Missing Link ML-3G2DVI User Manual

ML-3G2DVI

SDI to DVI Converter

User Manual

Made in Taiwan

~ 1 ~

Safety and Notice

The ML-3G2DVI SDI to DVI Converter has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all electronic equipments, the
ML-3G2DVI should be used with care. Please read and follow the safety instructions to protect yourself from
possible injury and to minimize the risk of damage to the unit.

 Follow all instructions and warnings marked on this unit.
 Do not attempt to service this unit yourself, except where explained in this manual.
 Provide proper ventilation and air circulation and do not use near water.
 Keep away the objects that might damage the device and assure that the placement of this unit is on a

stable surface.

 Use only the power adapter, power cords and connection cables designed for this unit.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

~ 2 ~

The ML-3G2DVI SDI to DVI Converter with Loopout provides a cost effective way to convert
3G/HD/SD-SDI signal to DVI signal. The conversion between SDI and DVI is pure digital and guarantees no
loss transformation for both audio and video. Plus, with up to 8 channels audio support, 7.1 channel or 5.1
channel audio becomes available. The ML-3G2DVI also provides 1 low jitter and re-clocked outputs for daisy
chain or a monitor.

Features

 Supported high-definition (HD) formats:

NTSC 525@59.94, PAL 625@50, 720p@50,720p@59.94, 720p@60(recommand), 1080i@50,

1080i@59.94, 1080i@60, 1080p@23.97, 1080p@24, 1080p@25, 1080p@29.97, 1080p@30, 1080p@50,

1080p@59.94, 1080p@60(recommand)

Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 270 Mbps

 Auto 3G/HD/SD-SDI detection
 One SDI compliant output and two DVI compliant output

Introduction
