Owner’s Guide

LLT-3280/LT-3780

T-3280 /LT-3780

LCD Flat Panel

HDTV

visit our website at:

www.mitsubishi-t v.com

Display & Media Center

LCD Flat Panel

Display & Media Center

Owner’s Guide

HDTV

visit our website at:

www.mitsubishi-tv.com

For Your Records

Use this space to record the serial numbers, purchase date, and dealer information of the two companion devices—the display and media center. The serial numbers are on the rear of these devices.

Note: In this guide and all on-screen instructions, the HD-4001 Receiver/ Controller is referred to as the “media center.” The terms “TV” and “HDTV” are used interchangeably to refer to the LCD Flat Panel HDTV.

To operate as a complete HDTV, the display must be connected to the media center using both required MonitorLink™ cables. See Chapter 2 for more information.

MODEL NUMBER: LT-3280/LT-3780 Flat Panel HDTV

DISPLAY SERIAL NUMBER

MEDIA CENTER SERIAL NUMBER

PURCHASE DATE

DEALER NAME

STREET ADDRESS

CITY STATE ZIP

PHONE

Contents

Important Information

General Warnings and Cautions ....................................................... 1

Declaration of Conformity Important Safeguards Stand Removal Instructions

Chapter 1: Product Overview

Package Contents ................................................................... 8

Special Features Display Top Control Panel Media Center Front Control Panel Remote Control Overview Remote Control Operation

Battery Installation Care

............................................................................. 13

Sleep Timer Display Rear Panel Media Center Rear Panel

..................................................................... 9

...................................................................... 13

.................................................................. 14

............................................................. 2

................................................................ 3

........................................................... 5

........................................................... 10

............................................................ 12

........................................................... 13

................................................................ 13

............................................................ 15

..................................................... 11

Chapter 2: Connecting

Essential MonitorLink™ Connections .................................................. 18

AC Power Cords External Devices and NetCommand Wall Outlet Cable Cable Box Antenna with Twin Flat Leads Separate UHF and VHF Antennas Using a CableCARD™ Antenna or Wall Outlet Cable to a VCR Cable Box to VCR A/V Receiver or Stereo System Satellite Receiver or Other S-Video Devices DVD Player or Other Component Video Device HDMI Output Device DVI Output Device IR Emitters and NetCommand® Compatible IEEE 1394 Device Connection Styles Helpful Hints

.................................................................... 19

................................................................... 21

......................................................................... 21

............................................................... 23

................................................................... 25

................................................................ 28

.................................................................. 29

.................................................................. 33

....................................................................... 34

Overview

........................................................ 22

..................................................... 22

................................................ 24

....................................................... 26

..................................................... 30

........................................................ 32

........................................ 20

........................................... 26

......................................... 27

Chapter 3: NetCommand® Setup and Editing

NetCommand® Introduction ......................................................... 36

NetCommand Edit NetCommand®

Add an A/V Receiver Add Devices Change Devices Delete Devices

Finish Screen Setup Reminder Screen Using the Remote Control with NetCommand NetCommand 3D Graphical

Initial Setup ......................................................... 37

................................................................. 39

.............................................................. 39

..................................................................... 42

.................................................................. 45

................................................................... 46

..................................................................... 46

............................................................. 46

® ........................................ 47

On-Screen Buttons .................................................. 48

Menu System .................................................. 49

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Using the “Learn” Feature to Control IEEE 1394 Devices ................................. 52

Adding IEEE 1394 Devices Automatically Device Selection Menu

.............................................................. 55

Using the DEVICE MENU Button to Display Menus Device Menu IR Controlled Devices

....................................................................... 56

............................................................... 56

Using the GUIDE Button to Display ChannelView™ and Menus NetCommand® Controlled Recordings Peer-to-Peer Connections Using A/V Discs

.................................................................... 60

........................................................... 59

MediaCommand™ and Memory Card Playback Direct VCR Recording from an Antenna or Cable Source

.............................................. 53

..................................... 56

.......................... 57

................................................ 58

........................................ 61

................................ 63

Chapter 5: Using the TV Menu

Main Menu Choices ................................................................. 66

Setup Menu NetCommand Menu Antenna Menu Time Menu Captions Menu

........................................................................ 67

................................................................. 68

..................................................................... 69

......................................................................... 71

..................................................................... 72

Customizing Digital Settings V-Chip Rating Guidelines V-Chip Lock Menu V-Chip Menu Audio/Video Menu

.................................................................. 75

....................................................................... 75

.................................................................. 77

A/V Setting Descriptions

............................................................ 74

............................................................ 78

......................................................... 73

Chapter 6: Connecting and Using a PC

Connecting a PC to the Display ....................................................... 82

Setting PC Resoluiton PC Display Formats PC Video Settings Supported PC Timings

............................................................... 83

................................................................. 84

.................................................................. 85

.............................................................. 85

Chapter 7: Troubleshooting and Support

Troubleshooting .................................................................... 88

Using the System Reset Button Using the Reset Menu Support

........................................................................... 92

............................................................... 92

...................................................... 92

Appendices

Appendix A: Specifications .......................................................... 94

Appendix B: On-Screen Information Displays Appendix C: Bypassing the V-Chip Lock: Appendix D: Input Connection Compatibility Appendix E: Scan Rates for Input/Output Sources Appendix F: Using PIP and POP

..................................................... 101

Appendix G: TV Display and DVD Formats Appendix H: Remote Control Programming Codes Appendix I: Device Control with NetCommand Appendix J: NetCommand® Specialized Device Keys Appendix K: Changing the Color Temperature of the Display Appendix L: Cleaning

.............................................................. 111

.......................................... 96

.............................................. 97

........................................... 99

............................................ 102

.................................... 100

.................................... 104

® ...................................... 107

.................................. 109

............................ 110

Trademark and License Information ............................................. 112

Warranty ............................................................................. 114

Index .................................................................................. 115

iii

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user of the

presence of uninsulated “dangerous voltage” witUUhin the product’s enclosure that may be sufficient

magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Portions of the advanced circuitry of this Media Center must continue to operate even when the Media Center is turned off. Some of these circuits therefore need to be cooled at all times. A low power standby fan may be heard in a quiet environment. This is normal operation.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING

TO LOCAL, STATE OR FEDERAL LAWS.

CAUTION:

NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF

THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.

CAUTION

When mounting this product (LT-3280D or LT-3780D) to a wall or ceiling, only the specific 'Chief Manufacturing'

all Mount Kit PSM-2048 may be used. Use of any other wall mount kit may result in instability, causing

W possible injury. Complete mounting instructions will be stated in the user manual for PSM-2048.

Wall Mount Kit Part # PSM-2048

Manufacturer’s name: Chief Manufacturing, Inc.

To order a PSM-2048 Wall Mount Kit, please call the Mitsubishi Parts Department at (800) 553-7278, or call

Chief Manufacturing at (800) 582-6480.

IMPORTANT SAFEGUARDS

Please read the following safeguards for your LCD Flat Panel HDTV and retain for future reference.

Always follow all warnings and instructions marked on the LCD Flat Panel HDTV.

1. Read, Retain and Follow All Instructions

Read all safety and operating instructions before operating the LCD Flat Panel HDTV. Retain the safety and operating instructions for future reference. Follow all operating and use instructions.

2. Heed Warnings

Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning

Unplug the LCD Flat Panel HDTV from the wall outlet before cleaning. Do not use liquid, abrasive or aerosol cleaners. Use a lightly dampened cloth for cleaning.

4. Attachments and Equipment

Never add any attachments and/or equipment without approval of the manufacturer as such additions may result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture

Do not use the LCD Flat Panel HDTV where contact with or immersion in water is possible. Do not use near bath tubs, wash bowls, kitchen sinks, laundry tubs, swimming pools, etc.

6. Accessories

Do not place the LCD Flat Panel HDTV on an unstable cart, stand, tripod, or table. The LCD Flat Panel HDTV may fall, causing serious injury to a child or adult and serious damage to the LCD Flat Panel HDTV. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer, or sold with the LCD Flat Panel HDTV. Any mounting of the LCD Flat Panel HDTV should follow the manufacturer’s instructions, and should use mounting accessories recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the LCD Flat Panel HDTV and to protect it from overheating. Do not block these openings or allow them to be obstructed by placing the LCD Flat Panel HDTV on a bed, sofa, rug, or other similar surface. Nor should it be placed over a radiator or heat register. If the LCD Flat Panel HDTV is to be placed in a rack or bookcase, ensure that there is adequate ventilation and that the manufacturer’s instructions have been adhered to.

8. Power Source

This LCD Flat Panel HDTV should be operated only from the type of power source indicated on the marking label.

If you are not sure of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization

This LCD Flat Panel HDTV is equipped with a polarized alternating current line plug having one blade wider than

the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

10. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the LCD Flat Panel HDTV.

11. Lightning

For added protection for this LCD Flat Panel HDTV during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the LCD Flat Panel HDTV due to lightning and power-line surges.

IMPORTANT SAFEGUARDS, continued

12. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or

power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

13. Overloading

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

14. Object and Liquid Entry

Never push objects of any kind into this LCD Flat Panel HDTV through openings as they may touch dangerous voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the LCD Flat Panel HDTV.

15. Outdoor Antenna Grounding

E XAMP LE OF ANTE NNA G R OU NDING

If an outside antenna or cable system is connected to the LCD Flat Panel HDTV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electric Code, ANSI/NFPA No. 70-2002,

provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

GROUNDCLAMP

ELECTRIC SERVICE EQUIPMENT

NEC —NATIONAL ELECTRICAL CODE

ANTE NNA LEAD IN W IRE

ANTE NNA DISC HAR G E U NIT (NE C AR T IC LE 810-20)

GROUNDING CONDUCTORS (NE C AR T IC LE 810-21)

GROUNDCLAMPS

POWER SERVICE GROUNDIN ELECTRODE SYSTEM (NE C AR T 250, P AR T H)

16. Servicing

Do not attempt to service this LCD Flat Panel HDTV yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17. Damage Requiring Service

Unplug the LCD Flat Panel HDTV from the wall outlet and refer servicing to qualified service personnel under the following conditions:

(a) When the power-supply cord or plug is damaged. (b) If liquid has been spilled, or objects have fallen into the LCD Flat Panel HDTV. (c) If the LCD Flat Panel HDTV has been exposed to rain or water. (d) If the LCD Flat Panel HDTV does not operate normally by following the operating instructions, adjust only those

controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the LCD Flat Panel HDTV

to its normal operation. (e) If the LCD Flat Panel HDTV has been dropped or the cabinet has been damaged. (f) When the LCD Flat Panel HDTV exhibits a distinct change in performance - this indicates a need for service.

18. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

19. Safety Check

Upon completion of any service or repair to the LCD Flat Panel HDTV, ask the service technician to perform safety checks to determine that the LCD Flat Panel HDTV is in safe operating condition.

2 0. H e a t

The product should be situated away from heat sources such as radiator s, heat registers, stoves or other products

(including amplifiers) that produce heat.

Stand Removal Instructions

CAUTION

• A minimum of TWO PEOPLE are needed to safely remove the stand.

• One person needs to hold the stand while the other person removes the stand screws.

This is necessary to prevent the stand from falling to the floor.

• Failure to follow these recommendations may result in personal injury as well as damage to the product.

1. Before performing work, make sure to disconnect the AC power cord from the display.

Before performing work, spread the protective sheet that was wrapped around the display on a flat, even surface (such as a table). The protective sheet will prevent the display from being damaged.

3. Gently place the display face down on the protective sheet with the display stand hanging over the edge of the table. See the illustration to the right.

CAUTION: The stand is heavy and can fall, so two people are needed to safely remove it.

4. Remove the small cover on the back of the display. See the illustration to the right. Press on the small tab to release the cover. Keep the cover and reinstall it after connecting the display to the media center.

5. With the stand hanging over the edge of the table, have one person hold the stand firmly with both hands while the other person uses a screwdriver to remove the six (6) stand screws. See the illustration to the right.

1SPUFDUJWF TIFFU

5BC M F

Step 4: Remove the small cover to access stand screws and the AC power input.

%JTQMBZ

4BGFUZ5BC

4UBOE

4UBOE4DSFXT

4UBOE

6. While the first person continues to hold the stand firmly, have the other person unscrew the Safety Tab screw. See the illustration to the right.

7. The person holding the stand can now put the stand carefully in a safe place for future use.

8. The display is now ready for mounting. Refer to the instructions provided with the Wall Mount Kit (purchased separately).

Wall Mount Kit

To order a Wall Mount Kit (Part #

Please call the

or call Chief Manufacuring,

Mitsubishi

Parts Department at: (800) 553-7278

Inc. at: (800) 582-6480.

PSM-2048)

IMPORTANT

BEFORE MOUNTING THE DISPLAY TO A WALL: Be sure to connect a VGA cable to the

display PC (video) Input, and if applicable, a stereo mini cable to the PC Audio Input. Otherwise, you will not be able to access the PC Inputs after wall-mounting.

The media center does not have PC inputs. See Chapter 6 for more information.

Chapter

Product Overview

Package Contents ....................................... 8

Special Features Display Top Control Panel Media Center Front Control Panel Remote Control Overview Remote Control Operation

Battery Installation

Care

Sleep Timer Display Rear Panel Media Center Rear Panel

............................................... 13

........................................9

................................. 10

................................. 12

................................ 13

.................................... 13

.......................................... 13

...................................... 14

.................................. 15

........................... 11

Chapter 1: Product Overview

"(&

Package Contents

The display and media center must be connected together with these two cables.

Please take a moment to review the following list of items to ensure that you have received everything including:

1. Display

2. Media Center

5. One Digital A/V

Sends

MonitorLink™

cable.

audio and video signals from the media center to the display.

6. One MonitorLink™

Control RS-232C cable.

Sends control signals between the media center and the display, allowing

IR signals from the remote

control and other control signals to reach the media center.

7. One Digital Audio cable.

Sends audio from digital TV channels to a digital Audio/Video (A/V) Receiver.

3. Remote Control

4. Two AA Batteries

8. Two AC Power cords.

One for the display and one for the media center.

9. One Quadruple IR Emitter cable.

Allows NetCommand

to control up to four (4)

A/V devices.

LT-3280/LT-3780 Owner’s Guide (not

10.

pictured)

LT-3 2 80 /LT- 3 7 80 Q u ick Se t up/ Refer e nce

11. Guide

(not pictured)

Product Registration Card (not pictured)

13. TV Guide On Screen® Interactive Guide: User’s Manual (not pictured)

Chapter 1: Product Overview

Special Features

Your new LT-3280/LT-3780 LCD Flat Panel HDTV (display + media center) has many

special features, which include:

Two-Piece Design for Maximum Installation Flexibility

The LT-3280/LT-3780 display and media center are designed to work exclusively together as

an integrated HDTV. You can place the display on one side of the room, and with only two connecting cables, place the media center on the other side of the room with your A/V Receiver, VCR, DVD Player, and other A/V devices.

Multiple Connection Capability

On the compact media center rear panel you will find a full complement of the connections needed for the most sophisticated home theater system. Included are standard Audio/Video/ S-Video, wideband component video, FireWire®, IEEE 1394, CableCARD, and two HDMI Inputs.

Digital Cable Ready (CableCARD™)

Your Mitsubishi media center is “Plug-and-Play” ready. It can de-scramble a cable provider’s

one-way digital signals with the use of a CableCARD security module. The CableCARD is used in place of a traditional cable box to access digital cable programming (including high definition). Contact your local cable provider for availability information and service details.

NetCommand® Home Network Control System

Your Mitsubishi media center offers a new level of networking to combine selected older products

with new and future digital products. NetCommand supports IEEE 1394 connections, Audio Video Control system (AV/C), 5C copy protection and IR control of selected older products such as VCRs, DVD players, cable boxes or satellite receivers. NetCommand includes the ability to learn remote control signals directly from the remote control of many devices, allowing you to customize the NetCommand system in a way that works best for your viewing.

PC Connectivity

The display has a PC video connector that supports VGA, SVGA, XGA, or SXGA signals. Please

see Chapter 6 for signal compatibility. A stereo audio input is also provided.

Memory Card Reader

The four card slots in the front of the media center provide easy access to your pictures and audio

files stored on memory cards. This includes JPEG pictures from many types of digital cameras, as well as MP3 or WMA audio files recorded from computers or other digital recording devices.

Chapter 1: Product Overview

Display Top Control Panel

Top View of Display

The buttons on the top control panel of the display are also found on the remote control and media center front panel. See Remote Control Overview in this chapter for information about how to use these buttons.

Display Power Indicator and IR Sensors

Power Indicator

The media center and display power on and off together when you press the POWER button on the remote control. The display POWER indicator is lit during normal operation of the TV. The indicator is in the lower left corner of the display, below the screen, as shown in the diagram below.

IR Sensors

The display has two IR sensors, one for ordinary TV operation and one for “Learning.”

• Under normal conditions, point the remote at the display and the IR signal will reach both sensors.

• If using the remote close to the TV, point the remote control at the sensor you wish to activate. For ordinary TV operation, point the remote at the operating sensor.

TV, aim the remote

0QFSBUJOH*3

4FOTPS

i-FBSOJOHw *34FOTPS

When close to the

at the sensor you

wish to activate.

During typical use, the signal from the remote reaches both sensors.

0QFSBUJOH*3

4FOTPS

i-FBSOJOHw *34FOTPS

Chapter 1: Product Overview

Media Center Front Control Panel

Except for SYSTEM RESET and the memory card reader Eject buttons, the buttons on the media center Front Control Panel are also found on the remote control and display top control panel. The top row of labels show the control functions when no TV menus are displayed on the screen. The bottom row of labels show the control functions when the TV menus are displayed on the screen or when a special function has been activated. See Remote Control Overview in this chapter for information about how to use these buttons.

Power Indicator Light

The Power Indicator Light is located to the right of the Power button. Each time the media center is plugged into

a wall electrical outlet, or when power is restored after a power failure, or after pressing the SYSTEM RESET button, a blue light will flash rapidly for about one minute. Do not attempt to turn on the media center during this period. Wait for the flashing to stop. While the media center is powered on, the blue light illuminates steadily.

System Reset

If the media center will not respond to the remote control, the media center front-panel controls, or the display toppanel controls (and/or will not power Off), press the SYSTEM RESET button by inserting a pointed item (like the end of a paperclip) into the SYSTEM RESET opening. The media center will turn Off and the front panel Power Indicator Light will flash quickly for about one minute. When the light stops flashing, you may again turn on the media center.

The changes you made the last time the media center was on before you used the SYSTEM RESET button may be lost,

however, the changes that were previously saved are not lost.

A/V Reset

There may be times when you wish to reset the A/V (Audio and Video) settings back to the factory defaults. To return

all of the settings at once, press GUIDE and FORMAT on the front panel at the same time. To reset the defaults for individual devices, use the A/V Memory Reset selection on the Audio/Video menu.

Memory Card Reader

The four memory card slots are located on the front of the media center allow you to view JPEG pictures and listen to

MP3 or WMA audio files recorded from computers or other digital recording devices.

NOTE: The memory card slots are designed for the specific types of cards listed below. Do NOT insert other cards or objects, as this may damage the card reader. See Memory Card Playback on page 61 for more information.

Slo t Ca r d Types Slo t Ca r d Types

CARD 1 SmartMedia™ CARD 2

CARD 3

CompactFlash®, Types I and II

Microdrive™ Memory Stick™

CARD 4

MultiMediaCard™

Secure Digital (SD)

Memory Stick PRO™

Chapter 1: Product Overview

Remote Control Overview

Figure 1, following page

To send signals to the TV, point the remote control at the display.

1. Slide Switch: Selects the A/V product to

controlled by the remote control. For NetCommand® device control, select CABLE/DBS/DTV.

2. Numbers: Individually select channels or enter information into menus.

3. SQV (SuperQuickView™): Scans through

memorized lists of favorite channels.

4. CHANNEL/PAGE: Scans up or down through memorized channels. Pages up and down through screens when used with TV Guide On Screen®, ChannelView, a satellite receiver, or some cable boxes.

5. DEVICE: Displays the Device Selection menu in which you can select the device to view (ANT-1 and ANT-2, or devices connected to the TV’s inputs, including IEEE 1394 devices).

6. ADJUST: Press to navigate menus, change settings, and move the PIP on-screen location. Operates many NetCommand functions. Navigate TV Guide On Screen® and change settings.

7. TV MENU: Displays the on-screen menu system.

8. ENTER: Selects a channel number or menu item.

9. DEVICE MENU: Displays the menu for devices

connected to the TV, including CableCARD™. For VCR or DVDs, the first press displays the transport menu, the second press displays the VCR or DVD menu. Displays and removes options menus for TV Guide On Screen.

10. INFO: Press to display an on-screen summary of the current device used and any broadcast information available (including current V-Chip information). See Appendix B for details.

While in the TV Guide On Screen, press repeatedly to cycle through the available info box sizes.

11. V-CHIP: Turns the V-Chip Lock on or off.

12. PIP/POP: Turns on PIP and cycles through PIP and

POP display choices.

13. PIP CH: Scrolls up or down through memorized channels for PIP

14. PIP DEVICE: Displays PIP Selection menu to select the PIP or POP image source device

15. REC (Record): Displays the Record menu for setting up recordings, such as recordings for a

DVCR or IEEE 1394 devices, or while in ChannelView. Records with a VCR. Starts a recording when the Listings screen for TV Guide On Screen is displayed.

16. REW/REV: Rewinds a VCR. Reverses scan with a DVD, A/V Disc, or memory card file.

17. POW E R : Turns power on and off for the TV and other A/V products.

18. QV (QuickView™): Switches between the current channel and last channel viewed.

19. SUB/CANCEL: Clears SQV and some menu entries, and cancels recordings. For digital channels, adds separator between main and sub-channel numbers.

20. VOLUME: Changes sound level.

21. MUTE: Turns sound on or off.

22. GUIDE: Displays or removes TV Guide On Screen

or ChannelView for ANT-1 and 2. Displays Track List for A/V Disc. Displays program guide for satellite receiver, or DVD Disc menu. Displays thumbnails or playlists for memory card files.

