INTELLIGENT FIRE ALARM CONTROL PANEL FX-2000 SERIES
MEA
ed
Features
• Listed to UL 864, 9th edition
• Large system capacity
• Modular design
• Each Analog Loop is capable of supporting 99 Analog
Sensors and 99 Addressable Modules which can be
wired in Class A (Style 6 or 7) or Class B (Style 4)
• Base system supports 16 conventional hardwired
modules with the provision to add more using the
ALC-H16 Hardwire Loop Controller Module
• 6 or 12 Amp power supply
• Four Class A/B (Style Z/Y) Indicating Circuits rated at
1.7 Amps each
• Congurable for Two Stage operation
• Three level password protection with field
programmable denition which enables the installer
to determine what functions are accessible for each
password level
• Panel Security to protect site congurations
• Manual Control Enable which allows password
protection for all front panel function switches
Description
Mircom’s FX-2000 Series Microprocessor Based
Intelligent Fire Alarm Control Panel is designed
to provide maximum flexibility of analog system
requirements while also providing easy installation
and operation at a cost-effective price.
The FX-2000 base panel consists of one intelligent
analog loop controller capable of supporting 99 Analog
Sensors and 99 Addressable Modules which can be
wired in Class A (Style 6 or 7) or Class B (Style 4). The
system can be expanded by adding additional Analog
Loop Controller Modules. In addition the base panel
supports 16 conventional hardwire adder modules
such as the DM-1008A Initiating Circuit Module, SGM1004A Indicating Circuit Module and the RM-1008A
Relay Circuit Module. Additional conventional hardwire
adder modules can be added with the ALC-H16 Adder
Hardwire Loop Controller Module, which allows the
system to support an additional 16 conventional adder
modules. The base panel also consists of 4 Class A/B
(Style Z/Y) Indicating Circuits rated at 1.7 Amps each
and either a 6 or 12 Amp Power Supply.
Equipped with a large 4 x 20 Back-lit Alphanumeric
LCD display, the FX-2000 utilizes a simple Menu
system complete with a directional keypad, common
control switches and LEDs, Alarm Queue switches and
LEDs and two congurable input switches.
• Correlatable Switch Inputs which allows for multifunctional outputs
• Four Alarm Queues with selector switches and LEDs
for Alarm, Supervisory, Monitor and Trouble
• Auxiliary relay contacts for Common Alarm, Common
Supervisory and Common Trouble
• RS-232 output for remote system printer or CRT
• Two Event History Logs comprised of a 1000 Alarm
History Log for alarm related events and a 2000 Event
Log for all events
• Front Panel Auto-Congure and/or Computer laptop
Programmable
• Large 4 by 20 character Back-lit LCD Display with user
friendly menu
• Common Control switches and/or indicating LEDs for
System Reset, Signal Silence, Fire Drill, Acknowledge,
General Alarm, Lamp Test, A.C. On, Pre-Alarm and
Ground Fault
• Built-in One Man Walk Test operation
• Congurable for Coded Operation
• Supports an RS-485 interface to the QX-5000 Voice
Evacuation System
• Panel selection for Canadian (ULC) or U.S.A. (UL)
requirements for smoke sensors (sensitivity) via
computer laptop
• Capability to adjust Intelligent Smoke Detector
sensitivity level
S7010
S7010
7165-1477:111
7170-1477:119
APPROVED
3013980
approv
313-97-E
City of
Chicago
Class I (Con) E15095
Class II (Con) E15096
Class I (Add) E15097
Class II (Add) E15098
Highrise
CATALOG NUMBER
Mircom reserves the right to make changes at any time without notice in prices, colours, materials, components, equipment, specications and models and also to discontinue models.
NOT TO BE USED FOR INSTALLATION PURPOSES.
5910
Page 2
Operation
The FX-2000 is eld programmable via the front
panel auto configuration or a laptop computer.
In addition, it allows for a three level password
protection that can be eld dened via a laptop
computer. This unique feature allows the installer
to determine what functions are accessible for each
password level.
