MIRA-ART Babyschwinger, Traumschwinger M, Traumschwinger L, Traumschwinger XXL, Traumschwinger XXL extra large User Manual
...
- 1 -
your manual
- 2 -
Inhalt
1 Introduction .................................................................................................. 4
2 Prerequisites ................................................................................................ 5
3 Individual Parts ............................................................................................ 7
4 Assembly of the height adjustment ........................................................... 9
4.1 Prepare the threaded rods ................................................................... 9
4.2 Insertion of threaded rods (1) .............................................................. 9
4.2 Inserting the threaded rods (2) .......................................................... 10
4.3 Attach the rst stainless steel inlays .................................................. 10
4.4 Attach the stainless steel bushings .....................................................11
4.5 Inserting the steel pin into the wooden wedge ....................................11
4.6 Placing the wood wedge over the stainless steel .............................. 12
4.7 Attaching the second noble steel inlay ............................................... 12
4.8 Attaching the second wooden panel .................................................. 13
4.9 Screw on and tighten the round nuts ................................................. 13
4.10 Insertion of the carabiner .................................................................. 14
4.11 Finished height adjustment .............................................................. 14
5 Connecting the netting with the height adjustment ............................... 15
5.1 Spread netting ................................................................................... 15
5.2 Insert the rope ends and jam them .................................................... 16
6 Netting hang up and span ........................................................................ 18
6.1 Netting hang up with height adjustment ............................................. 18
6.2 Insert vertical strut (conjunction) ........................................................ 18
6.3 Insert side strut .................................................................................. 19
6.4 Attaching the rope bag ....................................................................... 20
- 3 -
7 Montage Footboard (optional) .................................................................. 20
7.1 Insert vertical strut (conjunction) ........................................................ 21
7.2 Insert side strut .................................................................................. 21
7.3 Adjusting the foot part ........................................................................ 22
7.4 Mounting of the foot ........................................................................... 23
8 Models for Children - Baby chair and Model M ...................................... 23
8.1 Baby chair .......................................................................................... 24
8.2 Children Swinger model M ................................................................. 24
9 Usage of your TRAUMSCHWINGER ........................................................ 25
9.1 Maintenance ....................................................................................... 25
9.2 Cleaning ............................................................................................. 25
9.3 Washing instructions .......................................................................... 26
9.4 Adjusting the seat height .................................................................... 27
9.5 Adjusting the seat position ................................................................. 27
9.6 Sitting, feeling comfortable and getting up .......................................... 27
IMPORTANT!
PLEASE READ CAREFULLY!
KEEP FOR FUTURE REFERENCES
- 4 -
1 Introduction
Create with your TRAUMSCHWINGER (dream swing) a favorite place, a personal Oasis in your home, in the garden, on the balcony or at your workplace. You
will notice that ceilings, ceiling beams, loft beds, roof- and balcony projections,
conservatories, pergolas, stable branches as well as wide doorframes diverse opportunities to place the chair. Also during your vacation, while camping or on trips
you will soon welcome the hammock chair as a companion. Even the transport is
not a problem, since with each chair, you will receive a bag made of cotton fabric,
where you can store the chair ready and space-saving.
This manual will explain to you the instruction, of how to use your TRAUMSCHWINGER (dream swing). The different sizes of the models are construction
equal, the individual steps therefore will be shown as illustrated on Model L. All
information also apply to the other models. The peculiarities of the models for
children (Baby chair and children‘s chair) are explained in chapter 8.
- 5 -
2 Prerequisites
For your TRAUMSCHWINGER you need your building conditions and use wishes
adequately secured. You can receive the standard xing for our products directly
through MIRA - ART we would be pleased to advise you.
Basically, you have the choice between a ceiling mounting, attachment to a beam
or the use of a stator. Pay attention of the respective weight if you are purchase
the attachment for the TRAUMSCHWINGER. Make sure when you chose ceiling
mounting, that your requirement for your ceiling (e.g. concrete) is met. Inquire at
a local hardware store, what kind of attachment you are suppose to use for your
structural circumstances.