23. Light: Located on the right side of the remote control, this button illuminates buttons or labels when pressed.

24. HOME: Exits TV on-screen menus and the TV Guide On Screen system and returns to TV viewing.

25. AUDIO: Selects and adjusts individual audio settings.

26. VIDEO: Selects and adjusts individual video settings.

27. EXCH: Exchanges PIP or POP and main TV picture.

28. SLEEP: Sets the TV to turn off within 2 hours. See

the next page for setup instructions.

29 CONNECT: Initiates IEEE 1394 peer-to-peer

connections.

30. FORMAT: Changes the shape and size of the main

TV picture. This feature is not availble when in PC

mode.

31. PAUSE: Pauses a live TV picture when no PIP or POP image is displayed. When PIP image is visible, pauses that image. Pauses a VCR, DVD, A/V Disc, or memory card file.

32. PLAY: Plays a VCR, DVD, A/V Disc, or memory card file.

33. FF/FWD: Fast forward a VCR or memory card file, or fast play a DVD.

34. STOP: Stops play of a VCR, DVD, A/V Disc, or memory card file.

Chapter 1: Product Overview

2. Load the batteries, making sure the (-) and (+) polarities are correct. For best results, insert the negative (-) side first.

1"(&

29 30

""BMLBMJOF CBUUFSJFT

Figure 2. Operation: Installing the Batteries

Care

For Best Results from the Remote Control:

• Be within 20 feet of the equipment.

• Do not press two or more buttons at the same

time unless instructed.

• Do not allow unit to get wet or become heated.

• Avoid dropping on hard surfaces.

• Do not use harsh chemicals to clean. Use only

a soft cloth, lightly moistened with water.

• Do not mix new and old batteries.

• Do not heat, take apart or throw batteries into fire.

• Use only AA alkaline batteries.

Hint: If the remote is in the Cable/DBS/DTV layer

and will not operate the media center, press and hold

POWER and enter 1, 9, 7 to reset the remote control.

Sleep Timer

Figure 1. Remote Control Overview

Remote Control Operation

Battery Installation

Figure 2

Installing the Batteries:

1. Remove the remote control’s rear cover by gently pressing the ribbed tab in the direction of the arrow and sliding off the cover.

Setting the Sleep Timer:

1. Press SLEEP on the remote control.

2. Each press of SLEEP increases the time displayed by

30 minutes, until the maximum value of 120 minutes is reached.

3. After 5 seconds of inactivity, the message will disappear.

4. Press SLEEP to view the remaining time before the timer turns the TV off.

Canceling the Sleep Timer:

1. Press SLEEP to display the on-screen message.

2. Press SLEEP repeatedly until OFF is displayed.

Note: After 5 seconds of inactivity, the message box

disappears.

Chapter 1: Product Overview

Display Rear Panel







To provide complete HDTV funtionality, the

display and media center must be connected using both MonitorLink™ terminals [A] and [B].

Remove the covers shown in the lower diagram to access the inputs described on this page.

A . MonitorLink™ RS-232C Control

Use the supplied RS-232C cable to connect the RS-232C terminal on the display [A] to the RS-232C terminal on the media center [A]. This input only supports the media center.

B. MonitorLink™ A/V Input

Use the supplied A/V cable to connect the MonitorLink A/V Input terminal on the display [B] to the MonitorLink A/V Output terminal on the media center [B]. This input only supports the media center.

1. PC Video Input

Use this RGB video terminal to connect to the Video Out terminal on a PC. This terminal supports VGA, SVGA, XGA. and SXGA resolutions. See Chapter 6 for more information.

2. PC Audio Input

Use this Stereo Mini jack to connect to the Audio Out terminal on a PC (the Headphone terminal can be used).

3. AC Power Input

Remove covers to access the signal and AC power inputs.

Media Center Rear Panel

Chapter 1: Product Overview

To provide complete HDTV funtionality, the

display and media center must be connected using both MonitorLink™ terminals [A] and [B].

A. MonitorLink™ RS-232C Control

Use the supplied RS-232C cable to connect the RS-232C terminal on the display [A] to the RS-232C terminal on the media center [A]. This output only supports the display.

B. MonitorLink™ A/V Output

Use the supplied A/V cable to connect the MonitorLink A/V Input terminal on the display [B] to the MonitorLink A/V Output terminal on the media center [B]. This output

only supports the display.

1. IR Emitters and NetCommand

Two terminals are provided for connecting IR emitters.

IR Emitters connected to these terminals are used by

the NetCommand system of the media center to control

external analog devices such as a VCR, DVD player,

cable box, satellite receiver and A/V receiver.

2 . Input-1, -2

Input 1 and 2 can be used for the connection of a VCR,

Super VHS (S-VHS) VCR, DVD player, standard satellite

receiver or other A/V device to the media center. Either

S-VIDEO or (Composite) VIDEO can be selected, but both

cannot be connected at the same time.

3. HDMI Input-1, -2

Use this input to connect to EIA/CEA-861 compliant

devices such as a high definition cable box, satellite

receiver or DVD player. This input supports 480i, 480p,

720p and 1080i video formats. It is not intended for use

with personal computers or devices outputting video signals with computer resolutions.

This input can also be used as a DVI connection with

separate analog audio inputs (see item 4). An optional HDMI-to-DVI adaptor or cable will be necessary to make this connection and may be available from your local electronics retailer. When using the optional HDMI-toDVI adapter, the DVI analog audio inputs on your media center allow you to receive left and right audio from your DVI device.

This input is HDCP (High-Bandwidth Digital Copy

Protection)

compliant.

4. DVI Audio Input

Use these analog stereo audio inputs when using the HDMI input with a device that outputs DVI instead of HDMI. A DVI-to-HDMI video adapter (purchased separately) is needed. Unlike HDMI, DVI does not carry audio information on the same cable.

5. Component-1, -2 Inputs YPbPr (480i/480p/720p/1080i)

These inputs can be used for the connection of devices

with component video outputs, such as a high definition cable box, satellite receiver, DVD player or compatible video game system. Please see Appendix D for signal compatibility.

Chapter 1: Product Overview

Media Center Rear Panel, continued

6. Antenna (ANT-1 MAIN, ANT-2 AUX)

ANT-1 MAIN and ANT-2 AUX can each receive both

digital and analog over-the-air channels from a VHF/UHF antenna or non-scrambled digital/analog cable channels.

Your primary viewing signal source should be connected

to ANT-1 MAIN. ANT-1 MAIN must be used to view premium subscription cable TV service authorized by the CableCARD™ access card. The CableCARD access card is provided by your local cable company.

ANT-2 AUX can continue to receive over-the-air or non-

scrambled cable signals.

7. Audio Line Out

These analog L/R audio output terminals provide an

additional other audio device.

NOTE: For the best audio quality, use the Digital Audio Out terminal if supported by your A/V receiver. For analog audio, it is generally preferable to connect directly to the A/V receiver from the cable box, statellite receiver, DVD player, etc.

8. CableCARD™ Slot

The CableCARD access card provided by your cable TV

service provider is inserted into this slot. The top of the card should face upwards.

NOTE: If you are using a CableCARD, be sure to connect the cable from the cable wall outlet to ANT-1 MAIN on the media center.

option for connecting to an A/V Receiver or

Some digital cable channels send MPEG-1 digital audio instead of Dolby Digital, however, not all A/V receivers can decode MPEG-1 digital audio. This can cause the A/V receivers to produce a loud noise that can damage speakers. For this reason, the media center will automatically turn off the digital audio output when tuned to a channel or device that has MPEG-1 digital audio and send it to the A/V receiver as analog left and right audio from Monitor Output.

10. Monitor Output

Use this Composite video and analog audio outputs under the following circumstances:

• Output to VCR for recording, or other A/V device.

• Output to an auxilliary monitor.

11. IEEE 1394

These terminals allow the media center to connect

to external IEEE 1394 digital products by means of a single cable. Two terminals are provided for this purpose, which allow for a high degree of flexibility for connecting your NetCommand controlled system. Detailed information regarding IEEE 1394 connection requirements are in Chapter 4.

12. AC Power Input

CableCARD is a nationwide standard system that allows your local cable TV provider to supply you with an access card customized to your account. This card allows the HDTV (display + media center) to receive, decode and unscramble the premium digital channels included in your cable TV subscription without the use of a cable box. See page 23 for additional CableCARD information and activation instructions.

If your cable company is not currently offering CableCARD access cards, you will need to use a cable box provided and authorized by your local cable company to view scrambled channels.

9. Digital Audio Output

This output will automatically send Dolby® Digital audio

from digital channels and IEEE 1394 devices to a digital

Audio/Video receiver. Connect this output to the A/V

receiver’s coaxial digital audio input. The output will automatically turn off when viewing an analog channel or device. Use Audio Line Out to send analog sound to your A/V receiver.

Chapter

Connecting

Essential MonitorLink™ Connections ......................... 18

AC Power Cords External Devices and NetCommand Wall Outlet Cable Cable Box Antenna with Twin Flat Leads Separate UHF and VHF Antennas Using a CableCARD Antenna or Wall Outlet Cable to a VCR Cable Box to VCR A/V Receiver or Stereo System Satellite Receiver or Other S-Video Devices DVD Player or Other Component Video Device HDMI Output Device DVI Output Device IR Emitters and NetCommand®

............................................ 21

........................................ 19

Overview

....................................... 21

.............................. 22

............................ 22

..................................... 23

........................ 24

....................................... 25

............................. 26

.................... 26

..................................... 28

...................................... 29

............................ 30

.................. 20

.................. 27

Compatible IEEE 1394 Device Connection Styles Helpful Hints

.......................................... 34

...................................... 33

.............................. 32

Chapter 2: Connecting

Essential MonitorLink™ Connections

MonitorLink™ RS-232C Control and Digital A/V

Figure 1. MonitorLink™ RS-232C Control cable (required and provided)

Figure 2. MonitorLink™ Digital A/V cable (required and provided)

The media center is designed specifically to work with the LT-3280 and LT-3780 displays. The MonitorLink™ RS-232C control connection allows the media center to turn the display and media center automatically on or off and control A/V devices connected connected devices to the display.

A. Connect the MonitorLink

the MonitorLink™ Control terminal on the display left rear panel (MonitorLink is also called MonLink or M-Link). Finger-tighten the retaining screws to ensure snug connections.

to the media center. The MonitorLink™ Digital A/V cable carries v

™

Control cable from the MonitorLink Control terminal on the media center rear panel to

-ONITOR,INK

To operate as a complete HDTV, the display must be connected to the media center using both required MonitorLink™ cables. See the instructions below.

ideo and audio signals from

23# #ONTROL

-ONITOR,INK

23# #ONTROL

-EDIA#ENTER

,EFT2EAR0ANEL OF$ISPLAY

Figure 1. Connecting MonitorLink™ RS-232C Control cable from Media Center to Display

B. Connect the supplied Digital A/V cable from the MonitorLink

MonitorLink™ A/V Input on the display left rear panel. You can secure in place the two cables just connected by routing them through the cable clip mounted next to the AC power input on the back of the display.

-ONITOR,INK

™

A/V Output on the media center rear panel to the

!6/UTPUT

-ONITOR,INK

!6)NPUT

-EDIA#ENTER

Figure 2. Connecting MonlitorLink™ Digital A/V cable from Media Center to Display.

,EFT2EAR0ANEL OF$ISPLAY

AC Power Cords

Figure 3. AC power cords for display and media center

Chapter 2: Connecting

After you have connected all A/V devices to the media center, connect the display to a nearby AC wall outlet,

then connect the media center to a AC wall outlet. The blue light next to the Power button on the front panel of the media center will start blinking. Wait for the blinking to stop (about 1 minute) before pressing the Power button on the remote control.

NOTE: power cord has been accidentally unplugged), the blue light on the front of the media center will start to blink.

• This is normal; the media center is re-initializing.

• Wait for the blue light to stop blinking (about 1 minute),

After a power outage (or after the media center

then press Power on the remote control.

IMPORTANT: Do not connect power cords to AC outlets until AFTER all connected. Instructions

A/V devices are

for connecting A/V devices are provided in this chapter.

%JTQMBZ

"$8BMM 0VUMFU

Figure 3. Connecting display and media center power cords to AC wall outlets. Wait until after you have connected all A/V devices to the medial center before plugging in the AC power cords.

.FEJB$FOUFS

"$8BMM 0VUMFU

Chapter 2: Connecting





External Devices and NetCommand

NetCommand is able to control many current audio and video devices by sending remote control signals from the media center to each device through IR emitters.

Additionally, it is also able to learn the remote control

signals used by most audio video devices not already in the media center’s memory. NetCommand can automatically switch to compatible Audio/Video (A/V) devices or those that have or “learned” NetCommand settings. It is important that the inputs on the media center and A/V receiver rear panels match the NetCommand setup that is displayed on screen.

%JTQMBZXJUI

JOUFSOBMTQFBLFST

.POJUPS-JOL5.34$ $POUSPMDBCMF

.POJUPS-JOL5.%JHJUBM "7DBCMF

7JEFP

"VEJP

Overview

To simplify the installation of NetCommand, step-by-

step on-screen NetCommand Setup procedures are provided in Chapter 3, which includes the types and brands of devices you are connecting to the media center. NetCommand Setup also assigns preset media center and A/V receiver inputs for each device. Typically, each device is connected to the media center input (video) and to the A/V receiver (audio) as shown in the figure below. Connections will vary depending on your



$BCMF#PYPS

4BUFMMJUF3FDFJWFS



%7%1MBZFS%73FUD

.FEJB$FOUFS

7JEFP

" V E

"7EFWJDF

" V E

requirements.

*3 &NJUUFS



'PSJOGPSNBUJPOBCPVU DPOOFDUJOHB1$TFF $IBQUFS

The following charts show which

preset inputs you should use on the media center and A/V receiver.

Chart 1 shows media center

inputs.

Chart 2 shows the inputs used

by A/V receiver models already known by NetCommand.

$IBSU

%FWJDF"VEJP0VUQVUUP"73FDFJWFS*OQVUTCZ/BNF

7$3 4BUFMMJUF3FDFJWFS "VY %7%1MBZFS 57.POJUPS0VUQVU

%JHJUBM"VEJP

.JUTVCJTIJ.JUTVCJTIJ#PTF%FOPO*OUFHSB,FOXPPE.BSBOU[1JPOFFS1JPOFFS3PUFM4POZ:BNBIB:BNBIB



.PEFM

.73

.73

7$3 7$3 7$3 7$3 7JEFP 7JEFP 7$3 7$35B

%7% %7%

57 57 57 57%#4 7JEFP 7JEFP 57 %7%57 57 7JEFP %7%-% %7%-% $#-4"5

.PEFM

.73

.73

$BCMF%#4 "69 $% 7JEFP 7JEFP %44 $% 4"5 7JEFP 57%#4 57%#4 %57-%

.PEFM

-JGFTUZMF¥

CVJMUJO%7% %7% 7JEFP %7% -%4"5 %7%-% 7JEFP 5"1&.% $% %7%

4QFBLFS

*3&NJUUFS$BCMF

Chart 1 Device Audio and Video Outputs to Media Center Inputs

Cable for CableCARD™ Service ANT-1

Antenna/Cable (digital/analog ) ANT-1 if primary viewing source,

Cable box ANT-2

VCR Input-1

Satellite Receiver (DBS ) Input-2

DVD Player Component-1

.PEFM

"73

.PEFM

%53

.PEFM

73

.PEFM

43

.PEFM

749%

F 7$3%73 7JEFP 7JEFP 7$3 7$3

"73FDFJWFS

ANT-2 if secondary viewing source

.PEFM

74959

.PEFM

349

.PEFM

453%&

.PEFM

379

4QFBLFS

.PEFM

397

After setting up NetCommand, you may go to the NetCommand menu at any time to change the inputs you used for

connecting each device, create custom names for devices, add devices not included in the presets above or delete devices no longer used. See Helpful Hints, at the end of this chapter for additional information on device setup.

Chapter 2: Connecting

Wall Outlet Cable

(can be used with a CableCARD™)

Figure 4

It is very important to connect the incoming cable for your primary viewing source to ANT-1, especially for

CableCARD™ use.

1. Connect the primary incoming coaxial lead cable to ANT-1 MAIN on the media center rear panel.

2. For an optional secondary antenna source, connect an antenna (or cable) to ANT-2 AUX.

3. If you have subscribed to a CableCARD™ service, the CableCARD can now be inserted into the CableCARD SLOT. The top of the card should face upwards. Additional CableCARD information is on page 23.

0QUJPOBM 4FDPOEBSZ "OUFOOB PS$BCMF

1SJNBSZ8BMM 0VUMFU

$BCMF

Figure 4. Wall Outlet Cable

.FEJB$FOUFS

$BCMF$"3%



4MPU

Cable Box

Figure 5

3 coaxial cables and one two-way RF splitter are required. These are not included with the media center.

It is very important to connect the incoming cable for your primary viewing source to ANT-1, especially for CableCARD™ use.

1. Connect the incoming cable to IN on an RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the media center rear panel.

3. Connect one coaxial cable from OUT on the RF splitter to IN on the cable box.

4. Connect one coaxial cable from OUT on the cable box to ANT-2 AUX on the media center rear panel.



.FEJB$FOUFS



065

$BCMF#PY

CBDLQBOFMTFDUJPO









065

4QMJUUFS

1VSDIBTFE4FQBSBUFMZ

5808":41-*55&3



*ODPNJOH

$BCMF

Figure 5. Connecting a Cable Box

IMPORTANT

Additional connection cables are not provided with the product. They are available at most electronic stores.

NOTE: Net Command® will assume that your Cable

Box is connected as shown here. Also, that Channel 3 is the default output channel for the cable box. If either the connections or output channel are different, use the Change option of Edit NetCommand to apply the changes.

Chapter 2: Connecting

Antenna with Twin Flat Leads

(not for use with CableCARD™)

Figure 6

For an antenna with twin flat leads:

A 300-ohm to 75-ohm transformer is required. This is not included with the media center, but is available at most electronics stores.

1. For antenna with twin flat leads, connect the 300-ohm twin leads to a 300-ohm to 75-Ohm transformer (purchased separately).

2. Push the 75-ohm side of the transformer onto ANT-1 MAIN on the media center rear panel.

OR For cable or an antenna with coaxial lead:

3. Connect the coaxial lead directly to ANT-1 MAIN on the media center rear panel.

.FEJB$FOUFS





PIN

$PBYJBM

$BCMF

PIN 5XJO'MBU

-FBET



.BUDIJOH5SBOTGPSNFS

1VSDIBTFE4FQBSBUFMZPINUPPIN

Figure 6. Connecting an Antenna with Twin Flat Leads

NOTE: Mitsubishi strongly recommends that you use an antenna with coaxial cable—NOT an antenna with twin flat leads. Twin flat lead antenna wires are subject to interference which may adversely affect the performance of the TV.

Separate UHF and VHF Antennas

Figure 7

A UHF/VHF combiner is required. This is not included with the media center.

1. Connect the UHF and VHF antenna leads to the UHF/VHF Combiner.

2. Insert the Combiner into ANT-1 MAIN on the media center rear panel.

7)'"OUFOOB

$IBOOFMT

.FEJB$FOUFS

6)'"OUFOOB

$IBOOFMT

$PNCJOFS

1VSDIBTFE4FQBSBUFMZ

PINUPPIN



&YUFSOBM "OUFOOB

'MBU5XJO

-FBE

6)'

7)'

PS$BCMF

'MBU5XJO

-FBE

Figure 7. Connecting separate UHF and VHF Antennas

4JEF

#BDL



Chapter 2: Connecting

Using a CableCARD™

To start the CableCARD initialization process, insert a CableCARD into the CableCARD slot located on the media center rear panel, then press Power on the remote control. An initial screen will automatically display for a few minutes, with information that your Cable Provider will need in order to start service. Please write down this information before calling your cable provider.

Please call XYZ Cable at xxx-xxx-xxxx to activate cable service.

They will need these numbers: Host ID X-XXX-XXX-XXX-XXX CableCARD

See owner's manual for further information

An example of an initial screen is shown here. Your screen will display specific information from your cable provider and may not look like this screen.

If you were unable to record the information, you can press TV MENU on the remote and then enter the number 999 and the screen will re-display. You can also press DEVICE MENU when the CableCARD is the selected source and you will be able to select the startup application.

ID: X-XXX-XXX-XXX-XXX

IMPORTANT

To use a CableCARD, the primary incoming cable must be connected to ANT-1 MAIN.

About CableCARD™ Technology

CableCARD is a nationwide system standard that allows your local cable TV provider to supply you with an access card customized to your account. This card allows your media center to receive, decode and unscramble the premium digital channels included in your cable TV subscription, without the use of a cable box. It also allows your cable provider to automatically update and change your subscription. When you move to a new cable provider’s area, you simply return the CableCARD to the original cable provider and get a new card from your new cable provider.

Please note that CableCARD is a new technology and your local cable provider may not currently be offering this service. As time passes, this system will become broadly supported by most cable providers.

The CableCARD system is “unidirectional” which means your cable provider can send updates to the access card and media center, however, the media center cannot send back signals such as requests for Video-On-Demand or Pay-per-View by remote control.

Digital cable channels authorized by the CableCARD will be available on the Firewire® IEEE 1394 network and can be shared by other products on the network. Some digital channels or programs may not be copied or recorded because of copy restriction limits set by the content owners or copyright holders.

The media center is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card (CableCARD) provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

Chapter 2: Connecting

Antenna or Wall Outlet Cable to a VCR

Figure 8

A two-way RF splitter, 3 coaxial cables, right and left audio cables and a S-Video or (Composite) Video cables are required. These

are not included with the media center.

1. Connect the incoming cable or Antenna to IN on the RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to ANTENNA IN on the VCR rear panel.

3. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the media center rear panel.

4. To use the display’s internal speakers with the VCR, connect a Left/Right set of audio cables from AUDIO OUT on the VCR rear panel to INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the media center rear panel. The red

cable connects to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono

(non-stereo), connect only the white (left) cable.

5. Connect either an S-Video or Video cable from VIDEO OUT on the VCR rear panel to INPUT-1 VIDEO on the media center rear panel. Only one type of video cable should be connected. S-Video is recommended, if available.

