PDS-100G-GN/ID
Detection and Identication - Risks Prevention
PDS-100G-GN/ID
Spectrometric Personal Radiation Detector
The PDS-100G/ID and PDS-100GN/ID are the most
ultimate evolution of the gamma and gamma/neutron
radiation detectors offering embedded spectrum
acquisition and identication.
These sensitive pocket-sized devices are designed to
detect, locate, quantify and identify radioactive
sources to discriminate on the spot Naturally
Occuring Radioactive Material (NORM) and medical
isotopes against industrial sources or Special Nuclear
Materials.
High sensitivity provides better spectra in a shorter
time. Fully automated acquisition and identication as
well as manual modes are provided.
FEATURES
Detection, Search and Identication of nuclear material for
Homeland Security applications.
● Small, rugged, compact, user-friendly
● High sensitivity and fast response time
● Embedded identication, automated & manual mode
● Visual, audio and vibration alarms
● Wireless communication interface
Identcation results are displayed as a list of isotopes
with categories and condence levels. Spectra and ID
results are memorized for later transmission.
PDS-100G/ID and PDS-100GN/ID have been
designed specially for First Responders, Law
Enforcement, Customs inspectors and for Personnel
and Site security in critical infrastructures.
VERSIONS:
• PDS-100G/ID: Gamma version
• PDS-100GN/ID: Gamma and Neutron version
health physics
A Mirion Technologies Division
Featuring:
PDS-100G-GN/ID
Detection and Identication - Risks Prevention
DETECTION
● Detector gamma CsI(Tl): > 400 cps per µSv/h for
● Detector neutron LiI(Eu) (GN version only)
● Gamma dose rate display 0.01 µSv/h
137
to 100 µSv/h (1 µrem/h to 10 mrem/h)
● Gamma count rate display: 0 to 99 999 cps
● Neutron count rate display: 0.0 to 999 cps
● Gamma alarm response time:
● Standard threshold: 0.5 µSv/h step, alarm within 1 s
● Sensitive threshold: 0.05 µSv/h step, alarm within 3 s
● Neutron alert response time: mean time to detect
20000 n/s Cf252 at 10 cm: <2 sec.
SEARCH
● 1s integration time with chirp
SPECTROMETRY AND IDENTIFICATION
● 512 / 1024 channels spectra : 30keV to 1.7 MeV
● Automated alarm triggered mode with auto
conrmation
● Manual mode with preset time and/or counts and
resume capability
● Identication by NMD algorithm
○ up to 4 isotopes mixed
○ detectabiliby grade, unknown or ID unsure indication
○ identication time at 1 µSv/h typical 1 minute
○ designed to exceed ANSI N42-48 SPRD standard
Cs
● Easy-to-read display (OLED technology)
● Memory of 100/50 512 ch/1024 ch. spectra
and >1000 events
● IRDA and Bluetooth® technology communication
ELECTRICAL & MECHANICAL CHARACTERISTICS
● Power supply: 2 x AA batteries
(Lithium, Alkaline or Ni-MH); lifetime typical 100 hours
● Dimensions (l x w x h): 123 x 74 x 43 mm
(4.84 x 2.91 x 1.69 in); weight: 300 g (10.58 oz)
ENVIRONMENTAL CHARACTERISTICS
● Temperature range:- 20°C to 50°C (-4°F to 122°F)
ID: -15°C to +45°C (5°F to 115°F)
● EMI, shock, vibration, drop and water resistant
ACCESSORIES
● PDSmass software for remote display, spectra and
historic retrieve, parameters settings
● SMI software for spectra analysis and identication replay
● Silicon protection
● Belt Clip
● Pouch with belt clip
● External power supply / battery charger
NORM 40K, 226Ra and daughters, 232Th and daughters
Medical 18F, 51Cr, 67Ga, 75Se, 99mTc, 111In, 123I, 131I,
201Tl
Industrial 22Na, 57Co, 60Co, 133Ba, 137Cs, 152Eu, 192Ir,
241Am
SNM 235U, 238U, 239Pu
In bold, isotopes addressed by ANSI for SPRD
FUNCTIONAL FEATURES
● Detection, search and/or identication mode
● Source indication alarm and danger alarm
● Visual, audible and silent alarms (vibration, earphone)
Health Physics
Division
Mirion Technologies (MGPI) Inc
5000 Highlands Parkway
Suite 150
Smyrna Georgia 30082
USA
T +1.770.432.2744
F +1.770.432.9179
Mirion Technologies (MGPI) SA
Lieu-Dit Calès,
Route d’Eyguières
F-13113 Lamanon
France
T +33 (0) 4 90 59 59 59
F +33 (0) 4 90 59 55 18
Mirion Technologies (RADOS) Oy
P.O. Box 506
FIN-20101 Turku
Finland
T +358 2 468 4600
F +358 2 468 4601
Detection mode screen
Search mode screen
Auto ID in progress
Auto ID in progress
Mirion Technologies (RADOS) GmbH
Ruhrstrasse 49
DE-22761 Hamburg
Germany
T +49 (0) 40 851 93-0
F +49 (0)40 851 93 256
Manual ID in progress
NMD result screen
Spectra view with PDSmass
www.mirion.com
144215EN-C
Mirion Technologies Shanghai Branch
Room 801, 78 Jiangchang
San Lu, Zhabei District
Shanghai 200436
China
T +86 21 6180 6920
F +86 21 6180 6924
Since norms, specications and designs are subject to occasional change, please ask for conrmation of the information given in this publication.