SAFETY NOTICE
Our TRAUMSCHWINGER - hanging chairs are resting as well as relaxing
furniture. They are not to be used as trainers and/or play area. If you notice
damage of the material (e.g. cracks), the product should not be used anymore. When an infant or toddler is placed in the nettling, a cloth should be
placed underneath him. Children should not be allowed unsupervised the
use of the furniture. Carefully observe further notice and safety instructions
in this manual, and keep them for possible questions.
Follow exactly the instructions in order to avoid causing dangers due to
incorrect installation. The mounting should be carried out by an adult.
Suspension and height adjustment are to be checked regularely for tight-
ness.
In all one-dot-suspension a swivel or similar needs to be used in order to
avoid shear stresses on the suspension. Our stainless steel hangers with
integrated plain or ball bearing make the use of an additional rotating vortex
unnecessary.
- 6 -
Following table is shown the model-dependent values for the suspension:
Before you start the assembling of TRAUMSCHWINGER, you have to complete
the installation of your chosen mounting. Pay attention to this proper execution of
the installation according to the instructions for the respective xing.
SAFETY NOTICE
Check the attachment regularly for tightness and damages! For damages
caused due to improper or loosened xing, no liability will be assumed by
us. To avoid damage, please pay attention that your suspension of your
hammock chair does not scrubs along on ceilings or walls
Net/ Model
Suspension height
(min./ max.)
Load max.
Wall distance
min.
Babyschwinger
1,8 m / 4,0 m
(als Kindermöbel
1,2 m / 3m)
75 kg
65 cm
Modell M 1,5 m / 3,0 m 75 kg 65 cm
Modell L 1,8 m / 3,6 m 150 kg 70 cm
Modell XL 2,0 m / 3,8 m 150 kg 80 cm
Modell XXL 2,2 m / 4,0 m 150 kg 85 cm
Modell XXL extra
large
2,4 m / 3,8 m 150 kg 99 cm
- 7 -
3 Individual Parts
In the following two pictures as well as table you will see a summary of the
delivery parts of TRAUMSCHWINGER
1) Weaving net made of cotton
2) Rope bag universal 2
3) Wooden transverse strut 3
4) Wooden side strut, 2 piece 3
2
Only available in versions: „Set“ or „Set Plus“.
3
For models XXL and XXL extra large all wooden struts are of the same length.
- 8 -
All items shown on this page are only included when you buy a TRAUMSCHWINGER in the version „Set“ or „Set plus“. For the others versions this
can be purchased as an accessory item.
1
In case you select the baby chair or the model M the wooden wedge is 9 mm thick,
in the Models L to XXL extra large a wooden wedge of 6 mm thickness is used.
NOTE
All parts will be cleaned at the end of the production process. In addition
to this we recommend that you manually clean certain parts to avoid
contamination of cotton ropes. With a dry cotton cloth, clean the openings
in the wooden poles in order to remove residues of sanding dust. With a
moist cloth and a little detergent clean the following rope metal parts of
the height adjustment: the three stainless steel socket as well as the noncolored sticker marked sides of the two stainless steel inserts.
1) Wooden panel (x 2)
2) Stainless steel inserts (x 2)
3) Carabiner
4) Rundmutter (x 6)
5) Stainless steel socket ,rabbet
6) Stainless steel socket (x 2)
7) Allen wrench
8) Threaded rod (x 3)
9) Wood wedge
1
10) Steel pin
- 9 -
4 Assembly of the height adjustment
The rst part for mounting your TRAUMSCHWINGER forms of assembling of
the supplied height adjustment. For this you need the items from the box of
height adjustment and the swivel. The required Tool (an Allen key) is enclosed.
The mounting of the height adjustment can be most easily done, when sitting
at a table.
4.1 Prepare the threaded rods
Some metal parts are ore pre-assembled for testing.
For the assembly you need to disassemble those rst.Take the three
pre-threaded rod´s unscrew each
one of the round nuts and remove
the respective stainless-steel socket
of the threaded rod down. The remainiing ring nut on the threaded rod
screw tangible. Now you have three
threaded rods, on which each a
round nut is screwed.
