F700/Kiron Series

User Manual

Revision: R01 (May 2018)

Trademark

All brand and product names are trademarks or registered trademarks of their respective companies.

Disclaimer

Specications and documents are subject to change without notice.

Note

Not all models are available in all regions. Not all features are available on all models.

Depending on the specic model purchased, the colour and look of your device and accessories may not exactly match the graphics shown in this document. The screenshots and other presentations shown in this document are for reference only.

Table of Contents

1 Device Basics ............................................................................. 6

Getting to Know Your Device ..................................................................................6

Front-Side View ................................................................................................6

Rear-Side View ................................................................................................6

Right-Side View ................................................................................................6

Bottom-Side View .............................................................................................6

Cradle ...............................................................................................................7

Using a Micro-SIM Card .........................................................................................7

Using a Memory Card .............................................................................................7

Charging the Battery ...............................................................................................8

Extending the Battery Life ................................................................................8

Using the Cradle .....................................................................................................9

Turning the Device On and Off .............................................................................10

Turning On .....................................................................................................10

Sleep Mode ....................................................................................................11

Aeroplane Mode .............................................................................................11

Restarting the Device .....................................................................................11

Turning Off .....................................................................................................11

Shutting Down ................................................................................................11

Connecting the Device to a Computer ..................................................................11

Transferring Files Between the Device and Your Computer: .........................11

2 Getting Started ......................................................................... 12

Using the Touch Screen........................................................................................12

Rotating the Screen ..............................................................................................13

Home Screen ........................................................................................................13

Status Bar ......................................................................................................13

Desktop ..........................................................................................................14

Application Shortcuts and Widgets ................................................................14

Favourites Tray ..............................................................................................14

Grouping Shortcuts in a Folder ......................................................................14

Changing the Wallpaper .................................................................................15

Customising the Home Screen Settings ........................................................15

Navigation Buttons ...............................................................................................15

Quick Settings ......................................................................................................15

Your Apps .............................................................................................................16

App Permissions ............................................................................................16

App Links .......................................................................................................16

Battery Optimisation for Apps .........................................................................16

Stopping an App or a Service from Running ..................................................17

Using the Keyboard ..............................................................................................17

Changing the Keyboard and Input Methods ...................................................17

Basic Editing ..................................................................................................17

Adding Your Email Accounts .................................................................................18

Removing an Account ....................................................................................18

3 Connectivity .............................................................................19

Cellular Data Connection ......................................................................................19

Wireless Network Connection ..............................................................................19

Connecting to a Wireless Network .................................................................19

Removing a Remembered Network ...............................................................19

Bluetooth ..............................................................................................................20

Pairing with Another Bluetooth Device ...........................................................20

Disconnecting a Bluetooth Connection ..........................................................20

Changing the Bluetooth Name of the Device .................................................20

Removing a Paired Device .............................................................................20

Connecting to the Internet Using Bluetooth ...................................................20

NFC ......................................................................................................................21

Turning NFC On and Off ................................................................................21

Transferring Data Using NFC .........................................................................21

4 Applications .............................................................................22

Browser ................................................................................................................22

Calculator .............................................................................................................22

Calendar ...............................................................................................................22

Camera .................................................................................................................23

Taking a Photo ...............................................................................................23

Recording a Video ..........................................................................................23

Camera Settings ............................................................................................24

Clock .....................................................................................................................24

Contacts ...............................................................................................................25

Importing/Exporting Contacts .........................................................................25

Adding a Contact ............................................................................................25

Finding a Contact ...........................................................................................25

Editing a Contact ............................................................................................26

Managing a Contact .......................................................................................26

Adding a Contact to Favourites ......................................................................26

Merging Contacts ...........................................................................................26

Managing a Group .........................................................................................26

Downloads ............................................................................................................27

Email .....................................................................................................................27

Checking Your Email ......................................................................................27

Sending an Email Message ...........................................................................27

Responding to an Email Message .................................................................28

Managing Your Email Messages ....................................................................28

Searching Email Messages ............................................................................28

File Manager .........................................................................................................28

Gallery ..................................................................................................................29

Albums ...........................................................................................................29

Photos ............................................................................................................30

Videos ............................................................................................................30

MiDM Client ..........................................................................................................31

Music ....................................................................................................................31

Playback Controls ..........................................................................................32

Search ..................................................................................................................32

Sound Recorder ...................................................................................................32

Videos ...................................................................................................................33

5 Personalising Your Device ...................................................... 34

Settings Menu .......................................................................................................34

Wireless and Networks Settings ....................................................................34

Device Settings ..............................................................................................35

Personal Settings ...........................................................................................37

System Settings .............................................................................................38

6 Reference ..................................................................................39

Troubleshooting ....................................................................................................39

Caring for the Device ............................................................................................39

Regulatory Information .........................................................................................40

FCC ................................................................................................................40

IC ....................................................................................................................41

CE ..................................................................................................................41

RF Exposure Information (SAR) ....................................................................42

WEEE .............................................................................................................42

Bluetooth ........................................................................................................42

Safety Precautions ...............................................................................................42

1 Device Basics

Getting to Know Your Device

Front-Side View

❶

Rear-Side View

❶❷

❽

❺❻❺❹

❼

❹

❶

NFC sensor*

❷

❷ ❸ ❹

❺

❻ ❼

❽

❸

Front camera lens*

❸

Light sensor*

❹

Power button

❺

Volume buttons

❻

Touch screen

❼

Microphone

*For selected models only

❶

Rear camera lens*

❷

Flash*

❸

Microphone

❹

Screw hole for cradle

❺

Socket for cradle

❻

Dock connector

❼

Speaker

❽

Accessory screw hole

*For selected models only

Right-Side View

Bottom-Side View

❷ ❶

❶

Micro-SIM card slot*

❷

Memory card slot

*For selected models only. To use cellular services, you must have a subscription to the function with a mobile phone network service.

❶

Micro-USB connector

Cradle

❶

❷❷ ❷❷

❸

❹❺❻❼

❶

Release button

❷

AMPs hole pattern

❸

USB port*

❹

Fleet port

❺

Headphone jack

❻

Dock connector

❼

Micro-USB connector

*For selected models only

Using a Micro-SIM Card

The devices uses a Micro-SIM card.

Open the cover on the right side of the device to locate the Micro-SIM card slot. With its label side facing the rear side of the device, hold the Micro-SIM card by the edges and gently insert it into the

slot. Note that inserting the card in the reverse direction may cause damage.

To remove a card, gently push the top edge of the card inwards to release it, and pull it out of the slot.

Using a Memory Card

CAUTION: Do not apply pressure to the center of the memory card.

Open the cover on the right side of the device to locate the memory card slot. With its label side facing the rear side of the device, hold the MicroSD card by the edges and gently insert it into the slot. Note

that inserting the card in the reverse direction may cause damage.

To remove a MicroSD card, rst unmount it from the device by tapping on the desktop  Settings

Storage & USB 



out of the slot.

Do not apply pressure to the center of the memory card.

. Then gently push the top edge of the card inwards to release it, and pull it

Inserting the card in the reverse direction may cause damage.

The manufacturer does not guarantee the product's compatibilities with the storage cards from all manufacturers.

If you encounter access problems with your memory card, please visit the website https://www.sdcard.org/downloads/formatter_4/ and use

the "SD Memory Card Formatter 5.0 for SD/SDHC/SDXC" tool to format your memory card.

Charging the Battery

Use only the charger supplied with your device. Use of another type of charger will result in malfunction and/or danger.

When charging the battery for the very rst time, you should charge it for at least 8 hours (using the AC

charger).

CAUTION: For optimal performance of the lithium battery:

• Do not charge the battery where the temperature is high (for example, in direct sunlight).

• There is no need to fully discharge the battery.

• When storing the device for a long period of time, be sure to charge the device at least once every two weeks. Over discharge of the

device can affect the performance.

• Failure to follow the battery usage instructions could cause damage to your device, battery and even bodily injury or property damage, and will void any warranty.

