_,_MITSUBISHI

Television,

Owner's

Guide

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNI--L.

The lightning flash with arrowhead symbcl,
within an equilateral triangle, is intended to

alert the user to the presence ofuninsulated

"dangerous voltage" within the product's enclo-

sure that may be of sufficient magnitude to
constitute a risk of electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to the

presence of important operating and mainte-
nance (servicing) instructions in the lite:ramre
accompanying the appliance.

_Warning:

Don't leave stationary images, such as those generated from
stock market reports, video games, statior_ logos, or TV displays,
on-screen for more than 10 minutes. Still patterns such as these
can scar the TV, causing permanent damage to the picture tube.

.WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.

CAUTION:

TO PREVENT ELECTRIC SHOCK HAZARD, DO NOT USE 'THIS UNIT'S (POLARIZED) PLUG
WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES

CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

NOTE TO CATV SYSTEM INSTALLER:

THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER'S ATTENTION
TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR ]?ROPER

GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GP_OUND SHALL BE
CONNECTED TO THE GROUNDING SYSTEM Of THE BUILDING, AS CLOSE TO THE

POINT OF CABLE ENTRY AS PRACTICAL.

MITSUBISHI OWNER'S GUIDE

Table of Contents

Important Safeguards ................................................................ 3

Preface: Welcome to Mitsubishi ............................................. 5

Summary of Special Features ........................................... 6

Unpacking Your TV ............................................................. 7

What's in Each Chapter ...................................................... 8

Some Conventions Used :inthis Guide .............................. 9

Chapter 1: Getting to Know Your TV .................................. 11

Overview of the Control Panel ........................................ 12

Overview of the Remote Control ..................................... 14

Getting ready to use the remote control ..................... 14

Remote control buttons and functions ........................ 16

Chapter 2: Connecting Your TV ........................................... 21

Overview of the Back Panel .............................................. 22

Basic Connections ............................................................. 24

TV + antenna or cable without a

decoder box .............................................................. 25

TV + cable with a decoder box ...................................... 26

TV + separate UHF and VHF antennas .................... 27

TV + VCR + antenna or cable without

a decoder box ............................................................ 28

TV + VCR + cable with a decoder box ........................ 31

TV + audio system ........................................................ 34

Chapter 3: Operating Your TV .............................................. 35

Getting Started .................................................................. 36

Adjusting the color purity ............................................ 37

Using the remote control to operate ,:able boxes

and other brands of VCRs ...................................... 38

Turning the TV on/off. ................................................. 41

Selecting the input source .......................................... 42

Changing channels ........................................................ 43

Understanding the or.L-screen menus ......................... 46

Setting the clock ............................................................ 47

Memorizing channels ................................................... 49

Adding and deleting channels .................................... 50

Renaming the input ...................................................... 51

Selecting the menu language ..................................... 52

Using video mute .......................................................... 53

Adjusting the sound ...................................................... 54

Adjusting the picture ................................................... 56

Using the closed caption decoder ............................... 57

UsingtheAdvancedFeatures.........................................59

Settingthetimer..........................................................60

Usingtheparentallock...............................................61

UsingtheSuperQuickViewtuning..........................65

SelectinganadvancedPIPfunction...........................66

Chapter 4: Using the Special Features ............................... 67

Understanding the On-Screen Displays .......................... 68

Using the Off-Timer .......................................................... 69

Setting the off-timer. .................................................... 70

Changing or canceling the off-timer ........................... 71

Using the Advanced Picture-in-Picture (PIP) Modes ..... 72

Activating the PIP image .............................................. 73

Selecting the source of the PIP ................................... 74

Changing channels while using tile PIP modes ........ 74

Exchanging the PIP image and the main image ....... 75

Moving the PIP image ................................................. 75

Freezing the PIP image ............................................... 76

Using the Snap-shot feature ....................................... 77

Using the Replay feature ............................................. 78

Chapter 5: Troubleshooting ................................................. 79

Caution and Care ............................................................... 82

Calling for Service ............................................................. 83

Appendix: Procedure for Bypassing the

Parental Lock ............................................................................ 85

Index ........................................................................................... 87

Warranty ....................................................... Inside Back Cover

2 Table of Contents

IMPORTANT SAFEGUARDS

PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TV RECHVER AND RETAIN
FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON

THE _1_ RECEIVER.

1. Read Instructions
All the safety and operating instructions should be

read before the appliance is operated.

2. Retain Instructions

The safety and operating instructions should be
retained for future reference.

3. Heed Warnings

All warnings on the appliance and in the operating

instructions should be adhered to.

4. FolLow Instructions
All operating and use instructions should be followed.

Warning:

5. Cleaning
Unplug this TV receiver from the wall outlet before
cleaning. Do not use liquid or aerosal cleaners to

clean your TV. Use a damp cloth for cleaning.
Cleaners may permanently damage your screen. Do
not clean your TV when it is on.

6. Attachments
Do not use attachments not recommended by the TV

receiver manufacturer as they may cause hazards.

7. Water and Moisture

Do not use this TV receiver near water -- for ex-
ample, near a bath tub, wash bowl, kitchen sink, or

laundry tub, in a wet basement, or near a swimming
pool, and the like.

8. Accessories

Do not place this TV receiver on an unstable cart,
stand, tripod, bracket, or table. The TV receiver may
fall, causing serious injury to a child or adult, and
serious damage to the appliance. Use only with a
cart, stand, tripod, bracket, or table recommended by
the manufacturer, or sold with the TV receiver. Any

mounting of the appliance should follow the manu-
facturer's instructions, and should use a mounting

accessory recommended by the manufacturer.

9. Ventilation

Slots and openings in the cabinet are provided
for ventilation and to e_sure reliable operation

of the TV :receiver and t,3 protect it from over-
heating, and these openings must not be

blocked or covered. The openings should never

be blocked by placing the '[W receiver on a bed,
sofa, rug, or other similar surface. This _.W
receiver should never be placed near or over a
radiator or heat register. :_his TV receiw_r
should not be placed in a built-in installation
such as a bookcase or rack unless proper
ventilation is provided or '_he manufacturer's
instructions have been ad:_ered to.

10. Power Sources
This TV receiver should, b,_ operated only from

the type of power source indicated on the
marking label. If you are not sure of the type of

power supplied to your home, consult your
appliance dealer or local power company. For

TV receivers intended to operate from battery
power, or other sources, refer to the operating

instructions.

11. Grounding or Polarization
This TV receiver is equipped with a polarized

alternating-current line plug (a plug having one
blade wider than the other). This plug will fit

into the power outlet o:dy one way. This is a
safety feature. If you are unable to insert the

plug fully into the outlc.t, try reversing the plug.
If the plug should still fair[ to fit, contact your
electrician to replace your obsolete outlast. Do
not defeat the safety purlcose of the polarized
plug.

12. Power-Cord Protection
Power-supply cords should be routed so that
they are not likely to be walked on or pinched

by items :placed upon or against them, paying
particular attention to cords at plugs, conve-

nience receptacles, and t_e point where they
exit from the appliance.

An appliance and cart

combination should be
moved with care. Quick

stops, excessive force,
and uneven surfaces

may cause the apphance
and cart combination to

overturn.

13.

Lightning
For added protection for this TV receiver during
a lightning storm, or when it is left una'Ltended

and unused for long periods of time, unplug it
from the wall outlet and (tisconnect the antenna

or cable system. This will prevent damage to the
TV recei ver due to lighLni ng and power-line

surges.

14.PowerLines
Anoutsideantennasystemshouldnotbelocated

inthevicinityofoverheadpowerlinesorother
electriclightorpowercircuits,orwhereit canfall
intosuchpowerlinesorcircuits.Wheninstalling
anoutsideantennasystem,extremecareshould
betakentokeepfromtouchingsuchpowerlines

orcircuitsascontactwiththemmightbefatal.

15.Overloading

Donotoverloadwalloutletsandextensioncords
asthiscanresult,inariskoffireorelectricshock.

16.ObjectandLiquidEntry
:NeverpushobjectsofanykindintothisTV

receiverthroughopeningsastheymaytouch
dangerousvoltagepointsorshort-outpartsthat
couldresultinafireorelectricshock.Neverspill
LiquidofanykindontheTVreceiver.

17.'OutdoorAntennaGrounding
Ifanoutsideantennaorcablesystemisconnected
totheTVreceiver,besuretheantennaorcable
systemisgroundedsoastoprovidesomeprotec-
tionagainstvoltagesurgesandbuilt-upstatic
charges.

;Section810oftheNationalElectricalCode,ANSI/
NFPANo.70,providesinformationwithregardto

:propergroundingofthemastandsupporting
:structure,groundingofthelead-inwiretoan
antennadischargeunit,sizeofgroundingconduc-
tors,locationofantennadischargeunit,connec-
tiontogroundingelectrodes,andrequirementsfor
thegroundingelectrode.

EXAMPLE:OF ANTENNA GROUNDING

18. Servicing
Do not attempt to service this TV receiver

yourself as opening or removing covers may
expose you to dangero_.s voltage or other

hazards. Refer all servicing to qualified service
personnel.

19. Damage Requiring Service
Unplug this TV receiver from the wall outlet

and refer servicing to qualified service person-
nel under the followin_ conditions:
(a) When the power-supply cord or plug is

damaged.

(b) Ifl![quid has been spilled, or objects have

fallen into the TV receiver.

(c) If the TV receiver has been exposed to rain

or water.

(d) Iftlhe TV receiver daes not operate normally

by following the op(,rating instructions.
Acijust only those controls that are covered

by the operating im,_tructions as a_a improper
adjustment of other controls may result in

damage and will often require extensive
work by a qualified technician to restore the
TV receiver to its normal operation.

(e) If t:he TV receiver has been dropped or the

cabinet has been damaged.

(f) When the TV receiver exhibits a distinct

change in perfor_a:ace -- this indicates a
need for service.

20. Replacement Parts
When :replacement par:s are required, be sure

the service technicia:a has used replacement
parts specified by the manufacturer or have the
same characteristics as the original part.

Unauthorized substitutions may result in fire,
electric shock or other hazards.

NEC -- NATIONAL ELECTRICAL CODE

LEAD IN WIRE

DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING
CONDUCTORS

-(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM

(NEC ART 250, PART H)

21. Safety Check
Upon completion of any service or repairs to this

TV receiver, ask the se_:vice technician to
perform safety checks to determine that the TV

receiver is in safe operating condition.

bWarning:

Do not leave stationary images, such as stock
market reports, video games, station :Logos,or

the TV's displays, on-screen for more than 10
minutes. Still pattenls such as these can scar
the TV, causing pernmnent damage to the
picture tubes.

PREFACE

Welcome to Mitsubishi

Congratulations on your purchase of this Mits_:bishi TV. Your TV
is designed for superb viewing pleasure as well as continued_

reliability.

To familiarize you with your TV and owner's gnide, we suggest that
you read through the preface, which provides t:._e following impor-

tant information:

0 Summary of Special Features

0 Unpacking Your TV

What's in Each Chapter

0 Some Conventions Used in this Guide

Mitsubishi has strived to create your TV so that it will bring you
years of viewing enjoyment. Sirailarly, your owner's guide i,_

designed with a "user friendly" philosophy thai: will help you take
advantage of all of your equipment's features.

Once again, thank you for selecting our product and welcome to

Mitsubishi!

Summary of Special Features

Your top rated Mitsubishi TV delivers:

• 181-Channel Capacity .... programs up to 181 channels,

ensuring your continued viewing pleasure as cable sem4ces
continue to expand.

• Two-Speaker Sound System --- a special speaker system that

produces clear stereo sound.

• Expanded Sound Capability --- allows you to connect the TV

to an external audio system for enhanced listening pleasure.

In addition to the standard features found on most advanced TVs,
Mitsubishi is proud to offer the following distinctive featm:es:

Remote Control with TV/VCR/CABLE Function --- uses a
single remote control transmitter for the television, certain

Mitsubishi VCRs, and also some VCRs an] cable boxes from
other manufacturers.

• On-Screen Displays --- appear whenever you adjust your TV,

showing you the status of your TV's various functions.

• On-Screen Menu --- simplifies the television's features with

easy to follow instructions.

• Closed Caption Decoder --- decodes hidden text information

included with TV shows and displays the text on-screen.

