Presario 2200/4200
OPEN (3.2V)
Processor Boards Assembly Spare Part System
Board, Proc, w/ 16 MB
RAM/ 2MB VRAM
Board, Proc, w/ 16 MB
RAM/ 1MB VRAM
Board, Proc, w/ 32 MB,
w/ 2 MB
Board, Proc, ES 319277-001 4240ES
Board, Processor, w/o
Processor
Board, Processor, w/o
Processor
Board, Proc, 166MGX 292535-001 (LA)
Board, Proc, 180MGX 292536-001 2200, 10, 12
Board, Proc, 200MGX 292538-001 2230, 32
Board, Proc, 586 292598-001 4220, 12ES, 22
Board, Proc, 686, 512K 310128-101 311009-001 4230ES
CPU Clock Multiplier JP1 JP2 JP2 JP3 JP4
233 OPEN 2-3 1-2 5-6 (3.2V) OPEN
266 1-2, 5-6 2-3 1-2
Configuration Jumper Clear
327068-101 327149-001 2240, 44ES
327068-102 327149-002 2240, 46 (US,
LA, Brazil only)
310198-101 319208-001 2253, 54, 55, 56
337362-001 2256, 57, 58, 60 , 62,
64, 66, 68, 70, 74 , 75,
76, 78
387610-001 2 2 8 1 , 8 2 , 83 , 8 4 ,
85V, 86, 88, 89, 90,
92, 93, 94, 95, 97
2200, 12ES
292536-001 (Dom)
Jumper Settings, Presario 2200
3-4
1 – 2 Keep configuration info (CMOS) when
power is off
2 – 3 Clear config info when power is off
Jumper Settings, Presario 4200
CPU Clock Multiplier Freq 1 Freq 2 Processor
3.5x 1 – 2 1 – 2 233
3x 1 – 2 2 – 3 200
2.5x 2 – 3 2 – 3 150, 166
2x 2 – 3 1 – 2 120, 133
Clock Speed CLK1 CLK2 Processor
66 2 – 3 2 – 3 133, 166, 200, 233
60 1 – 2 1 – 2 120, 150
Configuration Jumper Clear 1
1 – 2 Keep configuration info (CMOS)
when power is off
2 – 3 Clear config. info when power is off
Jumper Settings, Presario 4230 E S
CPU Clock Multiplier JP1 JP2 JP3
233 OFF ON ON
266 ON OFF OFF
300 ON OFF ON
333 ON ON OFF
Configuration Jumper Settings Description
J17 1 – 2 Keep configuration info (CMOS)
when power is off
2 – 3 Clear config. info when power is off
3-34 Volume One
Page 2
Presario 2200/4200
Jumper Settings, Presario 4240ES
CPU Clock Multiplier JP1 JP2 JP2 JP3 JP4
233 OPEN 2-3 1-2 5-6 (3.2V) OPEN
266 1-2, 5-6 2-3 1-2 OPEN (3.2V) 3-4
Configuration
Codes
BP62 292598-001 4220
BP63 292598-001 4220
BP64 292598-001 4222
BP65 292598-001 4220
BP72 292536-001 2200
BP73 292536-001 2200
BP82 292536-001 2210
BP83 292536-001 2210
BP6N 292598-001 4212ES
BP8C 292536-001 2212
BP8M 292536-001 2210
BQQ2 311009-001 4230ES
BTF2 319277-001 4240ES
BTS2 327149-002 2246
BTT6 327149-001 2240
BTT7 327149-001 2240
BTT8 327149-001 2240
BTT9 327149-001 2240
BTTC 327149-001 2244ES
BTTD 327149-002 2240
BTTF 327149-001 2240
BTTG 327149-002 2240
BTTH 327149-001 2240
BTTJ 327149-001 2240
BXRB 319208-001 2254
BXRJ 319208-001 2254
BXRF 319208-001 2253