1. Push the tap outwards (❶), insert the plug to the AC charger and then push the tap inwards to lock the plug in place (

The look of the charger plug varies depending on your region.

2. Connect the Micro-B USB end of the USB cable to your device (❸), and the other end to the AC charger (❹).

3. Plug the AC charger to a wall outlet (

❷

❺

❶ ❷

❺

❹

❸

Extending the Battery Life

There are various ways to improve the device's battery life.

• Always fully charge the battery.

• Turn on Battery saver.

• Turn off unnecessary sounds, such as touch sounds.

• Close an app when you are not using it.

• Use a shorter timeout setting of the screen.

• Lower the brightness level of the screen.

• Turn off Bluetooth when you are not using it.

• Prevent the device from constantly scanning for available wireless networks.

• Enable Aeroplane mode to turn off all wireless transmission functions.

To change settings, tap

on the desktop  Settings.

Using the Cradle

Depending on your model, a cradle and/or a mount may be provided for your device. Follow the

illustrations to mount your device.

To install the cradle:

1. Line up and connect the dock connector on the cradle to the dock connector on the device. Magnets are incorporated to ensure proper alignment.

2. If needed, you can secure the device to the cradle with 2 screws.

To remove the cradle:

1. Remove the 2 screws (if installed) securing the device to the cradle.

2. While pressing and holding the release button on the cradle, pull the top of the device away and

lift the device out of the cradle in an upward motion.

Features of the cradle:

• Install a vehicle mount equipped with the AMPs hole pattern (may be sold separately).

• Charge the device via a 5V/2A car charger with a Micro-B USB cable (may be sold separately).

The Micro-USB connector on the cradle is intended only for charging, not for data transfer.

• Connect to a telematics box or vehicle battery (12V/24V) via a eet cable (may be sold

separately).

• Connect an external USB storage device (such as a USB ash drive). (This feature is not

available on all models.)

• Connect to the Ethernet via a USB-to-LAN adapter (not provided).

• Connect to headphones.

Turning the Device On and Off

Turning On

1. Press and hold the Power button for about 2 seconds to turn on your device. Wait for the boot screen to display.

2 SEC

Thebatterymaynotbefullychargedwhenyouusethedeviceforthersttime.Chargethebatteryrst.

2. The Home screen will display and the device is in Lock mode by default. Drag the Lock icon ( ) upwards to unlock. The device is ready for use.



Sleep Mode

Your device will automatically switch off the screen after 1 minute (by default) of inactivity. You can manually switch off the screen by pressing the Power button briey.

To resume the screen, press the Power button briey and then unlock the device by dragging the Lock

icon (

) upwards.

Aeroplane Mode

When you are in an aeroplane or in the area where data transferring is not allowed, enable Aeroplane mode. You will be able to use many of your device's applications, but all wireless radios, including wireless networks and Bluetooth, on the device are turned off – it cannot send or receive data.

To enable Aeroplane mode: press and hold the Power button to display the options menu and tap Aeroplane mode. The

You can enable WIFI and Bluetooth in Aeroplane mode.

To disable Aeroplane mode: tap on the desktop  Settings  More in Wireless & networks, and tap the Aeroplane mode switch to turn it off.

icon in the status bar indicates that Aeroplane mode is on.

Restarting the Device

You may need to reset the device when the device is running slower or improperly. Press and hold the Power button to display the options menu and tap Reboot to restart the device.

Turning Off

To turn off the device, press and hold the Power button to display the options menu and tap Power off.

Shutting Down

If the device stops responding, you may need to shut down the device by pressing and holding the Power button for 8 seconds.

Connecting the Device to a Computer

To connect the device to a computer, connect the Micro-USB end of the USB cable to your device and

the other end to a USB port in your computer.

When you connect the device to your computer for the rst time, allow the USB driver of the device to

be installed properly on your computer.

Transferring Files Between the Device and Your Computer:

1. Change the modem setting from USB to UART and restart the device. (For more information, see "Modem Interface" on Page 34.)

2. Connect the device to the computer using the USB cable.

3. Slide down from the top of the screen with one nger to open the Notications panel, and tap USB for charging. From the Use USB for notication, tap File transfers.

4. You can now transfer les between the two devices.

2 Getting Started

Using the Touch Screen

To operate your device, touch the screen with your nger. You can perform the following actions:

• Tap: Touch the screen once with your nger to open items or select on-screen buttons or options.

• Tap and hold: Tap and hold on the desired item to open the pop-up menu that contains the

available options for the item.

• Drag: Tap and hold on the item and then move it to the target position without releasing your nger.

• Slide/Swipe: Drag your nger vertically or horizontally across the screen.

• Drag to the left/right to switch to the next/previous item on the list.

• Drag to the top/bottom to scroll up/down the screen.

Not all slide gestures are applicable to all applications.

• Two-ngergestures: Move your ngers apart or together on the screen to zoom in or out while viewing a picture or a web page.

Notalltwo-ngergesturesareapplicabletoallapplications.

Rotating the Screen

For most applications, you can automatically change the screen orientation, from portrait to landscape and vice versa, by turning the device sideways.

Rotating the screen is not applicable to all applications.

Home Screen

The Home screen is your starting place for tasks, providing quick access to frequently used

applications and settings.

To display the Home screen, tap

Shortcut/widget

at any time.

Status bar

Desktop

Soft keys

Back Home Recent Apps

All Apps button

Favorites tray

Status Bar

The status bar is at the very top of the screen, displaying system status icons and notication icons.

Depending on your use of the device, some icons are not always shown in the status bar.

System status icons

The system status icons are displayed on the right side of the status bar. They provide information about your device's status, including the connection status, signal strength, battery power, time, and

more.

Noticationicons

The notication icons are displayed on the left side of the status bar. They report the arrival of new emails, calendar events, and other notications.

When you see notication icons displayed in the status bar, you can open the Notications panel to view the detailed descriptions. To open the Notications panel, swipe down from the top of the screen with one nger.

From the Notications panel, do one of the following:

• Tap a notication to open the related application.

• Tap

to clear all notications.

Desktop

The desktop includes the Home screen and the extended screens, providing useful information about notications and device status. It also allows you to add an access to your favourite application shortcuts/widgets on the Home screen and the extended screens.

Swipe left or right to switch between the screens.

To add an extended screen:

1. Tap and hold anywhere on the Home screen or an extended screen.

2. Tap NEW HOME to add a new extended screen.

An extended screen will be removed automatically when all shortcuts and widgets on it are moved or removed.

Application Shortcuts and Widgets

The application shortcuts and the widgets can be placed on either the Home screen or any of the

extended screens.

To add a shortcut:

1. Go to the screen where you want to place the shortcut.

2. Tap

3. Tap and hold the desired app until the Home screen appears, drag it into place, and lift your

To add a widget:

1. Go to the screen where you want to place the widget.

2. Tap and hold anywhere on the desktop, and select WIDGETS.

3. Swipe left and right to explore the available widgets.

4. Tap and hold the desired widget until the Home screen appears, drag it into place, and lift your

To move a shortcut or widget to another position:

1. Tap and hold the icon, and drag the icon to the new position.

2. Lift your nger.

To remove a shortcut or widget from the desktop (without removing it permanently from the device), tap and hold the icon, drag your nger toward the top-left corner of the screen, and drop it over X

(Remove) until the icon turns red.

on the desktop.

nger.

• To move between the screens on the desktop, swipe toward the edge of the screen.

• To bump another icon out of the way, slowly drag the desired icon into it.

Favourites Tray

You can use the Favourites tray at the right edge of the desktop to quickly access the apps.

You can edit the apps in the Favourites tray: simply tap and hold an icon and move it in or out of the

Favourites tray or the desktop.

Grouping Shortcuts in a Folder

You can group the shortcuts to apps or settings on the desktop and the Favourites tray into a folder.

1. Tap and hold a shortcut, and then drag it over to another shortcut. A folder will be created automatically.

2. Tap to open the folder.

• To add another shortcut to the folder, tap and hold the shortcut, and drag it over to the folder.

