MiTEC TALK BH39 User Manual

BLUETOOTH HEADSET BH39

1. ABOUT BLUETOOTH HEADSET BH39

The Bluetooth Headset BH39 allows you the
freedom to make and receive calls while on
the move or in the office, after you connect
the headset to a compatible phone that
supports Bluetooth wireless technology.
Read this user guide carefully before using
the headset. Also read the user guide for
your phone, which provides important
safety and maintenance information.

2. BLUETOOTH WIRELESS
TECHNOLOGY

Bluetooth wireless technology makes
it possible to connect compatible
communication devices without using
cables. A Bluetooth connection does not
require the phone and the headset be in
line of sight, but both devices should be
within 10 metres (30 feet) of each other.
Connections can be subject to interference
from obstructions, such as walls or other
electronic devices.

The MiTEC BH39 Bluetooth Headset is
compliant with Bluetooth Specification v2.1

supporting Headset Profiles 1.1 and Hands­Free Profiles 1.5.
There may be restrictions on using
Bluetooth technology in some locations.
Check with your local authorities or service
provider.

3. OVERVIEW

The headset contains the following parts as
shown in the figure:

(1)Call Button /Answer /end a call
(2)Earhook
(3)Power Switch /Power ON/OFF
(Green=ON, Red=OFF)
(4)Charging socket
(5)Microphone
(6)Indicator light (LED) (Red/Blue)
(7)Volume control /Multi-point connection

4. CHARGING THE HEADSET
This device has an internal, rechargeable
battery which must be fully charged before
being used for the first time. It takes about 3
hours to charge the battery fully for the first
time. During charging, the indicator shows
a steady red. When the battery is fully
charged, the red light will turn blue. After the
initial charge, it takes about 90 minutes to
fully charge.

You can charge the headset either by
using the AC travel charger, USB charging
cable or the car charger depending on the
package accessories available. Please
check your package for details. The MiTEC
BH39 Bluetooth Headset is intended for use

with the chargers that are included in the
package.

YOUR PACKAGE HAS A USB CHARGING
CABLE INCLUDED

Plug the charger lead of USB charging
cable into the charging port of your
Bluetooth headset. Then plug the other
end of the USB charging cable into a
computer’s USB port or into a mains
charger with USB socket. When charging is
complete, remove the USB charging cable
and remove the charger lead from your
headset.

The fully charged battery has power for up
to 6 hours of talk time or up to 120 hours
of standby time. However, the talk and
standby times may vary when used with
different mobile phones, products that use
a Bluetooth connection, usage settings,
usage styles, and environments.

When the battery is running out of power,
the blue indicator light starts to flash 3 times
every 30 seconds. This indicates that the