The system is also equipped with two Event History
Logs; one for Alarm and the other for full panel
sequence events. The Alarm History Log (1000
events) contains all alarm related functions while the
Event Log (2000 events) provides a full sequence
log of all operations, as well as alarms and troubles.
Both Event History Logs can be used during the One
Man Walk Test operation. This allows the event
logs to be downloaded to a laptop or printer for a
permanent record.
The FX-2000 is a very flexible system which
supports both internal and external annunciation
modules. The internal annunciation modules consist
of the RAX-1048TZDS Programmable Zone LED
Annunciator, the IPS-2424DS Programmable Input
Switches Module, the FDX-008 Fan Damper Module
and the AGD-048 Adder Graphic Driver Module.
All of these modules mount within the panel and
are driven from the main LCD display. The external
annunciator modules include the RAM-1032TZDS
and RAX-1048TZDS LED Remote Annunciators,
the MGD-32 Master Graphic Driver Module, and
the RAX-LCD Remote LCD Shared Display. The
RAX-LCD Remote LCD Shared Display provides the
same features as the main display on the FX-2000.
In addition the RAX-LCD also acts as a driver module
that allows for the RAX-1048TZDS, IPS-2424DS,
FDX-008 and AGD-048 to be connected to it. The
RAX-LCD is required as a driver module any time
any of the above mentioned external annunciator
modules are programmed differently from those
on the main panel or are mounted remote from the
main panel.
In addition to these adder modules, the FX-2000 also
supports the UDACT-300A Digital Communicator
Module and the PR-300 Polarity Reversal/City Tie
Module. The FX-2000 also supports an RS-485
interface to the QX-5000 Emergency Zoned Audio
System.
Input Correlations
All input circuits (addressable or hardwired) can be
congured for non-veried alarm, veried alarm,
waterow, latching/non-latching supervisory, monitor,
trouble only or remote switch inputs. All of the input
conguration types listed above, with the exception
of remote switch can be programmed to operate
relays, signal and strobe circuits for hardwired or
addressable devices. Please refer to the chart below
for correlations. The input circuits congured as nonlatching will cause the output circuits congured to
them to follow the state of the input device. This
feature allows for the connection of multiple panels
together for signal operation.
Intelligent or Conventional
Input Types
Relay Signal Strobe
Non-Veried Alarm Yes Yes Yes No
Veried Yes Yes Yes No
Waterow Yes Yes Yes No
Non-Latching Supervisory Yes Yes Yes No
Latching Supervisory Yes Yes Yes No
Monitor Ye s Yes Ye s No
Trouble Only Yes Yes Yes No
Remote Switch Input No No No Yes
The Remote Switch input, which must be momentary,
allows any input type device (addressable or
hardwired) to be congured as a common control
functions such as re drill, system reset, signal
silence etc. The remote switches operate in a
momentary mode like the control switches on the FX2000 main panel. For functions such as re drill, the
remote switch functions in a toggle mode, with one
press for “on” and one press for “off”. The remote
switch is supervised for “stuck in on” positions, where
the switch input is activated (stuck) for more than 30
seconds. If this occurs, a trouble is generated and
clears when the input goes away.
Output
Control Switches
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 2 of 10
Page 3
FX-2000 Standard Series
FX-2003-6DS/FX-2003-12DS Compact Main Control Units
The FX-2003-6DS and FX-2003-12DS Compact Main Control Units come
complete with one Intelligent Signaling Line Circuit, Four Style Z/Y (Class
A/B) Notication Appliance Circuits rated at 1.7 Amps each and a 4 line by 20
character back-lit LCD display. The FX-2003-6DS is equipped with a 6 Amp
Power Supply which charges 10-24 AH batteries while the FX-2003-12DS
includes a 12 Amp Power Supply which charges 17-55 AH batteries. The
FX-2003-6DS/FX-2003-12DS provides space for 3 adder modules and
2 internal annunciator adder modules. The FX-2003-6DS/FX-2003-12DS
mount in a UB-1024DS backbox.
