drain pump does not stop while unit has been stopped. Drain pump continues to operate while unit has been stopped.

Display of remote controller

"Cooling (Heating)" blinks

Normal display

"Defrost "

Light out

STAND BY

“HO” blinks “PLEASE WAIT” blinks

Light out

—

CAUSE

The indoor unit can not cool (Heat) if other indoor units are heating (Cooling).

Because of the control operation of auto vane, it may change over to horizontal blow automatically from the downward blow in cooling in cause the downward blow operation has been continued for 1 hour. At defrosting in heating, hot adjusting and thermostat OFF, it automatically changes over to horizontal blow. Ultra-low speed operation is commenced at thermostat OFF. Light air automatically change over to set value by time or piping temperature at thermostat ON. The fan is to stop during defrosting.

Fan is to run for 1 minute after stopping to exhaust residual heat (only in heating). Ultra-low speed operation for 5 minutes after SW ON or until piping temperature becomes 35°C. There low speed operate for 2 minutes, and then set notch is commenced. (Hot adjust control) System is being driven. Operate remote controller again after “HO” or “PLEASE WAIT” disappears.

After a stop of cooling operation, unit continues to operate drain pump for 3 minutes and then stops it. Unit continues to operate drain pump if drainage is generated, even during a stop.

9-5. INTERNAL SWITCH FUNCTION TABLE PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

The black square (■) indicates a switch position.

Switch

SW U1 1s digit

SW U2 10ths digit

Step

Rotary switch

Function

SWU2

(10ths digit)

SWU1

(1s digit)

Operation in Each Switch Setting

ON OFF When to Set

Before turning the power on

Remarks

SWU2

(10ths digit)

SWU1

(1s digit)

SW1 Digital Display Switching

SW2 Function Switching

SW3 Trial operation

Outdoor unit

SW4 Model Switching

SW5 Function switching

1~8

OFF

Selects operating system startup

Connection Information Clear Switch

Abnormal data clear switch input

Pump down

Auto change over from Remote controller

ON/OFF from outdoor unit

Mode setting

—

+1 MODEL SELECT 1:ON 0:OFF

1~6

PUMY-P100V PUMY-P125V PUMY-P140V

Pressure limitation value change

Change the indoor unit's LEV opening at

start

Fixing the indoor units linear expansion

valve opening Fix the operation frequency

Change the indoor unit's LEV opening

at defrost

Switching the target sub cool.

MODELS

SW4

123456 010010

010001 010011

234 567 8

With centralized controller

Clear

Clear abnormal data

Run adjustment mode

Enable

Heating

MODELS

PUMY-P100Y PUMY-P125Y PUMY-P140Y

Enable

Fix Normal

Enable

—

Can be set either during operation or not.

Without centralized controller

Do not clear

Normal

Disable

Before turning the power on

OFF to ON any time after the power is turned on.

During compressor running

Before turning the power on

——

OFF

Cooling

SW4

123456 110010

Any time after the power is turned on.

Before the power is turned on.

110001 110011

Normal

Can be set when off or during operation

OFF to ON during compressor running.

Can be set when off or during operation

OFF

234 567 8

OFF

23456

OFF

Set for each capacity.

OFF

234 567 8

During the FAN or COOL mode,and thermo-OFF or OFF in heating operation, set the opening of

linear expansion valve on indoor unit

Active

Inactive

During the FAN or COOL mode,and thermo-OFF

in heating operation, set the opening of linear expansion valve on indoor unit

Active Inactive

+1 SW5-7 Refrigerant amount shortage measure during heating operation (Refrigerant piping is long etc.) +2 SW5-8 Countermeasure against room temperature rise for indoor unit in FAN, COOL, and thermo-OFF (heating) mode.

Switch

Step

Function

The black square (■) indicates a switch position.

Operation in Each Switch Setting

ON OFF When to Set

Remarks

SW6 function switching

Outdoor unit

SW7 function switching

SW8 function switching

Switch of current limitation reading

in a different way

Restriction of maximum

frequency Ignore refrigerant filling

abnormality

Switching the target discharge

pressure (Pdm)

Switching (1) the target evaporation

temperature (ETm) Switching (2) the target evaporation

temperature (ETm)

Ignore current sensor

abnormality

Forced defrost

Silent mode/Demand Control

Selection (see next page)

Change of defrosting control

—

—— —

Enable

—— —

Enable

—

Forced defrost Normal

Demand Control

Enable (For high humidity)

Normal

Silent mode

Normal

Before turning the power on.

Can be set when off or during operation

Before turning the power on.

—

During compressor running in heating mode.

Can be set when off or during operation

OFF

234 567 8

—

OFF

23456

OFF

9-6. OUTDOOR UNIT INPUT/OUTPUT CONNECTOR

State (CN51)





Auto change over (CN3N)



SW1



SW2







CN51

5 4 3



















CN3N

2 3





 Distant control board  Relay circuit  External output adapter (PAC-SA88HA-E)  Outdoor unit control board

1: Error display lamp

2: Compressor operation lamp

X, Y: Relay (Coil standard of 0.9W or less for DC 12V) X, Y: Relay (DC1mA)

 Remote control panel  Relay circuit  External input adapter (PAC-SC36NA)  Outdoor unit control board

SW1 SW2

Heating

Validity of SW1

OFF

Cooling

Invalidity of SW1

 Lamp power supply  Procure locally  Max. 10m

 Relay power supply  Procure locally  Max. 10m

Silent Mode / Demand Control (CN3D)



SW1



SW2





The silent mode and the demand control are selected by switching the Dip switch 8-1 on outdoor controller board. It is possible to set it to the following power consumption (compared with ratings) by setting SW1, 2.

Outdoor controller board DIP SW8-1

Silent mode Demand control

OFF ON





CN3D

2 3





 Remote control panel  Relay circuit  External input adapter (PAC-SC36NA)  Outdoor unit control board

SW1 SW2

Heating

Validity of SW1

OFF

Cooling

Invalidity of SW1

 Relay power supply  Procure locally  Max. 10m



SW1 SW2 Function

ON OFF ON ON OFFONON

Silent mode operation

— OFF OFF

100%

75% 50%

(Normal)

(Stop)

9-7. HOW TO CHECK THE PARTS PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

Parts name

Thermistor (TH3) <Outdoor pipe>

Thermistor (TH4) <Dischatge> <Compressor>

Thermistor (TH6)

Low pressure saturated

temperature> Thermistor (TH7)

<Outdoor> Thermistor (TH8)

Fan motor (MF1, MF2)

Solenoid valve coil <Four-way valve> (21S4)

Motor for compressor (MC)

Check points

Disconnect the connector then measure the resistance with a tester. (At the ambient temperature 10~30)

Normal

TH4

TH3

TH6

TH7

TH8 +1

Refer to next page.

Measure the resistance between the terminals with a tester. (At the ambient temperature 20

Normal

1435 ± 150

Measure the resistance between the terminals with a tester. (Winding temperature 20)

160k~410k

4.3k~9.6k

39k~105k



)

Open or short

Abnormal

Open or short

Abnormal

+1 TH8 is internal thermistor of power module. (Y)

Solenoid valve coil <Bypass valve> (SV1)

Normal

0.330

Measure the resistance between the terminals with a tester. (At the ambient temperature 20)

Normal

1197 ± 10

Abnormal

Open or short

Abnormal

Open or short

Check method of DC fan motor (fan motor/outdoor controller circuit board)

Notes



· High voltage is applied to the connecter (CNF1, 2) for the fan motor. Pay attention to the service.

· Do not pull out the connector (CNF1, 2) for the motor with the power supply on. (It causes trouble of the outdoor controller circuit Self check



Symptom : The outdoor fan cannot turn around.

Fuse check

Check the fuse (F500) on outdoor multi controller board.

board and fan motor.)

Did the fuse blow?

Wiring contact check

Contact of fan motor connector (CNF1, 2)

Is there contact failure?

Power supply check (Remove the connector (CNF1, 2))

Measure the voltage in the outdoor controller circuit

Yes

Replace outdoor controller board (MULTI.B.) (C.B) and fan motor (MF1, 2).

Recover wiring.

board.

TEST POINT  : VDC (between 1 (+) and 4 (-) of the fan connector): VDC DC310-340V (Y)

: VDC (between 1 (+) and 4 (-) of the fan connector):

VDC DC280-340V (when ACTM stops), DC350V (when ACTM is operating) (V)

TEST POINT  : VCC (between 5 (+) and 4 (-) of the fan connector): VCC DC15V

Is the voltage normal?

Yes

Replace the fan motor.

Yes

Check the operation of fan. END

Replace outdoor

controller board.

Check the operation. END

Replace outdoor controller board.

Replace the fan motor.

9-8. HOW TO CHECK THE COMPONENTS

Low temperature thermistors

• Thermistor <Outdoor pipe> (TH3)

• Thermistor <Low pressure saturated temperature> (TH6)

• Thermistor <Outdoor> (TH7)

Thermistor R0 = 15k' ± 3% B constant = 3480 ± 2%

Rt =15exp{3480(

0: 15k' 10: 9.6k' 20: 6.3k' 25: 5.2k'

Medium temperature thermistor

• Heatsink temperature thermistor (TH8)

Thermistor R50 = 17k' ± 2% B constant = 4170 ± 3%

273+t – 273

30: 4.3k' 40: 3.0k'

)}

(Only VHMB)

Resistance (k)

-20-100 1020304050

Temperature ()

200

150

t =17exp{4170(

1 1

273+t – 323

)}

0: 180k' 25: 50k' 50: 17k' 70: 8k' 90: 4k'

High temperature thermistor

• Thermistor <Discharge/Compressor> (TH4)

Thermistor R120 = 7.465k' ± 2% B constant = 4057 ± 2%

t =7.465exp{4057(

20: 250k' 30: 160k' 40: 104k' 50: 70k' 60: 48k'

273+t – 393

)}

70: 34k' 80: 24k' 90: 17.5k' 100: 13.0k' 110: 9.8k'

Vout (V)

4.5

2.5

0.5

2.5 5 PRESSURE

(MPa)

MULTI CONTROLLER BOARD

5V DC

WHT

BLU

Vout

BLK

SENSOR

- : 5V (DC) - : Output Vout (DC)

63HS

100

Resistance (k)

500

400

300

200

Resistance (k)

100

MICRO COMPUTER

GND

25 50 75 100 110 125 

Temperature

50 75 100 120

Temperature ()

9-9. TEST POINT DIAGRAM Outdoor multi controller board

PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

<CAUTION> TEST POINT 1 is high voltage.