• To remove a shortcut from the folder, tap and hold the shortcut, and drag it out of the folder.

3. To rename the folder, tap the title bar of the folder, and enter the desired folder name.

4. To delete the folder, tap and hold the folder, drag your nger toward the top of the screen, and drop it over X (Remove).

Changing the Wallpaper

1. Tap and hold anywhere on the desktop, and select WALLPAPERS.

2. Swipe right and left at the bottom of the screen and select a wallpaper image, or tap Pick image to select an image from your device.

3. Tap Set wallpaper.

Customising the Home Screen Settings

Tap and hold anywhere on the desktop, and tap to access the Home screen settings. To close the settings, tap .

Home screen settings:

• Search bar: Show or hide the Google search bar on the Home screen.

• Scroll effect: Set the scrolling effect for the screens on the desktop.

• Icon labels: Show or hide the names of the icons.

• Scroll wallpaper: Set if you want the wallpaper to move along with the screens on the desktop.

• Grid size: Set the grid size for the icons on the desktop.

Drawer settings (for customising the app drawer when you tap

• Layout: Set if you want to scroll the app drawer horizontally or vertically.

• Scroll effect: When the horizontal layout is selected, you can set the scrolling effect for the

screens on the desktop.

• Sorting mode: When the horizontal layout is selected, you can sort the apps by the name, use

count or date.

• Icon labels: Show or hide the names of the icons.

App settings:

• Larger icons: Set if you want to use larger icons on the desktop.

• Small text size: Set if you want to use smaller text for the icons on the desktop.

on the desktop):

Navigation Buttons

Three navigation buttons are located at the bottom of the screen:

•

: The Back button opens the previous screen you were working in. (You cannot go back further

once you return to the Home screen.)

•

: The Home button returns to the desktop. Tap again to return to the Home screen.

•

: The Recent Apps button opens a list of thumbnail images of the screens you have worked with

recently. Tap one to open it. To remove a screen from the list, swipe it left or right, or tap the X.

Some screens in apps and Settings have a menu icon

. Tap to access additional options.

Quick Settings

Some frequently used settings can be found in Quick Settings. To open Quick Settings, simply swipe down from the top of the screen with two ngers or twice with one nger. Tap an icon to change its

setting.

• WIFI: Turn the wireless network on or off, or open the WIFI settings menu.

• Bluetooth: Turn Bluetooth on or off, or open the Bluetooth settings menu.

• Do not disturb: Set how and when to receive notications.

• Cellular data: See the cellular data usage, or turn it on or off.

• Aeroplane mode: Turn the Aeroplane mode on or off.

• Auto-rotate: Set the device's orientation to automatically rotate or lock in the portrait mode.

• Torch: Turn the ashlight on or off.

• Location: Turn the location services on or off.

Your Apps

To see all your apps, tap in the Favorites tray on the desktop to open the app drawer.

You can place an app icon on any of the screens on the desktop. Tap and hold the app icon, then drag into the desired screen, and lift your nger.

To view information about an app from the app drawer, tap and hold the icon, slide your nger toward the top of the screen, and drop the icon over L (App info).

App Permissions

When you use some apps for the rst time, you will be prompted to grant permissions for the apps to access certain data or features. To grant a permission, tap Allow; to reject a permission, tap Deny.

You can customise the permission settings of your apps in Settings:

1. Tap

2. Tap the desired option: App permissions, App links, Draw over other apps, or Modify system

3. Select an app to customise permission settings.

4. To reset the permission settings, tap

on the desktop  Settings  Apps  .

settings.

 Reset app preferences.

App Links

You can set the default app to handle a link or feature.

1. Tap

2. Tap App links.

3. Select an app, tap Open supported links and change the setting.

on the desktop  Settings  Apps  .

Battery Optimisation for Apps

You can prolong the battery standby time by performing battery optimisation for your apps.

1. Tap

2. Tap Battery optimisation.

on the desktop  Settings  Apps  .

3. Tap Not optimized  All apps.

4. Select an app, tap Optimize  Done.

Stopping an App or a Service from Running

1. Tap on the desktop  Settings  Apps.

2. Tap an app or a service, and tap FORCE STOP  OK.

Using the Keyboard

When you select a eld that requires text or numbers, the on-screen keyboard will automatically display. You can use the on-screen keyboard to enter text, numbers, symbols, etc.

Some apps open the keyboard automatically. In others, tap where you want to type to open the

keyboard.

As you type, suggestions for completing each word appear above the keyboard.

To close the keyboard, tap

Changing the Keyboard and Input Methods

To change the keyboard and input methods:

1. Tap

2. Tap Current Keyboard  CHOOSE KEYBOARDS to see available keyboards.

3. Tap the switch of the desired keyboard to turn it on.

4. Tap Current Keyboard and select the keyboard that you want to use as the main input method.

5. To customise the settings for a keyboard, tap it in the Keyboard & input methods section.

on the desktop  Settings  Language & input. The keyboards that you can use are

listed in the Keyboard & input methods section.

To hide a keyboard, tap its switch to turn it off.

Tap

. The new keyboard is now listed in the Keyboard & input methods section.

Basic Editing

To change where you want to type:

• Tap the cursor, and tap and drag the tab below the cursor to the new position.

To select text:

1. Tap and hold (or double-tap) within the text.

2. The nearest word highlights, with a tab at each end of the selection. Drag the tabs to change the selection.

To delete text:

• Tap

To cut, copy or paste text:

1. Select the text you want to cut or copy, and tap CUT or COPY.

2. Tap where you want to paste the text, and tap PASTE.

To type capital letters:

• To type one capital letter, tap

• To type multiple capital letters, tap and hold (or double-tap)

to delete the characters before the cursor or selected text.

on).

once to turn it to .

to turn it to (caps lock is turned

• To quickly change the capitalisation of a word you have already typed, select it and tap the /

/ .

• To type lowercase letters, tap

To type a symbol:

1. Tap

2. To view additional symbols, tap

3. Tap

To type an accented characters (not applicable to all apps):

• Tap and hold the letter. When the suggestions appear above the keyboard, slide to the desired

To use emoji (not applicable to all apps):

1. Tap

2. Slide left or right to view and select the desired emoji.

3. Tap

to return to the keyboard.

accented character and lift your nger.

. You will see the emoji symbols.

to return to the keyboard.

/ once to turn it to .

Adding Your Email Accounts

This requires the Internet connection.

You need to set up an account on your device to use the Calendar and Email apps. You can set up

multiple accounts.

1. Tap

2. Tap Add account.

3. Select the type of account that you want to add.

4. Follow the on-screen instructions to add the account.

By default, the auto-sync function of your account is enabled. To manually sync your account, tap

Sync now on the account list screen.

Removing an Account

When you remove an account that you have added to your device, everything associated with that account, including email, contacts, calendar events and settings, is also deleted.

1. Tap

2. Select the account to remove.

3. Tap the account email address.

4. Tap

on the desktop  Settings  Accounts.

 Remove account  REMOVE ACCOUNT.



3 Connectivity

Cellular Data Connection

This feature is not available on all models.

To use cellular services, you must have a subscription to the function with a mobile phone network service. In most cases, the settings of the cellular services are installed automatically.

To turn on or off the cellular services:

1. Tap

2. Tap the Mobile data switch to turn it on or off.

If you are on a limited data allowance, you can monitor the data usage on the device by tapping

the desktop  Settings  Data usage.

Turn off the cellular services when not in use to save battery power.

For optimal performances, you may need to change the modem interface setting. For more information, see "Modem Interface" on Page 34.

Wireless Network Connection

To use wireless local area networks (WIFI) on your device, you need access to a wireless access point

(AP) or "hotspot."

The coverage of the WIFI signal can be up to 300 feet (100 metres). However, it varies greatly due to the type of infrastructure, and other

objects through which the signal passes.

