MIPS MIPS32 74K, MIPS32 74Kf, MIPS32 74Kc Programming Manual

Download

Programming the MIPS32® 74K™ Core

Family

Document Number: MD00541

Revision 02.14

March 30, 2011

Unpublished rights (if any) reserved under the copyright laws of the United States of America and other countries.

This document contains information that is proprietary to MIPS Tech, LLC, a Wave Computing company (“MIPS”) and MIPS’ affiliates as applicable. Any copying, reproducing, modifying or use of this information (in whole or in part) that is not expressly permitted in writing by MIPS or MIPS’ affiliates as applicable or an authorized third party is strictly prohibited. At a minimum, this information is protected under unfair competition and copyright laws. Violations thereof may result in criminal penalties and fines. Any document provided in source format (i.e., in a modifiable form such as in FrameMaker or Microsoft Word format) is subject to use and distribution restrictions that are independent of and supplemental to any and all confidentiality restrictions. UNDER NO CIRCUMSTANCES MAY A DOCUMENT PROVIDED IN SOURCE FORMAT BE DISTRIBUTED TO A THIRD PARTY IN SOURCE FORMAT WITHOUT THE EXPRESS WRITTEN PERMISSION OF MIPS (AND MIPS’ AFFILIATES AS APPLICABLE) reserve the right to change the information contained in this document to improve function, design or otherwise.

MIPS and MIPS’ affiliates do not assume any liability arising out of the application or use of this information, or of any error or omission in such information. Any warranties, whether express, statutory, implied or otherwise, including but not limited to the implied warranties of merchantability or fitness for a particular purpose, are excluded. Except as expressly provided in any written license agreement from MIPS or an authorized third party, the furnishing of this document does not give recipient any license to any intellectual property rights, including any patent rights, that cover the information in this document.

The information contained in this document shall not be exported, reexported, transferred, or released, directly or indirectly, in violation of the law of any country or international law, regulation, treaty, Executive Order, statute, amendments or supplements thereto. Should a conflict arise regarding the export, reexport, transfer, or release of the information contained in this document, the laws of the United States of America shall be the governing law.

The information contained in this document constitutes one or more of the following: commercial computer software, commercial computer software documentation or other commercial items. If the user of this information, or any related documentation of any kind, including related technical data or manuals, is an agency, department, or other entity of the United States government ("Government"), the use, duplication, reproduction, release, modification, disclosure, or transfer of this information, or any related documentation of any kind, is restricted in accordance with Federal Acquisition Regulation 12.212 for civilian agencies and Defense Federal Acquisition Regulation Supplement 227.7202 for military agencies. The use of this information by the Government is further restricted in accordance with the terms of the license agreement(s) and/or applicable contract terms and conditions covering this information from MIPS Technologies or an authorized third party.

MIPS, MIPS I, MIPS II, MIPS III, MIPS IV, MIPS V, MIPSr3, MIPS32, MIPS64, microMIPS32, microMIPS64, MIPS-3D, MIPS16, MIPS16e, MIPS-Based, MIPSsim, MIPSpro, MIPS-VERIFIED, Aptiv logo, microAptiv logo, interAptiv logo, microMIPS logo, MIPS Technologies logo, MIPS-VERIFIED logo, proAptiv logo, 4K, 4Kc, 4Km, 4Kp, 4KE, 4KEc, 4KEm, 4KEp, 4KS, 4KSc, 4KSd, M4K, M14K, 5K, 5Kc, 5Kf, 24K, 24Kc, 24Kf, 24KE, 24KEc, 24KEf, 34K, 34Kc, 34Kf, 74K, 74Kc, 74Kf, 1004K, 1004Kc, 1004Kf, 1074K, 1074Kc, 1074Kf, R3000, R4000, R5000, Aptiv, ASMACRO, Atlas, "At the core of the user experience.", BusBridge, Bus Navigator, CLAM, CorExtend, CoreFPGA, CoreLV, EC, FPGA View, FS2, FS2 FIRST SILICON SOLUTIONS logo, FS2 NAVIGATOR, HyperDebug, HyperJTAG, IASim, iFlowtrace, interAptiv, JALGO, Logic Navigator, Malta, MDMX, MED, MGB, microAptiv, microMIPS, Navigator, OCI, PDtrace, the Pipeline, proAptiv, Pro Series, SEAD-3, SmartMIPS, SOC-it, and YAMON are trademarks or registered trademarks of MIPS and MIPS’ affiliates as applicable in the United States and other countries.

All other trademarks referred to herein are the property of their respective owners.

WƌŽŐƌĂŵŵŝŶŐ ƚŚĞ D/W^ϯϮΠ ϳϰ<Ρ ŽƌĞ &ĂŵŝůǇ ZĞǀŝƐŝŽŶ ϬϮϭϰ

Table of Contents

Chapter 1: Introduction........................................................................................................................11

1.1: Chapters of this manual............................................................................................................................. 12

1.2: Conventions............................................................................................................................................... 12

1.3: 74K™ core features................................................................................................................................... 13

1.4: A brief guide to the 74K™ core implementation ........................................................................................ 14

1.4.1: Notes on pipeline overview diagram (Figure 1.1):............................................................................ 14

1.4.2: Branches and branch delays............................................................................................................17

1.4.3: Loads and load-to-use delays.......................................................................................................... 18

1.4.4: Queues, Resource limits and Consequences.................................................................................. 19

Chapter 2: Initialization and identity...................................................................................................21

2.1: Probing your CPU - Config CP0 registers.................................................................................................21

2.1.1: The Config register........................................................................................................................... 22

2.1.2: The Config1-2 registers.................................................................................................................... 23

2.1.3: The Config3 register......................................................................................................................... 24

2.1.4: The Config6 register......................................................................................................................... 25

2.1.5: CPU-specific configuration — Config7.............................................................................................26

2.2: PRId register — identifying your CPU type ............................................................................................... 26

Chapter 3: Memory map, caching, reads, writes and translation ....................................................29

3.1: The memory map ...................................................................................................................................... 29

3.2: Fixed mapping option................................................................................................................................30

3.3: Reads, writes and synchronization............................................................................................................ 30

3.3.1: Read/write ordering and cache/memory data queues in the 74K™ core......................................... 30

3.3.2: The “sync” instruction in 74K™ family cores....................................................................................31

3.3.3: Write gathering and “write buffer flushing” in 74K™ family cores..................................................... 32

3.4: Caches ...................................................................................................................................................... 32

3.4.1: The L2 cache option.........................................................................................................................32

3.4.2: Cacheability options......................................................................................................................... 33

3.4.3: Uncached accelerated writes........................................................................................................... 34

3.4.4: The cache instruction and software cache management.................................................................34

3.4.5: Cache instructions and CP0 cache tag/data registers.....................................................................35

3.4.6: L1 Cache instruction timing..............................................................................................................37

3.4.7: L2 cache instruction timing............................................................................................................... 37

3.4.8: Cache management when writing instructions - the “synci” instruction ........................................... 37

3.4.9: Cache aliases...................................................................................................................................38

3.4.10: Cache locking.................................................................................................................................39

3.4.11: Cache initialization and tag/data registers ..................................................................................... 39

3.4.12: L23TagLo Regiser..........................................................................................................................40

3.4.13: L23DataLo Register.......................................................................................................................40

3.4.14: L23DataHi Register........................................................................................................................40

3.4.15: TagLo registers in special modes .................................................................................................. 41

3.4.16: Parity error exception handling and the CacheErr register............................................................41

3.4.17: ErrCtl register................................................................................................................................. 42

3.5: Bus error exception ................................................................................................................................... 43

3.6: Scratchpad memory/SPRAM..................................................................................................................... 44

3.7: Common Device Memory Map..................................................................................................................46

3 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.8: The TLB and translation............................................................................................................................47

3.8.1: A TLB entry......................................................................................................................................47

3.8.2: Live translation and micro-TLBs....................................................................................................... 48

3.8.3: Reading and writing TLB entries: Index, Random and Wired..........................................................48

3.8.4: Reading and writing TLB entries - EntryLo0-1, EntryHi and PageMask registers............................ 49

3.8.5: TLB initialization and duplicate entries.............................................................................................50

3.8.6: TLB exception handlers — BadVaddr, Context, and ContextConfig registers.................................51

Chapter 4: Programming the 74K™ core in user mode....................................................................55

4.1: User-mode accessible “Hardware registers”.............................................................................................55

4.2: Prefetching data ........................................................................................................................................ 56

4.3: Using “synci” when writing instructions...................................................................................................... 56

4.4: The multiplier.............................................................................................................................................57

4.5: Tuning software for the 74K™ family pipeline ........................................................................................... 58

4.5.1: Cache delays and mitigating their effect..........................................................................................58

4.5.2: Branch delay slot..............................................................................................................................59

4.6: Tuning floating-point..................................................................................................................................59

4.7: Branch misprediction delays...................................................................................................................... 60

4.8: Load delayed by (unrelated) recent store.................................................................................................. 60

4.9: Minimum load-miss penalty.......................................................................................................................60

4.10: Data dependency delays.........................................................................................................................61

4.10.1: More complicated dependencies ................................................................................................... 64

4.11: Advice on tuning instruction sequences (particularly DSP).....................................................................65

4.12: Multiply/divide unit and timings................................................................................................................ 65

Chapter 5: Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture............67

5.1: Hazard barrier instructions ........................................................................................................................ 67

5.2: MIPS32® Architecture Release 2 - enhanced interrupt system(s)............................................................ 68

5.2.1: Traditional MIPS® interrupt signalling and priority........................................................................... 69

5.2.2: VI mode - multiple entry points, interrupt signalling and priority.......................................................70

