Mitsubishi Electronics DX-TL5000E User Manual

DIGITAL RECORDER

INSTALLER’S MANUAL

MODEL

DX-TL5000E

ENGLISH

OTHERS

SLD Security & Communications The Old Forge, Ockham Lane, Ockham, Surrey GU23 6PH England Phone +44.1483225633 · Fax +44.1483225634 sales@sld.co.uk · www.sld.co.uk

THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER.

1

Features

DX-TL5000E is a digital recorder that is equipped with HDD as its main memory and 16ch triplex multiplexer. Addition to these features, this system has a very sophisticated video signal and data processing technique that provides high quality picture, stable operation and reliability. The graphical user interface and pointing devices make the operation very easy and comfortable in live monitoring and also in the handling of data from recording to export. The system offers excellent performance and has features to suit many video surveillance applications.

Refresh rates of 800pps*/system

Thanks to the newly developed multiplexing circuit, every camera can be viewed at 50 pps refresh rate in all screen formats.

pps* : picture per second

Triplex

User can view live and playback images on the same monitor in all screen multi-split layouts without disrupting recording.

Dual Multiplexer Outputs

The DX-TL5000E has two video outputs (Output A / B), and both of the outputs can show single-screen, 4, 9, 10, 13 and 16 split-screen, Switched Cameras, Alarmed Camera in live mode and Recorded pictures. On Screen Menu are shown only on monitor Output A. It is also possible to view playback pictures of different cameras at the same time with these two video outputs.

Covert Camera Function

It is possible to hide pictures of selected cameras that are installed in sensitive areas and should only be viewed by authorized personnel. It can be switched by <Multiplexer Setting>.

GUI

MENU, GUI (Graphical User Interface), guides the operators to their desired menu pages quickly. If the users need additional information on MENU functions, just press the HELP key and instructions will appear on screen. The menu supports English, German, French, Spanish, Italian and Russian. Function keys on the front panel or USB mouse can operate the menu on the DX-TL5000E.

Recording rate up to 200 pps/system

Because of the new recording circuit and compression chip, the maximum recording speed is 200 pps in total, this means that the system can record pictures with speed of up to 12.5 pps on all 16 channels. With this speed recorded pictures are seen by the eye as real-time.

JPEG2000

The system uses JPEG2000 compression. JPEG2000 is the standard and ideal compression method for still pictures. Because pictures are compressed to a user defined file size one by one, the estimated recording time calculated by the system automatically is relatively exact. Special playback search functions and transmission over network also benefit from this compression method. File sizes for each picture quality are minimized to improve storage efficiency over previous models.

Individual Recording Setting

Recording speed and picture quality (picture file size) can be set for each camera individually, it is also possible to set alarm recording setting in addition to normal recording setting. By adjusting the recording speed and picture quality, it is possible to use HDD storage space efficiently.

Audio Recording

4ch audio inputs are optional.

Copy

The easiest way for users to make a copy of recorded picture data is to use the built in CD/DVD Drive on the DXTL5000E. Or, they can also use other digital media such as HDD, DVD(-R/RW)*, CD-R/RW* USB Memory etc… through Serial Bus Interface. It is also possible to connect SCSI devices through the optional SCSI interface or NAS (Network Attached Storage) through network.

DVD(-R/RW), CD-R/RW* : only one drive can be used (including built-in CD/DVD drive)

Cascading Connection

Cascading connection allows to users to view pictures and to hear sounds from multiple DX-TL5000E by operating just a master unit.

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

2

ENGLISH

Microsoft is either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

All other company and product names appearing herein are the property of their respective owners.

3

Caution and care

HEAVY OBJECTS SHOULD NEVER BE PLACED ON THE UNIT (E.G., MONITOR)

NEVER TOUCH OR INSERT ANY OBJECT INSIDE THE UNIT

Touching the inside of the cabinet or inserting foreign objects of any kind through the disc loading slot or ventilation holes not only creates a safety hazard but can also cause extensive damage.

PROTECT THE POWER CORD

Damage to the power cord may cause fire or shock hazard. If the mains cord is damaged, turn OFF the MAIN switch and carefully unplug the cord by holding the mains plug. If this unit is moved with the power on status, the built-in HDD may be damaged. Confirm that more than one minute have passed since the power cord and the connecting cords were disconnected, then move this unit. Make sure to take the disc out and close the disc loading slot.

UNPLUG THE POWER CORD DURING A LONG ABSENCE

Turn off the power and unplug the power cord during a long absence.

MAINTAIN GOOD VENTILATION

Do not obstruct the many ventilation holes on the unit. For maximum ventilation, leave some space around the unit and place the unit on a hard level surface only, and ensure it is not covered during use. Heavy objects should never be placed on the unit.

WHEN NOT IN USE

When not in use, always eject the disc and turn OFF the MAIN switch.

CABINET CARE

Never use petroleum-based cleaners. Clean with a soft cloth moistened with soap and water and wipe dry. PVC cables or leads should not be left in contact with the cabinet surface for long periods.

INSTALLATION LOCATION

For excellent performance and lasting reliability install in a location that is:-

1. Well ventilated, out of direct sunlight and away from direct heat.

2. A solid vibration-free surface.

3. Free from high humidity, excessive dust and away from magnetic fields.

4. Please ensure that the ventilation fan located on the unit’s back panel is not blocked.

UNSUITABLE LOCATIONS

Placing the unit in the following places might shorten the product life:

• Extremely cold places, such as refrigerated warehouses and ice houses

• Places where excessive hydrogen sulfide is likely to be generated, such as hot-springs areas

• Places or locations with salt air environment.

NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. DO NOT PLACE HEAVY OBJECT ON THIS UNIT. DO NOT STEP ONTO THIS UNIT. DO NOT PLACE ANY OBJECTS IN FRONT OF THE DISC LOADING SLOT.

The unit may drop or fall by losing its balance. It may cause injury or failure of the unit.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

THIS APPARATUS MUST BE GROUNDED.

MAINS LEAD CONNECTION

The mains lead on this Unit is fitted with a non-rewireable mains plug, incorporating a 5A fuse. If you need to replace the fuse, use a 5A fuse approved by BSI or ASTA to BS 1362, ensuring you refit the fuse cover. If the mains plug is not suitable for the sockets in your home, and you require to remove the plug, remove the fuse, cut off the plug then dispose of the plug immediately, to avoid a possible electric shock hazard. To refit a new plug, follow these instructions; Green-and-yellow: Earth, Blue: Neutral and Brown: Live. As the colours in the mains lead of this Unit may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows.

• The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol

• The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

• The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

or coloured green or green-and-yellow.

