Safety

This Magellan receiver is a vehicle-navigation aid designed to
assist you in arriving to your selected destinations. When using
this Magellan product, these safety rules must be followed to
prevent accidents that can result in injury or death to yourself or
others:

• Please check with your state or local law enforcement for
applicable regulations regarding mounting to the windshield.
Go to www.magellanGPS.com for alternate mounting
solutions.

• When driving, the need to view the display is minimal. Voice
prompts will guide you to your destination. The driver should
enter data or program the Magellan receiver only when the
vehicle is stopped. Only a vehicle passenger should enter
data or program the receiver while the vehicle is moving.

• It is your responsibility to comply with all traffic laws.

• Every attempt is made to ensure that the database is
accurate. However, roadways, points of interest (POIs), and
business and service locations may change over time. The
database does not include, analyze, process, consider, or
reflect any of the following: legal restrictions (such as
vehicular type, weight, height, width, load and speed
restrictions); road slope or grade; bridge height, width,
weight, or other limits; population density; neighborhood
quality or safety; availability or proximity of law enforcement,
emergency rescue, medical, or other assistance;
construction work zones or hazards; road or lane closures;
road, traffic, or traffic facilities’ safety or condition; weather
conditions; pavement characteristics or conditions; special
events; traffic congestion. It is your responsibility to

605-0347-001 A.fm Page 3 Tuesday, March 15, 2011 2:51 PM

disregard any unsafe, hazardous, or illegal route
suggestions.

• Keep the receiver safe from extreme temperature conditions.
For example, do not leave it exposed to direct sunlight for an
extended period of time. The maximum operating
temperature is 140°F (60°C).

• Take care when mounting the receiver in your vehicle,
whether using the windshield mount or other mount or
accessories, that it does not obstruct the driver's view of the
road, interfere with the operation of the vehicle's safety
devices such as air bags, or present a hazard to occupants
of the vehicle should the receiver be dislodged while driving.
You assume the risks associated with damage to your
vehicle or vehicle occupants as the result of your choices in
mounting the receiver.

• The battery is rechargeable and should not be removed. In
the event it should need to be replaced, please contact
Magellan Technical Support.

Please do not return this product to the place of purchase

without Technical Support at www.magellanGPS.com/

support/.

Register your Magellan RoadMate at

www.magellanGPS.com/ to keep updated on the latest

offers.

Download the User Manual from the

www.magellangps.com/support for detailed information.

605-0347-001 A.fm Page 4 Tuesday, March 15, 2011 2:51 PM

Installation

Choose a Location. The

Magellan RoadMate receiver
needs a clear view of the sky to
receive signals from the GPS
satellites so choose a location
with an unobstructed view of the
sky, commonly on or near the
windshield. The instructions
here describe mounting the
receiver to the windshield, which
is the most common use, but
you can use any flat, smooth
surface that the suction mount
will attach to firmly. Be sure to
check the mount after
installation and verify that it
won’t lose suction.

Warning: Do not mount the
receiver on or allow the power
cable to pass over air bags.

Connect Power. Connect the

power cable to a vehicle power
receptacle. The internal battery
will begin charging as soon as
power is supplied to the
Magellan RoadMate receiver
through the vehicle power cable.

Attach the USB
connector to the
cradle.

Hold the cradle assembly firmly
against a clean, dry surface and
push lever towards the base.

Attach the receiver.

Note: Some vehicles require that
the ignition be on before power
is delivered to the power
receptacle.

A - Power Switch

B - Micro-SD slot

C - Power Input
(USB)

A

BC

605-0347-001 A.fm Page 5 Tuesday, March 15, 2011 2:51 PM

General Information

Please refer to this handbook for questions on using the Magellan
RoadMate receiver. If you are still unable to answer your questions,
check our technical support web page at: http://www.magellanGPS.com/
support/.

Magellan RoadMate

Power

Press the power switch (A) to turn the receiver on. Press the power
switch to put the receiver into suspend mode. Press and hold the power
switch for more than 3 seconds to turn the receiver completely off.
(Turning the receiver completely off and then back on [Power Reset] can
sometimes solve any problems encountered while using the receiver.)

The first time you use the Magellan RoadMate it may take up to 4
minutes to compute your location under normal conditions. With
adverse conditions (not having a clear view of the sky) the time to
compute your location the first time can greatly increase.

Battery

The Magellan RoadMate receiver has an internal battery that is charged
when it is being powered by the vehicle power cable or an external
(optional) AC power adapter. It is estimated that a receiver can operate
for 2 hours from a fully charged battery.

To view the battery strength indicator, access the Main menu. The
battery strength is shown below the signal strength indicator.

4 bars green:
Strong signal

Blank: No satellite
signals. Unable to
compute position.

Landscape Mode

Portrait Mode

605-0347-001 A.fm Page 6 Tuesday, March 15, 2011 2:51 PM

It can take up to 4 hours to fully charge the battery, depending on the
battery level. However, the battery does not need to be fully charged to
use the Magellan RoadMate receiver.

Satellite Signal Strength

To view the satellite signal strength indicator, tap on the Menu button.
The signal strength indicator can be found in the upper right corner.

If you are not getting your current location, use these tips to improve
satellite signal reception.

Leave the garage or parking structure so the GPS receiver has a clear
view of the sky.

Satellite signals can be blocked by tall buildings, trees or mountains. You
may intermittently see a drop in signal strength in these types of
environments.

Traffic Notice

Your Magellan RoadMate comes equipped with lifetime traffic but
requires that you use the supplied vehicle power adapter to work. Traffic
warnings will not appear if you are using a power adapter other than the
one supplied or operating the receiver on internal batteries.

Landscape or Portrait
Display

The Magellan RoadMate can
be used in landscape or
portrait display mode. For
optimum signal reception
orient the receiver with the
Magellan logo (in red here) to
the top or right.

A

B

C

D

E

F

G

H

I

J

K

605-0347-001 A.fm Page 7 Tuesday, March 15, 2011 2:51 PM

Map Screen while Routing

A Displays distance and street name for next maneuver. Tap

to repeat last instruction.

B Next Turn instruction.

C Traffic icon with the route delay time if traffic warnings

appear on route.

D Displays ETA (estimated time of arrival). Tap to select

distance to destination, arrival time, speed or time
remaining in the route.

E Zoom Out

F Zoom In

G Access Main Menu

H Press to display POIs found on next few highway exits.

(Displayed only while traveling on a highway.)

I Access Volume/Mute Controls

J Access OneTouch Menu

K Current Position Icon
