ST-13
CONTENTS
FIG.1 CASSETTE· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
FIG.2 DECK UNIT · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
• INDEX· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6
– 1 –
FIG. 1 CASSETTE
19
HDC
3BG
7
12
11
14
14
13
4
10
5
8
18
HAT
1
3
9*
WAD
16
17
2
9*
15
6
REAR STOPPER,PAPER(METRIC) are not necessary
*
when using inch-sized paper [8.5" x 14",8.5" x 11" or 5.5" x 8.5"].
– 2 –
FIG. 1 CASSETTE
Ref.
SP Part. No. Description
No.
'
1 2A107011 COVER,CASSETTE 1 1 1
'
2 2A107020 GROUND PLATE,CASSETTE 1 1 1
3 2A107030 SPRING,CASSETTE 2 2 2
4 2A107050 FRONT CLAW CASSETTE 1 1 1
5 76508130 SPRING BELT GUIDE ROLLER 1 1 1
6 19507011 CASSETTE,PAPER FEED 1 1 1
7 19507040 BASE,CASSETTE 1 1 1
'
8 19507050 LEVER,CASSETTE BASE RELEASE 1 1 1
9 19507080 REAR STOPPER,PAPER(METRIC) 2 2 2
10 34907021 FRONT CURSOR,CASSETTE 1 1 1
11 34907031 REAR CURSOR,CASSETTE 1 1 1
12 34907050 REAR CLAW,CASSETTE 1 1 1
'
13 34907060 LEVER,CURSOR RETAINING 1 1 1
14 34907070 PIN,CLAW CASSETTE 2 2 2
'
15 34907131 REAR STOPPER,PAPER 1 1 1
16 34907141 GEAR 18,CASSETTE 1 1 1
17 34907330 LABEL,PAPER UPPER LIMIT 1 1 1
18 68802070 SPRING A,LIFT UP 1 1 1
'
19 2A107060 FRICTION PLATE,CASSETTE 2 2 2
Quantity
230V120V 240V
Ref.
SP Part. No. Description
No.
3BG
Quantity
230V120V 240V
• Parts with "•" are component parts or sub-assemblies of the
assembly appearing immediately above them.
• Parts with "'" indicates the Service parts.
• Parts with "• •" are component parts or sub-assembly with "•"
appearing immediately above them.
– 3 –
FIG. 2 DECK UNIT
HAO
17
3BG
16
19
33
13
37
31
38
27
41
18
23
29
15
22
28
48
BBB
HAO
42
BBB
29
BBK
BHI
39
BBK
30
39
BBK
11
30
25
8
BHI
BHI
33
35
34
3
24
47
HAO
21
32
37
BBB
36
40
37
37
12
37
26
45
46
HAO
BBB
20
6
43
BBB
BBB
HAO
9
7
10
HCB
14
BBB
5
BBB
2
35
37
HAO
34
1
4
44
HDB
42
4
44
HDB
6
BBB
– 4 –
FIG. 2 DECK UNIT
Ref.
SP Part. No. Description
No.