5.2.3: External Interrupt Controller (EIC) mode.......................................................................................... 70

5.3: Exception Entry Points .............................................................................................................................. 71

5.3.1: Summary of exception entry points..................................................................................................72

5.4: Shadow registers....................................................................................................................................... 73

5.5: Saving Power ............................................................................................................................................ 75

5.6: The HWREna register - Control user rdhwr access .................................................................................. 75

Chapter 6: Floating point unit..............................................................................................................77

6.1: Data representation...................................................................................................................................77

6.2: Basic instruction set................................................................................................................................... 78

6.3: Floating point loads and stores.................................................................................................................. 79

6.4: Setting up the FPU and the FPU control registers .................................................................................... 79

6.4.1: IEEE options .................................................................................................................................... 79

6.4.2: FPU “unimplemented” exceptions (and how to avoid them)............................................................79

6.4.3: FPU control register maps ............................................................................................................... 80

6.5: FPU pipeline and instruction timing...........................................................................................................82

6.5.1: FPU register dependency delays..................................................................................................... 84

6.5.2: Delays caused by long-latency instructions looping in the M1 stage............................................... 84

6.5.3: Delays on FP load and store instructions......................................................................................... 84

6.5.4: Delays when main pipeline waits for FPU to decide not to take an exception................................. 84

6.5.5: Delays when main pipeline waits for FPU to accept an instruction..................................................85

6.5.6: Delays on mfc1/mtc1 instructions .................................................................................................... 85

Programming the MIPS32® 74K™ Core Family, Revision 02.14 4

6.5.7: Delays caused by dependency on FPU status register fields.......................................................... 85

6.5.8: Slower operation in MIPS I™ compatibility mode............................................................................85

Chapter 7: The MIPS32® DSP ASE .....................................................................................................87

7.1: Features provided by the MIPS® DSP ASE..............................................................................................87

7.2: The DSP ASE control register...................................................................................................................88

7.2.1: DSP accumulators ........................................................................................................................... 89

7.3: Software detection of the DSP ASE..........................................................................................................89

7.4: DSP instructions........................................................................................................................................90

7.4.1: Hints in instruction names................................................................................................................ 90

7.4.2: Arithmetic - 64-bit............................................................................................................................. 91

7.4.3: Arithmetic - saturating and/or SIMD Types......................................................................................91

7.4.4: Bit-shifts - saturating and/or SIMD types.......................................................................................... 91

7.4.5: Comparison and “conditional-move” operations on SIMD types......................................................91

7.4.6: Conversions to and from SIMD types .............................................................................................. 92

7.4.7: Multiplication - SIMD types with result in GP register ...................................................................... 92

7.4.8: Multiply Q15s from paired-half and accumulate...............................................................................93

7.4.9: Load with register + register address............................................................................................... 93

7.4.10: DSPControl register access........................................................................................................... 93

7.4.11: Accumulator access instructions....................................................................................................94

7.4.12: Dot products and building blocks for complex multiplication..........................................................94

7.4.13: Other DSP ASE instructions .......................................................................................................... 95

7.5: Macros and typedefs for DSP instructions ................................................................................................ 95

7.6: Almost Alphabetically-ordered table of DSP ASE instructions..................................................................96

7.7: DSP ASE instruction timing.....................................................................................................................100

Chapter 8: 74K™ core features for debug and profiling.................................................................102

8.1: EJTAG on-chip debug unit ...................................................................................................................... 102

8.1.1: Debug communications through JTAG..........................................................................................103

8.1.2: Debug mode...................................................................................................................................103

8.1.3: Exceptions in debug mode.............................................................................................................104

8.1.4: Single-stepping .............................................................................................................................. 104

8.1.5: The “dseg” memory decode region................................................................................................ 104

8.1.6: EJTAG CP0 registers, particularly Debug......................................................................................106

8.1.7: The DCR (debug control) memory-mapped register......................................................................108

8.1.8: The DebugVectorAddr memory-mapped register..........................................................................110

8.1.9: JTAG-accessible registers.............................................................................................................110

8.1.10: Fast Debug Channel....................................................................................................................112

8.1.11: EJTAG breakpoint registers......................................................................................................... 115

8.1.12: Understanding breakpoint conditions...........................................................................................117

8.1.13: Imprecise debug breaks...............................................................................................................118

8.1.14: PC Sampling with EJTAG............................................................................................................118

8.1.15: JTAG-accessible and memory-mapped PDtrace TCB Registers ................................................ 119

8.2: PDtrace™ instruction trace facility........................................................................................................... 121

8.2.1: 74K core-specific fields in PDtrace™ JTAG-accessible registers..................................................121

8.2.2: CP0 registers for the PDtrace™ logic............................................................................................123

8.2.3: JTAG triggers and local control through TraceIBPC/TraceDBPC..................................................125

8.2.4: UserTraceData1 reg and UserTraceData2 reg.............................................................................. 126

8.2.5: Summary of when trace happens .................................................................................................. 126

8.3: CP0 Watchpoints..................................................................................................................................... 128

8.3.1: The WatchLo0-3 registers..............................................................................................................128

8.3.2: The WatchHi0-3 registers .............................................................................................................. 128

8.4: Performance counters.............................................................................................................................129

5 Programming the MIPS32® 74K™ Core Family, Revision 02.14

8.4.1: Reading the event table.................................................................................................................130

Appendix A: References ....................................................................................................................135

Appendix B: CP0 register summary and reference.........................................................................137

B.1: Miscellaneous CP0 register descriptions................................................................................................140

B.1.1: Status register................................................................................................................................141

B.1.2: The UserLocal register .................................................................................................................. 143

B.1.3: Exception control: Cause and EPC registers................................................................................. 143

B.1.3.1: The Cause register............................................................................................................... 143

B.1.4: The EPC register...........................................................................................................................145

B.1.5: Count and Compare ...................................................................................................................... 145

B.2: Registers for CPU Configuration............................................................................................................. 145

B.2.1: The Config7 register......................................................................................................................145

B.3: Registers for Cache Diagnostics............................................................................................................. 148

B.3.1: Different views of ITagLo/DTagLo.................................................................................................148

B.3.2: Dual (virtual and physical) tags in the 74K core D-cache — DTagHi register...............................149

B.3.3: Pre-decode information in the I-cache - the ITagHi Register......................................................... 149

B.3.4: The DDataLo, IDataHi and IDataLo registers................................................................................ 150

B.3.5: The ErrorEPC register...................................................................................................................150

Appendix C: MIPS® Architecture quick-reference sheet(s) ...........................................................151

C.1: General purpose register numbers and names ...................................................................................... 151

C.2: User-level changes with Release 2 of the MIPS32® Architecture.......................................................... 151

C.2.1: Release 2 of the MIPS32® Architecture - new instructions for user-mode ................................... 151

C.2.2: Release 2 of the MIPS32® Architecture - Hardware registers from user mode............................ 152

C.3: FPU changes in Release 2 of the MIPS32® Architecture....................................................................... 153

Appendix D: Revision History ...........................................................................................................155

Programming the MIPS32® 74K™ Core Family, Revision 02.14 6

List of Figures

Figure 1.1: Overview of The 74K™ Pipeline........................................................................................................... 14

Figure 2.1: Fields in the Config Register................................................................................................................. 22

Figure 2.2: Fields in the Config1 Register............................................................................................................... 23

Figure 2.3: Fields in the Config2 Register............................................................................................................... 23

Figure 2.4: Config3 Register Format....................................................................................................................... 24

Figure 2.5: Config6 Register Format....................................................................................................................... 25

Figure 2.6: Fields in the PRId Register...................................................................................................................26

Figure 3.1: Fields in the encoding of a cache instruction........................................................................................ 34

Figure 3.2: Fields in the TagLo Registers ..............................................................................................................39

Figure 3.3: L23TagLo Register Format................................................................................................................... 40

Figure 3.4: L23DataLo Register Format..................................................................................................................40

Figure 3.5: L23DataHi Register Format..................................................................................................................41

Figure 3.6: Fields in the CacheErr Register ...........................................................................................................41

Figure 3.7: Fields in the ErrCtl Register.................................................................................................................. 43

Figure 3.8: SPRAM (scratchpad RAM) configuration information in TagLo............................................................ 45

Figure 3-9: Fields in the CDMMBase Register........................................................................................................46

Figure 3.10: Fields in the Access Control and Status (ACSR) Register ................................................................. 47

Figure 3.11: Fields in a 74K™ core TLB entry........................................................................................................ 48

Figure 3.12: Fields in the EntryHi and PageMask registers.................................................................................... 49

Figure 3.13: Fields in the EntryLo0-1 registers.......................................................................................................50

Figure 3.14: Fields in the Context register when Config3CTXTC=0 and Config3SM=0.........................................51

Figure 3.15: Fields in the Context register when Config3CTXTC=1 or Config3SM=1............................................ 52

Figure 3.16: Fields in the ContextConfig register................................................................................................... 53

Figure 5.1: Fields in the IntCtl Register................................................................................................................... 69

Figure 5.2: Fields in the EBase Register.................................................................................................................72

Figure 5.3: Fields in the SRSCtl Register ............................................................................................................... 73

Figure 5.4: Fields in the SRSMap Register............................................................................................................. 74

Figure 5.5: Fields in the HWREna Register............................................................................................................75

Figure 6.1: How floating point numbers are stored in a register ............................................................................ 78

Figure 6.2: Fields in the FIR register....................................................................................................................... 80

Figure 6.3: Floating point control/status register and alternate views..................................................................... 81

Figure 6.4: Overview of the FPU pipeline .............................................................................................................. 83

Figure 7.1: Fields in the DSPControl Register........................................................................................................88

Figure 8.1: Fields in the EJTAG CP0 Debug register ........................................................................................... 107