CN102

Connect to the M-P.B (Transmission power board)

CN40,CN41

Centralized control power supply/ For storing jumper connector selection

CNS2

Transmission wire of centralized control

CNS1

Indoor/ outdoor unit connecting wire

CN2

Connect to the outdoor power circuit board 1-5: Power circuit board → Transmitting signal to the multi controller board (0-5V DC) 2-5: Zero cross signal (0-5V DC)

3-4: Not used 6-5: 16V DC 7-5: 16V DC

SW8

Demand/Silent selection

SW1

Display selection (Self diagnosis)

SWU2, SWU1

Address setting

CNLVB (Only VHMB)

Connect to the outdoor noise filter circuit board (CN52C)1 - 6: DC12V

63L

Low pressure switch

CN3N

Input of demand control

63H

High pressure switch

CN3D

Input of demand control

SW2

Pump down

SW3

Test run

SW7

Forced defrost

SW4

Model select

CN51

External signal output

TH4 Thermistor

TH3 Thermistor

TH7/TH6 Thermistor

63HS

High pressure sensor

VFG (TEST POINT4)

(Voltage between left pins of PC511 and PC512, pin1 and pin2) : (Same as CNF1,2 7(+)–4(-))

VSP

(Voltage between pins of C515 and C516) : DC0V (when stopped) DC1–6.5V (when operated) (Same as CNF1,2 6(+)–4(-))

CNF1, 2

Connect to fan motors 1–4 : DC310V-340V (Y) : DC280V-350V (V)

5–4 : DC15V 6–4 : DC0–6.5V 7–4 : DC15V (when stopped)

DC0–15V pulse (when operated)

VDC (TEST POINT1)

(Voltage between pins of C510) : DC310V-DC340V (Y) : DC280V-DC350V (V) (Same as CNF1,2 1(+)–4(-))

CNAC

Power supply for multi controller board 220-240VAC

SV1

Bypass valve

21S4

Four-way valve

VCC (TEST POINT2)

(Voltage between pins of C82A) : DC15V (Same as CNF1,2 5(+)–4(-))

CNDC

DC310V–340V (Y) DC280V–DC350V (V) (1(+)–3(-))

Outdoor power circuit board PUMY-P100VHMB(-BS)

PUMY-P125VHMB(-BS) PUMY-P140VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P125VHMBR1(-BS) PUMY-P140VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMBR2(-BS)

Brief Check of POWER MODULE W Usually, they are in a state of being short-circuited if they are broken. Measure the resistance in the following points (connectors, etc.). If they are short-circuited, it means that they are broken.

1. Check of POWER MODULE

1.Check of DIODE circuit S - P1 , T - P1 , S - N1 , T - N1

2.Check of DIP-IPM P - U , P - V , P - W , N - U , N - V , N - W

CN2 Connect to the outdoor controller multi circuit board (CN2) 1-5:Transmitting signal to the outdoor controller circuit board (0~5V DC)

2-5:Zero cross signal (0~5V DC) 3-4:18V DC 6-5:16V DC 7-5:16V DC

CN3 Thermistor (TH8) <Heatsink>

CN5 Detection of primary current Connect to the outdoor noise filter circuit board (CN5)

CNDC 280V-350V DC (1+, 3–) Connect to the outdoor controller multi circuit board

TABS/T Connect to the outdoor noise filter circuit board Voltage among phases:220-240V AC

TABN1/SC-N1 Connect to the ACTM(-)

TABP1/SC-P1 Connect to 52C

CN4 Connect to the outdoor controller multi circuit board (CN4)

TABP2/SC-P2 Connect to the ACTM (P)

TABU/V/W Connect to the compressor (MC) Voltage among phases: 10V~180V AC

TABN2/SC-N2 Connect to the ACTM (N2)

Outdoor power circuit board PUMY-P100YHMB(-BS)

PUMY-P125YHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P125YHMBR1(-BS) PUMY-P140YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMBR2(-BS)

Brief check of POWER MODULE W Usually, each point is in a state of being short-circuited if they are broken. Measure the resistance in the following points (connectors, etc.). If they are short-circuited, it means that they are broken.

1. Check of POWER MODULE

1.Check of DIODE circuit L1 - P1 , L2 - P1 , L3 - P1 , L1 - N1 , L2 - N1 , L3 - N1

2.Check of IGBT circuit

P2 - U , P2 - V , P2 - W , N2 - U , N2 - V , N2 - W Note:The marks, L1 , L2 , L3 , N1 , N2 , P1, P2 , U , V and W shown in the diagram are not actually printed on the board.

CN5

Detection of primary current (Connect to the outdoor noise filter circuit board (CNCT))

TAB connecter on X52A Connect to the RS resistor

CN4

Connect to the outdoor controller circuit board (CN4)

CN7

Connect to the outdoor converter circuit board (CN7)

CN2 Connect to the outdoor controller circuit board (CN2) 1-5: Power circuit board

→ Transmitting

signal to the controller board (0-5V DC)

2-5: Zero cross signal (0-5V DC) 3-4: Not used

[ 5 : – 1, 2, 6, 7 : + ]

6-5: 16V DC 7-5: 16V DC

TB-U, TB-V, TB-W

Connect to the compressor (MC) Voltage among phases: 10V-400V AC

N2N1P2

TB-L1, TB-L2, TB-L3

Connect to the outdoor converter circuit board (L1-OU, L2-OU, L3-OU) 380V-415V AC

TB-N1

Connect to the smoothing capacitor

– and the CK

CB2 capacitor

TB-P2

Connect to the smoothing capacitor CB1

TB-C1

Connect to the smoothing capacitor

– , CB2 +

CB1

POWER MODULE

Outdoor converter circuit board PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

CK-OU

Connect to the CK capacitor

L1-IN, N-IN

Connect to the noise filter circuit board (LO1, No)

L1-A1

Connect to the ACL1

CN7

Connect to the outdoor power circuit board (CN7)

L1-A2, L2-A2, L3-A2

Connect to the ACL1, ACL2, ACL3

L1-OU, L2-OU, L3-OU

Connect to the outdoor power circuit board (TB-L1, L2, L3)

Transmission power board

PUMY-P100VHMB(-BS) PUMY-P125VHMB(-BS) PUMY-P140VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P125VHMBR1(-BS) PUMY-P140VHMBR1(-BS) PUMY-P100VHMBR2(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMBR2(-BS) PUMY-P100YHMB(-BS) PUMY-P125YHMB(-BS) PUMY-P140YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P125YHMBR1(-BS) PUMY-P140YHMBR1(-BS) PUMY-P100YHMBR2(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMBR2(-BS)

CN2

Connect to the outdoor multi controller board

1-2: 24–30V DC 3-4: 24–30V DC

CN1

Connect to the outdoor noise filter circuit board 1–3 : 220–240V AC

Outdoor noise filter circuit board PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

CN5 52C driving signal (Connect to the outdoor controller circuit board(CNLVB))

RS1

LO, NO Voltage of

CNAC2 220-240V AC (Connect to the outdoor controller circuit board (CNAC))

220-240V AC is output (Connect to the outdoor power circuit board)

CNAC1 220-240V AC (Connect to the M-NET power circuit board (M-P.B.))

EI Connect to the earth

E2 Connect to the earth

CN5 Primary current (Connect to the outdoor power circuit board (CN5))

LI, NI Voltage of 220-240V AC is input (Connect to the terminal block(TB1))

Outdoor noise filter circuit board PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

LI1, LI2, LI3, NI

CNAC1 AC220/230/240V

(Connect to the outdoor transmission power board(CN1))

GD1

Connect to the earth

POWER SUPPLY

LI1-LI2/LI2-LI3/LI3-LI1 : AC380/400/415V input LI1-NI/LI2-NI/LI3-NI : AC220/230/240V input (Connect to the terminal block (TB1))

CNAC2 AC220/230/240V

(Connect to the outdoor controller circuit board (CNAC))

CNDC

(Connect to the outdoor controller circuit board (CNDC))

CNL Connect to the ACL4

NO Connect to the outdoor converter circuit board. (N-IN)

GD3

Connect to the earth

CNCT Primary current

(Connect to the outdoor power circuit board (CN5))

LO1, LO2, LO3 POWER SUPPLY

LO1-LO2/LO2-LO3/LO3-LO1 : AC380/400/415V OUTPUT (Connect to the outdoor converter circuit board and ACL (L1-IN, ACL2, ACL3))

Active filter module PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

Connect to the L1, L2 Connect to the DCL (Reactor)

outdoor power

circuit board

(TABP2)

N1 Non-connect

Upper side

Connect to the outdoor power circuit board (TABP1)

Connect to the outdoor

–

power circuit board (TABN1)

Connection and internal circuit diagram

(+)

(

Lower side

N2 Non-connect

Connect to the outdoor power circuit board (CNAF)

1 : GND 2-1 : 15V DC 3-1 : Control signal 4, 5 : Not used 6-1 : Control signal

DCL

L1 L2

)

ACTM

N1 N2

lo Connect to the outdoor power circuit board (TABN2)

Load

Tester check points of Active ﬁ lter module

Error condition Normal value (reference)

(–) and Io open less than 1

(–) and L2

P and L2

P and Io

L2 and Io

The symptom when the unit is in open error condition is described to determine open error by tester check.

short 100k" ~ 1M

open

short 100k" ~ 1M

open

short 100k" ~ 1M

open

short 100k" ~ 1M

open

The unit does not operate (can not be switched ON)

The breaker operates

The unit does not operate (can not be switched ON)

