LCD FLAT PANEL HDTV

D A I L Y

MODELS

LT-46244 LT-52244

OWNER’S GUIDE

• For questions:

- Visit our website at www.mitsubishi-tv.com.

- E-mail us at MDEAservice@mdea.com.

- Call Consumer Relations at 800-332-2119.

• For information on System Reset, please see the back cover.

• To order replacement or additional remote controls or Owner’s Guides, visit our website at www.mitsuparts.com or call 800-553-7278.

• Guidelines for setting up and using your new widescreen TV start on page 12.

x.v.Color

For Your Records

Record the model number, serial number, and purchase date of your TV. The model and serial numbers are on the back of the TV. Refer to this page when requesting assistance with the TV.

MODEL NUMBER

SERIAL NUMBER

PURCHASE DATE

RETAILER NAME

LOCATION

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user of the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

FCC Declaration of Conformity

Product: LCD HDTV Display Models: LT-46244, LT-52244 Responsible

Party:

Telephone: (800) 332-2119

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference,

and

(2) this device must accept any interference

received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by Mitsubishi could cause harmful interference and would void the user’s authority to operate this equipment.

Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road Irvine, CA 92618-1904

TV WEIGHT: This TV is heavy! Exercise extreme care when lifting or moving it. Lift or move the TV with a minimum of two adults. To prevent damage to the TV, avoid jarring or moving it while it is turned on. Always power off your TV, unplug the power cord, and disconnect all cables before moving it.

WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm.

Contents

Important Information About Your TV

Installation Notes . . . . . . . . . . . . . . . . . . . . . . . . 4

TV Guide Daily Access Requirements. . . . . . . . . . 4

General Warnings and Cautions, Notes on

Installation and Operation . . . . . . . . . . . . . . . . . 4

Important Safeguards . . . . . . . . . . . . . . . . . . . . . 5

1 Television Overview

Package Contents . . . . . . . . . . . . . . . . . . . . . . . 6

Special Features of Your TV . . . . . . . . . . . . . . . . 6

TV Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 7

TV Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 8

TV Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Stand Removal Instructions . . . . . . . . . . . . . . . . 11

2 TV Setup

Guidelines for Setting Up and Using Your New

Widescreen TV . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing the Remote Control Batteries . . . . . . . . 13

When You First Power On the TV . . . . . . . . . . . . 13

Initial TV Setup . . . . . . . . . . . . . . . . . . . . . . . . . 13

Setting Up TV Inputs . . . . . . . . . . . . . . . . . . . . 14

Controlling A/V Receiver Sound Volume . . . . . . . 15

Using a CableCARD . . . . . . . . . . . . . . . . . . . . . 16

Using the TV with a Personal Computer . . . . . . . 17

3 TV Connections

Before you Begin . . . . . . . . . . . . . . . . . . . . . . . 19

Cable Management . . . . . . . . . . . . . . . . . . . . . 19

HDTV Cable Box or Satellite Receiver with

Component Video . . . . . . . . . . . . . . . . . . . . . 20

DMI Device (Cable Box, Satellite Receiver,

DVD Player, or Other Device Standard Cable Box, Satellite Receiver, or Other

Device with S-Video . . . . . . . . . . . . . . . . . . . . 21

Direct Cable (no cable box) . . . . . . . . . . . . . . . . 22

Antennas with Separate UHF and VHF Leads . . . 22

Antenna with a Single Lead . . . . . . . . . . . . . . . . 22

DVD Player with Component Video . . . . . . . . . . 23

DVI Video Device (Cable Box, Satellite Receiver,

DVD Player, or Other Device) . . . . . . . . . . . . . . 23

VCR to an Antenna or Wall Outlet Cable . . . . . . . 24

VCR to a Cable Box (Audio & Video) . . . . . . . . . . 25

A/V Receiver (Sound System) . . . . . . . . . . . . . . 26

Older Cable Box . . . . . . . . . . . . . . . . . . . . . . . . 26

Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

) . . . . . . . . . . . . . . . 21

Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . 29

ChannelView Channel Listings . . . . . . . . . . . . . . 31

Status Display . . . . . . . . . . . . . . . . . . . . . . . . . 32

Fav (Favorite Channels) . . . . . . . . . . . . . . . . . . . 33

TV Signals and Display Formats . . . . . . . . . . . . 34

Viewing Camera Files . . . . . . . . . . . . . . . . . . . . 35

JPEG Photos and the USB Photo Port . . . . . 35

Photos and Moving Video as Composite

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5 TV Menu Settings

Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Remote Control Keys for the TV Menu System . . 37

AV Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Video Menu . . . . . . . . . . . . . . . . . . . . . . . . 39

Audio Menu . . . . . . . . . . . . . . . . . . . . . . . . 40

Captions Menu . . . . . . . . . . . . . . . . . . . . . . . . . 41

Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Inputs Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Lock Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Pass Codes . . . . . . . . . . . . . . . . . . . . . . . . 48

Parent Menu . . . . . . . . . . . . . . . . . . . . . . . 48

Other Menu (Alternate Rating System) . . . . . 48

Bypassing TV Locks . . . . . . . . . . . . . . . . . . 48

6 NetCommand

About NetCommand . . . . . . . . . . . . . . . . . . . . . 51

IR Emitter Placement . . . . . . . . . . . . . . . . . . . . 52

Initial NetCommand Setup for Most Devices . . . . 53

Adding or Removing Device Keys from

NetCommand Control . . . . . . . . . . . . . . . . . . . 53

NetCommand Specialized Device Keys . . . . . . . 54

Operating NetCommand-Controlled Devices . . . 55 Setting Up NetCommand Control of an A/V

Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Appendices

Appendix A: Bypassing the Parental Lock . . . . . 61

Appendix B: Specifications . . . . . . . . . . . . . . . . 63

Appendix C: TV Guide Daily . . . . . . . . . . . . . . . 64

Appendix D: Programming the Remote Control . 68

Appendix E: Troubleshooting . . . . . . . . . . . . . . 76

Trademark and License Information . . . . . . . . . . 82

Mitsubishi TV Software. . . . . . . . . . . . . . . . . . . . 83

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

4 TV Operation and Features

Choosing a Viewing Source . . . . . . . . . . . . . . . . 28

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Important Information About Your TV

Installation Notes

Wall Mount Requirements

For wall-mounting, see “Stand Removal Instructions.”

Use with other than the authorized accessories may cause the TV to become unstable, which can cause damage to the product or possible injury.

Custom cabinet installation must allow for proper air circulation around the television.

NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.

If Your TV Gets Damaged

Crystalline liquid may leak from the LCD panel and broken glass may be scattered.

CAUTION: The crystalline liquid is toxic. Avoid contact with your skin, eyes, or mouth. DO NOT

touch the broken glass or crystalline liquid. DO NOT get glass fragments or crystalline liquid into eyes or mouth. Should either contact with your eyes or

mouth, rinse the contacted area thoroughly with water and consult your doctor.

Disposal of Your TV

The LCD panel contains a small amount of crystalline liquid and the fluorescent tube in the panel contains mercury. Both are toxic and should not be touched.

Cleaning Recommendations

Normally, light dusting with a dry, non-scratching duster will keep your TV clean. If cleaning beyond this is needed, please use the following guidelines:

First, turn off the TV and unplug the power cord from the power outlet.

Top and Sides of the TV

• Occasionally clean dust build-up from the air-intake grilles on the back and sides of the TV. Clean using a vacuum cleaner with a brush attachment.

• Gently wipe down your TV with a soft, non-abrasive cloth such as cotton flannel or a clean cloth diaper, lightly moistened with water. Dry with a second dry, soft, non-abrasive cloth.

• For oily dirt, add a few drops of mild liquid detergent, such as dishwashing detergent, to the water used to moisten the cloth. Rinse with a second cloth moistened only with water. Dry with a third dry, soft, non-abrasive cloth.

LCD Screen Cleaning

IMPORTANT

DO NOT apply any type of liquid to the surface of the TV screen.

• Only use a soft, dry cloth to clean the LCD

screen. Do not use any liquids.

• Wipe the screen gently with an up and down motion.

• Clean the entire screen evenly, not just sections of the screen.

DO NOT dispose of the TV with general household waste. THE LAMPS INSIDE THIS PRODUCT CONTAIN

MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE, AND FEDERAL LAWS. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance at www.eiae.org.

Internal Fan

This TV has an internal cooling fan that may be audible while the TV is powered on.

TV Guide Daily Access Requirements

TV Guide Daily listings are not provided by Mitsubishi Digital Electronics America, Inc. Operation of TV Guide Daily requires over-the-air or direct cable (no cable box) access to stations carrying TV Guide Daily program listings. If listings are not available in your area or become discontinued by the local provider, TV Guide Daily will not operate. TV Guide Daily does not provide program listings for satellite TV systems.

General Cleaning Precautions

• DO NOT allow liquid to enter the TV through the ventilation slots or any crevice.

• DO NOT use any strong or abrasive cleaners, as these can scratch the surfaces.

• DO NOT use any cleaners containing ammonia, bleach, alcohol, benzene, or thinners, as these can dull the surfaces.

• DO NOT spray liquids or cleaners directly on the

TV’s surfaces.

• DO NOT scrub or rub the TV harshly. Wipe it gently.

TV Software

Do not attempt to update the software of this TV with software or USB drives not provided by or authorized by Mitsubishi Digital Electronics America, Inc. Nonauthorized software may damage the TV and will not be covered by the warranty.

Important Safeguards

ANT E NNA LE AD IN W IR E

ANT E NNA DIS C HAR GE UNIT (NE C AR TI CL E 8 10-20 )

GR O UNDI NG CO NDU CT OR S (NE C AR TI CL E 8 10-21 )

GR O UND CL AMP S

PO WE R S E RV IC E G R OUN DING E LE CT R ODE S YS T EM (NE C AR T 250, P AR T H )

GR O UND CL AMP

E LE CT R IC S ER V ICE E QUIP ME NT

NE C — NAT ION AL E L EC TR IC AL CO DE

E XA MP L E OF A NT E NNA G R OU ND ING

Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television.

1. Read, Retain and Follow All Instructions. Read all safety and operating instructions before operating the TV. Retain the safety and operating instructions for future reference. Follow all operating and use instructions.

2. Heed Warnings.

3. Cleaning.

damage the cabinet and screen. Use a lightly dampened cloth for cleaning.

4. Attachments and Equipment.

result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture. Do not use the TV where contact with or immersion in water is possible. Do not use near bath tubs, wash bowls, kitchen sinks, laundry tubs, in a wet basement, swimming pools, etc.

6. Accessories.

child, adult or pet and serious damage to the TV. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer, or sold with the TV. Any mounting of the TV should follow the manufacturer’s instructions, and should use mounting accessories recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Ventilation. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to protect it from overheating. Do not block these openings or allow them to be obstructed by placing the TV on a bed, sofa, rug, or other similar surface. Nor should it be placed over a radiator or heat register. If the TV is to be placed in a rack or bookcase, ensure that there is adequate ventilation and that the manufacturer’s instructions have been adhered to.

8. Power Source. This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization. This TV is equipped with a polarized alternating current line plug having one blade wider than the other. This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

10. Power-Cord Protection. Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the TV.

11. Lightning. For added protection for this TV during a lightning storm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV due to lightning and power-line surges.

12. Power Lines. An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

13. Overloading. Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

14. Object and Liquid Entry. Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the TV.

15. Outdoor Antenna Grounding. If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electric Code, ANSI/NFPA No. 70-2002, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

16. Servicing. Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17. Damage Requiring Service. Unplug the TV from the wall outlet and refer servicing to qualified service personnel under the following conditions: (a) When the power-supply cord or plug is damaged. (b) If liquid has been spilled, or objects have fallen into the TV. (c) If the TV has been exposed to rain or water. (d) If the TV does not operate normally by following the operating instructions, adjust only those controls that are covered by the operating

(e) If the TV has been dropped or the cabinet has been damaged. (f) When the TV exhibits a distinct change in performance - this indicates a need for service.

18. Replacement Parts. When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

19. Safety Check. Upon completion of any service or repair to the TV, ask the service technician to perform safety checks to determine that the TV is in safe operating condition.

20. Heat. The product should be situated away from heat sources such as radiators, heat registers, stoves or other products (including amplifiers) that produce heat.

Adhere to all warnings on the appliance and in the operating instructions.

Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive or aerosol cleaners. Cleaners can permanently

Never add any attachments and/or equipment without approval of the manufacturer as such additions may

Do not place the TV on an unstable cart, stand, tripod, or table. The TV may fall, causing serious injury to a

instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.

Television Overview

Package Contents

Please take a moment to review the following list of items to ensure that you have received everything.

1. Remote Control

2. Two AA Batteries

3. Owner’s Guide

4. Quick Reference Guide

5. Quick Connect Guide

6. Product Registration Card

7. Four-Ended IR Emitter

8. One Cable Tie

9. One Cable Clamp

Special Features of Your TV

Your new high-definition widescreen television has

many special features that make it the perfect center of

your home entertainment system, including:

1080p High-Definition LCD Display System

Your Mitsubishi LCD Flat Panel HDTV uses a full 1920

x 1080 LCD panel to create the picture you see on the screen. All images are displayed at 1080p. The TV uses Plush 1080p™ to convert lower-resolution signals to 1080p for display. HDMI 1080p signals are displayed without overscan when received on inputs named

Game (if Picture Mode Game is selected) or on inputs

named PC.

Smooth120Hz™ Operation

Smooth120Hz™ enables the display of more fluid and smoother fast-moving images, free from motion blur. In these LCD Flat Panel HDTVs, Smooth120Hz™ doubles the traditional progressive scan frame rate and creates new frames of video in between each of the traditional frames, providing the panel with additional information to smooth moving images.

16:9 Widescreen Picture Format

Enjoy a full theatrical experience in the comfort of your home. View pictures as film directors intended them. Digital TV broadcasts, DVDs and newer video game consoles support this widescreen format.

Integrated HDTV Tuner

Your widescreen Mitsubishi HDTV has an internal

HDTV tuner able to receive both over-the-air HDTV broadcasts (received via an antenna) and digital cable broadcasts, including HDTV cable programming (when authorized by the CableCARD provider).

High-Definition Video Inputs

Component Video Inputs. Also called Y/Pb/Pr

inputs, these inputs receive standard analog video formats of 480i, 480p, 720p, and 1080i high-definition signals. This provides a high level of flexibility when connecting DVD players/recorders, cable boxes, and satellite receivers.

HDMI 1.3 Inputs. These inputs accept digital 480i,

480p, 720p, 1080i, and 1080p video signals plus

PCM digital stereo signals. The HDMI™ inputs can also accept a variety of PC signals and resolutions.

These inputs are compatible with Deep Color and

x.v.Color. Used with an adapter, these inputs also accept

compatible digital DVI video signals. HDMI inputs provide additional high-performance, highdefinition connections for maximum flexibility in your choice of home theater products. The HDMI inputs are HDCP copy-protection compatible.

Easy Connect Auto Input Sensing

Easy Connect™ Auto Input Sensing automatically recognizes when you plug in an input and prompts you to assign a name to it. The TV ignores any unused inputs, so the result is an uncluttered Input Selection menu where you can easily find and select connected devices by name.

Home Theater Control

NetCommand with IR Learning

Your Mitsubishi HDTV offers a new level of networking

that seamlessly integrates selected older A/V products with new and future digital products. NetCommand® supports IR (infrared) control of products such as VCRs, DVD players, cable boxes, and satellite receivers. NetCommand can “learn” remote control signals directly from many devices, allowing you to create a customized NetCommand-controlled home-theater system.

1. Television Overview 7

NetCommand for HDMI Devices

Some newer HDMI devices may be compatible with the TV’s NetCommand for HDMI feature. Compatible devices can receive control signals through the HDMI connection. The TV’s remote control may be able to operate some functions of these devices without any further setup.

Swivelling Stand

The included stand allows the TV to be manually swiveled up to 30 degrees left or right to the best viewing angle.

TV Guide Daily Interactive Program Guide

TV Guide Daily is a subscription-free guide system. It lists regular, digital, and high-definition programming being broadcast in your area over the next twenty-four hours.

Off Steady On Slow Blinking Fast Blinking

TV Front Panel

Indicator Lights

Lights (located on the front left) indicate whether the TV is on or off, a timer is set, and the overall functional status of the TV. See chapter 4, “TV Operation and Features,” for more information.

Side Panel

(Controls and Inputs)

Remote Control IR Sensors

Decorative Blue Light (see options in the AV > Global > Blue Glow menu)

Power and Status Indicators

POWER/TIMER Indicator

LED Color TV Condition Additional Information

None

Blue

STATUS Indicator

Standby condition. Normal operation.

TV is powered on.

TV powered off, auto-on timer is set.

1. TV just plugged into AC outlet.

AC just restored after power failure.

3. TV rebooting after System Reset used.

4. TV rebooting after power fluc tuation or receiving abnormal digital signals from a digital channel or digital device.

5. You have begun the procedure to update software from an authorized flash memory device.

Normal operation.

Normal operation. TV can be turned on at any time.

Wait approximately one minute for blinking to stop before turning on. Normal operation.

LED Color TV Condition Additional Information

None

Red

Normal TV on or standby condition.

TV may require service.

Normal operation.

Turn off the TV and unplug the set from the AC power source. Wait one minute and then plug the set back in. See Appendix E.

If the LED is still on, contact your dealer or a Mitsubishi Authorized Service Center. Go to www.mitsubishi-tv.com or call 1-800-332-2119 to receive Authorized Service Center information.

8 1. Television Overview

TV Side Panel

The side panel contains TV control buttons and additional input jacks.

System Reset Button (see more

information below)

See chapter 4,

Side Panel Buttons duplicate some keys on the TV remote control

Side Panel Jacks

“TV Operation and Features”

Side Panel Input Jacks

COMPONENT 3

(five jacks)

INPUT 3

(lower three jacks)

Jacks

See chapter 3, “TV Connections”

System Reset Button

If the TV does not respond to the remote control, side panel controls, or will not power on/off, press the

SYSTEM RESET

object, such as the point of a pencil or end tip of a paperclip.

The blue minute. When the blue may turn on the TV. Recent setting changes you made before using

button on the side panel with a pointed

POWER

LED will flash quickly for about one

POWER

LED stops flashing, you

SYSTEM RESET

may be lost.

A/V Reset

If you wish to reset the A/V (Audio/Video) settings back to the factory defaults:

• To reset all settings at once, press on the side panel at the same time.

• To reset the defaults for individual inputs, use the

Reset selection found in the AV menu.

GUIDE

and

FORMAT

1. COMPONENT 3 Inputs (Audio and Video)

Y Pb Pr (480i/480p/720p/1080i) COMPONENT 3

these jacks to connect devices with component video outputs, such as DVD players, external HDTV receivers, or compatible video game systems. See Appendix B, “Specifications,” for signal compatibility.

2. INPUT 3 (Audio and Video)

The

INPUT 3

ack can serve either as a yellow composite video jack or as a green component video jack. The audio jacks can be used with either the composite or component inputs nearby on the side panel. The audio jacks also work with a DVI source connected

3. HDMI 4

HDMI 4 is an HDMI™ input located on the TV’s side panel for convenience. See item 6, “HDMI Inputs” for description and use. When you connect a DVI device to HDMI 4, connect analog audio cables to the nearby INPUT 3 L and R audio jacks to hear analog audio from the device.

is a third set of component inputs. Use

jacks have multiple uses. The

HDMI 4

Y/VIDEO

4. USB Photo Port

The USB port is used for viewing JPEG images. See chapter 4, “TV Operation and Features” for more information.

1. Television Overview 9

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

34

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

"55&/5*0/

"MJHOTUSBJHIUXJUI)%.*KBDLUIFO JOTFSUHFOUMZ

"/5"69

64&8*5)$BCMF$"3%

"/5."*/

"55&/5*0/

"MJHOTUSBJHIUXJUI)%.*KBDLUIFO JOTFSUHFOUMZ

"/5."*/

"/5"69

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73

"6%*0065165

1$%7*

"6%*0*/165

"6%*0

$0.10/&/5

*/1654

JQQJ

34

#"$,1"/&-

#"$,1"/&--"#&-

$BCMF$"3%

"$$&44%003

#"$,1"/&-

4*%& 1"/&-

TV Back Panel

TV Back Cover

Label for Back Panel #2

Back Panel #2

Back Panel #1

ANT 1/MAIN

(jack at rear of recessed

ANT 2/AUX (jack closest to you)

area)

Dealer Use Only

1. ANT 1/MAIN, ANT 2/AUX (Antenna)

If you are connecting an antenna, direct cable without a cable box, or are using cable with a CableCARD™, connect the main antenna or cable source to

ANT 1/MAIN

. Use

and

ANT 2/AUX

and analog over-the-air channels from a VHF/UHF antenna or non-scrambled digital/analog cable source.

ANT 1/MAIN and CableCARD

Use

ANT 1/MAIN

TV service authorized by the CableCARD™ access

card. The CableCARD access card is provided by your local cable company.

to receive premium subscription cable

to receive over-the-air or non-scrambled cable signals when

ANT 1

is used for CableCARD™ service.

ANT 2/AUX

for a secondary source.

can each receive digital

ANT 2/AUX

can continue

2. COMPONENT Inputs (Audio and Video)

Y Pb Pr (480i/480p/720p/1080i)

Use these jacks to connect devices with component video outputs, such as DVD players, external HDTV receivers, or compatible video game systems. See

Appendix B specifications for signal compatibility.

3. PC/DVI AUDIO INPUT

Use the device to one of the TV’s HDMI inputs using a DVI-toHDMI cable. These jacks allow you to send left and right analog audio from a PC or DVI device to the TV.

PC/DVI AUDIO INPUT

when connecting a DVI

4. AVR AUDIO OUTPUT

Use the audio of the program currently shown on the screen to an A/V surround sound receiver or stereo system. Digital audio from digital channels and HDMI devices is converted to analog audio by the TV. If using an analog

AVR AUDIO OUTPUT

jacks to send analog

10 1. Television Overview

TV Back Panel, continued

A/V receiver or stereo system, this is the only audio

connection needed between it and the TV.

5. INPUT 1, 2 (Audio and Video)

INPUT 1

VHS (S-VHS) VCR, DVD player, standard satellite receiver, or other A/V device to the TV. Each TV group consists of jacks for composite video, S-Video, and analog stereo audio. Note that when you connect to the S-video jack, the composite video jack is automatically disabled. video and stereo audio jacks located on the side of the

TV for convenience.

and 2 can be used to connect a VCR, Super

INPUT

INPUT 3

is a third set of composite

6. HDMI Inputs

The HDMI™ 1.3 (High Definition Multimedia Interface)

supports uncompressed standard and high-definition digital video formats and PCM digital stereo audio format.

Use the HDMI inputs to connect to CEA-861 HDMI compliant devices such as a high-definition receiver or DVD player. These inputs support 480i, 480p, 720p, 1080i, and 1080p video formats, plus PCM digital stereo audio.

Mitsubishi recommends you use category 2 HDMI cables to connect HDMI 1.3 source devices. High-speed category 2 cables bring you the full benefits of Deep Color and x.v.Color.

These inputs can also accept digital DVI video signals. To connect a DVI source, use an HDMI-to-DVI adapter

or cable plus analog audio cables. Connect the analog audio cables to

TV to receive left and right stereo audio from your PC or

DVI device.

The TV’s HDMI inputs are compatible with many DVI-D

and HDMI computer video signals. See chapter 2, “TV Setup” and Appendix B for additional information on PC compatibility.

These inputs are HDCP (High-Bandwidth Digital Copy

Protection) compliant.

These inputs are certified for proper interop-

erability with other products certified by Simplay™.

PC/DVI AUDIO INPUT

on the back of the

HDMI Cable Categories

HDMI cables are available as Category 1 and Category 2 versions.

• Category 2 Cables. Newer, HDMI 1.3-compliant DVD players, video games, and set-top boxes require Category 2 cables. Use category 2 cables for these high-speed HD signals carrying extended color encodings (i.e., 30 or more bits, also called Deep Color). Category 2 cables are also suitable for standard HDTV signals.

• Category 1 Cables. Unmarked cables are category 1 cables and are suitable for standard HDTV signals, including 1080p signals.

8. IR Emitter NetCommand

IR Emitters connected to this jack are used by the TV’s NetCommand system to control external IR remote controlled analog devices such as cable boxes, VCRs, DVDs, satellite receivers and audio receivers.

9. RS-232 Port

Use this port with external control systems for the control of TV power, channel, format, volume, and mute. For detailed information and control codes, please visit our website at www.mitsubishi.com.

10. CableCARD Slot

Insert the CableCARD™ access card into the slot located behind the CableCARD access door. When inserting the card, ensure that the top of the card faces in the direction indicated by CARD TOP.

If your cable company is not currently offering CableCARD access cards, use the cable box provided and authorized by your local cable company to view scrambled channels.

When using a CableCARD, make sure the incoming Cable-TV cable is connected to the TV’s jack on the back of the TV (Back Panel #2).

ANT1/MAIN

7. DIGITAL AUDIO OUTPUT

This output sends Dolby Digital or PCM digital audio to

your digital A/V surround sound receiver. Analog audio from analog channels and devices is converted by the TV to PCM digital audio. If you have a digital A/V receiver, in most cases this is the only audio connection needed between the TV and your A/V receiver.

This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

1. Television Overview 11

5BCMF

1SPUFDUJWF TIFFU

4UBOE

1MBTUJD 1PSUJPOPG 4UBOE

4UBOE4DSFXT

JOSFDFTTFEIPMFT

1SPUFDUJWF4IFFU

57#BDL$PWFS

Stand Removal Instructions

CAUTION

At least TWO PEOPLE are needed to safely remove the stand. One person must hold the TV while the other person removes the stand. Failure to follow these recommendations may result in personal injury, as well as damage to the product.