FX-2017-12ADS Mid-Size Main Control Unit
The FX-2017-12ADS Mid-Size Main Control Unit comes complete with
one intelligent Signaling Line Circuit (SLC) Four Style Z/Y (Class A/B) NAC Circuits
(1.7 Amps each), a 4 line by 20 character back-lit LCD display and a 12 Amp
Power Supply which charges 17-55 AH batteries. The FX-2017-12ADS
has space for up to 17 adder modules and 3 internal annunciator adder
modules. The FX-2017-12ADS mounts in the BBX-1072ADS enclosure.
FX-2003-6DS-16LED Compact Main Control Unit
The FX-2003-6DS-16LED Compact Main Control Unit come complete with
one Intelligent Signaling Line Circuit, Four Style Z/Y (Class A/B) Notication
Appliance Circuits rated at 1.7 Amps each and a 4 line by 20 character
back-lit LCD display with 16 LEDS for annunciation (DSPL-420-16TZDS).
This display is functionally equivalent to the classic FX-2000 main display,
but more compact adding in the 16 LEDs for annunciation in addition to
all the standard functions.The FX-2003-6DS-16LED is equipped with a
6 Amp Power Supply which charges 10-24 AH batteries. The
FX-2003-6DS-16LED provides space for 3 adder modules and 2 internal
annunciator adder modules. The FX-2003-6DS-16LED mounts in a
separate ordered UB-1024DS Backbox
NOT TO BE USED FOR INSTALLATION PURPOSES.
FX-2009-12DS Large Size Main Control Unit
The FX-2009-12DS Large Size Main Control Unit comes complete with
one Analog Loop Controller (99 Analog Sensors and 99 Addressable
Modules), 4 Class A/B (Style Z/Y) Indicating Circuits (1.7 Amps each), a
4 line by 20 character back-lit LCD display and a 12 Amp Power Supply
which charges 17-55 AH batteries. The FX-2009-12DS supports 16
conventional adder modules and provides space for up to 9 adder modules
and 3 internal annunciator adder modules. The FX-2009-12DS mounts
in the BB-5000 Series enclosures.
ECX-0012 Expander Chassis
The ECX-0012 Expander Chassis for the FX-2009-12DS/FX-2009S-12
supports up to 12 adder modules and has space for 2 internal annunciator
modules. The ECX-0012 mounts in the BB-5000 series enclosures.
FX-2000 Standard Series System Maximums
• 495 Input Circuits
• 150 Output Circuits
• 5 Intelligent Addressable Loops
• 4 Remote LCD Annunciators
• 4 Main LED Annunciators
• 100 Manual Control Switches
CAT. 5910
page 3 of 10
Page 4
Adder Loop Controller Modules
Adder Hardwire Modules
ALC-198S Single Analog Loop Controller Module
The ALC-198S Single Analog Loop Controller Module
provides an additional analog loop to the FX-2000
consisting of 99 Analog Sensors and 99 Addressable
Modules. The ALC-198S occupies one module slot in
the FX-2000 main or expander chassis.
ALC-396S Dual Analog Loop Controller Module
The ALC-396S Dual Analog Loop Controller Module
provides two additional analog loops to the FX-2000
consisting of 99 Analog Sensors and 99 Addressable
Modules per loop. The ALC-396S occupies one module
slot in the FX-2000 main or expander chassis.
DM-1008A Eight Initiating Circuit Module
The DM-1008A provides 8 Class B (Style B) or 4 Class
A (Style D) Initiating Circuits congurable for Alarm,
Supervisory or Trouble zones. The DM-1008A occupies
one module slot in the FX-2000 main or expander chassis.
SGM-1004A Four Indicating Circuit Module
The SGM-1004A provides 4 Class A/B (Style Z/Y)
Indicating Circuits configurable as Silenceable or
Non-Silenceable. Each Indicating Circuits is rated
at 1.7 Amps. Each of the indicating circuits have
individual signal silence inputs which are jumper
selectable. The SGM-1004A occupies one module
slot in the FX-2000 main or expander chassis.
ALC-H16 Hardwire Loop Controller Module
The ALC-H16 Hardwire Loop Controller Module allows the
FX-2000 to support an additional sixteen (16) conventional
hardwire adder modules. The hardwire modules consist
of the DM-1008 Eight Initiating Circuit Module, SGM1004 Four Indicating Circuit Module and the RM-1008
Eight Relay Circuit Module. The ALC-H16 occupies one
module slot in the FX-2000 main or expander chassis.