4.2 Insertion of threaded rods (1)
Take now one of the triangular
wooden panel. One side of the wooden
panel is marked with a colored sticker.
That is the inside of the panel.
Hold the panel with one hand, so that
the sticker marked side faces downward. With your other hand put through
each of the three holes a threaded rod
with a round nut.
- 10 -
4.2 Inserting the threaded rods (2)
Now place your free hand on the
three round nuts to prevent them
from slipping and turn with your
hand the wooden panel The side
with the colored sticker is facing
you now. Place the wooden panel
like that in front of you. The panel
lies now on the round nuts. The
threaded rods face upwards.
Take one of the stainless steel inlays.
A colored sticker marks the side of the
stainless steel inlays, which should be
attached with the inside of the wood
panel.
Grasp the stainless steel inlay in a
way that the side of the sticker is
facing downward. Place the lead over
the threaded rods and place it on the
wooden panel. With colored label
marked side of the stainless steel inlays is now placed on the with colored
sticker marked side of the wood cheek.
4.3 Attach the rst stainless steel
inlays
SAFETY NOTICE
It´s imperative that with colored stickers marked sides of the wooden panel
and the stainless steel inlays lie on each other. This provides that only the
rounded edge of the stainless steel inlays contacted with the supporting
ropes. Failure to comply these installation instructions may increase wear
of the supporting ropes.
- 11 -
4.4 Attach the stainless steel
bushings
4.5 Inserting the steel pin into the
wooden wedge
On the threaded rod into the top
of the triangular wooden panel insert
the stainless steel socket with a
groove. On the two threaded rods at
the short side of the triangular wood
cheek insert now the stainless steel
sockets (without groove).
Now take the wooden wedge and the
steel pen into your hand. Run the
steel pin through the hole in the extent
of the wood chisel uniformly, that on
each side of about 2 mm protrudes.
- 12 -
4.6 Placing the wood wedge over
the stainless steel inlay
4.7 Attach the second noble steel
inlay
Place now the wooden wedge,
which is inserted already with the
imported steel pin with smooth sides
on the already mounted stainless
steel inlay. Place the wooden wedge
so, that the protruding steel pin in
the slot of the stainless steel inlay
must be performed.
Take the second stainless steel inlay
in your hand. Grasp the stainless
steel inlay so, that with the label
marked side facing upward. Run the
stainless steel inlay on the threaded
rods and place it on the stainless
steel bushings. Please ensure that
the steel pin in wooden wedge also
performed in the second slot of the
stainless steel inlay.
SAFETY NOTICE
It´s imperative that with colored stickers marked sides of the wooden panel
and the stainless steel inlays lie on each other. This garantees that only the
rounded edge of the stainless steel inlays are in contact with the supporting
ropes. Failure to comply with this installation instructions may increase
wear of the supporting ropes.
- 13 -
4.8 Attaching the second wooden
panel
4.9 Screw down and tighten the
round nuts
Take the second wooden panel.
With a colored sticker marked side
of the wooden wedge must lie on
the second stainless steel inlay with
a color sticker. Grasp the second
wooden panel so, that the sticker
marked side facing downward. Run
the wooden panel on the threaded
rods and place it over the stainless
steel inlay. With colored sticker
marked side of the second wooden
panel is placed now on the colored
label marked side of the second
stainless steel inlay.
Now screw the three remaining
round nuts with the three threaded
rods, which are placed in the holes of
the second wooden panel. As tool you
can also use the Allen key from the
delivery. Finally drag every six round
nuts tightly. In front of you is now the
fully assembled height adjustment for
your TRAUMSCHWINGER.
SAFETY NOTICE
During use is a possibility that the round nuts loosen. Regularly check
the tightness of the round nuts and drag them rmly with the supplied
Allen key. In case the round nuts loosen, the space between the metal
components can cause metal abrasion, which possibly can stain cord.