Stand Removal Procedure:

1. Before starting to remove the stand, make sure to disconnect AC power cord from AC power outlet.

2. Spread the protective sheet that was wrapped around the TV on a flat, even surface (such as a sturdy table). The protective sheet will help prevent the display from being damaged.

IMPORTANT: To avoid damaging the screen,

make sure there are no foreign objects under or on top of the protective sheet.

3. With two people firmly grasping the left and right sides of the TV, gently place TV face down on the protective sheet with the display stand hanging over the edge of the table. See the illustration to the right.

4. Use a magnetic philips screwdriver to remove the four stand screws from the recessed holes (see illustration to right). Note: A regular screwdriver can be used with a separate magnetic pickup tool.

5. With one person holding the TV with both hands, grasp the plastic portion of the stand (see illustration to the right) and remove the stand by pulling it away from the TV in the direction of the large arrow shown in both illustrations.

6. The TV is now ready for wall mounting. See Wall Mount Kit below.

Wall Mount Kit (purchased separately)

To order a Wall Mounting Kit, please contact Peerless Industries, Inc. at (800) 473-3753 or visit www.peerlessmounts.com. Use wall mounting kit Model ST650.

Note: Complete instructions are included with the kit.

To order a Wall Mounting Kit from Mitsubishi Digital Electronics America, Inc., please visit www.mitsuparts.com or call (800) 553-7278.

CAUTION: Use with other than the authorized accessories may cause the TV to become unstable, which can cause damage to the product or possible injury.

IMPORTANT

Before attaching the wall mount kit to the TV, b sure to

connect all necessary cables to jacks

on the back of the TV. After wall-mounting, these jacks will not be accessible.

If you plan to connect a PC to the TV, before wall-mounting be sure to connect an HDMI cable and sound cable (if required) to the proper inputs

on the back of the TV. You can

also use the HDMI 4 jack on the side panel.

TV Set-Up

Guidelines for Setting Up and Using Your New Widescreen TV

Getting Started

1. Review the important safety, installation, and oper-

ating information at the beginning of this book.

2. Choose a location for your TV.

• Allow at least four inches of space on all sides of the TV to help prevent overheating. Overheating may cause premature failure of the TV.

• Avoid locations where light may reflect off the screen.

• If wall-mounting the TV, see “Stand Removal Instructions” in chapter 1, “Television Overview.”

3. Install the batteries in the remote control. See the following page. See chapter 4, “TV Operation and Features” for more on use of the remote control.

4. Plug your TV into a power outlet. The LED on the front of the TV will start blinking rapidly. After the LED stops blinking, press the the TV.

5. When the Welcome screen appears the first time you power on the TV, select a language for TV menus. You can later change the language through the Setup menu.

6. Connect your audio/video (A/V) devices to the TV and perform initial setup.

• See chapter 3, “TV Connections” for connec-

tion diagrams.

• See the following pages for initial TV setup and

use of the Auto Input Sensing feature.

• See chapter 6, “NetCommand,” to perform

NetCommand IR “learning” for control of your home theater.

7. Mitsubishi recommends you perform a channel scan for channels received on See “Initial TV Setup” on the following pages.

You can now start watching TV or you can perform additional setup and customization through the TV menus.

POWER

key to power on

ANT 1

and

ANT 2

TV Operation

1. Review chapter 4, “TV Operation and Features,” for

TV features including:

• Input Selection (viewing source). Select a connected program source to watch, such as a VCR, DVD player, or antenna. Press remote control to select from icons for the TV inputs. See “Choosing a Viewing Source.”

• ChannelView™/TV Guide Daily. Press to see channel listings for programs on and

ANT 2

. To override ChannelView and use the TV Guide Daily system, see Chapter 5, “TV Menu Settings” and the Inputs menu Guide options.

• Picture Formats. Press picture sizes and shapes to find the one best suited to the current program. See “TV Signals and Display Formats.”

2. To understand use of the Input Selection menu with NetCommand-controlled devices, see “Using NetCommand.”

3. To view JPEG photo files on the TV, see “Viewing Camera Files.”

FORMAT

INPUT

on the

GUIDE

ANT 1

to cycle through

Additional TV Setup

1. Review chapter 5, “TV Menu Settings,” to custom-

ize TV operation. Press the menu system. Some examples of settings you may wish to change include:

• Fav. Use an on-screen menu to create custom

lists of your favorite channels from

ANT 2

. See Setup > Edit.

• Order. Rearrange the device icons in the Input

Selection menu to put frequently used icons near the front. See Inputs > Order.

• Name. Change the device names that appear

in the Input Selection menu. See the Inputs menu Name options.

• TV Guide Daily. Set up and enable the TV

Guide Daily system. See the Inputs > Guide menu.

key to enter the

ANT 1

and

2. TV Setup 13

• Parental Locks. Restrict TV viewing by program rating, by channel, or by time of day. You can also disable the side-panel buttons if you have small children. See the Lock > Parent menu, the Lock > Front Panel menu, and Setup > Edit > Lock.

• Video Settings. Change video adjustments to get the best picture for your viewing conditions. See “AV Menu.”

Note: You may wish to change the Picture Mode from

the default Brilliant to either Bright or Natural, which are suitable for most home viewing.

2. To program the remote control to operate A/V devices not under NetCommand control, see Appendix D, “Programming the Remote Control.”

TV Care

General Cleaning. See the cleaning recommendations under “Important Information About Your TV.”

Assistance

• For troubleshooting, service, and product

support, see Appendix E.

• For warranty information, see the TV warranty

in the back of this book.

When You First Power On the TV

Turning the TV On or Off

To turn the TV on or off, point the remote control at the front of the TV and press the natively, press the of the TV.

POWER

button on the side panel

Choosing a Language for Menus

1. Power on the TV for the first time.

2. Press to select either English or Spanish for all menus. You can later change the language selection through the Setup menu Language option.

POWER

key. Alter-

Installing the Remote Control Batteries

1. Remove the remote control’s back cover by gently pressing in the tab and lifting off the cover.

2. Load the batteries, making sure the polarities (+) and (-) are correct. For best results, insert the negative (-) end first.

3. Snap the cover back in place.

The remote control requires two AA alkaline batteries.

When you first power on the TV, the Welcome screen lets you change the menu language.

Initial TV Setup

Use the Setup menu for basic TV setup options.

1. Press

2. Press to highlight the Setup icon and display the

Setup menu highlighted in TV Main menu

to open the Main menu.

Setup menu.

14 2. TV Setup

Initial TV Setup, continued

Change the Menu Language

Choose to display on-screen menus in either English or Spanish (Español).

Select a menu language in the Setup menu.

1. With the Setup menu displayed, press to highlight the Language icon.

2. Press to highlight either English or Spanish.

3. Press

Memorize Channels (Channel Scan)

For ANT 1/MAIN and ANT 2/AUX

icons.

to return the highlight to the top row of

3. Press to highlight the on-screen START button.

4. Press

5. When memorization is complete you can:

After channels have been memorized:

• To tune to memorized channels, press CH /

• Use the Setup > Edit menu for additional channel

ENTER

to start automatic channel memoriza-

tion.

To stop channel memorization before completion, press

• Press

while watching TV on the

options, such as adding or deleting channels from memory, naming channels, and saving favorite channels in custom memory banks.

MENU once to return to the top row of icons. MENU again to return to the Main menu. EXIT

to watch TV.

CANCEL

ANT 1

ANT 2

inputs.

Additional TV Setup Using the Setup Menu

See chapter 5, “TV Menu Settings,” to:

• Edit channel options

• Set the TV clock

• Set the TV Timer

• Select an Energy Mode to manage power use while the TV is off.

Setting Up TV Inputs

Start a channel scan (memorization) from the Setup menu.

Note: I

To start channel memorization

1. With the Setup menu displayed, press to high-

2. Press to highlight an input selection based on

Input Condition

Ant 1 Air Ant 2 Air

Ant 1 Cable Ant 2 Cable

f using a CableCARD, the TV will automatically acquire the complete list of available channels from the service provider. Perform channel memorization for if you need to reacquire the channel list.

light the Scan icon.

your connections:

When connected to an indoor or outdoor antenna

When connected to direct cable (no cable box)

ANT 1

CableCARD service only

When You First Connect a Device

This TV’s Easy Connect™ Auto Input Sensing feature detects most connections automatically. When you first connect a device, the TV will:

a. detect the connected device and automatically

switch to it b. prompt you to identify the device type c. prompt you to perform NetCommand set-up for

the device d. repeat these steps for any additional newly

detected devices

The tables below state which connections trigger Auto Input Sensing.

Auto Detection Active No Auto Detection

INPUT

COMPONENT

HDMI

DIGITAL AUDIO OUT

AVR AUDIO OUTPUT

USB (USB photo port on side)

Note: For connection and setup of a personal com-

video jacks

ANT 1

and

ANT 2

, right (red) analog audio jack only

If the device is powered off when connected, detection occurs when the device is next powered on.

puter, see the information later in this chapter.

2. TV Setup 15

Setting Up TV Inputs, continued

1. See chapter 3, “TV Connections,” for recommendations on connecting your devices.

2. Connect your devices to the TV, making note of which TV input is used for each device.

The TV and the devices can be either on or off when connecting.

First select a device type.

Auto Input Sensing screen for most device types.

3. Power on the TV if not already on. When the TV detects a connection, the Auto Input Sensing screen opens.

• Most Device Types: Specify the device

type and then, if desired, proceed directly to NetCommand setup.

a. In the Auto Input Sensing screen, press

to move through the device list to select the device type connected to the input. The device type you select here will appear in the Input Selection menu.

b. You can perform NetCommand IR “learn-

ing” now or at a later time. To perform now, highlight the Learn icon and press See chapter 6, “NetCommand” for more.

• A/V Receiver: The TV can detect audio connections on the and the right (red) analog jack.

Note for Analog A/ V Receivers: When you disconnect an analog A/V receiver, be sure to change the Speakers setting manually to TV to hear sound from the TV speakers.

You can perform “learning” for the A/V receiver now or at a later time. To perform now, highlight th

e Learn icon in the Auto Output Sensing screen and press “NetCommand” for more.

DIGITAL AUDIO OUTPUT

ENTER

. See chapter 6,

Next perform IR “learning.”

ENTER

jack

AVR AUDIO OUTPUT

desired. Program the TV’s remote control or perform NetCommand IR “learning” to add functions.

4 Press

EXIT

to close the Auto Input Sensing screen. The TV will then display the Auto Input Sensing screen for the next connection it finds.

More About Auto Input Sensing

• Choose a different name for each input.

• Antenna inputs ( although you can turn off unused antenna inputs in the Inputs > Name menu.

• You can change the device type at a later time using the Inputs > Name menu. Any “learned” NetCommand IR codes will be erased, however.

• If you wish to reset an HDMI input:

1. Disconnect the HDMI device.

2. Turn off the HDMI input in the Inputs > Name

menu.

3. Connect the new device and the Auto Input

Sensing screen will display. If you want the device under NetCommand IR control, perform NetCommand “learning” for the new device.

ANT 1/ANT 2

) are never detected,

Controlling A/V Receiver Sound Volume

Although the TV detects when you connect an A/V receiver, you must use one of the methods below to control sound volume from the A/V receiver.

With a Standard TV Setup

• Recommended Method: Program the TV’s remote control for your A/V receiver and enable the Audio Lock feature. See Appendix D, “Programming the Remote Control.”

• Program the TV’s remote control for your A/V receiver and set the TV remote’s slide switch to the

AUDIO

position to control volume. Set the switch

back to the TV position to control the TV.

• Use the remote control that came with the A/V receiver.

With NetCommand Control of an A/V Receiver

• Set up NetCommand control of the A/V receiver’s volume functions in the Inputs > AVR menu. The TV’s remote will then automatically control A/V receiver volume. See chapter 6, “NetCommand.”

• Use any of the methods described for the standard TV setup.

• HDMI Devices Compatible with the TV’s NetCommand for HDMI Feature: Compatible HDMI devices are often recognized automatically by the TV. The TV’s remote control may operate some device functions without further setup. You can add more control functions if

16 2. TV Setup

64&8*5)$BCMF$"3%

065165

*3&.*55&3

4&37*$&64&

0/-:'03

%*(*

5"-

"6%*0

"/5."*/

"/5"69

64&8*5)$BCMF$"3%

"/5."*/

KBDLBUSFBSPG SFDFTTFEBSFB



Using a CableCARD

The CableCARD™ system allows your TV to receive, decode, and unscramble the premium digital channels included in your cable TV subscription without the use of a cable box. The system is unidirectional, meaning that certain digital cable services, such as requests for video-on-demand and pay-per-view programs, a cable operator’s enhanced program guide, and dataenhanced television services may require use of a settop box instead. For more information, call your local cable operator.

Note: CableCARD requires the TV’s Fast Power On

setting. If you insert a CableCARD, the TV will automatically override a Low Power setting and change to the Fast Power On setting.

Installing a CableCARD

1. Connect your primary incoming cable to

ANT1/MAIN

on the back of the TV.

Displaying CableCARD Information

To display information needed by your service provider to start cable service, press menu appears, press

In order to start cable service for this device, please contact your cable provider 1-800-xxx-xxxx CableCARD(tm): xxx-xx x-xxx-xxx-xxx-x Host: xxx-xx x-xxx-xxx-x Data: xxx-xx x-xxx-xx Unit Address: xx-xx xxx-xx xxx-xxx

Press EXIT to exit.

9 9 9.

and when the Main

Sample CableCARD information screen. Write down the information before contacting your cable provider.

CableCARD Menu

CableCARD menu

Network Setup

CableCARD(tm) Status CableCARD(tm) Pairing Conditional Access

Back of TV

2. Power on the TV.

3. Open the access door and insert the CableCARD into the CableCARD slot with the top of the card oriented as shown in the diagram below

Location of CableCARD access door

Orient the CableCARD

as shown before

inserting it into the slot.

4. Wait a few moments while the CableCARD initializes. A message will display on screen when initialization is complete.

Sample CableCARD menu

To display the CableCARD menu with links to applications from your cable provider:

1. While watching CableCARD, press

INPUT

to open the

Input Selection menu.

2. With the CableCARD icon highlighted, press

open the CableCARD menu.

3. Press to highlight a link, then press

ENTER

access the linked page.

4. To redisplay the CableCARD menu, repeat steps 1 and 2.

5. Press

EXIT

to return to TV viewing.

If there are technical problems with the CableCARD, an error screen automatically displays with information that may be needed by your cable provider when you call them for assistance.

Moving Through Other CableCARD Screens

In addition to CableCARD menus, other CableCARD application screens may display and require you to make additional selections. When using these screens on your Mitsubishi television:

• Blue text denotes a function. Press

ENTER

to perform

the function.

• You cannot move backward through the links. To exit the CableCARD system, press

EXIT

. The

CANCEL

key may not work with some CableCARD screens.

Contact your cable provider if you have any problems with the application screen displays.

2. TV Setup 17

NPEFM

-5 0OMZ

4*%& 1"/&-



57

%7*UP )%.* $BCMF





4UFSFP "VEJP$BCMF

1FSTPOBM$PNQVUFS

XJUI%7*0VUQVU

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

1FSTPOBM $PNQVUFSXJUI )%.*0VUQVU

)%.*UP)%.*$BCMF



57#BDL1BOFM

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

3 -

.0/0

.0/0



"73065

%7**/

"73

"6%*0065165

1$%7*

"6%*0*/165



57#BDL1BOFM

57#BDL 1BOFM

%7*UP)%.* $BCMF





4UFSFP "VEJP$BCMF

Using the TV with a Personal Computer

Connecting a Computer to the TV

Use one of the connection methods listed below based on your computer’s video output.

Computer Video Output

Video Connection

Digital DVI DVI-to-HDMI cable

or an HDMI cable with an HDMI-toDVI adapter

Note: If the computer’s audio output is a single mini jack, a mini audio-toRCA-male “Y” adapter cable is also required.

HDMI HDMI-to-HDMI

cable

Audio

Connection

Stereo audio cables

No additional audio connection is required.

IMPORTANT

This TV accepts digital computer signals only.

1. See the TV specifications in Appendix B to confirm that your computer signal is compatible with the TV.

2. Connect the computer’s digital signal output to one of the TV’s

HDMI

jacks. See the connection dia-

grams for the method suited to your equipment.

3. Connect the computer’s audio output using one of these options:

• For digital DVI signals, connect analog left/right

audio to the TV’s

PC/DVI AUDIO INPUT

jack.

• For HDMI signals, no additional audio connec-

tion is required.

4. Power on the TV and computer. The TV will detect the connection and display the Auto Input Sensing screen.

5. In the Auto Input Sensing screen, press to highlight PC in the list of device types. You can change the type at a later time using the Inputs > Name menu.

6. Press

EXIT

to close the Auto Input Sensing screen.

DVI-to-HDMI connection with analog audio cables.

Above: Connection to the TV back panel. Below: Connection to the TV side panel.

HDMI connection to TV Back Panel #2. An HDMI-toHDMI connection carries all video and audio on a single cable.

Note:

If your computer provides digital audio output (coaxial or digital), you can connect it directly to a digital A/V receiver and bypass the TV.

18 2. TV Setup

Using the TV with a Personal Computer, continued

Computer Video Adjustments

1. Power on the computer if it is not already on.

2. Select PC from the Input Selection menu. To do this, press move the highlight to the PC icon, and press

3. Working from the computer, change the resolution of the computer image. View the computer image on the TV and maximize the computer resolution while maintaining a suitable aspect ratio for the image.

4. Perform TV video adjustments. Press video-adjustment options. The following additional adjustments are available for computer video:

Horiz Position (Horizontal Position). Manually adjust the horizontal position.

Vert Position (Vertical Position). Manually adjust the vertical position.

INPUT

to open the Input Selection menu,

VIDEO

repeatedly to access

ENTER.

Tip:

Set the computer’s screen saver to display a pattern after several minutes of inactivity. This acts as a reminder that the TV is powered on.

Computer Display Formats

Press the able for your computer’s video signal.

VGA 640 X 480

FORMAT

key repeatedly to cycle through the TV displays avail-

Computer Signal

Original Format

As Displayed on TV Screen

4 X 3

Standard

16 X 9

Standard

Zoom

5. Press

FORMAT

repeatedly to find the picture format best suited to the image. See the chart on this page showing how different computer resolutions are displayed on the TV.

Image Resolution

Your Mitsubishi TV can display resolutions from standard VGA (640 x 480) through 1920 x 1080 signals at a refresh rate of 60 Hz. The resolution of 1920 x 1080 is supported at refresh rates of 24, 30, and 60 Hz. See Appendix B in this book for more on compatible screen resolutions.

In most cases, the computer will select the best resolution match to display on the TV. You can override this setting if you wish. Refer to your computer operating system’s instructions for information on changing the screen resolution.

You may need to restart the computer for changes to take effect.

WVGA 848 X 480

SVGA 800 X 600

WSVGA 1064 X 600

Format Standard Zoom

XGA 1024 X 768

PC 720p 1280 X 720

WXGA 1360 X 768

SXGA 1280 X 1024

Format Standard

PC 1080p 1920 X 1080

TV Connections

INPUT

S-VIDEO

VIDEO

(MONO

)

RLL

(MONO)

(MONO

)

1 2 1 2

AVR OUT

DVI IN

AUDIO

COMPONENT

INPUTS

Note: One cable clamp (round) and one cable tie (ﬂat) are provided in the accessories bag.

Pre-installed cable tie with rivet (attached to case at factory)

Cable Clamp with Rivet

Cable Tie with Rivet

¡

5PQ7JFX

'SPOU

Before you Begin

Auto Input Sensing

The TV’s Auto Input Sensing feature automatically recognizes most connections and prompts you to identify the type of device connected. See chapter 2, “TV Setup,” for more on Auto Input Sensing.

Connection Types

Review the connection types available on your input devices and use connections that will give the best video quality. For example, choose HDMI over component video, and choose component video over S-video or composite video.

Picture Quality

For best picture quality, route video signals directly from the input device to the TV; avoid routing video signals through an A/V receiver, for example.

Cable Management

Sound Quality

For best surround sound audio quality, route audio signals from the input device directly to your A/V receiver or sound system whenever possible.

IMPORTANT

Accessory items such as cables, adapters, splitters, or combiners required for TV connections are not supplied with the TV. These items are available at many electronics stores.

One cable tie and one cable clamp are supplied loose and one cable tie is already attached (see illustration below). Use the clamp and ties to keep cables properly organized and connected. This is especially important if you need to swivel the TV on its stand. Use the clamp and ties as needed to control cables used in your set-up.

The TV can be swiveled up to 30 degrees left or right.

IMPORTANT

Be sure there is enough slack in the cables below the cable clamps/ties to allow the TV to swivel freely. Without enough cable slack, there is risk of damaging the cables and the TV.

20 3. TV Connections

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

"6%*0

: 1C











$"#-&*/PS 4"5&--*5&*/

*ODPNJOHGSPN $BCMF4FSWJDFPS 4BUFMMJUF%JTI

57#BDL1BOFM

$BCMF#PY PS4BUFMMJUF 3FDFJWFS

34

HDTV Cable Box or Satellite Receiver with Component Video

If your cable box or satellite receiver has an HDMI output, use the connections for HDMI devices described later in this chapter.

Required: RCA component video cables, left/right analog stereo audio cables.

1. Connect the cable from the outside cable or satellite service to cable box or satellite receiver. See your device’s owner’s guide for instructions and cable compatibility.

2. Connect RCA-type cables from the outputs on the HDTV cable box or satellite receiver to

COMPONENT INPUTS

#1, matching the colored green, blue, and red connections.

3. Connect left (white) and right (red) audio cables from the HDTV cable box or satellite receiver to

COMPONENT INPUTS L (MONO)

back panel #1.

CABLE IN

SATELLITE IN

on the

Y Pb Pr

on the TV back panel

and R on the TV

Note:

To hear digital surround sound, connect the digital audio output from your cable box or satellite receiver directly to your digital A/V receiver.

Figure 1. Connecting an external HDTV receiver with component video connections

3. TV Connections 21

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

57#BDL1BOFM

"/5."*/

)%.*%FWJDF

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

"6%*0065

7*%&0065

$"#-&*/PS 4"5&--*5&*/





"OZ47JEFP%FWJDF

57#BDL1BOFM

*ODPNJOH

$BCMFGSPN

8BMM





34

DMI Device (Cable Box, Satellite

Receiver, DVD Player, or Other Device

)

Required: HDMI-to-HDMI cable.

Connect an HDMI cable from the TV back panel #2 to

the HDMI device output. HDMI devices provide video and audio through the single cable.

Mitsubishi recommends you use category 2 HDMI

cables to connect HDMI 1.3 source devices. High-

speed category 2 cables bring you the full benefits of Deep Color and x.v.Color. See chapter 1, “TV Overview,” for more on HDMI cable types.

Standard Cable Box, Satellite Receiver, or Other Device with S-Video

Required: S-Video cable and left/right analog stereo audio cables.

1. Connect the cable from the outside cable or satellite service to cable box or satellite receiver.

2. Connect an S-Video cable from the cable box or satellite receiver back panel to

INPUT S-VIDEO

3. Connect left (white) and right (red) audio cables from

AUDIO OUT

receiver to back panel #1.

Note: Refer to the cable box or satellite receiver

Owner’s Guide for cable or dish antenna connections to the receiver.

CABLE IN

SATELLITE IN

S-VIDEO OUT

on the TV back panel #1.

on the cable box or satellite

INPUT AUDIO L (MONO)

on the

and R on the TV

Figure 2. Connecting an HDMI device.

Note:

HDMI and Audio Signals

• Digital Surround Sound: The TV’s HDMI

• A/V Receiver with HDMI. If your A/ V

HDMI inputs are certiﬁed for proper

interoperability with other products certiﬁed by Simplay™.

IMPORTANT

inputs can receive digital stereo audio signals only. To hear digital surround sound from an HDMI device, connect the device’s digital audio output directly to your A/V receiver. See the Owner’s Guides for those devices for instructions.

receiver has an HDMI input, use the audio connections described in “A/V Receiver (Sound System)” instead.

Figure 3. Connecting a device with S-Video

22 3. TV Connections

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

"/5."*/

"/5

"69

57#BDL1BOFM

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

"/5."*/

0IN

'MBU

5XJO-FBE

0QUJPOBM0INUP0IN

.BUDIJOH5SBOTGPSNFS

0IN $PBYJBM $BCMF

#

"

"

57#BDL1BOFM

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

"/5."*/

#BDL

7JFX

4JEF

7JFX

6)'"OUFOOB

$IBOOFMT

7)'"OUFOOB

$IBOOFMT

0INUP

0IN

$PNCJOFS

'MBU5XJO-FBE

6)'

7)'





5P"/5."*/

57#BDL1BOFM

&YUFSOBM "OUFOOB PS$BCMF

Direct Cable (no cable box)

(can be used with a CableCARD™)

You must connect the incoming cable for your

primary viewing source to CableCARD™ use.

1. Connect the primary incoming coaxial lead cable to

ANT 1/MAIN

on the TV back panel.

2. For an optional secondary antenna source, connect an antenna (or cable) to

3. If you have subscribed to a CableCARD service, Insert the CableCARD into the CableCARD slot.

ANT 1/MAIN,

ANT 2/AUX

especially for

Antenna with a Single Lead

A. For an antenna with flat twin leads

Required: 300-ohm-to-75-ohm transformer. A1. For an antenna with flat twin leads, connect the

300-ohm twin leads to the 300-ohm-to-75-ohm transformer.

A2. Push the 75-ohm side of the transformer onto

on the TV back panel.

B. For cable or antenna with coaxial lead

Connect the coaxial lead directly to

TV back panel.

