Mirapoint RazorSafe 170, RS170 Getting Started Manual

RazorSafe 7-Series Hardware Getting Started Guide

Release: AOS 5.0 September 2010 Part Number: 010-00822c

This manual supports Archiving Operating System (AOS) release 5.0 and later releases, and RazorSafe 7-Series appliances, until replaced by a newer edition.

The Mirapoint Software and Mirapoint documentation are Copyright © 1998-2010 Mirapoint Software, Inc. All Rights Reserved. You may not print, copy, reproduce, modify, distribute or display this work in hard copy, electronic, or any other form, in whole or in part, by any electronic, mechanical, or other means, without the prior written consent of Mirapoint Software, Inc., except that you are permitted to make one copy for archival purposes only in connection with the lawful use and operation of this software.

Mirapoint, RazorGate, and the Mirapoint logo are registered trademarks of Mirapoint Software, Inc. Mirapoint Message Server, Mirapoint Directory Server, Mirapoint Operations Console, RazorSafe, DirectPath, WebMail Direct, WebCal Direct, and GroupCal Direct are trademarks of Mirapoint Software, Inc.

Mirapoint integrates third party software programs within the Mirapoint Software, which are subject to their own license terms. If the user does not agree to abide by the applicable license terms for the integrated third party software programs as defined by the Mirapoint Software License Agreement, then you may not install or operate the Mirapoint Software. These software license agreements, including the Mirapoint Software License Agreement, Red Hat End User License Agreement, and Open LDAP Public License, can be viewed at http://

www.mirapoint.com/licenses/thirdparty/eula.php.

Portions of this product are Copyright © 2008 Red Hat, Inc. All Rights Reserved. The “Red Hat” trademark and the “Shadowman” logo are registered trademarks of Red Hat, Inc. in the U.S. and other countries.

Portions of this product are Copyright © 1999-2003 The OpenLDAP Foundation, Redwood City, California, USA. All Rights Reserved. Permission to copy and distribute verbatim copies of this document is granted.

OpenLDAP is a registered trademark of the OpenLDAP Foundation.

Macintosh is a trademark of Apple Computer, Inc.

Windows, Outlook, Exchange, and Active Directory are trademarks of Microsoft Corporation.

Java and Solaris are trademarks of Sun Microsystems, Inc.

Linux is a registered trademark of Linus Torvalds.

All other trademarks are the property of their respective owners.

OTHER THAN ANY EXPRESS LIMITED WARRANTIES THAT MIRAPOINT PROVIDES TO YOU IN WRITING, MIRAPOINT AND MIRAPOINT'S LICENSORS PROVIDE THE SOFTWARE TO YOU “AS IS” AND EXPRESSLY DISCLAIM ALL WARRANTIES AND/OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL MIRAPOINT'S LICENSORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY (INCLUDING NEGLIGENCE OR OTHER TORT), ARISING IN ANY WAY OUT OF YOUR USE OF THE SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF DAMAGES. MIRAPOINT’S LIABILITY SHALL BE AS LIMITED IN THE LICENSE AGREEMENT.

Contents

Mirapoint RazorSafe 170 (RS170) Installation.................................5

Obtaining Technical Assistance...........................................................................................5

Overview ............................................................................................................................5

Unpacking the Appliance ....................................................................................................6

Installing the Rails and Appliance in a Rack .......................................................................6

Connecting Keyboard, and Monitor ...................................................................................6

Connecting the Power Cable...............................................................................................7

Securing the Power Cord.....................................................................................................7

Connecting Ethernet Cables................................................................................................7

Powering the Appliance ......................................................................................................8

Installing the Bezel (Optional).............................................................................................8

Completing the Operating System Setup .............................................................................8

Mirapoint RazorSafe 700 (RS700) Installation.................................9

Obtaining Technical Assistance...........................................................................................9

Overview ............................................................................................................................9

Unpacking the Appliance ..................................................................................................10

Installing the Rails and Appliance in a Rack .....................................................................10

Connecting Keyboard, and Monitor .................................................................................10

Connecting the Power Cables............................................................................................11

Securing the Power Cord...................................................................................................11

Connecting Ethernet Cables..............................................................................................12

Powering the Appliance ....................................................................................................12

Installing the Bezel (Optional)...........................................................................................12

Completing the Operating System Setup ...........................................................................13

Additional Information ............................................................... 15

Other Information You Might Need ................................................................................ 15

Technical Specifications ................................................................................................... 16

RS170 Technical Specifications ................................................................................. 16

RS700 Technical Specifications ................................................................................. 19

S7000-RS Technical Specifications ............................................................................ 22

Mirapoint RazorSafe 170 (RS170) Installation

The following provides information and procedures for getting started with a Mirapoint RazorSafe 170 (RS170).