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

4

Notice about construction of the surveillance system using this unit

• This unit can be controlled by the external devices via RS-232C terminal or LAN terminal. This unit can also be used to control the external devices via external terminal, RS-422/485, or RS-232C terminal. Owning to these functions, this unit flexibly applies to the high grade security system, but the whole surveillance system may be affected by the malfunction of this unit or the external devices depending on the setting contents of this unit or the connection or combination between the external devices.

• When configuring a surveillance system using this unit, it is recommended to confirm first that this unit operates normally with the other devices connected or combined.

• It is recommended to copy or back up the important recorded contents to the other devices periodically.

• Damages arising out of any operational error of the surveillance system or loss of the recorded data or any other

damages because of any malfunction of this unit are not covered.

There may be cases when the unit’s built-in MOTION DETECTION function does not operate properly due to external condition or video input signal or other factors.

The user will not be indemnified for problems (e.g., recording failure or playback failure) that occur with either the unit or a connected device during operation. It is recommended that backups of important recordings are made regularly as a precaution against possible breakdowns and accidents.

Recordable time and product warranty

Continuous recordable time and the estimated time displayed on the menu screen is the continuous recordable time when operating this unit and is not the product warranty period. Furthermore, it is not the period that guarantees life time at the unit.

• This unit uses a built-in hard disk, which is a precision device. Please handle this unit with sufficient care.

• Do not subject this unit to vibrations or shocks. This may cause trouble specially when the power of the unit is turned on

or when the hard disk is being accessed, and sufficient care is required.

• Do not disconnect the power plug while the power of the unit is turned on or while recording or playing.

• For early detection of faults, we recommend that you request inspection once a year.

ENGLISH

The hard disk and cooling fan are not permanent items and will need replacement with time. When operated in an ambient temperature of 25 °C, it is recommended that both of the hard disk and fan are replaced every 30,000 hours. (This figure is only a guide, and should not be taken as a guaranteed lifespan of the products. Use the <Elapsed Operating Time> (System Menu

Service Info) as a guide to perform checkups.)

INSTALLATION LOCATION AND HANDLING

• Place this unit on the horizontal and stable place. If this unit is used on the unstable place, the unit may be damaged such as removal of the DVD/CD disc.

• Do not place this unit close to other equipment. The equipment and this unit have a bad influence each other and the pictures or audio of this unit may be distorted.

• When a monitor and this unit are placed vertically, the pictures may be distorted or DVD/CD disc may not be ejected.

• Do not let stick your hands into the disc loading slot. You may get your hand caught in the slot and may got injured. If you get

your hand caught, do not get out of the slot by force. Contact your dealer after turning off the power and disconnecting the plug.

DVD/CD DISC

• Do not use the disc cracked, deformed or repaired with adhesive. The disc may fly into pieces and cause injury.

• Do not touch the playback surface when holding the disc.

• When dew condensation occurs on the disk, wipe the surface off before use.

• Dirt such as fingerprints or dust causes the deterioration of the picture quality and audio quality. Gently wipe the DVD/CD

disc from the center to the outside with a soft cloth.

• When the disc is very dirty, soak a soft cloth with water and screw water of it, wipe off the dirt lightly, then wipe with a dry cloth.

• Do not use solvent such as benzine and thinner, a record cleaner, and static-stopper. They may damage the disc.

• Do not use the disc described below. They may damage the disk itself or this unit.

Discs on which a piece of paper or sticker is put, or a disk damaged. Discs which the label is peeled or a disk with oozing Discs cracked, deformed, or repaired with adhesive

• Store the disc in the specified casing, avoiding the following places. Places where it will be subjected to direct sunlight Places with excessive dust. Places where it will be subjected to high temperatures or high humidity.

• The movie software on the market or privately recorded picture cannot be played back on this unit. Only the picture recorded on this unit can be played back.

MAINTENANCE OF THE LENS FOR RECORDING/PLAYBACK (LASER PICKUP)

• When any dust adheres on the lens for recording/playback, the image may be distorted or the audio may skip. The normal recording or playback may become impossible. Ask your dealer for cleaning. The commercial lens cleaning disk may damage the lens. Do not use it.

5

Contents

Features ................................................................ 2, 3

Caution and care ..................................................4, 5

Contents................................................................ 6, 7

Flowchart .............................................................. 8, 9

Flowchart for connection and settings ............................ 8, 9

Major operations and their functions .............. 10-14

Front view ................................................................... 10, 11

Loading/Ejecting a DVD disc or CD .................................. 11

Front view (inside of the door) .......................................... 12

Rear view .................................................................... 13, 14

Connections ...................................................... 15-23

Precautions for installation ................................................ 15

Precautions for attaching or removing the HDD ......... 15

Connecting to CCTV camera, monitor, and sensor .......... 16

Alarm recording connection .............................................. 17

Cascade connection ......................................................... 18

Attaching or removing the HDD ................................... 19-21

When removing a HDD ............................................... 19

When attaching a HDD ......................................... 20, 21

Clamping the cables ......................................................... 22

Connecting to an analogue video cassette recorder ......... 22

Optional items ................................................................... 23

Recommended items ........................................................ 23

Attaching the optional board ............................................. 23

How to set the menus .......................................24-27

Setting the menus ........................................................ 24-26

How to set a menu with a mouse ................................ 24

Setting a mouse ..................................................... 24

Setting a menu with a mouse ................................. 24

How to set a menu with buttons on the unit ................ 24

Displaying a menu screen ........................................... 25

Closing a menu screen ............................................... 25

Selecting an item ........................................................ 25

Inputting numbers ....................................................... 26

Setting parameters ...................................................... 26

Symbols in the menus ....................................................... 27

Setup Wizard .................................................... 28, 29

Setup Wizard .............................................................. 28, 29

Menu chart .........................................................30-39

Menu chart ................................................................... 30-39

User Menu ............................................................ 30, 31

Setup Menu ............................................................ 32-36

System Menu ......................................................... 37-39

Search ............................................................... 40, 41

Selecting the search function ............................................ 40

Select Source Device ........................................................ 40

Search by Time and Date ................................................. 40

Search by Alarm List ......................................................... 40

Find data storage location ................................................. 40

Search by Book Mark ........................................................ 40

Search by Motion .............................................................. 41

Copy .................................................................. 42, 43

Copy Data to Copy A Drive/Set Copy A Drive ................... 42

Copy Data to Copy B Drive/Set Copy B Drive ............ 42, 43

Playback software ............................................................. 43

Copying the data of this unit to a video cassette .............. 43

Information/Audio .................................................. 44

Information ........................................................................ 44

Audio ................................................................................. 44

Protect Data ............................................................45

Protect Data ...................................................................... 45