- 14 -
4.10 Insertion of the carabiner 4.11 Finished height adjustment
Take the supplied carabiner and
place it in the stainless steel bush
with the groove (on the upper side of
the height adjustment).
Please use both supplied Allen keys
to make sure that all metal parts are
properly tightened. Please make sure
to check these metal parts every time
when using the TRAUMSCHWINGER.
- 15 -
5 Connecting the netting with the height adjustment
Next you connect the netting of your TRAUMSCHWINGER with the height
adjustment. Due to the fact that you have to spread the netting in front of you,
we recommend you put a blanket on the oor. The height adjustment you should
place next to you. This will help you with the next steps.
5.1 Spread netting
Take the rolled netting and unroll it. Loosen the by knots fastened cloth bag with
the wooden crossbars as well as the two page woods off the netting. The cloth
bag may be put aside, since you need the timbers only in the next section. The
best way to spread the netting is, when you raise it once completely with your
hands. For this, take one of the two connection knots in each hand and lift the net
completely in to air. That netting will rotate itself into the correct position. You just
need to return it at on the oor in this position.
For the next steps you need to make sure that the netting is aligned rightly on
the ground. This is indicated by the position of the Netting attached labels. When
the label is on the right top side of aligned netting in front of you, then it lies in the
proper position. If the label is not in this position, rotate or apply the netting accordingly.
- 16 -
5.2 Insert the rope ends and jam them
On delivery, the track ropes can be twisted in themselves and each other, because
of material and manufacturing conditions. Prior to inserting the rope ends in the
height adjustment, you need to make sure that the support ropes are not twisted in
itself and into each other.
SAFETY NOTICE
In case the suspension ropes are inserted into the height adjustment twisted
in itself or into each other, this may increase the wear of the ropes through
damage to the rope surface.
Start at the left side to align the carrying ropes without twisting. Take the left
connecting knots into your left hand and lift this to the extent that the two ropes
are easily clammed to the corners of the netting. Turn the connecting knots in
your hand in a way that the two ropes from the connection knots avoid to overlie one another. (See the following two pix).
If the left connection knot is in this position, take the one from the knot running
rope pair between your thumb and forenger of your right Hand (see next gure).
RIGHT
WRONG
- 17 -
Now drag with your left hand the rope
pair trough the right hand, without to
twist the ropes. If you reach the end
of the rope, grab around. Hold the end
of the rope pair with your left hand so
tight, that it does not twist again.
Now take the height adjustment so
in your right hand, the wood wedge
almost half inserted into the height
adjustment. Insert the end of the rope
pair as the left stainless steel bushing
of height adjustment, that two ropes
side by side laying on the stainless
steel bushing.
Lead out the end of the rope pair between this bush and the wooden
wedge from the height adjustment.
Drag now on this rope pair that it´s
hanging out about 40 cm from the
height adjustment.
Place the height adjustment on the
netting, which is pulled on the left side
rope.
Now take the right connection node in
your right hand and proceed on this
side as well as on the left side. If you
also have led the right pair of ropes
through the height adjustment, press
the wooden wedge into the height
adjustment. This xed the ropes in the
height adjustment.
- 18 -
6 Netting hang up and span
In this section you will nished assembling your TRAUMSCHWINGER For this
you will need the height adjustment connected with the netting, the vertical wood
and the two side wood, the rope bag and a ladder.
6.1 Netting to hang up with height adjustment
6.2 Insert vertical strut
Hang the connected height adjustment with the
swivel into the prepared (resp. existing) suitable
attachment (see chapter 2 Prerequisites). The
following gure shows an example of a mounting
in a wooden beam.
Safety note
Regardless of the type of mounting this has to
be regularly checked for tightness and wear!
One of the supplied wooden struts is longer than the
others. This is the vertical wood (conjunction) NOTE:
For models XXL and XXL extra large all wooden struts
are of same length. You will recognize the vertical strut
since it is thicker than the two of the other woods.