Before performing the following procedures, review the safety instructions provided with the appliance.

Obtaining Technical Assistance

If you need help understanding a procedure in this guide or if the appliance performs unexpectedly, see Additional Information on page 15 and the Mirapoint RazorSafe 170 (RS170) Hardware Guide.

Overview

Installing and configuring your appliance involves the following tasks:

◆ Unpacking the Appliance on page 6

◆ Installing the Rails and Appliance in a Rack on page 6

◆ Connecting Keyboard, and Monitor on page 6

◆ Connecting the Power Cable on page 7

◆ Securing the Power Cord on page 7

◆ Powering the Appliance on page 8

◆ Installing the Bezel (Optional) on page 8

◆ Completing the Operating System Setup on page 8

Mirapoint RazorSafe 170 (RS170) Installation

Unpacking the Appliance

Unpack your appliance and identify each item.

Installing the Rails and Appliance in a Rack

If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment might be greater than room ambient temperature. Consider installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer. For more information, see RS170 Technical Specifications on page 16.

Following the safety instructions provided in your appliance box and the rack installation instructions provided with in the rail kit, assemble the rails and install the appliance in the rack.

Connecting Keyboard, and Monitor

Connect a keyboard, and monitor (not included).

The connectors on the back of your appliance have icons indicating which cable to plug into each connector. Be sure to tighten the screws (if any) on the monitor's cable connector.

Connecting the Power Cable

Connect the appliance’s power cable to the appliance, and connect the monitor’s power cable to the monitor.

Securing the Power Cord

Bend the appliance power cable into a loop as shown in the illustration and secure the cable to the bracket using the provided strap.

Plug the other end of the power cable into a grounded electrical outlet or a separate power source such as an uninterruptible power supply (UPS) or a power distribution unit (PDU).

Connecting the Power Cable

Connecting Ethernet Cables

Mirapoint recommends the use of Category 5 patch cables; port connections are standard RJ-45.

Designated Ethernet Port

Mirapoint RazorSafe 170 (RS170) Installation

Powering the Appliance

Press the power button on the appliance and the monitor. The power indicators illuminate.

Installing the Bezel (Optional)

A lock on the bezel restricts access to the power button, optical drive, and hard drives. The LCD panel and navigation buttons are accessible through the front bezel.

Install the bezel (optional).

Completing the Operating System Setup

The Archiving Operating System (AOS) is pre-installed on all Mirapoint RazorSafe appliances. Once your appliance is physically installed and powered on, you must complete the software configuration as described in the Mirapoint RazorSafe Software Configuration Guide.

For the latest information on AOS support, see support.mirapoint.com.

Mirapoint RazorSafe 700 (RS700) Installation

The following provides information and procedures for getting started with a Mirapoint RazorSafe 700 (RS700).

Before performing the following procedures, review the safety instructions provided with the appliance.

Obtaining Technical Assistance

If you need help understanding a procedure in this guide or if the appliance performs unexpectedly, see Additional Information on page 15 and the Mirapoint RS700 Hardware Guide.

Overview

Installing and configuring your appliance involves the following tasks:

◆ Unpacking the Appliance on page 10

◆ Installing the Rails and Appliance in a Rack on page 10

◆ Connecting Keyboard, and Monitor on page 10

◆ Connecting the Power Cables on page 11

◆ Securing the Power Cord on page 11

◆ Powering the Appliance on page 12

◆ Installing the Bezel (Optional) on page 12

◆ Completing the Operating System Setup on page 13

Mirapoint RazorSafe 700 (RS700) Installation

Unpacking the Appliance

Unpack your appliance and identify each item.

Installing the Rails and Appliance in a Rack

Following the safety instructions provided in your appliance box and the rack installation instructions provided with in the rail kit, assemble the rails and install the appliance in the rack.