6. For NetCommand® controlled recordings, connect a set of audio cables from AUDIO IN on the VCR rear panel to MONITOR OUTPUT AUDIO-LEFT (MONO) and AUDIO-RIGHT on the media center rear panel. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel.

7. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the VCR rear panel to MONITOR OUTPUT on the media center rear panel.

Note: With this connection configuration, it is possible to view live cable programs through the VCR. For best picture quality, however, always view live cable programs directly from the cable box (connected to ANT-1) instead of the VCR.

*ODPNJOH $BCMF









"UUBDIPOMZPOFWJEFPDBCMFUZQF 47JEFPPS$PNQPTJUF7JEFP

065

.FEJB$FOUFS

4QMJUUFS





065

5808":41-*55&3



47JEFPSFDPNNFOEFEJGBWBJMBCMF



)46

7$3CBDLQBOFM



*GZPVS7$3IBTBWJEFPDIBOOFM PS3'0/0''TXJUDITFUJUUP 0''



"6%*03

-.0/0

"6%*03-

7*%&0

47*%&0

7*%&0

47*%&0

"$5*7&"7/&5803,

*/



065



065

$0/7&35&3 #09$0/530-

5*.&33&4&5

7$3



Figure 8. Connecting a VCR to an Antenna or Wall Outlet Cable

Note: NetCommand® will assume your VCR is connected to inputs as shown on this page. If you use any other inputs for your VCR or add a second VCR, this change must match in the NetCommand system. See Edit NetCommand... in Chapter 3 for more information.

Chapter 2: Connecting

Cable Box to VCR

Figure 9

A two-way RF splitter, 4 coaxial cables, right and left audio cables and an S-Video or Video cable are required. These are not

included with the media center.

1. Connect the incoming cable to IN on the RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to IN on the cable box rear panel.

3. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the media center rear panel.

4. Connect one coaxial cable from OUT on the cable box to ANTENNA IN on the VCR rear panel.

5. Connect one coaxial cable from ANTENNA OUT on the VCR rear panel to ANT-2 AUX on the media center rear panel (optional).

6. To use the display’s internal speakers with the VCR, connect a set of audio cables from AUDIO OUT on the VCR rear panel to INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the media center rear panel. The red cable connects

to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono (non-stereo), connect only the white (left) cable.

7. Connect either an S-Video or Video cable from VIDEO OUT on the VCR rear panel to INPUT 1 VIDEO on the media center rear panel. Only one type of video cable should be connected. S-Video is recommended, if available.

8. For NetCommand® controlled recordings, connect a set of audio cables from AUDIO IN on the VCR rear panel to MONITOR OUTPUT AUDIO-LEFT (MONO) and AUDIO-RIGHT on the media center rear panel. The red cable

connects to the R (right) channel and the white cable connects to the L (left) channel.

9. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the VCR rear panel to MONITOR OUTPUT VIDEO on the media center rear panel.

$BCMF#PY









065

"UUBDIPOMZPOFWJEFPDBCMFUZQF 47JEFPPS$PNQPTJUF7JEFP

CBDLQBOFMTFDUJPO

*ODPNJOH $BCMF

4QMJUUFS

1VSDIBTFE4FQBSBUFMZ



065

5808":41-*55&3



.FEJB$FOUFS



065



*GZPVS7$3IBTBWJEFPDIBOOFM PS3'0/0''TXJUDITFUJUUP

"6%*03

-.0/0

"6%*03-

0''



"$5*7&"7/&5803,

7*%&0

47*%&0

*/

065

7*%&0

47*%&0

5*7&"7/&5803



#09$0/530-

#09$0/53

5*.&33&4&5

*.&33&4&



065





065









7$3

47JEFPSFDPNNFOEFEJGBWBJMBCMF

Figure 9. Connecting a VCR to a Cable Box

Chapter 2: Connecting

"69

$% 5"1&

5"1&



7$3

%7%

%*(*5"-"6%*0



A/V Receiver or Stereo System

Figure 10 A digital audio cable and stereo audio cables are required. The digital audio cable is provided. The stereo audio cables are not

included with the media center. “Y” splitter cables may also be required.

1. Connect a set of stereo audio cables from AUDIO LINE OUT on the media center rear panel to the TV AUDIO INPUT on the back of the A/V receiver. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel.

To connect a digital A/V receiver with Dolby® Digital surround sound:

2. Connect one end of the digital audio cable supplied with the media center to DIGITAL AUDIO on the back of the media center. Connect the other end to the COAXIAL DIGITAL INPUT on the back of the A/V receiver.

Check A/V receiver’s Owner’s Guide for information concerning the use of the digital input and switching between

the digital sound and analog stereo sound from the display.

*/165

015*$"-

*/165

$0"9*"- $0"9*"-

*/165

$0"9*"-

%*(*5"-"6%*0

*/

065

065

.FEJB$FOUFS

8IJUF

"69 $% 5"1& 5"1& 7$3 7$3 57 %7%

7$3

3FE

S T

*/

"73FDFJWFS

3FBS1BOFM

6TFPOMZJGDPOOFDUJOHB %JHJUBM"73FDFJWFS

Figure 10. Connecting an A/V receiver

Satellite Receiver or Other S-Video Devices

Figure 11

An S-Video cable and audio cables are required. These are not included with the TV sytem.

1. Connect an S-Video cable from VIDEO OUT on the satellite receiver rear panel to INPUT-2 VIDEO on the media center rear panel.

2. Connect a set of audio cables from AUDIO OUT on the satellite receiver rear panel to INPUT-2 AUDIO, on the media center rear panel. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel. Refer to the Satellite Receiver Owner’s Guide for Dish Antenna connections.

3FE

8IJUF



8IJUF



3FE

"6%*0065





065

:$

065

7*%&0065

"6%*0*/



BOZ47JEFP%FWJDF

Figure 11. Connecting a Satellite Receiver with S-Video

.FEJB$FOUFS

Note: NetCommand® will assume you connected your Satellite Receiver to Input-2. If you add a second Satellite Receiver or use any other inputs for your Satellite Receiver, this change must match in the NetCommand system. See Editing NetCommand Setup in Chapter 3 for more information.

Chapter 2: Connecting

#*5453&".1$.

$)

$0"9*"-

015*$"-

"$*/

7*%&0

46#800'&3

$)463306/%

6#4

)

DVD Player or Other Component Video Device

Figure 12 Component video cables and audio cables are required. These are not included with the media center.

1. Connect the Component Video cables from Y/Pr/Pb VIDEO OUT on the back of the DVD player to COMP-2 on the

media center rear panel, matching the correct connection:

Y to Y (Green), Pr to Pr (Red), Pb to Pb (Blue)

2. Connect a set of audio cables from AUDIO OUT on the back of the DVD player to COMPONENT-1 AUDIO Input on the media center rear panel. The red cable connects to the R (right) channel, and the white cable connects to the L

(left) channel.

NOTE: For the best audio quality, if your A/V receiver supports digital audio, connect the DVD Coaxial or Optical digital

audio directly to the A/V receiver

.FEJB$FOUFS

(instead of using the L/R analog audio ports).

8IJUF

3FE





065

7*%&0065

7*%&0



8IJUF

3FE

065

"6%*00665

$)463306/% $)

46#800'&3 $0"9*"-

%7%1MBZFS

.*546#*4)*

#*5453&".1$.

015*$"-

"$*/

5P"73FDFJWFSVTJOH$PBYJBMPS0QUJDBM EJHJUBMBVEJPDPOOFDUPSTJGTVQQPSUFE

Figure 12. Connecting a DVD Player with Component Video

NOTE: NetCommand® will assume you connected your DVD player to Component-1. If you add a second DVD or use any other inputs for your DVD, this change must match in the NetCommand system. See Edit NetCommand in Chapter 3 for more information.

IMPORTANT

See Appendix D for component video signal compatibility information.

For digital audio connections, see your DVD Owner’s Guide.

Chapter 2: Connecting

HDMI Output Device

(Cable Box, Satellite Receiver, DVD Player, Etc.)

Figure 13

An HDMI to HDMI cable is required. This cable is not included with the media center.

Connect an HDMI cable from the HDMI input on the media center rear panel to the HDMI output on the source device output. HDMI devices provide video and audio through this cable.

($-)).

YYYYYYYYYY YYYYYYYYYY YYYYYYYYYY

)%.*065

$0.10/&/5 7*%&0065

47*$&0065

YYYYYYYYYYYYYYYYYYYYYYYYYYYYY YYYYYYYYYYYYYYYYYYYYYYYYYYYYY YYYYYYYYYYYYYYYYYYYYYYYYYYYYYYY

YYYYYYYYYYYYYYYYYYYYYYYYY YYYYYYYYYYYYYYYYYYYYYYYYYYYYY YYYYYYYYYYYYYYYYYYYYYYYYYYYYY

($-)/54

$6$0LAYERWITH

.FEJB$FOUFS

($-)/UTPUT

Figure 13. Connecting the media center’s HDMI Device Input

NOTE: The HDMI™ input terminals are compliant with the EIA-861 Standard and are not intened for use with personal computers.

Chapter 2: Connecting

!.4

DVI Output Device

Figure 14

A DVI-to-HDMI cable or DVI/HDMI adaptor and HDMI cable and audio cables are required. These are not included with the media center. They may be available at your local electronics retailer.

1. Connect the DVI-to-HDMI cable (recommended) (or DVI/HDMI adaptor with an HDMI cable) from the DVI device’s rear panel to the media center’s rear panel.

NOTE: If you are using a DVI/HDMI adaptor, it is important to connect the adaptor to the DVI side for best

performance.

2. Connect a set of audio cables from AUDIO OUT on the the DVI device rear panel to the DVI Analog Audio input on the media center rear panel. The red cable connects to the R (right) channel, and the white cable connects to the L (left) channel.

NOTE: The HDMI connection supports copy protection (HDCP). Some devices require connecting to an analog

input first, in order to view on-screen menus and select DVI as the ouput. Please review your equipment instructions for DVI connectivity and compatibility.

%7*UP)%.*$BCMF

)%.**/

.FEJB$FOUFS

"VEJP*/

3!4%,,)4%

!4%,,)4%

!.4

#!",%

!",

%7*065

2'"/54

$6)/54

%7*%FWJDF

"VEJP*/

,

!5$)/

46/54

6/54

2

-3"OBMPH"VEJP$BCMF

Figure 14. Connecting a DVI Device

NOTE: The HDMI™ input terminals are compliant with the EIA-861 Standard and are not intened for use with personal computers.

IMPORTANT

The HDMI/DVI connection does not support audio. For audio, you must connect left and right analog audio cables.

Chapter 2: Connecting



(

IR Emitters and NetCommand®

Figures 15 and 16

A quadruple IR Emitter cable is included with the TV

The four (4) IR emiters connected to the IR emitter cable (see Accessories in Chapter 1) are used by the NetCommand

system to control up to four other devices, such as a VCR, DVD player, Cable box, and a Satellite receiver.

1. Connect the plug end of the supplied quadruple IR Emitter Cable to one of the IR Output NetCommand terminals on the media center rear panel.

2. Run the cable for each of the emitter ends under, along side or over the top of each device to be controlled to the area of the front where the remote control sensor is located.

3. Place one of the emitters in front of the remote control sensor of the device to be controlled. The emitter bulb should face the remote control sensor on each device. This bulb emits infrared light in a cone shaped pattern. The bulb needs to be placed far enough from the remote control sensor to allow the cone pattern to include the sensor.

Note: See Figures 15 and 16 for examples of emitter placement.

The remote control sensor is usually behind the plastic window of the front display panel. It is sometimes visible when

you look through the display plastic using a flashlight and is normally a round or square cutout behind the plastic. If you cannot see the sensor and the device’s Owner’s Guide does not specify the location, you can find it by using the device’s remote control. Hold the remote about 1/2 inch from the front of the device. Starting from one end of the display window plastic, press the POWER button.

If the device does not respond, move the remote control 1 inch toward the center and try again. Repeat this until the device responds. Note this location then start over from the other end of the display window plastic, repeating until the device responds again. The remote control sensor will be somewhere between these two positions. This is usually enough accuracy for the placement of the IR emitters.

• With some devices, the emitter will work better facing downward from the top of the device. Some experimentation

may be needed.

• The emitter end being used can be secured in place using double stick tape.

• If you are not going to

be using all emitter ends, place the unused ends behind the devices so that they cannot send

signals to the remote control sensors.







"7EFWJDF

.FEJB$FOUFS

"7EFWJDF

(

% /

3 3 6

"73FDFJWFS



Figure 15. Connecting IR Emitter NetCommand

If a single emitter end can be placed in a position that will operate more than one device, do not use a separate emitter end for the additional device. A single device receiving remote control signals from too many emitters or remote controls may not respond at all.

IMPORTANT

IR Emitter Placement

Figure 16

*3FNJUUFSJOGSPOUPGTJOHMF BWFSBHFTJ[FE"7EFWJDF

Chapter 2: Connecting

*3TFOTPS

*3FNJUUFSPOUPQPG TJOHMFUBMMTJ[FEEFWJDF

*3TFOTPS

Figure 16. IR Emitter Placement Recommendations

*3TFOTPS

*3FNJUUFSJOGSPOUTIBSFECZ UXPBWFSBHFTJ[FE"7EFWJDFT

Chapter 2: Connecting

Compatible IEEE 1394 Device

It is possible to connect devices to the media center that

have IEEE 1394 connectors but are not compatible with

the media center or with the NetCommand® control

system. Areas of compatibility to consider are:

1. Digital Video Signals

The media center is able to decode MPEG2 video. Other types of digital video, such as DV video provided by

some camcorders, must be decoded by the source device and sent to the media center as analog video or SVideo. If the camcorder uses a compatible digital control

system, the IEEE 1394 cable can still provide control for the camcorder while the display is receiving the analog video or S-Video signals.

2. Digital Audio Signals

The media center is able to decode Dolby Digital signals

and MPEG audio signals. Other types of digital audio as

provided by some digital recording devices, such as MP3

audio and DTS audio, cannot be decoded by the media center when received over IEEE 1394.

The media center may not be able to pass incompatible digital audio signals on the coaxial digital audio output,

however these signals may pass on the IEEE 1394 cable to other devices.

3. Digital Control Signal

The media center is able to act as the control center for IEEE 1394 audio/video devices, such as VCRs, A/V Discs, tuners, cable boxes and amplifiers that are compatible with the following IEEE 1394 control standards.

• EIA-775 is designed for tuning devices such as cable boxes allowing the device to send simple graphics. However, this standard does not allow the media

center to control the cable box by IEEE 1394.

• Do not place an IEEE 1394 device between the media center and the display.

• Do not make a loop with the last device in the chain. When the device chain is looped, the media center may not be able to work with the other devices.

• Place devices that have only a mechanical (twoposition) power switch at the end of the chain or leave the power switch in the On position. When turned Off, IEEE 1394 signals may not be able to pass through the device to other devices.

• Place devices with the slowest communication speed at the end of the chain. Sometimes the communication speed will be marked near the IEEE 1394 connector with an “S” number. The higher the number, the faster the communication speed. This media center has a communication speed of S400. Devices with slow communication speed can interfere with IEEE 1394 signals from faster devices. When using NetCommand to set up a digital recording between a faster and slower device, the slower device should be the source and the faster device should be the recorder.

• Do not use an IEEE 1394 cable longer than 15 feet between each device.

• The media center is an IEEE 1394a Device. IEEE

1394b is currently under development. This

system will provide for longer distances and multiroom applications. Included in the IEEE 1394b systems are IEEE 1394a to IEEE 1394b converters to maintain compatibility with this media center and other IEEE 1394a devices.

• AV/C (Audio Video Control) is designed to provide basic controls such as play, stop, channel selection and volume, as appropriate for the device.

Some devices may be a combination of two or more types of devices. For example, there may be a recording device that is also a tuning device. Each portion of the device is called a sub-unit. When you select a device on the Device Selection menu that has sub-units, a pop-

up menu will appear so you can select which sub-unit section you wish to use.

6 pin connector

(

Connection Styles

Chapter 2: Connecting

There are two different connection styles that can be used when connecting IEEE 1394 devices. Use the style that fits your network of audio/video products.

Direct Device-To-Device Style

The IEEE 1394 offers you the capability to chain devices,

unlike previous audio and video connections where you had to individually connect each device directly to the media center. For example, you can connect a D-VHS to a 1394 DVD Player and then to the media center. The resulting IEEE 1394 chain will allow you to add more devices to the chain. You will be able to see each video device on the media center’s Device Selection Menu and send information from any IEEE 1394 device to other compatible devices.



.POJUPS-JOL5.$POUSPM34$ BOE%JHJUBM"7DBCMFTDPOOFDUJOH .FEJB$FOUFSUP%JTQMBZ

.FEJB$FOUFS

%JTQMBZ

%JHJUBM 7$3

%JHJUBM %7%

Hub Connection Style

The IEEE 1394 also offers you the capability to connect

your devices using the media center as a hub within the audio/video network. Each device can send information, which may include audio and video, to any other device in the network.

(

0UIFS %FWJDF

%JHJUBM 7$3

%JHJUBM %7%

%JHJUBM 7$3



.POJUPS-JOL5.$POUSPM34$ BOE%JHJUBM"7DBCMFTDPOOFDUJOH .FEJB$FOUFSUP%JTQMBZ

.FEJB$FOUFS

%JTQMBZ

%JHJUBM%7%

4-Pin Style vs. 6-Pin Style Connectors

There are two different types of connectors used for IEEE 1394 terminals and cables, a 4-pin and a 6-pin style.

The 4-pin connector sends digital audio signals, digital

video signals and digital control signals back and forth between devices. Your media center has two (2) 4-pin type connection terminals

4 pin connector

The purpose of this low voltage electrical power is to

provide the needed operating power to a device that is not connected directly to the household AC power such as a camcorder. A device with a 6-pin connector can send this electrical power to another device, or receive electrical power from another device, or simply use a 6pin connector without using the two additional pins.

A 6-pin connector cannot be connected directly to a 4-pin terminal, and vice versa. To connect a 6-pin device

QJOUPQJOBEBQUPS

device) you will need to connect the camcorder directly to the household AC, or use the camcorder’s battery for power. If this is not possible, then the camcorder will need to be connected directly to another 6-pin device in the network that can provide the electrical power.

available on the rear panel.

The 6-pin connector is capable

of sending the same digital audio, video and control signals as the

4-pin connector, but the 6-pin

connector is also able to send low voltage electrical power. This media center does not have 6 pin connectors.

to a 4-pin device, you will need to obtain a 6-pin to 4-pin adaptor or adaptor cable. These cables are available from electronic and computer stores.

When connecting a 6-pin device (such as a camcorder) to the media center, (if it is designed to receive electrical power from another 6-pin

%JHJUBM7$3

0UIFS%FWJDF

Chapter 2: Connecting

Helpful Hints

Q My VCR (or other device) does not have two sets of stereo audio outputs. How can I connect this device’s audio to both the media center and the A/V Receiver?

A. There are two solutions:

1. Connect the single set of stereo audio outputs to the media center only. Use Edit NetCommand® to change the setup of this device. In the Connection screen of “Change” make sure both audio and video for the media center input are check marked and neither the audio or the video for the AVR input are check marked. This will allow the NetCommand system to use the media center outputs to transfer the device’s audio to the A/V Receiver. See Edit NetCommand in the next chapter for details.

2. Use RCA type “Y” splitter cables to split the device’s audio output to be connected to both the TV and the A/V Receiver.

Q. I have both the media center/Audio Line Out stereo audio output and media center digital audio output connected to the same input designation on my A/V Receiver. How do I switch between analog audio and digital audio?

A. This depends on the individual A/V Receiver. Some A/V Receivers will switch automatically to digital when a

digital audio signal is supplied. Other A/V Receivers can be manually switched by remote control. For these types of A/V Receivers, see Edit NetCommand in the next chapter for NetCommand control of these features. Some A/V Receivers will require that you make this change on the front panel of the A/V Receiver.

Q. The front panel of my A/V Receiver is too tall or too convex for the IR emitter signal to reach the remote control sensor of the A/V Receiver. What can I do?

A. There are several possible solutions.

1. Mount the IR Emitter on the top, front edge of the A/V Receiver over the remote control sensor. Use tape to secure it in place.

2. Mount the IR Emitter on the underside of the shelf above the A/V Receiver (if the A/V Receiver is in a cabinet). Use double sided tape to secure it in place.

3. Some small stick-on emitters from other manufacturers may be compatible with this media center’s IR Emitter terminals. These may be used instead of the supplied IR Emitters.

Q. I occasionally need to see the menu from my A/V Receiver. How can I connect it to the HDTV receiver for this purpose?

A. You can connect the video output of the A/V Receiver to an unused input on the media center. Then use Edit

NetCommand to “Add” this as an “Other” device, not a A/V Receiver. On the “Connection” screen, indicate which media center input was used and check mark the video box. Make sure the media center input audio box and both the audio and video boxes for the AVR input are not check marked. You should also name this device so you can easily identify it on the Device Selection Menu. You can also use Input 3 (Camcorder) on the front panel.

Q. I have a separate high definition receiver I would like to connect and it also has an S-video output and would like to be able use it as well. Is there any way to connect this receiver both ways?

A. Yes, this item will appear twice in the Device Selection Menu. Just add this unit once using the Input-DTV

receiver and once using one of the S-video inputs. Make sure you learn the remote control twice, on for each input. We suggest that you connect stereo audio outputs with the S-video to the media center so that you do not need to use two inputs on the A/V Receiver. If this is a NetCommand compatible media center that HD or SD outputs can be switched by remote control, see Edit NetCommand in the next chapter for NetCommand control of this feature.

Chapter

NetCommand

NetCommand® Introduction ............................... 36

NetCommand

Initial Setup ............................... 37

Setup and Editing

Edit NetCommand®

Add an A/V Receiver

Add Devices

Change Devices

Delete Devices

Finish Screen

Setup Reminder Screen Using the Remote Control with NetCommand® NetCommand 3D Graphical

......................................... 42

........................................ 46

On-Screen Buttons .......................... 48

..................................... 39

................................... 39

...................................... 45

....................................... 46

.................................. 46

Menu System .......................... 49

.................. 47

Chapter 3: NetCommand® Setup and Editing

NetCommand® Introduction

NetCommand makes your TV the heart of your Home Theater

NetCommand® is an intelligent control system that makes your Mitsubishi TV the heart of your home theater. With NetCommand, the TV sends signals to the other devices in the system via the IR emitters, telling the devices to play, record, change inputs, adjust volume, change channels and many more functions. All of this is accomplished with one remote control and without changing control layers.