The breaker operates

The unit does not operate (can not be switched ON)

The breaker operates

The unit does not operate (can not be switched ON)

The breaker operates

The unit does not operate (can not be switched ON)

Symptom when the unit is in trouble

4220 Abnormal stop (9-10. No.189 "ACTM error" display)

9-10. OUTDOOR UNIT FUNCTIONS

1516171819

202122

232425

SW1 setting

12345678

00000000

10000000

01000000

11000000

00100000

10100000

01100000

11100000

00010000

10010000

01010000

11010000

00110000

10110000

01110000

11110000

00001000

10001000

01001000

11001000

00101000

10101000

01101000

11101000

00011000

10011000

01011000

11011000

00111000

10111000

01111000

Relay output display

Check display

Indoor unit check status

Protection input

Abnormality delay display 1

Abnormality delay display 2

Abnormality delay display 3

Abnormality delay history 1

Abnormality delay history 2

Abnormality delay history 3

Abnormality code history 2

Abnormality code history 3

Abnormality code history 4

Abnormality code history 5

Abnormality code history 6

Abnormality code history 7

Abnormality code history 8

Abnormality code history 9

Cumulative time

Outdoor unit operation display

Indoor unit operation mode

Indoor unit operation display

Capacity code (No. 1 indoor unit)

Capacity code (No. 2 indoor unit)

Capacity code (No. 3 indoor unit)

Capacity code (No. 4 indoor unit)

Capacity code (No. 5 indoor unit)

Compressor operation

No.1 unit check

52C

No.2 unit

check

21S4

No.3 unit check

SV1

No.4 unit check

Over capacity

No.7 unit check

(SV2)

No.5 unit check

No.6 unit check

TH6 abnormality delay

Lighting always

No.8 unit check

TH8 abnormality

ON: light on OFF: light off

•When abnormality occurs, check display.

Check: light on Normal: light off

Display input microprocessor

protection (abnormality)

Display all abnormalities

remaining in abnormality

delay

Display all abnormalities

remaining in abnormality

delay history

•Display abnormalities up to

present (including abnormality

terminals)

•History record in 1 is the

latest; records become older

in sequence; history record

in 10 is the oldest.

Display of cumulative

compressor operating time

Thermo ON : light on Thermo OFF : light off

•Display of indoor unit

capacity code

•The No. 1 unit will start from

the address with the lowest

number

Notes

Alternating display of addresses

0000-9999 and abnormality code

(including abnormality delay code)

0~9999(unit: 1-hour)

0~9999(unit: 10-hour)

0~255

Excitation Current

No.1 unit mode

No.1 unit operation

Restart after 3 minutes

No.2 unit mode

No.2 unit operation

Compressor operation

No.3 unit mode

No.3 unit operation

Abnormality(detection)

No.4 unit mode

No.4 unit operation

No.5 unit mode

No.5 unit operation

No.6 unit mode

No.6 unit operation

No.7 unit mode

No.7 unit operation

No.8 unit mode

No.8 unit operation

0000~9999 (Alternating display of addresses and error code)

Display mode

Display on the LED1, 2 (display data)

No.

Delay code

1202

1205

1211

1214

1221

Delay code

1402

1600

1601

4320

4330

4350

Abnormality delay

Discharge/Compressor temperature abnormality

Discharge/Compressor temperature sensor (TH4) abnormality

Outdoor pipe temperature sensor (TH3) abnormality

Heatsink thermistor (TH8) abnormality

Outside air temperature sensor (TH7) abnormality

Abnormality delay

High-pressure abnormality

Pressure sensor (63HS) abnormality

Over charge refrigerant abnormality

Insufficient refrigerant abnormality

Heatsink temperature abnormality

Power module abnormality

Abnormality in the

number of indoor units

High-pressure

abnormality delay

High-pressure

abnormality delay

High-pressure

abnormality

Address double

setting abnormality

TH4

abnormality

delay

TH4

abnormality delay

Current sensor

abnormality

TH3 abnormality

delay

Saturation temperature of suction pressure

sensor (TH6) abnormality

Frequency converter insufficient

wiring voltage abnormality

Cooling : light on Heating: light flashing

Stop fan: light off

Abnormality code history 10

(the oldest)

Abnormality code history 1

(the latest)

Indoor unit

address error

Outdoor unit

address error

Current sensor

abnormality delay

Current sensor

abnormality delay

Heatsink

overheating

Over current interception

TH4 abnormality

TH3 abnormality

Outdoor fan rotantial

frequency abnormality

TH7 abnormality

Heatsink

overheating delay

Heatsink

overheating delay

SHd(low discharge temperature)

abnormality

SHd(low discharge temperature)

abnormality delay

Over current interception

delay

Over current

interception delay

Discharge/Compressor

temperature

abnormality

Indoor unit

capacity error

Discharge/Compressor

temp.

abnormality delay

Voltage abnormality

delay

Discharge/Compressor

temp.

abnormality delay

Voltage abnormality

delay

Insufficient refrigerant

amount abnormality

Insufficient refrigerant

amount abnormality delay

Frozen protection delay

Insufficient refrigerant

amount abnormality delay

Frozen protection delay

TH3 abnormality

delay

Power module

abnormality delay

Power module

abnormally delay

Low-pressure

abnormality

Outdoor fan rotantial fre-

quency abnormality delay

Low-pressure

abnormality delay

TH6 abnormality

delay

Outdoor fan rotantial

frequency abnormality delay

Low-pressure

abnormality delay

63HS abnormality

Current sensor

open/short

TH7 abnormality

delay

63HS abnormality

delay

Current sensor

open/short delay

TH7 abnormality

delay

63HS abnormality

delay

Current sensor

open/short delay

start over current

interception abnormality

serial communication

abnormality

start over current inter-

ception abnormality delay

communication(POWER

BOARD)abnormality delay

start over current inter-

ception abnormality delay

communication(POWER

BOARD)abnormality delay

start over current inter-

ception abnormality delay

SHd(low discharge temperature)

abnormality delay

Voltage abnormality

start over current inter-

ception abnormality delay

SW:setting

0....OFF

1....ON

3132333435

38394041424344

SW1 setting

12345678

111110 00

00000100

10000100

01000100

11000100

00100100

10100100

01100100

11100100

00010100

10010100

01010100

11010100

00110100

10110100

01110100

11110100

00001100

IC1 operation mode

IC2 operation mode

IC3 operation mode

IC4 operation mode

IC5 operation mode

OC operation mode

External connection status

Communication demand capacity

Number of compressor ON/OFF

Compressor operating current

Input current of outdoor unit

Thermo ON operating time

Total capacity of thermo on

Number of indoor units

DC bus voltage

State of LEV control

State of compressor

frequency control 1

State of compressor

frequency control 2

•Display of indoor unit

operating mode

Light on/light off

Input: light off No input: light on

Display of communication demand capacity

Notes

0~255

0000~9999 (unit : o10)

0~999.9 (A)

0000~9999 (unit : o10)

0~255

0~255 (Max. 12 unit)

0~999.9 (V)

OFF

Td over heat

prevention

Discharge

pressure

control

Heatsink

over heat pre-

vention control

SHd declease

prevention

Discharge/

Compressor

temp.control

Secondary

current control

Min.Sj

correction

depends on Td

LEV opening

correction

depends on Pd

Discharge

temp.(heating)

Backup

LEV opening

correction

depends on Td

Correction of

high compression

ratio prevention

Freeze

prevention

control

Fan

Cooling

thermo

Cooling

thermo

OFF

Heating

thermo

Heating

thermo

OFF

ON/OFF

Heating/Cooling

Abnormal/Normal

DEFROST/NO

Refrigerant pull back/no

Excitation current/no

P96:Autochange

over fixed mode

CN3N1-2 input

P95:Undefined

CN3S1-2 input

P94:Demand

CN3D1-3 input

P93:Silent

CN3D1-2 input

3-min.delay/no

P97:Autochange

over permission

CN3N1-3 input

Display mode

Display on the LED1, 2 (display data)

No.

10001100

01001100

11001100

Protection input

State of compressor frequency(Hz) control (Words)

Content

Discharge pressure control Hz control by pressure limitation

Discharge/Compressor temperature control

Hz control by discharge/compressor temperature limitation

Max.Hz control

Max.Hz limitation when power supply on

Hz control by bypass valve

Abnormal rise of Pd control Control that restrains abnormal rise of discharge pressure

Heatsink over heat prevention control Heatsink over heat prevention control

Secondary current control

Input current control Input current control

Hz correction of receipt voltage decrease prevention

Max.Hz correction control due to voltage decrease

Hz restrain of receipt voltage change Max.Hz correction control due to receipt voltage change

The second current value when

microprocessor of POWER

BOARD abnormality is detected

The radiator panel temperature

when microprocessor of POWER

BOARD abnormality is detected

0~999.9 [Arms]

-99.9~999.9 (Short/Open:-99.9 or 999.9)

Frozen protection

TH6 abnormality

Power module

abnormality

Discharge

pressure(heating)

Backup

SV control

Max. Hz

control

Input current

control

Frequency restrain

of receipt voltage

change

Max. Hz

control

545758

596061

636465

737475

777880

818283

SW1 setting

12345678

00101100

10101100

01101100

10011100

01011100

110 11100

00111100

10 111100

011111 00

11111100

00000010

10000010

01000010

10100010

01100010

11100010

00010010

10010010

01010010

11010010

00110010

10110010

01110010

00001010

10001010

01001010

11001010

00101010

10101010

Indoor uint check status

Indoor unit operation mode

Indoor unit operation display

IC6 operation mode

IC7 operation mode

IC8 operation mode

IC9 operation mode

IC10 operation mode

IC11 operation mode

IC12 operation mode

Operational frequency

Target frequency

Outdoor fan control step number

IC1 LEV Opening pulse

IC2 LEV Opening pulse

IC3 LEV Opening pulse

IC4 LEV Opening pulse

IC5 LEV Opening pulse

High-pressure sensor (Pd) kgf/cm

TH4 (Td) °C

TH6 (ET) °C

TH7 (Outdoor-temp.) °C

TH3 (Outdoor pipe) °C

TH8 (Power module) °C

IC1 TH23 (Gas) °C

IC2 TH23 (Gas) °C

IC3 TH23 (Gas) °C

IC4 TH23 (Gas) °C

IC5 TH23 (Gas) °C

Display of actual operating frequency

Display of target frequency

Display of number of outdoor

fan control steps (target)

Display of opening pulse of

indoor LEV

Display of outdoor subcool

(SC) data and detection data

from high-pressure sensor and

each thermistor

Notes

0~FF (16 progressive)

0~255

0~15

0~2000

Display mode

Display on the LED1, 2 (display data)

-99.9 ~ 999.9

(When the indoor unit is not connected,it is displayed as"0".)