BXRF 319208-001 2254
BXRG 319208-001 2255
BXRH 319208-001 2255
BXRJ 319208-001 2255
BXR2 319208-001 2254
BXR4 319208-001 2254
BXR6 319208-001 2254
BXR7 319208-001 2254
BXR8 319208-001 2254
BXR9 319208-001 2253
BXS2 319208-001 2256
BXS3 319208-001 2255
BXT2 337362-001 2276
BXT3 337362-001 2274
BXT4 337362-001 2270, 75
BXT5 337362-001 2270, 75
System Board or Processor
Board Spare Part Model
Continued
Volume One 3-35
Page 3
Presario 2200/4200
Configuration
Codes
BXT6 337362-001 2270, 78
BXT7 337362-001 2274, 75
BXTB 337362-001 2274
BXTC 337362-001 2274
BXTD 337362-001 2278
CDQB 337362-001 2262
CDQC 337362-001 2264
CDQD 337362-001 2260
CDQ2 337362-001 2262
CDQ3 337362-001 2262
CDQ5 337362-001 2260
CDQ6 337362-001 2268
CDQ7 337362-001 2262
CDQ8 337362-001 2262
CDQ9 337362-001 2266
CFH2 387610-001 2288
CFH4 387610-001 2289
CFH5 387610-001 2288
CFJ2 387610-001 2292
CFJ3 387610-001 2297
CFJ6 387610-001 2294
CGV2 387610-001 2282
CGV4 387610-001 2280
CGV5 387610-001 2282
CGV6 387610-001 2284
CGV7 387610-001 2284
CGV9 387610-001 2280
CGVB 387610-001 2286
CGVC 387610-001 2285V
CGW2 387610-001 2294
CGW3 387610-001 2294
CGW4 387610-001 2293
CGW6 387610-001 2290
System Board or Processor
Board Spare Part Model
Microprocessors Assembly Spare Part System
166 MHz 235229-001 4200, 4220, 4222
166 MHz 240181-001 4212ES
200 MHz 327169-001 2240, 2244ES
233 MHz 170724-001 2246
233X 296576-003 319281-001 2253, 54
266 MHz 286275-001 4230ES
266X 296576-005 319236-001 2254, 55
300, w/ Heat Sink 320471-002 337374-001 2270, 74
300/66 (MX2) 337375-001 2260, 62
300/75 (MX-2) 386217-001 2262, 64, 66
300X 320471-004 319336-001 2255, 2256
333 278308-002 320666-001 4240ES
333/100, MHz, K6S-2 401555-001 2290, 92, 94
333/100, MHz, w/ Heat
Sink
P333, M2 388239-001 2281, 82, 83, 84, 85 V, 86
P350, M2 388240-001 2288, 89
337364-001 2275, 76, 78
Continued
3-36 Volume One
Page 4
Presario 2200/4200
Microprocessors Assembly Spare Part System
350, K6S-2 388241-001 2293, 94, 97
400, K6S-2 330631-001 320668-001 2295, 97
Heat Sink 292644-001 4220,4222, 4212ES
Heat Sink w/ Clip 327170-001 2240 Series
Heat Sink w/ Clip 337369-001 2281, 82, 83, 84, 85V,
86, 88, 89; 2290
Series
Heat Sink w/ Clip 317216-001 4230ES
Memory Assembly Spare Part System
1 MB VRAM 210257-004 327265-001 2240 Series, 2253,
54, 55, 56
8 MB, 60ns, SDRAM 278029-002 288438-001 2240, 2244ES
16 MB, 60ns, SDRAM 271108-002 271117-001 4200
16 MB, 60ns, SDRAM 278030-002 278066-001 2240, 2244ES, 2246,
