ASSEMBLY INSTRUCTIONS
Description : 2 DRAWER COUNTRY ACCENT TABLE
- 1 -
Printed in Vietnam
BEFORE ASSEMBLY
NOT INCLUDED
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call for us.
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws, bolts until all completely assembled.
- Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQUIRED
- 2 -
Printed in Vietnam
PART
LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A Top 1
Side panel
B
(L – R)
2
C Back panel
E Back apron 1
G
I
Upper
Drawer side
Lower
Drawer front
1
2
1
D Front apron 1
F
H
J
Upper
Drawer front
Upper
Drawer back
Lower
Drawer side
1
1
2
K
M Rail 2
Lower
Drawer back
1
- 3 -
L
Drawer
bottom
2
Printed in Vietnam
HARDWARE LIST
STEP 1
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1
3
5
7
Bolt
( M6 x 35mm)
Flat Washer
(6.5 x19mm)
Pan head screw
(M4 x 25 mm)
Allen key
(4x80mm)
4
4
3
1
2
4
6
Lock Washer
(6.5 x11mm)
Screw
(M4x30mm)
Knob
(38x30mm)
4
24
3
Attach side panel (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with
allen key (7).
- 4 -
Printed in Vietnam
STEP 2
STEP 3
Slide back panel (C) into the grooves as shown below.
Attach front apron (D) and back apron (E) to the side panel (B) with screws (4) as shown below.
Tighten with a screwdriver.
Attach side panel (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with
allen key (7).
- 5 -
Printed in Vietnam
STEP
4
STEP
5
Attach drawer side (G) to drawer front (F) and drawer back (H) with screws (4). Tighten with a
screwdriver.
Slide drawer bottom (L) into the grooves as shown below.
Then attach drawer side (G) to the unit with screws (4) as shown below. Tighten with a screwdriver.
Attach rail (M) to drawer front (F) and drawer back (H) with screws (4). Tighten with a screwdriver.
Attach drawer side (J) to drawer front (I) and drawer back (K) with screws (4). Tighten with a
screwdriver.
Slide drawer bottom (L) into the grooves as shown below.
Then attach drawer side (J) to the unit with screws (4) as shown below. Tighten with a screwdriver.
Attach rail (M) to drawer front (K) and drawer back (I) with screws (4). Tighten with a screwdriver.
Printed in Vietnam
- 6 -
STEP
6
Put drawers into the unit as shown below.
Attach knobs (6) to front of drawer with pan head screws (5). Tighten with a screwdriver.
Printed in Vietnam
- 7 -