Recording .......................................................... 46-50

Settings concerning normal recording and alarm recording

.......................................................................................... 46

Pre-alarm recording .................................................... 46

Set Recording Pattern A to D ....................................... 46-48

Alarm Input .................................................................. 48

Emergency Recording Setup ............................................ 49

Emergency recording .................................................. 49

Long pre-alarm recording ............................................ 49

Audio Recording Setup ..................................................... 50

Timer ................................................................. 51, 52

Overlapped timer settings ........................................... 52

Motion Det......................................................... 53, 54

Set Motion Detection Pattern A/Set Motion Detection

Pattern B ..................................................................... 53, 54

System ............................................................... 55-66

Time/Date Setting ............................................................. 55

Menu Language Selection ................................................ 55

Rear Terminal Setting.................................................. 56, 57

Mode Out Settings ...................................................... 56

Call Out Settings ......................................................... 56

Key Sound .................................................................. 57

Buzzer ......................................................................... 57

Password Setting ........................................................ 58, 59

SIMPLE LOCK ............................................................ 58

Activating the simple lock ....................................... 58

Releasing the simple lock ...................................... 58

PASSWORD LOCK............................................... 58, 59

Using “Operation control” of PASSWORD LOCK

(level 1 to 3) ........................................................... 58

Registering the PASSWORD ........................... 58, 59

Activating the PASSWORD LOCK ......................... 59

Releasing the PASSWORD LOCK......................... 59

Changing the PASSWORD .................................... 59

Changing the lock mode from PASSWORD LOCK to

SIMPLE LOCK ....................................................... 59

Multiplexer function related button operations/

operation table ............................................................ 60, 61

Camera number button operations ............................. 60

SPLIT buttons operations............................................ 60

SEQUENCE button operations ................................... 60

DIGITAL ZOOM button operations .............................. 60

The function of the SPLIT, SEQUENCE, DIGITAL

ZOOM, and camera number buttons .......................... 61

Multiplexer Setting ....................................................... 62-64

Output A Display Settings ........................................... 62

Output B Display Settings ........................................... 63

Alarm Display Setting .................................................. 64

Covert Camera Setting ............................................... 64

On Screen Display Setting .......................................... 65, 66

On Screen Information ................................................ 65

Camera Title................................................................ 65

Recorder Title.............................................................. 65

Monitor Output Adjust ................................................. 66

Audio Setting ..................................................................... 66

Reset to Factory Setting ................................................... 66

Menu Data ...............................................................67

Load Menu Data ............................................................... 67

Save Menu Data ............................................................... 67

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

6

COM/LAN .......................................................... 68, 69

RS-232C Setting ............................................................... 68

RS-485 Cascade Setting .................................................. 68

LAN B (Communication) Setting ................................. 68, 69

LAN A (NAS) Setting ......................................................... 69

PTZ Setting ............................................................. 70

PTZ Camera Configuration ............................................... 70

Configuration Check List ................................................... 70

Service Info ............................................................. 71

System Log List ................................................................ 71

Elapsed Operating Time ................................................... 71

Disk Information ................................................................ 71

Restore .................................................................... 72

Restore Data to Main HDD from Drive A/B/

Export Drive A/B Configuration ......................................... 72

Memory .............................................................. 73-75

Add/Remove HDD Device .......................................... 73, 74

Notes for using the external device ........................ 73

Attaching the HDD and setting the ID number ....... 74

The order of recording/playback when internal and

external HDDs are registered as the main device .. 74

Add/Remove DVD/CD Drive ............................................. 74

Data Management Setting for Main Memory .............. 74, 75

Recording Data Readout Setting ...................................... 75

Data Clear ............................................................... 76

Main Storage Memory ....................................................... 76

Copy A/Copy B .................................................................. 76

Other convenient functions ............................. 77-81

Cascade ............................................................................ 77

PTZ control ....................................................................... 78

Various playback functions.......................................... 79, 80

Playing still frames ...................................................... 79

Shuttle viewing/direct shuttle viewing ......................... 79

Shuttle hold ................................................................. 79

Frame-by-frame playback ........................................... 79

Reverse playback ....................................................... 79

High-speed fast-forward/high-speed rewind ............... 79

Changing playback intervals ....................................... 80

Simultaneous playback during recording .................... 80

Playback the latest recorded contents ........................ 80

Triplex playback .......................................................... 80

Registering the picture ...................................................... 81

Registering a book mark ............................................. 81

Picture copy ................................................................ 81

Functions of the unit in case of power failure .................... 81

Power failure compensation circuit ............................. 81

Power failure reset recording ...................................... 81

Log function when power failure occurs while the unit is in operation or the MAIN switch on the rear of the unit is

turned OFF .................................................................. 81

RESET button ................................................................... 81

Operation examples .......................................... 82-87

Operation example 1 ......................................................... 82

Operation example 2 ......................................................... 83

Operation example 3 ................................................... 84, 85

Operation example 4 ................................................... 86, 87

Basic operations ...............................................88-92

Basic multiplexer functions ............................................... 88

Multiplexer buttons ...................................................... 88

Basic manual recording .................................................... 89

Setting the recording rate and picture grade for normal

recording ..................................................................... 89

Basic playback .................................................................. 90

Basic search ............................................................... 91, 92

Search by Time and Date ........................................... 91

Search by Alarm List ................................................... 92

Communications by Web Browser ................ 93-101

Communications by Web Browser .................................... 93

The personal computer product requirements ............ 93

Connections ................................................................ 93

Login ........................................................................... 93, 94

Main Menu ................................................................. 94-101

Live Monitoring ............................................................ 95

Playback ............................................................... 96, 97

Time Search ........................................................... 96

Alarm List Search ................................................... 97

Image Search ......................................................... 97

Configuration Menu .............................................. 97-100

User Registration ............................................. 97, 98

Memo & Camera Titles........................................... 99

E-mail Setup ........................................................... 99

NAS Setup ........................................................... 100

Clock Setup .......................................................... 100

Logout ....................................................................... 101

Change Login User ................................................... 101

Recording time table.................................... 102, 103

Continuous recording time table ............................. 102, 103

HDD continuous recording time ........................ 102, 103

Without audio recording ....................................... 102

With audio recording ............................................ 103

Troubleshooting ........................................... 104, 105

Warnings and CALL OUT output ................ 106, 107

Warnings and their appropriate countermeasures .. 106, 107

Check sheet ...................................................108-127

Setup Menu .............................................................. 108-122

System Menu ........................................................... 123-127

Glossary ........................................................ 128, 129

Glossary .......................................................................... 128

Relation of recording operation to the number of

cameras and recording rate settings ............................... 129

Specifications ....................................................... 130

How to read this manual

• Viewing displays (Refer to this information when operating):

Reference information concerning operation

(Caution required):

Cautionary items concerning operation

(See reference page):

Reference item and page number

• Finding desired information

There is a “Contents” at the beginning of this manual. In addition, reference pages are indicated throughout this manual.