Adder Auxiliary Modules
UDACT-300A Digital Alarm Communicator Module
The UDACT-300A Digital Alarm Communicator Module
allows the FX-2000 to transmit addressable point information
to a central station. The UDACT-300A can be congured
locally via the on-board keypad and the CFG-300
Conguration Tool or with a UIMA programming tool and a
computer with an available serial or USB port. The UDACT300A occupies one module slot in the FX-2000 main or
expander chassis.
RM-1008A Eight Relay Circuit Module
The RM-1008A provides the FX-2000 with 8 individual
congurable relays per module. Each relay provides
one Form C contact rated at 28 VDC @1 Amp
(resistive load). The RM-1008A occupies one module
slot in the FX-2000 main or expander chassis.
PR-300 Polarity Reversal/City Tie Module
The PR-300 Polarity Reversal/City Tie Module provides
the system with a supervised City Tie (24 VDC/200 mA
max.) and Polarity Reversal connection (24 VDC (open
circuit), 8 mA max. (shorted)). The PR-300 mounts in
the FX-2000 main chassis.
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 4 of 10
Page 5
Programmable Modules
RAX-1048TZDS Programmable Zone LED
Annunciator Module
The RAX-1048TZDS Programmable Zone LED
Annunciator Module provides 48 programmable bicoloured LEDs. The RAX-1048TZDS connects to the
main panel or the RAX-LCD Shared Display when
mounted remotely. The RAX-1048TZDS occupies
one display position in the BB-1000 or BB-5000
enclosures.
FDX-008 Fan Damper Module
The FDX-008 Fan Damper Module provides individually
programmed circuits which can be used for fan or
damper control. Each circuit has a slide-in label, a three
position selector switch, green “run or open” LED and an
amber “off or closed” LED. The three-position selector
switch has a centre “auto” position, a left “off or close”
position and a right “on or open” position. The FDX008 connects to the main panel or the RAX-LCD when
mounted remotely. It uses MIX-M500CH for control of
fans or dampers and two MIX-M501A for status. The
FDX-008 occupies one display position in the BB-1000
or BB-5000 enclosures.
IPS-2424DS Programmable Input Switches
Module
The IPS-2424DS Programmable Input Switches
Module provides 24 programmable switches that can be
congured for ancillary functions such as zone bypass
or added common control functions. The switches
operate in a toggle operation with one press for “on”
and one press for “off”. The IPS-2424DS connects to
main panel or the RAX-LCD when mounted remotely.
The IPS-2424DS occupies one display position in the
BB-1000 or BB-5000 enclosures.
Electrical Ratings
Current Consumption
Model Standby Alarm
FX-2003-6DS-16LED 230 mA 380 mA
FX-2003-6DS
FX-2003-12DS
FX-2017-12ADS 230 mA 380 mA
FX-2009-12DS 230 mA 380 mA
ALC-198S/ALC-396S 35 mA 50 mA
ALC-H16 35 mA 50 mA
DM-1008A 80 mA 100 mA
SGM-1004A 35 mA 150 mA
RM-1008A 25 mA 150 mA
PR-300 50 mA 300 mA
UDACT-300A 40 mA 60 mA
RAX-LCD 100 mA 150 mA
IPS-2424DS 10 mA 144 mA
FDX-008 10 mA 100 mA
MGD-32 35 mA 1.6 Amps
AGD-048 25 mA 2.4 Amps
RAM-1032TZDS 50 mA 150 mA
RAX-1048TZDS 15 mA 100 mA
230 mA 380 mA
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 5 of 10
Page 6
Remote Annunciators
Graphic Annunciator Driver Modules
RAX-LCD Remote Shared Display
The RAX-LCD Remote Shared Display is a remote
annunciator that provides the same functions as the
main display on the fire alarm control panel, less
the 16 zone LEDs. In addition to operating as a
remote annunciator, it can also be used as a driver
module for standard LED annunciation or reduced
zone annunciation (different from the main panel
annunciation), graphic drivers programmed different from
the main annunciators, programmable switch modules
with a unique conguration and fan damper control also
with a unique conguration. Each time a different type
of annunciation conguration is needed an additional
RAX-LCD is required. The RAX-LCD occupies one
display position in the BB-1000 or BB-5000 enclosures.