Extended Data Services --- (also knowr., as '_[DS,") allows
broadcasters to supply you with channel information, program

information, and the time of day. You can display this informa-

tion on-screen.

• Picture-in-Picture Mode --- allows you to view two different

sources at the same time.

Each of these features will be expIained in more detail in

Chapter 3, "Operating Your _J," and Chapter 4, "Using the Special

Features."

6 Preface: Welcome to Mitsubishi

€ Unpacking Your TV

What you will find

As you unpack your new TV, please check t:o be sure that along
with the TV, the following items are included:

• an owner's guide containing a warranty',

• a registration card,

• a remote control transmitter, and

• a set of two AA size batteries for the remote control.

A few suggestions

Before you hook up your new TV, please take a few minutes to:

O

Complete the registration card. The r¢_,_tration card asks for
the TWs serial number, which you'll find on the back of the

unit.

0

Keep the box and packing materials for future use.

0

File your sales receipt.

Place the TV on a stable surface with suJ_cient lighting to do

0

the hook-up.

Unpacking Your TV 7

What's in Each Chapter

Here's what you will find in this owner's guide:

Chapter 1, "Getting to Know Your TV," introduces you to the
location and functions of the buttons and controls of your TV.

Chapter 2, "Connecting Your TV," explains how to connect a
VCR, antenna, decoder box and other equipment to your _[V.

Chapter 3, "Operating Your TV," provides the step-by-step

instructions you need in order to use your TV.

Chapter 4, "Using the Special Features," explains how to use
some of the special features of the TV.

Chapter 5, "Troubleshooting," summarizes the problems you
may have along with suggestions for remedying these problems.

The appendix explains a procedure that allows you to bypass the
parental lock.

You'll also find a detailed index at the back oJ'the book.

8 Preface: Welcome to Mitsubishi

Some Conventions Used in this Guide

Mitsubishi has gone to great effort to provide users with an easy-to-

follow, useful owner's guide. You will find tha_ different types of
information are treated in different ways.

Users should read information labeled Important and int_rmation
that is boxed and labeled Warning• The owner's guide uses these

terms sparingly, and you should carefully rea,_t all information
highlighted in this manner.

Ima_o*opicortosklIlis*of*ela*edtopicsor*asksl

Ba_c Comaec*.ions

Lrelated topics or tasks J

/_

This cue indicates information

c_:itical to the operation of your

new TV.

I_,o,0_to.

This cue alerts you to informa-
tion describing dangerous
situations that could ruin your
equipment or cause electrical

shock.

Some Conventions Used in this Guide 9

The step-by-step instructions
on how to accomplish a
particular task are signaled
by white numbers on a black

backgro and.

I

_ CHAPTER ONE

Getting to Know Your TV

Now that you've unpacked your TV, read through the safety
information, and glanced at the overview explaining how this
owner's guide is organized, it's time to become Familiar with the
buttons and controls you'll be using when you operate the TV.
This chapter will introduce the range of options available when
using the buttons on the remote control or oil tlhe control panel of
the TV. It also offers some general guideline,_ fi)r using the remote.

Most functions can be controlled by using eithc,r the control panel

or the remote control, but certain specialized functions require the
use of one or the other. This chapter, which will familiarize you

with the full range of button functions, contains the following
sections:

€ Overview of the Control Panel

€ Overview of the Remote Control

11

Overview of the Control Panel

Buttons (!) through 0

are lecated here

The STRENGTH!DIRECTION
swi Bches (_)) are located here

]

1 _-"_ 2 S

STRENGTH DIRECTION

12 Chapter 1: Getting to Know Your TV

(_) power button (POWER)

Use this button to turn the TV on or off. When you turn the TV
on, the power indicator will light in green.

®

program timer indicator

This indicator lights up in green when you turn the TV on; it
lights up in red when the timer is set and 1;he TV's power is off;
it lights in orange if the timer is set and the TV's power is on.

® volume controls (VOL)

Press the • button to turn up the volume and the • button to
turn down the volume.

(_) channel controls (CH)

Use the • button to switch to a channel with a higher number

and the • button to switch to a channel with a lower number.

input button (INPUT)

Use this button to select the input source you want to view:

• TV, or

• Input.

® A/V reset button (A.V. RESET)

Press this button to reset all audio and vi,Jeo functions, to their
normal level or setting, except: volume, reception mode,

speaker, and closed captioning.

®

degauss button (DEGAUSS)

If there is color impurity in your TV's picture, press this button.

®

color purity adjustment switches (STRENGTH,
DIRECTION)

Set these switches accordb_g to the placement of your

television. (Please see page 37.)

Overview of the Control Pane] 13

Overview of the Remote Control

Getting ready to use the remote control

installing the batteries

O Take the box containing two AA size batteries from the packing

bag.

O Remove the back cover of the remote control by pushing in the

direction of the arrow.

Load the batteries as indicated in the illusl;ration, making sure
that they are positioned correctly (+ to +_ and - to -).

0 Replace the back cover of the remote control.

O O

O

For best results, use Duracell AA (MN1500) batteries.

14 Chapter 1: Getting to Know Your TV

some do's and don'ts

To ensure that your remote control will continue working properly,
follow these guidelines:

• Don't press two or more buttons at the santo time, unless

specifically instructed to do so in this owner's guide.

• Don't allow the remote control to get wet or become heated.

• Avoid dropping the remote control on a ha:d surface.

• When cleaning the remote control, don't use any harsh
chemicals. Use only a soft, slightly moistened cloth.

general instructions

When using the remote control to operate the TV, VCR, or cable
box, follow these procedures:

O Be within 20 feet of the desired equipment.

O Point the top of the remote control toward the equipment.

Press the appropriate button or sequence of buttons.

guidelines for using batteries

• Don't use a new battery with an old one.

• Don't heat, take apart, or throw batteries into a fire.

The following section explains :more about the range of options

available when using the remote control.

Overview of the Remote Control 15

@

Remote control buttons and functions

"IV CABLE VCR-A VCR-B

• REC STOP PAUSE

©__-

REW PLAY FF

@
@

©
®

@

®
@

@

VOLUME INPUT CHANNEL

MENU CANCEL DISPLAY HOME

CD _.) CD-

Q

vcpgrv

OFF-T

®

®®

VCR-CH

-_Q

INDEX

( - I + )

(2D--

-- ---- SOURCE

®

®

16 Chapter 1: Getting to Know Your TV

select buttons

Q

Use these buttons to select the component you wish to operate:
the TV, a cable decoder box, or a VCR. These buttons are also

used to set up your remote control for your particular brand of
cable box or VCR.

VCR buttons

®

These buttons can be used to control VCRs. The remote control
is pre-set to operate Mitsubishi VCRs, and it can be pro-

grammed to operate VCRs t_om other manufacturers.

®

power button (POWER)

Use this button to turn the TV on or off. _:hen you turn the TV
on, the power indicator lights in green.

mute control (MUTE)

®

Use this button to turn the sound off completely or to restore it
to its original volume.

®

super quick view button (SQV)
Press this button to view the channels t:_at you have pro-

grammed into super quick view memors'. (See page 45.11

®

quick view button (QV)

Press this button to instantly switch to the channel that you
memorized as the quick view channel. (Se_ page 45.)

volume control (VOLUME)

®

Press the top part of the button to turn Ul_the volume; press
the bottom part of the button to turn down the volume.

®

input button (INPUT)

Use this button to select the input source you wish to view:

Q WV_ or

• Input.

®

channel control (CHANNEL)
Press the top part of this button to change to a channel with a
higher number; press the bottom part to change to a channel

with a lower number.

®

enter and exchange button (ENTER/EXCH)

Use this button after selecting a channel number or at_Ler

selecting an item from the on-screen menu system. You will
also use this button with the PIP modes.

Overview of the Remote Control 17

Remote control buttons and functions (cont.)

audio and video controls

©

These buttons are used together to adjust, audio and video
functions (other than volume) with a two-step process: you use

the audio or video button to select a function, then you _:se the
adjust up!down buttons or _ght/left button:_ to adjust it.

audio function button (AUDIO) --- Use this button to
select one of the following audio functions:

- stereo/SAP/mono,

- bass,

- treble,

- balance,

- surround off/simulate/hall, or

- speaker on/off.

video function button (_VIDEO) --- U,_e this button to

select one of the following video functions:

- tint,

- color,

- contrast,

- brightness,

- sharpness,

- color temperature high/middle/low, or

- closed captioning.

adjust buttons (ADJUST • V), rightqeft button,_ (,,)
After selecting the audio or video function, use the ADJUST

buttons (• • ) or right]left buttons ('') to adjust the
function you've selected. These buttons can be used to:

- turn the function on or off(e.g., speakec),

- increase or decrease the function (e.g., color),

- shift from one end of a scale to the othc,r (e.g., balance), or

- select a position (e.g., s_ereo).

You will also use the adjust buttons with the Picture-in-Picture
features and to select items on the on-scree:a menus.

menu button (MENU)

@

Use this button to display the on-screen menu system, which
gives you access to your TV's features.

@

cancel button (CANCEL)

This button is used to cancel a channel number and to clear the
settings of on-screen menus.

18 Chapter 1: Getting to Know Your TV

®

display button (DISPLAY)

Use this button to view an on-screen sumraary of the current
TV settings and the displays related to Extended Data Services

(XDS).

home button (HOME)

@

Press this button to return to regular TV _4ewing from the on-
screen displays and menus. This button can also be used to

turn off captions.

number buttons (0-9)

®

Use these buttons to select a channel number and to enter the
parental lock code.

off-timer button (OFF-T)

®

Use this button to program the TV to turn off automatically at
a later time.

®

picture-in-picture controls

Use these buttons to control the special picture-in-picture (PIP)
modes. (For more information, see page,_ 72-78.)

• PIP button (PIP) --- Press this button to begin displaying

the PIP image, change t:he size of the image, or to cancel it.

• VCR channel button (VCR-CH) --- If you use a VCR as
the source for the PIP image, use this button to change the
channel of the PIP image.

• source button (SOURCE) --- Press. this button to switch
the source of the PIP image between the TV and the exter-

nal input.

• pause button (PAUSE) --- Press this button to freeze the
PIP image or to return the image to a _live" picture. You can

also use this button with the Snap-shot and Replay features.

• enter and exchange button (ENTE!PJEXCH) --- Press
this button to exchange the contents of the PIP image and
the main image.

• adjust (up/down) buttons, right/left buttons --- Press
these buttons to move the PIP image, o:a the screen.

Overview of the Remote Control 19

_ CHAPTER. TWO

Connechng Your TV

This chapter offers step-by-step instructions for completing the
most common hook-ups. It contains the follcv_Lng sections:

0 Overview of the Back Panel

t Basic Connections

21

Overview of the Back Panel

VHF/UHF

0

S-VIDEO

(75_)

(MONO)

_>Important:

@

@ antenna terminal

Connect a cable antenna or a VHF/UHF antenna here.

@ video output terminal

Use these terminals to "send out" the TV's video signal to a
VCR, a video copy processor, etc.

@ audio output terminals

Use these terminals to "send out" the TV_s audio signal to a

VCR, a video copy processor, etc.

Never connect one piece of equipment to both the TV_s input
terminals and the TV's output terminals. If you do, the TV will

turn off as a safety precaution.

22 Chapter 2: Connecting Your TV

@ S-VIDEO input terminal

Use these terminals to "bring in" an S-video signal frora a VCR
or disc player into the TV.

Important:

If you connect S-video equipment, the standard video input will be
unavailable.

@ video input terminal

Use this terminal to "bring in" a video signal from a VCR or

another component into the TV.

@ audio input terminals

Use these terminals to '%ring in" an audio, signal from a VCR or

other equipment into your TV.

Overview of the Back Panel 23

Basic Connections

This section explains the basic connections you will need t_ make
between your TV, antennas, and VCR. You _ill see there are
different connections shown depending on th,_ type of antenna you
are using and whether or not you have a decoder box. Chcose the
type of connection for the type of equipment you have.

If you are having difficulty making the connections to your TV, you
may want to contact your Mitsubishi dealer or your local cable

company.