• Troubleshooting

Read Troubleshooting (pages 104, 105) for possible remedies to the problem.

• Menu settings

See Check list (pages 108-127) for available setting parameters for each menu.

ENGLISH

7

Flowchart

Flowchart for connection and settings

This is a flowchart of the example operation: Making connections of the terminal on the rear panel Setting the alarm area in the main device Making the initial settings Playback the recorded data Copying the data to a copy device.

Making an alarm recording with timer recording Searching recorded data using the alarm list

Connections

• Connections for camera, monitor, and sensor.

• Connection for the alarm recording.

See “ Connecting to CCTV camera, monitor,

and sensor” on page 16.

See “ Alarm recording connection” on page

17 and “ Rear view” on pages 13, 14.

Boot-up the unit

When not executing Setup Wizard:

See “ Setup Wizard” on pages 28, 29.

Only when the unit is turned on for the first time, the <Setup Wizard> screen is displayed automatically. It

is not displayed next time.

• Set the present time and HDD settings in each menu manually. (“ present time.“ Data Management Setting for Main Memory” on pages 74, 75. Set the alarm area.)

Time/Date Setting” on page 55. Set the

Recording

Connections

• Connections for camera, monitor, and sensor.

See “ Connecting to CCTV camera, monitor,

and sensor” on page 16.

• Connection for the alarm recording.

See “ Alarm recording connection” on page

17 and “ Rear view” on pages 13, 14.

Boot-up the unit

When executing Setup Wizard:

See “ Setup Wizard” on pages 28, 29.

Only when the unit is turned on for the first time, the <Setup Wizard> screen is displayed automatically. It

is not displayed next time.

• The language, present time, HDD configuration, and recording settings are set automatically by following the instructions in the menu.

Making the initial menu settings

• Setting the present time display mode.

See “ On Screen Information” on page 65.

• Setting the audio recording.

See “ Audio Recording Setup” on page 50 and

“ Continuous recording time table” on pages 102, 103.

Making the HDD settings

• Setting the repeat recording.

• Setting the remaining HDD capacity.

• Setting the CALL OUT.

• Setting the buzzer.

See “ Data Management Setting for Main

Memory” on pages 74, 75.

See “Low Memory Alarm Setting” on page 56.

See “ Call Out Settings” on page 56.

See “ Buzzer” on page 57.

Making the multiplexer settings

• Making the split screen settings.

• Making the sequence setting.

See “ Multiplexer Setting” on pages 62, 63.

Setting other various functions

• Setting the camera title/recorder title.

See “ Camera Title” and “ Recorder Title” on

• Setting the display mode.

• Setting the output signal of the unit status.

page 65.

See “ On Screen Information” on page 65.

See “ Mode Out Settings” on page 56.

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

8

Setting the motion detection

• Selecting the camera number.

• Setting the detection areas.

• Setting the sensitivity.

• Setting the minimum number of dots for starting the

motion detection operation.

• Setting the detection interval.

See “Motion Det” on pages 53, 54.

Setting the timer recording

• Setting the normal/alarm recording or pre-alarm recording.

• Setting the recording rate/picture grade for normal recording.

• Setting the recording rate/picture grade for alarm recording.

• Setting the motion detection recording.

• Selecting the camera selection during the alarm

recording and trigger for alarm recording.

• Setting the alarm recording time.

• Setting the pre-alarm recording time.

• Setting the PTZ camera preset.

See “ Set Recording Pattern A to D”

on pages 46-48.

• Setting the timer program.

• Setting the holiday.

• Selecting the timer program number.

• Making the timer recording settings.

• Selecting the day of the week.

• Selecting the start time.

• Selecting the end time.

• Selecting the program mode.

• Selecting the motion detection mode.

(• Selecting the special day of the week.)

See “Timer” on pages 51, 52.

Copy the data

• Setting the copy device.

See “ Add/Remove HDD Device” or “ Add/

Remove DVD/CD Drive” on pages 73, 74.

• Setting the copy function.

See “ Copy Data to Copy A Drive” or “ Copy

Data to Copy B Drive” on pages 42, 43.

ENGLISH

Timer recording is executed and completed

See “ Warnings and their appropriate

countermeasures” on pages 106, 107.

Searching the recorded data

• Setting the device to be searched.

• Setting the alarm list search.

See “ Select Source Device” on page 40.

See “ Search by Alarm List” on page 92.

The search is completed and the search result is displayed

Playback the search result

• Selecting the camera number to be played back.

• Selecting the split/sequence screen.

• Playback the recorded data.

• Selecting the playback speed.

See “ Multiplexer Setting” on pages 62, 63.

See “ Basic playback” on page 90.

See “ Various playback functions” on pages

79, 80.

9

Major operations and their functions

Front view

17

BUSY

PUSH

18

19 20 21

1 3 4 5 6 7 8 9 1011 12

1. POWER indicator

Illuminates while the MAIN switch on the rear panel is turned on and the POWER button is pressed. Turns off while the unit is in stand-by mode or MAIN switch on the rear panel is turned off. It takes about 1 or 2 minutes from pressing the POWER button to switch the unit to the stand-by mode. When the unit is in operational transition such as boot-up, the indicator flashes and other operations are not accepted.

2. REMOTE jack

Input connector for optional wired remote control.

3. ACCESS indicator

Illuminates during accessing to hard disk drive, or peripheral recording devices. Press the POWER button after the ACCESS indicator is turned off and “POWER OFF” is displayed on the LCD display.

4. COM (COMMUNICATION) indicator

Illuminates when establishing the communication with personal computer.

151413 162

10. COPY 1 indicator

Illuminates while performing copy A operation. Flashes when starting or ending the copy A operation.

11. COPY 2 indicator

Illuminates while performing copy B operation. Flashes when starting or ending the copy B operation.

12. REC/STOP button

Starts recording. The button lights up during recording. When pressing the button for more than 2 seconds, the recording stops and the light turns off. When pressing this button for more than 2 seconds during alarm recording, recording stops. During timer recording, recording will not stop even if the button is pressed.

13. SPLIT screen buttons (

Selects split screen to be displayed. Uses for the menu settings.

,,,,

)

10

5. ALARM indicator

Illuminates during alarm recording.

6. TIMER indicator

Illuminates during timer recording or timer recording stand-by mode.

7. LOCK indicator

Illuminates while simple lock or password lock is turned on.

14. SEQUENCE button

Uses when displaying the sequential screen.