Connecting Keyboard, and Monitor

Connect a keyboard, and monitor (not included).

The connectors on the back of your appliance have icons indicating which cable to plug into each connector. Be sure to tighten the screws (if any) on the monitor's cable connector.

Connecting the Power Cables

Connect the appliance’s power cables to the appliance, and connect the monitor’s power cable to the monitor.

Securing the Power Cord

Bend the appliance power cable into a loop as shown in the illustration and secure the cable to the bracket using the provided strap.

Plug the other end of the power cables into a grounded electrical outlet or a separate power source such as an uninterruptible power supply (UPS) or a power distribution unit (PDU).

Connecting the Power Cables

For improved redundancy, Mirapoint recommends connecting the two power supplies to separate circuits, but never mixing the voltages.

For example: Do not plug one power supply into a 120V current and the other power supply into a 240V current.

Mirapoint RazorSafe 700 (RS700) Installation

Connecting Ethernet Cables

Mirapoint recommends the use of Category 5 patch cables; port connections are standard RJ-45.

Designated Ethernet Port

Powering the Appliance

Press the power button on the appliance and the monitor. The power indicators illuminate.

Installing the Bezel (Optional)

A lock on the bezel restricts access to the power button, optical drive, and hard drives. The LCD panel and navigation buttons are accessible through the front bezel.

Install the bezel (optional).

Completing the Operating System Setup

For the latest information on AOS support, see support.mirapoint.com.

Mirapoint RazorSafe 700 (RS700) Installation

Additional Information

The following provides additional information relevant to a Mirapoint appliance.

Provided information includes:

◆ Other Information You Might Need

◆ Technical Specifications on page 16

◆ NOM Information (Mexico Only) on page 21

Other Information You Might Need

See the safety, regulatory, and warranty information which accompanies your appliance.

◆ The rack documentation, included in the rail kit, describes how to install the

rack rails and mount your appliance on to the rack rails.

◆ The Mirapoint RazorSafe 170 (RS170) Hardware Guide and Mirapoint

RazorSafe 700 (RS700) Hardware Guide provide information about the

appliance features and describe how to troubleshoot the appliance and install or replace appliance components. These documents are available online at

support.mirapoint.com.

◆ The CD and DVD media, which accompanies these instructions within the

folio, provides documentation and tools for configuring and managing your appliance.

Always first check for updates online at support.mirapoint.com, and read any updates, because they often supersede information in other documents.

Additional Information

Technical Specifications

RS170 Technical Specifications

Processor

Processor type

Bus type PCI Express Generation 2

Memory capacity 8GB DDR3

Hard drives Two 3.5-inch cabled SATA internal drives

Optical drive One internal slimline SATA DVD-ROM

Single Quad-core Intel

Expansion Bus

Memory

Drives

Connectors

Xeon

Back

NIC Two RJ-45 (for integrated 1-GB NICs)

Serial 9-pin, DTE, 16550-compatible

USB Two 4-pin, USB 2.0-compliant

Video 15-pin VGA

eSATA One 7-pin connector

Front

Video 15-pin VGA

USB Two 4-pin, USB 2.0-compliant

Internal

USB One 4-pin, USB 2.0-compliant

Technical Specifications

Power

AC Power Supply

Wattage 250W

Voltage 100-240 VAC, 50/60 Hz, 4-2 A

Heat dissipation 1039 BTU/hr maximum

Maximum inrush current Under typical line conditions and over the entire

system ambient operating range, the inrush current might reach 25 A.

Batteries

Appliance battery CR 2032 3.0-V lithium ion coin cell

Physical

Height 4.24 cm (1.67 in)

Width 43.4 cm (17.09 in)

Depth 39.37 cm (15.5 in)

Weight (maximum configuration) 8.058 kg (17.77 lb)

Environmental

Temperature

Operating 10° to 35°C (50° to 95°F) with a maximum

temperature gradation of 10°C per hour NOTE: For altitudes above 2950 feet, the maximum operating temperature is derated 1°F/550 ft.