This section explains:

• TV + antenna or cable without a decoder box,

• TV + cable with a decoder box,

• TV + separate UHF and VHF antennas,

• TV + VCR + antenna or cable without a

decoder box,

• TV + VCR + cable with a decoder box, and

• TV + audio system.

[>Important: You must connect a VCR to see two active images when using

Picture-In-Picture (PIP).

bWarning: I You should unplug your TV and any other components before

connecting them.

I

24 Chapter 2: Connecting Your TV

TV + antenna or cable without a decoder box

equipment you will need

If you have a standard 75-ohm coaxial cable, you will not need
additional equipment. If your antenna has two leads (called flat
twin leads), you'll need:

• One 75-300 ohm transformer.

_F 75-ohm

Coaxial Cable

TV Rear Terminals

I O

VHF/UHF

(Tsnl

O

O O __

/

Transformer

connecting a cable

In) Push or screw the end of the cable onto the ANT-A te:rminal on

the TV.

connecting an antenna with fiat twin leads

In) Use a screwdriver to connect the leads to the transformer.

Push or screw the transformer onto the antenna terminal on
the TV.

Basic Connections 25

TV + cable with a decoder box

equipment you will need

Use this hook-up if you need a decoder box to descramble cable

channels. When you complete this hook-up, you should set up your
remote control to operate your cable box (see page 38).

To complete the hook-up, you'll need:

• One length of 75 ohm coaxial

cable.

procedure

O Connect the incoming cable to

the IN terminal on the decoder

box.

O Connect the coaxial cable to the OUT terminal on the back of

the decoder box; connect the other end of this cable to the

antenna terminal on the back of the TV.

Incoming Cable

I

0

Cable Decoder Box

Rear Terminals

IT

0

VHF/UHF

----* _)

TV Rear Terminals

75_)

26 Chapter 2: Connecting Your TV

TV + separate UHF and VHF antennas

equipment you will need

If UHF and VHF signals are brought into your home with two
separate antennas, you'll need to combine the antennas in order to
connect them to the TV. To do this you will need a UHF/VHF

combiner. (There are different combiners for different kinds of
leads. Check with your local electronics store for the kind of com-

biner you need.)

Pictured to the right is a
standard combiner.

To connect separate UHF and VHF antennas to your TV:

O Connect the UHF and VHF antenna leads to the appropriate

terminals on the UHF/Vt[F combiner.

O Press the combiner onto the antenna terminal on the rear of

the TV.

VHF Antenna UHF Antenna

(Channels2-13) (Channels14-69)

\\ I\l

/7//

-- Flat Twin Lead

\\_,\\\\_P !

Flat Twin Lead --

-'V Rear Terminals

300 Ohmto

75 Ohm

E) Combiner O

Back Side

Basic Connections 27

TV + VCR + antenna or cable without a
decoder box

equipment you will need

You may want to connect a VCR along with yoar antennas or cable.
To complete this hook-up, you may need the following equipment:

• One 75 ohm coaxial cable,

One set of RCA pin-type audio
cables,

One RCA pin-type video cable,
(if connecting a standard VCR),

OR

One S-Video cable for S-VHS

VCRs.

28 Chapter 2: Connecting Your TV

procedure

(See illustration on the following page.)

0 Connect the incoming cable or antenna to the ANTENNA IN

terminal on the VCR.

O Connect one end of a coaxial cable to the ANTENNA OUT

terminal on the VCR.

Connect the other end of the coaxial cable to the antenna
terminal on the TV.

O Connect an RCA pin-type video cable tc the VIDEO OUT

terminal on the back of the VCR. Connect the other end of this
cable to the VIDEO INPUT terminal on the back of the televi-

sion.

_Important:

_'Important:

_Important:

If you are connecting a Super _rHS (S-VHS)VCR, use an S-Video
cable instead of an RCA pin-type video cable. Connect this S-Video

cable to the S-VIDE0 OUT terminal on the VCR. Connect the other
end of this cable to the S-VIDEO INPUT terminal on the back of
the TV.

O Connect a set of RCA pin-type audio cables to the AUDIO OUT

terminals on the back of the VCR. Use the red cable tc connect
the right (R) channel and the white cable for connecting the left

(L) channel.

Connect the other ends of these cables r2 the AUDIO INPUT

terminals on the back of the TV.

If your VCR is monaural (non-stereo), you on:[y need to connect a
single RCA pin-type audio cable. Connect t:he cable to the VCR,
then connect the other end to the L (LEFT) audio input on the back

of the TV.

If your VCR has a video channel switch with an "0FF/AV" position,

set it that position. See your VCR's owner's gaide for details.

Start playing a tape on your VCR.

Use the INPUT button on :your TV's remote control to select
Input-1.

Basic Connections 29

TV + antenna or cable without a
decoder box (cont.)

O

Cable

IN

Antenna

OUT

O

0

{_]]_ or Antenna

VCR Rear Terminals

AUDIO OUT®.VIDEO OUT S-VIDEO OUT

lI°,°

Yellow Lead -- _ -- _ or the other

Incoming Cable

l _) _Connect

one

_) J but not both

TV Rear Terminals

----" • /--

O

-- White Lead

==_]33=

O

-Red Lead

30 Chapter 2: Connecting Your TV

._,-v,,,,ol

_111

TV + VCR + cable with a decoder box

equipment you will need

This hook-up will allow you to watch a non-scrambled channel
while you are recording another channel. Wl:en you complete this
hook-up, you should set up your remote control to operate your

cable box (see page 38).

To complete the hook-up, you will
need:

• One two-way splitter,

• Three lengths of 75 ohm coaxial

cable,

• One set of RCA pin-type audio
cables,

One RCA pin-type video cable
(if connecting a standard VCR),

fl÷}

OUT OUT

OR

One S-Video cable for S-Sr.[-IS
VCRs.

Basic Connections 31

TV + VCR + cable with a decoder box (cont.)

procedure

O Connect the incoming cable to the IN terminal on the two-way

splitter.

O Connect a coaxial decoder box to one of the OUT terminals on

the two-way splitter. Connect the other end of this cable to the

antenna terminal on the back of the TV.

Connect a second coaxial cable to the other OUT terminal on
the two-way splitter. Connect the other end of this cable to the

IN terminal on the decoder box.

O Connect a third coaxial cable to the OUT terminal of the

decoder box; connect the other end of this cable to the
ANTENNA-IN terminal oil the back of the VCR.

Connect an RCA pin video cable to the VIDEO OUT teizninal
on the back of the VCR. Connect the other end of this cable to

the VIDEO INPUT terminal on the back of the TV.

Important:

Important:

Important:

If you are connecting an S-VHS VCR, use an S-Video cable instead
of an RCA pin-type video cable. Connect this S-Video cable to the

S-VIDEO OUT terminal on the VCR. Connect the other end of this
cable to the S-VIDEO INPUT terminal on the back of the _V.

O Connect a set of RCA pin-type audio cables to the AUDIO OUT

terminals on the back of the VCR. Use the red cable to connect
the right (R) channel and the white cable tbr connecting the left

(L) channel.

Connect the other ends of these cables to the AUDIO INPUT
terminals on the back of the TV.

If your VCR is monaural (non-stereo), you only need to connect a
single RCA pin-type audio cable. Connect the cable to the VCR,
then connect the other end to the L (LEFT) audio input on the back

of the TV.

If your VCR has a video channel switch with an "OFF/AV" position,
set it that position. See your VCR's owner's guide for details.

Start playing a tape on your VCR.

Use the INPUT button on your TV's remote control to select
Input-1.

32 Chapter 2: Connecting Your TV

@

Incoming Cable

Cable Decoder Box

E_C[_ q Rear Terminals

OUT _N

VCR Rear Terminals

l

AUDIO OUT VIDEO OUT S-VIDEO OUT

Antenna L (_) (_

OUT

TV Rear Terminals

Basic Connections 33

'IV" + audio system

equipment you will need

To hook up an audio system, you will need:

• One set of RCA pin audio cables.

procedure

Connect the audio cables to the

0

AUDIO OUTPUT terminals on
the back of the TV. Use the red

IIo-/

cable to connect the right (R)
channel and the white cable to

connect the left (L) channel.

O Connect the other ends of these cables to the AUX IN terminals

on the back of the audio system.

O Turn off the television's speakers. To do this, press the AUDIO

function button on the remote control until you see the
"Speaker" display. Set the speakers to "Of?' by pressing the

ADJUST buttons. See "A_usting the sound," on page 54.

Set the audio system's input to the "ALE_" position.

Audio System Rear Terminals

-- White Lead

[_ RedLead O

-- White Lead

Red Lead

TV Rear Tern-inals

VHF/UHF

(75_)

AUX

---},- L (_)

--}'- R (_

>:hnportant: You should make this connection in addition t_ one of the other

connections in this chapter, not instead of other connections.

34 Chapter 2: Connecting Your TV

CHAPTE THREE

Operatmg i'our TV

R

Now that your TV is connected to the cable, antenna, or external

components, it's time to enjoy your equipment. This chapter will
explain how to operate the TV, first focusing on functions that are

basic and easy and then explaining some advanced features.

This chapter explains:

0 Getting Started

Using the Advanced Features

35

t Getting Started

This section is designed to get you started enjoying your new TV. If
you follow these procedures one by one, you _:[1 soon begin discov-

ering everything your television can do.

You'll find information on:

• Adjusting the color purity,

• Using the remote control to operate cable boxes mad
other brands of VCRs,

• Turning the TV on/off,

• Selecting the input source,

• Changing channels,

• Understanding the on-screen menus,

• Setting the clock,

• Memorizing channels,

• Adding and deleting channels,

• Renaming the input,

• Selecting the menu language,

• Using video mute,

• Adjusting the sound,

• Adjusting the picture, and

• Using the closed caption decoder.

36 Chapter 3: Operating Your TV

Adjusting the color purity

Because your Mitsubishi color television has a large screen picture
tube, the earth's magnetic field can cause discolored patches on the
edges of your screen. To correct this, follow the instructions below.

O Turn off the TV set.

O Determine the compass direction where the set is facing. The

direction is determined from the front of the screen facing
forward.

/ :_TRENGTH DIRECTION 1

J

_>Important:

Set the DIRECTION switch according to the chart below.

North

North East

North West

South

South East

South West

East

West

DIRECTION SWITCtt

S NEUTRAL N

X
X

X

X
X

STRENGTH SWITCHTV SET DIRECTION

X
X

X

O Turn the TV on, and check the color performance.

- If color impurity is still present, change the STRENGTH switch

to position "1." If there is still impmfity, wait a few minutes,
then press the DEGAUSS button on the control panel.

- You must adjust the color purity switches each time you move

the TV to a new location.

- If there is still color impurity after adjusting the switches,
contact your Mitsubishi Authorized Warranty Semdce Center.

Color impurity can also be caused by unshielded speakers and
strong magnets. Move these items away from your TV.

Getting Started 37

Using the remote control to operate cable boxes
and other brands of VCRs

operating Mitsubishi components

This TV's remote control comes programmed to operate Mitsubishi
TVs and VCRs. The select buttons (across the top of the remote )

determine which component the remote control will operate.

The following buttons are available when usi_g this TV:

• power button

• pause button

• mute control

• super quick view button

• quick view button

• volume control

• input button

• channel control

• enter button

operating VCRs or cable boxes from other manufacttvrers

The remote control is pre-set to operate Mitsubishi VCRs, but it
can also operate VCRs from other manufacturers as well. If you
have a VCR from another manuihcturer, or if y,_u have a cable box,

you should "set up" the remote control.

• audio and video controls

• menu button

• cancel button

• display button

• home button

• off-timer button

• number bu_tc,ns

• PIP controls

• VCR buttons

Each layer on the remote control (CABLE, VCF.-A, or VCR-B) can
be set for either a cable box or a VCR.

setting up the remote control to operate y,_ur VCR

O Turn off your VCR.

Press one of the select buttons across the top of the remote
control to choose the layer that you want to "set up." You can
choose between VCR-A, VCR-B or CABLE.

O While holding in the POWER button on the remote control,

enter the code number listed in the chart on the following page
for your brand of VCR. Be sure to enter both digits of th,e code

number. If more than one number is listc,d, try the first one.

Release the POWER button.

Press the POWER button again. Your VCR should turn on. If
the VCR turns on, your remote control is now "set up" correctly.