'
1 3BG02010 BASE,PAPER FEED 1 1 1
'
2 3BG02020 GROUND PLATE,MACHINE 1 1 1
3 3BG02030 STOPPER,CASSETTE GROUND 1 1 1
4 3BG02040 SLIDER,CASSETTE 2 2 2
5 3BG02050 COVER,GROUND 1 1 1
6 3BG02060 PLATE SPRING,CASSETTE HOLDER 2 2 2
7 3BG02070 LEFT GROUND PLATE,MACHINE 1 1 1
'
8 3BG04010 COVER,RELEASE 1 1 1
'
9 3BG04020 UPPER REAR COVER 1 1 1
'
10 3BG04030 REAR COVER,LID 1 1 1
'
11 3BG04040 HOOK,RELEASE 1 1 1
12 72114120 GEAR 19,DEVELOPER UNIT 1 1 1
'
13 3BG05020 LABEL,CASSETTE SIZE 1 1 1
14 3BG06010 GUIDE,PAPER FEED 1 1 1
'
15 3BG06020 ROLLER,FEED 1 1 1
'
16 3BG06030 HOUSING,PAPER FEED 1 1 1
17 3BG06040 ACTUATOR,FEED 1 1 1
18 3BG06050 COVER,ACTUATOR 1 1 1
19 3BG06060 SPRING,ACTUATOR 1 1 1
20 3BG22010 MOUNT,DRIVE 1 1 1
21 3BG22020 GEAR 25/59 1 1 1
22 3BG22040 SHAFT,CLUTCH 1 1 1
23 3BG27010 WIRE,CASSETTE 1 1 1
'
24 3BG27030 MOTOR,CASSETTE 1 1 1
25 74318270 SPRING,TONER DISPOSAL 1 1 1
'
26 2AV27330 CLUTCH,PAPER FEED 1 1 1
'
27 2A106010 PULLEY,PAPER FEED 2 2 2
28 2A106040 SHAFT,PAPER FEED 1 1 1
'
29 2A106170 PULLEY B,PAPER FEED 2 2 2
30 2A106191 SUPPORT PLATE,GUIDE PULLEY 2 2 2
'
31 29806560 BUSHING 6 1 1 1
'
32 29806810 BUSHING,6 REGISTRATION 1 1 1
33 3A504020 COUPLER,RELEASE 2 2 2
'
34 3A506070 PULLEY,CONVEYING 2 2 2
35 3A506090 SPRING,PRESSING 2 2 2
36 34806140 STOPPER 4 1 1 1
37 34806150 STOPPER 5 6 6 6
'
38 34906150 INNER BUSHING,PAPER FEED 1 1 1
'
39 34907290 PULLEY,GUIDE 2 2 2
40 34918090 GEAR 19,DISPOSAL 1 1 1
Quantity
230V120V 240V
Ref.
SP Part. No. Description
No.
'
41 35327400 SWITCH,FEED 1 1 1
'
42 35927420 SWITCH,SIZE 2 2 2
'
43 36093040 PARTS MOTOR DRIVE PCB(SP) 1 1 1
'
44 66260030 BASE RUBBER,SORTER 4 4 4
'
45 67322230 BUSHING 8 1 1 1
46 M2105720 MINIATURE CLAMP,UAMS-05-2 1 1 1
47 M2107120 BINDING BAND SG-130 1 1 1
48 M2104260 EDGING,EDS-0607U(KITAGAWA) 1 1 1
3BG
Quantity
230V120V 240V
• Parts with "•" are component parts or sub-assemblies of the
assembly appearing immediately above them.
• Parts with "'" indicates the Service parts.
• Parts with "• •" are component parts or sub-assembly with "•"
appearing immediately above them.
– 5 –
INDEX
Part. No.SP Description
Quantity
120V 240V
230V
Fig. No.
Part. No.SP Description
Quantity
120V 240V
230V
3BG
Fig. No.