2255, 2256
16 MB, 60ns, SDRAM 320759-101 319327-001 4240ES
16 MB, 100 MHz, SDRAM 323010-001 166969-001 2274, 76, 78, 82, 84,
85V, 86, 89, 93, 94,
95
32 MB, 60ns, SDRAM 271109-002 271118-001 4200
32 MB, 60ns, SDRAM 286548-001 304287-001 4230ES
32 MB, 60ns, SDRAM 320767-101
320766-101
32 MB, 100 MHz, DIMM 323029-001 337372-001 2281, 82, 84, 85V,
64 MB, 100 MHz, DIMM 323012-001 179190-001 2262, 66, 74, 75, 78,
256K Cache 237716-001 243117-001 2240 Series, 2253,
512K Cache 240108-001 243117-002 4230ES
319326-001 2260, 62, 64, 70;
4240ES
86, 89, 93, 94, 95, 97
83, 88, 89, 90, 92, 94,
97
2254, 2255, 2256
Miscellaneous Spare Part System
Backplane Board, w/ NIC, w/o ISA 337360-001 2262, 74, 78, 83, 84,
89, 94
Backplane Board, w/o NIC 387611-001 2281, 82, 85V, 86, 88,
90, 92, 93, 94, 95, 97
Backplane Board, w/o NIC, w/ ISA 337359-001 2262, 74, 76
Backplane Board, w/o NIC, w/o ISA 386216-001 2260, 64, 66, 70, 74,
75
Bezel 319207-001 2253, 54, 55, 2256,
Bezel 337358-001 2280 Series, 2290
Series
Bezel Button Board w/ Cable 292562-001 Prior to 2240 Series
and 4230ES
Bezel Button Board w/ Cable 298468-001 2240 Series, 4230ES
Bezel Button Board w/ Cable 319206-001 2250 Series; 4240ES
Bezel, ES 319279-001 4240ES
Bezel, Front w/ Buttons 292561-001 Prior to 2240 Series
and 4230ES
Bezel, Front w/ Buttons 298470-001 2240 Series, 4230ES
Button/Headphone Board w/ Cable 337357-001 2260 Series, 2270
Series, 2280 Series,
2290 Series
Hard Drive Mounting Bracket 243231-001 2240 Series, 2253, 54,
55, 56, 4230 Series for
3.5 inch drive in 5.25
inch bay,
Continued
Volume One 3-37
Page 5
Presario 2200/4200
Miscellaneous Assembly Spare Part System
Fan, System 298474-001 4230ES
Fan, System 292617-001 4212ES, 20, 22
Headphone Board 298469-001 2244ES, 4230ES,
4240ES
Keyboard, US English,
Sunset
Keyboard, US English,
Education
Keyboard, Ivory – US/CAN
English
Misc Hardware Kit 298592-001 2240 Series; 4240ES
Misc Hardware/Plastic Kit 337368-001 2260 Series, 2270
Modem 293020-001 4212ES (Teacher buy
Modem, 33.6/56K 007201-003 317296-001 2254, 55, 62, 74, 76
Modem, 56K,
Controllerless – Z(3C)
Modem, 56K 292269-003 2253, 54, 55, 56
Modem, Diamond - Spain 170762-073 2254
Modem, Diamond - Spain 334790-021 334808-021 2282, 88, 92, 93, 94,
Mouse, KYE Shielded 149998-006 199181-401 2240 Series, 2250
Mouse, Ivory 141649-008 337416-001 2260 Series, 2270
Mouse, Scroll 334684-001 334689-001 2290, 94, 97
Speaker, Left 292612-001 Prior to 2240 Series