Connecting to a Wireless Network

1. Tap on the desktop  Settings  WIFI.

2. Tap the WIFI switch to turn it on. The device will automatically scan for available wireless

3. Tap a wireless network to connect.

4. If you select an open network, you will be automatically connected to the network.

5. When your device is connected to a wireless network, the WIFI icon (

The next time your device connects to a previously accessed secured wireless network, you will not be prompted to enter the key again, unless you reset the network settings or reset your device to its

factory default settings.

Turn off the WIFI function when not in use to save battery power.

on the desktop  Settings  Data usage.

networks.

If the wireless network you are looking for is not on the list, tap

If you select a secured network, enter the key and then tap CONNECT.

bar.

 Refresh to start a new scan.

) will appear in the status

Removing a Remembered Network

1. Tap on the desktop  Settings  WIFI.

2. Tap and hold the network to remove on the list, and select Forget network.

Bluetooth

Bluetooth is a short-range wireless communications technology that allows Bluetooth-enabled devices to exchange information over a distance of about 30 feet (10 metres) without requiring a physical

connection.

Pairing with Another Bluetooth Device

1. Make sure that the Bluetooth function of the other device is turned on.

2. Tap

3. Tap the Bluetooth switch to turn it on.

4. Tap the desired device from the list to initiate pairing.

5. Make sure that the same passkey is displayed on your device and the other device, and then tap

Turn off the Bluetooth function when not in use to save battery power.

Disconnecting a Bluetooth Connection

1. Tap on the desktop  Settings  Bluetooth.

2. Tap the desired paired device.

3. When prompted to disconnect, tap OK.

Changing the Bluetooth Name of the Device

1. Tap on the desktop  Settings  Bluetooth.

2. Tap the Bluetooth switch to turn it on.

3. Tap

on the desktop  Settings  Bluetooth.

The device is visible to nearby devices when the Bluetooth function is turned on.

The device will automatically scan for available Bluetooth devices.

If the Bluetooth device you are looking for is not on the list, tap

PAIR.

 Rename this device, enter a new name, and tap RENAME.

 Refresh to start a new scan.

Removing a Paired Device

1. Tap on the desktop  Settings  Bluetooth.

2. Tap the Bluetooth switch to turn it on.

3. Tap

next to the desired paired device, and tap FORGET.

Connecting to the Internet Using Bluetooth

1. Make sure that the Bluetooth tethering function of the paired device is turned on.

2. Tap

3. Tap the Bluetooth switch to turn it on.

4. Tap

on the desktop  Settings  Bluetooth.

next to the desired paired device, select the checkbox for Internet access, and tap OK.

On the paired device, make sure that the Internet connection sharing checkbox is selected in the Bluetooth connection settings with your device, and tap OK.

NFC

This feature is not available on all models.

Your device supports the Near Field Communication (NFC) feature that allows you to easily transfer data to an NFC-compatible device. The NFC area is located at the upper side of the front of the device.

Turning NFC On and Off

1. Tap on the desktop  Settings  More  NFC.

2. Tap the NFC switch to turn it on or off. The device will automatically scan for available wireless

networks.

Transferring Data Using NFC

1. Access the data you want to share, access the share options, and tap Android Beam.

2. Touch the screen of your device.

3. Hold the upper front side of your device close to the NFC sensor of the other device (within the range of 4 cm).

4. Pay attention to and accept the beam notication on the other device.

4 Applications

From the desktop, tap the All Apps button to see all your apps.

Note that not all apps and features are available for all models.

Browser

This feature requires the Internet connection.

Open Browser to start surng the web. Browser is fully optimised and comes with advanced functionalities, allowing you to enjoy Internet browsing on your device.

on the desktop  Browser.

Tap

• On the browser screen, tap the URL eld and enter the web page address or search keyword.

As you enter the address, the matching web pages/addresses will be displayed on the screen. If you nd the web page you want, simply tap the address. Otherwise, continue entering the web

page address. When done, tap

• To open a new tab, tap

• To bookmark the current web page, tap location for it, and tap OK. The bookmark icon changes from

• To access the bookmarks list, tap

• To share the current web page, tap

• To search for a specic word or phrase on the current web page, tap

• To change to the desktop verion of the current web page, tap

option again to disable it.

• To view the info of the current web page, tap

• To customise the settings of the browser, tap

on the tab bar, or tap  New tab.

. Check the bookmark label and select the desired

to .

 Share page.

 Find on page.

 Request desktop site. Tap the

 Page info.

 Settings.

Calculator

Calculator helps you calculate simple math problems and complex mathematical functions.

on the desktop  Calculator.

Tap

The screen displays the basic panel and the advanced panel (the green panel).

Calendar

You must sign in to an account to use Calendar.

Syncing calendar events requires the Internet connection.

Use Calendar to view and edit your schedule.

1. Tap

2. Tap .

3. On the event details screen, enter the information for the event.

4. Set the event reminder if necessary. You can set multiple reminders.

5. When nished, and tap DONE.

on the desktop  Calendar.

• To change the calendar view, tap the date eld on the top-left of the screen and select Day, Week, Month or Agenda.

• To read the event details, tap the event on the calendar.

• To edit the details, tap

• To delete the event, tap

• To email all parties in a meeting invitation, tap Email guests, select a quick response or

write your own response.

• To customise the Calendar settings, tap

 Settings.

Camera

Use Camera to take and share photos and videos.

Taking a Photo

1. Tap on the desktop  Camera.

If you are in the Video mode, slide your nger from the left edge to the right, and tap

to the Photo mode.

2. Frame your subject.

• To focus on a certain part of the image, tap it.

• To zoom in or out, use the two-nger gestures.

3. Tap

4. Tap

to access the quick settings in the Photo mode:

• Switching camera

• Flash

• HDR

with a better ratio of light to dark.

• Grid

• Self-timer

The photo displays as a thumbnail in the top-right corner momentarily. Tap the thumbnail to view

the photo.

: Cycle through the ash mode: always on, off or automatically on.

: When enabled, the HDR (High Dynamic Range) feature can create a clear photo

: Display or hide the grid line that can be helpful in photo composition.

to take the picture.

: Tap to switch between the front and rear cameras.

: Set the countdown time before taking a photo.

Recording a Video

1. Tap on the desktop  Camera.

2. Slide your nger from the left edge to the right, and tap

3. Frame your subject.

• To focus on a certain part of the image, tap it.

• To zoom in or out, use the two-nger gestures.

4. Tap

to access the quick settings in the Video mode:

• Switching camera

• Flash

• Grid

: Turn the ash on or off.

: Display or hide the grid line that can be helpful in photo composition.

: Tap to switch between the front and rear cameras.

to switch to the Video mode.

to switch

5. Tap to start recording.

6. To stop recording, tap

The video displays as a thumbnail in the top-right corner momentarily. Tap the thumbnail to play

the video.

Camera Settings

To access the camera settings, slide your nger from the left edge to the right, and tap .

• Resolution & quality

• Back camera photo: Set the photo resolution of the rear camera.

• Front camera photo: Set the photo resolution of the front camera.

• Back camera video: Set the video resolution of the rear camera.

• Front camera video: Set the video resolution of the front camera.

• Save location: When enabled, the app will remember the photo/video locations.

• Advanced

• Manual exposure: When enabled, you can tap

set the exposure level to adjust the brightness of the image.

• Antibanding: Allow the camera to avoid problems caused by articial light sources that are

not constant.

in the quick settings in the Photo mode to

Clock

Clock displays the current date and time. It also lets you set alarm clocks, and works as a world clock, timer and stopwatch.

on the desktop  Clock.

Tap

• Clock

• Tap to add and show the clocks of other cities.

• Alarm Clock

• Tap an alarm item to turn it on and set details of the alarm.

• Tao the switch of an alarm item to turn it on or off.

• Tap

• Countdown Timer

• Tap the numbers to set the time interval.

• Tap

• Stopwatch

• Tap to start counting.

• Tap

to add a new alarm.

to start the countdown.

to pause the countdown.

to reset the timer.

to set a new timer. Multiple timers can run at the same time.

to delete a timer.

to pause counting.

to mark a lap.