ANT 1

on the

ANT

Figure 4. Connection for direct cable service

Antennas with Separate UHF and VHF Leads

Required: UHF/VHF combiner

1. Connect the UHF and VHF antenna leads to the UHF/VHF combiner.

2. Push the combiner onto back panel.

Figure 5. Connecting separate UHF and VHF Antennas

ANT 1/MAIN

Figure 6. Connecting a Single Antenna Lead

on the TV

Mitsubishi strongly recommends you avoid using antennas with flat twin leads. Flat twin lead antenna wires are subject to interference which may adversely affect the performance of the TV. We recommend using coaxial antenna cable.

3. TV Connections 23

"6%*0065

%7*065

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

3 -

.0/0

"73065

%7**/

"73

"6%*0065165

1$%7*

"6%*0*/165

%7*%FWJDF



57#BDL1BOFM

57#BDL1BOFM

%7*UP)%.* $BCMF

*/165

47*%&0

7*%&0

.0/0

3--

.0/0

   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

$0.10/&/57*%&0

"6%*0065

- 3

%7%1MBZFS

57#BDL1BOFM

34

DVD Player with Component Video

Component video cables and analog audio cables are required.

1. Connect the component video cables from

VIDEO OUT COMPONENT INPUTS

on the back of the DVD player to the

jacks on the TV back panel #1, matching the green, blue, and red colored connections.

2. Connect left (white) and right (red) stereo audio cables from player to

AUDIO OUT

on the back of the DVD

COMPONENT INPUTS L (MONO)

on the TV back panel #1.

Y Pb Pr

and R

DVI Video Device (Cable Box, Satellite Receiver, DVD Player, or Other Device)

Connect DVI devices (digital only) to the TV’s HDMI input jacks.

Analog stereo audio cables and a DVI-to-HDMI cable or DVI/HDMI adapter and HDMI cable are required.

1. Connect the DVI-to-HDMI cable (recommended) or HDMI cable with DVI/HDMI adapter from the DVI device’s back panel to the TV’s HDMI jack.

Note: If you are using a DVI/HDMI adapter, it is impor-

tant to connect the adapter to the DVI device for best performance.

2. Connect a set of audio cables from on the DVI device back panel to the

INPUT

on the TV back panel. Connect the red

cable to the R jack and the white cable to the

(MONO)

jack.

AUDIO OUT

PC/DVI AUDIO

Note: The HDMI connection supports copy protection

(HDCP).

Some devices require connecting to an analog input ﬁrst, in order to view on-screen menus and to select DVI as the ouput. Please review your equipment instructions for DVI connectivity and compatibility.

Figure 7. Connecting a DVD player with component video

Note:

See Appendix B for component video signal compatibility information.

For digital audio connections to your A/V receiver, see your DVD player and A/V receiver Owner’s Guides.

To hear digital surround sound from your DVD

player, connect the digital audio output from the

DVD player directly to your digital A/V receiver.

IMPORTANT

Figure 8. Connecting a digital DVI device

24 3. TV Connections

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFEBSFBBUUPQ

"/5."*/

065

-.0/0

"6%*0

065

47*%&0

"/5&//"

065

7*%&0

"6%*0

"/5&//"

065

47*%&0

065

57#BDL1BOFM

57#BDL1BOFM





34

VCR to an Antenna or Wall Outlet Cable

Required: Two-way RF splitter, two coaxial cables, right and left analog audio cables, either S-video or video cable.

1. Connect the incoming cable or antenna to IN on the RF splitter.

2. Connect one coaxial cable from splitter to

ANTENNA IN

on the VCR back panel.

3. Connect one coaxial cable from splitter to

ANT 1/MAIN

on the TV back panel. This

OUT

on the RF

OUT

on the RF

connection also allows you to use the TV Guide Daily feature.

4. To use the TV speakers with the VCR, connect left (white) and right (red) audio cables from on the VCR to

RIGHT

on the TV back panel. If your VCR is mono

INPUT AUDIO L (MONO)

AUDIO OUT

and

AUDIO

(non-stereo), connect only the white (left) cable.

5. Connect either an S-Video or composite video cable from

INPUT VIDEO

VIDEO OUT

S-VIDEO

on the VCR back panel to

on the TV back panel. Connect only one type of video cable; S-Video is recommended, if available.

Figure 9. Connecting a VCR to an Antenna or Wall Outlet Cable

3. TV Connections 25

065

-.0/0

"6%*0

065

47*%&0

"/5&//"

065

7*%&0

"6%*0

"/5&//"

065

47*%&0

065

"6%*0

47*%&0

$"#-&

065

"6%*0

47*%&0

*/165

47*%&0

7*%&0

.0/0

3--

.0/0

   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

57#BDL1BOFM

"UUBDIPOMZPOFUZQFPG WJEFPDBCMF47JEFP SFDPNNFOEFEJGBWBJMBCMF



*ODPNJOH $BCMF











34

VCR to a Cable Box (Audio & Video)

Required: Two coaxial cables, right and left audio cables, S-Video or composite video cable, plus cables required to connect the TV to the cable box.

1. Connect the incoming coaxial cable to CABLE IN on the cable box.

2. Connect one coaxial cable from OUT on the cable box to ANTENNA IN on the VCR back panel.

3. Connect the cable box outputs to the TV as shown in one of the options listed below. This connection allows the TV to receive the best available signal directly from the cable box. See the referenced figures in this chapter, “TV Connections.”

Option 1 (see Figure 1: Component video output to the TV’s analog stereo audio to the associated

COMPONENT INPUTS Y Pb Pr

AUDIO

jacks;

jacks.

Option 2 (see Figure 2): HDMI output to the TV’s

HDMI

jack.

Option 3 (see Figure 3): S-Video output to the TV’s

INPUT S-VIDEO

the associated

jack; analog stereo audio to

AUDIO

jacks.

4. To use the TV speakers with the VCR, connect left (white) and right (red) audio cables from on the VCR to

INPUT AUDIO L (MONO)

AUDIO OUT

and

AUDIO R

on the TV back panel #1. If your VCR is mono (nonstereo), connect only the white (left) cable.

5. Connect either an S-Video or composite video cable from

INPUT VIDEO

VIDEO OUT

INPUT S-VIDEO

on the VCR back panel to

on the TV back panel #1. Connect only one type of video cable. S-Video is recommended, if available.

Note: When using this connection conﬁguration with

the connections used in step 3, it is possible to view live cable programs through the VCR Device. For best picture quality, however, always view live cable programs directly from the cable

box device.

Figure 10. Connecting a VCR to a cable box

26 3. TV Connections

"!#+).0540!.%, BELOWLABELWITHINRECESSEDAREAATTOP

"/5."*/

065

$BCMF#PY

5P"/5."*/

57#BDL1BOFM

*/165

47*%&0

7*%&0

.0/0



3--

.0/0

.0/0



   

"73065

%7**/

"6%*0

$0.10/&/5

*/1654

"73

"6%*0065165

1$%7*

"6%*0*/165

$0.10/&/5

*/1654

JQQJ

"!#+).0540!.%, BELOWLABELWITHINRECESSEDAREAATTOP

"/5."*/

%JHJUBM$PBYJBM$BCMF 6TFUPDPOOFDUB EJHJUBM"7SFDFJWFS

4UFSFP"OBMPH$BCMFT 6TFUPDPOOFDUBO BOBMPH"7SFDFJWFS

57#BDL1BOFM

57#BDL1BOFM

34

A/V Receiver (Sound System)

Most setups require either a digital audio cable or analog stereo audio cables.

The TV makes all audio available in digital and analog

formats:

Analog audio coming into the TV is output in

digital stereo format on the

OUTPUT

jack (TV back panel #2).

Digital incoming audio is available as analog

output on the

AVR AUDIO OUTPUT, L

jacks (TV back panel #1).

Usually, only one of the following connections is required:

• To connect an analog A/V receiver

Connect left (white) and right (red) audio cables from

AVR AUDIO OUTPUT, L

panel #1 to the

TV AUDIO INPUT

• To connect a digital A/V receiver with Dolby Digital surround sound and PCM audio support:

Connect one end of the digital audio cable to

DIGITAL AUDIO OUTPUT

on the back of the TV

(back panel #2). Connect the other end to the

COAXIAL DIGITAL INPUT

on the back of the A/V

receiver.

DIGITAL AUDIO

and R

and R on the TV back

on the A/V receiver.

Important

A/V Receivers with HDMI Inputs

If your A/V receiver has an HDMI input, use one of the audio connections described here instead of an HDMI connection.

Note:

On rare occasions, an HDMI signal may be

copy-restricted and cannot be output from the TV as a digital signal. To hear these copyprotected signals through the A/V receiver, use connections for analog A/V receivers.

Check the A/V receiver’s Owner’s Guide for

information concerning use of the digital input and switching between digital sound and analog stereo sound from the TV.

Older Cable Box

Required: One coaxial cable.

Note: This connection is not recommended. The

other connections described in this chapter provide better quality audio and video to the TV and allow NetCommand to work with the cable box.

Figure 11. Connecting the TV to an A/V receiver

1. Connect the incoming cable to IN on cable box.

2. Connect one coaxial cable from box to

ANT 1/MAIN

on the TV back panel.

OUT

on the cable

Figure 12. Connecting an older cable box

3. TV Connections 27



574JEF1BOFM#PUUPN





574JEF1BOFM#PUUPN



574JEF1BOFM#PUUPN





Camcorder

Inputs on the side of the TV offer the most convenient way to connect a camcorder.

Jacks on the TV side panel offer the most convenient way to connect a camcorder

Composite Video Connection

Required: Analog stereo audio and composite video cables supplied with the camcorder.

1. Connect a composite video cable from on the camcorder to

INPUT 3/VIDEO

the TV.

2. Connect left (white) and right (red) audio cables from

AUDIO OUT

AUDIO L

and

on the camcorder to

AUDIO R

on the TV.

VIDEO OUT

Y/VIDEO

INPUT 3/

Component Y Pb Pr Video Connection

Required: Analog stereo audio and component video cables supplied with the camcorder.

1. Connect component video cables from on the camcorder to one of the TV’s sets of

PONENT INPUTS

jacks (TV Back Panel #1 or TV

Side Panel).

2. Connect left (white) and right (red) audio cables from

COMPONENT 3, L

AUDIO OUT

on the camcorder to

and R jacks on the TV side panel.

VIDEO OUT

COM-

Figure 13. Composite video connections for a camcorder

Figure 14. Component video connections for a camcorder

HDMI Connection

Required: HDMI cable supplied with the camcorder.

Connect the camcorder to the TV’s side panel.

Note: Three additional HDMI inputs are located on

Back Panel #2.

Figure 15. HDMI connection for a camcorder.

HDMI 4

jack on the

TV Operation and Features

Choosing a Viewing Source

Input Selection menu

Choose a viewing source from the Input Selection menu. The current TV input appears as a full-color icon in this menu.

1. Press Note: If there are only two inputs to the TV,

2. Highlight an input icon using .

3. Press

More About the Input Selection Menu

• To assign meaningful names to the icons, see the

• To rearrange the icons, see the Inputs > Order

INPUT

to display the Input Selection menu.

INPUT

switches between them without displaying the menu. The menu will display, however, if one of the two inputs is a CableCARD.

ENTER

to switch to the input and close the

menu.

Inputs > Name menu in chapter 5, “TV Menu Settings.”

menu in chapter 5, “TV Menu Settings.”

Sleep Timer

The Sleep Timer turns the TV off after the length of time you set.

Setting the Sleep Timer

1. Press

2. Press

3. Press

4. Press

Cancelling the Sleep Timer

1. Press

2. Press

Note: After ﬁve seconds of inactivity, the message box

SLEEP

on the remote control. An on-screen status display will appear and show the number of minutes before automatic shut-off.

SLEEP

additional times to increase the time in 30-minute increments up to the maximum of 120 minutes.

EXIT

or wait five seconds without pressing any

keys for the message to disappear.

SLEEP

to view the time remaining before the sleep timer turns off the TV.

SLEEP

to display the on-screen message.

SLEEP

repeatedly until OFF is displayed.

will disappear.

TV Tips

Turning the TV On or Off

To turn the TV on or off, point the remote control at the front of the TV and press the press the

Controlling Sound Volume

Press “Controlling A/V Receiver Sound Volume” in chapter 2, “TV Setup.”

Changing Channels (antenna sources)

To change channels:

• Enter the channel number using the number keys

POWER

button on the side panel of the TV.

VOL

/ to adjust the sound level.

on the remote control and press

POWER

key. Alternatively,

ENTER

. For a two-

Remote Control

POWER

: Turns TV power on and off.

2. Slide Switch: Selects the A/V device to be oper-

ated by the remote control. Set the slide switch to TV for operation of the TV and NetCommandcontrolled devices. Control of additional devices requires programing (see Appendix D, “Programming the Remote Control.”

SLEEP

: Sets the TV to turn off within 2 hours.

4. Digits/Letters: Press digits for channel numbers,

then press the

CANCEL

Use also for entering letters or names in menus. To select letters when naming channels, repeatedly

press the associated number key. Press the letter. Special characters are available with the 1 key (!, &, blank space) and 0 key (/, *, -).

—/CANCEL (SUB-CHANNEL/CANCEL)

channel numbers, adds a separator between main and sub-channel numbers. Clears Fav and some menu entries.

6. QV (QuickView™): Switches between the current

channel and the last channel viewed on

ANT 2

MUTE

: Turns TV sound on and off.

SPLIT

: Not used with this model.

FAV

(Favorites): Scans through memorized lists of

favorite channels. See “Setup Menu” in chapter 5,

“TV Menu Settings,” for more information.

10.

VOL

/ (Volume Up/Down): Changes sound

level.

11.

CH/PAGE

Scans up or down through memorized channels. Pages up and down through screens when used with the TV Guide Daily system or ChannelView .

12.

FORMAT

picture.

13.

LIST

: Works like the

receiver when “learned” for NetCommand or when the remote has been programmed for the device.

14.

INPUT

: Displays the Input Selection menu from

which you can select an input source to view, such as an antenna input ( device.

15. (Adjust Up/Down/Left/Right): Navigate menus and change settings.

16.

ENTER

: Selects a channel number or menu item.

17.

GUIDE

: Displays or removes ChannelView™ channel

listing for ings if TV Guide Daily is enabled. Displays DVD disc or top menu for a NetCommand-controlled DVD player.

ENTER

—

/ (Channel or Page Up/Down):

: Changes the shape and size of the TV

for faster tuning. Use numbers and

key to enter digital sub-channel numbers.

ENTER

to set

: When entering digital

ANT 1

LIST key for a cable box or satellite

ANT 1

and

ANT 1/2

ANT 2

) or a connected

, or TV Guide Daily list-

18.

19.

20.

21.

22.

7 8

2524

27 28

INFO

Displays an on-screen summary of the current device in use and any broadcast information available, including current V-Chip ratings information. See chapter 4, “TV Operation and Features,” for details.

AUDIO

: Selects individual audio settings to adjust.

VIDEO

: Selects individual video settings to adjust.

: Displays the main TV menu. When a sub-

menu is open, backs up one menu level.

EXIT:

Closes TV on-screen menus/displays.

30 4. TV Operation and Features

Remote Control, continued

23.

F1–F4

For devices under NetCommand control:

Perform NetCommand “Learning” to assign your choice of functions to the F1–F4 keys.

For devices operating independently of NetCommand: The F1–F4 keys work like the A, B,

C, D keys on some cable boxes, satellite receivers, and DVD players. Program the remote control for your equipment and test the keys. See Appendix D,

“Programming the Remote Control.”

25. (

Record/Playback Keys

Use any of these methods to enable the recording and playback commands:

• Program the remote control for your DVR, VCR, or

• Perform NetCommand IR “learning” for the device.

• Check HDMI devices for compatibility with the TV’s

24.

PAUSE

): Freezes a broadcast TV picture.

DVD player/recorder and set the slide switch to

DVD, CABLE/SAT

NetCommand for HDMI feature.

(

RECORD

, or

AUDIO

as appropriate.

Records with a VCR or DVR.

VCR

NetCommand for HDMI Devices

The TV’s remote may operate some functions of compatible HDMI devices able to receive commands through the HDMI cable. Test your equipment with the TV’s remote to find out which commands are supported. See below for commands that may be available, depending on the individual device. You can add commands using NetCommand IR “learning” after connecting and placing IR emitters for the devices.

Press

PLAY

on the device itself to:

• Turn on the TV if not already on

• Switch to the device (no need to display the Input Selection menu)

• Begin play of the device

VCR, DVD, and DVR functions that may be available:

Record/

Playback

Navigation

ENTER

—

(to cancel)

CANCEL

Channel Tuning Other

GUIDE

(content)

Digits

—

0–9

CANCEL

ENTER MENU

25. (

26.

27.

28. (

29.

Note: To operate other audio/video devices using

• See Appendix D, “Programming the Remote

• See chapter 6, “NetCommand,” for NetCommand

• For HDMI devices compatible with the

PAUSE

): Pauses a VCR, DVR, or DVD. See

above for use during TV viewing.

(

STOP

): Stops play of a VCR, DVR, or DVD.

(

REVERSE

): Rewinds a VCR. Reverse scans a

DVR or DVD.

PLAY

): Plays a VCR, DVR, or DVD.

(

FORWARD

scans a DVR or DVD.

the TV’s remote control:

Control.”

IR “Learning” of device keys.

TV’s NetCommand for HDMI feature, see “NetCommand for HDMI Devices“ on this page.

): Fast forwards a VCR. Forward

Resetting the Remote Control

If the slide switch is set to TV and the TV does not respond properly, reset the remote control.

1. Press and hold key blinks twice and goes off.

2. Release the

3. Press keys twice when you finish entering the code. While entering the code, pause for a moment between each key press to ensure it is recognized.

POWER

for several seconds until the

POWER

key.

0 0 9 3 5

and the

POWER

key will blink

Low-Battery Indicator

If you press a key and the replace the remote control’s batteries.

POWER

key blinks five times,

Care of the Remote Control

• Use only alkaline batteries.

• Be within 20 feet of the equipment.

• Do not press two or more keys at the same time

unless instructed to do so.

• Do not allow unit to get wet or become heated.

• Avoid dropping on hard surfaces.

• Do not use harsh chemicals to clean. Use only a

soft, lightly moistened cloth.

• Do not mix old and new batteries.

4. TV Operation and Features 31

ChannelView Channel Listings

ChannelView screen

ChannelView™ shows memorized channels on or

ANT 2

. It displays channel names and program information as sent by broadcasters or your local cable service provider and may be incomplete. No program information is displayed for analog channels. An analog channel name is displayed only if you assigned a name in the Setup > Edit menu.

• You can use either ChannelView or the TV Guide

Daily system to see channel listings. ChannelView is accessible via the the TV Guide Daily system. For details, see Appendix C.

• T

o receive ChannelView updates:

- Keep the Energy Mode set to Fast Power On

- Set the TV clock

- Leave the TV powered off for a while each day to receive updates.

Note: Whenever you watch a digital channel, listings

are updated for the channel you are watching.

GUIDE

key unless you activate

ANT 1

Using ChannelView

Feature Press Key

See ChannelView listings from ANT 1 or ANT 2.

Close ChannelView Press

Scan channels one by one.

Scan channels quickly.

Jump to listings for a specific channel.

See more of the program description (if available).

Move navigation to the program guide.

Move navigation to the channel guide.

Tune to the highlighted channel.

Press

GUIDE.

GUIDE

EXIT.

Press and hold or .

Press and hold PAGE /

Enter the channel number (see numbers in upper left of screen).

2. Press Press

Press .

Press

INFO

ENTER

32 4. TV Operation and Features

Status Display

Press the

INFO

key to see the on-screen status display. The most common displays are shown here. Seldom or never do all the status indicators appear at the same time.

Ant 1 7-1 KABC-HD Monday Night Football

HD 16:9 Standard St. Louis vs. Tampa Bay

TV-PG Fav1 Stereo English

Tuesday 9:10 PM Sleep 30 min

On-screen status display

sample information

MUTE Signal Strength

1615

Analog Sources Digital Sources

1. Source antenna or input Source antenna or input

Analog channel being received (antenna sources only)

Digital major and sub-channel numbers

(antenna

sources only)

3. Analog channel name (if named in the Setup > Edit menu or provided by TV Guide Daily); antenna

sources only.

4. Program name; displayed only if provided by TV Guide Daily.

5. Signal Type Being Received. Possible:

On antenna sources or

INPUT 1–3

: 480i

On component jacks: 480i, 480p, 720p, 1080i

Digital Channel Name (if broadcast, provided by TV Guide Daily, or if named in the Setup menu > Edit options; antenna sources only)

Program name (if broadcast or provided by TV Guide Daily; antenna sources only)

Signal Type Being Received. Possible:

On antenna sources: SD 4:3, SD 16:9, HD 16:9 On HDMI: 480i, 480p, 720p, 1080i, 1080p, all PC resolutions

6. Screen Format in use. Possible:

Analog 480i /480p signals: Standard, Expand, Zoom, Stretch, Stretch Plus, Narrow 720p/1080i signals: Standard, Wide Expand

Screen Format in Use. Possible:

SD 4:3, 480i, or 480p: Standard, Expand, Zoom, Stretch, Stretch Plus, Narrow SD 16:9 or HD 16:9, 720p, or 1080i: Standard, Wide Expand 1080p: Standard

7. Current Fav bank number of channel (antenna sources only)

8. Program description (if supplied by TV Guide Daily); antenna sources only

9. V-Chip rating (antenna sources or

INPUT 1—3

jacks

Current Fav bank number of channel (antenna sources only)

Program description (if broadcast or supplied by TV Guide Daily); antenna sources only

V-Chip rating (antenna sources only)

only)

10. Audio Source. Possible:

TV speakers, external sound system

11. Listen To indicator: Stereo, Stereo SAP, SAP

Audio Source. Possible:

TV speakers, external sound system

Stereo, Surround, Dual Mono (antenna sources only)

(antenna sources only)

12. (Does not apply) Current language (antenna sources only)

13. Day and time Day and time

14. Sleep Timer remaining time Sleep Timer remaining time

15. Mute indicator Mute indicator

16. (Does not apply) Signal strength indicator (antenna sources only)

4. TV Operation and Features 33

Fav (Favorite Channels)

Use the six Fav channel banks to store groups of your favorite channels from up a Fav channel bank for each of your favorite program types or set up a bank for each TV user.

You may prefer to perform Fav channel setup from a menu. See chapter 5, “TV Menu Settings,” and the Setup > Edit options.

Using Fav Channels

See the current Fav bank number Press

View channels in current Fav bank

Change Fav banks

ANT 1

and

ANT 2

. You can set

INFO

1. Press the

2. Press the FAV current Fav bank.

1. Press the

2. When tuning is complete and while the TV status display is still visible on screen, press the number key for the desired bank (1–6).

Note: Wait for the channel change to ﬁnish before pressing the number key.

FAV

Otherwise, the TV may ignore the Fav number.

ANT-1 4

480i Stretch TV-PG Stereo SAP

Channel and Fav numbers in the on-screen status display

key. Wait for the TV to tune to a channel in the current Fav bank. key repeatedly to cycle through the channels available in the

key. Wait for the TV to tune to a channel in the current Fav bank.

Fav2

FAV

If no Fav banks are set up The

Fav Setup Using Only the Remote Control

Add Fav channels 1. While watching TV, tune to the channel you want to add to the current

Remove Fav channels

This procedure removes the channel only from the selected bank and leaves the other banks unchanged.

FAV

key switches to the previously tuned channel; works like the QV key.

Fav memory bank. The default bank is Fav1. See the instructions above if you need to change to a different Fav bank.

2. Press and hold the memory bank number appear under the channel number, the channel has been successfully added.

1. While watching TV, press the

2. While the TV status display is still visible on screen, press the number key for the memory bank.

3. Press the screen status display.

4. While the channel number and Fav indicator (with correct bank number) are still displayed on the screen, press while the indicator is displayed. When the Fav indicator disappears after pressing

FAV

key repeatedly until you see the desired channel in the on-

CANCEL

FAV

key for about 2 seconds. When Fav and the

FAV

key.

CANCEL

. You must press

, the channel has been successfully removed.

CANCEL

34 4. TV Operation and Features

TV Signals and Display Formats

This is a 16:9 widescreen TV suitable for images available from HDTV and many DVDs. You can view olderstyle squarish images (4:3 aspect ratio) using one of the display formats described on this page. Press the

FORMAT

key to cycle through the available display formats. The TV remembers the format you last used for each device.

DVD Image Definitions

Image information may be stated on the DVD case. Some DVDs support both formats.

Anamorphic (or Enhanced for WideScreen TV)

DVDs recorded to properly show widescreen images on 16:9 TV sets using the Standard format mode (recommended)

Non-Anamorphic (or 4:3, 1:33:1, Letter Box, or Full Screen)

DVDs recorded for viewing on squarish TV screens. They may be full screen (4:3 or 1:33:1) which crops movies to fit the narrow TV, or letter box, which adds black top and bottom bars.

Signal Definitions

480i: Traditional interlaced signals from

2, INPUT 1–3, COMPONENT

and

HDMI

480p: Progressive-scan DVD signals on

and

HDMI

jacks.

720p and 1080i: High-definition signals received through

COMPONENT

and

HDMI

jacks. These signals

are always 16:9 (widescreen). SD 4:3: Standard-definition squarish-screen-format

signals from digital channels on

ANT 1

SD 16:9: Standard-definition widescreen-format signals

from digital channels on

ANT 1

and

ANT 2

HD: High-definition 16:9 widescreen signals from digital

channels on

ANT 1

and

ANT 2

ANT-1

jacks.