Figure 8.2: Exception cause bits in the debug register.........................................................................................108

Figure 8.3: Debug register - exception-pending flags...........................................................................................108

Figure 8.4: Fields in the memory-mapped DCR (debug control) register ............................................................. 109

Figure 8.5: Fields in the memory-mapped DCR (debug control) register ............................................................. 110

Figure 8.6: IFields in the JTAG-accessible Implementation register..................................................................... 110

Figure 8.7: Fields in the JTAG-accessible EJTAG_CONTROL register...............................................................111

Figure 8.8: Fast Debug Channel........................................................................................................................... 113

Figure 8.9: Fields in the FDC Access Control and Status (FDACSR) Register....................................................113

Figure 8.10: Fields in the FDC Config (FDCFG) Register.....................................................................................114

Figure 8.11: Fields in the FDC Status (FDSTAT) Register...................................................................................114

Figure 8.12: Fields in the FDC Receive (FDRX) Register.....................................................................................115

Figure 8.13: Fields in the FDC Transmit (FDTXn) Registers................................................................................115

Figure 8.14: Fields in the IBS/DBS (EJTAG breakpoint status) registers.............................................................116

7 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Figure 8.15: Fields in the hardware breakpoint control registers (IBCn, DBCn)...................................................117

Figure 8.16: Fields in the TCBCONTROLE register ............................................................................................. 122

Figure 8.17: Fields in the TCBCONFIG register ................................................................................................... 123

Figure 8.18: Fields in the TraceControl Register .................................................................................................. 123

Figure 8.19: Fields in the TraceControl2 Register ................................................................................................ 123

Figure 8.20: Fields in the TraceControl3 register.................................................................................................. 123

Figure 8.21: Fields in the TraceIBPC/TraceDBPC registers................................................................................. 125

Figure 8.22: Fields in the WatchLo0-3 Register.................................................................................................... 128

Figure 8.23: Fields in the WatchHi0-3 Register .................................................................................................... 128

Figure 8.24: Fields in the PerfCtl0-3 Register....................................................................................................... 129

Figure B.1: Fields in the Status Register...............................................................................................................141

Figure B.2: Fields in the Cause Register .............................................................................................................. 143

Figure B.3: Fields in the TagLo-WST Register ..................................................................................................... 148

Figure B.4: Fields in the TagLo-DAT Register......................................................................................................149

Figure B.5: Fields in the DTagHi Register.............................................................................................................149

Figure B.6: Fields in the ITagHi Register..............................................................................................................149

Programming the MIPS32® 74K™ Core Family, Revision 02.14 8

List of Tables

Table 2.1: Roles of Config registers........................................................................................................................ 21

Table 2.2: 74K™® core releases and PRId[Revision] fields...................................................................................26

Table 3.1: Basic MIPS32® architecture memory map............................................................................................29

Table 3.2: Fixed memory mapping..........................................................................................................................30

Table 3.3: Cache Code Values...............................................................................................................................34

Table 3.4: Operations on a cache line available with the cache instruction............................................................ 36

Table 3.1: Caches and their CP0 cache tag/data registers.....................................................................................37

Table 3.5: L23DataLo Register Field Description ................................................................................................... 40

Table 3.6: L23DataHi Register Field Description.................................................................................................... 41

Table 3.7: Recommended ContextConfig Values................................................................................................... 53

Table 4.1: Hints for “pref” instructions..................................................................................................................... 57

Table 4.2: Register → eager consumer delays.......................................................................................................62

Table 4.3: Producer → register delays.................................................................................................................... 63

Table 5.1: All Exception entry points....................................................................................................................... 73

Table 6.1: FPU (co-processor 1) control registers..................................................................................................80

Table 6.2: Long-latency FP instructions.................................................................................................................. 84

Table 7.1: Mask bits for instructions accessing the DSPControl register................................................................93

Table 7.2: DSP instructions in alphabetical order...................................................................................................96

Table 8.1: JTAG instructions for the EJTAG unit..................................................................................................103

Table 8.2: EJTAG debug memory region map (“dseg”)........................................................................................ 105

Table 8.3: Fields in the JTAG-accessible EJTAG_CONTROL register ................................................................ 111

Table 8.4: FDC Register Mapping.........................................................................................................................113

Table 8.5: Mapping TCB Registers in drseg........................................................................................................119

Table 8.6: Fields in the TCBCONTROLA register.................................................................................................122

Table 8.7: Fields in the TCBCONTROLB register.................................................................................................122

Table 8.8: Performance Counter Event Codes in the PerfCtl0-3[Event] field. ...................................................... 131

Table B.1: Register index by name....................................................................................................................... 137

Table B.2: CP0 registers by number..................................................................................................................... 138

Table B.3: CP0 Registers Grouped by Function................................................................................................... 140

Table B.4: Encoding privilege level in Status[UM,SM].......................................................................................... 142

Table B.5: Values found in Cause[ExcCode]........................................................................................................ 144

Table B.6: Fields in the Config7 Register..............................................................................................................146

Table C.1: Conventional names of registers with usage mnemonics ................................................................... 151

Table C.2: Release 2 of the MIPS32® Architecture - new instructions................................................................. 152

9 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Programming the MIPS32® 74K™ Core Family, Revision 02.14 10

Chapter 1

Introduction

The MIPS32® 74K™ core is the ﬁrst member of a family of synthesizable CPU cores launched in 2007, and offers the highest performance yet from a synthesizable core. It does this by issuing two instructions simultaneously (where possible) and by using a long pipeline to enable relatively high frequency operation. Conventional high-throughput designs of this type are slowed by dependencies between consecutive instructions, so 74K family cores use out-of- order execution to work around short-term dependencies and keep the pipeline full.

74K Cores offer better performance in the same process compared to MIPS Technologies’mid-range24K® family, at the cost of a larger and more complex core.

Intended Audience

This document is for programmers who are already familiar with the MIPS® architecture and who can read MIPS assembler language (if that’s not you yet, you’d probably beneﬁt from reading a generic MIPS book - see Appendix

A, “References” on page 135).

More precisely, you should deﬁnitely be reading this manual if you have an OS, compiler, or low-level application which already runs on some earlier MIPS CPU, and you want to adapt it to the 74K core. So this document concentrates on where a MIPS 74K family core behaves differently from its predecessors. That’s either:

• Behavior which is not completely speciﬁed by Release 2 of the MIPS32® architecture: these either concern priv-

ileged operation, or are timing-related.

• Behavior which was standardized only in the recent Release 2 of the MIPS32 speciﬁcation (and not in previous

versions). All Release 2 features are formally documented in [MIPS32]1, and [MIPS32V1] describes the main

changes added by Release 2.

But the summary is too brief to program from, and the details are widely spread; so you’ll ﬁnd a reminder of the

changes here. Changes to user-privilege instructions are found in Appendix C, “MIPS® Architecture quick-

reference sheet(s)” on page 151, and changes to kernel-privilege (OS) instructions and facilities are detailed in

Chapter 5, “Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture” on page 67.

• Details of timing, relevant to engineers optimizing code (and that very small audience of compiler writers), found

in Section 4.5 “Tuning software for the 74K‘ family pipeline”.

This manual is distinct from the [SUM] reference manual: that is a CPU reference organized from a hardware viewpoint. If you need to write processor subsystem diagnostics, this manual will not be enough! If you want a very careful corner-cases-included delineation of exactly what an instruction does, you’ll need [MIPS32]... and so on.

For readability, some MIPS32 material is repeated here, particularly where a reference would involve a large excursion for the reader for a small saving for the author. Appendices mention every user-level-programming difference any active MIPS software engineer is likely to notice when programming the 74K core.

1. References (in square brackets) are listed in Appendix A, “References” on page 135.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 11

All 74K cores are able to run programs encoded with the MIPS16e™ instruction set extension - which makes the binary signiﬁcantly smaller, with some trade-off in performance. MIPS16e code is rarely seen - it’s almost exclusively produced by compilers, and in a debugger view is pretty much a subset of the regular MIPS32 instruction set so you’ll ﬁnd no further mention of it in this manual; please refer to [MIPS16e].

The document is arranged functionally: very approximately, the features are described in the order they’d come into play in a system as it bootstraps itself and prepares for business. But a lot of the CPU-speciﬁc data is presented in coprocessor zero (“CP0”) registers, so you’ll ﬁnd a cross-referenced list of 74K core CP0 registers in Appendix B, “CP0

1.1 Chapters of this manual

• Chapter 2, “Initialization and identity” on page 21: what happens from power-up? boot ROM material, but a

good place to cover how you recognize hardware options and conﬁgure software-controlled ones.

• Chapter 3, “Memory map, caching, reads, writes and translation” on page 29: everything about memory

accesses.

• Chapter 4, “Programming the 74K™ core in user mode” on page 55: features relevant to user-level program-

ming; instruction timing and tuning, hardware registers, prefetching.

1.1 Chapters of this manual

• Chapter 5, “Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture” on page 67: 74K-

core-speciﬁc information about privileged mode programming.

• Chapter 6, “Floating point unit” on page 77: the 74K core’s ﬂoating point unit, available on models called

74Kf™.

• Chapter 7, “The MIPS32® DSP ASE” on page 87: A brief summary of the MIPS DSP ASE (revision 2), avail-

able on members of the 74K core family.

• Chapter 8, “74K™ core features for debug and profiling” on page 102: the debug unit, performance counters and

watchpoints.

• Appendix A, “References” on page 135: more reading to broaden your knowledge.

• Appendix B, “CP0 register summary and reference” on page 137: all the registers, and references back into the

main text.

• Appendix C, “MIPS® Architecture quick-reference sheet(s)” on page 151: a few reference sheets, and some

notes on what was new in MIPS32 and its second release.