IR Learning and IEEE 1394 Support

The IR “ Learning” feature of NetCommand allows the TV to learn the remote control signals for new devices that the TV is not preprogrammed to operate. NetCommand® also includes the capability of controlling IEEE 1394 devices by sending control signals on a FireWire® cable.

Using NetCommand is completely optional

When you first turn on the TV, the NetCommand Setup Wizard launches. If you decide to use NetCommand, follow the on-screen instructions. If you choose not to use it right away, simply quit the Setup Wizard and NetCommand will remain inactive. Later, if you decide to use NetCommand, you can easily access the Setup Wizard.

NetCommand and Levels of Control

When you set up NetCommand, you decide how much control you want the TV to have over your home theater system. You have the choice of performing a basic, limited, or complete NetCommand setup.

• Basic Setup

In a basic setup, NetCommand will: ◊ automatically switch to the correct TV input when you want to view programming from a different device. All

you do is select the device from the on-screen device selection menu. This saves you from having to search for the correct input every time you want to change devices. Unused inputs are automatically deactivated so that you don’t see them in the menu.

◊ show an on-screen icon for each device connected to the TV so you always know what devices are available.

Note that with a basic setup, you still need to use the remote control specific to each device.

• Limited Setup

In a limited setup, you get the benefits of the basic setup plus NetCommand control over the specific devices you have chosen. Use this type of setup if you:

◊ only want NetCommand to control a few devices, such as the TV, a playback device (like a DVD player), and a

cable box. With this setup, you can use the TV’s remote to control these devices.

◊ want to use TV Guide On Screen® to control your cable box and VCR and/or A/V disc. After performing this

setup, you can use the TV’s remote to control these devices.

◊ want the ease and flexibility of NetCommand-controlled recording, with seamless setup of time-delayed or

immediate recordings among networked devices.

• Full Setup

Perform a full setup if you want NetCommand to: ◊ control a surround sound A/V receiver. ◊ automatically change input selections for the A/V receiver. ◊ control all devices with the TV’s remote, including the A/V receiver. ◊ provide seamless setup of time-delayed or immediate recordings among networked device.

NetCommand Helps Manage Your Home Theater

With the NetCommand Review screen you can:

• view a summary of all devices connected to the TV and the input used for each device.

• deactivate or turn off unused input connections, then reactivate or turn them on when needed.

If you need to change your setup, the NetCommand sub-menu lets you easily

• add new devices.

• delete devices you have disconnected.

• change device and input selections.

Chapter 3: NetCommand® Setup and Editing

IMPORTANT

To take advantage of the versatility of your new HDTV, Mitsubishi recommends that you set up

NetCommand® as soon as you finish connecting your A/V devices and power on the LCD Flat Panel TV for the first time. Although setting up NetCommand is optional, TV Guide On Screen® can not control connected cable boxes or record TV programs unless NetCommand is set up. You also have the option of setting up NetCommand at a later time.

NetCommand® Initial Setup

Setting up NetCommand gives you centralized control of all A/V devices connected to the media center and allows you to record TV shows using TV Guide On Screen®. After you place IR emitters in front of connected A/V devices, you will only need one remote control because NetCommand can learn the IR codes used by the

remotes controls of A/V devices.

Welcome Screen

Figure 1

When you first turn on your TV, the Welcome screen displays and asks you to select either English or Spanish

as the language for the on-screen menus. The default language is English. To change Language later, select

Setup from the Main Menu.

Figure 1. Welcome screen

IMPORTANT: If the NetCommand Welcome screen does

not appear the first time you turn on the HDTV system, check to make sure the media center and the display are connected using both MonitorLink™ cables (Control & A/V).

NetCommand (Information) Screen

Figure 2

After the Welcome screen, the NetCommand

(Information) screen displays automatically the first time

you power On your TV. This screen describes how to

start or delay the initial NetCommand Setup.

o set up NetCommand: select Next> and press

If you cancel NetCommand Setup before it is

completed, you can restart the NetCommand setup by

doing the following:

1. Press TV MENU on the remote control to display the TV Main menu.

ENTER.

2. Select NetCommand. The available options will be: Add, Review and Initial. Change and Delete will be grayed out.

3. Press ADJUST , , or to select Initial.

4. Press ENTER. The Device Setup screen displays.

Figure 2. Information screen

Device Setup Screen

Figure 3, next page

If the devices connected to the media center are already in NetCommand memory, you can quickly select them at this screen. Press ADJUST or to move to each device type. Press ADJUST or to select the manufacturer. Select “Other” if the manufacturer is not listed. Later, you can use the Change setting in the Edit NetCommand menu to learn the remote control signals for this device. Select “None” for device types that are not connected.

For the A/V Receiver, if the manufacturer is not listed, you cannot select “Other”. Instead, select “None”. Later, you can use the “Add” feature in the NetCommand menu to have the media center add and learn the remote control signals for this device. After completing your choices, select Next> and press ENTER.

Chapter 3: NetCommand® Setup and Editing

NetCommand® Initial Setup, continued

Figure 3. Device Setup screen

Note: If you selected “Other” for any of the device names, the media center can “Learn” the connected device by following the Edit NetCommand instructions. For many device types, non-listed models will operate in the same way as the listed models and you can still use the pre-loaded setting.

TV Guide On Screen® System Setup

Figure 4

The TV Guide On Screen option allows you to select

whether you want to enable the Guide and which devices you want to include in the listing. In order to get the correct listings for your area, you will need to enter your 5-digit ZIP code.

Depending on your setup, you can select either or both antenna inputs, or antenna inputs and a cable box, or Cable CARD™ on Antenna 1 and an over-the-air antenna on Antenna 2. If you have multiple cable connections such as direct cable without a box on one antenna and a cable box on the other antenna or an input, these will share the same channel number assignment and as a result may not match correctly for both connections.

For detailed information on using the TV Guide On Screen system, please see the TV Guide On Screen® Interactive Program Guide User’s Manual.

Note: Inputs to TV Guide On Screen can include only one over-the-air source and one cable souce.

If you connect an HDTV cable box to the TV using Component 1 or 2, HDMI Input 1 or 2, or IEEE 1394, and plan to use TV Guide On Screen to control this cable box, also connect an over-the-air antenna in order to download TV Guide On Screen data.

Review Screen

Figure 5

After you have made your device choices the Review Screen

will display. It is important to review the settings to ensure that they are correct. If necessary, you can use <Back to return to the Device Setup screen to make changes.

Figure 5. Review screen

Note: The Review screen lists the media center input and A/V receiver input used with each device. You must correctly identify the inputs you used when you connected the devices. If you have not connected your devices, write down these inputs as a guide. If you cannot use these inputs, or if you would like to change the name of a device, use the instructions in Edit NetCommand to make necessary changes.

Note: If you select Next> on the Review screen, all selections made are finalized.

On the Review screen, adding or deleting check marks will turn the adjacent devices, memory cards or inputs On or Off. 1394 device names only appear on the Review screen when the devices are connected to the media center.

Figure 4. TV Guide On Screen

Finish Screen

Figure 6, next page

To complete the NetCommand setup, select Finish from the Finish screen.

If you wish to change any of the pre-configured inputs or names for the devices, or add devices not in the pre-configured setup, select Edit to display Edit NetCommand menu.

If your A/V receiver (AVR) was not listed, select Edit to add the AVR and then assign all devices to new AVR inputs.

Figure 6. Finish screen

It is still necessary to memorize the available channels for Antenna-1 (and Antenna-2, if used). You may do that by going to the TV Main menu and selecting Antenna. Instructions to memorize channels are found in the Antenna menu section.

Edit NetCommand®: Add an A/V Receiver

A/V Receiver Screen

Figure 7

If your A/V Receiver manufacturer was not listed, and you selected “None” during the initial NetCommand setup, you may add the A/V Receiver and have NetCommand learn its remote control’s functions.

• If you are in the Finish screen for initial setup, select Edit.

• If you have already finished initial setup, change the audio source to TV Audio. Press the DEVICE key to verify the current audio source. To change, press the AUDIO key to acess the audio section and change the source. Next open the Main menu, select NetCommand, then press ENTER. The Edit NetCommand screen will display.

Chapter 3: NetCommand® Setup and Editing

until you see A/V Receiver as the device type. Highlight Next and press ENTER to open the A/V Receiver screen.

IMPORTANT

To make changes to the A/V receiver setup, first ensure that the current audio source is TV Audio.

Choose ONE of these options:

• Select a recognized manufacturer. The model number optimized for NetCommand will display at the bottom of the screen. If a number follows the manufacturer’s name, (example: Mitsubishi 1), this indicates additional models are optimized for that manufacturer. For many device types, non-listed models will operate in the same way as the listed models and you can still use the pre-loaded setting.

After selecting Next>, the screens that follow are: the Name Screen (Figure 11), Audio Line Out to AVR screen (Figure 12), ending with the Finish screen (Figure 13).

• Select “Other”, then highlight “Learn” and press ENTER. This will allow you to have NetCommand learn the remote control signals of this new device.

After selecting “Learn” and pressing ENTER, the screens that follow are: the A/V Receiver Input screen (Figure 8), A/V Receiver Input Learn screen (Figure 9), A/V Receiver Learn screen (Figure 10), Name screen (Figure 11), Audio Line Out to AVR screen (Figure 12), ending with the Finish screen (Figure 13).

• Select “Other”, skip Learn and select Next>. This will allow the device to appear and will allow NetCommand to switch inputs to use this device. However, NetCommand will not be able to control this device. Later you may use the “Change” option in the NetCommand menu to learn the remote control signals.

After selecting Next>, the screens that follow are: the A/V Receiver Input screen (Figure 8), Name screen (Figure 10), Audio Line Out to AVR screen (Figure 12), ending with the Finish screen (Figure 13).

Figure 7. A/V Receiver screen

Highlight Add and press ENTER. When the New Device screen displays (see figure 15), press ADJUST or

A/V Receiver Inputs

Figure 8

If you select “Other” as the manufacturer, you will see the A/V Receiver Input screen after selecting “Learn” and pressing ENTER. After selecting the number of inputs, this screen will not appear again.

Depending on your A/V Receiver’s capability, you may connect up to seven (7) A/V inputs. Select the number of inputs by pressing ADJUST or .

Chapter 3: NetCommand® Setup and Editing

If the number of connected inputs changes, you will need to delete the A/V receiver through Edit NetCommand and add it again, as described above.

Figure 8. A/V Receiver Input screen

A/V Receiver Input Learn Screen

Figure 9

Figure 9. A/V receiver Input Learn screen

NetCommand can now learn the remote control signals used to select each input on the A/V receiver.

and ENTER to select each letter of the name. These names will appear on the Review screen as the A/V receiver’s input names.

6. To erase the learned input signal, highlight the check box for

that input and press CANCEL.

7. Repeat for each connected input.

8. When the input selection signals have been learned and the

inputs named, press ADJUST to select Next> and move to the A/V receiver Learn screen.

A/V Receiver Learn Screen

Figure 10

1. Press ADJUST or on the TV remote to select the check box for each function to be learned.

2. Press ENTER and the function name will begin to flash to confirm the ready-to-learn status.

3. Press the button on the A/V receiver’s remote control that corresponds to the selected function, A check mark will appear and the function name will stop flashing. This confirms the signal learned status.

4. To test the learned command, press ENTER on the TV remote control. The A/V receiver will perform the selected function. The A/V receiver needs to be turned on and the IR emitters properly placed for the test to be successful (see page 30 for IR emitter placement).

5. Repeat for each function to be learned.

6. To erase a learned function, highlight the check box for that function and press CANCEL.

7. When the function signals have been learned, press ADJUST to select Next> and move to the Name screen.

1. Press ADJUST or on the TV remote control to select the check box for each function to be learned.

2. Press ENTER and the function name will begin to flash to confirm the ready-to-learn status.

3. Point the A/V receiver’s remote control at the display. If close to the screen, see page 10 for the location of the Learning IR sensor. Press the button on the remote control that corresponds to the selected function. A check mark will appear and the function name will stop flashing. This confirms the signal learned status.

4. To test the learned command, while the function is selected, press ENTER on the TV remote control. The A/V receiver will perform the selected function. The A/V receiver needs to be turned on and the IR emitters properly placed for the test to be successful (see page 30 for IR emitter placement).

5. To customize the input names, press ADJUST to move to the Input Name text box and then press ADJUST or

Figure 10. A/V receiver Learn screen

Hint: If your A/V receiver remote control uses a single

button for both Power On and Power Off, don’t learn the Power Off function. If your A/V receiver uses a single button to toggle between digital and analog sound, then learn only Analog to Digital. If your A/V receiver automatically switches between analog and digital audio, then you don’t need to learn either Analog to Digital or Digital to Analog functions

Chapter 3: NetCommand® Setup and Editing

Add an A/V Receiver, continued

Name Screen

Figure 11

The Name screen allows you to change the default name

for the A/V receiver to a custom name of up to eight characters (including a blank space), selecting from

letters, numbers, and nine different characters. Using the media center’s remote, press ADJUST or to select each letter, then press ENTER to move to the next position. Press CANCEL to delete the current letter and move back one character position. When in the first position, the CANCEL button will return the name to the default name.

Finish Screen

Figure 13

To finalize your selections and complete the A/V

receiver setup, select Finish from the Finish screen.

Note: If you connected the audio output of any device directly to the A/V Receiver, you must use the “Change” function of the Edit NetCommand menu and select the device to assign the correct A/V Receiver input to be used with each device.

Figure 13. Finish screen

Figure 11. Name screen

Audio Line Out to AVR Screen

Figure 12

If you connected the media center Audio Line Out to an

A/V Receiver (AVR), use this screen to select the name of

the analog input you’re using on the A/V receiver.

If the A/V receiver also has a digital audio input, then

connect the media center Digital Audio Output to the A/V

receiver digital audio input.

Note that the media center MONITOR OUTPUT

AUDIO connection is only for VCR recording and is

not synchronized with the video display. Do not use

MONITOR OUTPUT AUDIO as input to an A/V receiver.

Figure 12. Audio Line Out to AVR screen

Chapter 3: NetCommand® Setup and Editing

Edit NetCommand® : Add Devices

Note: Mitsubishi’s NetCommand allows you to edit your

home theater configuration. You can add new devices, change device settings and connections, delete devices and learn remote control IR signals not already in NetCommand memory.

Edit NetCommand Screen

Figure 14

If you selected Edit when you were at the Finish screen, the Edit NetCommand screen displays. The choices are:

Figure 14. NetCommand Menu, Edit NetCommand Option

Add

Add a new device to the NetCommand setup. See Figure

15 and “New Device Screen” for more information.

Change

Change the brand/model or input connections of a device already listed in the configuration. Learn the remote control signals of devices listed as “Other” brands. See Figure 24 for more information.

Guide

Edit TV Guide On Screen® zip code and input selections. See the separate TV Guide On Screen Interactive Program Guide System manual for more information about customizing the Guide.

Review

View a list of all devices and input connections in the NetCommand home theater configuration. This is also

where you can turn On or Off unused media center inputs or devices. See Figure 5 for more information.

that will display is the Device Setup Screen. See Figure 3 for more information.

Note: If you have completed the NetCommand setup, you can access the Edit menu at any time by pressing TV MENU, then selecting NetCommand.

See page 66 for details.

Use these settings to change the NetCommand setup to reflect a change in your home theater system. To learn the remote control IR signals of a device that is not already in the NetCommand memory, add this device as manufacturer of “Other.” The learning screens will then automatically be included in the series of screens used for adding the device.

New Device Screen

Figure 15

Select “Add” from the Edit NetCommand screen, and the New Device screen will display. Select the Device type that you would like to add. You may add your A/V receiver (if not added in Initial setup) Cable Box, Camcorder, DBS, DVD, Laser Disc, PC and VCR.

At the next screen, choose the manufacturer. If you choose “Other” for the manufacturer, the device (A/V

receiver, Cable, DBS, DVD or VCR) can be learned. For

device types Laser Disc, Camcorder, Game and PC, the

“Learn” screen is skipped. There is no NetCommand

support or learning for these devices.

At the next screen, you can keep the default Name or select a custom Name for the device, using ADJUST or to select letters A-Z, numbers 0-9, and/or symbols (!.&’/:*- and blank) for each character of the name you would like for the selected channel.

The next screen displays the Connection screen (RF

Connection for Cable, Figure 23). Select the media center and A/V receiver inputs that the device is connected to. Only audio can be connected to the A/V receiver. The A/V receiver may need configuring for digital audio.

Delete

Remove a device or erase the complete NetCommand home theater configuration. The learned remote control signals are erased when the associated device is deleted.

See Figure 25 for more information.

Initial

Start the setup at the beginning. This button only becomes available after deleting the entire configuration,

or if NetCommand was not set up when the media center was first powered On. If you select Initial, the first screen

Figure 15. New Device screen

Chapter 3: NetCommand® Setup and Editing

Add Devices, continued

[Device] Screen

Figure 16

If you selected “None” for a device type during initial

setup, you can later add a device with this screen. This screen also opens when you select the Change option in

the Edit NetCommand screen. The sample screens here show the choices for adding a

VCR; similar screens will appear for any satellite receiver,

DVD player, or cable box.

Figure 16. [Device] screen

Our examples show the choices for adding a VCR,

however, the same type of screens will appear for any

DBS (Satellite receiver), DVD player or Cable Box.

Choose ONE of these options:

• Select a recognized manufacturer. The model number

optimized for NetCommand will display at the bottom of the screen. If a number follows the manufacturer’s name, (example: Mitsubishi 1), this indicates additional models are optimized for that manufacturer. For many device types, non-listed models will operate in the same way as the listed models and you can still use the pre-loaded setting.

After selecting Next>, the screens that follow are: the

Name Screen (Figure 19), Connection for [Device] screen

(Figure 20) and specialized device screens (Figures

21–23), ending with the Finish screen (Figure 26).

• Select “Other,” then highlight “Learn” and press ENTER.

This will allow you to have NetCommand learn the

remote control signals of this new device.

After selecting “Learn” and pressing ENTER, the

screens that follow are: [Device] Learn screen (Figure

17), [Device] Advanced Learn screen (Figure 18), Name screen (Figure 19), Connection for [Device] screen

(Figure 20), and specialized device screens (Figures

21–23), ending with the Finish screen (Figure 26).

• Select “Other,” skip Learn and select Next>. This will allow the device to appear and will allow NetCommand to switch inputs to use this device. However, NetCommand will not be able to control this device. Later you may use the “Change” option in the Setup menu to learn the remote control signals.

[Device] Learn Screen

Figure 17. Shown only if “Learn” was selected

Figure 17. [Device] Learn screen

1. Press ADJUST , , or to select the check box for each function to be learned.

2. Press ENTER and the function name will begin to flash to confirm the ready-to-learn status.

3. Point the device’s remote control at the display and press the button that corresponds to the selected function. A check mark will appear and the function name will stop flashing. This confirms the signal learned status.

4. To test the learned command, press the ENTER button on the remote control while the learned function is still highlighted. The device should perform the selected function. The device needs to be turned on and the IR emitters properly placed for the test to be successful (see page 30 for IR emitter placement). If the functions are not learned the first time, try Learn again.

5. Repeat for each function to be learned.

6. To erase a learned function, highlight the check box for that function and press CANCEL.

7. When the function signals have been learned, press ADJUST to select Next> and move to the [Device] Advanced Learn screen.

Hint: If the device’s remote control uses a single button

for both Power On and Power Off, don’t learn the Power

Off function.

IMPORTANT

When learning the device’s remote control signals, point the device’s remote control at the display. for the location of the Learning IR sensor.

If close to the screen, see page 10

Chapter 3: NetCommand® Setup and Editing

Add Devices, continued

[Device] Advanced Learn Screen

Figure 18

After learning the basic device keys, the [Device] Advanced Learn screen allows you to learn any special keys for your device. Most common IR remote control signal formats can be learned by NetCommand.

A table of specialized device keys is shown in Appendix

J. You only need to learn the functions your devices

respond to and can ignore the functions that do not apply to your device.

Connection for [Device] Screen

Figure 20

This screen allows the media center to learn the

connection between device(s) and input(s). Inputs 1 & 2, HDMI Input 1 & 2, Component 1 & 2, and/or the inputs for the A/V Receiver all need to be checked, if connected. Add or remove check marks to indicate what type of connections (Audio, Video or both) are used with each media center and A/V Receiver input.

Figure 20. Connection for [Device] screen

Figure 18 [Device] Advanced Learn screen

Name Screen

Figure 19

The Name screen allows you to change the default

name for each device to a custom name of up to eight

characters (including a blank space), selecting from

letters, numbers and nine different characters. Press ADJUST or to select each letter, then press ENTER to move to the next position. Press CANCEL on the

remote to delete the current letter and move back one character position. When in the first position, the CANCEL button will return the name to the default name.

The Add Devices screens described below may not be necessary for your home theater setup. If they do not display automatically on screen, they are not required.

VCR for Recordings Screen

Figure 21

If more than one analog VCR is connected to the media center, you need to select the one to be used for recording. Make sure Line In video and audio ports of the recording VCR are connected to Monitor Out ports of the media center.

You may also select whether you want the recorded 16:9

signals from digital channels or IEEE-1394 devices to be cropped (sides are cut off) or Anamorphic (full screen). If Anamorphic is selected for viewing, choose the Standard format for the best quality playback.

Figure 19. Name screen

Figure 21. VCR for Recordings screen

Chapter 3: NetCommand® Setup and Editing

Add Devices, continued

IR Code for [Device] Screen

Figure 22

This screen only displays if an added device has the

same IR code as a previously added device of the same type and manufacturer. You can specify the IR setting for the new device. For example, for the second Mitsubishi VCR you can specify the IR Code setting to VCR-B, if the

primary Mitsubishi VCR is using the VCR-A IR code.