Speaker, Left 298479-001 2240 Series, 4230ES,
Speaker, Right w/
Enclosure
Speaker, Right w/
Enclosure
286220-003 304286-003 2240, 46, 85V, 86;
340740-003 340869-003 2254, 55, 56, 64, 66,
337550-001 337559-001 2262, 64, 66, 74, 75,
286241-005 2200; 4212ES
2244ES; 4230ES,
4240ES
75, 81, 85V, 86, 92, 94
Series; 2281, 82, 83,
84, 85V, 86, 88, 89;
2290 Series
program)
78, 84, 85V, 86, 89,
94, 97
95, 97
Series
Series; 2281, 82, 83,
84, 85V, 86, 88, 89;
2290 Series
and 4230ES
4240ES
292611-001 Prior to 2240 Series
and 4230ES
298480-001 2240 Series, 4230ES,
4240ES
Modem Cable Kits Assembly Spare Part System
Cable Kit, Modem, UK 165227-033 165224-032 2282, 90, 92
Cable Kit, Modem, UK 165227-003 165224-033 2240, 54, 55, 56, 57,
58, 62, 74
Cable Kit, Modem, US,
PR, Can, Caribbean, LA,
Brazil, APD, Prc, Taiwan,
Japan, Spain
Cable Kit, Modem 165224-001 2240
Cable Kit, Modem w/
Adapter, Aus, NZ
Cable Kit, Modem w/
Adapter, Belgium
Cable Kit, Modem w/
Adapter, Denmark
Cable Kit, Modem w/
Adapter, France
112666-003 137256-001 2240, 2240ES, 2254,
55, 56, 57, 58, 62, 64,
75, 78, 82, 83, 84,
85V, 86, 88, 89, 93,
94, 95, 97
112666-005 304398-011 2254, 57, 62, 82, 94,
97
112666-005 304398-181 2254, 57, 62, 92
112666-005 304398-081 2254, 57, 92
112666-005 304398-051 2254, 55, 56, 57, 58,
60, 62, 92
Continued
3-38 Volume One
Page 6
Presario 2200/4200
84, 85V, 86, 88, 89, 94
Modem Cable Kits Assembly Spare Part System
Cable Kit, Modem w/
Adapter, Finland
Cable Kit, Modem w/
Adapter, Italy
Cable Kit, Modem w/
Adapter, Netherlands
Cable Kit, Modem w/
Adapter, Sweden
Cable Kit, Modem w/
Adapter, Switzerland
Controller Boards Assembly Spare Part System
NIC PCI 10/100 169849-001 4230ES, 2244ES
PCI, 10/100, w/ TX 317607-001 317606-001 4240ES
Hard Drives Assembly Spare Part System
1.6 GB, IDE, 3.5” 292542-001 2200, 10, 12
2.1 GB, IDE 292541-001 4212ES, 20, 22
2.1 GB, IDE 328285-001
2.1 GB, IDE, 3.5” 327213-001 2240, 2244ES, 2246
3.2 GB, IDE 337564-001 2253, 54, 55
3.2 GB, IDE 388237-001 2282
4.0 GB, IDE 286248-001 2253, 2254, 55, 56,
4.0 GB, IDE 328287-001
6.0 GB, IDE 241139-001 271127-001 2255
6.0 GB, IDE 166973-001 2275
6.0 GB, IDE 387612-001 2284, 86, 88, 89, 94,
8.0 GB, IDE 334180-001 337419-001 2258
8.0 GB, IDE 298464-001 4240ES
112666-005 304398-351 2254, 57, 92
112666-005 304398-061 2254, 57, 62, 92
112666-005 304398-331 2254, 55, 57, 58, 62,
74, 92
112666-005 304398-101 2254, 57, 92
112666-005 304398-111 2254, 57, 92
337366-001 2260, 62
166820-001
4230ES