1.2 Conventions

Instruction mnemonics are in bold monospace; register names in small monospace. Register ﬁelds are shown after the register name in square brackets, so the interrupt enable bit in the status register appears as Status[IE].

CP0 register numbers are denoted by n.s, where “n” is the register number (between 0-31) and “s” is the “select” ﬁeld (0-7). If the select ﬁeld is omitted, it’s zero. A select ﬁeld of “x” denotes all eight potential select numbers.

In this book most registers are described in context, spread through various sections, so there are cross-referenced tables to help you ﬁnd speciﬁc registers. To ﬁnd a register by name, look in Table B.1, then look up the CP0 number

Programming the MIPS32® 74K™ Core Family, Revision 02.14 12

Introduction

in Table B.2 and you will ﬁnd a link to the register description (a hotlink if you’re reading on-screen, and a reference including page number if you’re reading paper).

Register diagrams in this book are found in the list of ﬁgures. Register ﬁelds may show a background color, coded to distinguish different types of ﬁelds:

read-write read-only reserved,

Numeric values below the ﬁeld diagram show the post-reset value for a ﬁeld which is reset to a known value.

1.3 74K™ core features

All 74K family cores conform to Release 2 of the MIPS32 architecture. You may have the following options:

• I- and D-Caches: 4-way set associative; I-cache may be 0 Kbytes, 16Kbytes, 32Kbytes or 64Kbytes in size. D-

cache may be 0 Kbytes, 16Kbytes, 32Kbytes or 64Kbytes in size. 32Kbyte caches are likely to be the most pop-

ular; 64Kbyte caches will involve some cost in frequency in most processes. The D-cache may even be entirely

omitted, when the system is ﬁtted with high-speed memory on the cache interface (scratchpad RAM or SPRAM:

see Section 3.6 “Scratchpad memory/SPRAM”.)

• The caches are virtually indexed but physically tagged (the D-cache also keeps a virtual tag which is used to save

a little time, but the ﬁnal hit/miss decision is always checked with the physical tag). Optionally (but usually) the

32K and 64K

which explains some software-visible effects. The option is selected when the “cache wrapper” was deﬁned for

the 74K core in your design and shows up as the Conﬁg7[AR] bit. L2 (secondary) cache: you can conﬁgure your

74K core with MIPS Technologies’ L2 cache between 128Kbyte and 1Mbyte in size. Full details are in “MIPS®

PDtrace™ Interface and Trace Control Block Specification”, MIPS Technologies document MD00439. Current

revision is 4.30: you need revision 4 or greater to get multithreading trace information. [L2CACHE], but pro-

gramming information is in Section 3.4 “Caches” of this manual.

D-cache conﬁgurations can be made free of cache aliases — see Section 3.4.9, "Cache aliases",

always zero

unused software-only write has

unusual effect.

• Fast multiplier: 1-per-clock repeat rate for 32×32 multiply and multiply/accumulate.

• DSP ASE: this instruction set extension adds a lot of new computational instructions with a ﬁxed-point math unit

crafted to speed up popular signal-processing algorithms, which form a large part of the computational load for

voice and imaging applications. Some of these functions do two math operations at once on two 16-bit values

held in one 32-bit register. 74K family cores support Revision 2 of the DSP ASE.

There’s a guide to the DSP ASE in Chapter 7, “The MIPS32® DSP ASE” on page 87 and the full manual is

[MIPSDSP].

• Floating point unit (FPU): if ﬁtted, this is a 64-bit unit (with 64-bit load/store operations), which most often runs

at half or two-thirds the clock rate of the integer unit (you can build the system to run the FPU at the same clock

rate as the integer core, but it will then limit the speed of the whole CPU).

• The “CorExtend®” instruction set extension: is available on all 74K CPUs. [CorExtend] deﬁnes a hardware

interface which makes it relatively straightforward to add logic to implement new computational (register-to-reg-

ister) instructions in your CPU, using predeﬁned instruction encodings. It’s matched by a set of software tools

2. Note that a 4-way set associative cache of 16Kbyte or less (assuming a 4Kbyte minimum page size) can’t suffer

from aliases.

13 Programming the MIPS32® 74K™ Core Family, Revision 02.14

1.4 A brief guide to the 74K™ core implementation

which allow users to create assembly language mnemonics and C macros for the new instructions. But there’s

very little about the CorExtend ASE in this manual.

1.4 A brief guide to the 74K™ core implementation

The 74K family is based around a long (14-19 stage) pipeline with dual issue, and executes instructions out-of-order to maintain progress around short-term dependencies. The longer pipeline allows for a higher frequency than can be reached by 24K® family cores (in a comparable process), and the more sophisticated instruction scheduling means that the 74K core also gets more work done per cycle.

Long-pipeline CPUs can trip up on dependencies (they need a result from a previous instruction), on branches (they don’t know where to fetch the next instructions until the branch instruction is substantially complete), and on loads (even on cache hits, the data cannot be available for some number of instructions). Earlier MIPS Technologies cores had no real trouble with dependencies (dependent instructions, in almost all cases, can run in consecutive cycles). That’s not so in the longer-pipeline 74K core, and its key trick to get around dependencies is out-of-order execution. But the techniques used to deal with branches and loads still include branch prediction, non-blocking loads and late writes — all familiar from MIPS Technologies’ 24K and 34K® core families.

Figure 1.1 Overview of The 74K™ Pipeline

74K pipeline stages

I-cache

IFU

speculative fetch

BHT

ID IS

IDU

issue

DR DS

reg ﬁle

completion buffers

ALU AGEN

out-of-order execution

EM EA

rename

map

D-cache

cache miss data updates

GRU

in-order

completion

memory pipeline

loads. stores, etc

external

read/write

read data

1.4.1 Notes on pipeline overview diagram (Figure 1.1):

Although this diagram is considerably simpler (and further abstracted from reality) than those in [SUM], there is still a lot to digest. Rectangles and circles with a thick outline are major functional units — the rectangles are the active

Programming the MIPS32® 74K™ Core Family, Revision 02.14 14

Introduction

units and each has a phrase (in italics) summarizing what it does. The three-letter acronyms match those found in the detailed descriptions, and the pipeline stage names used in the detailed descriptions are across the top. Tosimplify the picture the integer multiply unit and the (optional) ﬂoating point unit have been omitted — once you ﬁgure out what’s going on, they shouldn’t be too hard to put back. So:

• The 74K core’s instruction fetch unit (“IFU”) is semi-autonomous. It’s 128 bits wide, and handles four instruc-

• Issue: the IDU (“instruction decode/dispatch unit”) keeps its own queue of instructions and tries to ﬁnd two of

tions at a bite.

The IFU works a bit like a dog being taken for a walk. It rushes on ahead as long as the lead will stretch (the IFU,

processing instructions four at a time, can rapidly get ahead). Even though you’re in charge, your dog likes to go

ﬁrst - and so it is with the IFU. Like a dog, the IFU guesses where you want to go, strongly inﬂuenced by the way

you usually go. If you make an unexpected turn there is a brief hiatus while the dog comes back and gets up front

again.

The IFU has a queue to keep instructions in when it’s running ahead of the rest of the CPU. This kind of design is

called a “decoupled” IFU.

them which can be issued in parallel. The instruction set is strictly divided into AGEN instructions (loads, stores,

prefetch, cacheops; conditional moves, branches and jumps) and ALU (everything else). If all else is good, the

IDU can issue one instruction of each type in every cycle. Instructions are marked with their place in the program

sequence, but are not necessarily issued in order. An instruction may leapfrog ahead of program order in the

IDU’s queue, if all the data it needs is ready (or at least will be ready by the time it’s needed).

Instructions which execute ahead of time can’t write data to real registers — that would disrupt the operation of

their program predecessors, which might execute later. It may turn out that such an instruction shouldn’t haverun

at all if there was a mispredicted branch, or an earlier-in-program-order instruction took an exception. Instead,

each instruction is assigned a completion buffer (CB) entry to receive its result. The CB entry also keeps informa-

tion about the instruction and where it came from. An instruction which is dependent on this one for a source reg-

ister value but runs soon afterward can get its data from the CB. CB-resident values can be found through the

rename map; that map is indexed by register number and points to the CB reserved by the instruction which will

write or has written a register value.

• out-of-orderexecution:theeffectoftheaboveisthatinstructions are issued in “dataﬂow” order,asdeterminedby

their dependencies on register values produced by other instructions. Up to 32 instructions can be somewhere

between available for issue and completed in the 74K core — those instructions are often said to be in ﬂight. The

32 possible instructions correspond to 32 CB entries — 14 for AGEN instructions, 18 for ALU instructions.

Inside the “execution” box the AGEN and ALU instructions proceed strictly through two internally-pipelined

units of the same names. The two pipelines are in lockstep, and are kept that way. This sounds rigid, but is help-

ful. When the IDU issues an instruction, it does not have to know that an instruction’s data is ready “right now”:

it’s enough that the instruction producing that data is far enough along either execution pipeline. When no other

progress can be made its probably best to think of the IDU issuing a “no-op” or “bubble” into either or both pipe-

lines.

Most of the time the execution pipelines just keep running — the IDU tries to detect any reason why an instruc-

tion cannot run through either the AGEN or ALU pipe.When dependent instructions run close together, the data

doesn’t have time to go into a register or CB entry and be read out again. Instead it can ﬂow down a dedicated

bypass connection between two particular pipestages — a routine trick used in pipelined logic. In the 74K core

there are bypasses interconnecting the AGEN and ALU pipelines, as well as within each pipeline. But whereas

pipeline multiplexing in a conventional design is controlled by comparing register numbers, in 74K cores we

compare completion buffer entry IDs.