If your VCR does not turn on, repeat the instructions, trying
each code number listed for your brand of VCR. If none of those
code numbers work, try each number, 01 through 20.

38 Chapter 3: Operating Your TV

If yourVCR

is thisbrand...

Mitsubishi (A)
Mitsubishi (B)

Canon
Emerson

Funai
GE
Goldstar

Hitachi
JVC

...enterthis

code

01
02

03

04, 05

06

03

07
08

09

Ifyour VCR

is this brand...

Magnavox
Multitech

NEC
Panasonic

Philco
Philips

Quasar
RCA

Sanyo

...enterthis

code

03, 10, 11

O6

12

O3

03, 10

03, 10, 11

03

08, 13, 20

14

If yourV(:R

is this brand...

Scot

Sylvania

_honic

Teknika
Toshiba
Totevision

Zenith

...enl:erthis

code

15
16

_17,18

03, 10, 11 _

06

04, 06

15
O7
19

setting up the remote control to operate your cable, box

O Turn on your cable box.

O Press one of the select buttons across the top of the remote

control to choose the layer that you wan_ to "set up." "You can
choose between VCR-A, VCR-B or CABI,E.

O While holding in the POWER button on the remote contro!,

enter the code number listed in the chart below for your brand
of cable box. Be sure to enter both dig%s of the number. If more
than one number is listed, try the firs'_ one.

E>Important:

If yourcablebox Ifyourcablebox

isthis brand.., isthis branc....

General Instrument Philips
Hamlin

Jerrold

Macom

Oak

Panasonic

...enterthis

code

54, 55, 56, 57, 58, 59
60, 67, 68, 72, 85, 87
52, 53, 69

54, 55, 56, 57, 58, 59
60 67 68 72 85, 87

71
61, 62, 82 _____

63, 70

Pioneer
Oak

Regency ___
Scientific Atlanta

Tocom

Zenith

...ent_rthis

code

:73, 74, 75, 76, 77, 93,

94, 95, 96 97, 98, 99

164_65, 84

61, 62, 82
79

66, 86, 88_89, 91, 92

54, 55, 56, 57, 58, 59
60 67 68, 72, 85, 87

51

Release the POWER button.

O Press the POWER button again. Your cable box sho_:ld turn off

If the box turns off, your remote control is now set to operate
your cable box.

If your cable box does not turn on, repeat the instructions
above, trying each number listed for your brand of cable box. If

none of these numbers work, try each number, 51 through 99.

You may need to press the CHANNEL b_tt_ns to turn your cable

Getting Started 39

Using the remote control to operate cable boxes

and other brands of VCRs (cont.)

_Important:

Important:

_Important:

Sometimes manufacturers will c.hange their products, or they may

use more than one code. If this is the case, your remote may not be

able to operate your VCR or cable box.

Each layer (CABLE, VCR-A or VCR-B) can be set for either a cable
box or a VCR.

When you replace the batteries :in your remote control, the remote
may return to its initial setting.

using your remote control to operate your VCR

After you have set up your remote control fb_:your particular brand

of VCR, you can use the remote to operate your VCR.

O Use the select buttons across the top ofth_ remote control to

choose the layer you "set up" to operate the VCR: VCR-A,
VCR-B, or CABLE.

O Point the remote control at the VCR and p:ress the desired

buttons.

If you are using a Mitsubishi VCR, you will be able to use all of the

buttons on the remote control to operate your VCR except fi)r

MUTE, VOLUME and the PIP fhnction buttons, which will always
operate the TV itself.

If you are using another brand of VCR, you c:an use the POWER,
CHANNEL, REC, STOP, PAUSE, REW, PI_,kY and FF buttons to
operate your VCR.

using your remote control to operate your cable box

After you have set up your remote control for your particular brand

of cable box, you can use the remote to operate your cable box.

q[_ Use the select buttons across the top of the remote control to

choose the layer you "set up" to operate the cable box: VCR-A,

VCR-B, or CABLE.

Point the remote control at the cable box a:ad press the desired

buttons.

Only the POWER, CHANNEL, and number _0 - 9) buttons can be

used when operating your cable box.

40 Cha_ter 3: Operating Your TV

Turning the TV on/off

_Important:

_Important:

Before using the remote control to operate the TV, press the "TV"
select button on the remote control.

Use the POWER button on either the control panel or the r,emote
control to turn the TV on and off. The power indicator will light up
in green when you turn the TV on.

Even with the power turned off, there is a sma ll amount of current
that continues to flow into the 3_V.This maintains any changes to

the settings and operates the built-in clock and timing functions.
Unplugging the set will erase these settings, requiring you to set
them again. Unplug the TV only when it won't be used for a long

time.

000¢:_

_000_

_O00U

::Zzz_ 0 ¢b

POWER

When you turn on your TV for the first time, !;he screen may be
displaying the "Select Language" menu. You ,_hould select the on-

screen language you want to use. For more information, see page
52, "Selecting the menu language."

Getting Started 41

Selecting the input source

If you connected a component, such as a VCR, camcorder, or laserdisc
player, to your TV, you will need to change the !input source to view
the signal from the component.

To select an input source, press the input butto]_ (INPUT) o_] the
control panel or on the remote control.

0

The name of the input you have selected will be displayed briefly in
the corner of the screen.

42 Chapter 3: Operating Your TV

Changing channels

Your TV offers you four ways of changing channels once their
numbers have been programmed into channel memory:

• selecting a channel sequentially using the channel controls,

• directly accessing a channel by pressing the number battons,

• using the Quick View option to switch to a particular memo-

rized channel, and

• using the Super Quick View function to switch between chan-

nels on a user-chosen list_

To change channels faster, use either of the :[ollowing procedures:

• Enter three digits for every channel number, using ze:ros where

needed. (For example, enter "004" to view channel 4 and "028"

to view channel 28.)

• Press the ENTER button after selecting the number of the

channel. (For example, press "4" and "E_FrER" to view
channel 4.)

Important:

Cable channel numbers 0 and greater than :L26 are not used. TV
stations 0, i and 70 through 999 are not used. If these channel
numbers are pressed, the channel remain_ unchanged.

Getting Started 43

Changing channels (cont.)

,K:_c:::f:

'!ooo ©

I_ooo

changing channels

sequentially

To change channels:

O Press one of _he channel con-

trols (CH, CttANNEL) on the
control pane] or on the remote

control. The TV will automati-
cally tune Lothe next memo-

rized channel.

DImportant:

You cannot change channels sequentially until available channels
have been programmed into memory. (See "Memorizing channels,"

page 49.)

changing cha:anels directly

To move directly to a particular
channel without going through the

programmed Cl:Lannels in bel_ween:

ooo0

O Use the remote control to select

the number of the channel you
want to vie,_.

,..o O O_

_000
oOOO_

Press the ENTER button,,

44 Chapter 3: Operating Your TV

using the Quick View option

Quick View allows you to memo-
rize a particular channel and
switch to it quickly.

O Tune 1:othe channel you wish to

memorize.

O

Press arLd hold the QV button

for about 3 seconds. _/Vhen you

release 1,he button, tile channel
number will appear on the
screen, indicating that you have

memcri:_,ed that channel.

O After you've changed to another

channel, press the quick view
(QV) button to immediately

return to the memoI:[zed
channel.

0 If you press QV while you are

watchi_ g the memorized
channel, you will sw:itch to last

channel you were watching.

_Important:

The memorized channel will remain the ,_ame until you memorize a

new channel with the procedure described above.

using the Super Quick View
option

To view selected channels pro-
grammed into Super Quick View
memory:

_klJ _ U,'=

0©0_

_:_O O O
_OOO_

c:::_ 0

Enter the desired cbannels into
Super Quick View memory.

(See "Using the Super Quick

View tuning," page 65.)

Press the SQV button repeat-
edly _:oview the desired chan-
nels in sequence.

Getting Started 45

Understanding the on-screen menus,

One of the distinctive features of this TV is an on-screen menu
system that provides step-by-step instructions for using some of the

TV's special capabilities.

When using any of the on-screen menus, please keep the following
in mind:

• The on-screen menus will clear if no item is selected within ,5
minutes.

• Unavailable menu items are indicated by light blue letters,
instead of the normal white letters.

• Some on-screen menu items must be set before other items are
available. For example, "Set the timer" will only be available if

"Set the clock" has been set.

• You can exit the on-screen menus any time by pressing the
MENU button repeatedly. You will then return to regular TV
viewing.

• You can also exit the on-screen menus by pressing the HOME
button on the remote control.

46 Chapter 3: Operating Your TV

Setting the clock

Your TV contains an internal clock to indicate the current time. If
there is a broadcaster in your area that is sending the CU_Tent time

along with its regular broadcast signal, then your TV can automati-
cally set its clock with this signal. Otherwise, you can set the clock

yourself.

,_ TV Main Menu

QI irst Time Set-Up

Customize Viewing

_ Advanced Features

Use ADJUST to select.

Then press ENTER.
Press MENU to exit menus.

i(_ First Time Set-Up

1_ Set the clock

Memorize channels

Add/delete channels

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
"IV Main Menu.

('-_ Set the clock

-- ), Auto clock On
Day - -

Clock - -

Time zone Atlantic
Daylight savings On

Use ADJUST to select.

Then press ENTER.
Press MENU to return to

First Time Set-Up Menu.

O Press the MENU button on the

remote control. The TV Main
Menu will appear on the screen.

O Select "First Time Set-Up"

using the ADJUST buttons;
then, press the ENTER button.

You _LI1 see the "First Time

O

Set-Up" screen. Select "Set the
clock" using the ADJUST
buttons; then, press the ENTER

button..

O

If you want your TV to set its
clock aul:omatically, use the

ADJUST buttons to set "Auto
clock" to "On"; if you want to set

the clock yourself, set "Auto
clock" to "Off," then follow the
instructions in "Setting the
clock yourself," on page 48.

using automatic clock setting

• Set "Auto clock" to "On" using
the ADJUST buttons; press the

ENTF, R button.

['_ Set the clock

Auto clock On
Day Monday

Clock 10:00 am
Time zone Atlantic

Daylight savings On
Use ADJUST to select.
Then press ENTER.

Press MENU to return to
First Time Set-Up Menu.

Use the ADJUST bul:tons to
select the "Time zone" you are

in; then, press the ENTER
button. The available time

zones are: Atlantic, Eastern,
Central, Mountain, Pacific,

Alaska and Hawaii.

Getting Started 47

Setting the clock (cont.)

Set the clock

Auto clock On
Day Monday

Clock 10:00 am
Time zone Eastern

• Daylight savings On
Use ADJUST to select•

Then press ENTER.

Press MENU to return to
First Time Set-Up Menu.

If you follow daylight savings
time, set "Daylight savin_:s" to
"On" using: the ADJUST but-

tons. If you do not follow
daylight savings time, set it to

"Off." Press the ENTER button.

At this point, you have pre-
pared the '1_rto set its clock

automatically. The screen will
return to the "First Time Set-

Up" menu.

Important:

The TV can only set the clock automatically when there is a broad-
caster in your area that is sending the currenl: time via Extended

Data Services (XDS). The clock will start just after the TV receives
the XDS signal.

setting the clock yourself

Set the clock

• Auto clock Off

Day - -

Clock - -
Time zone - -

Daylight savings --

Use ADJUST to select.

Then press ENTER.

Press MENU to return to
First Time Set-Up Menu•

(_ Set the clock

• Day

Clock

Use ADJUST to select•

Then press ENTER.

Press MENU to return to
First Time Set-Up Menu,

Monday

• Set "Auto clock" to "Off' using

• the ADJUST buttons. Press the
ENTER button.

Select the "Day" using the
ADJUST buttons. Press the

ENTER butl;on.

(_ Set the clock

Day

• Clock

Use ADJUST to select•
Then press ENTER•

Press MENU to return to
First Time Set-Up Menu.

Monday
10:00 am

48 Chapter 3: Operating Your TV

• Set the "Clock" using the
ADJUST buttons.

• After you have set the "Day"

and "Clock," press the ENTER
button to :start the clock.

The screen will return to the "First
'rime Set-Up" menu.

Memorizing channels

You can use the menus to automatically memorize the channels
your TV can receive. Once channels are memorized, you can scan

through them using the channel controls on the remote control or
on the front panel.