Figure 22. IR Code for [Device] screen

Edit NetCommand®: Change Devices

Change Device Screen

Figure 24

Selecting Change from the Setup menu screen, displays the Change screen. To change a device, select the device by name, not type. You can change the name or input connections to the media center and A/V receiver. If “Other” is selected for the manufacturer then you can also “Learn.” The rest of the screens that follow are the same as when you Add a device.

Figure 24. Change screen

RF Connection for Cable Screen

Figure 23

The RF Connection screen displays only when adding or

changing a Cable Box. If your Cable Box is connected to a media center antenna input, check the RF check box. Select the antenna input that is used with the Cable Box. Select the channel number used for output by your cable box. The default channel is 003. If the Cable Box is also connected to a VCR for recording, select that VCR.

If your Cable box is connected using Audio/Video cables, make sure the RF check box is unchecked. Then the next screen will be Connection for [Device] screen (Figure 20), to allow the selection of the media center input used with the Cable Box.

Figure 23. RF Connection for Cable screen

IMPORTANT

To delete a device or change connections for a device (like a VCR or a DVD player), you must first switch the TV to a different input device. Press the DEVICE key and select a different input device from the Device Selection menu.

To make changes to the A/V receiver setup, set the current audio source to TV Audio. First press the DEVICE key to verify the current audio source. To change, press the AUDIO key to acess the audio selection window and select TV Audio.

IMPORTANT

NetCommand must be set up and the IR emitters properly placed for your cable box and VCR so the TV Guide On Screen system can control these devices.

Chapter 3: NetCommand® Setup and Editing

Edit NetCommand®:

Delete Devices

Delete Device Screen

Figure 25

Selecting Delete from the Setup menu, displays the Delete screen. You can choose to delete a single device by selecting the device you would like to delete, or you can delete the entire NetCommand configuration. After you have chosen the device, or the entire configuration, you will be prompted to confirm your choice to delete. If you select the Entire Configuration, the Initial button becomes available on the Edit NetCommand screen. If you delete a device that you learned the remote control signals for the learned signals are erased.

Setup Reminder Screen

Figure 27

This screen only appears if you did not set up NetCommand when the TV was first turned on. The Setup Reminder screen displays each time you power on the TV for six times.

If you would like to set up NetCommand and/or the TV Guide On Screen system, select Next and press ENTER. If you do not wish to setup NetCommand and/or the TV Guide On Screen system, then select Cancel and press ENTER.

Refer to the separate TV Guide On Screen Interactive Program Guide System manual for details on using the TV Guide On Screen system and special guide customization instructions.

Figure 25. Delete screen

Edit NetCommand®:

Figure 26

To finalize your selections and complete the

NetCommand setup, select Finish from the Finish

screen.

Note: To change any of the inputs or names for the

devices, or add devices not included in the initial settings,

select Edit to display the Edit NetCommand menu.

Finish Screen

Figure 27. Setup Reminder screen

Figure 26. Finish screen

Chapter 3: NetCommand® Setup and Editing

Using the Remote Control with NetCommand

Below is a list of several manufacturers devices tested and shown to be compatible with NetCommand. These devices can

be controlled without changing the setting of the remote control from the media center to another device. NetCommand may be able to operate additional models since many manufacturers use the same control signals to operate some or all of the

models they offer. This chart lists only the models that have been tested with NetCommand. The NetCommand Learning feature is able to learn the remote control signals of most Audio Video devices. For devices not listed in the table, or if your device does not operate using the same remote control as the models listed below, use the learning feature by selecting

“Other” as the Manufacturer at the [Device] screen. See the Edit NetCommand section of this Guide.

NOTE: There are many different types of remotes and not all of them may be compatible with the learning feature. Bright

light near the front of the display can also adversely affect the learning feature. If it is not possible to learn a device, you will need to use the original remote control of the device, or program the TV remote control to operate these devices in the traditional manner.

NetCommand Pre-Memorized Devices

DEVICE

Manufacturer A/V receiver Cable Box SAT (Satellite

Receiver)

Mitsubishi M-VR800,

M-VR900 Bose Lifestyle® 28 Lifestyle® 28 Denon AVR-2700 Echostar 6000 Funai F260LA General Instruments CFT2200 Hitachi DV-P415U VT-FX665A Hughes HIRD-E45,

Integra DTR-9.1 DPS-9.1 JVC XV-S65GD HR-VP 650U Kenwood VR2080 Marantz SR8200 Microsoft XBox™ (requires the DVD kit from

Motorola DCT2244 Panasonic TU-HDS20 DVD-A310 PV-8662 Philips VR620CAT Pioneer VSX-D557,

VSX-49TX RCA DRD480RE,

Rotel RSX-1065 Scientific Atlanta 8600 Sharp VC-H810U Sony STR-DE825 SAT-A55 DVP-S500D, PlayStation® 2

Toshiba DTS-3000 SD-9200,

Yama h a RX-V20 9 5,

RX-V2200 Zenith DTV1080

SR-HD5 DD-6000,

HIRD-E86

DTC-100

DVD Player VCR

HS-U795,

DD-8020

Microsoft)

DV-414

(Playstation® 2 requires the DVD Remote Controller kit from Sony; DVD Player software disc version 2.10)

SD-5109 DVD-S520,

DVD-C996

HS-U778

SLV-778HF

W-717

Chapter 3: NetCommand® Setup and Editing

NetCommand® On-Screen Buttons

To use the media center’s NetCommand feature, you need to provide some detailed information during the setup. You

must define the manufacturer of the devices that are connected to the media center, or “learn” the IR code remote control signals for the device connected. For each device, the input to the media center and A/V receiver, and the names for the device are pre-set during Initial NetCommand setup. You may change those inputs or names using the Edit NetCommand or Learn screens. The buttons described below will help you navigate the screens.

On your remote control, the ADJUST and buttons allow you to navigate left and right to different selections on the screen. The ADJUST and buttons allow you to:

• Change the radio button

• Change current text box selection

• Navigate up and down on the screen

The ENTER button allows you to:

• Confirm the selected character when naming a device

• Add or delete check marks in check boxes

• Select on-screen buttons to change screens

Text Box

Press ADJUST or to make a selection.

Check Box

<Back Button

Use the <Back button to navigate back to the previous screen.

Next> Button

Use the Next> button to navigate forward to the next screen.

Cancel Button

The Cancel button will cancel out any changes you

are currently making without saving them into memory. When you select the Cancel key, NetCommand will prompt you to confirm that you want to cancel the changes you are currently making. If you select Cancel during Initial Setup, you can setup NetCommand later by selecting the NetCommand menu, then choosing Initial.

Check marks indicate the item or input is added or turned On. Press ENTER when the check box is highlighted to add or delete a check mark. When viewing the Review screen, a check box reflects which devices are turned On or Off, or connected to the media center.

Radio Buttons

The setting changes when one of the choices is

highlighted.

Control Buttons

Much like the software on your computer, you will use graphic buttons to navigate through the NetCommand Setup screen. Highlight the button and press ENTER to select the function.

Chapter 3: NetCommand® Setup and Editing

3D Graphical Menu System

Your TV also has Mitsubishi’s exclusive 3D Graphical on-screen operating system, which provides on-screen information for menu choices and changes, using the media enter’s remote control.

Menu Screens

A picture (icon) will be highlighted on the

menu screen when selected with the

ADJUST arrows. You may then make

changes within the menu or access submenus, if available.

You can also access sub-menus from a

button. Sometimes when you select a button, an automatic function begins.

The

features:

• The currently selected icon or button is highlighted with a yellow outline; the text color is yellow.

• On-screen instructions, shown in the message line at the bottom of the menu, provide feature selection and adjustment information.

• Some on-screen menu options must be set before other options are available.

system includes the following special

Remote Control Buttons

The following buttons on your remote control help you

navigate within the system :

1. A DJUST change.

2. ADJUST

3. ENTER to enter into a menu, start an automatic function or select a check box.

4. CANCEL to clear a setting or stop an automatic function.

5. TV MENU to display the display’s main menu or move back one menu screen at a time.

6. HOME to exit all menus and return to TV viewing.

or to select the menu item you want to

or to change the settings.

1"(&

Main Menu: This screen will always be the first screen that appears when you press the remote’s TV MENU button.

Press ADJUST or to change text boxes. Some text boxes have preset labels. Other boxes allow you to select letters, numbers or characters to customize names.

Chapter

IEEE 1394 Devices and NetCommand® Controlled Recordings

Using the “Learn” Feature to Control IEEE 1394 Devices ........... 52

Adding IEEE 1394 Devices Automatically Device Selection Menu Using the DEVICE MENU Button to Display Menus

Device Menu

IR Controlled Devices Using the GUIDE Button to Display ChannelView™ and Menus NetCommand® Controlled Recordings Peer-to-Peer Connections Using A/V Discs MediaCommand™ and Memory Card Playback Direct VCR Recording from an Antenna or Cable Source

......................................... 56

........................................ 60

................................... 55

.................................. 56

................................. 59

...................... 53

............... 56

........................ 58

.................. 61

........... 63

....... 57

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Using the “Learn” Feature to Control IEEE 1394 Devices

NOTE: See pages 32–33 for information regarding compatible IEEE 1394 devices and connection styles. The media center

is not able to control IEEE 1394 devices that use other types of control protocols. Incompatible digital audio, video and/or control information will still be able to pass from one device through the

These incompatible devices may not appear on the Device Selection menu or in the Review screen of the Edit NetCommand

menu.

Some IEEE 1394 devices such as cable boxes or satellite receivers will not have compatible digital control signals or require the use of the device’s own remote control. Some of these IEEE 1394 devices will not display on-screen information through the IEEE 1394 connection and will require using an analog connection for on-screen displays. In many cases, to control these digital devices, the Learning feature of NetCommand can be used.

1. Place an IR Emitter for NetCommand in front of the device’s remote control sensor (see IR Emitters, page 30–31).

2. On the Name for 1394 Device screen (Figure 2, page 53) use ADJUST and ENTER to check mark the Analog Connection box.

3. Select the device type on the IEEE 1394 Device Type screen (Figure 3, page 54) of DBS (Satellite receiver) or similar tuning device.

4. If desired, use the ADJUST buttons enter a custom Name on the Name screen (Figure 19 , page 44).

media center to another device on the network.

5. At the Device Screen, Select “Other” as a manufacturer and then highlight “Learn” and press ENTER (Figure 4, page 54).

6. Follow the device learning instructions found on the screen(s) or in the Edit NetCommand section of Chapter 3.

7. The Connection screen (Figure 5, page 54) follows the learning screens. If analog connections are used, select the correct inputs.

8. Proceed with the Finish screen.

This will allow NetCommand to use the learned remote control signal to control these IEEE 1394 devices.

Note: When using the NetCommand learning feature for IEEE 1394 devices that do not have analog connections, the GUIDE function will require pressing GUIDE twice. The first press of GUIDE will display the media center’s digital channel guide. The second press will display the program guide for the device if an IEEE 1394 Guide is available.

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Adding IEEE 1394 Devices Automatically

When an IEEE 1394 device is connected into the media center and is powered On, the new device will automatically announce its presence. This process is called device discovery and can take up to 1 minute. Some non-audio/video or non-compatible IEEE 1394 devices, such as Personal Computers (PCs), may not announce their presence to the media center. The media center will not be able to show these devices in the Device Selection menu, however, they can coexist and will still be available to other devices on the IEEE 1394 network that are compatible with these non-audio/video devices.

IEEE 1394 cable boxes and satellite receivers may require that you use the remote control that came with those devices. For some compatible devices, the other slide switch positions of the HDTV remote control may be able to control operation.

New 1394 Device Screen

Name for 1394 Device Screen

Figure 2

If you choose to add the discovered IEEE 1394 device, the Name for 1394 Device screen will appear. Name the device or use the default name that appears automatically.

Some IEEE 1394 digital devices, such as some DVCRs, can also operate as analog devices. For example, some

DVCRs can record and play as VHS or S-VHS, in addition to D-VHS. This allows you to play analog rental tapes

or analog tapes from your established library or make

analog recordings from antenna or cable systems. To use the analog capability, check the Analog Connection box.

Figure 1

When your media center discovers a new IEEE 1394 device, the New 1394 Device screen will appear. Selecting “Add” will include the device in the Device Selection menu. Selecting “Do Not Add” will not add the device to the Device Selection menu. If the IEEE 1394 device does not provide audio and video, you may not want to add that device to the media center’s Device Selection menu. Devices that were discovered but not added to the Device Selection menu will still be listed in the Review screen of the Edit NetCommand® menu.

Figure 1. New 1394 Device screen

Figure 2. Name for 1394 Device screen

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Adding IEEE 1394 Devices Automatically, continued

IEEE 1394 Device Type Screen

Figures 3 and 4

If the new IEEE 1394 device is also connected using analog inputs, you will need to define the device type. Select the type of device, such as a VCR.

Figure 3. IEEE 1394 Device Type screen

Once the device type is selected, then the Device screen is displayed so the manufacturer can be selected. If the manufacturer is listed, then you may be able to control this device while it is operating as an analog

VCR. For example, if the IEEE 1394 device you have

added is a Mitsubishi DVCR, and you have selected an analog connection as a second connection, then you will select Mitsubishi for the manufacturer. If the manufacturer is not listed, select “Other” and use the Learn screens.

Connection Screen

Figure 5

Select the media center input that you used when you connected the video or S-Video cables. You may also select the media center or A/V receiver input you used when you connected the stereo audio cables. The media center will learn the input names for the media center input and A/V Receiver input selections. If your A/V receiver has other inputs than those listed in the menu, those other inputs are not available for NetCommand.

The playback and record control of some DV camcorders

may still operate by the IEEE 1394 cable automatically, even though you must use the video or S-video cable for the picture. In this case, when you select the Camcorder, be sure to select analog (not digital) from the pop up when a camcorder is selected from the Device Selection menu. Then the picture is shown via the analog connection but control is from IEEE 1394.

Figure 5. Connection screen

Be sure to place an IR Emitter in front of the remote control sensor, just as you have done for other NetCommand® devices. It is necessary to use the IR Emitter only when the DVCR is being used as an S-VHS or VHS VCR. When the DVCR is playing or recording digital signals in D-VHS, the media center will control the VCR through the IEEE 1394 cable

Figure 4. Device screen

Finish Screen

Figure 6

To finalize your selections and complete the

NetCommand setup, select Finish from the Finish

screen.

Figure 6. Finish screen

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Device Selection Menu

When you press DEVICE on the media center’s remote control, the Device Selection menu (Figure 7) displays. If NetCommand® has not been set up, the Device Selection menu allows you to select an input for viewing. If NetCommand is set up, the Device Selection menu allows you to select the device for viewing, select audio from the display’s internal speakers or A/V receiver, power compatible devices On or Off, and verify the destination of signals. On the Device Selection menu, the device or input currently displayed appears as a goldcolored icon.

Device Section

Figure 7. Device Selection Menu with NetCommand

Power On/Off Devices

Devices that have separate On and Off remote control buttons will power On automatically when you select the device and will power Off when you turn off the media center. For devices that do not power On or Off automatically, display the Device Selection menu, press

ADJUST or to highlight the device icon and press

POWER on the remote control. For the A/V receiver, press AUDIO to move the navigation to the Audio Section. Highlight the A/V receiver icon and press POWER. If you press POWER on the remote control when the Device Selection menu is not displayed, the media center will turn Off.

Device Section

To select another device or input, press ADJUST

on the media center’s remote to move the highlight. Press ENTER to select the device to view and hear. The media center inputs are automatically changed. If NetCommand is set up, the inputs on compatible A/V receivers are automatically changed at the same time.

Video Section

The TV icon shows the destination for the device

highlighted in the Device Section.

Video Section

Connection Section

Audio Section

is currently recording, when you move the highlight to the Ant-1 icon, the D-VCR icon will appear in the Connection Section. This icon will disappear when you move the highlight to another icon, Press CANCEL to stop

recording.

Audio Section

When a NetCommand pre-memorized or learned IR controlled A/V receiver has been connected to the media center and added to NetCommand Setup, an AVR icon will appear in the audio section. Press AUDIO to change

navigation to the audio section. Then press

to select the display’s internal speakers icon or

ADJUST

the A/V receiver icon. Press ENTER to change the audio selection. Press DEVICE to return the navigation to the Device Section.

NOTE: Muting of the speaker occurs automatically when the A/V receiver is selected through NetCommand.

PIP Device Selection Menu

Figure 8

The PIP Selection menu displays when you press the PIP DEVICE button on the remote control. This menu has the same general format as the Device Selection menu. The source for the Video Section is the sub picture and the Audio and Connection Sections are not available.

Use

ADJUST

to move the highlight to the device to show in the PIP or POP screen, then press ENTER. Device icons that are grayed out are not available for use as PIP/POP sources or with the current source.

Video Section

Device Section

Figure 8. PIP Device Selection Menu

IMPORTANT

If a device does not respond to separate On or Off remote control signals, the manufacturer has not provided that ability for the device.

Connection Section

The Connection Section shows the other devices

currently connected to the device highlighted in the Device Section. For example, if the Digital VCR (D-VCR)

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Using the DEVICE MENU Button to Display Menus

Device Menu

If NetCommand is setup, pressing the remote control’s DEVICE MENU button displays the transport menu if the input is a VCR or DVD. Another press of the DEVICE MENU button will display menu for the current device source, if available.

Figure 9. Transport menu

IR Controlled Devices

For a NetCommand compatible traditional IR controlled device, pressing DEVICE MENU once or twice will display the menu for that device. While the menu for the device is displayed, press ENTER to navigate the screen. For some NetCommand traditional devices you will also be able to use the number buttons and other additional buttons on the HDTV remote control.

For traditional DVD players, DEVICE MENU is also known as the setup menu.

ADJUST

and

Moving Through Other CableCARD Screens

In addition to CableCARD menus, other CableCARD application screens may display and require you to make additional selections. While CableCARD application screens are customized in each area, some general rules apply in using these screens with your Mitsubishi media center.

1. Blue text denotes a link to another screen. Press ENTER to move to the next application. When screens do not have blue text, there are no more links.

2. You cannot move backward through the links. If you want to exit the CableCARD system, press HOME to exit and return to TV viewing. CANCEL may not apply to some CableCARD screens.

All information on these application screens is provided by your local cable company. Please contact your cable provider if you have any problems with the application screen displays.

IMPORTANT

Most CableCARD screens are status or diagnostic in nature and do not allow you to make changes. These screens are meaningful only to your local cable provider.

CableCARD™ Menu

Figure 10.

When using a CableCARD, pressing DEVICE MENU will display a list of up to 8 links to applications that contain basic CableCARD information made available from your cable provider. Press ADJUST the application links. To select a link (blue text) to an application, press ADJUST or to highlight the link, then press ENTER to access the linked page. Pressing DEVICE MENU will return to the CableCARD menu screen and pressing HOME will return to TV viewing. If there are technical problems with the CableCARD, an error screen will automatically display with information that may be needed by your Cable provider when you call them for assistance.The screen shown below is an example of the type of screen that may display. Specific

or to move through

Press HOME key to exit

Figure 10. Possible Device Menu for CableCARD

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Using the GUIDE Button to Display ChannelView™ and Menus

GUIDE and Devices (1394 or IR Controlled)

For NetCommand compatible satellite receivers and some cable boxes, GUIDE will display the on-screen programming guide for the receiver or cable box. Press

ADJUST displayed Guide. For NetCommand compatible satellite receivers, you may also be able to use the number or other additional buttons.

For NetCommand compatible DVD players, GUIDE will display the DVD disc “top” menu (not the setup menu). For A/V Discs, pressing GUIDE will display the Track List screen. For IEEE 1394 devices with digital connections, press GUIDE twice to display the device’s Guide.

GUIDE and the Device Selection Menu

For compatible traditional VCRs, pressing GUIDE when the VCR is highlighted on the Device Selection menu will change the VCR’s input.

When the A/V Receiver icon is highlighted in the Audio Section, pressing GUIDE switches the A/V Receiver from analog audio to digital audio and vice versa.

GUIDE and the Record To Menu

When in the Record To menu, pressing GUIDE will display the current list of programmed recordings. Please see Record List, page 59 for more infomation.

or and ENTER to navigate the

Recording a Current Program

To record a current program, press REC (record) when your program choice is highlighted on the program list in ChannelView. A red “R” will be added after the input name. The media center will immediately switch to the selected channel and start recording.

Figure 11. ChannelView screen, current programs

Recording Future Programs

To record a future program, press ADJUST or to select the channel you want to record from. For detailed program information, press ADJUST . Press REC (record) when your choice is highlighted. A red “R” will be added after the input name. The message, The recording has been added to the Record List will display. To view, change or cancel a recording, use the Record List (page 59 ). If a program title was not sent by the broadcaster, you will be unable to set up a recording and a message will display.

GUIDE and ChannelView

Figures 11 and 12

Press GUIDE while viewing Ant-1 or Ant-2 to display a list of available memorized digital channels (D) and analog (A) channel information (if available from the broadcaster). This list is called ChannelView™.

ChannelView for digital channels will show the major and sub-channels (or bitstreams). Analog channel information will display as sent. Press ADJUST or to scan through the all the channels in memory one by one. To cycle through the choices quickly, press CH or .

For detailed program information, press ADJUST . T return to basic information press ADJUST . This information is sent by the broadcaster. If limited data is shown or no program data appears, it is because the broadcaster is not sending the information. This is not a

defect of your media center.

Figure 12. ChannelView screen, future programs

IMPORTANT

For complete ChannelView information to be refreshed daily, the media center must be powered Off between 5 to 15 minutes a day, depending on the number of channels in memory. If the media center loses power, the program listings will be temporarily lost.

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

NetCommand® Controlled Recordings

Setting up Recordings

Figure 13

Through NetCommand, you can automatically start and

stop recordings and send signals from one playback device to a recording device. Recordings can be made on recordable devices connected to the media center.

The media center can convert digital channels and

IEEE 1394 device signals to analog signals that can be

recorded on NetCommand compatible analog VHS and

S-VHS VCRs.

