Cold Water – Gasoline – Belt Drive
Industrial cleaning contractors love the powerful
and lightweight CBA Aluminum Series because it
delivers high performance on a routine basis. It has
the power to blast through the toughest dirt and
grime. Stains on brickwork and concrete are
no match for this mighty machine.
PRESSURE WASHERS
CBA Aluminum Series
Pump:
Equipped with the Mi-T-M Pressure Relief Start which
eliminates pressure build-up in the system (Not available on
CBA-4004-1MCH)
into the system to protect from heat build-up (CAT and General
pump models)
n
valve
Water filter with clear sleeve for screen inspection
Frame:
Lightweight, corrosion-resistant aluminum frame and base plate
with 11⁄4-inch tube handles
four rubber isolators
belt guard for quick access to belts
n
External bypass system allows more water
n
Forged brass manifold
n
Patented vibration isolation plate with
n
Convenient gun/wand holder
n
Thermal relief
n
13-inch flat-free tires
n
Two-piece
CBA-4004-1MAK
Unit Includes:
n
Quick connect nozzles - 0°, 15°, 25° and 40°
non-marking high pressure hose with quick connects
Professional-grade insulated trigger gun with safety lock-off
50-foot x
n
Limited Warranties:
n
1 year Mi-T-M unloader
7 year AR, CAT and General pumps
3 year Honda and Kohler engines
Certification:
Intertek - Certified to UL-1776
3
⁄8-inch
n
CBA-4004-1MGH
MODEL NUMBER PSI GPM DISPLACEMENT/ENGINE PUMP Mi-T-M NO. UNLOADER LANCE DIMENSIONS (LxWxH) SHIP WT. NET WT.
CBA-3504-1MAH 3500 3.7 389cc Honda GX390 OHV AR 3-0308 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
CBA-3504-1MAK 3500 3.7 429cc Kohler CH440 OHV AR 3-0308 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
CBA-3504-1MGH 3500 4.0 389cc Honda GX390 OHV General 3-0393 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
CBA-4004-1MAH 4000 3.4 389cc Honda GX390 OHV AR 3-0308 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
CBA-4004-1MAK 4000 3.4 429cc Kohler CH440 OHV AR 3-0308 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
CBA-4004-1MCH 4000 3.7 389cc Honda GX390 OHV CAT 3-0450 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 206 lb. 156 lb.
CBA-4004-1MGH 4000 4.0 389cc Honda GX390 OHV General 3-0393 Mi-T-M, adjustable pressure 48in. 47x27.5x28.5in. 215 lb. 165 lb.
Accessories & Options:
PART NUMBER DESCRIPTION FITS MODELS
50-0161 High pressure detergent injector All models
851-0338 50-ft. x
3
⁄8
-in. non-marking high
pressure hose
All models
PART NUMBER DESCRIPTION FITS MODELS
AW-8400-0021 Low pressure detergent injector All models
CX-0082 External bypass system All AR pump models
9