15 Programming the MIPS32® 74K™ Core Family, Revision 02.14

1.4 A brief guide to the 74K™ core implementation

There are a few simple instructions where the ALU produces its results in one clock (they’re listed in Table 4.3),

but most ALU instructions require two clocks: so, in the 74K core, dependent ALU instructions cannot usually

be run back-to-back. This would have a catastrophic effect on the performance of an in-order CPU, because

many instructions are dependent on their immediate predecessor. But an out-of-order CPU will run just ﬁne,

because there are also a reasonable number of cases where an instruction is not dependent on its immediate pre-

decessor, so the pipeline can ﬁnd something to run. The CPU will slow down if fed with a sequence of relatively

long-latency instructions each of which is dependent on its predecessor, of course. For example, in the AGEN

pipeline it takes four cycles to turn a load address into load data (assuming a cache hit). So chasing a chain of

pointers through memory will take at least four cycles per pointer.

• Optimistic issue: any instruction which is issued may yet not run to completion (there might be an exception on

an earlier-in-program instruction, for example). But some instructions are issued even though they are directly

dependent on something we’renot sure about — they’reissued optimistically. The most common example is that

instructions dependent on load data are issued as if we were conﬁdent the load will hit in the L1 cache.

Sometimes it turns out we were wrong. Notably, sometimes the load we’re dependent on suffers a cache miss. In

this case the hardware does the simplest thing: rather than attempt to single out the now unviable instruction, we

take a redirect on the load-value-consuming instruction we issued optimistically — that is, we discard all work

on that instruction and its successors, and ask the front end of the pipeline to start again from scratch, re-fetching

the instruction from the I-cache.

• In-order completion: at the end of the execution unit we take the oldest in-ﬂight instruction (with luck, the sec-

ond-oldest too) and, if it’s results are ready, we graduate3one or two instructions (“GRU” stands for “graduation

unit”). Before we do that, we make a last minute check for exceptions: if one of the proposed graduates has

encountered a condition which should cause an exception it will be carrying that information with it, we discard

that instruction and do a redirect to the start of the appropriate exception handler. On successful graduation the

instruction’s results are copied from its CB entry back to a real CPU register, and it’s ﬁnished.

Because instruction effects aren’t “publicly” visible until graduation, our out-of-order CPU appears to the pro-

grammer to be running sequentially just like any other MIPS32-compliant CPU.

More details about out-of-order execution

That’s the basic ﬂow. But the dual-issue, out-of-order design has some subtle points which can affect how programs run:

• Mispredicted branches and redirects: because of the long pipeline, the 74K core relies very heavily on good

branch prediction. When the IFU guesses wrong about a conditional branch, or can’t compute the target for a

jump-register instruction, that’s detected somewhere down the AGEN pipeline (usually the “EC” stage). By then

we’ll have done a minimum of 12 cycles of work on the wrong path.

Whenever a branch is resolved the prediction result is sent back to the IFU to maintain its history table. For most

branches, the prediction result is sent back at the same time as we resolve the branch, which means that a few

branches which don’t graduate can affect the branch history. That’s OK, it was only a heuristic.

• Exceptions: can’t be resolved until we’re committed to running an instruction and have completed all its prede-

cessors. So they’re resolved only at graduation. That posts an exception handler address down to the front of a

pipe, clearing out all prefetched and speculatively-executed instructions in the process. There will be at least 19

3. Curiously,the alternative word to “graduation” (for an instruction being committed in an out-of-order design) is“retirement”: a rather different stage of one’s career. I guess that from a software point of view we’reglad that the instruction is now grown up and real, while the hardware is now ready to wave goodbye to it.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 16

Introduction

• Loads and Stores: the L1 cache lookup happens inside the out-of-order execution pipeline. But only loads which

cycles between the point where the exception is processed in the graduation unit and the time when the ﬁrst instruction of the exception handler graduates.

hit in the L1 cache are complete when they graduate. Other loads and stores graduate and then start actions in the memory pipeline. It’s probably fairly obvious how a store can be “stored” — so long as the hardware keeps a note of the address and data of the store, the cache/memory update can be done later. On the 74K core, even a write into the L1 cache is deferred until after graduation. While the write is pending, the cache hardware has to keep a note in case some later instruction wants to load the same value before we’ve completed the write; but that’s familiar technology.

It’s less obvious that we can allow load instructions which L1-miss to graduate. But on the 74K core, loads are non-blocking — a load executes, and results in data being loaded into a GP register at some time in the future. Any later instruction which reads the register value must wait until the load data has arrived. So load instructions are allowed to graduate regardless of how far away their data is. Once the instruction graduates its CB entry must be given back, so data arriving for a graduated load is sent directly to the register ﬁle.

There’s another key reason why we did this: with only L1 accesses done out-of-order, loads and stores only become visible outside the CPU after they graduate, so there’s no worry about other parts of the system seeing unexpected effects from speculative instructions.

An instruction which depends on a load which misses will (unless it was a long, long way behind in instruction sequence) have to wait. Most often the consuming instruction will become a candidate for issue before we know whether the load hit in the L1 cache. In this case the dependent instruction is issued: we’re optimists, hoping for a hit. If a consuming instruction reaches graduation and ﬁnds the load missed, we must do a “redirect”, re-fetching the consuming instruction and everything later in program order). Next time the consuming instruction is an issue candidate, we’ll know the load has missed, and the consumer will not get issued until the load data has arrived. The redirect for the consuming instruction is quite expensive (19 or more cycles), but in most cases that overhead will be hidden in the time taken to return data for the cache miss.

Stores are less complicated. But since even the cache must not be updated until the store instruction graduates, the memory pipeline is used for writing the L1 cache too: even store L1-hits result in action in the memory pipeline.

1.4.2 Branches and branch delays

The MIPS architecture deﬁnes that the instruction following a branch (the “branch delay slot” instruction) is always executed4. That means that the CPU has one instruction it knows will be executed while it’s ﬁguring out where a

branch is going. But with the 74K core’s long pipeline we don’t ﬁnally know whether a conditional branch should be taken, and won’t have computed the target address for a jump-register,until about 8 stages down the pipeline. It’s better to guess (and pay the price when we’re wrong) than to wait to be certain. Several different tricks are used:

• The decoupled IFU (the electronic dog) runs ahead of the rest of the CPU by fetching four instructions per clock.

• Branch instructions are identiﬁed very early (in fact, they’re marked when instructions are fetched into the I–

cache). MIPS branch and jump instructions (at least those not dependent on register values) are easy to decode, and the IFU decodes them locally to calculate the target address.

4. That’s not quite accurate: there are special forms of conditional branches called “branch likely” which are deﬁned to execute the branch delay slot instruction only when the branch is taken. Note that the “likely” part of the name has nothing to do with branch prediction; the 74K core’s branch prediction system treats the “likelies” just like any other branches. The dependency between a branch condition and the branch delay slot instruction is annoying to keep track of in an out-of-order machine, and MIPS would prefer you not to use branch-likely instructions.

17 Programming the MIPS32® 74K™ Core Family, Revision 02.14

1.4 A brief guide to the 74K™ core implementation

The IFU’s branch predictor guesses whether conditional branches will be taken or not - it’s not magic, it uses a BHT (a “Branch History Table”) of what happened to branches in the past, indexed by the low bits of the loca- tion of the branch instruction. This particular hardware is an example of Combined branch prediction (majority voting between three different algorithms, one of which is gshare; if you want to know, there’s a good wikipedia article whose topic name is “Branch Predictor”). The branch predictor is taking a good guess. It can seem surprising that the predictor makes no attempt to discover whether the history stored in a BHT slot is really that of the current branch, or another one which happened to share the same low address bits; we’re going to be wrong sometimes. It guesses correctly most of the time.

In this way the IFU can predict the next-instruction address and continue to run ahead.

• When the IFU guesses wrong, it doesn’t know (the dog just rushes ahead until its owner reaches the fork). The

branch mispredict will be noticed once the branch instruction has been issued and carried through to the AGEN “EC” stage, and is executed in its full context (“resolved”). On detecting a mispredict, the CPU must discard the instructions based on the bad guess (which will not have graduated yet, so will not have changed any vital

machine state) and start fetching instructions from the correct target5. The exact penalty paid by a program which suffers a mispredict depends on how busy the execution unit is, and how early it resolves the branch; the minimum penalty is 12 cycles.

• Even when we guess right, the branch target calculation in the IFU takes a little while to operate. A rapid

sequence of correctly-predicted branches can empty the queues, causing a program to run slower.

• Jump-register instruction targets are unpredictable: the IFU has no knowledge of register data and can’t in gen-

eral anticipate it. But jump-register instructions are relatively rare, except for subroutine returns. In the MIPS ISA you return from subroutines using a jump-register instruction, jr $31 (register 31 is, by a strong convention, used to hold the return address). So on every call instruction, the IFU pushes the return address onto a small

stack; and on every jr $31 it pops the value of the stack and uses that as its guess for the branch target6. We have no way of knowing the target of a jr instruction which uses a register other than $31. When we ﬁnd

one of those, instruction fetch stops until the correct address is computed up in the AGEN pipeline, 12 or more clocks later.

1.4.3 Loads and load-to-use delays

Even short-pipeline MIPS CPUs can’t deliver load data to the immediately following instruction without a delay, even on a cache hit. Simple MIPS pipelines typically deliver the data one clock later: a one clock “load-to-use delay”. Compilers and programmers try to put some useful and non-dependent operation between the load and its ﬁrst use.

The 74K core’s long pipeline means that a full D-cache hit takes four clocks to return the data, not two: that would be a three-clock “load-to-use delay”. A pair of loads dependent on each other (one fetches the other’s base address) must be issued at least four cycles apart (that’s optimistic, hoping-for-a-hit timing).