• Tap to reset the stopwatch.

• Tap

To change the clock settings tap

to share

 Settings.

Contacts

Contacts lists all contacts that are stored on the device and in your online accounts.

on the desktop  Contacts. The app displays the contacts list in the ALL CONTACTS tab.

Tap

• To set up your contact information, tap Setupmyprole.

• If you want to lter the contacts list by account, tap select a desired contact account, and tap OK.

• To change the sorting method of the contacts list, tap

• To change the format of the contacts' names, tap

Importing/Exporting Contacts

You can import contacts to the device, or export contacts for backup.

1. Tap

2. Tap

on the desktop  Contacts.

 Import/Export to access the following:

• To import contacts stored on the SIM card, select Import from SIM card. Select the desired

contacts, and tap OK. Tap OK to conrm.

• To import contacts stored in a .vcf le, select Importfrom.vcfle. Then select the desired

.vcf le.

• To export contacts to the SIM card, select Export to SIM card. Select the desired contacts,

and tap OK.

• To export contacts to a .vcf le, select Exportto.vcfle. Select the desired contacts, and

tap OK. Select the storage destination, edit the lename, and tap SAVE.

• To share the contacts via email, Bluetooth or NFC (Android Beam), select Share visible

contacts.

Adding a Contact

1. Tap on the desktop  Contacts.

2. To create a new contact, tap

3. To save the new contact locally on the device: when prompted, tap KEEP LOCALLY.

To save the new contact to an account for online backup: when prompted, tap OK to save the new contact to the current account, or tap ADD NEW ACCOUNT to create a new account to save the new contact.

4. Enter the information of the new contact in the elds.

5. Tap

to save the contact.

Finding a Contact

1. Tap on the desktop  Contacts.

2. Tap

 Contacts to display, select Customise,

 Settings  Sort by.

 Settings  Name format.

3. Enter information in the Find contacts box: the rst few letters of the contact name, the rst few numbers of the phone number, the rst few letters of the email address, or the rst few letters of

the company name.

Editing a Contact

1. Tap on the desktop  Contacts.

2. Tap the desired contact and tap

3. Enter the new information.

4. Tap

to save the changes.

Managing a Contact

1. Tap on the desktop  Contacts.

2. Tap the desired contact.

3. Tap

to do the following:

• Tap Delete to delete the contact.

• Tap Share to share the contact information via email, Bluetooth or NFC (Android Beam).

• Tap Send contact via SMS to share the contact information via a text message. (This

feature may not be supported on all models.)

• Tap Place on Home screen to add a shortcut of the contact on the desktop.

Adding a Contact to Favourites

You can save the contacts that you frequently use to Favourites for quick access. Tap the Favourites tab to view the Favourites list. The contacts that you access most frequently are automatically added

to the Frequently contacted group.

1. Tap

2. Tap the desired contact to view the detailed information.

3. Tap

4. To remove the contact from Favourites, tap

on the desktop  Contacts.

to turn it to .

Merging Contacts

If you have more than one contact entry for the same person in the same Google account, you can combine them. Tap

1. Tap

2. Tap the desired contact and tap

3. Tap

4. If you want to undo the merge, tap

on the desktop  Contacts.

 Merge. Then select the contact to combine, and tap to save the changes.

 Separate.

Managing a Group

You can organise contacts into a group to quickly contact all parties in the group. You need an account

to create groups.

1. Tap

2. Tap GROUPS, and tap

3. Enter the name of the group.

on the desktop  Contacts.

 Add Group.

4. Add the contacts to the group by entering the contact's name or tapping to select from the contacts list.

Tap

to remove a contact.

5. Tap

to save the changes.

Downloads

Downloads includes les that you have downloaded from emails or the Internet.

on the desktop  Downloads. You can:

Tap

• Tap an item to open it.

• To share a le with others, tap and hold the le, and tap

• To delete a le, tap and hold the le, and tap

• To copy a le to another location, tap and hold the le, tap

destination.

• To change the sorting method of the les, tap

• To change the viewing mode, tap

 Grid view or List view.

 By name, Bydatemodied or By size.

 Copy to..., and select the le

Email

This feature requires the Internet connection.

You need to set up an email account before using the Email app. For more information, see the "Adding Your Email Accounts" section.

Checking Your Email

Tap on the desktop  Email. The screen displays the inbox of one of your email accounts. You can:

• Tap an email message to read.

• To display email messages in another email folder, tap

• To switch to another email account, tap

• To view the email messages from all your email accounts, tap

• To change the settings of an email account, select the account and tap

and tap the desired account.

Sending an Email Message

1. Tap on the desktop  Email.

2. Select the desired email account.

3. Tap

4. Enter the email address of the recipient.

5. Enter the email subject and then your message.

6. To add an attachment, tap

7. Tap

• To add more recipients, tap + in To.

• To add more recipients in a carbon copy (Cc) or blind carbon copy (Bcc), tap ∨ in To  + in

Cc or Bcc.

and select a le.

to send the message.

and tap the folder you want to view.

 Combined view.

 Settings.

To save the message and send it later, tap  Save draft. The message will be saved in the Drafts folder.

Responding to an Email Message

1. Tap on the desktop  Email.

2. Select the desired email account.

3. Tap the desired email message.

4. To reply to the sender, tap

To reply to all recipients, tap

To forward the message to another recipient, tap

 Reply all.

Managing Your Email Messages

• To move a message that you are reading to another folder, tap and select a folder.

• To mark a message as read or unread, tap

• To delete a message that you are reading, tap

• To mark a message as important, tap

• To save a message as a PDF le, tap modify the lename, and tap SAVE.

You can select a message by tapping and holding it on the messages list.

or .

to turn it to . To unmark the message, tap to turn it

 Print  . Select the storage directory, conrm or

Searching Email Messages

1. Tap on the desktop  Email.

2. Select the desired email account.

3. Tap

4. Enter the words you want to search for in the search box.

5. Tap

6. On the results list, tap the desired message to view.

File Manager

File Manager allows you to browse a list of folders/les that are stored in the memory card and the internal storage of the device. You can open a le from File Manager by launching the associated application on your device (for example, viewing a picture le by Gallery).

You can also efciently manage your les using File Manager.

on the desktop  File Manager. The screen of le categories displays. You can do the

Tap following:

• To change the storage location:

• To access les on the memory card (if installed), tap

the name of your card).

• To access les in the internal storage of the device, tap

storage.

• To browse all types of les, tap All.

 BOOKMARKS  SD card (or

 BOOKMARKS  Internal

To browse les of a specic type, tap the desired category. The screen displays the list of the

search results.

• To change the view style, tap > to do the following:

• To change the sorting method of the les, tap

(descending), By date

size

(descending), By type



• To change the list view style, tap

Tap < to close the view options.

• You can access the editing and management options by tapping and holding a le/holder or by

tapping

• Add shortcut • Open with

• Add to bookmarks • Print

• Compute checksum • Properties

• Create copy • Refresh

• Delete • Rename

• Deselect all • Select

• Newle • Select all

• New folder • Send

• Open • Set as home

• Open parent

• To search for a le by keyword, tap

• To change the settings of File Manager, tap

(ascending), By date



(ascending), By type



 Icons, Simple or Details.

 By name

(descending), By size



 .

(ascending), By name



(descending).



(ascending), By





Gallery

You can browse all the images and videos that are on your device and the memory card in Gallery.

on the desktop  Gallery. By default, the screen displays the Timeline view with all photos

Tap

and videos.

Albums

To view photos and videos by albums, tap  Albums. Tap an album to view the photos and videos in a chronological order.

From the album list, you can do the following:

• Tap a photo or video in an album to view it.

• Tap

• To

• To change the viewing mode, tap

• To share an album/a photo, tap and hold an album/a photo until the check mark appears. Tap to

• To delete an album/a photo, tap and hold an album/a photo until the check mark appears. Tap to

• To select all albums/photos, tap and hold an album/a photo until the check mark appears. Then

to switch to the Camera app.

to view all photos in an album in a slideshow.