COMPONENT

and

ANT 2

and

ANT

TV Display Format Definitions

Standard: This is the full-screen format used by HDTV

signals. Use this format to display anamorphic DVDs with a 1.78:1 or 1.85:1 aspect ratio. Anamorphic DVDs with a 2.35:1 aspect ratio are displayed correctly but with top and bottom black bars. Narrow (4:3) images are stretched evenly from side to side. Available for all signals.

Expand: Enlarges the picture to fill the screen by cropping the top and bottom; useful for reducing the letter box top and bottom bars of non-anamorphic DVD images.

Zoom: Enlarges the picture to fill the screen by cropping the sides, top, and bottom; useful for removing or reducing the black top and bottom bars on anamorphic DVDs with a 2.35:1 aspect ratio.

Stretch: Stretches a narrow 4:3 image across the screen to display the entire image with less distortion than the Standard format.

Stretch Plus: Similar to Stretch, but minimizes distortion on the sides by expanding the picture to crop off portions of the top and bottom. Unless displaying a menu, press to adjust the vertical position of the picture.

Narrow: Displays narrow 4:3 images in their original shape. Adds black side bars to fill the screen.

Wide Expand: Enlarges the picture, cropping the image on both sides. Removes or reduces black side bars added to narrow images converted to 16:9 signals for digital broadcast.

Note: All high-definition channels send widescreen (16:9) signals, but not all such programming was created for this format. The broadcaster may stretch the image or add side bars to fill the widescreen area.

Original

Signal

Non-

anamorphic

or SD 4:3

Anamorphic

DVD

TV Display Formats. Press the

Standard Expand Zoom Stretch Stretch Plus Narrow

Distorted. Not recommended.

Recommended

Recommended for letterbox. See Note 1.

Distorted; not recommended. See Note 1.

Distorted. Not recommended. See Note 1.

Recommended for anamorphic

2.35:1 images. See Note 1.

FORMAT

key repeatedly to see different displays for the current program. Press the

key to see the name of the display format in use.

Recommended for standard broadcasts. See Note 1.

Distorted; not recommended. See Note 1.

Recommended for standard broadcasts. See Note 1.

Distorted; not recommended. See Note 1.

See Note 1

Distorted; not recommended. See Note 1.

Original

Signal

SD 16:9 or HD Digital

(broadcast with side bars)

Note 1

Available for 480i, 480p, and digital SD 4:3 signals only.

Note 2

Available for digital SD 16:9 and HD signals, 1080i, 720p; not available for 1080p signals.

Wide

Expand

Recommended to remove side bars. See Note 2.

INFO

4. TV Operation and Features 35

Viewing Camera Files

JPEG Photos and the USB Photo Port

1. Connect your USB card reader or USB drive to the USB Photo port on the side of the TV.

The USB Photo menu displays while files are being read. Wait until you see the completion message on screen before continuing.

JPEG Thumbnail Menu

Note:

Some manufacturers’ devices may be incompatible with the TV. If the TV is unable to display your photos, you can:

• Transfer

• Use the camera’s composite video output as described later in this chapter.

files to a different USB device.

Use these keys while viewing JPEG thumbnail images:

Keys for the JPEG Thumbnail Menu

ORMA

ENTER

Move the highlight from image to image.

T Rotate the thumbnail clockwise in 90˚

increments Play the slide show starting with the high-

lighted thumbnail.

Highlight the last thumbnail on the current page.

Highlight the first thumbnail on the current page.

USB Photo menu

2. Refer to the table below for use of the menu after files have been read.

USB Photo Menu Options

Start slide show. With the Slideshow icon high-

lighted, press or

Activate menu options.

Display or close the Main menu.

Display status for the file source.

Select a different connected device

Clear status display or menu to show the USB Photo menu

Highlight an icon and press

ENTER

to:

• start the slide show

• display picture thumbnails

• open the Media Setup submenu.

Press

MENU.

Press

INFO.

1. Press

2. Highlight the icon for a dif-

3. Press

Press

INPUT

ferent device.

ENTER

EXIT

USB Photo

ENTER

CH/PAGE /

EXIT

INPUT

Notes on Viewing JPEG Files

• The TV ignores all commands while reading files. for the completion message before continuing.

• Large files or high-capacity storage devices may take a long time to display. The screen will be blank while files are read.

• Use only one source device at a time.

Stop playback or change to a different TV input before disconnecting from the USB photo port.

Display the next or previous page of thumbnails.

Close the Thumbnail menu and display the USB Photo menu.

Close the Thumbnail menu and display the Main menu.

Close the Thumbnail menu and display the Input Selection menu.

Wait

IMPORTANT

36 4. TV Operation and Features

$PNQPTJUF 7JEFP$BCMF

0QUJPOBM

"VEJP$BCMF

Slide Show

Use these keys during the slide show:

Keys for JPEG Picture Slide Show

Begin or resume slide show playback

Pause or resume playback while in automatic advance mode.

ENTER

Advance to the next slide.

Go to the previous slide.

ORMA

T Rotate the slide clockwise in 90˚ incre-

ments. Stop slide show and display the USB Photo

menu.

INFO

Display status for the viewing device and current image.

INPUT

Note: Always press (

Display the Input Selection menu. Display or remove the TV Main menu.

STOP

) to stop slide show playback before disconnecting from the USB Photo port.

USB Photo Menu Compatible Picture Files

• Still images recorded on digital cameras using the Exchangeable Image File Format, version 2.1 (EXIF

2.1) standard for digital still cameras and Design Rules for Camera File Systems version 1.0 (DCF

1.0)

• Some images opened and resaved on a computer may not play back or may not display in the thumbnail list. This happens if the files were resaved in an incompatible format.

• Full path file names can be no longer than 50 characters and must end in a .jpg extension. Only the first 20 of the 50 characters will display.

• Images on storage devices with a capacity of over 256 MB can take a longer initial time to display.

Photos and Moving Video as Composite Video

Connect the camera to the TV using a composite video cable if:

• You are unable to see images using the USB photo port.

•

You wish to view moving video from the camera.

Media Setup Menu

Media Setup menu

In the Media Setup menu you can adjust the slide show display, number of repetitions, or display interval.

• Select either Auto or Manual advance. During manual operation, press or

ENTER

to advance to

the next slide.

• For automatic advance, select the number of times (frequency) to play the complete slide show: Once, Twice, or Continuous.

• For automatic advance, select the time interval for display of each slide. The interval you select here is the minimum time between slides; actual time may be longer for larger files.

• Press

EXIT

to close the Media Setup menu and

return to the USB Photo menu.

The TV’s USB Photo menu will be unavailable and you must control the slide show through the camera. Display resolution is standard-definition (480i).

1. Refer to the owner’s manual supplied with the camera for instructions needed for this setup.

2. Set the camera’s output signal type to NTSC and put the camera into playback mode.

3. With the camera still turned on, connect your digital camera’s composite video cable (usually yellow) to the

INPUT 3 Y/VIDEO

jack on the side of the TV. To hear audio, connect the camera’s audio output cable to the

INPUT 3 L-AUDIO

jack.

4. When the Auto Input Sensing screen displays, press

EXIT

or assign the name Camcorder.

5. Press

INPUT

to display the Input Selection menu.

6. Highlight the icon for the camera input and press

ENTER

If viewing photos, advance through the images manually or set the camera to advance automatically.

The TV can read JPEG files as created by the camera. If you edit a picture file on a computer and resave the image, the TV may be unable to read the resaved file.

IMPORTANT

Camera connection using a composite video cable

TV Menu Settings

Main Menu

Press

on the remote control to open the Main menu.

Icon Menu Name and Description

AV Menu

Captions Menu

Setup Menu

Inputs Menu

Lock Menu

Customize picture and sound settings.

Turn closed captions on and off; customize caption displays.

Perform basic TV setup. Set language, scan (memorize) channels, set the TV clock, edit channel options, lock TV use by channel, set Energy Mode, auto-on TV Timer.

Assign names to TV inputs, change icon order in the Input Selection menu, perform NetCommand IR “learning,” set up TV Guide Daily.

Restrict TV use by program ratings and by time of day. Disable the side-panel control buttons. Set a pass code.

Remote Control Keys for the TV Menu System

Key Function

EXIT

(Adjust Left/Right Keys)

(Adjust Up/Down Keys)

ENTER

Numbers

Letters

CANCEL

INFO

Display or close the Main menu or move back one menu level.

Close all menus and return to TV viewing.

• Move through screens to select menu options.

• Change settings.

• Scroll through lists.

Start an automatic function or check/uncheck a check box. When setting time, move from hour digits to minute digits and from month to day to year digits.

Enter channel numbers. Enter your ZIP code for the TV Guide Daily system. Enter letters for custom names in some text boxes.

• Clear a setting or stop an automatic function.

• Add a separator in a digital channel number. Get context-sensitive help.

Main menu

38 5. TV Menu Settings

AV Menu

An on-screen slider displays when making some audio and video adjustments. Numeric values represented on the slider range from 0 (minimum) to 63 (maximum), with 31 as the mid-point.

AV Menu Options

Video See the description of video adjustments later in this section.

AV menu for audio and video adjustments

Audio See the description of audio adjustments later in this section.

Reset

PerfectColor

Global

• To reset audio and video adjustments for the current input, highlight the Reset icon and press

ENTER

• Reset has no effect on settings for Balance, Listen To, Language, and Film Mode.

PerfectColor Sliders

PerfectTint Sliders

Highlight the PerfectColor™ icon and press are retained in memory independently for each TV input.

•

To switch between PerfectColor™ and PerfecTint™, highlight

• Press to move from one color bar to the next.

• Press to change settings.

• Press

Video Noise

Video Mute On, Off On

CANCEL

to restore default settings.

to return to the Main menu.

Adjust the saturation (intensity) of six colors for the current image source.

Adjust six hues for the current image source

ENTER

to display the PerfectColor menu. Settings

High, Medium, Low, Off

Adjust Mode

Reduce minor noise (graininess) in the picture. Use Low with good-quality signals. Use High with poor-quality signals. Use Off to leave the picture unaltered. Saved by input

displays a blue background when there is no signal on the

current INPUT, COMPONENT,

HDMI jack

and press .

Film Mode

(for 480i and 1080i signals only)

SharpEdge On, Off Use SharpEdge™ to add special edge enhancements to

Smooth 120hz Demo

Blue Glow On if TV

Auto, Off

Off, On

off, On if TV on, Off

Auto

, the TV automatically detects and applies filmdecoding correction. Try the many jagged edges. Saved by input.

make the image appear sharper. Saved by input

Use On to see a demonstration of Smooth120Hz™ processing.

Select Off to keep the decorative blue light turned off at all times; select one of the On options if you wish to see the blue light.

Off

setting if images show

5. TV Menu Settings 39

Video Menu

Assign names to TV inputs (use

the Inputs > Name menu) will be reset to the defaults if you name or rename inputs afterwards.

To make video adjustments:

• From the Video menu:

1. Press to highlight an option.

2. Press to display the submenu and adjust.

3. Pre

• While watching TV: Press the

display the video option you want to change. Press

Video Menu Options

Picture Mode Brilliant

to return to the AV menu.

to change settings.

before making video adjustments

. Otherwise, adjustments

VIDEO

key repeatedly to

For use under strong light; not available when the device name is

Game Optimize picture/video processing for gaming

consoles. Available only when the name of the input is Game or PC.

Bright For most daytime viewing and x.v.Color sources

Game

AV menu, Video options

Note: See chapter 2, “TV Setup,” for additional adjust-

ments available for images from a computer.

Set the Picture Mode first

or PC.

before changing other video settings, as some are stored independently for each Picture Mode. Use Picture Modes to optimize the image for different conditions.

Natural

Contrast • Adjust the white-to-black level

• Low contrast shows a variety of shades in darker images

• In most home lighting situations, medium contrast looks best.

• High contrast shows darker images more uniformly black and makes colors appear more vibrant. High contrast is good for brightly lit environments.

• Settings are stored independently for each Picture Mode.

Brightness • Adjust overall picture brightness

• Settings are stored independently for each Picture Mode.

Color Adjust overall color intensity

Tint Adjust the red-to-green ratio.

Sharpness Adjust picture detail and clarity.

Color Temp Adjust the white balance. Settings are stored independently for each Picture Mode.

High Give white images a cool cast. May provide the most realistic picture under

Low Give white images a warm cast. Natural/Color Temp at the low setting displays

Deep Field Imager

For most nighttime viewing and x.v.Color sources

bright lighting.

video at approximately the 6500K industry standard for NTSC pictures.

With DeepField™ Imager active, black levels are dynamically enhanced in portions of the screen to provide strong contrast with detail over mixed screen content.

Backlight

Off Contrast is adjusted uniformly across the entire screen.

Demo Display a split picture to show on (right side) or off (left side).

Adjust peak brightness of the backlight. Factory default is maximum brightness.

40 5. TV Menu Settings

Audio Menu

To make audio adjustments:

• From the Audio menu:

1. Press to highlight an option

2. Press to display the submenu and adjust.

3. Press

• While watching TV: Press the to display the audio option you want to change. Press to change settings.

Audio Menu Options

Speakers The Speakers option displays only if an A/V receiver connection has been detected.

to return to the AV menu.

AUDIO

key repeatedly

AV menu, Audio options

TV Turn on the internal TV speakers.

AV Receiver Turn off the TV speakers and hear sound only from a connected A/V receiver.

Bass Control volume level of low-pitched sound from the TV speakers.

Treble Control volume level of high-pitched sound from the TV speakers.

Balance Control audio balance between the right and left TV speakers

Surround Off No surround effects from the TV speakers (default)

Listen To

(analog channels from

ANT1/ANT2

only)

Simulated Stereo

Surround Sound

Stereo Default setting. The TV plays stereo broadcasts in stereo and mono broadcasts

SAP

(Second Audio Program)

Mono Reduce background noise. Use when receiving a weak stereo audio signal. All

Create a simulated stereo effect through the TV speakers when watching a monaural (non-stereo) program.

Create a simulated surround effect through the TV speakers when watching a stereo program.

in mono. The word Stereo is displayed when you tune to a channel broadcasting in stereo.

Select an additional monaural sound track not audible during normal TV viewing. The SAP signal might be related to the program (such as a sound track in a foreign language), or it might be unrelated (such as a weather report). If an SAP signal is broadcast, the letters SAP are displayed when you tune to the channel

audio is played as mono with this setting.

Language

(digital channels from

ANT1/ANT2

only)

Level Sound On, Off Reduce differences in sound volume between programming segments, such as

English French German Italian Portuguese Spanish Other

Select the current language for a digital program from an digital program may include up to seven language choices or no choice at all.

the difference between regular broadcast programs and commercial segments.

ANT

input. Each

5. TV Menu Settings 41

Captions Menu

Captions on Analog Channels

The TV can decode captions from

INPUT 1–3

dard closed captions or text service. Standard closed captions follow the dialogue of the program and display in a small section of the screen. Text-service closed captions often contain information such as weather or news and cover a large portion of the screen.

• Analog text-service options display a large

• The content of captions is determined by the

•

Captions Menu Options

Closed Captions

jacks. Broadcasters can send either stan-

IMPORTANT

black or gray box on the screen when no signal is being broadcast.

broadcaster. If captions show strange characters, misspellings, or odd grammar, it is not a malfunction of the TV. Closed caption signals are not available through HDMI or component jacks. See the menus for these devices for closed-caption decoding.

Analog Captions

ANT 1/ANT 2

On if Mute CC 1–CC 4 Text 1–Text 4 Off

and the

• On if Mute: Display analog closed captions signal CC 1

• CC 1–CC 4: Standard closed-caption signals

• Text 1–Text 4: Text-service signals

Captions on Digital Channels

The TV can decode captions from ANT 1/ANT 2

only.

Broadcasters can send up to six different captioning selections or can send analog captions that match those sent by the analog station. A TV station may broadcast only one or two types of captions or none at all.

Digital Settings menu. Check the caption test area (upper right) to see how custom settings look.

when audio from the TV speakers is muted. When watching TV, press

MUTE

to turn captions on/off.

devices

Digital Settings

Analog Background

Digital Captions

Font

Font Size

Font Color White, Black, Magenta, etc. Guidelines for setting digital captions:

Font Opacity Translucent, Opaque, Flashing,

Background Color

Background Opacity

Gray, Black Select either a gray or black text background to make analog

closed captions easier to read.

On if Mute Caption 1– Caption 6 Off

Default Font 1–Font 7

Large Standard Small

Transparent

White, Black, Magenta, etc.

Translucent, Opaque, Flashing, Transparent

• On if Mute: Display digital closed caption signal Caption 1

when audio from the TV speakers is muted. When watching TV, press

• Caption 1–Caption 6: Caption signals sent by the broadcaster

Default changes settings to those selected by the captions provider, or, if none, to the TV’s own caption defaults. Use Fonts 1 through 7 to give captions a custom appearance.

Large is the recommended size.

MUTE

to turn closed captions on/off.

• Use contrasting colors for captions and background.

• Check readability of captions using the sample text in the upper right corner of the menu.

• A white font on a black translucent

background makes an easy-to-read combination.

42 5. TV Menu Settings

Setup Menu

Use the Setup menu to:

• Select English or Spanish for menus and on-screen text.

•

Scan the channels available from the antenna or cable service connected to the ANT 1

• Edit channel options, including channel locking.

• Set the TV’s internal clock.

• Set the TV Timer to turn on the TV automatically at a designated time.

• Set the energy mode for power consumption when the TV is powered off.

Setup Menu Options

ANT 2

jacks

Setup menu, Scan option

English Spanish

Language

Ant-1 Air

Scan

Notes on Scan and channel memorization:

• Channel memorization may take up to 15 minutes to complete.

• To stop channel memorization before completion, press

CANCEL

• When watching TV, press CH to move through memorized channels.

• If you restart memorization, previously memorized channels for the selected input will be erased.

• If using TV Guide Daily, the channels displayed and their order are independent of the TV’s channel memorization. Refer to Appendix C for more information.

• I

f using a CableCARD, the complete list of available channels is provided through the CableCARD. There is no need to perform channel memorization for

ANT 1

CableCARD service unless you wish to clear channels from memory and reacquire the channel list from the service provider.

Ant-1 Cable Ant-2 Air Ant-2 Cable

Display on-screen menus in either English or Spanish.

Note: To listen to audio in other languages (when available), see the section on the AV menu, Audio submenu, and refer to either Listen To > SAP (analog signal) or Language (digital signal).

Scan memorizes broadcast channels to make them easier to find. To start channel memorization:

Highlight one of the input selections based on your connection to ANT 1 or

ANT 2

• Air when connected to an indoor or outdoor antenna.

• Cable when connected to direct cable (no cable box)

2. Press to highlight START.

3. Press

ENTER

to start channel memorization for the selected input.

•

To add a digital channel that does not appear in the Edit menu without repeating channel memorization:

1. Look up the physical channel number for the new digital channel. The website www.antennaweb.org can help you find the physical channel number.

2. Tune to any channel on the input your antenna is connected to.

3. Use the number keys and physical channel number followed by “-1” and

ENTER

. For example, for physical channel 36,

press

—

3 6

The TV will search for a digital channel on the channel 36 frequency. When it finds the channel, it will:

a. Add the channel to memory. b. Change the channel number to the virtual

channel number sent by the broadcaster.

c. Add any associated sub-channels to

memory.

CANCEL

ANT 1

—

CANCEL

ENTER

ANT 2

to enter the

5. TV Menu Settings 43

Setup Menu, continued

Edit

Virtual Channel Number (digital channels only). A

channel number sent by a local broadcaster. Usually the virtual number is associated with the corresponding analog channel number. For example, a broadcaster may associate digital channel 2-1 with their analog channel 2.

Physical Digital Channel Number. The channel number officially assigned to the actual broadcast frequency; shown on screen in parentheses.

Setup Menu Options

Setup menu, Edit channel options

Edit

Use the Edit menu to edit channel options when To highlight a channel number to edit:

• Press CH / to jump to the next page of channel numbers. Press and hold CH / to speed through pages.

• Press to move through all channel numbers, one at a time. Press and hold to speed through channel numbers.

The TV tunes to the highlighted channel on release of CH / or .

Channel Channels marked with a check are in memory. To add or delete a channel from

memory, highlight the channel number and press not in the list, see the notes under Scan.

Digital channels are listed by virtual channel number with the physical channel number shown in parentheses.

Name Assign a custom name up to six characters long to memorized channels. You can

name analog channels and digital channels if broadcast without pre-assigned names.

With the cursor in the Name field, press a number key repeatedly to cycle through the characters associated with the key, including !, &, blank (1

2. Press

Note: When the TV Guide Daily system is enabled, the name displayed is the name provided by TV Guide Daily instead of the name you assign here.

Fav1–Fav6 Use the six Fav channel banks to store groups of your favorite channels. For example,

you can set up a Fav channel bank for each of your favorite program types (e.g., sports, news, children’s programs) or set up a bank for each TV user.

• Use to move the highlight through the Fav area of the screen.

• Press

• The same channel can be added to multiple Fav banks

• Note: To set up Fav channel banks without using this menu, see chapter 4, “TV

Operation and Features.”

ENTER

to set the letter and move to the next letter position. To delete the

current character and move back one position, press

ENTER to insert a check mark to add the highlighted channel to one of the Fav

banks.

To remove a channel from a Fav bank, highlight the check mark and press

ANT 1

ANT 2

is the current source.

ENTER

. To add a single digital channel

key) and /, *, - (0 key).

CANCEL

ENTER

Lock Lock channels so that a pass code is required to view them. When you rememorize

channels, all lock settings are cleared. Highlight the Lock column and enter a pass code when prompted. If you previously

set a pass code to open the main Lock menu, use the same pass code. See the description of the Main menu > Lock for more on pass codes.

• Press

• To unlock a channel, highlight the check mark and press

ENTER

to insert a check mark to lock the highlighted channel.

ENTER.

44 5. TV Menu Settings

Setup Menu, continued

Clock

Use either the manual or auto method to set the clock. Set the clock if you wish to:

• Use the TV’s Timer function.

• Maintain accurate ChannelView listings.

Setup Menu Options

Settings Manual. To set the clock manually:

Clock

1. Select Manual. 2 Set the time of day.

3. Set the date.

4. Select your time zone.

5. Select either Applies or Ignore for Daylight Savings Time.

Setup menu, Clock options

Time

(Manual option only)

Date

(Manual option only)

Note: If using Manual, each time the time change occurs, you must open this menu and set the TV’s clock ahead or back.

Auto. To set the clock automatically:

1. Select Auto.

2. Select your time zone.

3. Select either Applies or Ignore for Daylight Savings Time.

4. After exiting the menus, tune the TV to a station carrying XDS data, typically an analog PBS station.

Note:

•

With the Auto setting, the TV’s clock adjusts automatically to daylight savings time.

• The TV’s clock will be reset if you tune to a channel sending incorrect time data. To prevent unwanted clock resets, first use the Auto method to set the clock from a channel sending the correct time, then change the method to Manual.

1. With the hour highlighted, press AM/PM indicator. Press and hold to change the hour display quickly.

2. Press

3. With the minutes highlighted, press to change the minutes. Press and

2. With the day highlighted, press to select. Press

3. With the year highlighted, press to select the current year.

ENTER

to set the hour.

hold to change the minutes display quickly.

With the month highlighted, press to select. Press ENTER

repeatedly to change the hour and the

to set.

ENTER

to set.

Time Zone

Daylight Savings Time

Eastern, Central, Mountain, Pacific, etc.

Applies Ignore

Required for both the Manual and Auto methods.

Required for both the Manual and Auto methods. Select the option for your area.

5. TV Menu Settings 45

Setup Menu, continued

Timer

Use the Timer to set a time for the TV to turn on automatically. Use this menu to set a day, time, input, and channel for the Timer. If the TV is already on at the requested time, the TV will automatically tune to the designated channel.

• The TV clock must be set before you can use the Timer feature.

• After the Timer turns on the TV, press any key on the remote control to keep it on. Otherwise, the TV will turn off after five minutes.

• The

Setup Menu Options

POWER

indicator flashes slowly while the TV is off

to indicate the TV Timer has been set.

Timer On, Off

Setup menu, Timer options

Timer

Energy

Day Daily, Mon-Fri, (every) Sunday, (every) Monday, (every) Tuesday, etc.

Select the day or days of the week for the Timer to turn on the TV.

Time To set the time for the TV to come on:

1. With the hour highlighted, press repeatedly to change the hour and the AM/ PM indicator. Press and hold to change the hour display quickly.

2. Press

3. Press t

Input Ant-1, Ant-2, DVD, VCR, etc.

Select the input you want displayed when the TV comes on. Choose from the defined and enabled inputs that appear in the Input Selection menu.

Channel

Use the Energy Mode option to select the level of power consumption while the TV is turned off.

Energy Mode

If the input is an antenna ( scroll quickly through the available channel numbers.

Fast Power On The default setting.

Low Power Uses less energy, but TV power-on takes longer (about 60

ENTER

to highlight the minutes.

o change the minutes. Press and hold to change the minutes display quickly.

ANT 1, ANT 2

seconds) and some TV features may be unavailable. Note: When the TV is first powered off, it remains in Fast Power On mode for 30 seconds before switching to Low Power mode. During that time, the TV will turn on without the Low Power 60-second delay.

), press repeatedly or press and hold to

Keep this setting at Fast Power On if you need to:

• Have faster power on.

• Receive updates to ChannelView channel listings.

• Receive updates to the TV Guide Daily program listings.

• Keep the TV Clock accurate for the TV Timer. With the Low Power setting, you must reset the TV Clock if the TV is left turned off for over 48 hours.

• Activate the Side Panel Lock.

Note: TV Guide Daily and CableCARD™ require the Fast Power On setting. If you activate TV Guide Daily or use a CableCARD, the TV will automatically override a Low Power setting and change to the Fast Power On setting.