But the AGEN and ALU pipelines are “skewed”, with ALU results delivered a cycle later than AGEN results. That means that when an ALU operation is dependent on a load, it can be issued only three cycles after the load. There’s a price to pay: a load/store whose base address is computed by a preceding ALU instruction must be issued a clock

5. In “branch-likely” variants of conditional branch instructions a mispredict means we also did the wrong thing with the instruction in the branch delay slot. To ﬁx that up, we need to refetch the branch itself, so the penalty is at least one cycle higher.

6. The return-stack guess will be wrong for subroutines containing nested calls deeper than the size of the return stack; but subroutines high up the call tree are much more rarely executed, so this isn’t so bad.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 18

Introduction

later than an ALU instruction with the same dependency — that’s usually a three cycle delay, because most ALU operations already take an extra clock to produce their result.

It’s like the skewed pipeline which experts in MIPS Technologies’ 24K® family might remember, and has the same motivation: ALU operations dependent on recent loads are more common than loads dependent on recent ALU operations.

1.4.4 Queues, Resource limits and Consequences

Queues which can ﬁll up include:

• Cache reﬁlls in ﬂight: Is dependent on the size of the “FSB” queue - this and other queues are described in more

detail under Section 3.3, "Reads, writes and synchronization". The CPU does not wait for a cache reﬁll process — at least not until it needs data from the cache miss. But in practice most load data is used almost at once, so the CPU will stop very soon after a miss. As a result, you’re unlikely to ever have four reﬁlls in ﬂight unless you are using prefetch or otherwise deliberately optimizing loops. If a series of aggressive prefetches miss often enough, the fourth outstanding load-miss will use the last FSB entry, preventing further loads from graduating and eventually blocking up the whole CPU until the load data returns. It’s likely to be good practice for code making conscious use of prefetches to ration itself to a number of operations slightly less than the size of the FSB.

• Non-blocking loads to registers (nine): there are nine entries in the “LDQ”, each of which remembers one out-

standing load, and which register the data is destined to return to. Compiled code is unlikely to reach this limit. If you write carefully optimized code where you try to ﬁll load-use delays (perhaps for data you think will not hit in the D-cache) you may hit this problem.

• Lines evicted from the cache awaiting writeback (4+): writes are collected in the “WBB” queue. The 74K core’s

ability to write data will in almost all circumstances exceed the bandwidth available to memory; so a long enough burst of uncached or write-through writes will eventually slow to memory speed. Otherwise, you’re unlikely to suffer from this.

• Queues in the coprocessor interface: the 74K core hides its out-of-order character from any coprocessors, so

coprocessor hardware need be no more complicated than it is for MIPS Technologies’24Kcore. The coprocessor hardware sees its instructions strictly in order. Each coprocessor instruction also makes its own way through the integer execution unit. Between the execution unit and coprocessor there are some queues which can ﬁll up:

• IOIQ (8 entries): instructions being issued — strictly in program order — to a coprocessor.

• CBIDQ (8 entries): data being returned from a coprocessor by an instruction which writes a GP register. But prior to graduation the data goes back to a completion buffer (hence the queue acronym).

• CLDQ (8 entries): track data being loaded to coprocessor registers (the job done for the GPRs by the LDQ above). CLDQ data isn’t necessarily provided in instruction sequence: in particular MIPS Technologies ﬂoating-point unit accepts FP load data as and when it arrives, making FP loads non-blocking.

The dispatch process stalls (ﬂooding the ALU and AGEN pipes with bubbles) when there is no space in any of these queues.

19 Programming the MIPS32® 74K™ Core Family, Revision 02.14

1.4 A brief guide to the 74K™ core implementation

Programming the MIPS32® 74K™ Core Family, Revision 02.14 20

Chapter 2

Initialization and identity

What happens when the CPU is ﬁrst powered up? These functions are perhaps more often associated with a ROM monitor than an OS.

2.1 Probing your CPU - Conﬁg CP0 registers

The four registers Conﬁg and Conﬁg1-3 are 32-bit CP0 registers which contain information about the CPU’s capabilities. Conﬁg1-3 are strictly read-only. The few writable ﬁelds in Conﬁg — notably Conﬁg[K0] — are there for historic compatibility, and are typically written once soon after bootstrap and never changed again.

The 74K core also deﬁnes Conﬁg7 for some implementation-speciﬁc settings (which most programmers will never use).

Broadly speaking the registers have these roles:

Table 2.1 Roles of Conﬁg registers

Conﬁg A mix of historical and CPU-dependent information, described in Figure 2.1 below. Some

ﬁelds are writable.

Conﬁg1 Read-only, strictly totheMIPS32architecture. Conﬁg1 shows the primary cache conﬁguration Conﬁg2

Conﬁg3 Read-only, strictly to Release 2 of the [MIPS32] architecture.

Conﬁg6 Provides information about the presence of optional extensions to the base MIPS32 architec-

Conﬁg7 74K-core-speciﬁc, with both read-only and writable ﬁelds. It’s a strong convention that the

and basic CPU capabilities, while Conﬁg2showsinformationaboutL2 and L3 caches, if ﬁtted (the L2 and the L3 cache is unavailable in 74K family cores). Shown in Figure 2.2 and Figure

2.3 below.

More CPU capability information.

ture in addition to those speciﬁed in Conﬁg2 and Conﬁg3.

writable ﬁelds should default to “expected” behavior, so beginners may simply leave these ﬁelds alone. The ﬁelds are described later, in Section B.2.1 “The Config7 register”.

While initializing your CPU, you might also want to look at the EBase register, which can be used to relocate your exception entry points: see Figure 5.2 and the text round it.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 21

2.1 Probing your CPU - Config CP0 registers

2.1.1 The Conﬁg register

Figure 2.1 Fields in the Conﬁg Register

31 30 28 27 25 24 23 22 21 20 19 18 17 16 15 14 13 12 10 9 7 6 4 3 2 0

M K23 KU ISP DSP UDI SB 0 WC MM 0 BM BE AT AR MT 0 VI K0

12 2 01 0 1 02

In Figure 2.1:

M: reads 1 if Conﬁg1 is available (it always is).

K23, KU, K0: set the cacheability attributes of chunks of the memory map by writing these fields. All share a 3-bit

encoding with the cacheability ﬁeld found in TLB entries, which is described in Table 3.3 in Section

3.4.2 “Cacheability options”.

Conﬁg[K0] sets the cacheability of kseg0, but it would be very unusual to make that anything other than cacheable

(on different, cache-coherent CPUs, it may want to be set to cacheable-coherent). The power-on value of this standard ﬁeld is not mandated by the [MIPS32] architecture; but the 74K core follows the recommendation to set it to "2", making "kseg0" uncached. That can be surprising; early system initialization software typically re-writes it to "3" in order that kseg0 will be cached, as expected.

If your

74K core-based system uses fixed mapping instead of having a TLB, Conﬁg[K23] is for program addresses

0xC000.0000-0xFFFF.FFFF (the “kseg2” and “kseg3” areas), while Conﬁg[KU] is for program addresses 0x0000.0000-0x7FFF.FFFF (the “kuseg” area). If you have a TLB, these regions are mapped and these ﬁelds are unused (write only zeroes to them).

ISP, DSP: read 1 if I-side and/or D-side scratchpad (SPRAM) is ﬁtted, see Section 3.6, "Scratchpad memory/

SPRAM".

(Don’t confuse this with the MIPS DSP ASE, whose presence is indicated by Conﬁg3[DDSP].)

UDI: reads 1 if your core implements user-deﬁned "CorExtend" instructions. “CorExtend” is available on cores whose

name ends in "Pro".

SB: read-only "SimpleBE" bus mode indicator. If set, means that this core will only do simple partial-word transfers on

its OCP interface; that is, the only partial-word transfers will be byte, aligned half-word and aligned word.

If zero, it may generate partial-word transfers with an arbitrary set of bytes enabled (which some memory controllers may not like).

WC: Warning: this is a diagnostic/test ﬁeld, not intended for customer use, and may vanish without notice from a

future version of the core. Set this 1 to make the Conﬁg1[IS] and Conﬁg1[DS] ﬁelds writable, which allows you to reduce the number of avail-

able L1 I- and D-cache ``sets per way'', and shrink the usable cache size. You'd never want to do this in a real system, but it is conceivable it might be useful for debug or performance analysis. If you have an L2 cache conﬁgured, then this makes Conﬁg2[SS] writable in the same way.

MM: writable: set 1 if you want writes resulting from separate store instructions in write-through mode merged into a

single (possibly burst) transaction at the interface. This has no affect on cache writebacks (which are always whole blocks together) or uncached writes (which are never merged).

Programming the MIPS32® 74K™ Core Family, Revision 02.14 22

Initialization and identity

BM: read-only - tells you whether your bus uses sequential or sub-block burst order; set by hardware to match your sys-

tem controller.

BE: reads 1 for big-endian, 0 for little-endian. AT: MIPS32 or MIPS64 compliance On 74K family cores it will read “0”, but the possible values are:

0 MIPS32 1 MIPS64 instruction set but MIPS32 address map 2 MIPS64 instruction set with full address map

AR: Architecture revision level. On 74K family cores it will read “1”, denoting release 2 of the MIPS32 specification.

0 MIPS32/MIPS64 Release 1 1 MIPS32/MIPS64 Release 2

MT: MMU type (all MIPS Technologies cores may be conﬁgured as type 1 or 3):

0 None 1 MIPS32/64 compliant TLB 2 “BAT” type 3 MIPS-standard ﬁxed mapping

VI: 1 if the L1 I-cache is virtual (both indexed and tagged using virtual address). No contemporary MIPS Technologies

core has a virtual I-cache.