Storage –40° to 65°C (–40° to 149°F) with a maximum

temperature gradation of 20°C per hour

Relative humidity

Operating 20% to 80% (non-condensing) with a

maximum humidity gradation of 10% per hour

Storage 5% to 95% (non-condensing) with a maximum

Maximum vibration

Operating 0.26 Grms at 5–500 Hz for 15 min

humidity gradation of 10% per hour

Additional Information

Storage 1.54 Grms at 10–250 Hz for 15 min

Maximum shock

Operating One shock pulse in the positive z axis (one pulse

Storage Six consecutively executed shock pulses in the

Altitude

Operating –16 to 3048 m (–50 to 10,000 ft)

Storage –16 to 10,600 m (–50 to 35,000 ft)

Airborne Contaminant Level

Environmental (Continued)

on each side of the system) of 31 G for 2.6 ms in the operational orientation

positive and negative x, y, and z axes (one pulse on each side of the system) of 71 G for up to 2 ms

For altitudes above 2950 feet, the maximum operating temperature is derated 1°F/550 ft.

Class G2 or lower as defined by ISA-S71.04-1985

NOM Information (Mexico Only)

The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM):

Exporter: Mirapoint Software, Inc.

1215 Bordeaux Drive Sunnyvale, CA 94089 408-720-3700

Importer: VIRMAR COMUNICACION EMPRESARIAL SA DE CV

Privada Liendo 708 Sur, Col. Obispado Monterrey, NL México 64060 Phone: 011 5281 83404032

Model number: E10S

Supply voltage: 100–240 VAC

Frequency: 50/60 Hz

Current consumption: 4.0 - 2.0A

RS700 Technical Specifications

Technical Specifications

Processor

Processor type

Dual Quad-core Intel

Expansion Bus

Bus type PCI Express x4

Storage Controller Plug-in card

Controller Interface Type Ultra320 SCSI

Data Transfer Rate 320 MBps

Supported Devices Backup Tape drive

Memory

Memory capacity 32 GB DDR3

Drives

Xeon

processors

Hard drives Six 3.5-inch, internal, hot-swappable SAS hard drives.*

Optical drive One internal slimline SATA DVD-ROM

*If you purchased your hardware before September 15, 2010, your configuration is different. For details, contact your Mirapoint representative.

Connectors

Back

NIC Four RJ-45 10/100/1000 Mbps Ethernet

Serial 9-pin, DTE, 16550-compatible

Video 15-pin VGA

Front

Video 15-pin VGA

Additional Information

AC Power Supply (per power supply)

Wattage 870 W (Max.)

Voltage 90–264 VAC, autoranging, 47-63 H

Heat dissipation 2968.6 BTU/hr maximum (Max.)

Power

Maximum inrush current

Batteries

Appliance battery CR 2032 3.0-V lithium coin cell

RAID battery 3.7-V lithium ion battery pack

Under typical line conditions and over the entire ambient operating range, the inrush current might reach 55 A per power supply for 10 ms or less.

Physical

Height 8.64 cm (3.4 in)

Width 48.24 cm (18.99 in) with rack latches

44.31 cm (17.4 in) without rack latches

Depth 72.06 cm(28.4 in) with power supplies and bezel

68.07 cm(26.8) without power supplies and bezel

Weight (maximum configuration) 26.1 kg (57.54 lb)

Weight (without hard drives) 17.7 kg (39 lb)

Temperature

Operating 10° to 35°C (50° to 95°F) with a maximum

Storage –40° to 65°C (–40° to 149°F) with a maximum

Relative humidity

Operating 20% to 80% (non-condensing) with a maximum

Environmental

temperature gradation of 10°C per hour For altitudes above 2950 feet, the maximum operating temperature is derated 1°F/550 ft.

temperature gradation of 20°C per hour

humidity gradation of 10% per hour

Technical Specifications

Environmental (Continued)

Storage 5% to 95% (non-condensing) with a maximum

humidity gradation of 10% per hour

Maximum vibration

Operating 0.26 Gms from 5–350 Hz for 5 minutes in

operational orientations

Storage 1.54 Gms from 10–250 Hz for 10 minutes in all

orientations

Maximum shock

Operating Half sine shock in all operational orientations of

31 G plus or minus 5% with a pulse duration of

2.6 ms plus or minus 10%

Storage Half sine shock on all six sides of 71 G plus or

minus 5% with a pulse duration of 2 ms plus or minus 10% Square wave shock on all six sides of 27 G with a velocity change at 235 in/sec or greater

Altitude

Operating –16 to 3048 m (–50 to 10,000 ft)

For altitudes above 2950 feet, the maximum operating temperature is derated 1°F/550 ft.