No.

No.9 unit check

No.9 unit mode

No.9 unit operation

OFF

No.10 unit check

No.10 unit mode

No.10 unit operation

Fan

No.11 unit check

No.11 unit mode

No.11 unit operation

Cooling

thermo

No.12 unit check

No.12 unit mode

No.12 unit operation

Cooling

thermo

OFF

Check: light on Normal: light off

COOL/DRY: light on

HEAT: light flashing

FAN/STOP: light off

Thermo ON: light on Thermo OFF: light off

Heating

thermo

Heating

thermo

OFF

Display of indoor unit

operation mode

Display of target subcool data

Display of indoor SC/SH data

Display of target subcool step data

Display of all control target data

Display on the LED1, 2 (display data)

-99.9 ~ 999.9

during heating: subcool (SC)/during cooling: superheat (SH)

0.0 ~ 20.0

-99.9 ~ 999.9

Pdm (0.0 ~ 30.0)

ETm (-2.0 ~ 23.0)

SCm (0.0 ~ 20.0)

SCm/SHm (0.0~20.0)

100

101

102

103

105

106

107

108

109

110

111

112

IC1 TH22 (Liquid) °C

IC2 TH22 (Liquid) °C

IC3 TH22 (Liquid) °C

IC4 TH22 (Liquid) °C

IC5 TH22 (Liquid) °C

IC1 TH21 (Intake) °C

IC2 TH21 (Intake) °C

IC3 TH21 (Intake) °C

IC4 TH21 (Intake) °C

IC5 TH21 (Intake) °C

Outdoor SC (cooling) °C

Target subcool °C

IC1 SC/SH °C

IC2 SC/SH °C

IC3 SC/SH °C

IC4 SC/SH °C

IC5 SC/SH °C

Discharge superheat (SHd) °C

Target Pd display (heating) kgf/%

Target ET display (cooling) °C

Target outdoor SC (cooling) °C

Target indoor SC/SH (IC1) °C

Target indoor SC/SH (IC2) °C

Target indoor SC/SH (IC3) °C

Target indoor SC/SH (IC4) °C

Target indoor SC/SH (IC5) °C

678

Display mode

No.

Notes

SW1 setting

12345678

01101010

11101010

00011010

10011010

01011010

11011010

00111010

10111010

01111010

11111010

00000110

10000110

01000110

11000110

00100110

10100110

01100110

11100110

10010110

01010110

11010110

00110110

10110110

01110110

11110110

00001110

-99.9 ~ 999.9

(When the indoor unit is not connected, it is displayed as “0”.)

-99.9 ~ 999.9

Display of outdoor subcool (SC) data

and detection data from high-pressure

sensor and each thermistor

Display of detection data from

high-pressure sensor and

each thermistor

Display of opening pulse of indoor

LEV at time of abnormailty delay

Display of actual frquency at time of abnormality delay

Display of fan step number at time of abnormailty delay

Display on the LED1, 2 (display data)

0.0 ~ 711.0 [PSIG]

0 ~ 2000

113

114

115

116

117

118

119

121

122

123

124

125

126

128

129

130

131

132

133

134

135

136

137

138

139

140

141

Target indoor SC/SH (IC6) °C

Target indoor SC/SH (IC7) °C

Target indoor SC/SH (IC8) °C

Target indoor SC/SH (IC9) °C

Target indoor SC/SH (IC10) °C

Target indoor SC/SH (IC11) °C

Target indoor SC/SH (IC12) °C

TH4 (Td) °F

TH3 (Outdoor pipe) °F

TH6 (ET) °F

TH7 (Outdoor temp.)

°F

High pressure sensor (Pd) PSIG

TH8 (Power module) °F

IC1 LEV opening pulse abnormality delay

IC2 LEV opening pulse abnormality delay

IC3 LEV opening pulse abnormality delay

IC4 LEV opening pulse abnormality delay

IC5 LEV opening pulse abnormality delay

IC6 LEV opening pulse abnormality delay

IC7 LEV opening pulse abnormality delay

IC8 LEV opening pulse abnormality delay

IC9 LEV opening pulse abnormality delay

IC10 LEV opening pulse abnormality delay

IC11 LEV opening pulse abnormality delay

IC12 LEV opening pulse abnormality delay

Actual frequency of abnormality delay

Fan step number at time of abnormailty delay

678

Display mode

No.

Notes

SW1 setting

12345678

10001110

01001110

11001110

00101110

10101110

01101110

11101110

10011110

01011110

11011110

00111110

10111110

01111110

00000001

10000001

01000001

11000001

00100001

10100001

01100001

11100001

00010001

10010001

01010001

11010001

00110001

10110001

SCm/SHm (0.0 ~ 20.0)

-99.9 ~ 999.9 [°F]

0 ~ FF (16 progressive)

0 ~ 15

Display of all control target data

142

143

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

SW1 setting

12345678

01110001

11110001

10001001

01001001

11001001

00101001

10101001

01101001

11101001

00011001

10011001

01011001

11011001

00111001

10111001

01111001

111110 01

00000101

01010101

11010101

00110101

10110101

01110101

11110101

00001101

10001101

01001101

11001101

00101101

10101101

01101101

11101101

00011101

High-pressure sensor data at time of abnormality delay

kgf

OC SC (cooling) at time of abnormality delay °C

TH4 sensor data at time of abnormality delay °C

TH6 sensor data at time of abnormality delay °C

TH3 sensor data at time of abnormality delay °C

TH8 sensor data at time of abnormality delay °C

IC1 SC/SH at time of abnormality delay °C

IC2 SC/SH at time of abnormality delay °C

IC3 SC/SH at time of abnormality delay °C

IC4 SC/SH at time of abnormality delay °C

IC5 SC/SH at time of abnormality delay °C

IC6 SC/SH at time of abnormality delay °C

IC7 SC/SH at time of abnormality delay °C

IC8 SC/SH at time of abnormality delay °C

IC9 SC/SH at time of abnormality delay °C

IC10 SC/SH at time of abnormality delay °C

IC11 SC/SH at time of abnormality delay °C

IC12 SC/SH at time of abnormality delay °C

ROM version monitor

ROM type

Check sum mode

IC1 LEV opening pulse at time of abnormality delay

IC2 LEV opening pulse at time of abnormality delay

IC3 LEV opening pulse at time of abnormality delay

IC4 LEV opening pulse at time of abnormality delay

IC5 LEV opening pulse at time of abnormality delay

IC6 LEV opening pulse at time of abnormality delay

IC7 LEV opening pulse at time of abnormality delay

IC8 LEV opening pulse at time of abnormality delay

IC9 LEV opening pulse at time of abnormality delay

IC10 LEV opening pulse at time of abnormality delay

IC11 LEV opening pulse at time of abnormality delay

IC12 LEV opening pulse at time of abnormality delay

234 5 6

Display on the LED1, 2 (display data)

Display of data from high-pressure sensor,

all thermistors, and SC/SH at time of

abnormality delay

Display of version data of ROM

Display of ROM type

Display of check sum code of ROM

Display of opening pulse of indoor LEV

at time of abnormality

-99.9 ~ 999.9

0 ~ 2000

No.

Display mode Notes

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

211

212

213

214

215

216

217

SW1 setting

12345678

10011101

01011101

11011101

00111101

10111101

01111101

11111101

00000011

10000011

01000011

11000011

00100011

10100011

01100011

11100011

00010011

10010011

01010011

11010011

00110011

10110011

11001011

00101011

10101011

01101011

11101011

00011011

10011011

Actual frequency of abnormality

Fan step number at time of abnormality

High-pressure sensor data at time of abnormality

OC SC (cooling) at time of abnormality

4420 Error history

TH4 sensor data at time of abnormality

TH6 sensor data at time of abnormality

TH3 sensor data at time of abnormality

TH8 sensor data at time of abnormality

IC1 SC/SH at time of abnormality

IC2 SC/SH at time of abnormality

IC3 SC/SH at time of abnormality

IC4 SC/SH at time of abnormality

IC5 SC/SH at time of abnormality

IC6 SC/SH at time of abnormality

IC7 SC/SH at time of abnormality

IC8 SC/SH at time of abnormality

IC9 SC/SH at time of abnormality

IC10 SC/SH at time of abnormality

IC11 SC/SH at time of abnormality

IC12 SC/SH at time of abnormality

IC6 Capacity code

IC7 Capacity code

IC8 Capacity code

IC9 Capacity code

IC10 Capacity code

IC11 Capacity code

IC12 Capacity code

23456

Display on the LED1, 2 (display data)

Display of actual frequency at time of abnormality

Display of fan step number at time of abnormality

Display of data from high-pressure sensor at time of abnormality

Display of SC data at time of abnormality

Display of data from high-pressure sensor,

all thermistors, and SC/SH at time of

abnormality

Display of indoor unit capacity code

0 ~ FF (16progressive)

0 ~ 15

-99.9 ~ 999.9

0 ~ 255

No.

Display mode Notes

CT sensor

disconn-

ection

Under

voltage

Over

Voltage

ACTM

error

Display of indoor SC/SH data

Display on the LED1, 2 (display data)

234 5 6

-99.9 ~ 999.9

Display of opening pulse of indoor LEV

0 ~ 2000

Display if detection data from each indoor

thermistor

-99.9 ~ 999.9

Display mode Notes

IC6 SC/SH

IC7 SC/SH

IC8 SC/SH

IC9 SC/SH

11011011

00111011

219

220

10111011

221

01011011

12345678

SW1 setting

No.