46 5. TV Menu Settings

Inputs Menu

Note:

When you change an input name in the Name menu and then exit the Name menu:

The name is changed

The icon in the Input Selection menu is changed

Audio and video settings are changed to the

defaults for the new device type.

All NetCommand “learning” for the input is also

erased.

Inputs Menu Options

Change input names using the Inputs > Name menu.

Name

Order

Learn

AVR

Cable Box, Camcorder, DVD, DVD2, DVR, Game, HD Disc, Satellite, VCR, PC

On/Off (

and 2 only)

Off (HDMI only)

Put frequently used icons at the start of the Input Selection menu.

1. Press to highlight the icon to move.

2. Press

3. Press to drag the icon to the desired position.

4. Press

• Perform initial set-up of NetCommand control of a device.

• Add or remove individual keys from NetCommand control of a device.

See detailed instructions in chapter 6, “NetCommand.”

Set up NetCommand control of an A/V receiver. This set-up allows you to:

• Operate the A/V receiver’s power and volume functions with the TV’s remote control.

• Make the A/V receiver switch automatically to the correct audio input when you select a

ANT 1

ENTER

device in the TV’s Input Selection menu.

• Assign or change names of inputs appearing in the Input Selection menu.

• Turn Ant-1 and Ant-2 On or Off.

• Turn unused HDMI inputs Off.

• Press to move between inputs.

• Press to select a name.

• If you change the name of an input after performing NetCommand

to confirm the selection.

to set the new position.

“learning,” the IR codes you “learned” are erased.

Note: Input Selection menu until you remove it. To remove an unwanted HDMI icon, select Off for the HDMI input.

When you disconnect an HDMI device, the icon remains in the

Guide

See detailed instructions in chapter 6, “NetCommand.”

Guide On/Off

Devices Ant-1, Ant-2

Zip Code [5-digit ZIP code]

Enable/disable or set up TV Guide Daily. See instructions on the following page.

5. TV Menu Settings 47

Inputs Menu, continued

Setting Up TV Guide Daily

Setup of the TV Guide Daily system is optional.

1. Display the Inputs > Guide menu to display TV Guide Daily setup options.

2. To enable the TV Guide Daily system, highlight On. If you wish to disable the system, highlight Off.

Inputs > Guide menu for TV Guide Daily setup

3. Select program sources for the listings. You can select one over-the-air source and one direct cable source for TV Guide Daily. If, however, you have multiple cable sources, the channel-number assignments may not match up correctly. See the following table and notes for the preferred connection combinations.

If One Source Is:

Ant-1 Channels via Cable N/A

Ant-2 Channels via Cable N/A

Note:

- Inputs to TV Guide Daily can include only one

over-the-air source and only one direct cable source.

- TV Guide Daily listings can be downloaded

from an over-the-air antenna or direct cable connected to

4. Move to the ZIP Code digits and enter the five-digit ZIP code for your location. To receive the correct program listings for your area, you must enter the ZIP code.

The Other Source Can Be:

Ant-1 Air Ant-2 Air

ANT 1

ANT 2

IMPORTANT

•

Operation of TV Guide Daily requires overthe-air or direct cable (no cable box) access to stations carrying TV Guide Daily program listings.

If listings are not available in your area or become discontinued by the local provider, TV Guide Daily will not operate. TV Guide Daily does not provide program listings for satellite TV systems.

•

TV Guide Daily listings will NOT be available if:

- TV Guide Daily is not set up as described in this section.

- No ZIP code is entered in the Inputs > Guide menu (setting remains at 00000).

- No antenna is selected in the Inputs > Guide menu.

•

The TV must be powered off for a while each day to allow new listings to download.

•

After initial setup, it may take up to 24 hours to receive program listings.

• After the initial listings download is complete, if there is more than one channel lineup available in your area, a lineup selection screen will be displayed the next time you press the on-screen instructions to choose a lineup.

• If TV Guide Daily is turned off, the source selection (antenna) settings and ZIP code will be cleared. If the Guide is turned back on, you will need to re-enter the ZIP code and reselect the antenna source(s). When the Guide is turned off for a period of time and then turned on, it may take up to 24 hours to receive current program listings.

GUIDE

. Follow

Using TV Guide Daily

• With the Guide set up and enabled, use the TV remote control’s system.

• See Appendix C for detailed information about the Guide.

GUIDE

key to launch the TV Guide Daily

48 5. TV Menu Settings

Lock Menu

TV locks available from the Lock menu are:

Lock by Ratings

Parent

Other

Time

Restrict access to programming based on V-Chip rating signals sent by the broadcaster.

Lock by Time

Restrict TV use by time of day.

Lock Side Panel

Side Panel

Note: Channel Lock is an additional lock that blocks

access to speciﬁc channels. Channel Lock is available under the Setup menu (Setup > Edit > Lock).

Disable the controls on the side panel of the TV. Use this option if small children in the home try to press the control buttons.

Pass Codes

Setting a Pass Code

You are prompted to enter a pass code whenever you select Lock on the Main menu. To set a pass code for the first time:

1. Press

2. Input a four-digit pass code using the number keys

3. Press

, highlight Lock, then press . A screen

prompting you for a pass code will display.

on the remote control.

• Press

CANCEL

to delete a number and move back

one space.

EXIT

to close the menu without

setting a pass code.

ENTER

to set the pass code.

The Lock > Parent menu lets you set parental controls using V-Chip technology.

Parent Menu

The TV comes from the factory with the rating locks turned off and with pre-set U.S. ratings TV-PG and movie rating PG. Turn on blocking for U.S. ratings to activate these rating restrictions. Use the Lock > Parent menu to change the level of blocking with U.S. ratings.

Any time you change the channel or device, it may take up to five seconds for the rating restrictions to take effect.

Other Menu (Alternate Rating System)

This TV can recognize new rating systems that may come into effect in the future. The Other menu allows you to block digital programming when such systems come into effect.

The first time you tune to a channel broadcasting an alternate rating system, the TV defaults to the most restrictive setting if the Lock menu > Other Lock option is set to On. Use this menu to change the allowed rating if you are unable to watch a program broadcast with an alternate system.

Resetting a Pass Code

See the procedure in Appendix A.

Important Notes on Rating Locks

•

Parent menu rating locks apply only to channels and signals received on ANT 1, ANT 2

INPUT 1–3

• Other nels received on ANT 1

• When viewing a cable box, satellite receiver, or other device connected to the

HDMI

locks.

jacks.

menu rating locks apply only to digital chan-

ANT 2

inputs, check the device’s menu for rating

, and the

COMPONENT

Bypassing TV Locks

If you try to watch a blocked program or channel or try to use the TV while it is locked by time, a notice appears prompting you for a pass code. To use the TV:

• Input your four-digit pass code and press

• Change to a channel airing an allowed program or change to another device.

To reactivate the parent ratings lock or TV Lock by Time after using the pass code:

• Power the TV off and then on to reactivate both locks.

• Change to a different channel or device to reactivate only the parent ratings lock.

ENTER

5. TV Menu Settings 49

Lock Menu, continued

Parent Menu Options (U.S.-based rating system)

Option Name and Description

Lock Off, On

TV Rating

FV Fantasy Violence. Applies to TV-Y7 only.

D Sexual Dialog. Applies in differing degrees to TV-PG and TV-14.

V Violence (graphic or realistic). Applies in differing degrees to TV-PG,

TV-Y Youth. For children under 7. Highlight the rating level

TV-Y7 Youth 7 and older.

TV-G General Audience. For the entire family.

TV-PG Parental Guidance. Parental Guidance recommended; may

TV-14

TV-MA Mature Audience. For adults only.

Adult Language. A

Sexual Situations. Applies in differing degrees to TV-PG, TV-14, and TV-MA.

TV-14, and TV-MA.

Disables or enables program blocking based on V-Chip signals and the U.S. rating system.

not be suitable for some children.

Adolescent 14 and older. Not recommended for children under 14.

pplies in differing degrees to TV-PG, TV-14, and TV-MA.

you wish to change and press

ENTER

to block it

( ) or allow it ( ).

You can apply supplemental content blocking to the age-based ratings by using the TV content categories listed below.

TV Content

NetCommand

About NetCommand

• The IR “Learning” feature of NetCommand allows the TV to determine the IR control signals for your A/V devices.

• NetCommand setup is optional.

• You can perform NetCommand setup when the TV first recognizes a device during Auto Input Sensing or at any convenient time afterward.

• NetCommand operates by sending remote control signals from the TV to your other devices via the IR emitters, telling the devices to play, record, change inputs, adjust volume, change channels, or perform other functions. All this is accomplished with the TV’s remote control and the slide switch left in the

position.

• You can choose the level of NetCommand control for your home theater.

Standard Setup. Perform a standard setup if

you want NetCommand to control A/V devices, such as the TV, a playback device (like a DVD player), and a cable box. With this setup, you can use the TV’s remote control to operate these devices.

A/V Receiver Setup. Perform A/V receiver

setup if you want NetCommand to:

Control a surround sound A/V receiver. Automatically change audio input selections

on an A/V receiver when you change inputs on the TV.

Important Note on NetCommand

Be sure to connect the IR emitter cable to the TV and properly place the emitters so that NetCommand can control your devices. See the explanation on the following page.

52 6. NetCommand

#"$,*/1651"/&- CFMPXMBCFMXJUIJOSFDFTTFE BSFBBUUPQ

"/5."*/

57#BDL1BOFM

%*( * 5" -

46330 6/%

"73FDFJWFS

0UIFS"7EFWJDF









0OUPQPGBTJOHMFUBMM EFWJDF

*3TFOTPS

*OGSPOUPGBTJOHMF

BWFSBHFTJ[FEEFWJDF

0OUPQPGBTJOHMF UBMMEFWJDF

*OGSPOUTIBSFECZ UXPBWFSBHFTJ[FE

EFWJDFT

*3TFOTPS

IR Emitter Placement

An IR emitter cable is included with the TV.

The NetCommand system uses emitters connected to

the

IR EMITTER

DVD players, cable boxes, satellite receivers, and VCRs.

1. Connect the plug end of the supplied IR emitter cable to the

TV back panel.

2. Run the cable for each of the emitter ends under, alongside, or over each device to be controlled so that the emitter end is in front of the area where the remote control sensor is located.

3. Position the emitter end with the emitter bulb facing the remote control sensor. The bulb emits infrared light in a cone-shaped pattern. Place the bulb far enough from the sensor to allow the cone pattern to reach the sensor.

The IR sensor is usually behind the plastic window

of the front display panel. It is sometimes visible with the aid of a flashlight and is normally a round or square cutout behind the plastic.

If you cannot see the sensor and the device’s Owner’s Guide does not specify the location, you can find it by following these steps using the device’s remote control:

a. Hold the device’s remote about one-half inch

from the front of the device. Starting from one end of the display window plastic, press the

POWER

b. If the device does not respond, move the

remote control one inch toward the center and

try again. c. Repeat this until the device responds. d. Note this location and then start over from the

other end of the display window plastic, repeat-

ing until the device responds again.

jack to control other devices such as

IR EMITTER NetCommand® jack on the

key.

The remote control sensor is somewhere

between these two positions. This is usually

enough accuracy for placement of the IR emit-

ters.

In some cases, the emitter works better facing downward from the top of the device. Experi-

ment to find what works best.

4. Secure the emitter ends in place using doublesided tape.

5. Place any unused ends behind the devices to prevent stray signals from reaching the IR sensors.

Connecting IR Emitter NetCommand

Place IR emitters so the signal can be “seen” by the IR sensor on each device.

IMPORTANT

Position IR emitters so that each device’s sensor “sees” the signal from only one emitter. Otherwise, a device receiving signals from multiple sources (remote controls, IR emitters) may not respond at all.

6. NetCommand 53

Initial NetCommand Setup for Most Devices

To perform this procedure, you need:

• The remote controls for both the TV and the device you want to control.

• The IR emitter cable supplied with the TV.

Note: To set up an A/V receiver, see “Setting Up

NetCommand Control of an A/V Receiver” later in this chapter.

1. Connect and position the IR emitters for the devices you wish to control. See “IR Emitter Placement” in this chapter.

2. Set the TV’s remote control slide switch to the TV position.

3. Open the NetCommand Learn screen in one of two ways:

• If working from the Auto Input Sensing screen

for the device, highlight the Learn icon and press

ENTER

to open the Learn screen for the

device.

• If performing NetCommand setup at any time

after the device has been recognized through Auto Input Sensing:

a. Press

b. Highlight the desired input icon and press

c. Press

4. The first function highlighted in the Learn screen is always Power On. Aim the TV’s remote control at the TV and press function.

5. When the Power On text starts flashing, aim the device’s remote control at the TV and press and hold the to Power On.

• If the text stops flashing before the check mark

appears, repeat this step.

• To remove the key from NetCommand control,

press the highlighted.

6. Press the keys on the TV’s remote control to highlight other keys on the list. Repeat steps 4 and 5 for each additional function you wish to control through NetCommand.

7. If the device’s remote control has keys that are not in the list, you can associate up to any four keys with the F1 through F4 keys.

For example, for a DVD player, assign the F1 and

keys to the DVD player’s

INPUT

to open the Input Selection

menu.

ENTER

to switch to that input.

, highlight Inputs, and highlight

Learn to open the Learn screen for the

device.

ENTER

to begin learning for that

POWER

key until a check mark appears next

CANCEL

key while the key name is

CHAPTER SKIP FORWARD

and

From the Auto Input Sensing screen, highlight the Learn icon and press ENTER to open the NetCommand Learn screen.

Inputs > Learn screen

CHAPTER SKIP BACK

for the F keys the same as you did for the named keys

8. If the device has a separate on the TV’s remote to highlight Power Off.

Repeat the earlier steps to “learn” the

If the device has no

Press

EXIT

current device.

keys. Perform NetCommand setup

POWER OFF

to finish NetCommand “learning” for the

key, press

POWER OFF

key, skip this step.

key.

Adding or Removing Device Keys from NetCommand Control

1. Press

3. When the Learn screen displays:

INPUT

to open the Input Selection menu and

select the affected device. Open the Inputs menu and highlight the Learn icon.

• To add keys: Continue as described earlier under “Initial NetCommand Setup for Most Device Types.”

• To delete keys: Highlight the name of the key you wish to delete and press remote control to clear the check mark.

CANCEL

on the TV‘s

54 6. NetCommand

NetCommand Specialized Device Keys

Refer to this chart when “learning” device keys. “Learn” some, all, or none of the keys used for each device type. The chart has space for you to write in functions you assign to the F1–F4 keys.

Key Name in Learning Screen

Power On Power On or Power ON/OFF (toggle)

Guide On Screen Program Guide or DVD Disc Menus

Channel Up Next Channel Higher

Channel Dn Next Channel Lower

Page Up Page Up in Guides

Page Dn Page Down in Guides

Menu Setup menu for device

Adjust Up Adjust or arrow up

Adjust Dn Adjust or arrow down

Adjust Lt Adjust or arrow left

Adjust Rt Adjust or arrow right

Enter Enter or Select (menus)

Cancel Cancel or erase (menus)

Play Start playback

Function

See the following page for more on keys marked in the “Special Operation Method” column.

Name on TV Remote Control

POWER

GUIDE

CH/PAGE

ENTER

—/CANCEL

See Special Operation Method Table

* *

Stop Stop playback

Forward Fast Forward

Rewind Rewind/Fast Reverse

Pause Pause playback

Record Start Recording

1, 2, 3, 4, 5, 6, 7, 8, 9, 0 Digit functions

Enter (digits) Use after digits to directly access channels by

number

- (separator) Add digital channel separator between main channel number and sub-channel number

Recall (QV) Last Channel Recall Info On-screen status display or information display

F4 Power Off Power Off

ASSIGN YOUR

CHOICE OF

SPECIALIZED

FUNCTIONS

1, 2, 3, 4, 5, 6, 7, 8, 9, 0

ENTER

—/CANCEL

INFO

POWER

May require two keypresses

6. NetCommand 55

Operating NetCommand-Controlled Devices

To Control Most Device Types

As an example of NetCommand control, if you are watching your cable box and you wish to tune to the next channel higher, press then sends the “learned” channel-up control signal to the cable box.

1. With an IR emitter properly positioned in front of the device, use the Inputs > Learn screen to perform NetCommand setup for the device.

2. When you wish to use the device, press display the Input Selection menu.

3. Press to highlight the icon for the device.

4. Press

5. To operate the device using the TV’s remote

6. Point the remote control at the TV (not the device)

ENTER

to switch the TV to the device. Note: for the A/V receiver, the A/V receiver will automatically switch to the correct input for the device.

control, set the slide switch to the TV position.

and press the key for the desired function.

if you have set up automatic input switching

CH/PAGE

. NetCommand

INPUT

To Control an A/V Receiver

Switching Audio to and from the A/V Receiver

1. Press

2. Press to show the Speakers option.

3. Press to select either AV Receiver or TV.

Controlling A/V Receiver Power

1. Press

2. Press to show the Speakers option.

3. Press to select AV Receiver.

4. Point the remote control at the TV (not the A/V

Controlling Other A/V Receiver Functions

With the A/V receiver powered on and selected, the TV’s remote operates the volume and mute functions. Also, when you switch to a device in the Input Selec- tion menu, the A/V receiver automatically switches to the correct audio input for the device.

AUDIO.

receiver) and press on or off

POWER

to power the A/V receiver

Special Operation Methods

Key Name in Learning Screen

Power On Manual Power On/Off

Power On

Power Off

Menu Displaying the Menu for a Device 1. While watching a device, press

Special Operation Description and Setup How to Use

Use for devices that have only one

Automatic Power On/Off

This feature is only for devices that have separate

POWER ON

controls. If your device does not have a separate

POWER OFF

ing position; use only the Manual Power ON/OFF method described above.

In the NetCommand Learn screen: a. “Learn” the Power On command in the Power

b. “Learn” the Power Off command in the

and

POWER OFF

key, do not use the Power Off learn-

On learning position.

Power Off learning position.

keys on their original remote

POWER

key.

1. Press

2. Press to highlight the icon for the

3. With the Input Selection menu still dis-

4. Press

• To Power On the Device

• To Power Off the Device

2. Press

INPUT

menu.

device to be powered on or off.

played, press you may need to press

Note: If you press Selection displayed, the TV will turn off.

ENTER

1. Press menu.

2. Press to highlight the icon for the device to be powered on or off.

3. Press and NetCommand will send the Power On command to the device.

When you turn the TV off, the TV sends all learned Power Off commands to all devices.

the Input Selection menu with the device icon highlighted.

device. The Input Selection menu will automatically clear from the screen.

to display the Input Selection

POWER

to send the power signal;

POWER

without the Input

to switch the TV to the device.

INPUT

to display the Input Selection

ENTER

to switch the TV to the device

to send the menu signal to the

twice.

INPUT

to display

56 6. NetCommand

Operating NetCommand-Controlled Devices, continued

Key Name in Learning Screen

Guide Displaying the Disc Menu (DVD or high-defini-

Page Up Page Dn

Enter Enter Functions (cable boxes, satellite receivers, etc.)

Special Operation Description and Setup How to Use

While watching the device, press

tion disc format)

“Learn” the named on the original remote in the Guide learning position.

Displaying the On-Screen Program Guide (cable box or satellite receiver)

1. “Learn” the the Guide learning position.

2. Learn the original remote in the Page Up and Page Dn learning positions.

Using Page Up/Down

If the device’s original remote control has separate keys for Channel Up/Dn and Page Up/Dn, the TV remote control’s like the two separate keys.

1. “Learn” positions.

2. “Learn” tions.

Some devices have two keys that have “enter” functions. One key is for menus and is often labelled

SELECT

or OK. A second key is for use with number keys for direct channel selection. NetCommand

uses the same When

the original remote control uses the same key for menus and channel selection:

Learn the NetCommand Enter learning position.

DISC MENU, TOP MENU,

GUIDE

key on the original remote in

PAGE

and

CH/PAGE

CHANNEL

PAGE

ENTER

has a menu or guide function or when

ENTER, SELECT,

/ in the Channel Up/Dn

/ in the Page Up/Dn posi-

ENTER

key for both operations.

or OK key in the

or other key as

PAGE

keys of the

/ key can work

the disc menu.

1. While watching the device, press

2. Press

Inside the Guide

Press commands.

Outside the Guide

Press signal.

1. Press

2. Press

GUIDE

to display

GUIDE

display the guide.

CH/PAGE

/ to send the Page Up/Dn

commands for the guide.

CH/PAGE

/ to send the Page Up/Dn

CH/PAGE

/ to send the Channel Up/Dn

GUIDE

to display the device’s

menu or guide.

ENTER

within the menu and NetCommand will send the Enter signal for menus.

Enter (digits)

Cancel CANCEL as the Cancel or Exit Function

— (separator)

When

ENTER

is for channel changes (i.e., the original remote control has a separate function):

Learn the NetCommand Enter (digits) learning position. Use this learning position only if the original remote control has separate keys for Enter in menus and Enter for channel selection.

“Learn” the Cancel or Exit function in the NetCommand Cancel learning position

The symbol “—” can serve as the separator

“Learn” the channel separator function in the NetCommand – (separator) learning position.

ENTER

key for channel selection in the

between a digital channel’s main and subchannel digits, e.g., digital channel 12-1 (main channel is 12, sub-channel is 1).

ENTER

key for this

Press digit key(s) and then press NetCommand will send the Enter signal for channel selection.

1. Press

2. Press

Press digit key(s) and press NetCommand will send the channel-separator signal.

GUIDE

to display the menu or

guide.

—

and NetCommand will send the

CANCEL

Cancel or Exit signal.

—

CANCEL

ENTER

6. NetCommand 57

Setting Up NetCommand Control of an A/V Receiver

Perform this setup to:

• Operate the A/V receiver’s power and volume functions with the TV’s remote control.

• Enable the A/V receiver to switch automatically to the correct audio input when you select a device in the TV’s Input Selection menu.

To set up control of an A/V receiver you need:

• The remote controls for both the TV and the A/V receiver.

• The IR emitter cable supplied with the TV.

Note: To set up control of other device types, see

“Initial NetCommand Setup for Most Devices” earlier in this chapter.

Perform this setup using the Inputs > AVR screen, shown below.

3. Set the position.

4. Open the AVR screen in one of two ways:

• If using the

• If performing NetCommand setup at any time

5. The first function highlighted in the AVR screen is always Power On. Aim the TV’s remote control at the TV and press On.

TV’s remote control slide switch to the TV

Auto Output Sensing screen for

the A/V receiver, highlight the Learn icon and press

ENTER

to open the AVR screen.

after the A/V receiver has been recognized through Auto Output Sensing:

Press

, highlight Inputs, and highlight AVR

to open the AVR screen.

ENTER

to begin learning for Power

A/V Receiver (AVR) screen. Perform NetCommand IR “learning” for A/V receiver power and volume keys.

AVR screen overview

Power and volume

A/V receiver when “learned”

A check under “learned” the command to switch the A/V receiver to the input.

Input1 through Input4 are temporary placeholder names for A/V receiver inputs. Use this screen to assign meaningful names , e.g., the name of the A/V receiver input.

Use this list to match devices connected to the TV

inputs with audio inputs on the A/V receiver.

commands the TV can send to the

Learn/Name

means the TV has

Setup to Control the A/V Receiver’s Power and Volume Functions

1. Connect your A/V receiver to the TV and any additional devices. See chapter 3, “TV Connections,” for suggestions.

2. Connect the IR emitter cable to the TV and position the IR emitter where it can send signals to the A/V receiver.

6. When the A/V receiver’s remote control at the TV and press and hold the appears next to Power On.

• If the text stops flashing before the check mark

• To remove the key from NetCommand control,

By completing “learning” for the power key, NetCommand now operates the power function for the A/V receiver.

Point the TV’s remote control at the TV to control the A/V receiver.

7. Press the key on the TV’s remote control to highlight other keys in the list. Repeat steps 5 and 6 for each additional function you wish to control through NetCommand.

8. If the A/V receiver has a separate press on the TV’s remote to highlight Power Off. Repeat steps 5 and 6 to “learn” the

Note: Perform “learning” for Power Off only if the

9. When finished “learning” the power and volume keys, either press next section to continue NetCommand setup of the A/V receiver.

Power On text starts flashing, aim the

POWER

POWER ON

appears, repeat this step.

press the highlighted.

CANCEL

key while the key name is

A/V receiver’s remote control has a separate

POWER OFF

key.

EXIT

to watch TV or proceed to the

key until a check mark

POWER OFF

key,

key.

58 6. NetCommand

BVEJPWJEFP

*ODPNJOH $PBYJBM$BCMF UP"/5"/5

"73FDFJWFS

%7%BVEJP

JOQVU

57BVEJPJOQVU

57BVEJP

PVU

BVEJPPVUQVUGSPN 57EJHJUBMPSBOBMPH

BOBMPHBVEJP

WJEFP

BOBMPHBVEJP

7$3XJUI

"OBMPH"VEJP0VUQVU

Setting Up NetCommand Control of an A/V Receiver, continued

Setup to Control Automatic Switching of A/V Receiver Audio Inputs

Two different setups are described here: Setup 1: Automatic A/V Receiver Switching to TV

Audio Input Setup 2: Automatic A/V Receiver Switching for a

device sending audio directly to the A/V receiver

• Audio Available from TV only: Use Setup 1.

Audio from A/V receiver from the TV’s DIGITAL AUDIO OUT or analog

Use Setup 1 to make the A/V receiver switch to its designated TV audio input when viewing these sources.

• HDMI, Digital Stereo Audio Only: Use Setup 1

Digital stereo audio from an HDMI connection is available both in digital format (from the TV’s DIGITAL AUDIO OUT) jack and in analog format (from the TV’s

• Analog Stereo Audio: Use Setup 1.