Press the MENU button on the

Q First Time Set-Up

Set the clock

_, Memorize channels

Add/delete channels

Use ADJUST to select.
Then press ENTER.
Press MENU to return to
TV Main Menu.

['_ Memorize channels

What is connected to
your TV?

lib Cable antenna

Indoor/outdoor antenna

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
First _me Set-Up Menu.

0

remote control. The TV Main
Menu _dl] appear on the screen.

0

Select "First Time Set-.Up"
using the ADJUST buttons;

then, p_:e,;s ENTER.

Select "Memorize channels"

0

using the ADJUST buttons;
then, p:ress ENTER.

Use the _._DJUST buttons to

0

choose the type of antenna you
connected: Cable antenna or

Indoor/outdoor anten_.a. Press
ENTER.

_] Memodze chaRnels

Now memorizing all the
stations you can receive.

Channel 004

Net in memory

Please stand-by.
To cancel memorization,

press CANCEL.

[>Important: Channel controls will work only after channels have been memo-

rized. After memorization, use the channel c_ntrols (CH, CHAN-
NEL) to automatically advance to the next memorized channel. Use

the number buttons to select individual channels.

channel memorization is in
progress. A channel being

added 1;omemory will be labeled
"In melmory." Channe]is not
being added will be labeled "Not

in memolw." You can stop

channel memorization at any
time by pressing CANCEL.

0 You will see a message that

Getting Started 49

Adding and deleting channels

After all available channels have been programmed automatically,
channels with weaker signals can be added or deleted with the
following procedure.

Either "In memory" or
"Not in memory" will

appear.

Q First Time Set-Up

Set the clock
Memorize channels

• Add/delete channels

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

TV Main Menu.

-1- Add/delete channels

Channel 006

In memory

Use ADJUST to select
another channel.
Press CANCEL to delete.
Press MENU to return to

First Time Set-Up Menu.

O Press the MENU button on the

remote control. The TV Main
Menu will appear on the screen.

O Select "First Time Set-Up"

using the ADJUST button%
then, press ENTER.

Select "Ad&/delete channels"
using the ADJUST button%

then, press ENTER.

The "Add!delete channels"
screen will appear. Use the

ADJUST buttons to select the

channel you. would like to add
or delete.

(You can also use the CHAN-

NEL button o:a the remote

control to change channels.)

If a channel is labeled "In
memory," use the CANCEL

button to remove it from
memory. If a channel is labeled
"Not in memo:ry," use the

ENTER butto:a to add it to
memory

50 Chapter 3: Operating Your TV

O

When you are finished adding

and deleting channels, press

the HOME button to return to
normal TV _4ewing.

Renaming the input

This feature allows you to rename the externa:[ input. For example,
you might want to name the input "VCR" or "I-}ISC." The name you
give the input will appear on the on-screen display.

,_ "IV Main Menu

Q First Time Set-Up

[_] Customize Viewing

I_ Advanced Features

Use ADJUST to select.

Then press ENTER.
Press MENU to exit menus.

I_ Customize Viewing

_, Rename the input

Select Language
Use Video mute

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
"IV Main Menu.

Rename the input

Input label New name

_" Input - ....

O Press the MENU button on the

remote control. The TV Main
Menu will appear on the screen.

O Select "Cu_stomize Viewing _'

using the ADJUST buttons;
press ENTER.

You will see the "Customize
Viewing" screen. Select "Re-

name the :input" using the
ADJUST buttons; press

ENTER.

O Set each character in t:he new

name u,_ing the ADJUoT
buttons and the ENTER button.

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
Customize Viewing Menu.

You can rename the inputs
using letters (A-Z), numbers

(0-9), or symbols (:/., ( ) ! " # $
% & ' blank + ; < = > ? blank -).

When you press the CANCEL
button while setting the name,

the cur,;or will move one posi-
tion to the left. You can clear

the entire name by pressing
CANCEL when the cu:csor is at

the left-most position.

After you have finished naming
the input: press the MENU

button; the screen will return to
the "Customize Viewing" menu.

Getting Started 51

Selecting the menu language

This TV allows you to display the on-screen menus in one of tlhree
languages: English, Spanish, or French.

Customize Viewing

Rename the input:

• Select Language
Use VLdeo mute

Use ADJUST to select.
Then press ENTER.

Press MENU to return to

TV Main Menu.

_'1 Select Language

• English
EspaSol
Franc,,ais

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
Customize Viewing Menu.

O Press the Mt_;NU button on the

remote control. The TV Main
Menu will appear on the screen.

O Select "Customize Viewinl_'

using the ._DJUST buttons;
press ENTEP.

Select "Select Language" using
the ADJUST buttons; press

ENTER.

O Use the ADJ-JST buttons to

select the language you want.

O Press the ENTER or MEbHJ

button to return to the "Cus-
tomize Vie,_ag " menu.

52 Chapter 3: Operating Your TV

Using video mute

When you use the video mute fllnction, your TV will display a blue
screen whenever it is receiving a very weak TV signal or a weak
signal from a VCR. If you want to try. viewing a weak signal, you

can turn the video mute off.

Customize Viewing

Rename the input:
Select Language

b, Use Video mute

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
TV Main Menu.

[_Use Video mute

l* Automatic

Off

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

Customize Viewing Menu,

O Press the MENU butto:a on the

remote control. The TV Main
Menu will appear on the screen.

O Select "Customize Viewing"

using the .._DJUST buttons;
press ENTER.

Select U_e Video mute" using
the ADJ_LIST buttons; press

ENTER.

O

Using the ADJUST bu'Ltons,
select "Automatic" to turn video

mute on or "Off' to turn video
mute off.

Press the ENTER or I_,[ENU

button 130return to the "Cus-

tomize Viewing" menu.

Getting Started 53

Adjusting the sound

Your TV allows you to customize and adjust the settings of its

audio functions. This section giw_s you descriptions of each audio

function, then explains how to adjust the functions.

descriptions of audio functions

The "Listen to" function allows you to determine how your rIW will
receive an audio signal and play back the sound that you hear. You
can set this function to "Stereo," "S.A.P.," and[ "Mono."

• For almost all situations, you should choose "Stereo." W:[th this
setting, the TV will play stereo broadcasts in stereo and mono

broadcasts in mono. If a channel is broadcasting in stereo, the
word "Stereo" will be displayed when you tune to that channel.

• Some TV stations will broadcast a separate audio programming,
or S.A.P., signal. This signal i!s an additional audio soundtrack

that you can't hear during normal TV Viewing. An S.A.P. signal
might be related to the program you are watching (e.g. a
soundtrack in a foreign language), or it might be unrelated (e.g.
a weather report). If a channel is broadea,_ting an S.A.P. signal,
the letters "SAP" will appear on-screen when you tune to that
channel. Choose "Listen to: SAP" to hear the S.A.P. signal.

• Use the "Mono" setting if you are receiving a weak audio
signal. This setting will reduce background noise. However,

with this setting, the TV will only play in m_no, even if tlhe
program you are watching is in stereo.

_>Important:

54 Chapter 3: Operating Your TV

An on-screen display appears when programs are broadcast in

stereo or when a separate audio programming (S.A.P.) is awdlable.

The "Bass" function provides a scale that controls the volume of
low frequency sound.

The "Treble" function provides a scale that controls the volume of
high frequency sound.

The "Balance" function provides a scale that. aJjusts the level of
sound between the left and right speakers. Adjust the scale until
the sound seems to come equally from both speakers.

The "Surround" function creates simulated stereo and surround
effects. You can set this function to "Off," "Simulate," or "Hall."

• Select "Off' if you do not want to use any surround effects.

• Select "Simulate" if you are watching a non-stereo program;
your TV will create a simulated stereo effi?cl;.

• Select "Hall" if you are watching a stereo program; your TV will
use its built-in speakers to create a simulated surround effect,

making the sound seem to extend around and behind you.

Adjusting the sound (cont.)

The "Speaker" function allows you to turn the TV's internal
speakers on or off.

• Choose "On" if you want to play the TV's sound through the
TV's built-in speakers.

• Choose "Off' if you connected your TV to an audio system.

adjusting tile audio functions

Press the AUDIO button on the

0

© c::b o

OOO 0

_-(I0 Ilk

_qir/

OOOc

oQQQ

_QQQB

remote control repeatedly until
the function you want to adjust

appears on-screen. (The func-

tions appear at the center of the
bottom of the screen.)

While the function is slfill on the

O

screen, use the ADJUST
buttons tc adjust the function's

setting.

O The funct:ions will disappear

from the screen after a few
seconds. (You cannot adjust a

function if it is not on the
screen.)

Getting Started 55

Adjusting the picture

Your TV allows you to customize and adjust the settings of its

video functions. This sections gives you descriptions of each video
function, then explains how to adjust the functions.

descriptions of video functions

The "Tint" function lets you adjust the proport,ion of red to green in

the picture. This determines the delicate tones of color.

The "Color" function lets you determine the intensity of the color.

The "Contrast" function controls the level of white-to-black in the
picture. When contrast is low, you will be able to see the variety of

shades in the darker images on the screen. When the contrast is
high, the screen's dark images will appear more uniformly black,

but this will also make the colors on the screen seem more vibrant.

"Brightness" controls the overall brightness of the picture.

"Sharpness" adjusts the detail and clarity of the picture.

The "Color temp" (Color temperature) function allows you to set
how the TV will display white images.

• With the "Low" setting, white images on-screen will have a
yellow cast to them.

• With the "High" setting, white images on-screen will haw_ a

blue cast to them.

• With the "Middle" setting, white images on-screen will be

balanced between yellow and blue.

The "_" function controls the closed caption decoder. See page 57.

adjusting the video functions

O Press the VIDEO button on the

Oc:_o

_C::Z:bc=

oooC

remote control repeatedly until
the function you want to adjust

appears at the bottom of the
center of the screen.

OOOc

_000 f

c:_O O 0
_O

While the function is still on the

screen, use the ADJUST
buttons to adjust the function.

The functions will disappear
from the screen shortly. (You

cannot adjust a function if it is
not on the screen.)

56 Chapter 3: Operating Your TV

Using the closed caption decoder

Many broadcasters now supply closed captioning information along
with their regular broadcasts. Your TV can decode that information

and display it on the TV screen.

There are two types of captioning that broadcasters can send:

"standard" and "text."

Standard captioning is related to the program that is being
shown. Standard captioning usually follows the dialogue of the

characters on-screen.

Text captioning often contains information such as weather or
news. Text captioning blocks out your view of the program you are
watching.

Your TV can decode four different "standard captioning" signals

and four different "text captioning _' signals on each TV channel.
However, each station may be broadcasting only one or two
captioning signals, or none at. all.

_Important:

_Important:

_Important:

When setting the decoder you can choose:

• to display one of four "standard captioning" signals ( _,_--C7:1,

:2, _ :3, _ :4),

• to display one of four "text captioning" signals ( _-_ : Text 1, [] :
Text 2, [] : Text 3, _-_ : Text 4),

• to display captions when muting ( [] : _rhen Muting),

• or to turn the captions off ( [] : Off).

If you select "[] : When Muting," the standard captioning signal
( [] :1) will appear whenever you use the MUTE button.

If you set the decoder to a "standard" caplfion setting and tune to a
broadcaster that is not sending a caption si_,mal, no captions will

appear.

If you set the decoder to a "text" setting and. tune to a broadcaster
that is not sending a text sig:aal, a large black rectangle will block
your screen.

The content of captions are determined by the broadcaster. If your
captions show strange characters, misspellings, or odd grammar, it

is not a malfunction of the 27V.

Getting Started 57

Using the closed caption decoder (cont.)

adjusting the closed
captioning decoder

Vv]aen adjusting the closed caption

oooC

_1o I_

O00c

_OOO_

_000
_z_ 0 e

decoder, you can use the buttons
on the remote control or on the

control panel.

To use the closed caption decoder:

O Press the VIDEO button until

the closed captioning display

appears on the screen.

O Press the ADJUST buttons to

select the captioning setting

you want.

(See the previous page for an
explanation of the caption

settings.)