218

IC10 SC/SH

IC11 SC/SH

IC12 SC/SH

11111011

01111011

00000111

222

223

224

225

IC6 LEV opening pulse

IC7 LEV opening pulse

IC8 LEV opening pulse

IC9 LEV opening pulse

IC10 LEV opening pulse

IC11 LEV opening pulse

IC12 LEV opening pulse

10100111

229

01100111

230

11100111

231

11000111

10000111

01000111

00100111

226

227

228

IC6 TH23 (Gas) °C

00010111

232

IC7 TH23 (Gas) °C

10010111

233

IC8 TH23 (Gas) °C

01010111

234

IC9 TH23 (Gas) °C

11010111

235

236

IC10 TH23 (Gas) °C

IC11 TH23 (Gas) °C

IC12 TH23 (Gas) °C

IC6 TH22 (Liquid) °C

IC7 TH22 (Liquid) °C

11110 111

01110111

00110111

10110111

237

238

239

00001111

240

IC8 TH22 (Liquid) °C

IC9 TH22 (Liquid) °C

IC10 TH22 (Liquid) °C

11001111

10001111

01001111

241

242

243

IC11 TH22 (Liquid) °C

IC12 TH22 (Liquid) °C

IC6 TH21 (Intake) °C

IC7 TH21 (Intake) °C

IC8 TH21 (Intake) °C

11101111

01101111

246

247

00 011111

248

00101111

244

10101111

245

IC9 TH21 (Intake) °C

IC10 TH21 (Intake) °C

IC11 TH21 (Intake) °C

110 11111

10 011111

01 011111

249

250

251

IC12 TH21 (Intake) °C

00 111111

252

ELECTRICAL WIRING

This chapter provides an introduction to electrical wiring for the CITY MULTI-S series, together with notes concerning power wiring, wiring for control (transmission wires and remote controller wires), and the frequency converter.

10-1. OVERVIEW OF POWER WIRING

(1) Use a separate power supply for the outdoor unit and indoor unit. (2) Bear in mind ambient conditions (ambient temperature, direct sunlight, rain water,etc.) when proceeding with the wiring and connections. (3) The wire size is the minimum value for metal conduit wiring. The power cord size should be 1 rank thicker consideration of voltage drops.

Make sure the power-supply voltage does not drop more than 10 %.

(4) Specific wiring requirements should adhere to the wiring regulations of the region. (5) Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible cord (design 60245 IEC57).

For example, use wiring such as YZW.

(6) Install an earth longer than other cables.

Warning:

· Be sure to use specified wires to connect so that no external force is imparted to terminal connections. If connections are not fixed firmly,

it may cause heating or fire.

· Be sure to use the appropriate type of overcurrent protection switch. Note that generated overcurrent may include some amount of direct

current.

Caution:

· Some installation site may require attachment of an earth leakage breaker. If no earth leakage breaker is installed, it may cause an electric

shock.

· Do not use anything other than breaker and fuse with correct capacity. Using fuse and wire or copper wire with too large capacity may cause a

malfunction of unit or fire.

Be sure to install N-Line. Without N-Line, it could casue damage to the unit.

10-2. WIRE DIAMETER AND MAIN POWER SWITCH CAPACITY

10-2-1. Wiring diagram for main power supply PUMY-P100/125/140VHMB(-BS) PUMY-P100/125/140VHMBR1(-BS) PUMY-P100/125/140VHMBR2(-BS)

Breaker for Wiring

Power supply single phase 50Hz 220-230-240V 60Hz 220V

and Current Leakage

Breaker for Wiring and Current Leakage

Outdoor unit

Grounded

Pull box

Indoor unit

Grounded

PUMY-P100/125/140YHMB(-BS) PUMY-P100/125/140YHMBR1(-BS) PUMY-P100/125/140YHMBR2(-BS)

Breaker for Wiring

Power supply (3phase 380-400-415V, 50Hz)

Power supply single phase 50Hz 220-230-240V

and Current Leakage

Breaker for Wiring and Current Leakage

Outdoor unit

Grounded

Pull box

Indoor unit

Grounded

10-2-2. Power supply wire diameter and capacity PUMY-P100/125/140VHMB(-BS) PUMY-P100/125/140VHMBR1(-BS) PUMY-P100/125/140VHMBR2(-BS)

Model

Outdoor Unit

Indoor Unit

P100-140

Power Supply

~/N AC 220/230/240V 50Hz ~/N AC 220V 60Hz ~/N AC 220/230/240V 50Hz ~/N AC 220V 60Hz

Minimum Wire Thickness (mm2)

Main Cable

5.5(6)

1.5

Branch

–

1.5

Ground

5.5(6)

1.5

*1. A breaker with at least 3.0mm contact separation in each pole shall be provided. Use earth leakage breaker (NV). *2. Max. Permissive system Impedance : 0.22(")

Breaker for

Wiring*1

32 A

15 A

Breaker for Current Leakage

32 A 30 mA 0.1 sec. or less

15 A 30 mA 0.1 sec. or less

PUMY-P100/125/140YHMB(-BS) PUMY-P100/125/140YHMBR1(-BS) PUMY-P100/125/140YHMBR2(-BS)

Minimum Wire Thickness (mm )

Main Cable

1.5

Branch

1.5

Model Outdoor Unit

Indoor Unit

Power Supply

P100-140 –

3N~ AC380/400/415V, 50Hz

~/NAC220/230/240V, 50Hz

*1. A breaker with at least 3.5mm contact separation in each pole shall be provided. Use earth leakage breaker (NV).

Ground

1.5

Breaker for

Wiring*1

16 A 15 A

Breaker for Current

Leakage 16 A 30 mA 0.1 sec. or less 15 A 30 mA 0.1 sec. or less

10-3. DESIGN FOR CONTROL WIRING

Please note that the types and numbers of control wires needed by the CITY MULTI-S series will depend on the remote controllers and whether they are linked with the system.

10-3-1. Selection number of control wires

M-NET remote controller

Remote controller used in system control operations.

Use

Remote controller → indoor unit

Wires connecting → indoor units

Wires connecting → indoor units with outdoor unit

Wires connecting → outdoor units

Transmission

wires

10-3-2. Control signal wires

Transmission wires

• Types of transmission cables : Shielding wire CVVS or CPEVS.

• Cable diameter : More than 1.25E

• Maximum wiring length : Within 200 m

10-3-3. M-NET Remote controller wiring

Kind of remote control cable Shielding wire MVVS

Cable diameter 0.5 to 1.25E

Remarks

When 10m is exceeded, use cable with the same specifications as 10-3-2. Control signal wires.

• Group operation involving different refrigerant systems.

• Linked operation with upper control system.

2 wires (non-polar)

10-3-4. MA Remote control cables

Kind of remote control cable 2-core cable (unshielded) Cable diameter 0.3 to 1.25E

10-4. SYSTEM SWITCH SETTING

In order to identify the destinations of signals to the outdoor units, indoor units, and remote controller of the MULTI-S series, each microprocessor must be assigned an identification number (address). The addresses of outdoor units, indoor units, and remote controller must be set using their settings switches. Please consult the installation manual that comes with each unit for detailed information on setting procedures.

10-5. EXAMPLE EXTERNAL WIRING DIAGRAM FOR A BASIC SYSTEM

10-5-1. Example using a M-NET remote controller

Breaker for Wiring

Power supply 3 phase 4 wire 50Hz 380-400-415V

Power supply Single phase 50Hz 220-230-240V

and Current Leakage

15A Breaker for Wiring and Current Leakage

:1.6mm × 2

Outdoor unit

1.25mm

Pull box

× 2

Grounded

Indoor unit

0.5~1.25mm

× 2

Group operation

Remote controller wire

10-6. METHOD FOR OBTAINING ELECTRICAL CHARACTERISTICS WHEN A CAPACITY

AGREEMENT IS TO BE SIGNED WITH AN ELECTRIC POWER COMPANY

The electrical characteristics of connected indoor unit system for air conditioning systems, including the MULTI-S series, will depend on the arrangement of the indoor and outdoor units. First read the data on the selected indoor and outdoor units and then use the following formulas to calculate the electrical characteristics before applying for a capacity agreement with the local electric power company.

10-6-1. Obtaining the electrical characteristics of a CITY MULTI-S series system

(1) Procedure for obtaining total power consumption

Page numbers in this technical manual Power consumption

Total power consumption of each indoor unit

*1 Power consumption of outdoor unit

Total power consumption of system

*1 Please note that the power consumption of the outdoor unit will vary depending on the total capacity of the selected

indoor units.

(2) Method of obtaining total current

Total current through each indoor unit

*2 Current through outdoor unit Standard capacity table— Refer to 5-2.

Total current through system

*2 Please note that the current through the outdoor unit will vary depending on the total capacity of the selected indoor units.

See the technical manual of each indoor unit Standard capacity table— Refer to 5-2. See the technical manual of each indoor unit

Page numbers in this technical manual Subtotal See the technical manual of each indoor unit

See the technical manual of each indoor unit

1 2

1+2 <kW>

1 2

1+2 <A>

(3) Method of obtaining system power factor

Use the following formula and the total power and current obtained in parts 1 and 2 on the above tables to calculate the system power factor.

System power factor =

(Total system power consumption)

(Total system current × voltage)

o 100%

10-6-2. Applying to an electric power company for power and total current

Calculations should be performed separately for heating and cooling employing the same methods; use the largest resulting value in your application to the electric power company.

11 REFRIGERANT PIPING TASKS

11-1. REFRIGERANT PIPING SYSTEM



Line-Branch Method

Connection Examples (Connecting to 4 Indoor Units)

Permissible

Length

Permissible High/

Low Difference

Total Piping Length

Farthest Piping Length

Farthest Piping Length After First Branch

High/Low Difference in Indoor/Outdoor Section

High/Low Difference in Indoor/Indoor Section

■ Selecting the Refrigerant Branch Kit

■ Select Each Section of Refrigerant Piping

(1) Section From Outdoor Unit to First Branch (A) (2) Sections From Branch to Indoor Unit (a,b,c,d) (3) Section From Branch to Branch (B,C)

Select the size from the table to the right.