TILT button

When pressing the button during PTZ mode, the angle of the camera adjusts to the upward direction.

15. PTZ (Pan, tilt, and zoom) button

Switches this unit to PTZ mode in order to control the camera connected.

8. M-DET indicator

Illuminates while the motion detection function is performed. Flashes during motion detection recording.

9. PRE ALARM indicator

Illuminates during pre-alarm recording. Also illuminates when the pre-alarm recording is set.

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

Camera control buttons

The following buttons control the camera when pressed during PTZ mode in the single screen display. Use the following buttons after pressing PTZ button.

CAMERA ZOOM button

Adjusts the camera zoom. turn JOG to the left

(wide) or right (tele) to adjust the

Press this button and then

camera zoom.

FOCUS button

Adjusts the focus of a camera. Press this button and then turn JOG to the left

(far) or right (near)

the focus.

IRIS button

Adjusts the iris of a camera. Press this button and then turn JOG to the left

(close) or right (open)

adjust the iris.

PRESET button

Presets up to 16 watching points. Press this button and then press the camera number button within 3 seconds to preset the points.

AUTO PAN button

Activates auto pan within the range between the preset watching points 1 and 2.

16. OUTPUT A/B button

Switches the multiplexer output between A and B. The light turns off when OUTPUT A is selected and lights up when OUTPUT B is selected. The playback and search functions are also switched between OUTPUT A and B.

TILT button

When pressing the button during PTZ mode, the angle of the camera adjusts to the downward direction.

17. Disc loading slot

Load the DVD disc or CD here to copy/back up the recorded data. The supported discs are: DVD-RW, DVD-R, CD-R, and CD-RW

OPEN/CLOSE button

Opens or closes the disc loading slot.

to adjust

to

20. JOG dial

Forwards or rewinds the picture during playback (frame-by-frame). Uses for controlling the camera connected.

21. Camera number buttons (1 to 16)

Displays the picture supplied from the camera connected. The number of the button corresponds to that of the CAMERA IN connector on the rear panel. The button of the displayed camera number lights up. Uses for the preset function of the camera control. Uses for the menu settings.

M-DET DOT ON/OFF/M-DET AREA SET UP (CAMERA NUMBER 9 and 13)

Uses for setting the detection area of the motion detection function.

Loading/Ejecting a DVD disc or CD

• Before using the disc, read the cautionary notes described in the manual included with the disc.

step1. Press the OPEN/CLOSE button.

• The disc loading tray opens.

(When loading the disc:)

step2

. Place the disc into the tray.

-1

• Make sure the disc is sitting properly in the correct recess, with the label side up.

(When ejecting the disc:)

step2

. Eject the disc from the tray.

-2

step3. Press the OPEN/CLOSE button again.

• The disc loading tray closes.

• Do not eject the disc while copying/restoring, saving/

loading menus, or immediately after inserting the disc. The disc or the contained data may be damaged.

• Please use the disc which we recommend. When a disc other than the recommended one is used, the data may not be read or written correctly. Please consult your dealer of purchase for the usable discs.

• When using DVD disc before using by <Data Clear> menu.

-RW or CD-RW disc, initialize the

ENGLISH

BUSY indicator

Flashes or illuminates during recording or playback.

18. LCD display

Displays the present time and the status of the unit.

19. SHUTTLE ring

Adjusts the playback speed, and rewinds or forwards the recorded pictures. Pans the camera.

11

Major operations and their functions (continued)

Front view (inside of the door)

25 262728

22 24 29 303132

22. POWER button

Turns on the power when pressing while the MAIN switch on the rear panel is set to ON. When the button is pressed again, the unit switches to standby mode. The POWER button operation is not accepted while the POWER indicator is flashing.

23. VIDEO OUT connector

Output connector for video signal (RCA pin).

24. SERIAL BUS port

Input and output port for the device equipped with SERIAL BUS port.

25. HELP button

Displays the help menu which shows the caution on use, operating method, and explanation on functions. Uses when the warning message is displayed. This button can be used even while the menu screen is displayed.

26. SET UP button

Displays the <User Menu>.

27. SEARCH button

Displays the <User Menu> with search menu opened.

28. TIMER button

Sets the unit to timer recording/stand-by mode and lights up the TIMER indicator. When pressing this button for more than 2 seconds, timer recording/ stand-by mode is cancelled and the TIMER indicator turns off.

29. LOCK button

Activates simple lock or password lock when pressing while the MAIN switch (main power) on the rear panel is turned on and lights up the LOCK indicator. Moreover, the PASSWORD can be set on the <Password Setting> (Setup Menu System Password Setting).

3323

30. TRIPLEX PB button

Inserts the playback picture of the desired camera number while displaying the picture supplied from the camera.

31. BOOK MARK button

When pressing this button during frame still playback of the single screen display, the selection screen appears and you can memorize the book mark or copy the picture being displayed.

32. DIGITAL ZOOM button

Magnifies the picture when pressing during single screen display or during playback. Pressing a camera number button (11, 14, 15, or 16) moves the magnification centre point.

33. Operation buttons

STOP button

Stops playback.

PAUSE/JUMP TO END button

Switches the playback to still frame playback when pressing this button during playback. Resumes playback when pressing this button again. The button lights up during still frame playback. When pressing this button during shuttle playback, the set playback speed is maintained even when letting go of the SHUTTLE ring. (Shuttle hold) When pressing this button during the unit is in stop mode of playback, the frame still picture of the end point of the latest recording appears. (Jump to end)

REV. PLAY (REVERSE PLAY) button

Starts reverse playback. The button lights up during reverse playback.

PLAY button

Starts playback. The button lights up during playback.

SPEED (+ and –) button

Switches the playback interval when pressing these buttons during normal or reverse playback.

12

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

+

Rear view

MAIN

OFF ON

AC IN~

100-240V

IN

1234 5678

OUT

CAMERA

IN

9 101112 13141516

OUT

CLAMPER

ALARM OUT

GND

1

2345678

RS-232C

9

10111213141516

VIDEO VIDEO

OUTPUT A

VIDEO CASCADE

RESET

1

2345678

4563

Y/C

ALARM IN

OUTPUT B

9

10111213141516

7

108 9

ENGLISH

AUDIO IN

1

2

GND

CASCADE

AUDIO OUT

MAX 350mA

DC 12V OUT

4

IN

1010010100

RS485RS485

INOUT

OPTION SLOT

P T Z

RS485 TERM ++RS485 TERM –

GND

+

–

RS422

GND

RS232

3

OUT

CLAMPER

AUDIO

INOUT

SERIAL BUSSERIAL BUS

CLOCK ADJ OUT

REC

CLOCK ADJ

REC STOP

EMERGENCY

MODE OUT 1 +

RESERVED

MODE OUT 1 –

LAN-A LAN-B

STORAGE COM

MODE OUT 2 ++MODE OUT 2 –

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

1

2

11

12

1. MAIN switch

This is the main power switch. When using this unit, set this switch to ON. Otherwise, the power cannot be turned on/off using the POWER button on the front of the unit.