K0: as described in the notes above on Conﬁg[K23] etc, this ﬁeld determines the cacheing behaviour of the ﬁxed kseg0

memory region .

2.1.2 The Conﬁg1-2 registers

These two read-only registers tell you the size of the TLB, and the size and organization of L1, L2 and L3 caches (a zero “line size” is used to indicate a cache which isn’t there). They’re best described together.

Conﬁg1 has some ﬁelds which tell you about the presence of some of the older extensions to the base MIPS32 archi-

tecture are implemented on this core. These bits ran out, and other extensions are noted in Conﬁg3.

Figure 2.2 Fields in the Conﬁg1 Register

31 30 25 24 22 21 19 18 16 15 13 12 10 9 7 6 5 4 3 2 1 0

M MMUSize IS IL IA DS DL DA C2 MD PC WR CA EP FP

1434301111

Figure 2.3 Fields in the Conﬁg2 Register

31 30 28 27 24 23 20 19 16 15 13 12 11 8 7 4 3 0

M TU TS TL TA SU L2B SS SL SA

10 0 0 0 0 0

Conﬁg1[M]: continuation bit, 1 if Conﬁg2 is implemented.

23 Programming the MIPS32® 74K™ Core Family, Revision 02.14

2.1 Probing your CPU - Config CP0 registers

Conﬁg1[MMUSize]: the size of the TLB array (the array has MMUSize+1 entries). Conﬁg1[IS,IL,IA,DS,DL,DA]: for each cache this reports

Number of sets per way. Calculate as: 64 × 2

Line size. Zero means no cache at all, otherwise calculate as: 2 × 2

A Associativity/number of ways - calculate as A + 1

So if (IS, IL, IA) is (2,4,3) you have 256 sets/way, 32 bytes per line and 4-way set associative: that’s a 32Kbyte cache.

Conﬁg1[C2,FP]: 1 if coprocessor 2 or or an FPU (coprocessor 1) ﬁtted, respectively. A coprocessor 2 would be a cus-

tomer-designed coprocessor.

Conﬁg1[MD]: 1 if MDMX ASE is implemented in the ﬂoating point unit (very unlikely for the 74K core). Conﬁg1[PC]: there is at least one performance counter implemented, see Section 8.4, "Performance counters". Conﬁg1[WR]: reads 1 because the 74K core always has watchpoint registers, see Section 8.3, "CP0 Watchpoints". Conﬁg1[CA]: reads 1 because the MIPS16e compressed-code instruction set is available (as it generally is on MIPS

Technologies cores).

Conﬁg1[EP]: reads 1 because an EJTAG debug unit is always provided, see Section 8.1, "EJTAG on-chip debug unit". Conﬁg2[M]: continuation bit, 1 if Conﬁg3 is implemented. Conﬁg2[TU]: implementation-speciﬁc bits related to tertiary cache, if ﬁtted. Can be writable. Conﬁg2[TS,TL,TA]: tertiary cache size and shape - encoded just like Conﬁg1[IS,IL,IA] which see above. Conﬁg2[SU]: implementation-speciﬁc bits for secondary cache, if ﬁtted. Can be writable. Conﬁg2[L2B]: Set to disable L2 cache (“bypass mode”). Setting this bit also forces Conﬁg2[SL] to 0 — most OS code

will conclude that there isn't an L2 cache on the system, which can be useful.

Writing this bit controls a signal out to the L2 cache hardware. However, reading it does not read back what you just wrote: it reﬂects the value of a signal sent back from the L2 cache. With MIPS Technologies' L2 cache logic, that feedback signal will reﬂect the value you just wrote, with some implementation-dependent delay (it's unlikely to be 100 cycles, but it could easily be more than 10). For more details refer to “MIPS® PDtrace™ Interface and Trace

Control Block Specification”, MIPS Technologies document MD00439. Current revision is 4.30: you need revision 4 or greater to get multithreading trace information. [L2CACHE].

Conﬁg2[SS,SL,SA]: secondary cache size and shape, encoded like Conﬁg1[IS,IL,IA] above.

2.1.3 The Conﬁg3 register

Conﬁg3 provides information about the presence of optional extensions to the base MIPS32 architecture. A few of

them were in Conﬁg2, but that ran out of bits.

Figure 2.4 Conﬁg3 Register Format

31 30 29 28 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

M 0 CMGCR ULRI 0 DSP2P DSPP

CTXTC

0 VEIC VInt SP

CDMM

MT SM TL

Programming the MIPS32® 74K™ Core Family, Revision 02.14 24

Initialization and identity

31 30 29 28 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

011100

Fields shown in Figure 2.4 include:

Conﬁg3[M]: continuation bit which is zero, because there is no Conﬁg4. Conﬁg3[CMCGR]: reads 1 if Global Control Register in the Coherence Manager are implemented and the

CMGCRBase register is present. Reads 0 otherwise Config3[ULRI]: reads 1 if the core implements the UserLocal register, typically used by software threads packages. DSP2P, DSPP: DSPP reads 1 if the MIPS DSP extension is implemented — as described in Chapter 7, “The

MIPS32® DSP ASE” on page 87. If so, DSP2P reads 1 if your CPU conforms to revision 2 of the DSP ASE — as

the 74K core does.

CTXTC: reads 1 when the ContextConﬁg register is implemented. The width of the BadVPN2 ﬁeld in the Context

VEIC: read-only bit from the core input signal SI_EICPresent which should be set in the SoC to alert software to the

availability of an EIC-compatible interrupt controller, see Section 5.2, "MIPS32® Architecture Release 2 - enhanced

interrupt system(s)".

VInt: reads 1 when the 74K core can handle vectored interrupts. SP: reads 0 when the 74K core does not support sub-4Kbyte page sizes. CDMM: reads 0 when the 74K core does not support the Common Device Memory Map. SM: reads 0, the 74K core does not handle instructions from the "SmartMIPS" ASE. TL: reads 1 if your core is conﬁgured to do instruction trace.

2.1.4 The Conﬁg6 register

Conﬁg3 provides information about the presence of optional extensions to the base MIPS32 architecture in addition to

those speciﬁed in Conﬁg2 and Conﬁg3.

Figure 2.5 Conﬁg6 Register Format

31 15 14 13 12 10 9 8 7 2 1 0

0 SPCD SYND

SPCD disables performance counter clock shutdown. The primary use of this bit is to keep performance counters

alive when the core is in sleep mode.

SYND disables Synonym tag update. By default, all synonym load misses will opportunistically update the tag so

that subsequent loads will hit at lookup.

IFUPerfCtl NMRUP

NMRUD 0

JRCP JRCD

IFUPerfCtl encodes IFU events that provide debug and performance information for the IFU pipeline.

NMRUP indicates that a Not Most Recently Used JTLB replacement scheme is present.

25 Programming the MIPS32® 74K™ Core Family, Revision 02.14

2.2 PRId register — identifying your CPU type

NMRUD disables the Most Recently Used JTLB replacement scheme bit.

JRCP indicates that a JR Cache is implemented.

JRCD indicates that JR Cache Prediction is enabled.

2.1.5 CPU-speciﬁc conﬁguration — Conﬁg7

Conﬁg7 is packed with implementation-speciﬁc ﬁelds. Most of the time, you leave them alone (a few of them might

sometimes need to be set as required by your SoC designer). So we’ve left these registers deﬁned in the all-CP0

appendix, in Section B.2.1 “The Config7 register”.

2.2 PRId register — identifying your CPU type

This register identiﬁes the CPU to software. It’s appropriately printed as part of the start-up display by any software

telling the world about the CPU on start-up; but when portable software is conﬁguring itself around different CPU

attributes, it’s always preferable to sense those attributes directly — look in other Conﬁg registers, or perhaps use a

directed software probe.

Figure 2.6 Fields in the PRId Register

31 24 23 16 15 8 7 5 4 2 1 0

CoOpt CoID Imp

Major Minor Patch

1 0x97

Rev

PRId[CoOpt]: Whatever is speciﬁed by the SoC builder who synthesizes the core — refer to your SoC manual. It

should be a number between 0 and 127 — higher values are reserved by MIPS Technologies.

PRId[CoID]: Company ID, which in this case is “1” for MIPS Technologies Inc.: PRId[Imp]: Identiﬁes the particular processor, which in this case is 0x97 for the 74K family. Any processor with differ-

ent CP0 features must have a new PRId ﬁeld.

PRId[Rev]: The revision number of the core design, used to index entries in errata lists etc. By MIPS Technologies’

convention the revision ﬁeld is divided into three subﬁelds: a major and minor number; with a nonzero "patch" revi-

sion number is for a release with no functional change. Core licensees can consult [ERRATA] for authoritative infor-

mation about the revision IDs associated with releases of the 74K core.