Audio from sources with only analog stereo output (such as a VCR) can be sent either directly to the A/V receiver or through to the TV and then on to the A/V receiver.

Mitsubishi recommends you send audio through the TV as shown in the example. Setup 1 causes the A/V receiver to switch to its input designated for TV audio.

If you have a digital A/V receiver, the TV makes the audio available by converting analog audio to a digital output.

ANT 1

and

ANT 2

AVR AUDIO OUTPUT

must be sent to the

jack).

could have HDMI output. A DVD player is used in this example.

Your setup may include additional devices with digital surround sound connected directly to the A/V receiver. These devices might be a DVD player plus a cable box or satellite receiver.

Before You Begin

1. Connect your A/V devices to the TV and connect your A/V receiver to the audio outputs on the TV and the DVD player. See chapter 3, “TV Connections,” for suggestions.

2. Open the Inputs > AVR menu.

Note: The terms Input 1–Input 4 used in the AVR

screen are temporary placeholder names. They refer to the A/V receiver inputs for which the TV can learn IR codes.

Setup 1: Automatic A/V Receiver Switching to Its TV Audio Input

Most devices are set up like the VCR in this example, in which analog audio from the device is sent through the TV.

Use this setup for:

• Sources providing only analog stereo output, such as a VCR.

• Audio from

ANT 1

and

ANT 2

• Digital Surround Sound: Use Setup 2.

A device can send digital surround sound such as Dolby Digital or DTS directly to the A/V receiver, bypassing the TV entirely. The device might be a DVD player, cable box, or satellite receiver, and

IMPORTANT

To hear audio sent from the TV to the A/V receiver, you must have:

•

physically connected the TV to the A/V receiver

•

selected the A/V receiver as the audio source. Press Speakers option, Receiver.

• “

learned” the IR codes for the A /V receiver

inputs

• chosen the correct input in the NetCommand A/V Receiver Learn screen

AUDIO

, then

then

to select the A/V

to show the

Setup 1: A/V receiver audio from the TV’s digital or analog audio output (

OUTPUT

)

DIGITAL AUDIO OUT

AVR AUDIO

1. Under Learn/Name, navigate to highlight the area next to Input 1.

In this example, the IR code for the A/V receiver’s

TV Audio

2. Press

input will be “learned” as Input 1.

ENTER

on the TV’s remote control.

3. While the text Input1 is flashing, press and hold the

TV INPUT

key on the A/V receiver’s remote control.

4. When a check appears next to Input 1, release the

TV INPUT

key.

• If the text stops flashing before the check mark

appears, repeat this step.

6. NetCommand 59

"73FDFJWFS

%7%BVEJP

JOQVU

%7%1MBZFSXJUI

%JHJUBM4VSSPVOE4PVOE

WJEFP

EJHJUBMTVSSPVOETPVOE

%7%1MBZFS

XJUI

%JHJUBM

4VSSPVOE

4PVOE

Setting Up NetCommand Control of an A/V Receiver, continued

• To erase the IR code just “learned,” press while the name is highlighted.

5. Press to highlight the name Input1. You can enter a custom name using the letters/numbers on the remote control. It is best to assign names to “learned” inputs that match the input names displayed on the A/V receiver. For this example, enter the custom name TV using these guidelines:

• To select a character, repeatedly press a

number key on the remote control to cycle through the characters associated with the key.

Special characters are available with the 1 key (!, &, blank space) and 0 key (/,*,-).

• Press

ENTER

to set the character and move the

highlight to the next character.

• To delete a character, highlight the character

and press

CANCEL.

• To highlight the first character, repeatedly press

CANCEL

IMPORTANT

All audio from what you are watching on the TV is always available as a stereo or mono output on both the TV’s AVR AUDIO OUTPUT and DIGITAL AUDIO OUT jacks.

To use the digital surround sound capabilities of your A/V receiver however, you must connect your DVD player, satellite receiver, or cable box directly to the A/V receiver, as surround sound may not be available from the TV’s audio output.

Setup 2: A/V receiver audio from a device providing surround sound directly to the A/V receiver

6. Press to move the highlight to the Assign

7. Use to highlight AudioOut (TV audio output).

8. Press

Completed NetCommand setup described for controlling A/V receiver switching to the A/V receiver’s audio input labelled “TV.”

Setup 2: Automatic A/V Receiver Switching for a Surround Sound Device

Use this setup to send digital surround sound directly from a device to an A/V receiver.

1. Under Learn/Name, navigate to highlight the area

2. Press

column.

The triangular marker is always next to the assigned sound source.

EXIT

if finished or continue with setup for

another TV source.

next to Input2. In this example, the IR code for the A/V receiver’s

DVD Audio

input will be “learned” as Input 2.

ENTER

on the TV’s remote control.

Completed NetCommand setup described for controlling A/V receiver switching to an A/V receiver input labelled “DVD.”

3. While the text Input2 is flashing, press and hold the

DVD INPUT

key on the A/V receiver’s remote control.

4. When a check appears next to Input 2, release the

DVD INPUT

key.

• If the text stops flashing before the check mark appears, repeat this step.

• To erase the IR code just “learned,” press

CANCEL

while the name is highlighted.

5. Press to highlight the name Input2. Assign a custom name that matches the input name displayed on the A/V receiver. For this example, enter the custom name DVD using the number keys and the guidelines given earlier.

6. Press to move the highlight to the second Assign column.

7. Use to highlight DVD in the list of devices recognized by the TV. The triangular marker always indicates the assigned sound source.

8. Press

EXIT

if finished or continue for additional TV

sources.

Appendices

Appendix A: Bypassing the Parental Lock . . . . . . . . . . 61

Appendix B: Specifications . . . . . . . . . . . . . . . . . . . . 63

Appendix C: TV Guide Daily . . . . . . . . . . . . . . . . . . . . 64

Appendix D: Programming the Remote Control . . . . . 68

Appendix E: Troubleshooting . . . . . . . . . . . . . . . . . . 76

Appendices 61

Appendix A: Bypassing the Parental Lock

Bypassing the Parental Lock

After you set the lock, you must use your pass code to view a locked program, view the locked TV, view a locked channel, cancel the lock, or enter the Lock menus.

If you forget your pass code, you can view the locked TV without entering your pass code. When you are prompted for your pass code, press the number 9 and

keys on the TV remote control at the same time. This

process temporarily unlocks the TV.

When entering the Lock menu, this process deletes your old pass code and prompts you to enter a new pass code.

• You can either enter a new pass code to open the Lock menu and make changes or press the menu.

• If any of the locks are turned on and you exit the menus when prompted for a new code, the old code and all lock settings are retained.

EXIT

to close

Lock Bypass Instructions Have Been Filed for

• If all locks are turned off and you exit the menus when prompted for a new code, then the previous code is erased.

Future Reference

IMPORTANT

Cut along the dotted line and file bypass instructions in a safe place for future reference.

IMPORTANT

When changing or deleting your pass code, you must use the remote control included with this TV. You cannot use a Mitsubishi remote control from another component or a “universal” remote.

62 Appendices

This page intentionally left blank

Appendices 63

Appendix B: Specifications

Size and Weight

Dimensions (inches)

With Stand/Without Stand

Model

LT-46244 29.0/26.5 42.3 12.6/5.6 73.0/64.2

LT-52244 32.5/30.0 48.0 14.2/5.8 86.0/76.6

Picture Technology and Power Consumption

Item Speciﬁcations

LCD Screen

Backlight Direct Type 24 CCFL

Power

Channel Frequency Reception

Channel Type*

* Note for Digital Channels: The channel numbers displayed on screen are determined by the broadcaster or cable company and can vary from the standard frequency number. If there is no channel-number information provided by the broadcaster or cable company, the TV creates a channel number. The created channel number uses the frequency number as the main channel number and the program number as the sub-channel number.

Height Width Depth

Color active matrix LCD, 1920 x 1080 dots, 16:9 aspect ratio

LT-46244: 325 w

LT-52244: 395 w

Over-the-Air: VHF 2–13, UHF 14–69 Analog Cable: 1–125 Digital Cable: 1–135

Over the Air:

Cable:

Analog NTSC, Digital ATSC with sub-channels (all 18 video formats)

Analog NTSC (non-scrambled) Digital QAM 64 and 256 with subchannels (non-scrambled)

Weight (lbs.)

With Stand/

Without Stand

Inputs

Type Qty. Input Speciﬁcations

S-Video 2

Component Video (Y/Pr/Pb)

Four-Pin DIN Plug Y: 1.0 Vp-p 75-ohm C: 0.286 Vp-p (burst signal), 75-ohm

3 CEA-770.1 & CEA 770.2 480i, 480p,

CEA 770.3 720p and 1080i (TV analog component video standards)

RCA Pin Plug

Y: 1.0 Vp-p (includes sync), 75-

ohm Pr: 700 mV p-p, 75-ohm Pb: 700 mV p-p, 75-ohm

USB Photo Port 1 For reading camera JPEG files only.

Audio Inputs 6

Analog left and right audio

pairs

RCA Pin Plug 500 mV (full scale), 43-k ohm

HDMI

The HDMI inputs are compliant with CEA-861D standards for standard, extended, and high-definition video; digital audio, and HDCP copy protection.

Outputs

Description Qty. Output Speciﬁcations

Audio Speakers 2 5.5" x 2.2"

Analog Audio (Signal)

Digital Audio Output

RCA Pin Plug, 500 mV rms + 200 mV

(full scale) for analog sources, 1.5

pair

Vrms + 0.5 Vrms (full scale) for digital sources.

RCA Pin Plug, Signal Type Dolby

Digital, PCM stereo

Inputs

Type Qty. Input Speciﬁcations

Antenna/Cable input

HDMI (digital video/audio)

F connector, 75-ohm

4 CEA-861D standard for digital audio

and video via HDMI

HDMI standard connector Video: 60 Hz: 480i, 480p, 720p, 1080i

Audio: PCM stereo

24 Hz, 30 Hz, 60 Hz: 1080p

PC (digital signals only):

VGA (640 x 480, 60 Hz) W-VGA (848 x 480, 60 Hz) SVGA (800 x 600, 60 Hz) W-SVGA (1064 x 600, 60 Hz) XGA (1024 x 768, 60 Hz) 1280 x 720, 60 Hz SXGA (1280 x 1024, 60 Hz) 1920 x 1080 (60 Hz) WXGA (1360 x 768, 60 Hz)

Composite Video

3 NTSC 48 0i only

Video: RCA Pin Plug, 1.0 V p-p,

75 ohm

64 Appendices

Appendix C: TV Guide Daily

Video Window

Ad Panel

Active Selection Source and Channel Information

Clock

Channel Call Letters

Info Box

Info Bar

Channel Number

Program Rating Icons

Progress Indicator

Info Icon

Program Title Tile

Highlighted Tile

(indicates active selection)

HD (highdefinition) Icon

This appendix explains the free TV Guide Daily service available with this TV. Use this optional service to:

• View 24 hours of show listings.

• Change how channels are displayed (channel call letters, numbers, or both).

• Watch the currently tuned channel while browsing listings.

• Get quick program information; icons indicate show ratings, new episodes, stereo, HD broadcasts, and closed captioning availability.

• Quickly tune the TV to a selected channel.

• View show descriptions and “what’s on next” information for a selected channel in an expandable INFO box.

• Customize the channel lineup and listings

Initial Guide Setup

Before you can use TV Guide Daily, you must perform the initial setup from the TV’s Inputs menu. See chapter 5, “TV Menu Settings,” Inputs > Guide menu for more information. Note: These settings can be changed at a later date using the same procedure.

Main Guide Screen Elements

• The TV Guide Daily screen provides basic program information, channel call letters and number, current time, program rating, and high definition programming (HD) icons.

• The Highlight indicates the current active selection. To navigate the screen, move the highlight using the TV remote control’s

keys.

• The Info Bar displays specific broadcast information (new episode, TV or movie rating) and a show progress indicator. The Info Icon indicates that information or help is available.

• The Info Box displays selected program information, upcoming channel programming, and help information.

• The Video Window displays current channel programming while in the Guide.

• The Ad Panel displays program or product information.

Appendices 65

Appendix C: TV Guide Daily, continued

Navigating the Guide

Guide navigation is simple. Move the highlight around the screen using the TV remote control’s and

CH/PAGE

keys. The highlight indicates the currently active tile in the Guide. Press information.

To open and close the Guide

• Press

To navigate through screens

• Press to move the highlight one item at a

• Press

• While in the Guide, press

To jump to a specific channel in the Listings

Enter a channel number using the remote control’s number keys. Use the separator for a digital sub-channel number. Press to move the highlight to the channel just entered.

To tune the TV to a program in the listings

Highlight the desired program title in the listings, then press

Note: If the highlighted program airs sometime in the future, the TV will tune to the channel on which that show will air.

GUIDE

to open or close TV Guide Daily (

also be used to close the Guide). Note: Until the initial 24 hours of program listings

have downloaded, the Setup Progress screen appears when you first open the Guide. Once the initial listings download is complete, the screen will go directly to the Guide.

time.

CH/PAGE

/ (Channel/Page Up/Down) to

move up or down one full screen at a time.

INFO

to open the Info Box for on-screen help and program information. When the Info Icon is displayed on the Info Bar, press view either full or brief information.

Program Information. With a program title highlighted, press the the Info Box for currently available and upcoming programs.

Setup screen. See also “Modify Guide Setup” on the next page.

Note: If the channel number entered does not exist, the highlight will move to the closest channel that is present in the listing.

ENTER

INFO

to see help and program

INFO

repeatedly to

INFO

key to see information in

to display the Guide

–/CANCEL

key to enter the

EXIT

can

ENTER

1. While in the Guide Listings, press plays the Setup Screen.

2. In the Setup Screen, press to highlight “Display setup progress” and press ress screen appears.

3. Press

GUIDE

to exit the Guide or press

to the Setup Screen.

ENTER

Accessing Ad Information

To view promotional information linked to ads

• Repeatedly press to move the highlight to the Ad panel. A screen with additional Ad information will appear.

• To close the Ad screen, press to move the highlight back to the listings.

Note: Some ads promote currently airing programs. If the ad is linked to a currently airing show, highlight the ad and press

ENTER

to watch the show.

Customize Guide Listings

You can customize how the Listings screen displays channel call letters/numbers. The options are:

• Both. Both the channel call letters and number are displayed.

• Call Letters. Only call letters are displayed.

• Number. Only channel numbers are displayed.

To change the Channel ID display

1. Press to move the highlight to the desired channel tile (channel number/call letters).

2. Press

3. To save changes, press to move the highlight

ENTER

to change the display (Both, Call Letters, or Number). Each press of the cycles through the choices.

back to the program listings.

. This dis-

. The Setup Prog-

ENTER

to return

ENTER

key

To check Guide setup progress

The Setup Progress screen displays the current Guide setup status. To open the Setup Progress screen:

66 Appendices

Appendix C: TV Guide Daily, continued

Modify Guide Setup

From the Guide Setup screen, you can change the channel lineup, change channel display settings, and view setup progress (e.g., when the next listings update will occur).

To select a channel lineup

You can view or change the channel lineup if more than one is available. Use the following procedure:

1. While in the Guide Listings, press plays the Setup Screen.

2. Press to highlight “Change channel lineup” and press

ENTER

. A selection screen will appear.

3. Make your lineup selection:

• If only one selection is available, Next will be

highlighted. Press

• If more than one selection is available, but you

want to use the one already selected (check marked), press

• If more than one selection is available and you

want to select a different lineup, press to move the highlight back to selections. Press

to move the highlight to the desired lineup and press Press to highlight Next and press

A confirmation screen will appear.

4. In the confirmation screen, verify the lineup selection:

• If the selection is correct, press

Yes (add check mark), press to highlight Next, and then press

• If the selection is incorrect, press to highlight

No, press press to highlight Next, and then press to return to the Make Lineup Selection screen.

Note: You may need to try several lineup options before you receive the correct one for your area. To edit a specific tune channel number in the Listings grid, see “To Modify Channel Settings” below.

ENTER

to select it (add a check mark).

ENTER

to select (add check mark),

. This dis-

ENTER

to select

ENTER

Available Options

• Position. Order of the channel in the Listings.

• Channel. Determines whether or not the channel is displayed in the Listings (On, Auto-hide, and Off). Auto-hide displays channels only when show information is available.

• Tune Channel. Shows the channel number that displays in the Listings and which channel number is used when tuning to that channel.

Procedure

1. While in the Guide Listings, press plays the Setup Screen.

2. Highlight “Change channel display” and press The channel editor screen will appear.

3. Use to highlight the desired row setting to be changed.

• To change channel position (Position Number

highlighted), press to move the position or enter a new channel position number. When correct, press to move the highlight to another position on the grid to save changes.

• To change channel display status (status tile

highlighted; next to position number), repeatedly press auto, off). When correct, press to move the highlight to another position on the grid to save changes.

• To change tune channel number* (Channel

Tune Number highlighted; far right), enter desired number with remote control number keys ( separator). When correct, press to move highlight to another position on the grid to save changes.

Note: If you receive both analog and digital versions

of the same channel, do not change the tune channel number of the digital channel to match the analog station, as this may hinder the ability of the Guide to receive data. Instead, locate the digital station in the channel editor and, if necessary, change the channel row position to a location you prefer.

ENTER

—/CANCEL

to cycle through choices (on,

key for digital sub-channel

. This dis-

ENTER

To modify channel settings

You can edit how channels appear in the Guide Listing.

Note: The default settings for each channel are determined by the broadcast data received by your TV.

Appendices 67

Appendix C: TV Guide Daily, continued

TV Guide Daily Troubleshooting Tips

Symptom Remarks

1. When I enter the Guide I see a Setup Progress screen.

2. Listing reads “Listings Pending.” The Guide has not yet completed initial setup, completed

3. Tiles in Listing read “No Listing” or “Title Unavailable.”

4. Tiles in Listing read “Turned Off.” The channel you were watching before entering the Guide

5. There are repeated or missing time slots in the Listings.

6. My channel lineup is incorrect or I see a channel lineup screen when I enter the Guide.

7. I receive a channel on two different broadcast services, but only one is available in the Guide Listings.

8. My TV is tuned to a different channel than the one I was watching the last time the TV was turned off.

You have not yet received all of the program listings (it may take up to 24 hours to receive a full grid of listings).

changes you made, or the Guide is setup incorrectly. Verify that your TV is properly connected to the input source. Then, verify that the ZIP code and input source (entered during initial setup of Guide) are correct. See chapter 5, “TV Menu Settings,” and “Inputs Menu” for more information.

The Guide has not received updated show information or no information was available the last time the Guide received an update, update did not occur, or there was a power failure. Make sure you turn the TV off when not in use to allow for updates. In the case of a power failure, it may take up to 24 hours to update listings.

is turned OFF in the grid. Use the channel editor to change the channel setting to ON (see previous page, “Modify Guide Setup”).

The Guide is close to the time that a Daylight Savings time adjustment is needed. The Guide automatically adjusts accordingly when the local time is 2:00 a.m. to account for the affected hour of programming. Once the adjustment is made, the Listings should return to normal within 24 hours.

An incorrect lineup for your area is selected in the Guide setup. Select the correct channel lineup for your area (see previous page, “Modify Guide Setup”).

The Guide is not setup correctly. See previous page, “Modify Guide Setup.”

The Guide changes the channel to receive updates and does not change the channel back until the update is complete. If the TV is turned on before the update is complete, the channel will not change back automatically.

68 Appendices

Appendix D: Programming the Remote Control

This appendix explains programming the TV’s remote control to operate other A/V devices. This is distinct from NetCommand control. The TV’s remote control can operate other devices by three different methods:

• Remote Control Programming: You must move the slide switch to the position specific to the type of device.

• NetCommand® IR “learning”: You can operate other devices with the slide switch in the TV position.

• NetCommand for HDMI devices: You may be able to operate compatible HDMI devices with the slide switch in the TV position. See the device’s Owner’s Guide and the description in chapter 4, “TV Operation and Features.”

Functions Available for Other A/V Devices

The TV’s remote control can be programmed to operate other types and brands of A/V products. To use the remote when programmed, set the slide switch to the position labelled for the product type. The functions performed in each switch position can vary depending on the product. Not all functions work for all models. The most common functions available are listed on this page.

VCRs and DVRs

• CH /

•

POWER

•

SLEEP

• (

Mitsubishi VCRs are compatible with some additional keys.

Cable Boxes and Satellite Receivers

•

• QV

• CH /

•

• (on some

•

• QV or

A/V Receivers

•

FAST FORWARD PAUSE PLAY

)

AUDIO (PAGE UP)

CANCEL

(last channel

on some models)

ENTER

(on some

models)

GUIDE

(on some models)

LIST POWER

models)

VIDEO (PAGE DOWN)

CANCEL (ENTER

channels on some models)

MUTE POWER SLEEP VOLUME 0–9

Number Keys

)

for

•

• (

•

The record/playback keys (on some models):

• (

• Direct Input Selec-

(

RECORD

)

REVERSE

)

STOP

)

GUIDE

(DVR only)

0–9

Number Keys

0–9

Number Keys (on

some models)

F1–F4

(A, B, C, D keys

on some models)

FAST FORWARD PAUSE PLAY

) RECORD REVERSE STOP

)

tion keys: numbers,

FAV

and QV (on some

Mitsubishi models)

)

Set the remote control’s slide switch to the type of device you wish to program for or control.

IMPORTANT

Some manufacturers may change their products or they may use more than one remote control system. The TV’s remote control may be unable to operate your A/V equipment in these cases.

CD Players

(not all functions for all models)

SLEEP

•

• (

DVD and Laser Disc Players

(not all functions for all models)

•

• CH / (for track

•

• (on some

FAST FORWARD PAUSE PLAY

)

CANCEL

(on some

models)

skip on some models)

ENTER MENU POWER SLEEP

models)

)

•

• (

•

• (

•

(

REVERSE

)

STOP

)

0–9

Number Keys

(

FAST FORWARD PAUSE

)

PLAY

) RECORD

)

REVERSE

)

STOP

)

0-9

Number Keys (on

some models)

)

Appendices 69

Appendix D: Programming the Remote Control, continued

Programming the Remote Control

1. Move the slide switch at the top of the remote to the position for the product you want to control. Refer to the table below. Only one of each device type can be controlled in each slide-switch position.

Switch Position Affected Device

CABLE/SAT

VCR

DVD

AUDIO

2. Press and hold several seconds until the key blinks twice and goes off.

3. Release the

4. Enter the first five-digit code listed for your equipment.

• The

• Move the slide switch to another position if you

5. Point the remote control at the equipment and press function, press a different key, such as (

• If the equipment responds, the remote control

• If the equipment does not respond, repeat

You may need to reprogram the remote control after changing the batteries.

POWER

enter the code and then once for each additional keypress.

POWER

entering a valid code.

need to start over or wish to exit programming mode.

POWER

(

STOP

VOL

is properly programmed to operate the equipment.

steps 2–4 with the next five-digit code listed for your equipment.

Cable Box DTV Receiver Satellite Receiver

VCR DVR Laser Disc Player DVD Player/Recorder

DVD Player/Recorder DVR Laser Disc Player VCR

A/V Receiver Audio Amplifier CD Player

POWER

on the remote control for

POWER

key.

key blinks twice when you start to

key blinks twice when you finish

. If the product has no power on/off

PLAY

, or

MUTE.

IMPORTANT

6. Once you have found the correct code, write it in the space below for future reference.

Switch Position

CABLE/SAT

VCR

DVD

AUDIO

Code Verification

To determine the code programmed for any position of

the slide switch:

1. Move the slide switch to the position you wish to verify.

2. Press and hold several seconds until the key blinks twice and goes off.

3. Press keys

4. Press 1 and count the blinks of the power key. Write down the number of blinks as the first digit of the code.

5. Repeat step 4 for the second, third, fourth, and fifth digits of the code.

Audio Lock: Universal A/V Receiver Control

With Audio Lock active, the remote control operates the volume and mute functions of the A/V receiver in all positions of the slide switch. Activate Audio Lock if you normally use an A/V receiver with your TV and other A/V equipment.

1. Program the described earlier in this section.

2. Move the slide switch to the

3. Press and hold several seconds until the key blinks twice and goes off.

4. Press keys The

POWER

key will blink twice to indicate Audio Lock

is active.

To Reset the Remote Control to Operate Volume and Mute for the TV Speakers

1. Press and hold key blinks twice and goes off.

2. Press keys The

POWER

key will blink four times to indicate Audio

Lock has cleared.

Device Type Code

POWER

on the remote control for

9 9 0

AUDIO

position for your A/V receiver as

AUDIO

position.