2. AC power socket

Used to connect the power cord. Earth terminal is used for safety. Use the 100 to 240 V plug with earth for the power of this unit.

• This unit must be earthed at all times. Never connect this unit to a power outlet which does not have an earth terminal.

• Please use the supplied AC power cord.

3. CAMERA connectors

• Do not connect superimposed voltage camera because it causes product failure.

CAMERA IN connectors

Input connector for signal of camera (BNC connector).

CAMERA OUT connectors

Output connector for signal of camera (BNC connector). If the MAIN switch is turned ON, the signal from CAMERA IN connector is looped out to this connector.

13 15 16 1714

OUTPUT B connector

Output connector for video signal to monitor (BNC connector) ( see page 16).

5. VIDEO CASCADE connectors

VIDEO CASCADE IN connector

Input video connector for cascade connection.

VIDEO CASCADE OUT connector

Output video connector for cascade connection.

6. SERIAL BUS port

Input and output port for the device equipped with SERIAL BUS port.

7. LAN-A port

Port for connection of NAS hard disk unit to back up the recorded data.

LAN-B port

Port for communication using web browser.

8. AUDIO BOARD SLOT

Used to attach an optional audio interface board.

9. Keyhole for antitheft lock

Used to connect a commercially available antitheft cable manufactured by Kensington.

10. OPTION SLOT

Used to attach an optional board.

4. VIDEO OUTPUT connectors

OUTPUT A VIDEO connector

Output connector for video signal to monitor (BNC connector).

OUTPUT A S(Y/C) connector

Output connector for video signals that separate brightness signals and colour signals for higher picture quality. Simultaneous output along with OUTPUT A VIDEO is also possible.

11. GND terminals

It is the common GND terminal.

12. RS-232C connector

Used to connect to a host device equipped with RS232C connector (such as a personal computer). This unit can be controlled from other devices via this connector.

13

+

Major operations and their functions (continued)

Rear view (continued)

MAIN

OFF ON

100-240V

1

13. ALARM IN terminals

Input terminals for alarm signal.

ALARM OUT terminals

Output terminals for alarm signal.

AC IN~

2

IN

1234 5678

OUT

CAMERA

IN

9 101112 13141516

OUT

CLAMPER

ALARM OUT

GND

1

2345678

RS-232C

11

12

13 15 16 1714

108 9

P T Z

+

–

RS422

RS485 TERM ++RS485 TERM –

RS422

GND

RS232

9

10111213141516

RESET

1

OUTPUT A

2345678

4563

VIDEO VIDEO

Y/C

OUTPUT B

VIDEO CASCADE

ALARM IN

9

10111213141516

7

AUDIO IN

1

2

GND

MAX 350mA

CASCADE

AUDIO OUT

DC 12V OUT

IN

4

1010010100

RS485RS485

INOUT

OPTION SLOT

3

OUT

CLAMPER

AUDIO

INOUT

SERIAL BUSSERIAL BUS

CLOCK ADJ OUT

REC

CLOCK ADJ

REC STOP

EMERGENCY

MODE OUT 1 +

RESERVED

MODE OUT 1 –

LAN-A LAN-B

STORAGE COM

MODE OUT 2 ++MODE OUT 2 –

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

MODE OUT 1 to MODE OUT 4 terminals

Output terminal to indicate the current mode of this unit. Select the mode of the unit to be output in the <Mode Out Settings> (Setup Menu System Rear Terminal Setting Mode Out Settings).

14. RESET button

Used to reset the unit and turn off the power. At this time, picture data, menu settings, and the present time are kept.

15. I/O terminals

CLOCK ADJ terminal

Input terminal to set the present time. Time display is adjusted to the nearest hour (00 minutes 00 seconds) when this terminal receives the CLOCK ADJ signal.

• The on-screen clock is reset to the nearest hour by

applying a signal to the CLOCK ADJ terminal. For example, if the current time is 11:29:59, it will be reset to 11:00:00, and if the current time is 11:30:00, it will be reset to 12:00:00.

CLOCK ADJ OUT terminal

Output terminal to send the signal to the other recorders connected for adjusting the clock to the nearest hour (00 minutes 00 seconds).

REC terminal

Input terminal to start recording. This terminal is not available during timer recording.

CALL OUT terminals/CALL OUT GND terminal

This is the ISOLATION output terminal. Information to be transmitted externally consists of CALL OUT settings made in the <Call Out Settings> (Setup Menu System Rear Terminal Setting Call Out Settings) as well as fixed output settings.

DC 12 V OUT terminal

Output the signal only when both the MAIN switch and POWER button are turned ON. The maximum electric current is 350 mA.

16. RS485 IN/OUT connectors

Connectors for the remotely control of the recorders. Used to connect with the other recorders.

17. RS422/RS232C connectors

Connectors for camera operations such as pan, tilt, and zoom when these connectors are connected to the dome camera.

14

REC STOP terminal

Input terminal to stop recording. This terminal is not available during timer recording.

EMERGENCY terminal

Input terminal to start EMERGENCY recording compulsorily.

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Beginning

Connections

Precautions for installation

Precautions for attaching or removing the HDD

• Do not attach or remove the HDD unnecessarily. Attaching or removing the HDD of DX-TL5000E is intended to

replace the faulty HDD or add the HDD when starting operation for the first time because of the structure of the connectors. It is not presumed to be used as a removable HDD.

• Make sure that the POWER button on the front panel and the MAIN switch on the rear panel are both turned OFF

when attaching or removing the HDD. Wait at least 1 minute after turning off the power.

• Do not remove the top cover of the unit.

• Do not drop the HDD. Also do not put the metallic object such as a coin or a screw driver into the HDD tray.

• Do not use an electric screwdriver.

• When a power failure occurs during recording, avoid adding, replacing or transporting the HDD as the recorded

data may be erased. In this case, turn the power back on to boot up the unit normally with the HDD that was being used at the time of the power failure attached. Then add, replace, or transport the HDD.

• HDD is very delicate. Handle the HDD with care and follow the precautions below because even a small shock may

damage the internal components of the HDD.

• Do not place the HDD on a desk or a table directly. Put a thick cushion under the HDD because even a small shock may damage the internal components of the HDD.

• Do not use an electric screwdriver. Vibrations and shocks caused by an electric screwdriver may damage the internal components of the HDD.