Storage –16 to 10,600 m (–50 to 35,000 ft)

NOM Information (Mexico Only)

The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM):

Exporter: Mirapoint Software, Inc.

1215 Bordeaux Drive Sunnyvale, CA 94089 408-720-3700

Importer: VIRMAR COMUNICACION EMPRESARIAL SA DE CV

Privada Liendo 708 Sur, Col. Obispado Monterrey, NL México 64060 Phone: 011 5281 83404032

Model number: E07S

Supply voltage: 100–240 VAC

Frequency: 50/60 Hz

Current consumption: 7.0 - 3.5A

MIRAPOINT SOFTWARE, INC. SOFTWARE LICENSE AGREEMENT

PLEASE READ THIS SOFTWARE LICENSE AGREEMENT (“LICENSE”) CAREFULLY BEFORE DOWNLOADING OR OTHERWISE USING THE SOFTWARE. BY DOWNLOADING, INSTALLING OR USING THE SOFTWARE, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF THIS SOFTWARE LICENSE AGREEMENT.

IF YOU DO NOT AGREE TO THE TERMS OF THIS LICENSE, YOU ARE NOT AUTHORIZED TO DOWNLOAD OR USE THIS SOFTWARE.

1. Scope. This License governs you (“User”) and your use of any and all computer software, any printed or electronic documentation, or other code, whether on disk, in read only memory, or on any other media (collectively, the “Mirapoint Software”) provided to you as part of or with a Mirapoint Product.

2. License, not Sale, of Mirapoint Software. The Mirapoint Software is licensed, not sold, to User by MIRAPOINT SOFTWARE, INC. or its affiliate, if any (“Mirapoint”). USER MAY OWN THE MEDIA ON WHICH THE MIRAPOINT SOFTWARE IS PROVIDED, BUT MIRAPOINT AND/OR MIRAPOINT’S LICENSOR(S) RETAIN TITLE TO THE MIRAPOINT SOFTWARE. The Mirapoint Software installed on the Mirapoint Product and any copies which this License authorizes the User to make are subject to this License.

3. Permitted Uses. This License allows User to use the pre-installed Mirapoint Software exclusively on the Mirapoint Product on which the Mirapoint Software has been installed. With respect to Mirapoint Software [identified by Mirapoint as the “administrative application”] that has not been preinstalled on the Mirapoint Product, this License allows you to copy, use and install such Mirapoint Software on one or more administrative workstations on which the Mirapoint Software is supported. User may make copies of the Mirapoint Software in machine-readable form for backup purposes only, provided that such backup copy must include all copyright and other proprietary information and notices contained on the original.

4. Proprietary Rights; Restrictions on Use. User acknowledges and agrees that the Mirapoint Software is copyrighted and contains materials that are protected by copyright, trademark, trade secret and other laws and international treaty provisions relating to proprietary rights. User may not remove, deface or obscure any of Mirapoint’s or its suppliers’ proprietary rights notices on or in the Mirapoint Software or on output generated by the Mirapoint Software. Except as permitted by applicable law and this License, you may not copy, decompile, reverse engineer, disassemble, modify, rent, lease, loan, distribute, assign, transfer, or create derivative works from the Mirapoint Software. Your rights under this License will terminate automatically without notice from Mirapoint if you fail to comply with any term(s) of this License. User acknowledges and agrees that any unauthorized use, transfer, sublicensing or disclosure of the Mirapoint Software may cause irreparable injury to Mirapoint, and under such circumstances, Mirapoint shall be entitled to equitable relief, without posting bond or other security, including but not limited to, preliminary and permanent injunctive relief.

5. Third Party Programs. Mirapoint integrates third party software programs with the Mirapoint Software which are subject to their own license terms. These license terms can be viewed at http://www.mirapoint.com/licenses/thirdparty/eula.php. If User does not agree to abide by the applicable license terms for the integrated third party software programs, then you may not install the Mirapoint Software.