Each Section of Piping



A+B+C+a+b+c+d  120m

(L)

A+B+C+d  80m

(1)

B+C+d  50m

(H)

50 meters or less (If the outdoor unit is lower, 20 meters or less)

(h)

12 meters or less

Use an optional branch piping kit (CMY-Y62-G-E). (1) Refrigerant Piping Diameter In Section

From Outdoor Unit to First Branch (Outdoor Unit Piping Diameter)

PUMY-P100~140

(3) Refrigerant Piping Diameter In Section From Branch to Branch

Liquid Line (mm) Gas Line (mm)

B C



Piping Diameter (mm)Model

Liquid Line

Gas Line

b c



W9.52 W15.88

W15.88W9.52

(2) Refrigerant Piping Diameter In Section From Branch to Indoor Unit (Indoor Unit Piping Diameter)

Model number

50 or lower

63 to 140



Outdoor Unit

First Branch

Indoor unit

Piping Diameter (mm)

Liquid Line

Gas Line

Liquid Line

Gas Line

W6.35 W12.7 W9.52 W15.88

■ Additional refrigerant charge

• Refrigerant of 3kg equivalent to 50m total extended piping length is already included when the outdoor unit is shipped. Thus, if the total extended piping length is 50m or less, there is no need to charge with additional refrigerant.

• If the total extended piping length exceeds 50m, calculate the required additional refrigerant charge using the procedure shown on the right.

• If the calculated additional refrigerant charge is a negative amount, do not charge with any refrigerant.

Additional refrigerant charge

<Example> Outdoor model : 125 Indoor 1 : 63 A : W9.52 10m a : W9.52 15m

2 : 40 B : W9.52 10m b : W6.35 10m 3 : 25 C : W9.52 10m c : W6.35 10m 4 : 20 d : W6.35 20m The total length of each liquid line is as follows;

W9.52 : A + B + C + a = 10 + 10 + 10 + 15 = 45m W6.35 : b + c + d = 10 +10 + 20 = 40m

<Calculation example> Additional refrigerant charge = 45 × 0.06 + 40 × 0.024 – 3.0 = 0.7kg (rounded up)

(kg)

Liquid pipe size Total length of W9.52 × 0.06

(m) × 0.06 (kg/m)

Liquid pipe size Total length of W6.35 × 0.024

(m) × 0.024 (kg/m)

Refrigerant amount for outdoor unit

–

At the conditions below:

3.0kg



Header-Branch Method

Connection Examples (Connecting to 4 Indoor Units)

Permissible

Length

Permissible High/

Low Difference

Total Piping Length

Farthest Piping Length

Farthest Piping Length After First Branch

High/Low Difference in Indoor/Outdoor Section

High/Low Difference in Indoor/Indoor Section

■ Selecting the Refrigerant Branch Kit

■ Select Each Section of Refrigerant Piping

(1) Section From Outdoor Unit to First Branch (A) (2) Sections From Branch to Indoor Unit (a,b,c,d)

Select the size from the table to the right.

Each Section of Piping

A+a+b+c+d  120m

(L)

A+d  80m

(1)

d is 30 meters or less

(H)

50 meters or less (If the outdoor unit is lower, 20 meters or less)

(h)

12 meters or less

Please select branching kit, which is sold separately, from the table below. (The kit comprises sets for use with liquid pipes and for use with gas pipes.)

(1) Refrigerant Piping Diameter In Section From Outdoor Unit to First Branch (Out door Unit Piping Diameter)

PUMY-P100-140



Branch header (4 branches)

CMY-Y64-G-E



Piping Diameter (mm)Model

Liquid Line

Gas Line



Branch header (8 branches)

CMY-Y68-G-E

(2) Refrigerant Piping Diameter In Section From Branch to Indoor Unit (Indoor Unit Piping Diameter)

W9.52 W15.88

50 or lower

63 to 140

Outdoor Unit

First Branch

Indoor unit

Piping Diameter (mm)Model number

Liquid Line

Gas Line

Liquid Line

Gas Line

W6.35 W12.7 W9.52 W15.88

■ Additional refrigerant charge

• If the total extended piping length exceeds 50m, calculate the required additional refrigerant charge using the procedure shown on the right.

• If the calculated additional refrigerant charge is a negative amount, do not charge with any refrigerant.

Additional refrigerant charge

<Example> Outdoor : 125 Indoor 1 : 63 A : W9.52 30m a : W9.52 15m

2 : 40 b : W6.35 10m 3 : 25 c : W6.35 10m 4 : 20 d : W6.35 20m The total length of each liquid line is as follows;

W9.52 : A + a = 30 + 15 = 45m W6.35 : b + c + d = 10 + 10 + 20 = 40m

<Calculation example> Additional refrigerant charge = 45

(kg)

Liquid pipe size Total length of W9.52 × 0.06

(m) × 0.06 (kg/m)

× 0.06 + 40 × 0.024 – 3.0 = 0.7kg (rounded up)

Liquid pipe size Total length of W6.35 × 0.024

(m) × 0.024 (kg/m)

Refrigerant amount for outdoor unit

–

At the conditions below:

3.0kg

Method of Combined Branching of Lines and Headers

Connection Examples (Connecting to 5 Indoor Units)

Note: Pipe re-branching after the header branching is not possible.

D D D

d e

Outdoor unit

First branching (branching

joint)

Branching joint

Indoor unit

Branching header

Blind caps

Permissible

Length

Permissible High/

Low Difference

Farthest Piping Length

Farthest Piping Length After First Branch

High/Low Difference in Indoor/Outdoor Section

High/Low Difference in Indoor/Indoor Section

■ Selecting the Refrigerant Branch Kit

■ Select Each Section of Refrigerant Piping

Total Piping Length

(1) Section From Outdoor Unit to First Branch (A) (2) Sections From Branch to Indoor Unit (a,b,c,d,e) (3) Section From Branch to

Each Section of Piping

Branch (B,C)

Select the size from the table to the right.

■ Additional refrigerant charge

• If the total extended piping length exceeds 50m, calculate the required additional refrigerant charge using the procedure shown on the right.

• If the calculated additional refrigerant charge is a negative amount, do not charge with any refrigerant.

A+B+C+a+b+c+d+e is 120 meters or less

(L)

A+B+b is 80 meters or less

(1)

B+b is 30 meters or less

(H)

50 meters or less (If the outdoor unit is lower, 20 meters or less)

(h)

12 meters or less

Please select branching kit, which is sold separately, from the table below. (The kit comprises sets for use with liquid pipes and for use with gas pipes.)

Branch Joint

CMY-Y62-G-E

(1) Refrigerant Piping Diameter In Section From Outdoor Unit to First Branch (Out door Unit Piping Diameter)

Piping Diameter (mm)Model

PUMY-P100~140

Liquid Line

Gas Line

Branch Header (4 branches)

CMY-Y64-G-E

(2) Refrigerant Piping Diameter In Section From Branch to Indoor Unit (Indoor Unit Piping Diameter)

Model number

W9.52 W15.88

50 or lower

Branch Header (8 branches)

63 to 140

(3) Refrigerant Piping Diameter In Section From Branch to Branch

Liquid Line (mm) Gas Line (mm)

W15.88W9.52

Additional refrigerant charge

(kg)

Liquid pipe size Total length of W9.52 × 0.06

(m) × 0.06 (kg/m)

Liquid pipe size Total length of W6.35 × 0.024

(m) × 0.024 (kg/m)

<Example> Indoor 1 : 50 A : W9.52 10m a : W9.52 5m

2 : 40 B : W9.52 20m b : W6.35 10m 3 : 32 C : W9.52 10m c : W6.35 5m 4 : 20 d : W6.35 5m

At the conditions below:

5 : 20 e : W6.35 5m The total length of each liquid line is as follows;

W9.52 : A + B + C + a = 10 + 20 +10 + 5 = 45m W6.35 : b + c + d + e = 10 + 5 + 5 + 5 = 25m

CMY-Y68-G-E

Piping Diameter (mm)

Liquid Line

Gas Line

Liquid Line

Gas Line

Refrigerant amount for outdoor unit

–

W6.35 W12.7 W9.52 W15.88

125: 3.0kg

<Calculation example> Additional refrigerant charge = 45

× 0.06 + 25 × 0.024 – 3.0 = 0.3kg (rounded up)

11-2. PRECAUTIONS AGAINST REFRIGERANT LEAKAGE

11-2-1. Introduction

R410A refrigerant of this air conditioner is non-toxic and nonflammable but leaking of large amount from an indoor unit into the room where the unit is installed may be deleterious. To prevent possible injury, the rooms should be large enough to keep the R410A concentration specified by KHK: (a high pressure gas safety association) installation guidelines S0010 as follows.

Maximum concentration Maximum refrigerant concentration of R410A of a room is 0.3 kg/K accordance with the installation guidelines. To facilitate calculation, the maximum concentration is expressed in units of O/K ( kg of R410A per K)

Maximum concentration of R410A: 0.3O/K

(KHK installation guidelines S0010)

Outdoor unit

Direction of refrigerant flow

Branch box

(2) Calculate room volumes (m

with the smallest volume

The part with represents the room with the smallest volume.

(a) Situation in which there are no partitions

(b) There are partitions, but there are openings that allow

the effective mixing of air.

Branch box

Indoor unit

) and find the room

Outdoor unit

Indoor unit

All refrigerant of this system will leak out to this room if there is leakage at this indoor unit.

11-2-2. Confirming procedure of R410A concentration

Follow (1) to (3) to confirm the R410A concentration and take appropriate treatment, if necessary.

(1) Calculate total refrigerant amount by each refrig-

erant system. Total refrigerant amount is precharged refrigerant at ex-factory plus additional charged amount at field installation.