• When replacing the HDD, do not knock the HDD with other components such as the another HDD and the HDD tray.

• Do not knock the HDD with tools such as a driver when replacing the HDD.

• The following HDD has been tested and compatibility is ensured. This information is as of December 2004. Supply

of this HDD may be stopped or it may be changed without notice by its manufacturer. Consult your dealer for the latest information or use of other HDDs. When you attach multiple HDDs, normally use the HDDs of the same capacity and the same model name.

<Hitachi Global Storage Technologies> HDS722525VLSA80 (250 GB, S-ATA)

ENGLISH

15

Connections (continued)

+

Connecting to CCTV camera, monitor, and sensor

To OUTPUT A VIDEO or OUTPUT A S(Y/C) connector

Clamp the power cord using the supplied

cable clamping band in order to prevent the

accidental removal of the cable. ( See page 22.)

VIDEO MONITOR

To VIDEO IN or S(Y/C) IN connector

One of either codes should be connected.

To VIDEO IN connector

CAMERA #1

Up to 16 cameras

To CAMERA IN 1 connector

MAIN

OFF ON

100-240V

POWER CORD

for the Continent

AC IN

~

DOME CAMERA

IN

1234 5678

OUT

CAMERA

IN

9 101112 13141516

OUT

CLAMPER

ALARM OUT

GND

1

2345678

RS-232C

To CAMERA IN connector

To GND terminal

To SERIAL

BUS

PC

VIDEO VIDEO

Y/C

OUTPUT A

VIDEO CASCADE

RESET

ALARM IN

1

2345678

9

10111213141516

To ALARM IN terminal corresponding to the CAMERA #.

SENSOR #1

OUTPUT B

9

10111213141516

INOUT

SERIAL BUSSERIAL BUS

To OUTPUT B connector

VIDEO MONITOR

Clamp the USB cable using the supplied cable clamping band in order to prevent the accidental removal of the cable. ( See page 22.)

AUDIO IN

1

2

GND

MAX 350mA

CASCADE

AUDIO OUT

DC 12V OUT

4

IN

1010010100

RS485RS485

INOUT

OPTION SLOT

P T Z

+

RS422

RS485 TERM ++RS485 TERM –

GND

–

RS422

GND

RS232

To LAN A

To LAN B

–

RS485 TERM +

RS485 TERM

GND

PTZ

RS422 +

RS422 –

CLAMPER

CLOCK ADJ

CLOCK ADJ OUT

REC

REC STOP

EMERGENCY

MODE OUT 1 +

RESERVED

MODE OUT 1 –

3

OUT

AUDIO

LAN-A LAN-B

STORAGE COM

MODE OUT 2 ++MODE OUT 2 –

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

GND

NAS

PC

RS232

16

for U.K

To SERIAL BUS

Mouse

External recording device

DX-ZD5UE(Z) (soon to be on sale) Up to 7 units can be mounted at the same time.

RS422 TYPE

DOME CAMERA

RS232C TYPE

DOME CAMERA

Processing the connecting line Connection on the ALARM IN terminals and the I/O terminals

Compatible power lines ø0.32 - ø0.65 mm (A WG 28 - 22)

Cut the designated area from the electric wire’s outer covering (vinyl portion).

5~7mm

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

Alarm recording connection

The diagram below shows an example of connection for alarm signals corresponding to sensor number 1.

ENGLISH

GND

RS-232C

ALARM OUT

123456789

ALARM SWITCH

10111213141516

ALARM IN

123456789

10111213141516

EMERGENCY/ALARM IN/REC/ CLOCK ADJ Input terminal

• Input Circuit

10kΩ

Input terminal

GND

22kΩ

5V

0.047µF

4.7kΩ

CALL OUT Output terminal

• Output Circuit

CALL OUT terminal

CALL OUT GND terminal

5V

ALARM OUT Output terminal

• Output Circuit

Output terminal

GND terminal

MODE OUT 1 - 4 Output terminal

• Output Circuit

MODE OUT

Mode out +/– (1-4) Active: Short Max. Drive current 500 mA DC. Relay output Non active: Open. Max. Voltage +24 V DC.

Call out +/– Active: Short Max. Drive current 7 mA DC. Photo coupler output Non active: Open. Max. Voltage +24 V DC.

Emergency input/Alarm input (1-16)/Recording/Clock adjust input

Active: When terminals are short-circuited or “Low”

Level is applied.

Non active: Open.

Alarm Output Active: “Low Level” Max. Drive current 7 mA DC.

Non active: Open. Max. Voltage +24 V DC.

17

Connections (continued)

+

Cascade connection

VIDEO MONITOR

(MASTER)

To VIDEO CASCADE OUT

Up to 16 cameras

To CAMERA IN

IN

OUT

CAMERA

DOME CAMERA

MAIN

OFF ON

IN

OUT

AC IN

~

100-240V

12345678

CAMERA

910111213141516

CLAMPER

ALARM OUT

GND

1

2345678

9

10111213141516

RS-232C

To VIDEO CASCADE IN

RESET

1

2345678

VIDEO VIDEO

Y/C

OUTPUT A

VIDEO CASCADE

ALARM IN

VIDEO MONITOR

(LOCAL)

AUDIO IN

1

2

OPTION SLOT

3

OUTPUT B

INOUT

SERIAL BUSSERIAL BUS

9

10111213141516

4

OUT

IN

CLAMPER

AUDIO

CASCADE

AUDIO OUT

LAN-A LAN-B

1010010100

STORAGE COM

P T Z

RS485RS485

+

–

INOUT

RS422

RS485 TERM ++RS485 TERM –

MODE OUT 4 ++MODE OUT 4 –

MAX 350mA

DC 12V OUT

CALL OUT ++CALL OUT –

GND

RS422

GND

RS232

To RS485 OUT

MODE OUT 1 +

MODE OUT 2 +

CLOCK ADJ

CLOCK ADJ OUT

REC

REC STOP

EMERGENCY

RESERVED

MODE OUT 1 –

MODE OUT 2 –

MODE OUT 3 ++MODE OUT 3 –

To OUTPUT B To AUDIO CASCADE IN

KEY BOARD

DX-KB5UE (Soon to be on sale)

Termination is not necessary on this side

when using key boad.