You can schedule the recording to take place at a later

time and program the recording duration for a minimum of 30 minutes and a maximum of 6 hours (in 30 minute increments). The default is 1 hour. During the recording, the media center can be powered Off. If the media center is powered On, it must be tuned to the source that is being recorded.

Recording Now

Can be used when viewing Antenna 1 or 2, an IEEE 1394 device or a non-recording traditional device.

To initiate recording now:

1. Press REC (record) on the TV remote.

2. Press DEVICE on the remote control to move to the Source Device section.

3. Press ADJUST will record from. If a source is not displayed, it is not available as a recording source.

4. Press ENTER to confirm selection and return to the “Record to” section.

5. In the “Record to” section, review the destination device and duration. Use ADJUST or to change if necessary.

6. Press REC a second time to initiate recording.

or to select the source device you

Time-Delayed Recording

To initiate a time-delayed recording:

Figure 13. Record To screen

1. Press REC (record) on the TV remote.

2. Press DEVICE on the remote control to move to the Source Device section.

3. Press

4. Press ENTER to confirm your source device selection

5. Press ADJUST or to select the Record to device,

6. Select Add and press ENTER to add the recording

7. To exit, press HOME on the TV remote after all

ADJUST

you will record from.

and move to the Record to section.

duration time, start time (press ENTER after selecting

hour, minutes and AM or PM to set the time) and day. For devices that can select channels, select the channel.

to the record list. If your selection is successful, a confirmation message will be displayed. If you pick overlapping times, day(s), or destination devices, you will see a message stating there is a conflict.

recordings have been added.

to select the source device

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Record List

Figure 14

Press GUIDE while viewing the Record To screen to see a

list of all currently programmed recordings. A maximum of

32 recordings can be scheduled.

Figure 14. Record List screen

Cancel Current Recordings

To cancel a recording in progress, press DEVICE to

display the Device Selection menu and highlight the source of the recording. Confirm that the icon for VCR (or

recording device) is in the Connection Section next to the

TV icon. Press the CANCEL button. The icon for the VCR

(or recording device) will disappear from the Connection Section to confirm the cancellation.

To cancel a recording on the Record List, press ADJUST

or to select the recording, then press CANCEL. To

page through the list, press CH or .

Peer-to-Peer Connections

A peer-to-peer connection allows the IEEE 1394 devices in your media center network to talk to each other without the further need of media center intervention once the

peer-to-peer connection is established. For example, the

media center can set up a connection for an or DVCR that sends a recorded program to an IEEE 1394 monitor in another room. NetCommand will establish the connection

between the two devices. Once the connection has been established, the media center can be turned off or be used to display another device on the monitor. Recording from digital channels to a DVCR is also a peer-to-peer connection. In this case, the media center is one of the devices in the peer-to peer connection.

NOTE: Multiple peer-to-peer connections can occur simultaneously, sometimes with the same source device.

Setting up a Peer-to-Peer Connection

To establish a peer-to-peer connection:

1. Press CONNECT on the HDTV remote.

2. Press DEVICE on the remote control to move to the

Source Device section.

3. Press ADJUST or to select the source device you

will record from.

4. Press ENTER to confirm selection and return to the

“Record to” section.

5. In the “Record to” section, review the destination

device (example: DVCR) and duration. Change if

necessary.

5. Press CONNECT a second time to initiate recording.

Canceling a Peer-to-Peer Connection

After a peer-to-peer connection has been established, you can cancel it by highlighting the source device in the Device Selection menu. Confirm that the on-screen icon for the peer-to-peer connection is in the Connection Section next to the TV icon, then press CANCEL. The connection will end and the destination icon will be

removed. If there is more than one peer-to-peer connection for the same device, all of the connections will all be canceled.

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Using A/V Discs

An A/V Disc is an external hard drive that stores music,

picture and/or video files, an IEEE 1394 cable.

A/V Disc Track List Screen

Figure 15

When viewing an A/V Disc, press GUIDE to display its

Track List. The Channel, Station, Date, Time, Program

name and whether it has been Watched (Y=yes, N=no) will be displayed. Tracks will be listed in date and time order and will vary in size.

and is usually connected using

Using the Remote Control with an A/V Disc

After selecting from the Device Selection menu, you may

use the following remote control keys:

GUIDE: displays the Track List of recorded

programs. PLAY: resumes playback of paused program. PAUSE: pauses or resumes playback of program. FF/FWD: forward picture search, multiple presses

increase the speed. REW/REV: reverse picture search, multiple presses

increase the speed. ADJUST : skip backward 12 seconds per press. ADJUST : skip forward 30 seconds per press. ADJUST : skip to the end of the track. ADJUST : skip to the beginning of the track. REC: Display the Record Menu to schedule

recordings

Figure 15. A/V Disc Track List screen

Press ADJUST or to navigate through the Track List. Press INFO to see the recording’s length and the amount of memory it will use. Free disc space is displayed in the upper right. If the broadcaster has sent detailed information regarding the program, it will also display when you press INFO. To play a track, select it on the list, then press ENTER. To change pages, press CH or . To delete a track, select it on the list and press

CANCEL. Press CANCEL again to confirm.

A/V Disc Search

NetCommand is able to search to a specific time in a recording on an IEEE 1394 A/V Disc.

1. Start the desired track’s playback on the A/V disc.

2. Use the number buttons to enter the time code position of hours followed by minutes. For example, to enter one hour and twenty-two minutes (1:22) into the track, enter 1, 2, 2.

3. Press ENTER to skip to the time code position.

4. To cancel the request or to start over, press CANCEL instead of ENTER.

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

MediaCommand™ and Memory Card Playback

Warning: Some memory cards available on the market are not properly certified to follow the card type specifications noted below and cannot be used by the Card Reader. If the Card Reader is unable to read one of your memory cards, please transfer the files to a properly certified card.

Inserting a Memory Card

1. Insert a memory card into a matching card slot on card reader on the media center. Be sure to use the correct card slot. Card 1 will accept MultiMediaCard™ and SD Memory Card. Card 2 will accept SmartMedia™. Card 3 will accept CompactFlash®. Card 4 will accept MEMORY STICK™. Cards up to 128mb, with a file format of FAT 16 (block size = 1024 or 2048) are supported.

Normally the label side should be up, but if the card

does not fit, try turning the card over and insert again. When properly inserted, the light next to the slot will light up.

2. Press DEVICE on the remote control to display the Device Selection Menu and then select the correct card slot from the list, using

3. The Media Dialog box (Figure 16) will automatically display. Use the AUDIO button to switch from JPEG Picture Slideshow setup to MP3 or WMA7 Audio Playlist setup or use the VIDEO button on the remote to switch from the MP3 or WMA Audio Playlist setup to JPEG Picture Slideshow setup.

For Slideshow, press PLAY. For Thumbnails, press GUIDE. To redisplay this menu or to setup, press DEVICE MENU.

ADJUST

Using Remote Control Buttons for Controlling Playback

For JPEG Pictures Slideshow:

PLAY: begins or resumes slideshow playback PAUSE: pauses or resumes playback while in the automatic advance mode. FF: skips to the next slide. REW: returns to the previous slide. FORMAT: single press rotates the slide 90˚. Multiple press continues to rotate the slide. STOP: Stop slideshow, return to Memory Card screen.

For MP3 or WMA Audio Playback

PLAY: begins or resumes playlist playback. PAUSE: pauses or resumes playback. FF: skips to the next track/song. REW: skips to the previous track/song. STOP: Stop playback and returns to Memory Card screen.

JPEG Picture Thumbnail Menu

Figure 16

1. Press GUIDE on the remote to display the JPEG picture Thumbnail menu.

2. Press

3. Press FORMAT to rotate the selected image 90˚

4. Press PLAY to begin playback of the Slideshow from

ADJUST different images (CH up/down will change pages of the Thumbnail menu). Use REW to go to the first slide and FF to go to the last slide on the page.

(pressing FORMAT four times will rotate the image completely around to the original position).

the selected image. The Thumbnail menu will be taken down.

to move the highlight to

For Playlist, press AUDIO.

Figure 16. Media Dialog Box

NOTE: Don’t pull a memory card out while it is playing.

4. On the remote control, press:

PLAY: to start the slideshow or play audio.

GUIDE: to display the JPEG Thumbnail menu (Figure 17) or Audio track playlist (Figure 18).

DEVICE MENU: to display the Media Setup menu (Figure 19).

Figure 17. JPEG Thumbnails

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

MediaCommand™ and Memory Card Playback, continued

MP3 or WMA7 Audio Playlist Menu

Figure 18

1. Press GUIDE to display the Playlist menu.

2. Using ADJUST or to move the highlight to different tracks (CH up/down will change pages of the Playlist).

3. Press PLAY to begin playback. The Playlist menu will be taken down. An asterisk (*) will be next to the song currently playing.

Figure 18. Audio Playlist

For JPEG Pictures up to 128MB

1. Still images recorded on digital cameras using the Exchangable Image File Format, version 2.1 (EXIF

2.1) standard for digital still cameras and Design Rules for Camera File Systems version 1.0 (DCF 1.0).

Some images opened and resaved on a computer may

not playback or may not be able to display a picture in the thumbnail list because the computer program that opened and resaved the images changed the file to an incompatible format.

2. Standard digital images with a maximum size of 5-megapixels for each image, or 2560 x 1920 pixels. Pictures will be scaled to the display. Some pictures may be cropped to fit.

3. Full path file names can be no longer than 50 characters and must end in a .jpg extension. Not all 50 characters will display.

For MP3 or WMA7 Audio files

Media Setup Menu

Figure 19

Press DEVICE MENU at any time to display the Media Setup screen, where you can adjust the Slideshow Display, Frequency, Interval or Playlist Frequency.

Figure 19 . Media Setup Menu

For JPEG Picture Slideshow Setup

• For JPEG picture Slideshow playback, select Automatic or Manual advance. For manual operation, press PLAY or ENTER on the remote control to advance each slide.

• For automatic advance, select the frequency or number of times to show the complete slide show, Once, Twice or Continuously.

• For automatic advance, select the interval time each slide is shown, for example, 5 seconds, or 30 seconds.

For MP3 or WMA7 Audio Playlist Setup

• Select the frequency or number of times to play the complete playlist. Once, Twice or Continuously.

• To exit, press DEVICE MENU on the remote control to re-display the memory card screen or press HOME to return to TV viewing.

IMPORTANT

JPEG images cannot be edited through the TV . To avoid file incompatibility problems,

temporarily move the JPEG images to your PC, and change the name file names. MP3’s must have at least 32 kHz sampling rate.

1. Files recorded with sampling rates of 32 kHz, 44.1 kHz or 48 kHz.

2. Files recorded with fixed bit rates

3. File names with .mp3 or .wma extensions

NOTE: During MP3 or WMA7 audio playback, audio from the cards will be sent to the A/V receiver as analog audio. Digital out is not available.

Chapter 4: IEEE 1394 Devices and NetCommand® Controlled Recordings

Direct VCR Recording from an Antenna or Cable Source

Pressing REC (record) on the media center’s remote control will function the same way as pressing the record button on the VCR’s remote control or front panel.

To record directly from antenna or cable:

1. Press DEVICE on the media center’s remote to display the Device Selection menu. Highlight the traditional VCR and press POWER to turn on the VCR. If necessary, press GUIDE to select the input the VCR is on, such as Antenna input (or line input).

2. Press ENTER to switch the media center to the VCR.

3. Select the correct channel for recording on the VCR and then press REC to start recording. You will need to manually stop the recording at the end of the program.

OR...

4. Press the DEVICE MENU button to display the VCR’s menu to schedule a delayed recording directly from antenna or cable.

Copy-Protected Material

When attempting to record copy-protected material, the

Record functions of the NetCommand and IEEE 1394 systems may be prevented or stopped. If you have a recording that is tagged “Record Once”, NetCommand will not allow the recording to be moved.

Restrictions for Traditional VCRs

If turned On, the media center must be tuned to the source device.

• Your VCR should be connected directly to Monitor  Output Audio and Video.

• The VCR must be set manually to “Line Input”. Display the Device Selection menu, highlight the VCR and press GUIDE to change VCR inputs.

• The media center can select channels on compatible cable boxes for recordings. Leave the cable box turned on.

• If the source device or recording device does not have separate power On and Off features, then leave that device powered On.

To record from Ant-1, Ant-2 or other devices, see

NetCommand Controlled Recordings.

Chapter

TV Menu Operations

Main Menu Choices ..................................... 66

Setup Menu NetCommand Menu Antenna Menu Time Menu Captions Menu Customizing Digital Settings V-Chip Rating Guidelines V-Chip Lock Menu V-Chip Menu Audio/Video Menu A/V Setting Descriptions

........................................... 67

..................................... 68

......................................... 69

............................................ 71

......................................... 72

................................. 74

...................................... 75

.......................................... 75

...................................... 77

................................. 78

............................... 73

Chapter 5: Using the TV Menu

Main Menu Choices

Setup Menu

Figure 1

Use the Setup menu to select English or Spanish as the language for the menus and on-screen displays.

Adjust Color Balance Automatically or manually (PerfectColor™). Color Balance uses six colors,

Magenta, Red, Yellow, Green, Cyan and Blue to obtain color balance. Reset the Color Balance to the factory default settings.

Choose Side Bar Color of black or gray. View the media center’s software version on this screen.

Figure 1. Main menu, Setup selected

NetCommand® Menu

Figure 2

Add, change, review or delete NetCommand® settings and devices. If you have more than one digital recording device connected, use this menu to change the default digital Record To device. Turn the transport menu off and change the order of the icons in the Device Selection menu. Set up TV Guide On Screen®.

Time Menu

Figure 4

Manually set the time for the media center, or select Auto and the media center will automatically set the time based upon Extended Data Service (XDS) time data. This time data is usually broadcast by your local PBS station. This menu is also used to set the TV timer.

Figure 4. Main menu, Time selected

Captions Menu

Figure 5

Display Closed Captions if sent by the broadcaster, select settings for analog or digital captions.

Figure 5. Main menu, Captions selected

V- Chip Lock Menu

Figure 6

Block or allow programing based upon rating signals sent by the broadcast station or lock by time.

Figure 2. Main menu, NetCommand selected

Antenna Menu

Figure 3

Memorize available analog and digital channels for both

Ant-1 and Ant-2. After memorization, if a channel displays

as digital and analog, you can choose to see the channel digitally every time it is selected. Manually add or delete channels from memory, name channels or add your favorite channels to a SQV (SuperQuickView™) list.

Figure 3. Main menu, Antenna selected

Figure 6. Main menu, V-Chip Lock selected

Audio/Video Menu

Figure 7

Reset the A/V Memory to return to the original factory A/V settings for a selected device. Customize the individual audio and video settings. Display a blue screen when viewing a device with no signal.

Figure 7. Main menu, Audio/Video selected

Setup Menu

Figure 8

Chapter 5: Using the TV Menu

Figure 8. Setup Menu, NetCommand Option

Language

Display the on-screen menus in either English or Spanish (Español). The first time you powered On your media center, you were requested to select an on-screen menu language. If you choose to change the selection, all menu text will immediately switch to the language of your choice.

Program titles and other information sent by a broadcaster will be shown in the original language.

Color Balance

Your media center uses six colors (Magenta, Red, Yellow, Green, Cyan and Blue) to create color balance. You may adjust the intensity of the colors automatically or manually (PerfectColor™) or reset them to the default settings. Each input or device has a memory for PerfectColor.

Auto (Color Balance)

If the Auto box is checked, your media center will optimize color automatically and continuously. Both PerfectColor and Reset options for Color Balance are grayed out and unavailable.

Figure 9. PerfectColor Menu, Manual Color Correction

Reset

Select to reset the Color Balance settings. Each active input can be individually reset, if Auto is not checked.

Side Bar Color

For some TV formats sidebars are visible (see TV Display Formats, G). You can choose to display these sidebars in gray or black. When used with the LCD display, black is recommended.

Software Version

For some service related issues, it may be necessary to know which software version is in your media center. This information is displayed on the Setup menu screen.

PerfectColor™ (Manual Color Balance)

Figure 9

The PerfectColor (manual) option is only available when Auto (Color Balance) is not checked. Select PerfectColor and press ENTER to display the menu. Individual sliders for Magenta, Red, Yellow, Green, Cyan and Blue will be displayed. The sliders have a numeric value, where 63 is the maximum. The default setting for each color is 31 (center). Highlighted text will show which slider you are adjusting. Each active input can be individually adjusted. Press ADJUST or to navigate between colors and ADJUST or to change the color slider settings.

Chapter 5: Using the TV Menu

NetCommand Menu

Figure 11

Figure 11. NetCommand Menu

NetCommand

Detailed information regarding setting up and editing the NetCommand menu is found in Chapter 3. The Edit NetCommand screens allow you to add new devices, change or edit traditional and IEEE 1394 devices, turn devices and unused inputs On or Off, set up TV Guide On Screen®, delete a single device or delete the entire setup configuration. If you choose to delete the entire configuration, or if the NetCommand setup was cancelled, deleted or not completed, you can start at the Initial NetCommand screen. The Review screen shows all devices connected to the media center.

Transpor t Men u

Note: Transport buttons (rewind, play forward, stop, pause and record) on the remote control are located in the bottom section of the remote control.

Default Digital Device

If multiple digital recording devices are available in NetCommand, this setting allows you to choose the device to use when recording digital programs. A digital recording can be made on either a digital or analog device although the quality will not be as good if recorded on an analog device. For best playback quality, record digital programs on a digital recording device.

If multiple devices were not connected and then added in the NetCommand setup, this setting will be unavailable

(grayed out). Analog recordings can only be made on the

one analog device connected to Monitor Out (usually a

VCR) and are not affected by this setting. This feature is

most useful when recording from ChannelView™ (page

57).

Icon Order

Figure 13

The Icon Order screen allows you to arrange the device

icon order on the Device Selection menu to a different sequence, for ease of selection and operation. To change the order, press the icon to be moved and then press ENTER. Press

ADJUST

position and then press ENTER to release the icon.

ADJUST

to move the icon to the desired

to highlight

Figure 12

Main Picture

Figure 12. Transport Menu

NetCommand uses the Transport menu to control the VCRs, DVDs, IEEE 1394 AV Discs, digital VCRs, and similar devices. If you choose to turn off this menu when viewing the devices, the transport buttons (rewind, play forward, stop, pause and record) on the media center’s

remote control will continue to operate these devices. In the Device Selection menu selecting a VCR or DVD Player will automatically display the Transport menu. You can

re-display this menu by pressing DEVICE MENU.

Select Transport menu functions by pressing ADJUST or and then ENTER. For example, to pause playback, press ADJUST or to move to PAUSE, then press ENTER. If a function is not possible, such as record for a DVD Player, the Transport menu button will be grayed out.

Figure 13 Icon Order Menu

Chapter 5: Using the TV Menu

Antenna Menu

Figure 14

Figure 14. Antenna Menu

he Antenna Menu options are available for use with analog and digital channels on Antenna-1 and Antenna-2. You can memorize channels, add or delete channels, name channels and add channels to an SQV (Super Quick View™) bank.

Memorize

For Antenna 1 (Main) or Antenna 2 (Aux)

Select either Air (when used with an indoor/outdoor antenna) or Cable (when used with direct cable) then press ENTER to start the automatic channel memorization process. If a CableCARD™ is being used, memorized channels are provided by your cable provider through the CableCARD.

To stop the automatic channel memorization process,

press CANCEL. Channels memorized before you pressed CANCEL are retained in memory.

After memorizing channels, the channels in the memory

can be accessed in ascending or descending order by pressing CH or .

Channel

Channels can be changed in 3 ways:

1. By pressing ADJUST or to select the channel.

2. By pressing CH or for channels already in memory.

3. Directly entering the number. With so many current and potential channels, the number range is greatly expanded. Channels can be one part, analog or digital (up to the number 16383) or two part, for digital channels (these use a separator). For a two part digital channel, you may press SUB/CANCEL on the remote to enter a separator after the first, second or third number, depending on the broadcaster’s channel information.

For digital channels, when the broadcaster has sent a

virtual channel number, the virtual channel number is shown in the text box and as a reference, the original digital channel is shown below the text box.

Memory

After the available channels have been memorized with

Memorize, weaker channels can be added. Unwanted channels can also be deleted. Press CH or on the remote control to see the channels in memory. Press

ADJUST or to select Added or Deleted for the

channel shown in the Channel number box.

Name

Analog channels shown on Antenna-1 or Antenna-2 can

be named (up to four characters). After you enter a name, it will appear on the TV screen, next to the channel number.

1. Press ADJUST or to select each letter.

The memorization will occur twice, as the media center

memorizes analog and digital channels separately.

Prefer Digital

When a memorized channel is available as both analog and digital, a check mark in the Prefer Digital box will allow digital channels to display and analog channels to be hidden (when using CH). Removing the checkmark will show both analog and digital choices. This function is unavailable (grayed out) when TV Guide On Screen® has been set up

2. Press ENTER to set the letter and move to the next letter position.

3. Press CANCEL to move back one position.

Digital channels are automatically named if the broadcaster sends the information.

Chapter 5: Using the TV Menu

Antenna Menu, continued

SQV (SuperQuickView™)

Using The Menu Screen

Figure 15

SQV (SuperQuickView™) allows you to put together

banks of your favorite channels from Antenna 1 and Antenna 2. You can store channels in any of the 9 different SQV memory banks. You can also store the

same channel in multiple memory banks. Once you

have added a channel to an SQV memory, “SQV” and

the memory bank number will appear under the tuned channel number on the display screen.

SQV (SuperQuickView™) Using The Remote Control

Viewing and changing SQV banks using the remote control:

1. Press the SQV button.

2. To change memory banks, press a number button within 5 seconds of pressing the SQV button.

3. Press the SQV button repeatedly to cycle through the channels available in that bank.

Adding SQV channels using the remote control:

1. Press CH , or number buttons to select the channel you want to add to the current SQV memory bank.

2. Press and hold the SQV button for about 2 seconds. When “SQV” and the memory bank number appear under the channel number, the channel has successfully been added.