Note: When single refrigeration system consists of several independent refrigeration circuit, figure out the total refrigerant amount by each independent refrigerant circuit.

Indoor unit

Opening

Wall

ratus that is linked to a household gas detection and alarm device, the calculations should be performed for the second smallest room.

Branch box

Ventilation apparatus

The smallest room

The second smallest room

(Situation in which there are no door openings or in which there are openings above and below doors that occupy at least 0.15% of the floor area)

Outdoor unit

Indoor unit

(3) Use the results of calculations (1) and (2) to cal-

culate the refrigerant concentration:

Total refrigerant in the refrigerating unit (O) [ Maximum concentration(O/K) The smallest room in which an indoor unit has been installed (K) Maximum concentration of R410A:0.3O/K

If the calculation results do not exceed the maximum concentration, perform the same calculations for the larger second and third room, etc., until it has been determined that nowhere the maximum concentration will be exceed.

12 DISASSEMBLY PROCEDURE

OUTDOOR UNIT: PUMY-P100VHMB(-BS) PUMY-P100VHMBR1(-BS) PUMY-P100VHMBR2(-BS)

PUMY-P125VHMB(-BS) PUMY-P125VHMBR1(-BS) PUMY-P125VHMBR2(-BS) PUMY-P140VHMB(-BS) PUMY-P140VHMBR1(-BS) PUMY-P140VHMBR2(-BS)

OPERATING PROCEDURE

1. Removing the service panel and top panel

(1) Remove 3 service panel fixing screws (5 × 12) and slide the

hook on the right downward to remove the service panel.

(2) Remove screws (3 for front, 3 for rear/5 × 12) of the top

panel and remove it.

2. Removing the fan motor (MF1, MF2)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 5 fan grille fixing screws (5 × 12) to detach the fan

grille. (See Figure 1)

(4) Remove a nut (for right handed screw of M6) to detach the

propeller. (See Photo 1)

(5) Disconnect the connectors, CNF1 and CNF2 on Multi con-

troller board in electrical parts box.

(6) Remove 4 fan motor fixing screws (5 × 25) to detach the fan

motor. (See Photo 2)

Figure 1

Grille fixing screws

Photo 1

Nut

PHOTOS & ILLUSTRATION

Top panel fixing screws

Slide

Front panel

Propeller

Photo 2

Fan motor fixing screws

Top panel

Service panel

Fan grille

Service panel fixing screws

Fan motor

3. Removing the electrical parts box

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Disconnect the connecting wire from terminal block. (4) Remove all the following connectors from Multi controller board;

fan motor, thermistor <Outdoor pipe>, thermistor <Discharge>, thermistor <Low pressure saturated temp>, thermistor <Outdoor>, high pressure switch, high pressure sensor, low pressure switch, 4-way valve coil and bypass valve coil. Pull out the disconnected wire from the electrical parts box. <Diagram symbol in the connector housing>

• Fan motor (CNF1, CNF2)

• Thermistor <Outdoor pipe> (TH3)

• Thermistor <Discharge> (TH4) (PUMY-P·VHMB(R1)(-BS)) Thermistor <Compressor> (TH4) (PUMY-P·VHMBR2(-BS))

• Thermistor <Low pressure saturated temp, Outdoor> (TH6/7)

• High pressure switch (63H)

• High pressure sensor (63HS)

• Low pressure switch (63L)

• 4-way valve coil (21S4)

• Bypass valve coil (SV1)

(5) Remove the terminal cover and disconnect the compressor

lead wire.

Fan motor fixing screws

Photo 3

Electrical parts box

Multi controller board (MULTI.B)

Terminal block (TB3) (TB7)

Terminal block (TB1)

Valve bed

Compressor (MC)

Terminal cover

Cover panel (Front)

Cover panel fixing screws

Continued to the next page.

From the previous page.

OPERATING PROCEDURE

(6) Remove electrical parts box fixing screw (4 × 10) and

detach the electrical parts box by pulling it upward. The electrical parts box is fixed with 2 hooks on the left and 1 hook on the right.

4. Removing the thermistor <Low pressure saturated temp.> (TH6)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Disconnect the connectors, TH6 and TH7 (red), on the Multi

controller board in the electrical parts box. (4) Loosen the wire clamps on top of the electrical parts box. (5) Pull out the thermistor <Low pressure saturated temp.> (TH6)

from the sensor holder.

Note: In case of replacing thermistor <Low pressure satu-

rated temp.> (TH6), replace it together with thermistor

<Outdoor> (TH7) since they are combined together.

Refer to No.5 below to remove thermistor <Outdoor(TH7)>.

Photo 4

Photo 5

PHOTOS & ILLUSTRATION

Electrical parts box

Electrical parts box fixing screw

5. Removing the thermistor <Outdoor> (TH7)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Disconnect the connector TH7 (red) on the Multi controller

board in the electrical parts box. (4) Loosen the wire clamps on top of the electrical parts box.

(See Photo 4) (5) Pull out the thermistor <Outdoor> (TH7) from the sensor

holder.

Note: In case of replacing thermistor <Outdoor> (TH7),

replace it together with thermistor <Low pressure satu-

rated temp> (TH6), since they are combined together.

Refer to No.4 above to remove thermistor <Low pres-

sure saturated temp>.

Thermistor <TH6>Electrical parts box

Photo 6

Lead wire of thermistor <Outdoor> (TH7)

Sensor holder

OPERATING PROCEDURE

6. Removing the thermistor <Outdoor pipe> (TH3) and thermistor <Discharge/Compressor> (TH4)

(1) Remove the service panel. (See Figure 1) (2) Disconnect the connectors, TH3 (white) and TH4 (white), on

the Multi controller board in the electrical parts box.

(3) Loosen the clamp for the lead wire in the rear of the electri-

cal parts box.

(4) Pull out the thermistor <Outdoor pipe> (TH3) and thermistor

<Discharge/Compressor> (TH4) from the sensor holder.

Photo 7

PHOTOS

Thermistor <Outdoor pipe>

(TH3)

7. Removing the 4-way valve coil (21S4)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1)

[Removing the 4-way valve coil]

(3) Remove 4-way valve coil fixing screw (M4 × 6). (4) Remove the 4-way valve coil by sliding the coil toward you. (5) Disconnect the connector 21S4 (green) on the Multi control-

ler board in the electrical parts box.

8. Removing the 4-way valve

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 3 valve bed fixing screws (4 × 10) and 4 ball valve

and stop valve fixing screws (5 × 16) and then remove the valve bed.

(4) Remove 4 right side panel fixing screw (5 × 12) in the rear

of the unit and then remove the right side panel. (5) Remove the 4-way valve coil. (See Photo 8) (6) Recover refrigerant. (7) Remove the welded part of four-way valve.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3: When installing the four-way valve, cover it with a

wet cloth to prevent it from heating (120°C or more), then braze the pipes so that the inside of pipes are not oxidized.

*For VHMBR2(-BS)

Thermistor <Compressor> (TH4)

Photo 8

4-way valve coil (21S4)

4-way valve coil fixing screw

Compressor (MC)

Thermistor <Discharge> (TH4)

4-way valve

Thermistor <Low pressure saturated temp.> (TH6)

OPERATING PROCEDURE

9. Removing bypass valve coil (SV1) and bypass valve

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 3 right side panel fixing screws (5 × 12) in the rear

of the unit and remove the right side panel. (4) Remove the bypass valve coil fixing screw (M4 × 6). (5) Remove the bypass valve coil by sliding the coil upward. (6) Disconnect the connector SV1 (white) on the Multi controller

circuit board in the electrical parts box. (7) Recover refrigerant. (8) Remove the welded part of bypass valve.

PHOTOS

Photo 9

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

10. Removing the high pressure switch (63H) and low pressure switch (63L)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove the electrical parts box. (See Photo 4) (4) Remove 3 right side panel fixing screws (5 o 12) in the rear

of the unit and remove the right side panel.

(5) Pull out the lead wire of high pressure switch and low pres-

sure switch. (6) Recover refrigerant. (7) Remove the welded part of high pressure switch and low

pressure switch.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3: When installing the high pressure switch and low

pressure switch, cover them with a wet cloth to prevent them from heating (100°C or more), then braze the pipes so that the inside of pipes are not oxidized.

High pressure switch (63H)

Bypass valve coil fixing screw

Bypass valve coil (SV1)

Bypass valve

High pressure sensor (63HS)

Photo 10

11. Removing the high pressure sensor (63HS)

(1) Remove the service panel. (See Figure 1.) (2) Remove the top panel. (See Figure 1.) (3) Remove the electrical parts box. (See Photo 4.) (4) Remove 3 right side panel fixing screws (5 o 12) in the rear

of the unit and remove the right side panel. (5) Pull out the lead wire of high pressure sensor. (6) Recover refrigerant. (7) Remove the welded part of high pressure sensor.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3:

When installing the high pressure sensor, cover it with a wet cloth to prevent it from heating (100°C or more), then braze the pipes so that the inside of pipes are not oxidized.

High pressure sensor (63HS)

Low pressure switch (63L)

OPERATING PROCEDURE

PHOTOS

12. Removing the compressor (MC)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 2 front cover panel fixing screws (5 × 12) and

remove the front cover panel. (See Photo 3)

(4) Remove 2 back cover panel fixing screws (5 × 12) and

remove the back cover panel. (5) Remove the electrical parts box. (See Photo 4) (6) Remove 3 valve bed fixing screws (4 × 10) and 4 ball valve

and stop valve fixing screws (5 × 16) and then remove the

valve bed. (7) Remove 3 right side panel fixing screw (5 × 12) in the rear

of the unit and then remove the right side panel. (8) Remove 3 separator fixing screws (4 × 10) and remove the

separator. (9) Recover refrigerant. (10)

Remove the 3 compressor fixing nuts for motor using span-

ner or adjustable wrench. (11)

Remove the welded pipe of motor for compressor inlet and

outlet and then remove the compressor.

Note: Recover refrigerant without spreading it in the air.