RAM-1032TZDS Main Remote LED Annunciator
The RAM-1032TZDS Main Remote LED Annunciator
provides common annunciator functions and 32 points of
LED annunciation. Each display point can be identied
by the slide-in label that slides in beside the LED. The
RAM-1032TZDS is equipped with sealed membranelike buttons for Common Control functions. The RAM1032TZDS allows for the control switches to be disabled
on a per function basis for areas that do not require
certain common control functions to be remotely located
from the re alarm control panel. The RAM-1032TZDS
can be programmed differently than the main panel
annunciator or a remote RAX-LCD. All RAM-1032TZDS
remote annunciators on the system must be programmed
the same. The RAM-1032TZDS occupies one display
position in the BB-1000 or BB-5000 enclosures.
MGD-32 Master Graphic Driver Module
The MGD-32 Master Graphic Driver Module provides
common control inputs for the common control switches
such as System Reset, Signal Silence, Auxiliary
Disconnect, Fire Drill, Lamp Test, Acknowledge and
General Alarm. Any or all of these switch inputs can
be used. There are supervised outputs for all of the
support LEDs and the common control switches. The
MGD-32 can also drive up to 32 supervised outputs.
These output points are capable of driving LEDs or
incandescent lamps. Mounts in a graphic annunciator
wallbox or in the BB-5000 enclosures. External power
supply required for incandescent lamps and lamp
test.
AGD-048 Adder Graphic Driver Module
The AGD-048 Adder Graphic Driver Module can be used
with the MGD-32 Master Graphic Driver modules, or
if located remotely it must be connected and mounted
with the RAX-LCD Shared Display. The AGD-048 will
support an additional 48 supervised outputs. As with
the master modules, the AGD-048 will support both
LEDs and incandescent lamps. Mounts in a graphic
annunciator wallbox or in the BB-5000 enclosures.
NOTE:
The combined total of RAM-1032TZDS and MGD-32 per
system is eight. All RA-1000 Series annunciators or Graphic
driver modules must have the zoned LED or graphic LED
correlated to the same combination of addressable devices
or hardwired zones . However, the zoned LED annunciator
on the FX-2000 main panel can be programmed differently
from the annunciators mounted remotely.
RAX-1048TZDS Adder Remote LED Annunciator
The RAX-1048TZDS Adder Remote LED Annunciator
provides an additional 48 points of LED annunciation.
The RAX-1048TZDS is an expandible module that
connects to the RAM-1032TZDS. The RAX-1048TZDS
occupies one display position in the BB-1000 or BB-5000
enclosures.
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 6 of 10
Page 7
Enclosures
DOX-1024DS DOX-1024DSR
UB-1024DS Universal Backbox
The UB-1024DS Universal Backbox houses the FX-20036DS or FX-2003-12DS main control unit and provides
space to mount up to 17 AH batteries. A DOX-1024DS(R)
door is ordered separately.
Dimensions (minus built-in trim ring): 26”H x 14.5”W x 4.2”D
DOX-1024DS(R) Door
The DOX-1024DS mounts on the UB-1024DS backbox.
The door features the universal CAT-30 lock and is available
in a white (DOX-1024DS) or red exterior (DOX-1024DSR).
BBX-1072ADS
The BBX-1072ADS enclosure is capable of handling one
FX-2017-12ADS Mid-Size Main Control Unit as well as
up to 24 AH Batteries. The cabinet features the universal
CAT-30 lock and a removable door for easy installation
and servicing. The cabinet is available in a white or red
exterior (BBX-1072ARDS).
Dimensions (minus built-in trim ring): 32.5”H x 25”W x 6 .5”D
BB-5008
The BB-5008 is a lobby control centre enclosure which
is capable of handling one FX-2009-12DS Large Main
Control Unit which supports 2 internal annuciator modules
such as the IPS-2424DS, FDX-008, RAX-1048TZDS, etc.