337379-001 2262, 64, 66, 70, 74,
320783-001
75, 76, 81, 82, 83, 84,
85V, 88, 90, 92, 93,
94, 95
97
CD-ROM Drive Assembly Spare Part System
CD-ROM, IDE, 8X 292540-001 2200, 10, 12
CD-ROM, IDE, 16X 292569-001 4212ES, 20, 22
CD-ROM, IDE, 20X 317210-001 2240, 2244ES, 2246
CD-ROM, IDE, 32X 310185-002 317212-001 2200 Series; 2281, 83,
DVD2 286466-408 317213-001 4230ES, 4240ES
Diskette Drives Spare Part System
1.44 MB 292549-001 All except 2240
Series and 4230ES
1.44 MB 239612-401 2240, 2244ES, 2253,
54, 55, 56, 58, 2260
Series, 2270 Series,
2281, 82, 83, 84,
85V, 86, 88, 89, 2290
Series; 4240ES,
4230ES
Volume One 3-39
Page 7
Presario 2200/4200
33.6 Kb/s Modem, Upgradeable to 56 Kb/s (Presario 2240, 2246, 2254, 2255)
Cable
Country Cable/Adapter Spare Part
Australia 304398-011 317296-001 165224-001
Belgium 304398-181 317296-001 165224-001
Denmark 304398-081 317296-001 165224-001
Finland 304398-351 317296-001 165224-001
France 304398-051 317296-001 165224-001
Italy 304398-061 317296-001 165224-001
Netherlands 304398-331 317296-001 165224-001
New Zealand 304398-011 317296-001 165224-001
Norway 304398-091 317296-001 165224-091
Singapore 317296-001 165224-001
Sweden 304398-101 317296-001 165224-001
Switzerland 304398-111 317296-001 165224-001
U Kingdom 317296-001 165224-033
33.6 Kb/s Modem, Upgradeable to 56 Kb/s (all except Presario 2240, 2246)
Country Spare Part
APD 293020-371 165224-001
Australia 293020-012 165224-012
Belgium 293020-181 304398-181
Brazil 293020-001 165224-001
Canada 293020-001 165224-001
Caribbean 165224-001
Denmark 293020-001 304398-081
France 293020-051 304398-051
Germany 293020-041 286241-045
Italy 293020-161 165224-062
Japan 293020-291 165224-001
Korea 165224-001
Latin America 293020-001
Mexico 293020-001 165224-001
Netherlands 293020-331 304398-331
New Zealand 293020-012 165224-033
Norway 317296-001 304398-091
Portugal 165224-131
PRC/Thailand 293020-001 165224-001
Puerto Rico 165224-001
Singapore 293020-AF1 165224-001
Spain 165224-071
Sweden 293020-101 304398-101
Switzerland 293020-111 304398-111
Taiwan 293020-AB1 165224-001
U Kingdom 293020-031 165224-033
US 293020-001 165224-001
US 4212ES 293020-001 165224-001
Spare Part
Cable
Spare Part
3-40 Volume One
Page 8
Presario 2200/4200
Daughter Cards to Upgrade to 56 Kb/s
Country Spare Part
One part supports all countries 292614-001
56 Kb/s DSVD (Presario 2240, 2246, 2253, 2254, 2255, 2256, 2257)
Modem
Country
APD English (Malaysia, Hong
Kong, Vietnam, Indonesia,
Philippines)
