A105 Series
User Manual
Welcome
Thank you for purchasing a Mio product. This Quick Start Guide guides you through the successful
setup of your device and familiarizes you with the basic skills of using the device.
Knowing your device
1. LED indicator 1
(Barcode reader status)
2. LED indicator 2
(Battery charge status)
3. Barcode reader
4. POWER button
5. Barcode reader button
6. Speaker
7. Rear camera
8. Flash
9. Front camera
10. Microphone
11. Micro-USB port
12. HD connector
13. Dock connector
(selected models only)
14. Headphone socket
15. Lanyard holder
16. Volume buttons
17. Memory card slot
en
1
en
3
Getting started
Charging the battery
Your device has an internal battery that may not be fully charged when you purchase it. You should
charge the battery for at least 8 hours before you start using it for the very first time.
To charge the battery, plug the home charger cable into the Micro-USB connector on the bottom of
your device and the mains power charger into the power socket.
1
2
3
CAUTION!
For optimal performance of the lithium battery, note the following:
• Do not charge the battery where the temperature is high (e.g. in direct sunlight). The battery
will stop charging when the ambient temperature is less than -10ºC (14ºF) or more than 60ºC
(140ºF).
• Recharge the battery when it is nearly discharged. When recharging, make sure that the battery
is fully charged. Doing so can extend the battery life.
• If the device has not been used for over a month or if you find the discharge/recharge time has
been shortened, be sure to fully discharge the battery first before recharging it. You are also
advised to fully discharge and recharge the battery once every 1~2 months.
• Failure to follow the battery usage instructions can cause damage to your device, battery and
even bodily injury or property damage and will void the warranty.
2
Performing the initial start-up
1. Press and hold the POWER button until the device turns on.
2. The Home screen will be displayed and the device is in Lock mode by default.
3. To unlock the device, drag the Lock icon ( ) to the right. You can now use your device.
en
3
en
5
Installing the memory card
1. Open the cover on the left side of the device to locate the memory card slot.
2. Hold the microSD card by the edges and gently insert it into the slot with the
label facing the back of your device.
CAUTION! Do not apply pressure to the centre of the memory card.
3. To remove a card, gently push the top edge of the card inwards to release it,
and pull it out of the slot.
IMPORTANT! Before removing the memory card, you are recommended to
unmount it from the system. To unmount the memory card, tap Storage >
Unmount SD card from the Settings menu.
Connecting your device to a computer
Connect the Micro-USB end of the USB cable to your
device and the other end to a USB port in your computer.
Tip: If this is the first time you connect the device to your
computer, you need to install the USB driver on your
computer when prompted. The device’s USB driver is
available from Mio’s website: http://miocare.mio.com/
CAUTION!
The IEC 60529/IP54 is a European system of test specification standards for classifying the degree
of protection provided by the enclosures of electrical equipment. An IP54 designation means that
the unit withstands dust protected (Ingress of dust is not entirely prevented, but it must not enter
in sufficient quantity to interfere with the satisfactory operation of the equipment; complete
protection against contact), and water splashing for up to 5 minutes (water volume: 10 litres per
minute, Pressure: 80-100kPa). Mio guarantees this grade provided the battery door and all jack
covers are properly and securely closed. This device is not IPX7/IPX8 grade; immersion in water
or water-pressure such as washing the unit with running water may cause damage to the unit and
voids warranty.
4