Take the vertical wood and run the respective rope
pair just above the connection knots in the recesses
of the vertical wood. Take care that the ropes, which
are running out of the bottom of the connection knots,
do not overlie one another or are twisted! Turn the
connecting knots in your hand so, that the two ropes
run freely to back and front (see the two Pictures on
the following page). Press the rope pair all the way
into the recess of the vertical wood (conjunction).
- 19 -
RIGHT
WRONG
6.3 Insert side strut
In order to facilitate the insertion of the side woods,
set yourself for 2 minutes into the netting to stretch
the cotton (even in the M models and baby vibrator).
This is also good for the netting to give its comfortable shape after the rst unpacking. After getting
up take the two side woods and plug them on both
sides along the seat surface between the existing
knots above the netting. Press the suspension
ropes all the way in the recesses of the side woods.
For information of adusting the seat height see the
chapter „Using your TRAUMSCHWINGER“.
SAFETY NOTICE
Do not use sharp objects to the rope pair in order to push it into the recesss. This
may damage the surface of the rope, and can interfere with the carrying capacity
of the cables.
SAFETY NOTICE
If the suspension ropes lay on each other or are twisted, this can
increase wear of the ropes through damage to the rope surface. Do
not use sharp objects to the rope pair to push into the recess. This
may damage the surface of the rope, and can interfere with the
carrying capacity of the cables.
- 20 -
6.4 Attaching the rope bag
As a nal step you bring the rope bag
between the two rope pairs above the
cross of wood. Hang on the universal
case with the two adjustable straps. For
the motive bags (sun and sheep) you
should made a knot in order to attach
the cords. Then stow ropes and the
possibly end of the rope of the foot part
in this pocket.
SAFETY NOTICE
The stowage of the ropes is for your safety. Due to the fact that the ropes
are in the bag, an accidental release of the height adjustment cannot occure.
7 Assembly ot foot part (optional)
In this section we show you the installation and mounting of the foot part of your
TRAUMSCHWINGER. Since you have to spread the netting in front of you, we
recommend you put a blanket on the oor. Put the foot bundle in front of you and
unwind the cord of the foot bundles. Then loosen the cotton bag with the timbers
from the netting.
Note
All´ the parts will be cleaned at the end of the production process. In addition
we recommend that you manually clean certain parts to avoid contamination
of cotton ropes. With a dry cotton cloth, clean the openings in the wooden
poles to remove sanding dust residues.
- 21 -
7.1 Insert vertical strut (conjunction)
Spread the netting in front of you so, that the label is in the upper right corner.
One of the supplied wooden struts is longer than the other two. This is the vertical
conjunction wood.
Ensure that the ropes running down from
the connection knot are not aligned or
twisted! Turn the connecting knot in your
hand, if neccessary, so that the two ropes
lie freely forwards and backwards (see
gure). Take the wooden cross and run
each cable pair just above the connection
knot (below the wrapped rope end) into
the recesses of the vertical wood.
SAFETY NOTICE
If the suspension ropes lay on each other or are twisted, it can increase wear
of the ropes through damage to the rope surface. Do not use sharp objects in
order to push the rope pair into the recess. This may damage the surface of
the rope, and can interfere with the carrying capacity of the cables.
7.2 Insert side strut
In order to easily install the insertion of the side woods, stretch the two short sides
of the cotton network vigorously. This is also good for the netting to give its comfortable shape after the rst unpacking. Then hold down the ends of the net and
pull vigorously on each node above the net.
RIGHT
WRONG
After stretching, take both side woods
and stuck them both on sides along
the netting surface and between the
existing knots above the net mesh.
Push the supporting ropes all the way
into the recesses of the side wood.
- 22 -
7.3 Adjusting the foot part
Take the rope as in Fig. 1, and pull a
loop of approximately 50 cm in length
(depending on the mounting height of
the hanging chair).
Following pull the rope on the other
side.
Pull on the rope end as shown in FIG. 3 Note: You can adjust the length of the
rope by changing loop size. Please
make another loop as shown in Fig. 1
As a nal step, please make with the
rope end a security knot directly
behind the height adjustable footrest.