In addition the BB-5008 allows for 4 footprints for mounting
Audio Lobby Control modules, Fire Fighter’s Lobby Control
modules and FX-2000 Internal Annunciator modules. The
cabinet hold up to 24 AH batteries. Door and Chassis
hardware are ordered seperately.
Dimensions: 36”H x 30”W x 7”D
Other Enclosures
BB-1001: 9”H x 12.75”W x 1.2”D
BB-1002: 18”H x 12.75”W x 1.2”D
BB-1003: 26.4”H x 12.75”W x 1.2”D
BB-1008: 33”H x 22.5”W x 1.25”D
BB-1012: 45”H x 22.5”W x 1.25”D
BB-5014
The BB-5014 is a lobby control centre enclosure which
is capable of handling one FX-2009-12DS Large Main
Control Unit which supports 2 internal annuciator modules
such as the IPS-2424DS, FDX-008, RAX-1048TZDS, etc.
In addition the BB-5014 allows for 10 footprints for mounting
Audio Lobby Control modules, Fire Fighter’s Lobby Control
modules and FX-2000 Internal Annunciator modules. The
BB-5014 can also support a graphic annunciator in place
of these modules. The cabinet holds up to 24 AH batteries.
Door and Chassis hardware are ordered seperately.
Dimensions: 60”H x 30”W x 7”D
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 7 of 10
Page 8
Typical FX-2000 Panel Wiring Class B (Style 4)
%%HQFORVXUHFZ5$;/&'
5$;7='6,36'6DQG)';
%%HQFORVXUHFZ
5$;/&'5$;7='6
DQG,36'6
);'6/DUJH0DLQ&KDVVLVLQD
%%HQFORVXUHFZ(&;
([SDQGHU&KDVVLV5$;7='6,36'6
)';DQG$*',QFOXGHV'0$
&RQYHQWLRQDO,QGLFDWLQJ&LUFXLW0RGXOHV
([WHUQDOSRZHUVXSSO\LVUHTXLUHGIRU
LQFDQGHVFHQWODPSVDQGODPSWHVW
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 8 of 10
Page 9
Ordering Information
Model Description
FX-2000 Standard Series
FX-2003-6DS-16LED Compact Main Control Unit c/w one Intelligent Signaling Line Circuit, Four Style Z/Y (Class A/B)
Notication Appliance Circuits rated at 1.7 Amps each and a 4 line by 20 character back-lit LCD
display with 16 LEDS for annunciation (DSPL-420-16TZDS). This display is functionally equivalent
to the classic FX-2000 main display, but more compact adding in the 16 LEDs for annunciation in
addition to all the standard functions.TheFX-2003-6DS-16LED is equipped with a 6 Amp Power
Supply which charges 10-24 AH batteries. The FX-2003-6DS-16LED provides space for 3 adder
modules and 2 internal annunciator adder modules. Order UB-1024DS and DOX-1024DS(R)
separately.
FX-2003-6DS Compact Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each), a 6 Amp power supply and a backbox. Supports up to 16 Conventional Adder Modules. Provides space for 3 Adder Modules and 2 internal annunciation modules. Order UB-1024DS
and DOX-1024DS(R) separately.
FX-2003-12DS Compact Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each), a 12 Amp power supply and a backbox. Supports up to 16 Conventional Adder Modules. Provides space for 3 Adder Modules and 2 internal annunciation modules. Order UB-1024DS
and DOX-1024DS(R) separately.
FX-2017-12ADS Mid-Size Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and
99 Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits
(1.7 Amps each) and a 12 Amp power supply. Supports up to 16 Conventional Adder Modules.
Provides space for 17 Adder Modules and 3 Internal Annunciation modules. Mounts in the BBX1072ADS enclosure.
FX-2009-12DS Large Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each) and a 12 Amp power supply. Supports up to 16 Conventional Adder Modules. Provides space for 9 Adder Modules and 3 Internal Annunciation modules. Mounts in the BB-5000
series enclosures.