Removing SQV channels using the remote control:

1. Press the SQV button and then the memory bank number.

Figure 15. Antenna Menu, SQV (SuperQuickView)

Adding SQV Channels

1. Select the channel using the “Channel” option box or press CH or .

2. Highlight the bank (SQV1-SQV9).

3. Press ENTER to check mark the selected SQV memory bank.

4. Repeat for additional channels or banks.

Removing SQV Channels

1. Highlight the box for the SQV bank number.

2. Press ENTER to remove the check mark.

2. Press the SQV button repeatedly until you see the desired channel.

3. While the channel number and SQV indicator (with correct bank number) are still displayed on the screen, press the CANCEL button. If the CANCEL button is not pressed before the SQV indicator disappears automatically, the channel will not be removed.

4. When the SQV indicator disappears, the channel has successfully been removed only from that bank.

“Other” banks remain unchanged.

Chapter 5: Using the TV Menu

Time Menu

Setting the Clock

You may choose to manually or automatically set the

clock that your media center will use for recording or timer functions. You cannot schedule recordings if the clock is not properly set.

Manual

Figure 16

To manually set the clock, you need to select the current

time, including AM or PM, current date, time zone for your area and the Daylight Savings time setting.

will automatically retrieve the correct time and date information from this channel. Be aware that if a channel displays incorrect time information, it is because of information sent from the broadcaster and is not a defect of the media center.

Timer On/Off

Figure 17

The timer can be turned to On or Off. When On, you

need to select the time and day to turn the TV On and the device and channel to display. With the TV off and the timer active, the blue POWER LEDs on the front of the display and media center blink slowly as reminders. At your preselected time, the timer will turn the TV on, and this message will be displayed: “Press a button for the media center to stay on.” Press any button on the remote control within 5 minutes or the TV will turn itself off.

Figure 16. Time Menu, Manual Clock Setting

Set Time

Press ADJUST or repeatedly to slowly select the hour or press and hold to quickly select the hour. Press ENTER to move to the minutes options. Press ADJUST

or to select minutes, then press ENTER to select

AM or PM.

Set Date

Press ADJUST or to select the correct date.

Time Zone

Select your correct time zone. Press ADJUST or to select the time zone (Atlantic, Eastern, Central, Mountain, Pacific, Alaska or Hawaii) for your area. Then press

ADJUST to move to the Daylight Savings time option.

Daylight Savings Time

Select the Daylight Savings time (DST) option that your state uses. Press ADJUST or to select Applies if your state or area uses DST, or Ignore if DST does not apply.

Auto

Select the Time Zone and Daylight Savings time setting, as noted above. You may then tune to a channel (on

Ant-1 or Ant-2) that uses Extended Data Service (XDS)

time data, typically a PBS channel. The Auto selection

Figure 17. Timer Menu (Timer On/Off)

Set Time

Press ADJUST or repeatedly to slowly select the hour or press and hold to quickly select the hour. Press ENTER to move to the minutes options. Press ADJUST

or to select minutes, then press ENTER to select

AM or PM.

Set Day

Select the day or days that the media center will turn on automatically. Press ADJUST or to select Everyday, Mon-Fri (Monday through Friday), or the individual days of the week.

Device

Press ADJUST or to select the device to use when the timer turns on media center. If the media center is already on, the timer select this pre-selected device.

Channel

When an antenna is the selected device, you may select

any memorized channel. Press ADJUST or to select the channel and the media center will tune to this channel in memory when the timer turns it on. This includes sub-channels for digital choices.

Chapter 5: Using the TV Menu

Captions Menu

Figure 18

For analog channels broadcasters can send either Standard or Text closed captioning. Standard Closed Captions follows the dialogue of the characters onscreen and displays in a small section of the screen.

Text Closed Captions often contain information such as

weather or news and covers a large portion of the screen. On digital channels, broadcasters can send up to 6 different captioning selections. Each TV station may broadcast only one or two types of captions or none at all. The media center cannot decode Closed Captions received on Component 1 or 2.

Figure 18. Captions Menu

Analog Captions

Background

To make the analog closed captions easier to read, you

can choose to display the background color as either black or gray behind the captions.

Digital Captions

The media center can display one of the following

Captions for Digital sources:

• Captions 1-6. Sent by broadcaster.

• On if Mute. Closed captions when mute. When selected, the captioning signal (Caption 1) will turn on/off by pressing MUTE on the HDTV remote control.

• Off. No closed captions.

Note: If the broadcaster is only sending analog captions converted to digital, then the analog captions settings apply.

Appearance

The Default options shows what the closed caption

provider intended to send. You may select the Custom option to override and customize Closed Captions appearance. These settings do not apply to analog Closed Captioning converted to digital.

The media center can display one of the following

captions for Analog sources:

• CC1, CC2, CC3, or CC4. (Standard closed captioning signals).

• Tex t1, Tex t2, Tex t3, or Tex t 4 . (Text closed captioning signals).

• On if mute. Closed captions when mute. When selected, the standard closed captioning signal (CC1)will turn on/off by pressing MUTE on the HDTV remote control.

• Off. No closed captions.

IMPORTANT

When analog text closed captioning is selected, a large black or gray box appears on the display’s screen if no text is being sent.

Digital Settings

Figures 18 and 19

Digital Settings are available only when Custom was selected from Appearance (Figure 18) and do not apply to analog closed captions converted to digital. Select Digital Settings by moving the ADJUST buttons and

pressing ENTER. You can select Font, Size, Color,

Background, Opacity (Font) and Background Opacity.

Figure 19. Closed Captions Menu Digital Settings

Chapter 5: Using the TV Menu

Captions Menu, continued:

Customizing Digital Settings

Fonts

You can customize the text of digital captions by

selecting the font of your choice. The available Font options are as follows:

• Default - Selected by the Closed Captions provider

• Font 1 - Mono-spaced font with Serifs

• Font 2 - Proportional spaced font with Serifs

• Font 3 - Mono-spaced font without Serifs

• Font 4 - Proportionally spaced without Serif

• Font 5 - Casual font

• Font 6 - Cursive font

• Font 7 - Small Capitals font

Size

You can also customize the text of digital captions

by selecting your desired size of font. Large is the

recommended font size.

Color

You can customize the text of digital captions by

selecting the color of font. The available font colors are as follows:

• White • Yellow

• Black • Green

• Magenta • Cyan

• Red • Blue

Background

To make the digital closed captions easier to read,

you can choose the background color. The available background colors are as follows:

Opacity (Font)

You can customize the visibility of your fonts using the

following categories:

• Transparent - See-through text to the TV program

• Translucent - TV program is visible behind the text

• Opaque - Solid color text; blocks the TV program

• Flashing - Text flashes in intervals

IMPORTANT

We recommend you use contrasting colors between captions and background. In particular, Black background with translucent opacity and White font are best.

Care must be exercised when selecting customized colors. Your choice may change the legibility or readability of captions.

Background Opacity

You can customize the background for digital captions

using the following categories:

• Transparent - See-through background to the TV program

• Translucent - TV program is visible behind the background

• Opaque - Solid background; blocks TV program

• Flashing - Background flashing in intervals

IMPORTANT

The content of captions is determined by the

broadcaster. If your captions show strange characters, misspellings or odd grammar, it is not a malfunction of the media center

• White • Yellow

• Black • Green

• Magenta • Cyan

• Red • Blue

Chapter 5: Using the TV Menu

V- Chip Rating Guidelines

V-Chip Signal Information

When provided by the broadcaster, V-Chip ratings can be used to control which programs can be viewed or will be blocked. When V-Chip ratings are sent, you will see the ratings when you change the channel or when you press the INFO button on the remote control. Both TV and Movie ratings will display. TV ratings apply to programs and movies developed for TV and may have supplemental blocking by content categories. Movie ratings use MPAA ratings for movies released in theaters.

V-CHIP EXCEPTIONS:

1. V-Chip is not effective for programs viewed on devices connected to Component input or HDMI.

2. Videotapes, laser discs and DVDs may not contain V-Chip rating signals. If they don’t contain the V-Chip signal, V-Chip cannot block the program or movie.

3. Broadcasters are not currently required to include V-Chip rating signals at this time. If the broadcaster does not include the V-Chip rating signal, V-Chip cannot block the program.

TV Ratings:

Used with TV programs and Made-for-TV movies.

TV-Y Youth, for children under the age of 7. TV-Y7 Youth, 7 years old and older. For children 7 years old and older. TV-G General Audience. For the entire family to view. TV-PG Parental Guidance. Parental Guidance is recommended, may not

be suitable for some children. TV-14 Adolescent 14 years old and older. Not recommended for children under the age of 14. TV-MA Mature Audience. For adults only.

TV Rating FV D L S V

TV-Y TV-Y7 X TV-PG XXXX TV-14 XXXX TV-MA XXX

Content Categories:

Used in association with the TV ratings above.

FV Fantasy Violence- applies to TV-Y7 only. D Sexual Dialog- applies in different degrees to TV-PG and TV-14. L Adult Language-applies in different degrees to TV-PG, TV-14, and TV-MA. S Sexual Situations- applies in different degrees to TV-PG, TV-14, and TV-MA V Violence (graphic or realistic)- applies in different degrees to TV-PG, TV-14, and TV-MA.

When you select a TV rating, you are selecting the least-restricted program level that can be viewed. As an example, if you select TV-PG, you are allowing programs rated TV-Y, TV-Y7, TV-G and TV-PG to be seen and

blocking programs rated TV-14 and TV-MA. When you select a TV Content category, you will block all TV programs that have the same content category listing. As an example, if you select to block V (Violence) at the

TV-14 level, you will also block any program that has the V category listing at the TV-PG rating level as well.

Movie Ratings:

Used with theater released movies and direct-to-video movies. G General Audience- Designed for the entire family to view. PG Parental Guidance- Parental Guidance is recommended, may not be suitable for some children. PG-13 Parental Guidance 13 years old and older- Not recommended for children under the age of 13. R Restricted- Restricted in the theater to 17 years old and older unless accompanied by an adult. NC-17 No Children- Restricted in the theater to 18 years old and older. X Adult- Designed for and restricted in the theater to adult audiences only.

When you select a Movie rating, you are selecting the least restricted program level that can be viewed. As an example, if you select a movie rating of PG-13, you are allowing movies rated G, PG and PG-13 to be seen and

blocking movies rated R, NC-17, and X.

Programs Not Rated: Used for programs that are

not rated like news, sports, weather, emergency bulletins, or movies such as those prior to or without MPAA Ratings.

If you select to block programs that carry the V-Chip rating “Programs Not Rated,” you may block News or Emergency Bulletins, when “None” or “NR” Not Rated V-Chip rating is included. Care should be used when blocking programming that is not rated.

IMPORTANT

This does not include programs without V-Chip signals.

V- Chip Lock Menu

Chapter 5: Using the TV Menu

V-Chip Lock Menu Overview

Figure 20

The V-Chip Lock menu gives you access to V–Chip options and to non-V-Chip TV-locking options as well. You must use a pass code to open this menu to enable/ disable the lock options. The two different types of locks available are:

• V-Chip Lets you restrict access to programming based on program-rating signals sent by the broadcaster. You can also set the time of day for these restrictions to be in effect.

• Lock by Time Lets you restrict all TV viewing by time of day.

V-Chip Icon

Lock TV by

Time

To reset the pass code, see the procedure in Appendix C.

V-CHIP PARENT LOCK

To go to the menu, enter a new passcode.

––––

Use the NUMBER buttons and press ENTER.

Figure 21. The V-Chip Parent Lock screen

IMPORTANT

If you forget your four-digit pass code, see Appendix C.

V- Chip Menu

Figure 22

The V-Chip menu allows you to:

• Turn the V-Chip Lock on or off

• Change the permitted V-Chip rating level

• Set the time of day to enforce rating restrictions

Figure 20. V-Chip Lock Menu

Setting a Pass Code

You are prompted to enter a pass code whenever you select V-Chip Lock on the menu or press the V-CHIP key on the remote control. To set a pass code for the first time:

1. Do one of the following:

• Press V-CHIP on the remote control.

• Press TV MENU, highlight V-Chip Lock, then

press ENTER.

The V-chip Parent Lock screen in Figure 21 displays.

2. Input a four-digit pass code using the number keys on the remote control.

• Press CANCEL to delete a number and move back one space.

• Press MENU or HOME to exit without setting a pass code.

3. Press ENTER to confirm the pass code just input.

The TV comes from the factory with pre-set V-Chip ratings and with the V-Chip Lock turned off. The preset ratings are TV-PG (TV rating) and PG (movie rating). If you turn on the V-Chip, these presets will allow only programs rated TV-PG/PG or lower. You can turn on V-Chip from this menu or by using the V-CHIP button on the remote control. Use the V-Chip menu to change the permitted rating levels.

After changing channels or devices, there may be a delay of up to five seconds before the V-Chip lock takes effect.

Figure 22. V-Chip Menu

Chapter 5: Using the TV Menu

Setting V-Chip Options

1. Highlight the V-Chip icon on the V-Chip Lock menu and press ENTER to open the V-Chip menu.

2. Press ADJUST or to select On or Off.

3. If you selected On, press ADJUST to move to the TV Rating box.

4. Press ADJUST or to select the TV rating level you want to allow.

5. Press ADJUST to move to the TV content categories.

• Press ADJUST or to move between

categories.

• Press ENTER to add check marks to the TV

content categories you want to block.

6. Press ADJUST to move to the Programs Not Rated box. Press ENTER to add or delete a check mark to allow or block programs that are not rated.

NOTE: Use care when choosing to block unrated programming. News programs and emergency bulletins carry the “None” or “NR” (Not Rated) V-Chip rating, and these are blocked with this option active.

7. Press ADJUST to move to the Movie Rating box. Press ADJUST or to select the movie rating level you want to allow. See the next page for detailed information on rating guidelines.

8. To set the time of day when these restrictions will be in effect, press ADJUST to move to the Start box. To set the time:

a. With the highlight on the hour number, press

ADJUST or repeatedly to change the hour. You can also just press and hold to change the hour.

b. Press ENTER to move the highlight to the

minutes.

c. With the highlight on the minutes number, press

ADJUST or repeatedly to change the minutes. Just press and hold to move quickly through the numbers.

d. Press ENTER to move the highlight to the am/

pm option. Press ADJUST or to make a selection.

9. Press TV MENU to save the settings and close the menu.

The V-CHIP Button

Press the V-CHIP button on the remote control to turn the V-Chip lock on and off without going through the menu. A screen will appear prompting you for your pass code. To change V-Chip settings, you must open the V-Chip Lock Menu and then open the V-Chip menu.

Lock by Time

Lock by Time allows you to entirely block use of the TV during specified hours. During the lock time, you must use your pass code to view the TV. To lock the TV by time:

1. Press ADJUST or to select On or Off for Lock by Time.

2. Press ADJUST to move to the Lock Time box. a. With the highlight on the hour number, press

ADJUST or repeatedly to change the hour. You can also just press and hold to change the hour.

b. Press ENTER to move the highlight to the

minutes.

c. With the highlight on the minutes number, press

ADJUST or repeatedly to change the minutes. Just press and hold to move quickly through the numbers.

d. Press ENTER to move the highlight to the am/

pm option. Press ADJUST or to make a selection.

To make Lock by Time active 24 hours a day, set the Lock and Unlock Times to the same time.

Bypassing V-Chip Lock and Lock by Time

If you try to watch blocked programming, a notice appears prompting you for a pass code. To use the TV:

• Input your four-digit pass code and press ENTER.

• Change to a channel airing an allowed program or change to another device.

If you try to use the TV when it is locked by time, a similar screen appears, prompting you for your pass code.

To reactivate the V-Chip lock or TV lock by time after using the pass code, power the TV off and then on.

NOTE: To make the V-Chip restrictions active twentyfour hours a day, make the V-Chip Start and Stop the same time.

Chapter 5: Using the TV Menu

Audio/ Video Menu

Figure 23

Figure 23. Audio/Video Menu, Settings

A/V Memory Reset

A/V Memory Reset allows you to select the device which

will have the A/V Settings returned to the original factory settings. To return a device’s memory to the original factory settings, select the device and then press ENTER.

Settings

Each device has its own A/V memory. Select the device in A/V Memory Reset, then select Audio or Video to adjust the device’s individual settings. Press ENTER, the menu is removed, and the individual settings are displayed.

Use the AUDIO and VIDEO buttons on the remote control to change settings, as these options are not accessible from this screen.

Use ADJUST or to select the individual settings for adjustment. Use ADJUST or to adjust. For descriptions of the individual A/V settings, see pages 78–79.

Video Mute

Video Mute lets you display a blue background when no signal is being received on Inputs 1-2, Component 1-2, HDMI Inputs 1-2, and PC.

Chapter 5: Using the TV Menu

A/V Setting Descriptions: Audio

NOTE: The effects of the Audio Settings of Bass, Treble,

Balance and Surround affect the sound heard through the display’s internal speakers only.

Using the AUDIO Button on the Remote Control

To adjust individual Audio settings directly with the

remote control:

1. Press AUDIO to cycle through the available settings.

2. Press ADJUST or to adjust the setting. After 5

seconds of inactivity, the setting display will disappear.

Analog and Digital Audio Setting

A slider will display on-screen for most settings. When

the slider is displayed it has a numeric value, where 63 is the maximum, 31 is the mid-point and 0 is the minimum.

◊ Bass

Enhances or reduces low-pitch sound.

◊ Treble

Enhances or reduces high-pitch sound.

◊ Balance

Adjusts the level of sound between the left and right

speakers.

◊ Surround

Creates simulated stereo and surround effects

through the display’s internal speakers. Your

choices are:

• Off: No surround effects.

• Surround Sound: Will create a simulated surround effect when watching a stereo program.

• Simulated Stereo: Will create a simulated stereo effect when watching a non-stereo program.

Analog-Only Audio Settings

◊ Listen to

Determines how your media center will receive a broadcast audio signal and play back the sound you hear. Your choices are:

• Stereo: Default setting. Will play stereo broadcasts in stereo and mono broadcasts in mono. The word “Stereo” will be displayed

when you tune to a channel broadcasting stereo.

• SAP (Second Audio Program): Additional monaural sound track that you cannot hear during normal TV viewing. The SAP signal might be related to the program you are watching, such as a sound track in a foreign language, or unrelated to the program you are watching, such as a weather report. If a SAP signal is broadcast, the letters “SAP” will be displayed when you tune to the channel.

• Mono: Reduces background noise and should be used when receiving a weak stereo audio signal. All audio will be played mono with this setting.

Listen to is not available for devices connected to the video inputs, component inputs or 1394 devices.

◊ Level Sound

Turn On or Off to automatically equalize the volume level of programs containing significant

level differences from one segment to another (for

example, regular programming to commercials). To

receive the best fidelity with music programs, you

can turn this setting to Off.

Digital-Only Audio Settings

◊ Language

Determines what possible language you will hear.

Your choices are:

• English

• French

• German

• Italian

• Portuguese

• Spanish

• “Other”

◊ Level Sound

Automatically reduces loud passages and boosts

soft passages to a more uniform loudness. When connecting to an A/V receiver, set level sound to OFF and turn the display’s internal speakers off to

send full dynamics to the A/V receiver.

This feature only works with Dolby Digital sources.

Other digital audio formats do not offer this dynamic

range control. In these cases, no effect will be

heard when changing the level sound setting.

Chapter 5: Using the TV Menu

A/V Setting Descriptions: Video

Using the VIDEO Button on the Remote Control

To adjust individual Video settings directly with the

remote control:

1. Press VIDEO to cycle through the available settings.

2. Press ADJUST

seconds of inactivity, the setting display will disappear.

Video Settings

◊ Contrast

Provides a slider to adjust the white-to-black level.

Low contrast shows a variety of shades in darker images, while high contrast shows darker images more uniformly black and makes colors appear more vibrant. In most home lighting situations, a medium contrast looks best. High contrast is good for brightly lit environments.

◊ Brightness

Provides a slider to adjust the overall brightness of

the picture.

or to adjust the setting. After 5

◊ Backlight

Use to manually adjust the contrast of the PC screen

image.

NOTE: A slider will display on-screen for most settings. When the slider is displayed it has a numeric value, where 63 is the maximum, 31 is the mid-point and 0 is the minimum.

NOTE: For PC video settings, see Chapter 6.

◊ Sharpness

Provides a slider to adjust the detail and clarity.

◊ Color

Provides a slider to adjust the color intensity.

◊ Tint

Provides a slider to adjust the proportion of red to

green.

◊ Video Noise

Use to reduce minor noise (graininess) in the

broadcast received on Ant-1 and Ant-2, Inputs 1 and 2, and Component 1 and 2. Use standard with good quality signals.

◊ Film Mode (Auto) - On or Off

On is the automatic setting and will automatically

detect and apply film decoding correction for signals that originated on 24 frames per second film cameras and then were converted for broadcast to 30 frames per second video.

When the original signals originated on 30 frames

per second video cameras, the On setting will automatically apply video decoding, the same as used with the Off setting. Try the Off setting when the TV seems to have difficulties and adds too many jagged edges to the images.

Film Mode is not effective for progressive scan

(480p) devices, and high definition signals.

Chapter

Connecting and Using a PC

Connecting a PC to the Display ............................. 82

Setting PC Resoluiton PC Display Formats PC Video Settings Supported PC Timings

..................................... 84

...................................... 85

.................................... 83

................................... 85

Chapter 6: Connecting and Using a PC

Connecting a PC to the Display

Figure 1. A 15 pin PC monitor cable and an audio video cable is required. These are not included with the TV.

To connect a PC to the display (audio and video), do the following:

1. Connect a VGA video cable (purchased separately) from the PC to the VGA port on the rear panel of the display. Refer to the Supported PC Timings table on page 85.

2. Connect a Stereo Mini audio cable (purchased seperately) from the display rear panel to the PC (the Headphones terminal can be used for this purpose).

Note: The display’s PC video input is only compatible with VGA, SVGA, XGA, or SXGA resolutions.

If your PC has digital audio output, connect that terminal to a digital input of your digital A/V receiver, if available.

The HDTV (display and media center) only supports analog PC audio.

3. Add the device (PC) in the NetCommand® menu.

4. Select the PC through the Device Selection menu.

6)$%//54

!5$)//54

%JTQMBZ3FBS1BOFM





1$3FBS1BOFM XJUI7JEFP0VUQVU BOE"VEJP0VUQVU

Figure 1. Connecting a PC to the Display

IMPORTANT:

Be sure to connect a VGA cable to the display PC (video) Input, and, if applicable, a stereo mini cable to the PC Audio Input. Otherwise, you will not be able to access PC Inputs after wall-mounting. The media center does not have PC inputs.