19507011 CASSETTE,PAPER FEED 1 1 1 1
19507040 BASE,CASSETTE 1 1 1 1
'
19507050 LEVER,CASSETTE BASE RELEASE 1 1 1 1
19507080 REAR STOPPER,PAPER(METRIC) 2 2 2 1
'
2AV27330 CLUTCH,PAPER FEED 1 1 1 2
'
2A106010 PULLEY,PAPER FEED 2 2 2 2
2A106040 SHAFT,PAPER FEED 1 1 1 2
'
2A106170 PULLEY B,PAPER FEED 2 2 2 2
2A106191 SUPPORT PLATE,GUIDE PULLEY 2 2 2 2
'
2A107011 COVER,CASSETTE 1 1 1 1
'
2A107020 GROUND PLATE,CASSETTE 1 1 1 1
2A107030 SPRING,CASSETTE 2 2 2 1
2A107050 FRONT CLAW CASSETTE 1 1 1 1
'
2A107060 FRICTION PLATE,CASSETTE 2 2 2 1
'
29806560 BUSHING 6 1 1 1 2
'
29806810 BUSHING,6 REGISTRATION 1 1 1 2
3A504020 COUPLER,RELEASE 2 2 2 2
'
3A506070 PULLEY,CONVEYING 2 2 2 2
3A506090 SPRING,PRESSING 2 2 2 2
'
3BG02010 BASE,PAPER FEED 1 1 1 2
'
3BG02020 GROUND PLATE,MACHINE 1 1 1 2
3BG02030 STOPPER,CASSETTE GROUND 1 1 1 2
3BG02040 SLIDER,CASSETTE 2 2 2 2
3BG02050 COVER,GROUND 1 1 1 2
3BG02060 PLATE SPRING,CASSETTE HOLDER 2 2 2 2
3BG02070 LEFT GROUND PLATE,MACHINE 1 1 1 2
'
3BG04010 COVER,RELEASE 1 1 1 2
'
3BG04020 UPPER REAR COVER 1 1 1 2
'
3BG04030 REAR COVER,LID 1 1 1 2
'
3BG04040 HOOK,RELEASE 1 1 1 2
'
3BG05020 LABEL,CASSETTE SIZE 1 1 1 2
3BG06010 GUIDE,PAPER FEED 1 1 1 2
'
3BG06020 ROLLER,FEED 1 1 1 2
'
3BG06030 HOUSING,PAPER FEED 1 1 1 2
3BG06040 ACTUATOR,FEED 1 1 1 2
3BG06050 COVER,ACTUATOR 1 1 1 2
3BG06060 SPRING,ACTUATOR 1 1 1 2
3BG22010 MOUNT,DRIVE 1 1 1 2
3BG22020 GEAR 25/59 1 1 1 2
3BG22040 SHAFT,CLUTCH 1 1 1 2
3BG27010 WIRE,CASSETTE 1 1 1 2
'
3BG27030 MOTOR,CASSETTE 1 1 1 2
34806140 STOPPER 4 1 1 1 2
34806150 STOPPER 5 6 6 6 2
'
34906150 INNER BUSHING,PAPER FEED 1 1 1 2
34907021 FRONT CURSOR,CASSETTE 1 1 1 1
34907031 REAR CURSOR,CASSETTE 1 1 1 1
34907050 REAR CLAW,CASSETTE 1 1 1 1
'
34907060 LEVER,CURSOR RETAINING 1 1 1 1
34907070 PIN,CLAW CASSETTE 2 2 2 1
'
34907131 REAR STOPPER,PAPER 1 1 1 1
34907141 GEAR 18,CASSETTE 1 1 1 1
'
34907290 PULLEY,GUIDE 2 2 2 2
34907330 LABEL,PAPER UPPER LIMIT 1 1 1 1
34918090 GEAR 19,DISPOSAL 1 1 1 2
'
35327400 SWITCH,FEED 1 1 1 2
'
35927420 SWITCH,SIZE 2 2 2 2
'
36093040 PARTS MOTOR DRIVE PCB(SP) 1 1 1 2
'
66260030 BASE RUBBER,SORTER 4 4 4 2
'
67322230 BUSHING 8 1 1 1 2
68802070 SPRING A,LIFT UP 1 1 1 1
72114120 GEAR 19,DEVELOPER UNIT 1 1 1 2
74318270 SPRING,TONER DISPOSAL 1 1 1 2
76508130 SPRING BELT GUIDE ROLLER 1 1 1 1
M2104260 EDGING,EDS-0607U(KITAGAWA) 1 1 1 2
M2105720 MINIATURE CLAMP,UAMS-05-2 1 1 1 2
M2107120 BINDING BAND SG-130 1 1 1 2
• Parts with "'" indicates the Service parts.
– 6 –