1 2
3
4
5
- 23 -
7.4 Assemby of the foot part
Place the loop behind the carabiner on the groove
connection. If you have no height adjustment, put
the loop of the foot part simply in your carabineer.
Note
With the height adjustable footrest you can
easily adjust the height with only a few grasps. In order to let the foot part down slide
the height adjustable footrest upward. To lift
up the foot part, slide the height adjustable
footrest downward.
8 Models for Children - BABYSCHWINGER and Model M
With these models, you should adjust the height of the BABYSCHWINGER so
that your child can swing freely just above the ground. In addition, it´s recommended to place some damping material on the ground (1.5 m wide). Please note that
hanging chairs as well as cradles are not for rocking and are no toy equipments.
Always stow the ropes in the rope bag, so that they are not reachable for children.
Regularly check attachment, suspension and ropes for wear.
SAFETY NOTICE
Do not allow children in the models unattended or let small children play
nearby unsupervised. If an infant or toddler is placed in the netting, at
least one cloth has to be placed underneath. The products may not be
used, if one part is broken or torn or missing. You should not hang the
swing near open res or other sources of intense heat such electrical
heaters, gas ovens, etc.
- 24 -
8.1 BABYSCHWINGER
While the models M to XXL essentially differ only by the size, the BABYSCHWIN-
GER has a separate web form. Head- and foot side of the net are pulled up (see
gure) to secure your child against falling out.
The
BABYSCHWINGER is suitable as a cot for infants and babies from day rst.
If the child can sit up, kneel or pull itself up, you may no longer use the baby
chaire as an infant cot.
Then operate it by simply changing the side woods into a children high chair. The
necessary position of the side wood in the second pix illustrates. As high chair for
children the baby chair swing is suitable up to about 5 years.
SAFETY NOTICE
Don’t use any mattresses or pillows in addition to the optional MIRA - ART futon.
8.2 Children Swing model M
The model M is suitable for children from 3 to aprox. 10 years.
- 25 -
9 Usage of your TRAUMSCHWINGER
You will nd in this section various information about usage and maintenance your
TRAUMSCHWINGER.
SAFETY NOTICE
If you notice damage of the material (e.g. cracks), the product may not be
used anymore. When an infant or toddler is placed in the netting, a cloth
must be placed underneath at least. Children´s are not allowed unsupervised use of the furniture.
9.1 Maintenance
The natural materials used for the TRAUMSCHWINGER (wood and cotton) are untreated
and ideal for indoor use. For outdoor usage it should be noted that the untreated materials
are not durable and moisture are weather resistant. Avoid that the netting and the untreated
wood are exposed to humidityand rain. We recommend that you remove the hammock chair
and optionally place it to dry in a warm, ventilated place. To take care of the wooden parts
(wooden wedges of height adjustment, vertical and side woods) we recommend from time to
time a treatment with linseed oil varnish. You also can provid the wooden pieces with a wood
preservative or customize colors. Make sure that the recesses of the lateral and side woods
remain free of boiled linseed oil, wood preservatives color. Otherwise, it may later come to
abrasion by contamination of the suspension ropes.
Note
These wood we are using is of high quality, carefully controlled material. Since it is a natural product, the wood may have hidden defects, which can in rare cases lead to breakage.
We will replace wood weaknesses breaks within a period of 2 years from date of purchase.
Damage to the rope surfaces are at an early stage to reported as damage to the repair to
permit under warranty. Loosening and moving the existing knots performs well invalidate the
warranty, as overuse and improper use.
9.2 Cleansing
For light soiling, we recommend to dry the contaminated sites (bone dry!) and remove the dirt
with a coarse brush. For greasy dirt, the affected area should selectively leaned with vinegar
water or mild soapy water. Strong contamination can be washed out by hands, e.g. gall
soap. At large-scale pollution, the netting can also be cleaned in the washing machine (see
Washing instructions).