BEFORE MOUNTING THE DISPLAY TO A WALL

Chapter 6: Connecting and Using a PC

Setting PC Resoluiton

Figure 16

For the correct screen resolution (pixels), while the PC is displayed on screen, use the PC’s Control Panel settings, as shown below (for most PC’s). Your display can display VGA, SVGA, XGA, and SXGA refresh rates.

1. In the PC’s “Start” menu, select “Settings”.

2. Select “Control Panel”.

3. Select “Display”.

4. Select the “Settings” tab.

5. Depending on your PC, use either the Screen Area slider or the Screen Resolution slider to adjust the resolution.

You may need to restart your PC for this change to take effect.



Figure 16. Selecting VGA resolution for a PC









Chapter 6: Connecting and Using a PC

PC Display Formats

LT-3280 Display

PC Video Signal

VGA (640 x 480)

SVGA (800 x 600)

XGA (1024 x 768)

WXGA (1280 x 768)

Displayed Format

1366 x 768

LT-3780 Display

PC Video Signal

VGA (640 x 480)

SVGA (800 x 600)

XGA (1024 x 768)

WXGA (1280 x 768)

Displayed Format

1920 x 1080

SXGA (1280 x 1024)

PC720P (1280 x 720)

(1360 x 768)

1366 x 768

SXGA (1280 x 1024)

PC720P (1280 x 720)

(1360 x 768)

1920 x 1080

1920 x 10801920 x 1080

Chapter 6: Connecting and Using a PC

PC Video Settings

Press the VIDEO key on the remote control repeatedly to cycle through the Video options to the one you want to change. Use ADJUST to change settings.

◊ Contrast

Manually adjusts the contrast of the PC screen image.

◊ Bightness

Manually adjusts the brightness of the PC screen

image.

◊ Back Light

Manually adjusts the contrast of the PC screen image.

◊ Video Clock

Manually adjusts the PC clock frequency.

◊ Horiz Res (Horizontal Resolution)

Manually adjusts the horizontal size of the PC screen

image.

◊ Vert Res (Vertical Resolution)

Manually adjusts the vertical size of the PC screen

image.

◊ HorizPosition (Horizontal Position)

Manually adjusts the horizontal position of the PC screen image. This selection will override the Auto Position selection.

Supported PC Timings

Resolution Horizontal Vertical LT-3280 LT-3780

1 640 X 480

(VGA)

2 37.86kHz 72Hz Expanded Expanded

3 37.50kHz 75Hz Expanded Expanded

4 800 X 600

(SVGA)

5 48.08kHz 72Hz Expanded Expanded

6 46.88kHz 75Hz Expanded Expanded

7 1024 X 768

(XGA)

8 56.48kHz 70Hz Expanded Expanded

9 60.02kHz 75Hz Expanded Expanded

10 1280 X 768

(WXGA)

11 47.78kHz 60Hz Expanded Expanded

12 60.29kHz 75Hz Expanded Expanded

13 1280 X 1024

(SXGA)

14 80.00kHz 75Hz Comp. Expanded

15 1280 X 720 44.44kHz 60Hz Expanded Expanded

16 44.77kHz 60Hz Expanded Expanded

17 56.46kHz 75Hz Expanded Expanded

18 1360 X 768 47.37kHz 60Hz Expanded Expanded

19 47.72kHz 60Hz Expanded Expanded

20 60.29kHz 75Hz Expanded Expanded

21 1920 X 1080 66.59kHz 60Hz N/A 1 to 1

31.47kHz 60Hz Expanded Expanded

37.88kHz 60Hz Expanded Expanded

48.36kHz 60Hz Expanded Expanded

47.40kHz 60Hz Expanded Expanded

63.98kHz 60Hz Comp. Expanded

◊ VertPosition (Vertical Position)

Manually adjusts the vertical position of the PC screen image. This selection will override the Auto Position selection.

◊ Fine Detail

Manually adjusts the flicker (clock phase) of the PC

screen image. This selection will override the Auto Position selection.

◊ Auto Position

Press ENTER on the remote control to automatically center the PC screen image.

NOTE: All timings in the table above are in Expanded Mode (expanded from the resolution of the PC video signal), except for the following:

◊ #13 and #14 “Comp.” The PC video signal resolution

has been compressed.

◊ #21 N/A This timing is not supported for this display.

◊ #21 “1 to 1” The PC signal resolution is the same as

the displayed resolution.

Chapter

Troubleshooting and Support

Troubleshooting ....................................... 88

Using the System Reset Button Using the Reset Menu Support

.............................................. 92

.................................... 92

............................. 92

Chapter 7: Troubleshooting and Support

Troubleshooting

Problem Possible Solution

1. When the HDTV is turned on for the first time, the NetCommand WELCOME screen does not appear (see figure 1, page 36).

2. The HDTV remote control does not work. • Check that the batteries are installed correctly.

3 The media center takes several seconds to

respond.

4. Cable provider needs information to start CableCARD™ service.

5. You cannot access a channel. • Use number keys instead of CHANNEL up/down.

6. On-screen displays appear each time you change a function.

7. You cannot program the media center to turn on automatically (timer function)

8. There is no sound even when the volume is turned up.

9. NetCommand unable to learn specific device keys.

• Check to make sure the media center and the display are connected using both MonitorLink™ cables (A/ V and Control).

• See Essential MonitorLink™ Connections in Chapter 2 for complete instructions.

• Check that the selected switch is set to CABLE/DBS/DTV.

• Be within 20 feet of the media center when using the remote control. Program the remote control to operate the media center (Appendix H).

•

• It is normal for digital channels to take longer to tune in.

• Press ENTER after a channel number to avoid delays.

• Use a 4 digit number for an over-the-air digital channel

• Use a 6 digit number for cable digital channels

• On the remote control, press TV MENU and then enter the numbers 999 to display the Host ID and CableCARD™ ID information.

• Be sure the channel you want to view is in memory. See page 69.

• Check that the media center is turned to the correct device or antenna for that channel, by pressing the DEVICE button.

• Make sure the V-Chip lock is off.

• If unable to tune to a digital channel, tune to the physical channel

first.

• This is part of normal TV operation.

• The media center may be locked.

• The clock may not be set.

• Check audio source in Device Menu.

• Check to see if the MUTE button is on.

• The media center’s “Listen to:” setting may be set to SAP.

• If you are listening through a DVI device, check that the analog audio

has been connected to the media center and your DVI device.

• Device does not use IR format for remote control signal. ITT and

RF formats cannot be learned.

• Room lighting may affect the signal. Have the remote very close

(6 inches or less) to the display during Learning.

location of the Learning IR sensor.

• If using a Mitsubishi remote control, make sure the slide switch is not

set to the CABLE/DBS/DTV position.

• Some, but not all, device key functions can be learned by

NetCommand. For example, POWER and PLAY may be learned, but other functions may not.

• The signal from the remote control may not be strong

enough. Insert fresh batteries and try Learning again.

10. You have forgotten your V-Chip passcode. • See Appendix C, Bypassing the V-Chip Lock.

See page 10 for the

11. PIP does not display a picture. • Make sure the V-Chip lock is off.

• Not all inputs can be displayed as a PIP.

12. Digital channels do not appear in PIP/POP. • Normal PIP/POP operation.

13. You cannot see a picture when playing a VHS tape.

• Open the Review screen and verify that the input for the current VCR as listed in NetCommand is the same as the physical connection.

• Display the Device Selection menu and select the correct VCR.

• Check your VCRs owner’s guide for further trouble shooting.

Chapter 7: Troubleshooting and Support

Problem Possible Solution

14. V-Chip is not working. • Make sure that V-Chip is On.

• If V-Chip Hours are currently set to disable the V-Chip lock, the V-Chip will not block programming.

15. The media center will not turn on after being plugged in.

16.

After a power outage (or after the media center power cord was accidentally unplugged), the blue light on the front of the media center starts to blink.

17. The media center turned itself Off and the blue light on the front panel starts to blink.

18. Media center functions do not respond to the remote control or to front panel control and will not Power Off.

• If blue light on front panel is blinking, wait for at least one minute for the light to turn off, then press Power again.

• This is normal; the media center is re-intitalizing.

• Wait for at least one minute for the light to turn off, then press Power.

• Momentary power fluctuation caused the media center to turn off to prevent damage. Wait for the blue light to stop flashing and turn On again.

• If the media center does not stay turned On, use the System Reset button. If this happens frequently, obtain an AC line power conditioner/surge protector.

• Use the System Reset button as explained at the end of this section.

Name options are not available for some channels

19.

20. When viewing a stopped VCR, white lines are rolling on the screen.

21. When a Device is selected from the Device Selection menu, the screen is blue (no signal source).

22. The Device does not respond to button presses from the remote.

23. The A/V Receiver is the selected audio source but there is no sound.

• Only memorized analog channels can be named.

• Turn off video mute for the VCR.

• Begin playing the tape.

• Change the VCR input to the antenna input.

• Make sure the selected device is turned on.

• From the Edit NetCommand® menu select Review. Verify that the inputs are actually connected to the media center . If they are not, either change the physical connections on the rear panel, or select Change on the Edit NetCommand menu to change the media center NetCommand settings for the connection screen for each device.

• Remote has not been set up for NetCommand

• The incorrect manufacturer was selected during setup. Select Change from the Setup menu and then the device to display the manufacturer selection. Change if necessary.

• The device is not supported and keys have not been learned.

• The requested function is not supported by NetCommand. Verify that the function is supported or keys are learned.

• The IR emitter is incorrectly placed. Make sure the IR emitter is facing the IR sensor in the device.

• The IR emitter is not plugged into the IR emitter Output NetCommand.

• The IR emitter is facing the display, causing double signals. Be sure that the IR emitter cannot send to the display.

• Check to see if the A/V Receiver power is turned on. After the power is turned on, redisplay the Device Selection menu and press ENTER to allow NetCommand to correctly select the A/V Receiver input.

• From the NetCommand Menu select Review. Check the Review screen to see if the A/V Receiver inputs and device correspond to the actual connections on the A/V Receiver. If they do not match, either change the actual connections, or select Change on the Edit

NetCommand menu to change the AVR input on the Connection screen.

• Verify the connections and NetCommand setup for the A/V receiver and the desired source device, if any.

From the NetCommand menu, select Review. Check the Review screen to

see if the A/V Receiver inputs and device listed correspond to the physical connections on the A/V Receiver. If they do not match, either change the physical connections or change the NetCommand setup. To change the NetCommand setup, make the audio source TV Audio and select a source device other than the one you want to change. Next select the Change option on the Edit NetCommand menu to change the A/V receiver input for the device on the Connection screen.

use.

Chapter 7: Troubleshooting and Support

Problem Possible Solution

24. The TV Audio icon or A/V Receiver icon is grayed out and not selectable.

25. Devices are grayed out in the Device Selection menu or the PIP Selection menu.

26. Cannot see the A/V Receiver menu. • The A/V Receiver is not connected to any input of the media center.

27. Screen is black when trying to view digital channels or IEEE 1394 device.

28. The REC button is not working, or, on the Transport menu the record key is grayed out and not available.

29. Excessive digital artifacts. • The IEEE 1394 cable is too long (15 feet between devices is the

30. DVCR analog/digital problems. • If the tape is currently playing but no picture displays, there may be a

31. D-VHS recordings for digital cable have dropouts (loss of picture or sound), or no playback.

32. There is no audio and video from the IEEE 1394 device.

33. The IEEE 1394 Device is not listed in the Device Selection menu.

34. The IEEE 1394 device cannot be selected. • The device may be busy, either recording or a peer-to-peer

35. DEVICE MENU button does not display a menu. • The IEEE 1394 device does not provide a menu.

• Select the Change setting from the Edit NetCommand menu, and then select the device (for example VCR). Once the Connection screen is displayed, check if the audio checkbox is selected for the TV input and/or AVR input.

• Verify the connections and NetCommand setup for the A/V receiver and the desired source device, if any. See the instructions for item 23, previous page.

• A recording is in progress requiring the use of Monitor Out. Cancel

the recording to select the device.

• Digital channels and media cards cannot display in the PIP or POP.

To check the A/V Receiver menu temporarily plug into an unused input of the media center. Then select Review from the NetCommand Menu, turn the input On to view the A /V Receiver menu.

• The PerfectColor™ color balance has been incorrectly set. Use the

Setup menu to reset the color balance.

• The device does not support recording, such as a DVD player.

• Recordings can not be initiated from the Transport menu when

using an IEEE 1394 device. Press REC instead. The Record menu displays allowing setup of a recording.

maximum length).

• There may be a slow device in the middle of the IEEE 1394 network.

Move the slow devices to the end so that connections for faster devices do not pass through them.

mismatch of the media with the display. Press DEVICE to display the Device Selection menu. Press ENTER for the DVCR device. If digital is selected, try analog, or if analog is selected, try digital.

• Digital cable signals on IEEE 1394 can exceed the data rate

standards supported by DVCR.

• The device is not turned on - turn the device power on.

• No media (tape or disc) is inserted into the device.

• The media is blank (has no recording).

• The play command failed - Try pressing play again on the device’s

remote control or front panel.

• The device is already in use (for example: the device is currently

recording).

• The source is copy-protected or violates copy protection.

• The device’s digital video signal is not supported by the TV, such as

DV video, common with camcorders. Use analog connections instead, if available.

• The device is not an audio/video device.

• Too many other devices are already communicating over IEEE 1394.

Remove or stop some devices and try again.

• The device is unchecked in the Review screen. Select the

NetCommand menu. Through Review, verify the device is checked.

• The IEEE 1394 plug is disconnected or loose.

• The IEEE 1394 Device has not been powered On. Turn on.

• The device has not been discovered.

• The device is not an Audio/Video device.

connection has been established. Cancel the recording or peer-to-peer connection.

• The TV cannot support IEEE 1394 menus. See page 32.

Chapter 7: Troubleshooting and Support

Problem Possible Solution

36. All IEEE 1394 devices disappear. • The connected devices must not be in a loop that returns to the media center. Make sure a device is connected at the end.

• Disconnect all the cables and devices from the TV. Replace them one by one to locate the problem device or cable.

• Use System Reset (front control panel).

37. Cannot rediscover a deleted IEEE 1394 device • The device has been disconnected. Plug it in.

• The device is unchecked in the Review screen. Select NetCommand from the Main menu, then select Review. Check the device.

• Remove IEEE 1394 plug. Go to the Edit NetCommand menu. Delete the IEEE 1394 device. Plug the device in again so it can be discovered again.

38. An IEEE 1394 device has been plugged in but

does not appear in the Device Selection menu (not discovered).

39. Cannot record to or from the IEEE 1394 device,

including Dub recordings.

40. Cannot control the IEEE 1394 device from the

Transport Menu.

• The IEEE 1394 connection to the media center or another device is not secure or is loose.

• The IEEE 1394 device is not powered on.

• A device in the IEEE 1394 chain is not powered on - turn on all the devices.

• The device discovery can take as long as a minute to initiate.

• IEEE 1394 cable is too long (maximum of 15 feet between devices).

• The IEEE 1394 device uses an incompatible protocol and will not be discovered

• To initiate a recording to IEEE 1394 device press the REC key. The Record menu displays allowing setup of the recording.

• The source device for the recording is not powered on.

• When dubbing, the destination device for the recording is not powered on.

• The wrong media, (analog tape for digital recording, or digital tape for the analog recording) is in the device.

• Either the program is copy protected, or if there are multiple subchannels and one of the programs (not necessarily the program requested) is copy protected.

• The program has already been recorded once and the copy protection only allows one recording.

• Unapproved source device for copy protected material.

• The recording device can not decode the copyright signal included in the signal source (try another device if available).

• The playing device (for dubbing) does not support copyrighted material.

• Source for recording is copyrighted.

• Too many IEEE 1394 devices in network. Insufficient bandwith available. Disconnect unused devices.

• Source Device has higher speed (S 400) than record device. If possible, reverse devices, play in the slower device and record in the faster device.

• Device may not support the command.

• Selected function is gray (such as Record for a DVD, which does not support the Record function).

41. When ChannelView™ list is displayed,

information appears incomplete.

42. Program to be recorded was correctly selected

from ChannelView, however, incorrect program was recorded.

43. Incomplete ChannelView program recorded. • Recording device may have lack of space availability and there is not

• Available information is sent from the broadcaster or cable provider. No other data is available.

• The broadcaster supplied program information that was incorrect and/or was changed after a recording was added to the Record List.

enough blank space to make a full recording.

Chapter 7: Troubleshooting and Support

Problem Possible Solution

44. ChannelView program recording failed. • Connection and compatibility issues with IEEE 1394 (FireWire®) digital devices. This may include too many Firewire devices in use at one time, or the recording device not understanding the record command.

• The media center lost power long enough to lose current clock time.

• Analog VCR power was left Off.

45.

After pulling out a memory card during playback the media center is not responding,

46. Can’t see a thumbnail picture in the JPEG

menu, or can’t see a track/song name in the Playlist menu.

• Press STOP or wait until playback is complete before removing media card.

• The image or audio

file does not meet file standards for playback.

Using the System Reset Button

If the media center doesn’t respond to either the remote control or the front panel controls or will not power off, press the SYSTEM RESET button on the front panel with a pointed item such as the point of a ball point pen or end tip of a paperclip.

The media center will turn off and the blue LED (light

next to the Power button) will flash quickly for about one minute. When the blue LED stops flashing, you may turn on the media center again. The changes you made while the media center was most recently on—before you used the SYSTEM RESET button—may be lost. However, the changes you made previously will not be lost—only those changes since the last power On may be lost when the system reset button is pressed. All other settings will be retained.

Using the Reset Menu

1. Press Device Menu on the remote control, and select a device.

2. Press TV Menu followed by the “1, 2, 3” buttons.

3. Use the Reset Service Menu to reset the media center.

Read on-screen warnings before proceeding, as some user data or settings may be erased.

Reset the System Defaults

CAUTION : All settings, except V-Chip, will be reset to the original factory defaults.Service and Support

If you are unable to correct a problem with your display or media center, consult your Mitsubishi dealer or a Mitsubishi Authorized Warranty Service Center.

Support

Telephone: 800-332-2119

Email: MDEAservice@mdea.com

Website: www.mitsubishi-tv.com

• DO NOT adjust any controls other than those described in this owner’s guide.

• DO NOT remove the protective rear cover of your display or media center.

Menus not described and shown in this owner’s guide are designed for factory use and for authorized service personnel. Damage caused to the display or media center by non-authorized changes or changes to these menus made by non-authorized persons are not covered under warranty.

Appendices

Appendix A: Specifications ................................ 94

............................ 101

Appendix G: TV Display and DVD Formats Appendix H: Remote Control Programming Codes Appendix I: Device Control with NetCommand

................... 96

...................... 97

.................... 99

.............. 100

..................... 102

............... 104

® ................ 107

Appendix J: NetCommand® Specialized Device Keys ............ 109

Appendix K: Changing the Color Temperature of the Display Appendix L Cleaning

.................................... 111

....... 110

Appendix A: Specifications

Software Updates: From time to time, Mitsubishi may offer software updates to expand the features or operation of

this media center. When these updates are available they will be announced on our web site, Mitsubishi-tv.com. If you return your Owner’s registration card, with your model and serial number, you may receive written notification of available software updates.

Display and Media Center Specifications

Channel Frequency Reception Over-the-Air: VHF 2 - 13, UHF 14 - 69

Analog Cable: 1 - 125 Digital Cable: 1 - 135

Channel Type Over the Air: Analog NTSC, Digital ATSC with sub-channels

(all 18 video formats) Cable: Analog NTSC (non-scrambled) Digital QAM 64 and 256 with sub-channels (non-scrambled) CableCARD™: Authorized scrambled and non-scrambled digital channels

Note for Digital Channels: The channel numbers displayed on screen are determined by the broadcaster or cable company and can vary from the standard frequency number. If there is no channel number information included from the broadcaster or cable company, then the TV will create a channel number based on the frequency number as the main channel number and the program number as the sub-channel number. When using an authorized CableCARD, the channel numbers are determined by the cable company.

Inputs

Antenna/Cable input, Qty 2 F connector, 75 ohm

HDMI (digital video/audio), Qty 2 Signal Type

Video/S-Video, Qty 2 each

Signal Type

Component Video (Y/Pr/Pb), Qty 2 sets

Signal Type

PC Input (RGB), Qty 1 Signal Type

Audio Inputs, Qty 6 pair RCA Pin Plug 500mV (full scale), 43kohm

MonitorLink™ Control RS-232C NOTE: Must connect to MonitorLink™ RS-232C terminal on display.

HDMI standard connectors (on media center) HDMI standards for digital audio and video. Not intended for use with personal computers

Video: RCA Pin Plug, 1.0 V p-p, 75 ohm S-Video: Four Pin DIN Plug Y: 1.0 Vp-p 75 ohm C: 0.286 Vp-p (burst signal), 75 ohm NTSC 480i only

RCA Pin Plug (EIA-770.3 Standard Levels and Timing) Y: 1.0 Vp-p (includes sync), 75 ohm Pr: 700 mVp-p, 75 ohm Pb: 700 mVp-p, 75 ohm EIA-770.1 & EIA 770.2 480i, 480p, EIA 770.3 720p and 1080i

Mini-D Sub, 15 pin (Note: located on display rear panel) VGA, SVGA, XGA, WXVGA, SXGA

(video standards)

Outputs

Video

Monitor Output, Qty 1 Signal Type

Video: RCA Pin Plug 1.0 Vp-p, 75 ohm NTSC 480i only for recording only

Audio

Monitor Output, Qty 1 pair RCA Pin Plug, 500 mV rms + 200 mV (full scale) for analog sources.

1.5 V + 0.5 V (full scale) for digital sources.

Audio Line Out, Qty 1 pair RCA Pin Plug, 500 mV rms + 200 mV (full scale) for analog sources.

1.5 V + 0.5 V (full scale) for digital sources. Fixed audio ouput when connected to A/V Receiver.