Brazil 292256-003 292269-003 137256-001
Caribbean 292256-003 292269-003 137256-001
Japan 292256-003 292269-003 137256-001
Latin America 292256-003 292269-003 137256-001
Mexico 292256-003 292269-003 137256-001
PRC/Thailand 292256-003 292269-003 137256-001
Puerto Rico 292256-003 292269-003 137256-001
Spain 170740-001 170762-073 137256-001
Taiwan 292256-003 292269-003 137256-001
US /Canada 292256-003 292269-003 137256-001
Cables Assembly Spare Part System
Cable Kit 292568-001 All except
Cable Kit, Miscellaneous 170720-001 2240 Series,
Cable Kit, Miscellaneous 337361-001 2260 Series,
Cable Kit, Miscellaneous 298486-001
PCA Spare Part
292256-003 292269-003 137256-001
337562-001 4240ES
310188-003
349006-001
320558-001
Cable
Spare Part
2240 and
4230ES Series
2253, 54, 55,
56, 4230ES
2270 Series,
2281, 82, 83,
84, 85V, 86,
88, 89, 2290
Series
Battery/Power Supply Spare Part System
Battery, Replaceable 234556-001 All
Power Supply, 51W, Auto-Detect 293814-001 All except 2240 and 4230ES
Series
Power Supply, 75W 337373-001 2260 Series, 2270 Series,
2280 Series, 2290 Series
Power Supply, 75W, w/ Baffle 319234-001 2250 Series
Power Supply, 75W, w/ Baffle 298471-001 2240, 2244ES
Power Supply, 110W 317218-001 4230ES
Power Supply, 110W, w/ Baffle 319235-001 4240ES
Volume One 3-41
Page 9
Presario 2200/4200
Presario 2200 Series
Memory Upgrade Chart
I/O BOARD
A MAXIMUM OF 80 MB TOTAL MEMORY
NO OPTIONS
NO SPARES, ALL MEMORY DOWN
3-42 Volume One
Page 10
Presario 2200/4200
Presario 2240 Series
Memory Upgrade Chart
I/O BOARD 16 MB
327149-001
A MAXIMUM OF 48MB TOTAL MEMORY
16 MB STANDARD .
32-MB SDRAM DIMMS, - OPTION PN 271434-001
Volume One 3-43
Page 11
Presario 2200/4200
Presario 2253, 2254, 2255, 2256
Memory Upgrade Chart
PROCESSOR BOARD
310198-001
(32 MB)
A MAXIMUM OF 48 OR 64 MB TOTAL MEMORY
32 MB STANDARD MEMORY SOLDERED
ON SYSTEM BOARD.
MEMORY OPTIONS ARE NOT AVAILABLE FOR THE
PRESARIO 2250 SERIES, 2510, AND 2410ES
3-44 Volume One
Page 12
Presario 2200/4200
Presario 2260, 2262,
2264, 2266, 2270, 2274, 2275, 2276, 2278
Memory Upgrade Chart
PROCESSOR BOARD
A MAXIMUM OF 256 MB TOTAL MEMORY
USE 16, 32, OR 64 MB 100 MHz DIMMs
MEMORY OPTIONS ARE NOT AVAILABLE
Volume One 3-45
Page 13
Presario 2200/4200
Presario 2285V Series
Memory Upgrade Chart
SYSTEM BOARD
(96MB)
MAXIMUM MEMORY 384MB
32-MB 100MHz SDRAM DIMM - OPTION PN 308875-001
64-MB 100MHz SDRAM DIMM - OPTION PN 308877-001
128-MB 100MHz SDRAM DIMM - OPTION PN 308878-001
3-46 Volume One
Page 14
Presario 2200/4200
Presario 4200 Series
Memory Upgrade Chart
I/O BOARD
A MAXIMUM OF 80 MB TOTAL MEMORY
NO MEMORY OPTIONS
16-MB SDRAM DIMM - SPARE PN 271117-001
32-MB SDRAM DIMM - SPARE PN 271118-001
Volume One 3-47
Page 15
Presario 2200/4200
Presario 4230 Series
Memory Upgrade Chart
I/O BOARD 32 MB EDO
311009-001
A MAXIMUM OF 256 MB TOTAL MEMORY
16-MB DIMMS, - OPTION PN 271433-001
32-MB DIMMS, - OPTION PN 271434-001
64-MB DIMMS, - OPTION PN 309081-001
128-MB DIMMS, - OPTION PN 309082-001
3-48 Volume One
Page 16
Presario 2200/4200
Presario 4240ES Series
Memory Upgrade Chart
PROCESSOR BOARD
SPARE PART # 319277-001
A MAXIMUM OF 384 MB TOTAL MEMORY
16-MB SDRAM DIMMs - OPTION PN 271433-001
32-MB SDRAM DIMMs - OPTION PN 271434-001
64-MB SDRAM DIMMs - OPTION PN 309081-001
128-MB SDRAM DIMMs - OPTION PN 309082-001
Volume One 3-49