Important:

You can turn captions offby selecting the "off' seLting, or by
pressing the HOME button on the remote control during normal
TV viewing.

uses for closed captioning

Closed captioning was initially de_,_igned so that lhose with hearing
difficulties could better enjoy viewing television. However, clo_sed
captioning can also be used in other ways, such as:

• helping children learn to read,

• learning a foreign language, and

• using the television without disturbing others.

If you cannot display any captions on the screen, please keep iLn
mind that not all broadcasters, video tapes, or [a_erdiscs supply
closed caption signals.

Additionally, captions might not appear:

• if you are playing a video tape that is worn or deteriorated, or

• if you are starting to play a taserdisc from sti]l or search mode.

58 Chapter 3: Operating Your TV

Using the Advanced Features

This section explains how to use some of the more advanced func-
tions. You'll learn about:

• Setting the timer,

• Using the parental lock,

• Using the Super Quick View tuning, and

• Selecting an advanced PIP function.

59

Setting the timer

This special feature allows you to program the TV to turn on
automatically at a preset time. To set the timer:

O :Press the MEI_Sd button on the

_,, TV Main Menu

Q First Time Set-Up

:remote control. The TV Main
Metal will appear on the screen.

Customize Viewing

[_ Advanced Features

Use ADJUST to select.
Then press ENTER.

Press MENU to exit menus.

_ Advanced Features

b. Set the timer

Use parental lock
Use Super Quick View

Use Advanced PIP

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
"rv Main Menu.

Set the timer

1, Day --

Start time - -

Channel - -

Use ADJUST to select.

Then press ENTER.

Press MENU to return to
Advanced Features Menu.

O ,Select "Advanced Features"

using the ADJT_ST buttons;
press ENTER.

You will see the "Advanced
Features" screen. Select "Set

the timer" using the ADJUST
buttons; press ENTER.

0 Use the ADJUST buttons and

the ENTER button to set Day,

Start time, and Channel.

After setting the timer, make sure
that the program timer indicator

is lit. The indicaS_r will light in
orange when the TV is turned on

and light in red when the TV is
turned off. The indicator will light

in green when using the menus, or
when you have locked the TV.

[>Important:

When the timer turns the TV on, the display will flash as a warn-
ing. If you do not press any TV function buttons within about 5

minutes, the TV will automatically turn off. Press a TV function
button (such as the display button) to keep the [[W on and turn off
the flashing display.

60 Chapter 3: Operating Your TV

If you press the CANCEL butt;on
while setting the timer, the arrow
will move to the previous item. To
clear the timer, press the CAN-

CEL button wi_h the arrow at the
"Day" position.

Using the parental lock

This special feature allows you to lock the entire TV or lock an
individual channel. (You cannot lock the TV and lock an individual

channels at the same time.) When you turn on the lock, you enter a
4-digit secret code that will allow you to turn cff the lock later.

If you try to turn on a locked TV or view a locked channel, you will
see a message asking you to enter the secret, code. If you don't enter

the code within five minutes, the TV will turn off or tune to an

unlocked channel.

If you enter the secret code, the message will disappear and the

lock will be turned off temporaI_ly. However, the TV or channel will
be locked again after you turn off the TV. This will continue until
you turn the lock off permanently. To turn the lock off perma-

nently, follow the procedure later in this section.

using parental lock

_>Important:

_>Important:

_ Advanced Features

Set the timer

b" Use Parental lock

Use Super Quick View
Use Advanced PIP

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
TV Main Menu.

O Press the MENU button. The

TV Main Menu will ap]?ear.

Select "Advanced Features"

using the ADJUST button,_;
then, press ENTER.

Select"

U_.e parental lock" using

the ADJUST buttons; then,

[]_, Use Parental lock

_- Lock the TV

Lock the channel

press ENTER.

Select "Lock the TV" or "b_ck

the channel" using the ADJUST

buttons; then, press ENTER.

Use ADJUST to select.
Then press ENTER.
Press MENU to return to
Advanced Features Menu.

If you want to lock a particular channel, tune the TV to that
channel before you set the lock:.

If you turn the parental lock on, you cannot ELsethe timer.

Using the Advanced Features 61

Using the parental lock (cont.)

locking the '1_€

• The message for locking the TV

[_Lock the TV

will appear.

The lock is now off.

Enter your personal code

using NUMBER buttons.

Then press ENTER
to set the lock.

Press MENU to return to
Advanced Features Menu.

i,_ Lock the "IV

• Start : 2:00pm
End : 3:00pm

Use ADJUST to select.
Then press ENTER,

Press CANCEL to clear.
Press MENU to return to
Advanced Features Menu,

[]_ Lock the TV

Start : 2:00pm

• End :3:00pm

Use ADJUST to select.

Then press ENTER.

Press MENU to retum to

Advanced Features Menu.

° Enter a four-digit secret code

using the number buttons (0-9);
then, press the ENTER button.

Use the ADJUST buttons to

select "Start"':; press ENTER.

Use the ADJUST buttons to set
the time at which you want the

TV lock to turn on. Press
ENTER.

Use the ADJ2JST buttons to set
the time at which you want the

TV lock to turn off. Press
EN_FER. If you want the T7

lock: to be in effect all the time,
set the same '_'End" time as you

set for the "Star_" time.

Press HOME to exit the menus.

This "IV is locked.

Enter your personal code
using NUMBER buttons.
Then press ENTER

to watch this TV.

_>Important: Any lock that has been set will continue to work even if the clock

has lost its time.

62 Chapter 3: Operating Your TV

When you turn on a locked TV,
you will be aEked to enter your
four-digit sec:ret code. Enter the
code to temporarily disable the

lock:. The lock: will be enabled
again when you turn the ]_v_ off.

locking channels

[_ Lock the channel

The lock is now off.
Enter your personal code

using NUMBER buttons.
Then press ENTER

to select the channels.
Press MENU to return to
Advanced Features Menu.

Lock the channel

_. ...

Use ADJUST to select.

Then press ENTER.

Press MENU to retum to

Advanced Features Menu.

[_] Lock the channel

I_ Channel 0 0 3

...
...

• The message for locking a
channel will appear.

• Enter a four-digit secret code
using the number buttons ,(0-9);
press ENTER.

You will see the channel lock

set-up screen. Use the ADJUST

..°

..°

._°

buttons to select a position.

Press ENTER.

Use the ADJUST button to
choose the channel you want to

lock. Press ENTER.

Repeat the steps above to lock

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

Advanced Features Menu.

additional channels. When you
are finished, press the HOME

button to turn off the menus.

When you try to view a locked
channel, you will be asked to

This Channel is locked.

enter your four-digit secret
code. Enter r.he code to tempo-

rarily disable the lock. The lock
will be enabled again when you

Enter your personal code
using NUMBER buttons.

Then press ENTER
to watch this channel.

turn the TV off.

Using the Advanced Features 63

Using the parental lock (cont.)

canceling the parental lock

Parental lock 0-V)

Now, the lock is on.
Enter your personal code

using NUMBER buttons.
Then press ENTER to change

the lock.
Press MENU to return to the

Advanced Features Menu.

Use Parental lock (Channel)

Now, the lock is on.

Enter your personal code
using NUMBER buttons.

Then press ENTER to turn

the lock off.
Press MENU to return to

Advanced Features Menu,

O Press the MENU button. The

TV Main Merm will appear on
the screen.

Select "Advanced Features"
using the ADJUST buttons;
press ENTER.

Select "Use parental lock" using
the ADJUST buttons; press

ENTER.

0 Use the ADJT_IST button to

select the lock you want to
cancel. Press ENTER.

Entor the fbur digits of your
secret code using the number

buttons (0-9):; press ENTER.

Press the MENU button to
return to the "Advanced Fea-

tares" menu.

_Important:

If you forget your four-digit secret code, please see page 85.

64 Chapter 3: Operating Your TV

Using the Super Quick View tuning

Super-Quick-View allows you to cycle through a list of up to ten
channels with the SQV button. You use the menus to add channels

to the list or to remove channels from the list. You can also acid
channels to the list using only the remote control.

,_i, Advanced Features

Set the timer
Use parental lock

_" Use Super Quick View

Use Advanced PIP

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

TV Main Menu.

Use Super Quick View

ii, ..-

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
Advanced Features Menu.

g se Super Quick View

b" Channel 003

Use ADJUST to select.

Then press ENTER.

Press MENU to return to
Advanced Features Menu.

customizing the Super Quick

View list with the menus

O Press the MENU button on the

remote control. The TV Main
Menu will appear on the screen.

O Select "Advanced Features"

using the ADJUST buttons;
press ENTER.

Select "Use Super Quick View"
using the ADJUST buttons;

then, press the ENTER button.

O Use the _DJUST buttons to

select a position in the list;
press ENTER.

O Use the ADJUST buttons,

CHANNEL buttons or number
buttons to add a channel 1Lothe

list; press ENTER. You can
clear a channel by pressing the
CANCEL, button. Repeat these
steps to add channels to t:he
Super Q_LickView memory.

Press the MENU button to exit
this menu.

adding channels to the list with the remote control

O Use the channel controls to tune the TV 1_othe channel you

want to add to the list.

O Press and hold the SQV button for about 2 seconds. When you

release the button, the letr_ers "SQV" will appear under the
channel number, indicating that the channel has been pro-
grammed into Super Quick View memo_1.

Using the Advanced Features 65

Selecting an advanced PIP function

When you are using the PIP features, there are special functions
you can use. Before using these advanced functions, you need to

choose one in the menu. These advanced functions are:

• TV Still,

• Snap-shot, or

• Replay.

In "TV Still," the PIP image switches between st!ill and moving. In
"Snap-shot," you can view and move several frozen PIP images. In
"Replay," you can view still PIP images in sequence for a "strobe"
animation effect. These images will appear in sel;s of three (from a
total of seven stored images) at the speed you select. (See 'qJsing
the Advanced Picture-in-Picture (PIP) Modes," page 72.)

O Press the MENU button on the

, Advanced Features

Set the timer
Use parental lock

Use Super Quick View

), Use Advanced PIP

Use ADJUST to select.

Then press ENTER.

Press MENU to return to
TV Main Menu.

remote control. The TV Main
Menu will appear on the screen.

Select "Advanced Features"
using the ADJUST buttons;

press ENTER.

Select "Use Advanced PIP"
using the ADJUST buttons;

press ENTER.

• Current setting :

TV Still

Use ADJUST to select.

[_ Use Advanced PIP

Then press ENTER.

Press MENU to return to

Advanced Features menu.

[] Use Advanced PIP

Current setting:

• Reptayspeed : 1

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
Advanced Features Menu.

Replay

66 Chapter 3: Operating Your TV

Use the ADJUST buttons to

O

select the advanced feature you
would like to use: TV Still,

Snap-shot, or Replay. Press

ENTER.

When you select "Replay," the

next option will be "Replay
speed." Use the ADJUST

buttons to set the replay speed
from i to 9. (1=short intercal

and 9=long interval.) Press
ENTER. (See "Using the Replay
feature" on page 78 for more

infi)rmation.)

Press the MENU button to
return to the "Advanced Fea-

tures" menu.

_ CHAPTER FOUR

Using the S-pecial Features

In addition to the basic and advanced features explained in the
previous chapter, this TV offers the user several special features
not generally available on other brand TVs. This chapter will
explain how to use these distinctive features. It contains the
following topics:

0 Understanding the On-Screen Displays

0 Using the Off-Timer

0 Using the Advanced Picture-in-Picture

(PIP) Modes

67

Understanding the On-Screen Displays

Your TV provides an on-screen summary of the current settings for
the TV, as well as the information related to Extended Data Ser-
vices (XDS). XDS allows broadcasters to supply you with channel

information, program information, and the currenl; time. To view
this information, press the display button (DISP_kY) on the
remote control repeatedly. This section describes t:he displays in

the order that they occur.

The first time you press
DISPLAY, you will sea

display like this, if your
main source is an antenna:

OR

The first time you press
DISPLAY, you will see a

display like this, if your
main source is an input:

The second time you press
DISPLAY, you will see a

display like this:

The third time you press
DISPLAY, you will see a

display like this:

023 ESPN

Stereo & SAP SQV

O23

Thursday 10:23 am

Input

S-VIDEO

O23

Thursday 10:23 am

network name ]

I-programname1

The first setting ._.hows:

• channel nuraber,

• the call letters for this chanrml,

• stereo and/or SAP are available
for reception on this channel,

• this channel is programmed
into Super Quick View memory,

• PIP input source (when a PIP
image is showing),

• current day of the week, and.

