Refrigeration
EK SERIES TOP MOUNT
PRODUCT FLYER
EK Series
TOP MOUNT
The EK Series smart elevating shelf function is a unique time and space saving feature, helping to
maximise the usable space in the refrigerator compartment.
TOTAL CAPACITY
560/508 LITRES
Dimensions
FREEZER
178 LITR ES
REFRIGERATOR
382/330 LITRES
MR-560EK / MR-508EK FEATURES
» Elevating Shelf
» Tempered Glass Shelves
» Deodoriser
» Egg Shelf (2 egg racks)
» 2-Way Flexi Glass Shelf
» LED Light
» Adjustable Door Shelf
» Big Bottle Pockets & Stopper
» Anti-Bacteria Food Liner
» Revolving Ice Tray
» Frost Free
» Adjustable Feet
MR-560EK
H 1777 x W 751 x D 795mm
MR-508EK
H 1652 x W 751 x D 795mm
» 4 Rollers
» 4.0 Star Energy Rating
» Multi Airflow System
» R600a Refrigerant
MR-560EK
MR-560EK
560 Litres
MR-508EK
508 Litres
Elevating Shelf
Simply slide the lever and you
can raise or lower each shelf by
up to 40mm. There is no need to
remove any items from the shelf...
what could be easier than that!
Sliding Case
Equipped with a smooth-sliding
roller, the Sliding Chilled Case
allows for easy access. Great for
storing dairy products, fresh fish
or meat and chilling drinks.
Shiny
Black
White
Stainless
Steel
LED Light
The LED light will illuminate your
refrigerator while being energy
efficient.
Tempered Glass Shelves
The Tempered Glass Shelves
are easy to clean, heat resistant
and built to withstand up to 100
kilograms of weight.
4 Star Energy Rating
Introduction of an inverter
compressor and design changes
deliver a 4.0 star energy rating
and reduced power consumption
compared to non-inverter models.
2-Way Flexi Glass Shelf
Make the Tempered Glass shelf
deeper or push it in for more
space. It is ideal for storing taller
items such as a salad or dessert
bowl.
Y
E
A
S
MR-508EK
Specifications
MR-508EK MR-560EK
Total 508 560
Capacity (L)
Gross
Freezer Compartment 178 178
Refrigerator Compartment 330 382
Height 1652 1777
Dimensions (mm)
Width 751 751
Depth 795 795
Top 100 100
Clearance
Dimensions (mm)
Left 20 20
Right 20 20
Back 50 50
Energy Star Rating 4.0 Stars 4.0 Stars
Energy Consumption (kW/h per year) 340 350
White • •
Colour Options
Stainless Steel • •
Shiny Black • •
E
V
R
N
T
I
E
R
N
O
C
O
Y
T
N
A
R
R
A
W
S
S
T
T
R
R
A
P
A
P
R
0
1
D
N
I
M
F
O
E
C
A
M
P
R
L
&
E
P
R
O
S
A
O
R
R
R
A
Mitsubishi Electric Inverter refrigerators
N
M
T
I
T
Y
S
U
are backed by a comprehensive 5
B
I
S
H
I
year parts and labour warranty and a
E
L
E
C
10 year parts warranty on the Inverter
T
R
I
C
R
E
compressor. See website for full Terms
F
R
I
G
E
R
A
T
O
F
R
and Conditions.
10 Year Compressor Warranty
E
U
O
R
B
S
A
W
Fridge Finder App
Available to download
from the App Store
MitsubishiElectric.com.au
The specifications and information in this flyer are subject to change without notice. Colours depicted in this flyer may vary slightly. Images are for illustrational purposes only.
Printed October 2019. © Mitsubishi Electric 2019