ECX-0012 Expander Chassis for the FX-2009-12DS c/w space to add up to 12 adder modules and 2 Internal
Annunciation modules. Mounts in the BB-5000 series enclosures
Adder Loop Controller Modules
ALC-198S Single Loop Intelligent Analog Loop Controller Module (99 Analog Sensors and 99 Addressable Modules)
ALC-396S Dual Loop Intelligent Analog Loop Controller Module (198 Analog Sensors and 198 Addressable
Modules)
ALC-H16 Hardwire Loop Controller Module. Supports 16 Conventional Hardwired Modules
Adder Hardwire Modules
DM-1008A Eight Class B (Style B) or 4 Class A (Style D) Initiating Circuit Module
SGM-1004A Four Class A/B (Style Z/Y) Indicating Circuit Module (Rated at 1.7 Amps per circuit)
RM-1008A Eight Relay Circuit Module c/w eight form C relays (Rated for 28 VDC @ 1 Amp max. per relay)
Adder Auxiliary Modules
UDACT-300A Digital Alarm Communicator Transmitter/Dialer Module
PR-300 Polarity Reversal and City Tie Module
Programmable Modules
RAX-1048TZDS Programmable Zone LED Annunciator Module c/w 48 bi-coloured LEDs.
IPS-2424DS Programmable Input Switches Module c/w 24 selector switches and 24 bi-coloured LEDs
FDX-008 Fan Damper Control Module c/w 8 programmable switches
Remote Annunciators
RAM-1032TZDS Main Annunciator Chassis c/w Common Control Features, Indicators and 32 Bi-Coloured LEDs
RAX-1048TZDS Adder Annunciator Chassis c/w 48 Bi-Coloured LEDs
RTI-1 Remote Trouble Indicator
Remote Shared Display Annunciators
RAX-LCD Remote Shared Display LCD Annunciator c/w Display Queues and Common Controls
Graphic Annunciator Driver Modules
MGD-32 Master Graphic Driver Module c/w Fire Alarm Common Control Switch Inputs and 32 Supervised Outputs
AGD-048 Adder Graphic Driver Module c/w 48 Supervised Outputs
NOT TO BE USED FOR INSTALLATION PURPOSES.
CAT. 5910
page 9 of 10
Page 10
Ordering Information cont’d
Enclosures
UB-1024DS Universal backbox for FX-2003-6DS/FX-2003-12DS. Order DOX-1024DS separately
DOX-1024DS White door for UB-1024DS backbox
DOX-1024DSR Red door for UB-1024DS backbox
BBX-1072ADS Black backbox enclosure for FX-2000 c/w removable door and CAT-30 lock and key. Houses one FX-
2017-12ADS Mid-Size Main Control Unit and up to 24 AH batteries. Includes White door
BBX-1072ARDS Black backbox enclosure for FX-2000 c/w removable door and CAT-30 lock and key. Houses one
FX-2017-12ADS Mid-Size Main Control Unit and up to 24 AH batteries. Includes Red door
BB-5008 Lobby Control Centre Wallbox Enclosure. Supports 8 Module Footprints
DOX-5008M White Metal Door for BB-5008
DOX-5008MR Red Metal Door for BB-5008
CCH-5008 Custom Mounting Kit for BB-5008. One required per BB-5008
BB-5014 Lobby Control Centre Wallbox Enclosure. Supports 14 Module Footprints
DOX-5014M White Metal Door for BB-5014
DOX-5014MR Red Metal Door for BB-5014
CCH-5014 Custom Mounting Kit for BB-5014. One required per BB-5014
NOT TO BE USED FOR INSTALLATION PURPOSES.
Canada
25 Interchange Way
Vaughan, Ontario L4K 5W3
Telephone: (905) 660-4655
Fax: (905) 660-4113
Web page: http://www.mircom.com Email: mail@mircom.com
U.S.A.
4575 Witmer Industrial Estates
Niagara Falls, NY 14305
Toll Free: (888) 660-4655
Fax Toll Free: (888) 660-4113
Distributed by:
CAT. 5910
Rev. 11
Loading...