• time.

The second setting shows:

• the externa:[ input source (or
input name),

• an S-Video cable has been

connected,

• PIP input, source (when a PIP

image is showing),

• current day of the week, and

• time.

The third setting shows where the
network name and program name
will appear if a broadcaster' is

supplying information via X_DS.

The fourth setting shows where
the program description will

appear if a broadcaster is sapply-
ing that information via XDS.

program description

DImportant: If the channel you are watching does not supply iifformation via

XDS, an error message will appear ("No name available," "No

description available"), and the "call letters" will not appear.

68 Chapter 4: Using the Special Features

€ Using the Off-Timer

This special function allows you to set the TV to turn off automati-

cally. You can set the TV to turn off after a period of time ran_ng
from 10 to 120 minutes (in ten minute intel"q_ds_,. In this section

you'll learn:

• Setting the off-timer, and

• Changing or canceling the off-timer.

Using the Off-timer 69

Setting the off-timer

@ _:_ Ol

c_ c_ c_ cD

000o

c=O00 _

",,_ O O 0 U

L__

_]}Press the off.-timer button.

(OFF-T) on the remote control.

P>Important:

TV Off timer 120 min.

O Select how long you want the

TV to stay on by repeatedly
pressing the off:timer button
(OFF-T). The time will decrease

in 10 minute intervals each
time you press the button.

If you later want to check: on

how much time is left in the off-

timer, press the off-timer

button (OFF-T) once. The on-.

screen display reads "off-timer"
and shows the amount of time

remaining.

During the last minute before the TV is set to turn off, "Off-timer 1
min." will flash in red to remind you that the off-timer is set.

TV Off timer 1 min.

Chapter 4: Using the Special Features

Changing or canceling the off-timer

TV Off timer 10 min.

O Press the off-timer butt;on

(OFF-T) oll the remote control.
An on-screen display will

indicate the amount of time
remaining until the TV will

turn off.

O

Continue pressing the off-timer

button (OFF-T) repeatedly to

change the remaining time or

cancel the off-timer. The off-
timer is canceled when" "

appears instead of the remain-
ing time.

Using the Off-timer 71

Using the Advanced Picture-in-Picture (PIP) Modes

The special features of this TV include the advanced picture-in-

picture (PIP) modes, which allow :you to view and manipulate the
images of two different sources at the same time. In this section
you'll learn about:

• Activating the PIP image,

• Selecting the source of the PIP image,

• Changing channels while using the PIP modes,

• Exchanging the PIP image and the main image,

• Moving the PIP image,

• Freezing the PIP image,

• Using the Snap-shot feature, and

• Using the Replay feature.

_>Important: You must have a VCR connected to the TV to see two different live

pictures when using PIP. The instructions for connecting your VCR
are described in Chapter 2.

72 Chapter 4: Using the Special Features

Activating the PIP image

_]) Select the. number of the TV

channel you want to view by
using the channel control

(CHANNEL).

PIP

Stereo & SAP SQV

I

Stereo & SAP SQV

ooo0

023 ESPN

023

023 ESPN

023

O Press the PIP button. A PIP'

image will appear in the bottom
right cornel: of the screen.

0 Press the PIP button again,.

within 10 ._econds; the PIP
image will change to a s.ma]ler

size.

(If you wait longer than 10
seconds, the PIP image will
disappear when you press the

PIP button.)

Important:

Important:

Press the PIP button once again
to cancel the PIP image.

When the main image is black and white, the PIP image will also

appear in black and white.

If you move the PIP image and then turn it off, it will remain in its
new position when you turn it on again.

Using the Advanced Picture-in-Picture (PIP) Modes 73

Selecting the source of the PIP image

O Turn your VCR on and select a

channel on the VCR that is

different than the channel you
see on your TV screen.

Press the source button

O

SOURCE

(SOURCE) on the remote
control repeatedly to select the

source of the PIP image: TV or
Input.

O The PIP image will change as

follows.

_Important:

÷ TV ----" Input

__]

To change the input of the background (main)image while a PIP
image is on the screen, press the input button (INPUT) on the

control panel or on the remote control.

Changing channels while using the PIP modes

You can use t:he buttons on the
remote control to change the

c:_ c::; o (:D

ooo0

988

/. _ x

ccJO 0 © II

channels of both the main image
and the small PIP image, as if'

your TV had two-tuners.

_]}Point the remote at the VCR

and press the VCR channel
button (VCR-CH) on the remote

control to change the channel of
the PIP image.

Press the CI-L_NNEL button on
the remote control to change
t:he channel of the main image.

E>Important:

When the source of both the main image and the PIP image is the
TV, the VCR channel (VCR-CH) button will not change the chan-
nels of the main image or the PIP image.

_Important:

You must have set up the "VCR-A" layer of your remote for this
button to work correctly. (See pages 38-40.)

74 Chapter 4: Using the Special Features

Exchanging the PIP image and the main image

Press the ENTER button to

exchange the contents of the main
(background) image and the PIP

image.

023 ESPN

Stereo & SAP SQV

Input

Moving the PIP image

@c:_o

0ooO

dmb\

_1 o I)_

qmmJ

OOOO

oO00
oOO0_

_0 o

input

¢23

Press the ADJUST (up/down)
buttons or right/left buttons to

move the PIP image.

_Important: If you move the PIP image and then turn it off, it will remain in its

new position when you turn it on again.

Using the Advanced Picture-in-Picture (PIP) Modes 75

Freezing the PIP image

[] Use Advanced PIP

), Current setting :

Use ADJUST to select.
Then press ENTER.

Press MENU to return to
Advanced Features Menu.

"IV Still

_O00Q

oO00O

O Select "Use Adwmced PIP':' in

the "Advanced Features" menu
and set it to "TV Still." (See

"Selecting an advanced PIP
function," page (;6.)

O Use the MENU button to return

to the normal picture.

O Press the PAUSE button to

freeze the PIP image on the
screen.

O Press PAUSE again to return

the PIP image to a "live"
picture.

000_

)Important: When you press the pause button while viewing the normal pictm:e,

the PIP image will appear and be _¥ozen.

disappears after a

few seconds

76 Chapter 4: Using the Special Features

TV Still

Using the Snap-shot feature

[_Use Advanced PIP

Currentsetting:

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

Advanced Features Menu.

Snap-shot

ooo0

OOOo

0000

c:::::_ O o

O Select "Use Advanced PIP" in

the "Advanced Features" menu
and set it to "Snap-shot." (See
"Selecting an advanced PIP

function," page 66.)

O Use the MENU button to return

to the normal picture.

Press the PAUSE button once;

a frozen PIP image and a

:moving P]:P image will appear.

0 Press tile PAUSE button again;

a third PIP image will appear,
moving. The previous two PIP

images will be frozen.

Each time you press the
PAUSE button, the PIP images
will shift upwards one by one:

the top ima_'e will be replaced

by the second image, the second
image will be replaced by the

third, and a new moving image

will appear in the third space.

To cancel the PIP image, press

the PIP button twice.

if the PIP image is off

PAUSE

®

PAUSE

®

PAUSE

IP-

c

if the PIP image is on

[]

PAUSE

®

[]

B

PAUSE

®

[]
[]

[] c

PA'JSE

• _

*A, B, C, D: the moving images

*a, b, c, d: the frozen images of A, B, C, and D at the instant the PAUSE

button is pressed.

Using the Advanced Picture-in-Picture (PIP)Modes 77

5D

Using the Replay feature

[] Use Advanced PIP

• Current setting :

Replay speed : 1

Use ADJUST to select.
Then press ENTER.

Press MENU to return to

Advanced Features Menu.

[] Use Advanced PIP

Current setting:

• Replay speed : 1

Use ADJUST to select.

Then press ENTER.

Press MENU to return to

Advanced Features Menu.

Replay

Replay

0 Select "Use Advanced PIP" in

the "Advanced Features" menu
and set it to "Replay." (See

"Selecting an advanced PIP
function," page 66.)

O Set the replay speed between 1

(short intelwal) and 9 (long
interval).

Use the MEI_FU button to :return
to t:he normal[ picture.

O Press the PAUSE button. The,

TV will memorize seven frames
of video from the main image

and display the first three of
these frames as PIP images.

(The interval between the
frames is determined by the

replay speed set in step 0.)

*al - a7 : memorized frames

PAUSE PAUSE PAUSE

i PAUSE

[] []

ooo0

888

O00_

_©00
_©008

A

PAUSE

®,

%]
[]
[] B

Each time you press the
PAUSE button, the memorized

frames will shift upwards.

To cancel the PIP images, press
the PIP button twice.

PAUSE PAUSE

[a] E@ %]

78 Chapter 4: Using the Special Features

_ CHAPTER FIVE

Troublesl oot-ing

Even though you're now familiar with the basic and advanced
operations of the TV, you may rlln into trouble from time to time as

you become accustomed to the TV. This chapter offers solutions to

some of the common problems you may encounter. We suggest that

you consult this chart before contacting a Mitsubishi service

representative.

79

Troubleshooting (cont.)

Problems Possible Solutions For More Information

The remote control doesn't
work.

The TV takes several
seconds to respond to button

commands.

Check that the batteries are
installed correctly.

Check that the select button
is set to "TV."

Be sure that you are point-
ing the tip of the remote

control toward the TV from
a distance of no more than
20 feet.

• Use the ENTER button to
avoid delays.

See "Getting ready to use
the remote control" in

Chapter 1 for an explanation
of how to install batteries in

the remote control.

See "Remote control buttons
and fu_ctions" in Chapter 1,

which explains where the
select buttons are located.

See "Getting ready to uae
the remote control" in

Chapter 1, which contains
pointers for using the remote

control

See "Changing channels" in
Chapter 3, which explains

the function of the ENTER
button.

You can't access a channel.

You can't see a different

picture in l_he reduced PIP
image.

80 Chapter 5: Troubleshooting

Be sure that the channel you
want to view is programmed

into memory.

Check that the TV is tuned
to the correct input source

(antenna) for that channel.

• Use the SOURCE button to
select the picture from your

VCR.

• Turn on your VCR and

select a channel different
from the one on your TV.

See "Memorizing channels"
in Chapter 3, which explains

how to program channels
into the TV's memory.

See "Selecting the input
source" in Chapter 3, which
explains how to change the
input source.

• See "Using the Advanced
Picture-in-Picture (:PIP)

Modes:" one page 72.

Problems Possible Solutions

For More Information

On-screen displays appear
each time you adjust a

function.

There's no sound even when
the volume is turned up.

• You forget the code you used
to set the parental lock.

• This is part of the normal
operation of the TV.

Check that the MUTE
button isn't on.

The TV's reception mode
may be set to "separate

audio program" (S.A.P.).

• Use the alternate procedure

that doesn't require the use
of the code.

See "Understanding the On-
Screen Displays" in Chapter
4 for a full explanation of
the on-screen displays.

See "Remote control buttons
and thnct!Lons" in Chapter 1,
whiclh explains the location

and funct!ion of the MUTE

button.

See "Adjusting the sound" in
Chapter 3, which explains

how to select the appropri-

ate reception mode.

• See the Appendix, "Proce-
dure for Bypassing the

Parental ]Lock."

You can't program the TV to
turn on automatically.

The sound doesn't match the
image on screen.

There is a large black
rectangle on the screen.

• The TV may be locked.

• The TV's reception mode
may be set to "separate
audio program" (S.A.P.).

The TV has been set to
"text" mode, but there is no

text information being
broadcast.

Troubleshooting 81

See "Using the parental
lock" under "Using the

Advanced Features" in

Chapter 3.

See "Adjusting the sound" in
Chapter 3, which explains
how to select the appropri-
ate reception mode.

• See "Using the closed
caption decoder" under "Get-
ting started" in chapter 3.

Caution and care

Warning: !

_>Important:

_Important:

Don't leave stationary images on-screen for more than 10 minutes.
These images can scar the TV, causing permanent damage to the

picture tube. Some examples of stationary images are:

• stock-market reports,

• station loges (especially bright ones),

• video game displays,

• shopping channel displays,

• the television's own on-screen displays.