- 26 -
9.3 Washing instructions
Prepare:
First, remove the lateral and side struts and take out the TRAUMSCHWINGER. Loose
the netting of the height adjustment. Spread the netting and lay the track ropes curled
up on the netting. Fold the netting so that the support ropes completely enclosed with
the netting. Put this net bundle into the washing drum. Please note, depending on the
size of a washing machine the netting with suitable capacity is required (e.g. weight XXL
netting approx 7.5kg)
Washing:
Select the full wash cycle at 40 ° C and max. 1200 rev/ min at spinning. Use a bleach
free detergent and no fabric softener.
Note: The best washing results, we as a manufacturer of ecological have scored toile-
tries W. ULRICH GmbH. Our recommendations: detergent with soapwort extract, lanolin
wool rinse, stain remover. To buy this products, feel free to contact us. The detergent
you use just after the dosage instructions on the bottle. As care additive, we recommend
the addition of 10 ml lanolin wool ushing, to obtain the softness of cotton. If your water
is very hard, you can use up to 30 ml descaler to reduce the degree of hardness and to
receive a softer result. In highly polluted netting, you can use stain remover in the salt
compartment of your washing machine, to improve the cleaning result.
Drying:
The cotton is not suitable for tumble dry using. You can dry the netting quickly in a
warm and well-ventilated place. Do not dry out in cloudy weather conditions.The netting
may only be used again, if it´s thoroughly dry. Through the water, the ne surface bers
adhere to each other. To restore the original obtain ufness of the deck surface, you
can use a medium hard clothes brush to treat. A brush made of pure horsehair is best
for this purpose.
Note: The TRAUMSCHWINGER, is designed as relaxing furniture and a furniture is
unsuitable according to a common full laundry.
After drying and brushing
the cotton hang your
TRAUMSCHWINGER,
as it is described in the
manual.
After washing After brushing
- 27 -
9.4 Adjusting the seat height
With the height adjustment, you can personally setting the optimum seat height of your
TRAUMSCHWINGER. We recommend to adjusting the seat height so, that the bottom edge
of the netting rests in the knees when you are under the suspension point. To adjust the
height you access with each of your hand the rope pairs below the height adjustment. With a
short pull straight down to release the lock.
To make the TRAUMSCHWINGER position deeper, take your hands with the ropes shoulder
wide. Let the ropes smoothly glide, until the desired height has reached. Now take your hands
back together and let the rope go. Of the wooden wedge in the height adjustment jammed so
the ropes in the desired position.
To make the TRAUMSCHWINGER higher, pull down the ropes. When the desired height has
reached, release some of this rope. The wooden wedge in the height adjustment jammed so
the ropes in the desired position.
9.5 Adjusting the seat position
You can change the angle of inclination of the seat position. The plug-in system allows you
different variations between a more up right seated and a more lying posture. To change the
angle of inclination, change the side woods, located between knot and rope sections. Your
sitting position will be more upright, if you insert the side woods more steep. Make sure both
side woods set in the same manner.
9.6 Sitting, feel comfortable and getting up
If you want to sit down, take the netting with the front seat in your knees and take place in the
TRAUMSCHWINGER In Model XXL also your legs will placed. To get comfortable with the
whole body is to lay down position in the TRAUMSCHWINGER XXL, you gather about 1/3
of the netting in to your knees and then sit down. So you only need to take your legs up to
lie in the netting. To get up you move in your hammock chair two steps backward and stand
up. Please note that while sitting down and standing up you are not pulling the side woods
support or pull out of the hammock chair on the upper cross wood.
SAFETY NOTICE
Always keep both rope pairs tightly when adjusting the seat height. Result of one
sided pulling a rope pair, can be slippage of the other cable pair. Do not adjust the
seat height while using the TRAUMSCHWINGER by youself or someone else. Adjust not too hight, otherwise a fall hazard. For babies and infants you should hang
the cot or the hammock chair as low as possible and for security reason place a
mattress or a pillow under it.
MIRAART® GmbH
Bünderstraße 21
33613 Bielefeld
fon: +49 521 66545
mail: info@mira-art.de
web: www.mira-art.de
shop: www.traumschwinger.de
Loading...