VIDEO MONITOR

(LOCAL)

Up to 16 cameras

To CAMERA IN

CAMERA

DOME CAMERA

Up to 16 cameras

To CAMERA IN

CAMERA

DOME CAMERA

OFF ON

AUDIO IN

1

3

OUT

AUDIO

LAN-A LAN-B

STORAGE COM

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

GND

AUDIO IN

1

3

OUT

AUDIO CASCADE

LAN-A LAN-B

STORAGE COM

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

GND

2

4

IN

CASCADE

AUDIO OUT

MAX 350mA

DC 12V OUT

2

4

IN

AUDIO OUT

MAX 350mA

DC 12V OUT

To RS485 IN

OPTION SLOT

1010010100

P T Z

RS485RS485

+

–

INOUT

RS422

RS485 TERM ++RS485 TERM –

RS422

GND

RS232

To RS485 OUT

To RS485 IN

OPTION SLOT

1010010100

P T Z

RS485RS485

+

–

INOUT

RS422

RS485 TERM ++RS485 TERM –

RS422

GND

RS232

To RS485 OUT

To OUTPUT B

VIDEO MONITOR

(LOCAL)

To OUTPUT B

VIDEO MONITOR

(LOCAL)

RESET

1

2345678

VIDEO VIDEO

Y/C

OUTPUT A

VIDEO CASCADE

ALARM IN

OUTPUT B

9

10111213141516

INOUT

SERIAL BUSSERIAL BUS

To AUDIO CASCADE OUT

CLAMPER

MODE OUT 1 +

CLOCK ADJ OUT

REC

REC STOP

EMERGENCY

RESERVED

MODE OUT 1 –

MODE OUT 2 ++MODE OUT 2 –

CLOCK ADJ

To VIDEO CASCADE OUT

IN

12345678

OUT

CAMERA

IN

910111213141516

OUT

CLAMPER

AC IN

~

MAIN

100-240V

ALARM OUT

GND

1

2345678

9

10111213141516

RS-232C

To VIDEO CASCADE IN

To VIDEO CASCADE OUT

IN

12345678

OUT

CAMERA

IN

910111213141516

OUT

CLAMPER

AC IN

~

MAIN

100-240V

GND

RS-232C

VIDEO VIDEO

Y/C

OUTPUT B

OUTPUT A

CLAMPER

INOUT

VIDEO CASCADE

SERIAL BUSSERIAL BUS

RESET

ALARM IN

ALARM OUT

1

2345678

9

1

2345678

9

10111213141516

MODE OUT 1 +

CLOCK ADJ

CLOCK ADJ OUT

REC

REC STOP

EMERGENCY

RESERVED

MODE OUT 1 –

MODE OUT 2 ++MODE OUT 2 –

To VIDEO CASCADE IN

18

AUDIO IN

1

3

OUT

AUDIO CASCADE

LAN-A LAN-B

STORAGE COM

MODE OUT 3 ++MODE OUT 3 –

MODE OUT 4 ++MODE OUT 4 –

CALL OUT ++CALL OUT –

GND

MAX 350mA

DC 12V OUT

AUDIO OUT

2

4

IN

1010010100

RS485RS485

INOUT

To RS485 IN

OPTION SLOT

P T Z

+

–

RS422

RS485 TERM ++RS485 TERM –

RS422

GND

RS232

To OUTPUT B

Connect RS485

PTZ

–

GND

RS422 +

RS422 –

GND

RS232

RS485 TERM +

RS485 TERM

Up to 16 cameras

To CAMERA IN

CAMERA

DOME CAMERA

OFF ON

To VIDEO CASCADE OUT

IN

12345678

OUT

CAMERA

IN

910111213141516

OUT

CLAMPER

AC IN

~

MAIN

100-240V

GND

RS-232C

VIDEO VIDEO

Y/C

OUTPUT B

OUTPUT A

CLAMPER

INOUT

VIDEO CASCADE

SERIAL BUSSERIAL BUS

RESET

ALARM IN

ALARM OUT

1

2345678

9

1

2345678

9

10111213141516

MODE OUT 1 +

CLOCK ADJ

CLOCK ADJ OUT

REC

REC STOP

EMERGENCY

RESERVED

MODE OUT 1 –

MODE OUT 2 ++MODE OUT 2 –

TERM+ to RS485 TERM– with a wire.

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

Attaching or removing the HDD

Up to 3 HDDs can be mounted on this unit. The attaching, removing and replacing method of the HDDs are as follows.

• Turn off the MAIN switch on the rear panel before attaching or removing the HDD.

• When attaching multiple HDDs, attach in the order of HDD A, B, and C.

When removing a HDD

step1. Push the left end of each screw covers on both sides

of the cover to open.

step4. Remove the metal part.

• Remove 4 screws on the metal part.

ENGLISH

• Do not leave the screw cover open for general use.

step2. Remove the screws.

step5. Pull out the HDD tray halfway.

HDD B

HDD A

step6. Disconnect the cords.

HDD C

step3. Remove the front covers.

• Remove the cover on the right side first.

• Then, push the left side cover to the right to

remove.

step7. Remove the HDD tray.

• Pull out the HDD tray completely.

step8. Remove the HDD.

• Remove 4 screws which are used to fix the HDD and its frame.

19

Connections (continued)

When attaching a HDD

step1. Attach the new HDD onto the HDD tray with four

screws.

• Make sure to attach the HDD in the correct direction.

• When attaching the additional HDD to HDD B or C, use the supplied screws.

step4. Insert the hard disk tray completely.

step5. Attach the metal part.

• Adjust the upper side first, then push the lower side into the unit.

• Take care not to deform the springs.

step2. Insert the hard disk tray halfway.

step3. Connect the cords.

Spring

step6. Fix the metal part with four screws.

step7. Attach the front covers.

• Attach the left side cover and push to the left.

• Then, attach the right side cover.

20

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

step8. Fix the front covers with two screws.

step9. Close the left end of each screw covers on both sides

of the cover.

ENGLISH

• Follow the same procedures when removing or attaching the HDD B or HDD C.

21

Connections (continued)

Clamping the cables

step1. Put the supplied cable clamping band into the

clamper hole on the rear panel.

• There are 2 clamper holes on the unit, for power cable and USB cable.

step2. Put the cable to be clamped through the cable

clamping band as illustrated below.

• Face the serrated surface of the band inside.

step3. Pull the edge of the cable clamping band until it

stops.

22

Connecting to an analogue video cassette recorder

To VIDEO OUT connector

To VIDEO IN

Commercially available video cable

•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

connector

Analogue video cassette recorder

Optional items

DX-ZD5UE(Z)

Additional HDD unit (serial bus connection type)

(Soon to be on sale)

DX-KB5UE

Key board for digital recorder (cascade function supported)

(Soon to be on sale)

DX-GC5 (Soon to be on sale)

DX-SC5

R-2500

Graphic card for XGA output (attached to the PCI slot on the rear panel of the unit)

Interface board for audio recording and playback

Wired remote controller (SET UP and SEARCH buttons are not available.)

Mitsubishi Electronics DX-TL5000E User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