 Grid view or List view.

select other albums/photos. Tap

tap

 Select all.

to share via email, NFC (Android Beam) or Bluetooth.

to delete the selected albums/photos.

Photos

When viewing a photo, you can do the following:

• To share the photo via email, NFC (Android Beam) or Bluetooth, tap

• To delete the photo, tap

• To view all photos in the album in a slideshow, tap

• To set the photo as the wallpaper of the Home screen or the assigned photo for one of your contacts, tap

• To view the information of the photo, tap

• To save the photo as a PDF le, tap modify the lename, and tap SAVE.

Editing Photos

When viewing a photo, tap

You can do the following:

• To adjust the colour of the photo, tap Color and select the desired effect.

• To add a photo frame to the photo, tap Frames and select the desired photo frame.

• To crop the photo, tap Crop  Crop.

• To move the crop frame, tap and hold inside the frame, and drag it to the desired position.

• To resize the crop frame, tap and drag the edges or the corners of the frame inward or

outward.

• To straighten a crooked photo, tap Crop  Straighten. Tap and drag the crop frame until you

have the desired effect.

• To rotate the photo, tap Crop  Rotate to rotate it 90 degrees clockwise.

• To ip the photo, tap Crop  Mirror for a vertical ip; tap again for a horizontal ip; tap again for a vertical ip.

• To draw on the photo, tap Crop  Draw. Tap one of the colours at the bottom of the screen.

• To adjust the exposure of the photo, tap Exposure and select the desired effect.

• To add a beautifying effect to the photo, tap Beautify and select the desired effect.

When editing is nished, tap

• To undo the change, tap

• To view the information of the edited photo, tap

• To export the edited photo, tap Tap Done to save the settings.

• To save the edited photo as a PDF le, tap or modify the lename, and tap SAVE.

When all editing is done, tap Save to save the edited photo as a copy.

 Set picture as  Wallpaper or Contact photo.

 Slideshow.

 Details.

 Print  . Select the storage directory, conrm or

. Select Gallery as the photo editing app.

to accept the change. You can do the following:

 Reset.

 Information.

 Export. You can resize the photo and set the export quality.

 Print  . Select the storage directory, conrm

Videos

To view only videos, tap  Videos. The videos are listed in a chronological order.

From the video list, you can do the following:

• Tap a video.

• To view the information of the video, tap

 Details.

• Tap to view it.

• Tap

• To change the viewing mode, tap

• To share a video, tap and hold a video until the check mark appears. Tap to select other videos.

• To delete a video, tap and hold a video until the check mark appears. Tap to select other videos.

• To select all videos, tap and hold a video until the check mark appears. Then tap

On the playback screen, you can do the following:

• To share the video via email, NFC (Android Beam) or Bluetooth, tap

• To pause the playback, tap

• To fast backward (rewind)/forward 3 seconds, tap

• To change the viewing mode, tap

• To stop the playback, tap

• Tap

Editing Videos

Tap a video on the video list. You can do the following:

• To mute the video, tap

• To trim the video, tap

to switch to the Camera app.

 Grid view or List view.

Tap

to share via email, NFC (Android Beam) or Bluetooth.

to delete the selected videos.

Tap

. To resume the playback, tap .

/ .

to view in t-height full screen, in crop screen, or in

t-width full screen.

to access more options:

• Audio effects: When enabled, you can customise the sound settings.

• Loop/Single: Play the video repeatedly/once.

• Stereo/Single track: Set the audio mode.

• Input URL: Enter a URL address for streaming.

• Streaming Settings: Customise the settings for streaming.

• Previous/Next: Play the previous/next video.

• Settings: Change the time for each fast backward/forward step.

• Speaker ON/OFF: Turn off/on the speakerphone mode.

 Mute. The muted video is saved as a copy.

 Trim. Drag the trim sliders to the part where you want the video to begin

and end. Tap

to preview it. Tap SAVE to save the trimmed video as a copy.

 Select all.

MiDM Client

MiDM is an Android Mobile Device Management (MDM) solution for remote management and control

of Android devices. You can use it to update Android mobile devices, install or uninstall apps on Android mobile devices, etc.

For more information, refer to the MiDM documentation.

Music

Before using the Music app, have the audio les ready either on the device or on a memory card.

NotallmusicleformatsaresupportedbytheMusicapp.

Tap on the desktop  Music.

By default, the screen displays the Songs list. To lter audio les by category, tap  Artist, Albums or Playlists.

From the song list, you can do the following:

• To start playback, tap a le from the list, ShufeAll or

• To view the Now playing screen, tap the current playback area at the bottom of the playlist.

• Tap

• To search for a le by keyword, tap

• To customise the sound settings, tap

next to the desired le on the list to do the following:

• Play: Play the le.

• Add to playlist: Add the current le to the current or a new playlist.

• Delete: Delete the le permanently from the device or the memory card.

• Use as phone ringtone: Set the current le as the phone ringtone. (This feature may not be

supported on all models.)

• Share: Share the le via Bluetooth, NFC (Android Beam) or email.

• Details: View the information of the le.

 Snapdragon Audio+.

Playback Controls

On the playback screen, you can do the following:

• To pause the playback, tap

• To play the previous/next le, tap

• To play by random sequence, tap

• Tap

• To view the current playlist, tap

• Tap

to cycle through the repeat modes. : playing by sequence; : repeating the current le.

to access more options:

• Add to playlist: Add the current le to the current or a new playlist.

• Use as phone ringtone: Set the current le as the phone ringtone. (This feature may not be

supported on all models.)

• Sound effects: When enabled, you can customise the sound settings in Snapdragon

Audio+.

• Delete: Delete the le permanently from the device or the memory card.

. To resume the playback, tap .

/ .

. Tap again to disable the feature.

Search

The Search feature enables you to search the web, or applications, contacts and music stored on your device. Simply enter words in the Google search bar.

Sound Recorder

Sound Recorder is useful for quickly recording messages or thoughts at any time.

on the desktop  Sound Recorder.

Tap

1. To record a message, tap

2. To pause recording, tap

3. To stop recording, tap

, hold the device near your mouth, and start recording.

. To resume recording, tap .

. You can preview the message by tapping .

4. To save the message, tap Done. Otherwise tap Discard.

After the message is saved, you can access the le by using Music or File Manager to search and play

it.

Tap

to change the settings:

• Tap File type to change the format of the recorded messages.

• Tap Storage location to change the location of the recorded messages to the device or the

memory card.

Videos

See "Videos" in the "Gallery" section for information.

5 Personalising Your Device

You can easily customise the device for personal settings through the Settings menu, such as personalising the Home screen, changing the display and sound settings, conguration the connection settings, and more.

Note that not all setting items and options are available for all models.

Settings Menu

To access the Settings menu, do one of the following:

• Tap

• Slide down from the top of the screen with two ngers or twice with one nger to open Quick

Not all features are available on all models.

Wireless and Networks Settings

WIFI

See the "Cellular Data Connection" section in the "Connectivity" chapter for information.

Bluetooth

See the "Bluetooth" section in the "Connectivity" chapter for information.

Data usage

You can monitor the data usage on the device. This is useful if you are on a limited data allowance.

Aeroplane mode

See the "Aeroplane Mode" section in the "Device Basics" chapter for information.

NFC

See the "NFC" section in the "Connectivity" chapter for information.

WIFI Calling

When enabled, this "VoIP" feature helps improve the connection to make and receive calls and text messages, and audio quality over a WIFI network.

Android Beam

See the "NFC" section in the "Connectivity" chapter for information.

VPN

You can use a virtual private network (VPN) to access the Internet with more security and privacy. A

VPN may also get around regional restrictions.

To set up a VPN connection, tap +, enter the details of the VPN and tap SAVE. Tap the VPN to connect, enter the required username and password, select the checkbox for Save account information, and tap CONNECT.

If you want to access the Internet via a VPN only, tap

Mobile networks

• You can change the mobile network settings, such as turning on or off data services when

• Modem Interface: the interface options include USB and UART. For optimal performances:

on the desktop  Settings.