13. Removing the accumulator

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 2 front cover panel fixing screws (5 × 12) and

remove the front cover panel. (See Photo 3) (4) Remove 2 back cover panel fixing screws (5 × 12) and

remove the back cover panel. (5) Remove the electrical parts box. (See Photo 4) (6) Remove 3 valve bed fixing screws (4 × 10) and 4 ball valve

and stop valve fixing screws (5 ×16) and then remove the

valve bed. (7) Remove 3 right side panel fixing screw (5 × 12) in the rear

of the unit and then remove the right side panel. (8) Recover refrigerant. (9) Remove 4 welded pipes of power receiver inlet and outlet. (10)

Remove 2 receiver leg fixing screws (4 × 10).

(See Photo 13)

Photo 11

Valve bed fixing

screw

Compressor (MC)

Photo 12

Valve bed

Separator

Separator fixing screw

Valve bed fixing screws

Accumulator

Compressor

fixing nut

Inlet

Outlet

Accumulator

Note: Recover refrigerant without spreading it in the air.

Photo 13

Accumulator

Accumulator leg

Accumulator leg fixing screws

OUTDOOR UNIT: PUMY-P100YHMB(-BS) PUMY-P100YHMBR1(-BS) PUMY-P100YHMBR2(-BS)

PUMY-P125YHMB(-BS) PUMY-P125YHMBR1(-BS) PUMY-P125YHMBR2(-BS) PUMY-P140YHMB(-BS) PUMY-P140YHMBR1(-BS) PUMY-P140YHMBR2(-BS)

OPERATING PROCEDURE

1. Removing the service panel and top panel

(1) Remove 3 service panel fixing screws (5 × 12) and slide

the hook on the right downward to remove the service panel.

(2) Remove screws (3 for front, 3 for rear/5 × 12) of the top

panel and remove it.

2. Removing the fan motor (MF1, MF2)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 5 fan grille fixing screws (5 × 12) to detach the

fan grille. (See Figure 1)

(4) Remove a nut (for right handed screw of M6) to detach

the propeller. (See Photo 1.)

(5) Disconnect the connectors, CNF1 and CNF2 on Multi con-

troller board in electrical parts box.

(6) Remove 4 fan motor fixing screws (5 × 25) to detach the

fan motor. (See Photo 2)

Figure 1

Grille fixing screws

Photo 1

Propeller

Nut

PHOTOS & ILLUSTRATION

Top panel fixing screws

Photo 2

Front panel

Fan motor fixing screws

Slide

Top panel

Service panel

Service panel fixing screws

Fan grille

Fan motor

3. Removing the electrical parts box

an motor, thermistor <Outdoor pipe>, thermistor <Compressor>, thermistor <Low pressure saturated temp>, thermistor <Outdoor>, high pressure switch, high pressure sensor, low pressure switch, solenoid valve coil <Four-way valve> and solenoid valve coil <Bypass valve>. Then remove a screw (4 × 8) from the valve bed to remove the lead wire. Pull out the disconnected wire from the electrical parts box. <Diagram symbol in the connector housing>

• Fan motor (CNF1, CNF2)

• Thermistor <Outdoor pipe> (TH3)

• Thermistor <Discharge> (TH4) (PUMY-P·YHMB(R1)(-BS)) Thermistor <Compressor> (TH4) (PUMY-P·YHMBR2(-BS)

• Thermistor <Low pressure saturated temp, Outdoor> (TH6/7)

• High pressure switch (63H)

• High pressure sensor (63HS)

• Low pressure switch (63L)

• Solenoid valve coil <Four-way valve> (21S4)

• Solenoid valve coil <Bypass valve> (SV1)

(5) Remove the terminal cover and disconnect the compressor

lead wire.

Fan motor fixing screws

Photo 3

Electrical parts box

Noise filter circuit board (NF)

Multi controller board (MULTI.B)

Terminal block (TB1)

Terminal block (TB3) (TB7)

Screw

Valve bed

Compressor (MC)

Terminal cover

Cover panel (Front)

Cover panel fixing screws

Continued to the next page.

From the previous page.

OPERATING PROCEDURE

(6) Remove electrical parts box fixing screw (4 × 10) and

detach the electrical parts box by pulling it upward. The electrical parts box is fixed with 2 hooks on the left and 1 hook on the right.

4. Removing the thermistor <Low pressure saturated temp.> (TH6)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Disconnect the connectors, TH6 and TH7 (red), on the

Multi controller board in the electrical parts box. (4) Loosen the wire clamps on top of the electrical parts box. (5) Pull out the thermistor <Low pressure saturated temp.>

(TH6) from the sensor holder.

PHOTOS & ILLUSTRATION

Photo 4

Electrical parts box

Electrical parts box fixing screw

Photo 5

Note: In case of replacing thermistor <Low pressure satu-

rated temp.> (TH6), replace it together with thermistor <Outdoor> (TH7) since they are combined together. Refer to No.5 below to remove thermistor <Outdoor>.

5. Removing the thermistor <Outdoor> (TH7)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Disconnect the connector TH7 (red) on the Multi controller

board in the electrical parts box. (4) Loosen the wire clamps on top of the electrical parts box.

(See Photo 4.) (5) Pull out the thermistor <Outdoor> (TH7) from the sensor

holder.

Note: In case of replacing thermistor <Outdoor> (TH7),

replace it together with thermistor <Low pressure saturated temp> (TH6), since they are combined together. Refer to No.4 above to remove thermistor <Low pressure saturated temp>.

Electrical parts box

Thermistor <TH6>

Photo 6

Lead wire of thermistor <Outdoor> (TH7)

Sensor holder

OPERATING PROCEDURE

6. Removing the thermistor <Outdoor pipe> (TH3) and thermistor <Discharge/Compressor> (TH4)

(1) Remove the service panel. (See Figure 1) (2) Disconnect the connectors, TH3 (white) and TH4 (white),

on the Multi controller board in the electrical parts box.

(3) Loosen the clamp for the lead wire in the rear of the electri-

cal parts box.

(4) Pull out the thermistor <Outdoor pipe> (TH3) and thermis-

tor <Discharge/Compressor> (TH4) from the sensor holder.

Photo 7

PHOTOS

Thermistor <Outdoor pipe>

(TH3)

7. Removing the 4-way valve coil (21S4)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1)

[Removing the 4-way valve coil]

(3) Remove 4-way valve coil fixing screw (M4 × 6). (4) Remove the 4-way valve coil by sliding the coil toward you. (5) Disconnect the connector 21S4 (green) on the Multi control-

ler board in the electrical parts box.

8. Removing the 4-way valve

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 3 valve bed fixing screws (4 × 10) and 4 ball valve

and stop valve fixing screws (5 × 16) and then remove the valve bed.

(4) Remove 4 right side panel fixing screws (5 × 12) in the rear

of the unit and then remove the right side panel. (5) Remove the 4-way valve coil. (See Photo 8) (6) Recover refrigerant. (7) Remove the welded part of 4-way valve.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3: When installing the four-way valve, cover it with a

wet cloth to prevent it from heating (120°C or more),

then braze the pipes so that the inside of pipes

are not oxidized.

*For YHMBR2(-BS)

Thermistor <Compressor> (TH4)

Photo 8

4-way valve coil (21S4)

4-way valve coil fixing screw

Compressor (MC)

Thermistor <Discharge> (TH4)

4-way valve

Thermistor <Low pressure saturated temp.> (TH6)

OPERATING PROCEDURE

9. Removing bypass valve coil (SV1) and bypass valve

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove 3 right side panel fixing screws (5 × 12) in the rear

circuit board in the electrical parts box. (7) Recover refrigerant. (8) Remove the welded part of bypass valve.

PHOTOS

Photo 9

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

10. Removing the high pressure switch (63H) and low pressure switch (63L)

of the unit and remove the right side panel.

(5) Pull out the lead wire of high pressure switch and low pres-

sure switch. (6) Recover refrigerant. (7) Remove the welded part of high pressure switch and low

pressure switch.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3: When installing the high pressure switch and low

pressure switch, cover them with a wet cloth to prevent them from heating (100°C or more), then braze the pipes so that the inside of pipes are not oxidized.

High pressure switch (63H)

Solenoid valve coil fixing screw

Solenoid valve coil (SV1)

Bypass valve

High pressure sensor (63HS)

Photo 10

11. Removing the high pressure sensor (63HS)

of the unit and remove the right side panel. (5) Pull out the lead wire of high pressure sensor. (6) Recover refrigerant. (7) Remove the welded part of high pressure sensor.

Note 1: Recover refrigerant without spreading it in the air. Note 2: The welded part can be removed easily by remov-

ing the right side panel.

Note 3: When installing the high pressure sensor, cover it

with a wet cloth to prevent it from heating (100°C or more), then braze the pipes so that the inside of pipes are not oxidized.

High pressure switch (63H)

Low pressure switch (63L)

High pressure sensor (63HS)

OPERATING PROCEDURE

12. Removing the reactors (ACL1, ACL2, ACL3)

(1) Remove the service panel. (See Figure 1) (2) Remove the top panel. (See Figure 1) (3) Remove the 6 screws, screw 8 and 9 (5 × 12), that fix the

front panel and remove the front panel. (See Photo 3)

(4) Remove the 2 screws, screw 0 and 1 (both 4 × 10), that

fix the separator, screw 0 from the valve bed and screw 1 from the bottom of the separator, and tilt the separator to the side of the fan motor slightly. (See Photo 11)

(5) Disconnect the lead wires from the reactor and remove the

4 screws, screw 2, that fix the reactor to remove the reactor. (See Photo 12 and 13)

Note 1: The reactor is very heavy (4kg)! Be careful when

handling it.

Note 2: The reactor box is also removable.

Photo 11

PHOTOS

Electrical parts box

Screw0

Photo 12

Reactors

Propeller

Reactor box

Electrical parts box

4-way valve

Reactor box

Photo 13

Separator

Valve bed

Screw1

Reactor box

100

Screw2

Mitsubishi PUMY-P100VHMB, PUMY-P100VHMBR1, PUMY-P100VHMBR2, PUMY-P125VHMB, PUMY-P125VHMBR1 Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