POWER

on the remote control for

9 9 3 ENTER

POWER

for several seconds until the

9 9 3 VOL

70 Appendices

Appendix D: Programming the Remote Control, continued

Programming Codes

Audio Ampliﬁers Brand

Acurus Adcom Altec Lansing Aragon Bel Canto Design Bose Carver Classe Curtis Mathes Durabrand Elan GE Harman/Kardon JVC Klipsch Left Coast Lenoxx Lexicon Logitech Marantz Mark Levinson McIntosh Mondial Optimus

Philips Pioneer

Polk Audio RCA Realistic Sharp Sony Soundesign Technics Toshiba Victor Wards Yamaha

A/V Receivers Brand Code

ADC Adcom Aiwa

Akai Alco AMC Amplifier Technologies Anam Apex Digital Arcam

Code

30765 31100, 30577 31742 30765 31583

30674 30892 31462, 31461 30300 31561 30647 30078 30892 30331 30765 30892 31561 31802 31408 30892 31483 30251 30765 30823, 30395, 30300 30892 30823, 30300, 30257, 30013 30892 30823, 30300 30395 30226 30815 30078 30374, 30372 30353 30331 30078, 30013 30354

30531 31617, 31616 31641, 31405, 31388, 31347, 31321, 31243, 30189, 30121 31255 31390 31077 31584

31609, 31074 31774, 31430, 31257 31189

A/V Receivers Brand Code

Atlantic Technology Audiophase Audiotronic Audiovox B & K

Bel Canto Design BK Bose

Brix Cambridge Soundworks Capetronic Carver

Coby Curtis Delphi Denon

Fisher Fosgate Glory Horse GPX Harman/Kardon

Hitachi Integra JBL JVC

Kenwood KLH Koss Linn Liquid Video Magnavox

Marantz

McIntosh Micromega Mitsubishi

Myryad Nakamichi Onkyo

Optimus

Oritron Outlaw

31487

31387 31189 31627, 31390 30840, 30820, 30701 31584

30702 31253, 31229, 30639 31602 31477

30531 31289, 31189, 30189, 30121 31263 30797 31414 31360, 31311, 31142, 30121, 31801, 31409 31487 31263 31299 31306, 31304, 31289, 30891, 30189, 30110 31801, 31273 31320, 31298, 30135 31306, 30110 31811, 31643, 31495, 31374, 31282, 31263, 31058 31570, 31569, 31313 31428, 31390 31497, 31366 30189 31497 31514, 31269, 31189, 30531, 30189 31289, 31269, 31189, 30200, 30189, 31289 31189 31957, 31922, 31921, 31920, 31393, 30176 31189 31555, 31313, 30097 31320, 31298, 30842, 30135 31074, 31023, 30849, 30797, 30670, 30531 31497, 31366 31487

A/V Receivers Brand Code

Panasonic

Philips

Pioneer

Polk Audio Proscan RadioShack RCA

Rio Samsung Sansui Sanyo Sharp Sharper Image

Sherwood Sirius Sonic Blue Sony

Soundesign Stereophonics Sunfire Sylvania Teac

Technics

Thorens Toshiba Venturer Wards XM Yamaha

31764, 31763, 31633, 31548, 31518, 31509, 31363, 31350, 31316, 31308, 31288, 30309 31368, 31365, 31283, 31269, 31268, 31266, 31189, 30189 31384, 31343, 31023, 30630, 30531, 30150, 30014 31414, 31289, 30189 31254 31263 31609, 31511, 31390, 31254, 31074, 31023, 30531 31869 31500, 31295 31189, 30189 31801 31386, 31361 31416, 31411, 31410, 31409, 31385, 31263, 30797 31077 31811, 31627, 31602 31869 31858, 31759, 31758, 31658, 31622, 31558, 31529, 31503, 31458, 31441, 31406, 31382, 31371, 31367, 31258, 31131, 31058 30670 31023 31313 30797 31528, 31390, 31267, 31074 31633, 31518, 31308, 30309 31189 30135 31390, 30849 30189, 30014 31414, 31406 31375, 31331, 31276, 31176, 30176

Appendices 71

Appendix D: Programming the Remote Control, continued

Programming Codes, continued

CD Players Brand Code

Aiwa Akai Arcam Audio-Technica Burmester California Audio Labs Carver

Classic Denon

DKK DMX Electronics Emerson Fisher Garrard Gemini Genexxa GPX Harman/Kardon

Hitachi Integra JVC Kenwood

KLH

Koss Krell LG Linn LXI Magnavox

Marantz

Mark Levinson McIntosh

MCS MGA Miro Mission Mitsubishi MTC NAD Nikko

NSM

Onkyo

30157 30156 30157 30170 30420 30303, 30029

30437, 30299, 30179, 30157 31297 30873, 30034, 30003 30000 30157 30305 31325, 30179, 30174 30420, 30393 30625 30305, 30032 31296 31202, 30173, 30157, 30083 30032 30101 31294, 30072 30826, 30681, 30626, 30190, 30037, 30028, 31711, 31373, 31372, 31318 31317 30157 31208 30157 30305 30305, 30157, 30038 30626, 30435, 30180, 30157, 30038, 30029 31484 30660, 30290, 30256 30029 30083 30000 30157 30098, 30083 30625, 30420 30299, 30019 30625, 30174, 30170 30157 31327, 30868, 30102, 30101

CD Players Brand Code

Optimus

Panasonic

Parasound Philips Pioneer

Polk Audio Proceed Proton QED Quad Quasar RadioShack RCA

Realistic Rotel SAE Sansui Sanyo Scott Sears Sharp

Sherwood Sonic Frontiers Sony

Soundesign Sugden Symphonic TAG McLaren Tascam TDK Teac

Technics Tivoli Audio Toshiba Victor Wards Yamaha

YBA Yorx

31075, 31063, 30468, 30437, 30420, 30305, 30179, 30145, 30087, 30037, 30032, 30000 30752, 30388, 30303, 30029 30420 30626, 30274, 30157 31087, 31063, 31062, 30551, 30468, 30305, 30032 30157 30420 30157 30157 30157 30029 31075 31062, 30764, 30468, 30420, 30305, 30179, 30053, 30032 30420, 30180, 30179 30420, 30157 30157 30305, 30157 30179, 30087 30305 30305 30861, 30265, 30180, 30037 31067, 30180 30157 31364, 30673, 30605, 30604, 30490, 30185, 30100, 30000 30145 30157 30305 30157 30420 31208 30420, 30393, 30378, 30180, 30174 30303, 30029 31553 30299, 30019 30072 30157, 30053 31292, 30888, 30490, 30261, 30187, 30170, 30036, 30625 30461

Cable Boxes Brand

ABC

Allegro Americast Antronix Archer

BBT Belcor Bell & Howell Bell South Cable Star Cabletenna Cableview Century Citizen Clearmaster ClearMax Colour Voice Comtronics Contec Coolmax Digeo Digi Director Dumont Eastern Emerson Everquest Focus Garrard GC Electronics Gemini General Instrument GoldStar Goodmind Hamlin

Hitachi Hytex i3 Micro Jasco Jerrold

Linsay Magnavox Memorex Motorola

Movie Time Multitech Myrio Novaplex NSC Oak

Code

10017, 10014, 10013, 10011, 10008, 10007, 10003, 10001 10315, 10153 10899 10207, 10022 10797, 10207, 10153, 10022 10267 10056 10014 10899 10056 10022 10022 10153 10315, 10153 10883 10883 10031, 10025 10040 10019 10883 11187 10637 10476 10637 10002 10797 10040, 10015 10400 10153 10207, 10056 10797, 10015 10810, 10476, 10276, 10011, 10003 10144, 10040 10797 10273, 10259, 10034, 10020, 10009 10011 10007 11602 10315, 10153, 10015 10810, 10476,10276, 10024, 10015, 10014, 10012, 10011, 10003 10440 10027 10000 11376, 11254, 11187, 11106, 10810, 10476, 10276, 10014 10156, 10063 10883 11602 10618 10156, 10063 10019, 10007

72 Appendices

Appendix D: Programming the Remote Control, continued

Programming Codes, continued

Cable Boxes Brand

Optimus Pace Panasonic Panther Paragon Philips

Pioneer

Popular Mechanics Pulsar Quasar RadioShack

RCA Realistic Recoton Regal

Regency Rembrandt Runco Samsung Scientific Atlanta

Seam Sejin Signal Signature SL Marx Sony Sprucer Starcom Stargate Starquest StarSight Supercable Supermax Sylvania Tandy TeleCaption Teleview Texscan TFC Thomson Timeless Tocom Torx Toshiba Tristar Tusa TV86 Unika United Artists Universal

V2 Viewmaster Viewstar

Code

10021 11877, 10237, 10008 10107, 10021, 10000 10637 10000 11305, 10317, 10153, 10031, 10027, 10025 11877, 10877, 10533, 10144, 10023 10400

10000 10000 10883, 10797, 10315, 10015 11256, 10021 10207 10400 10279, 10273, 10259, 10020 10002 10011 10000 10144, 10040 11877, 10877, 10477, 10017, 10008, 10510 11602 10040, 10015 10011 10040 11006 10021 10015, 10003 10797, 10040, 10015 10015 10422 10276 10883 10001 10258 10221 10040 10001 10310 11256 10418, 10040 10013, 10012 10003 10000 10883 10015 10063 10207, 10153, 10022 10007 10207, 10191, 10153, 10056, 10022, 10883 10883 10258, 10063, 10027

Cable Boxes Brand

Vision Vortex View Zenith

Zentek

Code

10883 10883 10899, 10525, 10054, 10000 10400

DVD Players/Recorders Brand Code

Adcom Aiwa Akai Alco Allegro Amphion Media Works AMW Apex Digital

Aspire Digital Audiologic Audiovox Axion B & K Bel Canto Design Blaupunkt Blue Parade Broksonic California Audio Labs CAVS Cinea CineVision

Citizen Coby

Craig Curtis Mathes CyberHome

Daewoo

Daytek Denon Desay Disney Dual Durabrand DVD2000 Emerson

Enterprise Fisher

21094 20641 21089, 20770 20790 20869 20872

20872 21100, 21061, 21056, 21020, 21004, 20797, 20796, 20794, 20755, 20717, 20672 21407, 21168 20736 21072, 21041, 20790 21072 20662, 20655 21571

20717 20571 20695 20490

21057 20831 20876, 20869, 20833 21277 21351, 21177, 21165, 21107, 21086, 20852, 20778 20831 21087 21129, 21117, 21024, 21023, 20874, 20816 21242, 21234, 21172, 21169, 20869, 20833, 20784, 20705 20872 20634, 20490 21407 21270, 20675 21085, 21068 21127 20521 21268, 20675, 20591 20591 20670

DVD Players/Recorders Brand Code

Funai

Gateway GE Go Video

Go Vision GoldStar GPX Gradiente Greenhill Grundig Harman/Kardon Hitachi Hiteker iLo Initial Integra Jaton JBL JSI JVC

jWin Kawasaki Kenwood

KLH

Konka Koss

Landel Lasonic Lecson Lenoxx LG

LiteOn

Loewe Magnavox

Malata Marantz McIntosh Memorex

Microsoft Mintek Mitsubishi Momitsu Myryad NAD Nakamichi

21334, 21268, 20675 21158, 21077, 21073 20815, 20717, 20522 21730, 21304, 21158, 21144, 21099, 21075,21044, 20869, 20833, 20783, 20744, 20741, 20715 21072 20741 20769, 20699 20490 20717 20539 20702, 20582 20664, 20573 20672 21348 20717 20627, 20571 21078 20702 21423 21275, 21164, 20867, 20623, 20558 21051, 21049 20790 20737, 20682, 20534, 20490 21149, 21020, 20790, 20717 20721, 20711 21423, 20896, 20651 20826 21173, 20798 21533 21127 20869, 20801, 20741, 20591 21440, 21416, 21158, 21058 20511 20675, 20646, 20539, 20503 21159, 20782 20539 21533, 21273 21270, 20831, 20695 20522 20839, 20717 21521, 20521 21082 20894 20741, 20692, 20591 21222

Appendices 73

Appendix D: Programming the Remote Control, continued

Programming Codes, continued

DVD Players/Recorders Brand Code

NEC Nesa Next Base NexxTech Norcent

Onkyo

OptoMedia Electronics Oritron Panasonic

Philips

PianoDisc Pioneer

Polaroid Polk Audio Portland Princeton Proceed Proscan ProVision Qwestar RCA

Rio RJTech Rotel Rowa Sampo Samsung

Sansui Sanyo

Sensory Science Sharp

Sharper Image Sherwood

Shinsonic Sigma Designs Sonic Blue Sony

Sungale SVA Sylvania Symphonic TAG McLaren Teac Technics

20785 20717 20826 21402 21265, 21107, 21003, 20872 20792, 20627, 20503 20896

20651 21762, 20703, 20632, 20503, 20490 21354, 21267, 20675, 20646, 20539, 20503, 21024 21571, 20632, 20631, 20571, 20525 21086, 21061, 21020 20539 20770 20674 20672 20522 20778 20651 20822, 20790, 20717, 20571, 20522 20869 21360 21178, 20623 20823 20752, 20698 21075, 21044, 20820, 20744, 20573, 20490 20695 20873, 20695, 20670 21158 21256, 20752, 20675, 20630 21117 21077, 21043, 20770, 20633 20839, 20533 20674 21099, 20869 21533, 21431, 21033, 20864, 20533 21074 21105, 20860 21268, 20675 21268, 20675 20894 20809, 20790 20703, 20490

DVD Players/Recorders Brand Code

Technosonic Techwood Terapin Theta Digital Toshiba

Tredex

Urban Concepts US Logic Venturer Vizio Vocopro Xbox Xwave Yamaha

Yamakawa Zenith

Zoece

20730 20692 21031 20571 21154, 20695, 20503 20804, 20803, 20800, 20799 20503 20839 20790 21226, 21064 21027 20522 21001 20545, 20539, 20490 20872 20869, 20741, 20591, 20503 21265

Laser Disc Players Brand

Aiwa Carver

Denon

Disco Vision Funai Harman/Kardon Hitachi Kenwood Magnavox

Marantz Mitsubishi NAD Optimus Panasonic Philips Pioneer Polk Audio Quasar Realistic Samsung Sega Sony

Technics Theta Digital Yamaha

Code

20203 20323, 20194, 20064 20243, 20241, 20172, 20059 20023 20203 20194 20023 20258 20243, 20241, 20217, 20194 20194, 20064 20059 20059 20059 20204 20194,20064 20059, 20023 20194 20204 20203 20323 20023 20270, 20201, 20193 20204 20194 20451, 20217

Satellite Receivers Brand Code

AlphaStar Chaparral Crossdigital DirecTV

Dish Network System Dishpro

Echostar

Expressvu GE General Instrument GOI Goodmans Hisense Hitachi HTS Hughes Network Systems iLo Jerrold JVC LG Magnavox Memorex Mitsubishi Motorola NEC Next Level Panasonic Paysat Philips

Pioneer Proscan Proton RadioShack RCA

Samsung

Sanyo Sony Star Choice Tivo

10772 10216 11109 11856, 11749, 11640, 11639, 11609, 11444, 11443, 11442, 11414, 11392, 11377, 11142, 11109, 11108, 11076, 10819, 10749, 10724, 10639, 10566, 10392, 10247, 10099

11775, 11505, 11170, 11005, 10775, 11775, 11505, 11005, 10775 11775, 11505, 11170, 11005, 10775 11775, 10775 10566, 10392 10869

11775, 10775 11246 11535 11250, 10819 11775, 10775 11749, 11444, 11443, 11442, 11142, 10749 11535 10869 11775, 11170, 10775 11414, 11226 10724, 10722 10724 10749 10869, 10856 11270 10869 10701, 10247 10724 11749, 11442, 11142, 11076, 10819, 10749, 10724, 10722, 10099 11442 10566, 10392 11535 10869 11392, 10855, 10566, 10392, 10143, 11609, 11442, 11377, 11276, 11142, 11109, 11108 11219 11640, 11639, 10639 10869 11444, 11443, 11442, 11142

74 Appendices

Appendix D: Programming the Remote Control, continued

Programming Codes, continued

Satellite Receivers Brand Code

Toshiba

UltimateTV Uniden US Digital USDTV Voom Zenith

11749, 11285, 10819, 10790, 10749 11640, 11392 10724, 10722 11535 11535 10869 11856

VCRs and DVRs Brand Code

ABS Admiral

Adventura

Aiko Aiwa

Akai

Alienware America Action American High Asha Audiovox Beaumark Bell & Howell Broksonic

Calix Canon Capehart Carver CCE Citizen Colt Craig

Curtis Mathes

Cybernex CyberPower Daewoo

Daytron Dell Denon DirecTV Durabrand Dynatech Electrohome Electrophonic Emerex

21972 20479, 20209, 20048 20000

20278 20307, 20124, 20037, 20000 20242, 20175, 20106, 20061, 20041 21972 20278 20035 20240 20278, 20037 20240 20104 20479, 20295, 20209, 20184, 20121, 20002 20037 20035 20020 20081 20278, 20072 20278, 20037 20072 20271, 20240, 20072, 20047, 20037 20760, 20162, 20060, 20041, 20035 20240 21972 20637, 20561, 20278, 20045, 20020 20020 21972 20042 20739 20039, 20038 20000 20043, 20037 20037 20032

VCRs and DVRs Brand Code

Emerson

Fisher

Fuji Funai

Garrard Gateway GE

Go Video

GoldStar Gradiente Harley Davidson Harman/Kardon

Harwood Headquarter Hewlett Packard HI-Q Hitachi

Howard Computers HP Hughes Network Systems Humax Hush iBUYPOWER Jensen JVC

KEC Kenwood KLH Kodak LG Linksys Lloyd’s Logik LXI Magnasonic Magnavox

Magnin Marantz

21593, 20637, 20593, 20561, 20479, 20295, 20278, 20212, 20209, 20208, 20184, 20121, 20068, 20061, 20043, 20037, 20036, 20002, 20000 20104, 20066, 20054, 20047 20035, 20033 21593, 20593, 20000 20000 21972 20761, 20760, 20240, 20202, 20060, 20035 20643, 20526, 20432, 20240 20038, 20037 20000 20000 20081, 20075, 20038 20072, 20068 20046 21972 20047 20105, 20089, 20042, 20041, 20000 21972

21972 20739, 20042

20739 21972 21972 20041 21162, 20067, 20041, 20008 20278, 20037 20067, 20041, 20038 20072 20037, 20035 21037 21972 20208, 20000 20072 20037 20593 20593, 20563, 20149, 20110, 20081, 20039, 20035, 20000 20240 20081, 20035

VCRs and DVRs Brand Code

Marta Matsushita Media Center PC MEI Memorex

MGA

MGN Technology Microsoft Mind Minolta Mitsubishi

Motorola MTC Multitech NEC

Nikko Nikon Niveus Media Noblex Northgate Olympus Onkyo Optimus

Optonica Orion

Panasonic

Penney

Pentax Philco Philips

Pilot

20037 21162, 20162, 20035 21972 20035 21262, 21162, 21037, 20479, 20307, 20240, 20209, 20162, 20104, 20048, 20047, 20046, 20039, 20037, 20035, 20000 20240, 20061, 20043 20240

21972 21972 20105, 20042 20443, 20242, 20214, 20173, 20075, 20067, 20061, 20043 20048, 20035 20240, 20000 20072, 20000 20104, 20067, 20041, 20040, 20038 20037 20034 21972 20240 21972 20035 20222 21262, 21162, 21062, 21048, 20593, 20432, 20162, 20104, 20048, 20037 20062 20479, 20295, 20209, 20184, 20002 21262, 21162, 21062, 20616, 20225, 20162, 20077, 20035 20240, 20054, 20042, 20040, 20038, 20037, 20035 20105, 20042 20035 21181, 21081, 20739, 20618, 20110, 20081, 20062, 20035 20037

Appendices 75

Appendix D: Programming the Remote Control, continued

Programming Codes, continued

VCRs and DVRs Brand Code

Pioneer Polk Audio Portland Profitronic Proscan

Protec Pulsar Quarter Quartz Quasar

RadioShack Radix Randex RCA

Realistic

ReplayTV Ricavision Ricoh Runco Salora Samsung

Samtron Sanky Sansui

Sanyo

Scott

Sears

Sharp

Shintom Shogun Singer Sonic Blue Sony

Stack 9 STS

20067 20081 20020 20240 20761, 20760, 20202, 20060 20072 20039 20046 20046 21162, 20162, 20077, 20035 21037, 20000 20037 20037 20880, 20761, 20760, 20240, 20202, 20149, 20106, 20105, 20077, 20060, 20042 20104, 20066, 20062, 20048, 20047, 20046, 20037, 20035, 20000 20616, 20614 21972 20034 20039 20075 20739, 20240, 20045 20643 20048, 20039 20479, 20271, 20209, 20067, 20041, 20000 20240, 20159, 20104, 20047, 20046 20212, 20210, 20184, 20121, 20045, 20043 20105, 20104, 20066, 20054, 20047, 20046, 20042, 20037, 20035, 20000 20848, 20062, 20048 20072 20240 20072 20616, 20614 21972, 21032, 20636, 20035, 20034, 20033, 20032, 20000 21972 20042

VCRs and DVRs Brand Code

Sylvania

Symphonic

Systemax Tagar Systems Tatung Teac Technics Teknika

Thomas Tivo

TMK

Toshiba

Totevision Touch Unitech Vector Vector Research Video Concepts

Videomagic Videosonic Viewsonic Villain Voodoo Wards

White Westinghouse XR-1000

Yamaha Zenith

ZT Group

21593, 20593, 20110, 20081, 20043, 20035, 20000 21593, 20593, 20000 21972 21972 20041 20041, 20000 20162, 20035 20037, 20035, 20000 20000 21503, 20739, 20636, 20618 20240, 20208, 20036 21972, 21503, 21008, 20212, 20210, 20209, 20066, 20045, 20043 20240, 20037 21972 20240 20045 20040, 20038 20061, 20045, 20040 20037 20240 21972 20000 21972 20760, 20240, 20212, 20149, 20081, 20072, 20062, 20060, 20048, 20047, 20042, 20035, 20000 20637, 20209, 20072

20072, 20035, 20000 20038 21139, 20637, 20479, 20209, 20039, 20034, 20033, 20000 21972

76 Appendices

Appendix E: Troubleshooting

TV Reset Comparison Guide

You can resolve many common TV problems using the reset functions described in the following table. See also the troubleshooting suggestions later in this appendix.

IMPORTANT Before you change sound or picture settings: If

picture or sound settings seem wrong for a broadcast

Reset Name When to Use How to Use Resulting Action

Format When the picture

shape seems

PerfectColor™ and PerfecTint™ Reset

(for the single input currently being watched)

incorrect, use change the shape of the picture.

When the color intensities seem out of balance, use the PerfectColor/ PerfecTint reset to reset the color balances to the original factory settings. Both PerfectColor and PerfecTint and are reset at the same time.

FORMAT

Press the the available formats to find the best

format for the current picture.

1. While viewing the input to be

2. Use to highlight PerfectColor

3. Press

FORMAT

reset, press Main menu with the A/V icon highlighted.

and press PerfectColor adjustment screen.

CANCEL

channel (a channel from satellite receiver), first check other channels from the same input before changing settings. If most other channels from the same input seem correct, there is likely a problem with the broadcast rather than with the TV. Use care in this case, as changes you make to fix problems on individual channels also affect all other channels on the same input.

key to cycle through

to display the

ENTER

to display the

to reset the colors.

ANT 1, ANT 2

The last-used format for a signal type is memorized for each input. The next time the same input and the same signal type is viewed, the last-used format will be recalled.

All PerfectColor/PerfecTint sliders are reset to the original center position. The PefectColor/PerfecTint settings for other inputs remain unchanged.

, a cable box, or

A/V Memory Reset

(for the single input currently being watched)

A/V Reset

(for all inputs)

Channel Memorization

When audio and/or video settings for a single input seem incorrect, use A/V Memory Reset to return the input to the original factory settings.

To reset audio and video adjustments for ALL inputs back to their original factory settings.

To erase and rememorize channels on

ANT 1

ANT 2

1. While viewing the input to be reset, press Main menu with the A/V icon highlighted.

2. Use to highlight the Reset icon and press

While viewing the TV, press the side panel buttons same time.

1. While viewing the TV, press to display the Main menu.

2. Press to highlight the Setup icon.

3. Press to highlight the Scan icon.

4. Press to highlight the antenna input and reception mode, e.g. ANT 1 Air.

5. Press to highlight the Start button icon and press start the memorization.

to display the

ENTER

GUIDE

and

to reset.

FORMAT

at the

ENTER

All Video and all Audio (except Balance, Listen To, & Language) settings for an individual input are reset. In addition, two global settings (Video Noise & SharpEdge) are reset to their original factory settings.

All Audio and Video settings are returned to their original factory settings.

All previously memorized channels for the selected antenna input are erased and a new set of memorized channels is created. All custom settings for Fav, channel names, and channel locks are deleted. To add or delete individual channels, see Edit menu instructions in chapter 5, “TV Menu Settings.”

Appendices 77

Appendix E: Troubleshooting, continued

Reset Name When to Use How to Use Resulting Action

Lock Menu Pass Code

Side Panel Lock Release

System Reset If the TV does not turn

TV Reset IMPORTANT:

Use this reset only if all other resets have been unsuccessful.

To change your Lock menu pass code

To re-enable the side panel controls after activation of the Side Panel Lock

on or off, does not respond to the remote control or side panel buttons, or has audio but no video.

To reset all consumeraccessible settings and all memories to the original factory defaults.

CAUTION: All ownerperformed setups and adjustments will be erased.

See the

Press and hold the on the side panel for over eight seconds.

Press the side panel with a pointed object such as the point of pencil or end tip of a paperclip.

1. While viewing the TV, press

2. With the Main menu displayed,

3. READ THE ON-SCREEN

cutout page in Appendix A.

button

SYSTEM RESET

to display the TV Main menu.

press number keys 1 2 3 to display the Reset menu.

WARNING AND INSTRUCTIONS.

• If you do not wish to use this reset, press back out.

• If you do wish to use the reset, press memories and settings.

button on the

EXIT

ENTER

to erase all

Allows a new code to be established.

Allows the side panel controls to be unlocked if the remote control is misplaced.

The TV will turn off and the blue LED will flash quickly for about one minute. When the blue LED stops flashing, you may turn on the TV. The changes you made most recently, before using SYSTEM RESET may be lost. Changes you made previously, however, are not lost.

The TV will start the initialization process. The TV will then turn off and the front blue LED will start flashing. When the LED stops flashing (about. 1 min.), you can turn the TV on again. The Parental Lock Pass code will remain unaffected, but all other memories and settings outlined in this Owner’s Guide will need to be set again.