Settings, and tap

roaming, selecting a network mode, selecting Internet settings, or selecting a network manually.

• USB: Use this option when the device is using the mobile network, but is not connected to

the cradle or computer. Restart the device for the change to take effect.

 Always-on VPN.

• UART: Use this option when the device is using the mobile network and is connected to the

cradle or computer. Restart the device for the change to take effect.

Mobile plan

You may be able to access the website to view the mobile plan of your service provider. (This feature

may not be supported on all models.)

Device Settings

Display

• Brightness level: Move the slider to adjust the brightness level of the device.

• Adaptive brightness: When enabled, this can automatically optimise the brightness level of the

device based on the available light around you.

• Wallpaper: Change the wallpaper of the desktop.

• Sleep: Change the screen time-out setting.

• Daydream: Set the screensaver when the device is charging or docked.

• Font size: Select the desired font size.

• When device is rotated: To set the screen to rotate automatically based on the device

orientation, select Rotate the contents of the screen. Otherwise, select Stay in current orientation.

Sensors

• Touch:

• Tap Calibration to calibrate the touch screen if the touch screen is not working properly.

• Tap FW Update to update the touch sensor rmware (if available).

Sound&notication

• Move the slider to adjust the sound level for media playback, alarms and notications.

• Do not disturb: Set how and when to receive notications.

• You can set the ringtones for notications.

• Tap Other sounds to enable or disable Screen locking sounds, Charging sounds, Touch

sounds and Vibrate on touch.

• When device is locked: Set how to display notications when the device is locked.

• Appnotications: Set the notication settings individually for apps. (The setting under When

device is locked will always take precedence over the setting for an individual app.)

• Noticationaccess: View the apps that can access your notications.

• Do Not Disturb access: View the apps that can override the Do not disturb setting.

Apps

You can manage the permission settings, default links and battery optimisation for the apps. See the "Your Apps" section in the "Getting Started" chapter for information.

Storage & USB

The storage options of you device include the device internal storage and a removable memory card (if inserted). You can view the storage status in Storage & USB.

• Internal storage: This is used for personal settings and data, and downloaded or transferred

contents. Tap this item to view more information and options.

• Portable storage: You can move media les or apps to a memory card to free up space in the

internal storage. Tap this item to view more information and options.

• To unmount the memory card, tap

before removing the card from the device.

• To format the memory card, tap the card name   Settings  Format. Note that all data will be erased from the card when you format it.

• You can use and format a new memory card as the device's internal storage. Tap the card

name 

the procedure. Note that if this card is not to be used as internal storage any longer, move all data to the device's internal storage before reformatting the card.

Battery

You can view the percentage and time of the remaining battery power since the last full charge.

You can turn on the Battery saver feature to help conserve the battery power. Tap You can turn on or off Battery saver, or set when to turn it on automatically.

For information on battery optimisation for apps, see the "Your Apps" section in the "Getting Started"

chapter.

Memory

The memory (RAM) of the device is used to handle the system and running apps. It is not used as storage space. You can view the memory status in Memory.

Users

You can share the device with others by creating a separate user space for each person. Each user can have their own settings, Home screens, etc. You can also have someone use the device

temporarily as a guest user instead of a regular user.

To add a new user:

1. Tap

2. Tap SET UP NOW. The device will switch to the lock screen. Unlock the screen to use the device

as the new user.

3. To select a user, slide down from the top of the screen with two ngers or twice with one nger to open Quick Settings, tap

To remove a user:

1. Tap

2. If you are the owner of the device, tap

If you are not the owner of the device, tap

The system also allows you to create restricted proles to dene which apps, features, and content a restricted prole can see and use.

Onlythetabletownercancreate,edit,anddeleterestrictedproles.

To create a restricted prole:

1. Tap

2. To name the prole, tap Newprole. Enter the name and tap OK.

3. To pick which listed apps, features, and settings the prole can see and use, tap the On/Off

switches.

4. If you want to edit a restricted prole, from the users list, tap changes.

5. If you want to delete a restricted prole, from the users list, tap

DELETE.



 Settings  Format as internal. Follow the on-screen instructions to complete

 Battery saver.

on the desktop  Settings  Users  Adduserorprole  Add user  OK.

and select the desired user.

on the desktop  Settings  Users.

next to the user's name, and tap Remove user.

 Delete New user from this device.

on the desktop  Settings  Users  Adduserorprole  Restrictedprole.

next to the prole, and make the

next to the prole, and tap

Personal Settings

Location

You can turn the location services on or off, and set the location mode.

Security

• Screen lock: Set the lock setting when the screen enters the sleep mode or when you press the power button. This can protect your personal information.

When using Pattern as the screen lock, you can customise the settings in Make pattern visible, Automatically lock and Power button instantly locks.

When using Password and PIN as the screen lock, you can customise the settings in Automatically lock and Power button instantly locks.

• Lock screen message: Set the message to display on the lock screen.

• Encrypt phone: When the device is encrypted, the data on the device cannot be read by an

unauthorised party.

• Set up SIM card lock: You can enable/disable the SIM card lock and change the PIN code for

the SIM card.

• Make passwords visible: When enabled, the characters of your passwords will not be hidden

behind asterisks.

• Device administrators: View or activate/deactivate device administrators.

• Unknown sources: Enable this feature if you want to install an app from an unknown source.

• Storage type: Display the storage type.

• Trusted credentials: Most certicates are installed automatically for the purpose of identifying

your device for security. Tap to display the trusted certicates installed on the device.

• Install from SD card: Use this feature if you want to manually install a certicate.

• Clear credentials: Use this feature if you want to remove all certicates that you have installed (not

including the permanent system certicates).

• Trust agents: View or activate/deactivate security services to bypass the lock screen. To use this feature, you need to set the screen lock.

• Screen pinning: When enabled, you can lock the screen to a specic app, which can prevent prying from someone else while using your device and accidental key presses.

To use screen pinning:

1. Enable Screen pinning in Settings  Security.

2. Open the screen you want to pin.

3. Tap

4. Swipe up and then tap

5. To unpin the screen, tap and hold

• Apps with usage access: Manage what apps have access to app-usage data on your device

Accounts

You can set up multiple accounts on the device. For information on managing your accounts, see the "Adding Your Email Accounts" section in the "Getting Started" chapter.

Language & input

• Language: Change the display language.

• Spell checker: When enabled, you can tap on a misspelled word to get a list of suggested

replacements.

(Recent Apps button) on the device.

and at the same time.

• Personal dictionary: Add your own words to your personal dictionary so that your device

remembers them.

• Current Keyboard: Change the keyboard language.

• Android Keyboard (AOSP): Change the keyboard settings.

• Text-to-speech output: Customise the text-to-speech settings.

• Pointer speed: Change the speed of scrolling.

Backup & reset

• Network settings reset: Reset the settings for mobile data, WIFI or Bluetooth when you

encounter connection problems.

• Factory data reset: Delete all data and settings from the device. Back up your data before performing a factory data reset.

System Settings

Date & time

You can change the date and time, and time zone of your device.

Accessibility

There may not be accessibility services installed on your device.

• Captions: Enable or disable the closed captions.

• Magnicationgestures: When this item is enabled, you can zoom or magnify by triple-tapping

the screen.

• Large text: Enable this item to make the screen easier to see.

• High contrast text: Enable this item to make text easier to read by turning coloured text to black

or white.

• Auto-rotate screen: When this item is enabled, the screen rotates automatically based on the

device orientation.

• Speak passwords: When this item is enabled, password characters are announced audibly when optional accessibility services are enabled.

• Accessibility shortcut: When this item is enabled, you can enable optional accessibility services

quickly.

• Text-to-speech output: Customise the text-to-speech settings.

• Touch & hold delay: Change the delay level for a touch on the screen to become a touch and

hold.

• Colour inversion: Exchange colour values of the screen.

• Colour correction: When this item is enabled, the colours displayed on the screen are adjusted

for people with difculties distinguishing colours.