If you plan to place speakers next to the TV, make sure they are
magnetically shielded. Ordinary speakers will cause distortion in
the picture due to their strong magnets. This disto]tion, however,
will not harm the picture tube.

For maximum enjoyment and safe operation of your MITSUBISHI

Color TV, please read the "IMPORTANT SAFEGUARDS" carefully
and apply them properly.

To keep your TV from toppling in the event of an earthquake, you
can use the clamp attached to the back of the te:[e_ision to secure it
to the wall. Simply run a cord or :cope through the clamp, then
attach the rope to the wall directly behind the tele_rision.

Cleaning

Normally, light dusting with a non-scratching duster will keep your
TV clean.

If you want to wipe down your TV, turn it off and unplug it. Then,
wipe it gently with a soft cloth slightly moistened with water'.
You can add a few drops of mild liquid detergent to the water for

oily dirt.

DO NOT allow liquid to enter the TV through the ventilation slots.

DO NOT use strong or abrasive cleaners.

DO NOT use spray liquids or cleaners directly on the TV's surface.

DO NOT scrub or rub the TV harshly. Wipe gently.

82 Chapter 5: Troubleshooting

Calling for service

If you are unable to correct a problem with your TV, consult your
MITSUBISHI dealer or MITSUBISHI Authorized Warranty

Service Center.

Do not adjust any controls not described in this owner's gllide.

Do not remove the protective back cover of this unit.

If you see one of the following display on your screen, you should
not change any settings. These are special displays used by the
factory.

_' Initial

Hotel : Off
Power res : Off

Ant : 1
Input : 1

When mute : On

VCH
0 0 COL 63

P, Initial 3 dia : On

E2RESET CCD : On
Hotel : Off Auto clock : On
Power res : Off SystemlA : Off

Ant : 1 PIP : On(or Off)

Input : I Mntr. fix : Off

When m_Jte: On

If one of these displays appears, make sure that all of the on/off
settings are the same as the illustrations above and then turn the
TV off. If any of the settings are different from the illustration
above, turn the TV off and consult your MITSUBISHI dealer' or
MITSUBISHI Authorized Warranty Service Center.

Troubleshooting 83

APPENDIX

Procedure for Bypassing the Parental Lock

Cut along dotted line and file after reading.

After you lock the TV, you will need the secret code in order to:

• view the locked TV, or

• cancel the lock.

If you forget the code, you can view the locked TV without entering
the code. To do this, simply press the buttons on your remote

labeled "QV" and "9" at the same time.

DImportant: Unlocking with this procedure is only temporary. To cancel the lock

completely, follow the procedure below:

O Press the "QV" button and the "9" button on the remote control

at the same time. This will unlock the TV.

O Press the MENU button to view the main menu. Use the

ADJUST button to select "Advanced Features." Press ENTER.

Use the ADJUST button to select "Use Parental Lock."

Use the ADJUST button to choose the lock you want to turn off.
If the TV is locked, select "Lock the TV', OR:
If the channel was locked, select "Lock the Channel':'.

O

If you selected "Lock the TV', you must press the CANCEL
button to clear both the start and the end time. Then press
HOME to return to viewing the TV, OR: If you selected "Lock
the Channel", you must press the ADJUS:F, ENTER and
CANCEL buttons to clear every channel from the screen. Then
press HOME to return to viewing the TV.

85

Index

A

A/V reset button .................. 13

adding channels .................. 50

adjust buttons ............... 18, 19

advanced features ............... 59

advanced PIP ...................... 66

antenna

connecting .................. 25, 27

terminal ............................ 22

audio

adjusting .......................... 54

button ............................... 18

input ................................. 23

output ............................... 22

system, connecting ........... 34

auto clock ............................. 47

B

back panel ........................... 22

balance ................................. 54

bass ...................................... 54

batteries .............................. 14

brightness ............................ 56

C

cable

connecting ...... 25, 26, 28, 31

cable box

codes ................................. 39

connecting .................. 26, 31

cancel button ....................... 18

care ....................................... 82

CC ................................... 56, 57

channel

adding/deleting ................ 50

changing ............................ 43

changing PIP .................... 74

control .......................... 13, 17

lock ................................... 63

memorizing ...................... 49

programming ................... 49

clock, setting ........................ 47

closed captions .............. 56, 57

color ..................................... 56

color purity

adjusting .......................... 37

buttons ............................. 13

color temperature ................ 56

connecting

antenna ...................... 25, 27

audio system .................... 34

cable ............... 25, 26, 28, 31

decoder box ................. 26, 31

TV ..................................... 21

VCR ............................ 28, 31

contrast ................................ 56

control panel, overview ....... 12

D

decoder box

codes ................................. 39

connecting .................. 26, 31

degauss button .................... 13

deleting channels ................ 50

direction switch ................... 13

display button ..................... 19

displays ................................ 68

E

enter button ................... 17, 1!9

espafiol ................................. 52

exchange button ............ 17, 19

exchanging, PIP image ....... 75

F

features

advanced .......................... 5!)

special ........................... 6, 6'7

fran_ais ................................ 52

freezing PIP ......................... 76

front panel ........................... 17.

H

home button ........................ 19

I

important safeguards ............ '3

input button .................. 13, 17

input

audio/video ....................... 23

renaming .......................... 51

selecting ........................... 42

installing batteries .............. 14

L

language:, selecting .............. 52

lock

bypassing ......................... 85

channe:L ............................. 63

TV ..................................... 62

M

memorizing channels .......... 49

menu button ........................ 18

menu language, selecting ... 52

menus, understanding. ....... 46

mono .................................... 54

moving tile PIP image ......... 75

mute control ......................... 17

mute, video .......................... 53

N

number buttons ................... 19

O

off-timer ................................. 68

off-timer button ..................... 19

on-screen di,_plays ................ 68

on/off, turning your TV. ....... 41

outputs, audio/video .............. 22

overview

back paael ......................... 22

control panel ..................... 12

remote control ................... 14

P

:parental lock ....................... 61

pause buttor. ......................... 19

picture, adjusting ................ 56

PIP (Picture-.in-picture) ...... 72

activating ......................... 73

advanced functions .......... 66

button ................................ 19

channel ............................. 74

exchanging images ........... 75

freezing ............................. 76

moving .............................. 75

replay. .............................. 78

snap-shot .......................... 77

source .............................. 74

87

powerbutton.................13,17

programtimerindicator.....13

programmingchannels.......49

Q

quick view ............................ 45

quick view button ................ 17

R

rear panel ............................ 22

remote control

buttons ............................. 16

overview ........................... 14

using ................................. 38

renaming the input ............. 51

replay ................................... 78

reset, A/V ............................. 13

S

s-video input ........................ 23

S.A.P .................................... 54

safeguards, important ........... 3

select buttons ...................... 17

service .................................. 83

setting the clock .................. 47

sharpness ............................ 56

snap-shot ............................. 77

sound, adjusting .................. 54

source button ....................... 19

source, PIP .......................... 74

special features ............... 6, 67

SQV button .......................... 17

stereo ................................... 54

strength switch ................... 13

super quick view ........... 45, 65

super quick view button ..... 17

surround .............................. 54

T

text ........................................ 57

time, setting ........................ 47

timer ..................................... 60

timer indicatcr .................... 13

timer, off .............................. 69

tint ....................................... 56

treble ................................... 54

troubleshooting ................... 79

turning your TV on/off .......... 41

TV lock ................................. 61

TV, connecting ...................... 21

TV, unpac_dng ......................... 7

U

unpacking your TV ................ 7

V

VCR

buttons .............................. 17

codes .................................... 39

connecting .................. 28.., 31

VCR-CH button ................... 19

video

adjusting .......................... 56

button ............................... 18

input ................................. 23

mute ................................. 53

output ............................... 22

volume control ............... 13, 17

W

wake-up timer ..................... 60

X

XDS ..................................... 68

88 Index

MITSUBISHI COLOR TELEVISION OR COLOR MONITOR

LIMITED WARRANTY

MITSUBISHI CONSUMER ELECTRONICS AMERICA, INC. ("MCEA") warrants to the original purchaser of this television or monitor if purchased from

an authorized MITSUBISHI Audio/Video Dealer that, should it prove defective by reason of improper workmanship andtor material:

a.Picture Tube. For two years from the date of purchase at retail, we will repair or replace, at our option, any defective picture lube without charge for the tube.
b.Other Parts. For one year from the date of original purchase at retail, we will repair or replace, at our option, any defective part without charge for the part.

c.All parts used for replacement are warranted for the remainder of the original warranty period.
d. Labor. For one year frora the date of original purchase at retail, we will provide the labor for a warranty repair by an antl_orized M1TSUBISHI service center

without charge.

e. Notice. To obtain warranty service, you must notify an authorized MITSUBISHI service center of any defect within the aFplicable warranty time period.

1. TO OBTAIN WARRANTY SERVICE DURING THE FIRST YEAR:

a. Contact your nearest authorized MITSUBISHI service center, whose name and address can be obtained from your MITSUBIS HI dealer or by writing orcalling

MELA at the address and telephone number provided below.

b. Warranty service will be: provided in your home or, if required, at an authorized service shop, provided that your television is located within the geographic

territory customarily covered by an authorized MITSUBISHI service center. If not. you must either deliver your television to an authorized service location at your
own expense, or pay for any travel and/or transportation costs the service center may charge to and from your home. Actual servic_ labor will be provided without
charge.

c. Proof of purchase date from an authorized MITSUBISHI Dealer is required when requesting wammty setvice. Present your sales receipt or other document
which establishes proof and date of purchase. THE RETURN OF THE OWNER REGISTRATION CARD IS NOT A CONDITION OF WARRANTY
COVERAGE. However, please return the Owner Registration Card so that we can contact you should a question of safety arise which could affect you.

2. AFTER THE FlRST YEAR, to obtain warranty service for a defective picture tube, you are responsible for d,-qivering the television or monitor to an authorized
MITSUBISHI service center at your own expense.

3. THIS WARRANTY DOES NOT COVER damage caused by: modification, alteration, repair or service o["this product by _nyone other than all authorized
MITSUBISHI service center; physical abuse to, or misuse of, the product; operation in a manner contrar?¢ to the instructions which accompany the product; freight
damage; or any damage caused by acts of God such as lightning or fluctuation in electrical power. This warran:y also excludes all costs arising fl-om installation,
adjustment of user controls, external antenna systems, service of products purchased or serviced outside the U.S A., initial technical adjustments (set-up) and user-
required maintenauce. Consult the operating instructions furnished with the product for information regarding user controls.

4. ANY EXPRESS WARRANTY NOT PROVIDED HEREIN, AND ANY REMEDY WHICH, BUT FOR THIS PROVISION, MIGHT ARISE BY
IMPLICATION OR OPERATION OF LAW, IS HEREBY EXCLUDED AND DIS CLAIMED. THE IMPLIED WARRANTIES OFMERCHANTABILITY AND
OF FITNESS FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO A TERM OF ONE YEAR.

5. UNDER NO CIRCUMSTANCES SHALL MELA BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE.

6. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental, specM, or consequential damages, so
the above limitations or exclusions may not apply to you.

7. This warranty gives you specific legal rights and you may also have other rights which vary from slate to state.

8. BEFORE REQUESTING SERVICE, please review the instruction booklet to insure proper installation and correct customer cc,ntrol adjustment. If the problem
persists, contact your nearest MITSUBISHI Dealer for name(s) of authorized MITSUBISHI Service Center(s). [f you are unable to obtain this information, please

call 1-800-332-2119, or write us at the address below.

MITSUBISHI CONSUMER ELECTRONICS AMERICA,INC.Noreross,P.O.Box °5025GA30091-5025 A MITSUBISHI

l

FtETAIN THIS PORTION FOR YOUR RECORDS /

"1

SERIAL NO.

I

CUSTOMER NAME

O

,.,TREET ADDRESS
CITY

PHONE ( )

STATE ZIP

PURCHASE DATE

/ /

MO DAY YR

PLACE OF PURCHASE

,,,_,MITSUBISHI

MITSUBISHI CONSUMER ELECTRONICS AMERICA, INC.

6100 Atlantic Boulevard
Norcross, GA 30071-.1305

_D1995 Mitsubishi Consumer Electronics America, Inc.

1371C908A1

Printed in U.S.A