6. Disclaimer of Warranty on Mirapoint Software. User expressly acknowledges and agrees that use of the Mirapoint Software is at your sole risk. Unless Mirapoint otherwise provides an express warranty with respect to the Mirapoint Software, the Mirapoint Software is provided “AS IS” and without warranty of any kind and Mirapoint and Mirapoint’s licensor(s) (for the purposes of provisions 5 and 6, Mirapoint and Mirapoint’s licensor(s) shall be collectively referred to as “Mirapoint”) EXPRESSLY DISCLAIM ALL WARRANTIES AND/OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN ADDITION, MIRAPOINT DOES NOT WARRANT THAT THE MIRAPOINT SOFTWARE WILL MEET YOUR REQUIREMENTS, OR THAT THE MIRAPOINT SOFTWARE WILL RUN UNINTERRUPTED OR BE ERROR-FREE, OR THAT DEFECTS IN THE MIRAPOINT SOFTWARE WILL BE CORRECTED. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR OTHER DISCLAIMERS, SO THE ABOVE EXCLUSION OR DISCLAIMERS MAY NOT APPLY TO YOU.

7. Limitation of Liability. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL MIRAPOINT BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR RELATING TO THIS LICENSE. FURTHER, IN NO EVENT SHALL MIRAPOINT’S LICENSORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, LOSS OF USE, DATA OR PROFITS OR INTERRUPTION), HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY (INCLUDING NEGLIGENCE OR OTHER TORT), ARISING IN ANY WAY OUT OF YOUR USE OF THE SOFTWARE OR THIS AGREEMENT, EVEN IF ADVISED OF THE POSSIBILITY OF DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THIS LIMITATION MAY NOT APPLY TO YOU. In no event shall

Mirapoint’s total liability to you for all damages exceed the amount paid for this License to the Mirapoint Software.

8. Export Control. As required by the laws of the United States and other countries, User represents and warrants that it: (a) understands that the Mirapoint Software and its components may be subject to export controls under the U.S. Commerce Department’s Export Administration Regulations (“EAR”); (b) is not located in a prohibited destination country under the EAR or U.S. sanctions regulations (currently Cuba, Iran, Iraq, North Korea, Sudan and Syria, subject to change as posted by the United States government); (c) will not export, re-export, or transfer the Mirapoint Software to any prohibited destination or persons or entities on the U.S. Bureau of Industry and Security Denied Parties List or Entity List, or the U.S. Office of Foreign Assets Control list of Specially Designated Nationals and Blocked Persons, or any similar lists maintained by other countries, without the necessary export license(s) or authorizations(s); (d) will not use or transfer the Mirapoint Software for use in connection with any nuclear, chemical or biological weapons, missile technology, or military end-uses where prohibited by an applicable arms embargo, unless authorized by the relevant government agency by regulation or specific license; (e) understands and agrees that if it is in the United States and exports or transfers the Mirapoint Software to eligible users, it will, to the extent required by EAR Section 740.17(e), submit semi-annual reports to the Commerce Department’s Bureau of Industry and Security, which include the name and address (including country) of each transferee; and (f) understands that countries including the United States may restrict the import, use, or export of encryption products (which may include the Mirapoint Software and the components) and agrees that it shall be solely responsible for compliance with any such import, use, or export restrictions.

9. Miscellaneous. This License will be governed by and construed in accordance with the laws of the State of California, U.S.A., without reference to its conflict of law principles. If a court of competent jurisdiction finds any provision of this License invalid or unenforceable, that provision will be amended to achieve as nearly as possible the same economic effect as the original provision and the remainder of this License will remain in full force. Failure of a party to enforce any provision of this License shall not waive such provision or of the right to enforce such provision. This License sets forth the entire agreement between the parties with respect to your use of the Mirapoint Software and supersedes all prior or contemporaneous representations or understandings regarding such subject matter. No modification or amendment of this License will be binding unless in writing and signed by an authorized representative of Mirapoint. You will not export, re-export, divert, transfer or disclose, directly or indirectly, the Mirapoint Software, Mirapoint Products or any technical information and materials supplied under this Agreement without complying strictly with the export control laws and all legal requirements in the relevant jurisdiction, including without limitation, obtaining the prior approval of the U.S. Department of Commerce.

Mirapoint RazorSafe 170, RS170 Getting Started Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