Printing

There may not be printing services installed on your device.

About phone

You can view the device and software information, and check for available system updates.

6 Reference

Troubleshooting

For initial support, contact your IT department or your local authorised dealer.

Power does not switch on when using battery power.

The remaining battery power may be too low to run your device. Charge the battery.

Screen responds slowly.

Make sure that your device is not running out of battery power. If the problem still persists, restart your

device.

Screen freezes.

Restart your device.

Screen is hard to read.

Make sure that the backlight of the display is set to a high-enough brightness.

Cannot establish a connection with a computer.

• Make sure that your device and your computer are both switched on before trying to establish a

connection.

• Make sure that the cable is securely plugged into the USB port on your computer and on your device. Connect the USB cable directly to your computer—do not run the cable through a USB hub.

• Restart your device before connecting the cable. Always disconnect your device before you

restart your computer.

• You may need to change the modem setting from USB to UART and restart the device. (For more information, see "Modem Interface" on Page 34.)

Caring for the Device

Taking good care of your device will ensure trouble-free operation and reduce the risk of damage to

your device.

• Keep your device away from excessive moisture and extreme temperatures.

• Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of

time.

• Do not place anything on top of your device or drop objects on your device.

• Do not drop your device or subject it to severe shock.

• Do not subject your device to sudden and severe temperature changes. This could cause moisture condensation inside the unit, which could damage your device. In the event of moisture condensation, allow the device to dry out completely before use.

• The screen surface can easily be scratched. Avoid touching it with sharp objects. Non-adhesive generic screen protectors designed specically for use on portable devices with LCD panels may

be used to help protect the screen from minor scratches.

• Never clean your device with it powered on. Use a soft, lint-free cloth to wipe the screen and the

exterior of your device.

• Do not use paper towels to clean the screen.

• Never attempt to disassemble, repair or make any modications to your device. Disassembly, modication or any attempt at repair could cause damage to your device and even bodily injury or property damage and will void any warranty.

• Keep your device and its accessories out of the reach of small children or animals.

• Do not store or carry ammable liquids, gases or explosive materials in the same compartment as your device, its parts or accessories.

• To discourage theft, do not leave the device and accessories in plain view in an unattended

vehicle.

• Do not leave the device and its accessories in a vehicle in direct sunlight. Overheating may

damage the device.

• The device (excluding accessories) is protected again splashes, water and dust. When tested under controlled laboratory conditions, the device is compliant with the IP67 rating of the IEC 60529 standard. The manufacturer guarantees this grade provided all jack covers are properly and securely closed. Immersion in water or water-pressure such as washing the unit with running water may cause damage to the unit and voids warranty. Normal wear might decrease resistance. The device should not be operated in water.

Regulatory Information

For regulatory identication purposes, F700/Kiron series is assigned a model number of N564/N564A/

N564B.

Marking labels located on the exterior of your device indicate the regulations that your model complies

with. Please check the marking labels on your device and refer to the corresponding statements in this chapter. Some notices apply to specic models only.

Maximum radio frequency (RF) power for Europe:

FCC

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modications not expressly approved by the manufacturer could void the user's

authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Please note:

The use of a non-shielded interface cable with this equipment is prohibited.

Magellan

279 E Arrow Highway San Dimas, CA 91773

USA +1 909-394-5000

http://www.magellangps.com

Canadian Department Of Communications

CAN ICES-3(B)/NMB-3(B)

Radio Interference Regulations Class B Compliance Notice

This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment

regulations.

Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur.

This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement."

The device could automatically discontinue transmission in case of absence of information to transmit,

or operational failure. Note that this is not intended to prohibit transmission of control or signaling

information or the use of repetitive codes where required by the technology.

The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for

harmful interference to co-channel mobile satellite systems.

High-power radars are allocated as primary users (i.e. priority users) of the bands 5250–5350 MHz and 5650–5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Products with the CE marking comply with Radio Equipment Directive (Directive 2014/53/EU) - issued

by the Commission of the European Community.

Compliance with these directives implies conformity to the following European Standards:

• EN 62311

• EN 62209-2

• EN 50566

• IEC 60950-1:2005(Ed.2)+A1:2009+A2:2013

• EN 50332-2

• EN 301 489-1/-3/-17/-19/-52

• EN 55032

• EN 55035

• EN 61000-3-2

• EN 61000-3-3

• EN 300 328: BT/WLAN 2.4 GHz

• EN 301 893: WLAN 5 GHz

• EN 300 330: RFID/NFC

• EN 303 413: GPS

• EN 301 511: GSM 900/1800

• EN 301 908-1/-13

The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.

AT BE BG HR CY CZ DK

EE FI FR DE EL HU IE

IT LV LT LU MT NL PL

PT RO SK SI ES SE UK

WEEE

This symbol means that according to local laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities. Proper recycling of your product will protect human

health and the environment.

Bluetooth

DID: D033925

Safety Precautions

• When using the device, note that the ambient temperature should be below 45ºC (113ºF).

• To prevent possible hearing damage, do not listen at high volume levels for long periods of time.

About Charging

• Use only the charger supplied with your device. Use of another type of charger will result in

malfunction and/or danger.

• This product is intended to be supplied by a LISTED Power Unit marked with "LPS", "Limited Power Source" and output rated + 5 V dc / 2.0 A.

• Use a specied battery in the equipment.

About the Charger

• Do not use the charger in a high moisture environment. Never touch the charger when your hands or feet are wet.

• Allow adequate ventilation around the charger when using it to operate the device or charge the battery. Do not cover the charger with paper or other objects that will reduce cooling. Do not use the charger while it is inside a carrying case.

• Connect the charger to a proper power source. The voltage requirements are found on the

product case and/or packaging.

• Do not use the charger if the cord becomes damaged.

• Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is

damaged or exposed to excess moisture.

About the Battery

• Use a specied battery in the equipment.

• CAUTION: This unit contains a Lithium Ion battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of re or burns, do not disassemble, crush, puncture, or dispose of in re or water.

• Important instructions (for service personnel only)

• Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used

batteries according to the instructions.

• Replace only with the same or equivalent type recommended by the manufacturer.

• The battery must be recycled or disposed of properly.

• Use the battery only in the specied equipment.

Mitac Digital Technology N564A Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Device Basics

Getting to Know Your Device

Front-Side View

Rear-Side View

Right-Side View

Bottom-Side View

Cradle

Using a Micro-SIM Card

Using a Memory Card

Charging the Battery

Extending the Battery Life

Using the Cradle

Turning the Device On and Off

Turning On

Sleep Mode

Aeroplane Mode

Restarting the Device

Turning Off

Shutting Down

Connecting the Device to a Computer

Transferring Files Between the Device and Your Computer:

2 Getting Started

Using the Touch Screen

Rotating the Screen

Home Screen

Status bar

Desktop

Application Shortcuts and Widgets

Favourites Tray

Grouping Shortcuts in a Folder

Changing the Wallpaper

Customising the Home Screen Settings

Navigation Buttons

Quick Settings

Your Apps

App Permissions

App Links

Battery Optimisation for Apps

Stopping an App or a Service from Running

Using the Keyboard

Changing the Keyboard and Input Methods

Basic Editing

Adding Your Email Accounts

Removing an Account

3 Connectivity

Cellular Data Connection

Wireless Network Connection

Connecting to a Wireless Network

Removing a Remembered Network

Bluetooth

Pairing with Another Bluetooth Device

Disconnecting a Bluetooth Connection

Changing the Bluetooth Name of the Device

Removing a Paired Device

Connecting to the Internet Using Bluetooth

Turning NFC On and Off

Transferring Data Using NFC

4 Applications

Browser

Calculator

Calendar

Camera

Taking a Photo

Recording a Video

Camera Settings

Clock

Contacts

Importing/Exporting Contacts

Adding a Contact

Finding a Contact

Editing a Contact

Managing a Contact

Adding a Contact to Favourites

Merging Contacts

Managing a Group

Downloads