Service and Support

Service

If you are unable to correct a problem with your TV, consult your Mitsubishi dealer or Mitsubishi Consumer Relations at (800) 332-2119.

• DO NOT adjust any controls other than those described in this Owner’s Guide.

•

DO NOT remove the protective back cover of your TV.

Support

• To order replacement or additional remote controls or Owner’s Guides, parts.com or call (800) 553-7278.

• For questions:

Call Consumer Relations at 800-332-2119. E-mail: MDEAservice@mdea.com

visit our website at www.mitsu-

78 Appendices

Appendix E: Troubleshooting, continued

General TV Operation

Symptom Remarks

1. The TV remote control does not work. • Check that the batteries are fresh and installed correctly.

• Check that the slide switch on the remote is set to TV.

•

Be no more than 20 feet from the TV when using the remote control.

• Program remote control to operate the TV or other device.

• Reset the remote control.

2. The TV remote

3. TV does not respond to the remote control or to side panel controls and TV will not power on or off.

4. When a device is selected from the Input Selection menu, the screen is blue (no signal source).

You have forgotten your Lock menu pass code.

6. Rating restrictions are not working. Open the Parental Lock menu and:

7. On-screen displays appear each time you change a function.

TV Channels

Symptom Remarks

1. The TV takes several seconds to respond to channel changes.

2. You cannot access a channel.

3. Name options are not available for some channels.

4. When ChannelView™ list is displayed, information appears incomplete

POWER

key blinks five times. Batteries in the remote are low and should be replaced.

Use the System Reset button.

• Make sure the selected device is turned on.

• If the device is a VCR, begin play of the VCR.

See Appendix A, Bypassing the Parental Lock.

• Verify that the U.S. Ratings or Other Ratings setting is On.

• Check the Lock Time/Unlock Time to check if rating restrictions are disabled.

• Rating restrictions apply only to content on ANT 1 and ANT 2, INPUT 1–3.

Normal TV operation.

• It is normal for digital channels to take longer to tune in.

•

Press ENTER after a entering channel number to avoid delays.

• Use a 4-digit number for an over-the-air digital channel.

• Use a 6-digit number for digital cable channels if your cable service is able to recognize 6-digit channel numbers.

• Use number keys instead of CH/PAGE

• Be sure the channel you want to view is in memory. See Setup > Scan in chapter 5, “TV Menu Settings.”

• Check that the TV is switched to the correct device or antenna for that channel by pressing the INPUT key.

• Make sure Channel Lock is off.

• Make sure the Lock > Parent menu lock is set to off.

• If you cannot tune to a virtual digital channel even though the TV has already memorized digital channels, tune to the physical channel number used by the broadcaster. The virtual channel will then be automatically added to memory.

You can name only memorized analog channels and memorized digital channels not named by the broadcaster or TV Guide Daily.

• Available information is sent from the broadcaster or cable provider. No other data is available.

• Make sure the TV clock is set correctly.

/ .

Appendices 79

Appendix E: Troubleshooting, continued

TV Power On/Off

Symptom Remarks

1. TV takes an excessively long time to power on.

2. You cannot program the TV to turn on automatically (Timer function).

3. The TV will not turn on after being plugged in.

4. TV turned itself off and the light on the front panel started to blink.

5. TV will not power off. Use the System Reset button or unplug the TV, wait a few

• When switched on, the TV needs time to boot up, just as a computer does.

• TV Energy Mode is set to Low Power. Change TV Energy Mode to Fast Power On in the Setup menu.

• The TV may be locked.

• The clock may not be set.

• TV Energy Mode is set to Low Power. Change to Fast Power On in Setup menu.

If light on front panel is blinking, wait for at least one minute for the light to turn off, then press POWER again.

• Momentary power fluctuation caused the TV to turn off to prevent damage. Wait for the blue light to stop flashing and turn the TV on again.

• If the TV does not stay on, use the System Reset button on the side panel. If this happens frequently, obtain an AC line power conditioner/surge protector.

•

An unusual digital signal may have been received, triggering a protection circuit. Wait for the light to stop flashing and turn TV on.

seconds, then plug in the TV.


Symptom Remarks

1. Picture does not look like a high-definition picture.

2. Picture has become dimmer. Adjust the backlight setting. Press VIDEO repeatedly to display

3. There is a large black or gray rectangle on the screen.

4. You cannot view a picture when playing a VHS tape.

5. VCR or DVD player’s on-screen menus jitter up and down.

6. When viewing a stopped VCR, white lines are rolling on the screen.

7. A color program appears as a black and white image, or the colors are dim, or the screen is black.

Not all signals are high-definition signals. To receive high-definition programming from your cable or satellite provider, you must subscribe to the provider’s high-definition service. Some overthe-air broadcasts are in high-deﬁnition and can be received with a high-quality antenna suited to your location.

the backlight settings, then use to change the setting. The TV’s analog closed captioning has been set to “text” mode

in the Captions menu. Turn off because there is no text information being broadcast.

Check your VCR’s owner’s guide for further troubleshooting.

Possible cause: Many VCRs and DVD players provide onscreen menus at only half-resolution. These lower-resolution graphics may appear to jitter up and down when the TV converts them to high-definition graphics.

• Turn off video mute for the VCR.

• Begin playing the tape.

• Change the viewing source to ANT 1 to watch TV.

• The PerfectColor™ color balance has been incorrectly set. Reset the PerfectColor balance.

• If watching a program on a component video input, make sure the red and blue cables are plugged in.

• If watching a program on an S-Video input, check the connectors for bent pins.

80 Appendices

Appendix E: Troubleshooting, continued


Symptom Remarks

8. Picture from an HDMI input is noisy (poor quality).

9. The image from a computer appears distorted when viewed on the TV.

Sound (see also NetCommand troubleshooting for A/V receiver setup)

Symptom Remarks

1. There is no sound even when the volume is turned up.

2. The sound does not match the screen picture.

Upgrade a Category 1 (unmarked) HDMI cable to a Category 2 HDMI cable.

Normal TV operation. The TV does not correct distortion in the picture from a computer because the correction process may cause the edges of the image to be cut off. Press FORMAT on the TV remote control to adjust the size.

• Check if the MUTE key is on.

• The TV’s “Listen to:” setting may be set to SAP.

• Check that the Speakers option is set to TV to hear sound from the TV speakers instead of the AVR.

• If using an A/V receiver, check that the Speakers option is set to AV Receiver to hear sound from the A/V receiver speakers.

• Perform a System Reset.

• The TV’s Listen to: setting may be set to SAP.

•

If using stereo or A/V receiver speakers, check their input selection in the Inputs > AVR menu. rectly for the A/V receiver.

• If using stereo or A/V receiver, check that DIGITAL AUDIO OUT and/or AVR AUDIO OUTPUT on TV’s back panel is connected to the A/V receiver.

NetCommand® is set up incor-

Indicators

Symptom Remarks

1. STATUS indicator light is a steady/flashing red.

• Unplug set from AC power. Plug back in and wait one minute for blinking to stop.

• Press SYSTEM RESET button on side panel and wait for blinking to stop.

• If blinking continues, service is required. Contact your dealer or a Mitsubishi Authorized Service Center to arrange for a service evaluation. Listings of Mitsubishi Authorized Service locations can be obtained from our web site, www.mitsubishi-tv.com or by calling 1-800-332-2119.

Appendices 81

Appendix E: Troubleshooting, continued

NetCommand

Symptom Remarks

1. Cannot see the menu from the A/V Receiver.

2. NetCommand unable to learn specific device keys.

3. The A/V Receiver is the selected audio source but there is no sound.

4. There is no sound when I switch to the A/V receiver using the Speaker setting in the AV menu, even though I have physically connected the TV to the A/V receiver and learned IR codes for the receiver inputs.

5. There is no sound from the A/V receiver for my DVD player or other surround sound device even though I learned the IR code for the A/V receiver’s DVD input or other input.

6. I’ve selected my DVD player or other surround sound device in combination with the TV speakers but hear no sound from the TV speakers.

7. I “learned” the RECORD key for my VCR/ DVR but when I pressed the RECORD key, the VCR/DVR did not record anything.

The A/V Receiver is not connected to any video input of the TV. To check the A/V Receiver menu, temporarily plug into an unused input of the TV, such as Input 3. Exit the Auto Input Sensing screen and highlight Input 3 from the Input Selection menu. Press MENU on the A/V receiver remote control.

• Device does not use IR format for remote control signal. ITT and RF formats cannot be learned.

• Room lighting may affect the signal. Have the remotes very close (6 inches or less) to the TV during Learning.

• If learning from a Mitsubishi remote control, make sure slide switch is not set to TV position.

• Some, but not all, device key functions can be learned by NetCommand. For example, POWER and PLAY may be learned, but other functions may not.

• The signal from the remote control may not be strong enough. Insert fresh batteries and try Learning again.

• Check to see if the A/V Receiver power is turned on.

• With the power turned on, redisplay the Input Selection menu and press ENTER to allow NetCommand to correctly select the A/V Receiver input.

• Incorrect setup in the Inputs > AVR menu. Check the device connection assigned in the AVR menu.

Wrong input or no input was assigned in the AV Receiver Learn screen. All audio should go to the A/V receiver as audio output from the TV unless the device’s audio is connected directly to the A/V receiver. See chapter 6, “NetCommand,” and perform the procedure to select the correct A/V receiver input.

NetCommand A/V receiver setup for the DVD player or digital surround sound device or other device is not switching properly. See chapter 6, “NetCommand,” and perform A/V receiver setup for a digital surround sound device.

If you have only an audio connection from the device to the A/V receiver, a physical audio connection from the device to the TV is also required.

• Connect the left and right audio output from the device to the appropriate TV audio input. Now you can hear audio from the device through either the TV speakers or the A/V receiver.

• To switch audio sources, press AUDIO, press the Speakers option, then press to select AV Receiver or TV.

• If using an HDMI connection, you may need to set the audio output of the device to PCM AUDIO, as the TV is unable to decode other digital surround sound audio received on HDMI.

Check that the VCR or DVR is receiving a signal directly from your cable box or satellite receiver.

to show

82 Trademark and License Information

Trademark and License Information

LICENSOR’S SUPPLIERS DO NOT MAKE OR PASS ON TO END USER OR ANY OTHER THIRD PARTY, ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY OR REPRESENTATION ON BEHALF OF SUCH SUPPLIERS, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

CableCARD™ is a trademark of Cable Television Laboratories, Inc. Manufactured under license from Dolby Laboratories. Dolby is a trademark of Dolby Laboratories. HDMI™ the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual

property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited pay-per-view uses only unless otherwise authorized by Macrovision. Reverse engineering or

disassembly prohibited.

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a

license from Microsoft Licensing, Inc.

The logo and the words “Simplay™” and “Simplay HD™” are the trademarks of Silicon Image, Inc.

In the United States, TV Guide and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates.

The TV Guide Daily system is manufactured under license from Gemstar-TV Guide International, Inc. and/or one of its

affiliates.

The TV Guide Daily system is protected by one or more of the following United States patents 4,908,713; 6,498,895;

6,850,693; 6,396,546; 5,940,073; 6,239,794 to Gemstar-TV Guide International, Inc. and/or its subsidiaries. Gemstar-TV Guide International, Inc. and/or its related affiliates are not in any way liable for the accuracy or avail-

ability of the program schedule information or other data in the TV Guide Daily system and cannot guarantee service availability in your area. In no event shall Gemstar-TV Guide International, Inc. and/or its related affiliates be liable for any damages in connection with the accuracy or availability of the program schedule information or other data in the

TV Guide Daily system.

x.v.Color and the x.v.Color logo are trademarks of Sony Corporation. ChannelView™, DeepField™ Imager, Easy Connect™, NetCommand®, PerfectColor™, PerfecTint™, Plush 1080p®,

QuickView™, SharpEdge™, Smooth120Hz™ are trademarks of Mitsubishi Digital Electronics America, Inc.

Trademark and License Information 83

Mitsubishi TV Software

END-USER LICENSE AGREEMENT FOR EMBEDDED SOFTWARE

IMPORTANT – READ CAREFULLY: This License Agreement is a legal agreement between you (either an individual or an entity) and

Mitsubishi Digital Electronics America, Inc. (MDEA) for all software pre installed and/or provided along with this television (“Software”). By utilizing this television and Software, you agree to be bound by the terms of this License Agreement.

The Software is protected by United States copyright laws and international treaty provisions, as well as other intellectual property laws

and treaties. The Software is licensed, not sold.

1. LICENSE GRANT. MDEA grants you a non-exclusive, non-transferable, limited right and license to use one copy of the Software only with the Mitsubishi television model that included this owner’s guide and owned by you.

RIGHTS AND LIMITATIONS.

Software Not for Resale. You may not resell or otherwise transfer for value the Software, except in conjunction with a sale of the TV

that Software has been pre installed.

Prohibition on Reverse Engineering, Decompilation and Disassembly. The Software contains trade secrets or other proprietary material

in its human perceivable form and to protect them, you may not reverse engineer, decompile, or disassemble, or otherwise reduce the

Software to any human perceivable form, except to the extent that the foregoing restriction is expressly prohibited by applicable law. Separation of Components. The Software is licensed as a single product. Its component parts may not be separated for use on more

than one TV.

No Rental. You may not rent, lease, lend, or sublicense the Software.

Trademarks. This License Agreement does not grant you any rights to any trademarks of MDEA.

3. VIOLATIONS. You understand that any use, copying or transfer of the Software, except as permitted pursuant to this License, may subject you to serious criminal and civil penalties including damages and an award to MDEA of attorneys’ fees in connection with any violation of this License. You further understand that you may be held legally responsible for any copyright infringement or other violation of intellectual property rights that is caused, encouraged, or induced by your failure to abide by the terms of the License. This

license is effective until terminated, and will terminate immediately without notice from MDEA or judicial resolution if you fail to comply

with any provision of this License.

4. COPYRIGHT. All title and intellectual property rights in and to the Software (including but not limited to any images, photographs, animations, video, audio, music, text, and “applets” incorporated into the Software), and any accompanying printed materials are owned by or licensed to MDEA. All title and intellectual property rights in and to the content which may be accessed

through use of the Software is the property of the respective content owner and may be protected by applicable copyright or other

intellectual property laws and treaties. This License Agreement grants you no rights to use such content, except that you own the media on which the Software is recorded, but MDEA and its licensors retain ownership of the Software itself. All rights not expressly granted are reserved by MDEA.

5. EXPORT RESTRICTIONS. MDEA is licensing the Software for use within the United States. You agree that you will not export or re-export the Software. You specifically agree not to export or re-export the Software: (i) to any country to which the U.S. has embargoed or restricted the export of goods or services, which currently include, but are not necessarily limited to Cuba, Iran, Iraq, Libya, North Korea, Sudan, and Syria, or to any national of any such country, wherever located, who intends to transmit or transport the Software back to such country; (ii) to any person or entity who you know or have reason to know will utilize the Software in the design, development, or production of nuclear, chemical, or biological weapons; or (iii) to any person or entity who has been prohibited from participating in U.S. export transactions by any federal agency of the U.S. government. You warrant and represent that neither the BXA nor any other U.S. federal agency has suspended, revoked, or denied your export privileges.

6. DISCLAIMER OF WARRANTY. EXCEPT AS OTHERWISE PROVIDED IN THIS LICENSE OR IN THE LIMITED WARRANTY

APPLICABLE TO THE TV, MDEA MAKES NO OTHER WARRANTIES OF ANY KIND WHATSOEVER REGARDING THE SOFTWARE AND HEREBY EXPRESSLY DISCLAIMS ALL WARRANTIES OF ANY KIND WHATSOEVER, EXPRESS OR IMPLIED, WITH

RESPECT TO THE SOFTWARE. ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXPRESSLY DISCLAIMED BY MDEA. IN

NO EVENT SHALL MDEA BE LIABLE TO YOU OR ANY THIRD PARTIES, IN CONTRACT, IN TORT OR OTHERWISE, FOR ANY

DIRECT, INDIRECT, SPECIAL , INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES, THE ABOVE LIMITATION MAY

NOT APPLY TO YOU.

7. LIMITATION OF LIABILITY. MDEA SHALL NOT, UNDER ANY CIRCUMSTANCES BE LIABLE TO YOU OR ANY THIRD

PARTIES FOR ANY DAMAGES OF ANY NATURE, WHETHER INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, ANY CLAIMS FOR LOST PROFITS, LOSS OF GOOD WILL OR

EXPENDITURES MADE OR COMMITTED FOR IN RELIANCE ON THE CONTINUATION OF THIS LICENSE. YOU AGREE THAT

NEITHER MDEA’S BREACH OF THIS LICENSE NOR ITS FAILURE TO REPAIR A DEFECT, ERROR OR BUG SHALL CONSTITUTE A FAILURE OF THE ESSENTIAL PURPOSE OF THIS LICENSE. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE

EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY

NOT APPLY TO YOU. MDEA’s liability to you for direct damages for any cause whatsoever and regardless of the form of the action, will be limited to the money paid by you for the TV (based on fair market value of the TV) that caused the damages.

8. GENERAL. This License Agreement will be governed by the laws of the State of California.

WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm.

MITSUBISHI LCD FLAT PANEL HDTV LIMITED WARRANTY

MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. (“MDEA”) warrants to the original purchaser of this LCD Flat Panel HDTV that if purchased from an authorized MITSUBISHI Audio/Video Dealer, should it prove defective by reason of improper workmanship and/or material:

a. Parts. All parts (except any software incorporated into this HDTV are warranted for a period of one year from the date of the original purchase at retail. We will repair or replace, at our option, any defective part without charge for the part. Parts used for replacement may be replaced with those of like kind and quality and may be new or remanufactured. Parts used for replacement are warranted for the remainder of the original warranty period.

b. Embedded Software. MDEA warrants that all software incorporated into this HDTV (the “Embedded Software”) will perform in accordance with the functional description of Embedded Software in all material respects, but MDEA does not warrant that the Embedded Software is error-free. MDEA also does not warrant that the Embedded Software will be compatible under IEEE 1394 AV/C and HAVi software standards with products produced by any other manufacturer. The warranty contained in this section shall continue for a period of one year, from the date of the original purchase from the dealer. If, after prompt notice within the warranty period, MDEA determines that the Embedded Software has failed to perform in accordance with such functional description in all material respects and if such failure is not due to accident, misuse, modification or misapplication of the Embedded Software, then MDEA shall modify or replace the nonconforming Embedded Software at no charge to you, which at MDEA’s sole discretion may be fulfilled by means of modification or replacement software contained on a replacement memory card for Customer installation. The foregoing shall be MDEA’s sole obligation to you under this limited warranty. All rights under this limited warranty on the Embedded Software also subject to your compliance with the terms of the Software License Agreement applicable to this HDTV, and this limited warranty on the Embedded Software shall be null and void if the Embedded Software is modified or changed in any manner except as specifically authorized by MDEA.

c. Labor. For certain items that are designed to be replaced by the consumer, including (but not limited to) some Embedded Software, the consumer is solely responsible for any replacement labor. For all other parts, we will provide the labor for a warranty repair by an authorized MITSUBISHI service center without charge for one year from the original date of purchase at retail.

d. Notice. To obtain warranty service, you must notify an authorized MITSUBISHI service center of any defect within the applicable warranty time period.

BEFORE REQUESTING SERVICE, please review the TV owner’s guide to insure proper installation and correct customer control adjustment. If the problem persists, please arrange for warranty service.

1. TO OBTAIN WARRANTY SERVICE: a. Contact your nearest authorized MITSUBISHI service center whose name and address can be obtained from your

MITSUBISHI dealer, by writing to the address provided below, calling MDEA at 800-332-2119, or using the support feature of our website at www.Mitsubishi-tv.com.

b. Warranty service will be provided in your home or, if required, at an authorized service shop, provided that your television is located within the geographic territory customarily covered by an authorized MITSUBISHI service center. If not, you must either deliver your television to an authorized service location at your own expense, or pay for any travel and/or transportation costs the service center may charge to and from you home. Actual service labor will be provided without charge.

c. Proof of purchase date from an authorized MITSUBISHI dealer is required when requesting warranty service. Present your sales receipt or other document which establishes proof and date of purchase. THE RETURN OF THE OWNER REGISTRATION CARD IS NOT A CONDITION OF WARRANTY COVERAGE. However, please return the Owner Registration Card so that we can contact you should a question of safety arise which could affect you.

2. THIS LIMITED WARRANTY DOES NOT COVER: a. Up to .01% pixel outages (small dot picture elements that are dark or incorrectly illuminated). b. Cosmetic damage or any other damage where such damage is caused by unauthorized modification, alteration,

repairs to or service of the product by anyone other than an authorized MITSUBISHI service center; physical abuse to or misuse of the product (or any product damaged by excessive physical or electrical stress); any products that have had a serial number or any part thereof altered, defaced or removed; product use in any manner contrary to the Owner’s Guide; freight damage; or any damage caused by acts of God or other factors beyond the reasonable control of MDEA, such as power surge damage caused by electrical system or damages caused by use of third party mounting brackets or stands. This limited warranty also excludes service calls where no defect in the product covered under this warranty is found, service calls related to unsatisfactory audio or visual reception or signal unless caused by a defect in the product that is covered under this limited warranty, all costs, expenses or any other damages

arising from product installation, removal from or re-installation into custom installations or on wall mountings, or set-ups, any adjustments of user controls (including contrast, brightness, color, tint, fine tuning, sharpness), other adjustment necessary to prepare the unit for display or use, connection with any external audio receiver, antenna, cable or satellite systems, or service of products purchased or serviced outside the U.S.A.

Please consult the operating instructions contained in the Owner’s Guide furnished with the product for information regarding user controls.

3. ANY EXPRESS WARRANTY NOT PROVIDED HEREIN, AND ANY REMEDY WHICH, BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION OR OPERATION OF LAW, IS HEREBY EXCLUDED AND DISCLAIMED. THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO A TERM OF ONE YEAR.

4. UNDER NO CIRCUMSTANCES SHALL MDEA BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE.

5. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental, special, or consequential damages, so the above limitations or exclusions may not apply to you.

6. This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

7. In the event of any dispute under this limited warranty, jurisdiction and venue for resolving that dispute will be in the state where the television was purchased and the laws of such state will govern.

In no event shall Mitsubishi have any liability, including without limitation, for general, consequential, incidental, or special damages for loss, destruction, damage or corruption of recorded data, media or software resulting from use of this television, or cost of recovery of lost data, media or software therefore.

MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. 9351 Jeronimo Road Irvine, CA 92618-1904

86 Index

Index

A/V Memory Reset 76 A/V Receiver

Adding NetCommand Control

57, 58, 59 and the TV Speakers 40 and TV’s Remote Control 57, 68

Audio Lock 69 Codes 70

Connecting 10, 26, 58 Controlling Sound Volume 15

A/V Reset 8, 76 Adjust Keys (Up/Down/Left/Right)

29, 37 Anamorphic Picture Format 34 Antenna

Connecting 22

Antenna Inputs (ANT 1/MAIN, ANT

2/AUX) 9 Audio Lock 69 Audio Menu 40 Auto-off. Auto-on. Auto Input Sensing

Back Panel (described) 9, 10 Batteries 13 Blue Glow 38

CableCARD 16, 22

Cable Box

Cable Management 19 Cable Service (Direct) 22 Camcorder 27 Captions Menu 41 Channels.

See

Sleep Timer

See

Timer

Description 6 TV Setup 14

Channel Memorization 14, 42

and TV’s Remote Control 30, 68,

Connecting 20, 21, 25, 26

Mitsubishi Electronics LT-52244, LT-46244 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Important Information About Your TV

Installation Notes

TV Guide Daily Access Requirements

Important Safeguards

Television Overview

Package Contents

Special Features of Your TV

TV Front Panel

TV Side Panel

TV Back Panel

Stand Removal Instructions

Guidelines for Setting Up and Using Your New Widescreen TV

When You First Power On the TV

Installing the Remote Control Batteries

Initial TV Setup

Setting Up TV Inputs

Controlling A/V Receiver Sound Volume

Using a CableCARD

Using the TV with a Personal Computer

TV Connections

Before you Begin

Cable Management

HDTV Cable Box or Satellite Receiver with Component Video

Standard Cable Box, Satellite Receiver, or Other Device with S-Video

Direct Cable (no cable box)

Antenna with a Single Lead

Antennas with Separate UHF and VHF Leads

DVD Player with Component Video

DVI Video Device (Cable Box, Satellite Receiver, DVD Player, or Other Device)

VCR to an Antenna or Wall Outlet Cable

VCR to a Cable Box (Audio & Video)

A/V Receiver (Sound System)

Older Cable Box

Camcorder

TV Operation and Features

Choosing a Viewing Source

Sleep Timer

Remote Control

ChannelView Channel Listings

Status Display

Fav (Favorite Channels)

TV Signals and Display Formats

Viewing Camera Files

JPEG Photos and the USB Photo Port

Photos and Moving Video as Composite Video

TV Menu Settings

Main Menu

Remote Control Keys for the TV Menu System

AV Menu

Video Menu

Audio Menu

Captions Menu

Setup Menu

Inputs Menu

Lock Menu

Pass Codes

Parent Menu

Other Menu (Alternate Rating System)

Bypassing TV Locks

NetCommand

About NetCommand

IR Emitter Placement

Initial NetCommand Setup for Most Devices

Adding or Removing Device Keys from NetCommand Control

NetCommand Specialized Device Keys

Operating NetCommand-Controlled Devices

Setting Up NetCommand Control of an A/V Receiver

Appendices

Appendix A: Bypassing the Parental Lock

Appendix B: Specifications

Appendix C: TV Guide Daily

Appendix D: Programming the Remote Control

Appendix E: Troubleshooting

Trademark and License Information

Mitsubishi TV Software

Index