The following incomplete and not up-to-date table of historical revisions is provided as a guide to program-

mers who don’t have [ERRATA] on hand:

Table 2.2 74K™® core releases and PRId[Revision] ﬁelds

Release

Identiﬁer

2_0_* 1.0.0 / 0x20 First (GA) release of the 34K core September 30, 2005 2_1_* 2.1.0 / 0x44 MR1 release. Bug ﬁxes, 8KB cache support. March 10, 2006

Programming the MIPS32® 74K™ Core Family, Revision 02.14 26

PRId[Revision]

Maj.min.patch/hex Description Date

Initialization and identity

2_2_0 2.2.0 / 0x48 Allow up to 9 TCs, alias-free 64KB L1 D-cache option. August 31, 2006 2_2_1 2.2.1 / 0x49 Enable use of MIPS SOC-it® L2 Cache Controller. October 12, 2006 2_3_* 2.3.0 / 0x4c Less interlocks round cache instructions, relocatable

2_4_* 2.4.0 / 0x50 New UserLocal register,alias-proofI-cache hit-invalidate

2_5_* 2.5.0/0x54 Errata ﬁxes January, 2009 1_1_* 1.1.0/0x24 Errata ﬁxes January, 2009 1_2_* 1.2.0/0x28 Feature updates: improved low power support, fast debug

2_0_* 2.0.0 / 0x40 General availability of 24K core. March 19, 2004 3_0_* 3.0.0 / 0x60 COP2 option improvements. September 30, 2004 3_2_* 3.2.0 / 0x68 PDtrace available. March 18, 2005 3_4_* 3.4.0 / 0x6c ISPRAM (I-side scratchpad) option added June 30, 2005 3_5_* 3.5.0 / 0x74 8KB cache option December 30, 2005 3_6_* 3.6.0 / 0x78 L2 support., 64KB alias-free D-cache option, option to

3_7_* 3.7.0 / 0x7c Less interlocks round cache instructions, relocatable

4_0_* 4.0.0 / 0x80 New UserLocal register,alias-proofI-cache hit-invalidate

4_1_* 4.1.0/0x84 Errata ﬁxes January, 2009 2_0_* 2.0.0 / 0x40 General availability of 24KE core. June 30, 2005 2_1_* 2.1.0 / 0x44 8KB cache option December 30, 2005 2_2_* 2.2.0 / 0x48 L2 support., 64KB alias-free D-cache option, option to

2_3_* 2.3.0 / 0x4c Less interlocks round cache instructions, relocatable

2_4_* 2.4.0 / 0x50 New UserLocal register,alias-proofI-cache hit-invalidate

2_5_0 2.5.0/0x54 Errata ﬁxes January, 2009

1_0_* 1.0.0 / 0x20 Early-access release of 74K family RTL. January 31, 2007 2_0_0* 2.0.0 / 0x40 First generally-available release of 74K family core. May 11, 2007 2_1_0* 2.1.0 / 0x44 Can wait with interrupts disabled. October 31, 2007

Table 2.2 74K™® core releases and PRId[Revision] ﬁelds

January 3, 2007

reset exception vector location.

October 31, 2007 operation, can wait with interrupts disabled, per-TC performance counters.

July, 2009 channel, on-chip PDtrace buffers

July 12, 2006 haveupto 8 outstanding cache misses(previousmaximum

4).

January 3, 2007 reset exception vector location.

October 31, 2007 operation, can wait with interrupts disabled.

July 12, 2006 haveupto 8 outstanding cache misses(previousmaximum

4).

January 3, 2007 reset exception vector location.

October 31, 2007 operation, can wait with interrupts disabled.

27 Programming the MIPS32® 74K™ Core Family, Revision 02.14

2.2 PRId register — identifying your CPU type

Programming the MIPS32® 74K™ Core Family, Revision 02.14 28

Chapter 3

Memory map, caching, reads, writes and translation

In this chapter:

• Section 3.1, "The memory map": basic memory map of the system.

• Section 3.3, "Reads, writes and synchronization"

• Section 3.4, "Caches"

• Section 3.6, "Scratchpad memory/SPRAM": optional on-chip, high-speed memory (particularly useful when dual-ported to the OCP interface).

• Section 3.8, "The TLB and translation": how translation is done and supporting CP0 registers.

3.1 The memory map

A 74K core system can be conﬁgured with either a TLB (virtual memory translation unit) or a ﬁxed memory mapping.

A TLB-equipped sees the memory map described by the [MIPS32] architecture (which will be familiar to anyone who has used a 32-bit MIPS architecture CPU) and is summarized in Table 3.1. The TLB gives you access to a full 32-bit physical address on the system interface. More information about the TLB in Section 3.8, "The TLB and

translation".

Table 3.1 Basic MIPS32® architecture memory map

Segment Virtual range What happens to accesses here?

Name

kuseg 0x0000.0000-0x7FFF.FFFF The only region accessible to user-privilege programs.

Mapped by TLB entries.

kseg0 0x8000.0000-0x9FFF.FFFF a ﬁxed-mapping window onto physical addresses

0x0000.0000-0x1FFF.FFFF. Almost invariably cacheable - but in fact other choices are available, and are selected by Conﬁg[K0], see Figure 2.1. Accessible only to kernel-privilege programs.

kseg1 0xA000.0000-0xBFFF.FFFF a ﬁxed-mapping window onto the same physical

address range 0x0000.0000-0x1FFF.FFFF as “kseg0”

- but accesses here are uncached. Accessible only to kernel-privilege programs.

kseg2 0xC000.0000-0xDFFF.FFFF Mapped through TLB, accessible with supervisor or

sseg

kseg3 0xE000.0000-0xFFFF.FFFF Mapped through TLB, accessible only with kernel

kernel privilege (hence the alternate name).

privileges.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 29

3.2 Fixed mapping option

With the ﬁxed mapping option, virtual address ranges are hard-wired to particular physical address windows, and cacheability options are set through CP0 register ﬁelds as summarized in Table 3.2:

Table 3.2 Fixed memory mapping

Segment Virtual range Physical range Cacheability

Name bits from

kuseg 0x0000.0000-0x7FFF.FFFF 0x4000.0000-0xBFFF.FFFF Conﬁg[KU] kseg0 0x8000.0000-0x9FFF.FFFF 0x0000.0000-0x1FFF.FFFF Conﬁg[K0] kseg1 0xA000.0000-0xBFFF.FFFF 0x0000.0000-0x1FFF.FFFF (uncached)

kseg2/3 0xC000.0000-0xFFFF.FFFF 0xC000.0000-0xFFFF.FFFF Conﬁg[K23]

Even in ﬁxed-mapping mode, the cache parity error status bit Status[ERL] still has the effect (required by the MIPS32 architecture) of taking over the normal mapping of “kuseg”; addresses in that range are used unmapped as physical addresses, and all accesses are uncached, until

Status[ERL] is cleared again.

3.3 Reads, writes and synchronization

3.2 Fixed mapping option

The MIPS architecture permits implementations a fair amount of freedom as to the order in which loads and stores appear at the CPU interface. Most of the time anything goes: so long as the software behaves correctly, the MIPS architecture places few constraints on the order of reads and writes seen by some other agent in a system.

3.3.1 Read/write ordering and cache/memory data queues in the 74K™ core

To understand the timing of loads and stores (and sometimes instruction fetches), we need to say a little more about the internal construction of the 74K core. In order to maximize performance:

• Loads are non-blocking: execution continues “through” a load instruction, and only stops when the program tries to use the GPR value it just loaded.

• Writes are “posted”: a write from the core is put aside (the hardware stores both address and data) until the CPU can get access to the system interface and send it off. Even writes which hit in the cache are posted, occurring after the instruction graduates.

• Cache reﬁlls are handled after the “missing” load has graduated: most of the time the CPU will quite soon get hung up on an instruction which needs the data from the miss, but this is not necessarily the case. The CPU runs on after the load instruction, with the memory pipeline logic remembering and handling the load completion.

All of these are implemented with “queues”, called the LDQ, WBB and FSB (for “ﬁll/store buffer” — it’s used both for writes which hit and for reﬁlls after a cache miss) respectively. All the queues handle data ﬁrst-come, ﬁrst served. The WBB and FSB queues need to be snooped - a subsequent store to a location with a load pending had better not be allowed to go ahead until the original load data has reached the cache, for example. So each queue entry is tagged with the address of the data it contains.

An LDQ entry is required for every load that misses in the cache. This queue allows the CPU to keep running even though there are outstanding loads. When the load data is ﬁnally returned from the system, the LDQ and the main core logic act together to write this data into the correct GPR (which will then free up any instructions whose issue is blocked waiting for this data).

Programming the MIPS32® 74K™ Core Family, Revision 02.14 30

Memory map, caching, reads, writes and translation

The WBB (Write Back Buffer) queue holds data waiting to be sent out over the system interface, either from D-cache writebacks or uncached/write-through store instructions.

FSB (Fill Store buffer) queue entries are used to hold data that is waiting to be written into the D-cache. An FSB entry gets used during a cache miss (when it holds the reﬁll data), or a write which hits in the cache (when it holds the data the CPU wrote). Loads and stores snoop the FSB so that accesses to lines “in ﬂight” can be dealt with correctly.

All this has a number of consequences which may be visible to software:

• Number of non-blocking loads which may be pending: the CPU has nine LDQ entries. That limits the number of outstanding loads.

• Hit-under-miss: the D-cache continues to supply data on a hit, even when there are outstanding misses with data in ﬂight. FSB entries remember the in-ﬂight data. So it is quite normal for a read which hits in the cache to be “completed” - in the sense that the data reaches a register - before a previous read which missed.

• Write-under-miss: the CPU pipeline continues and can generate external store cycles even though a read is pending, so long as WBB slots are available. The 74K core’s “OCP” interface is non-blocking too (reads consist of separate address and data phases, and writes are permitted between them), so this behavior can often be visible to the system.

• Miss under miss: the 74K core can continue to run until the pending read operations exhaust FSB or LDQ entries. More often, of course, it will try to use the data from the pending miss and stall before it gets that far.

• Core interface ordering: at the core interface, read operations may be split into an address phase and a later data phase, with other bus operations in between.

The 74K core - as is permitted by [MIPS32] - makes only limited promises about the order in which reads and writes happen at the system interface. In particular, uncached or write-through writes may be overtaken by cache line reads triggered by a load/store cache miss later in sequence. However, uncached reads and writes are always presented in their program sequence. When some particular program needs to do things “really in order”, the

sync instruction can help, as described in the next section.

Cache management operations interact with several queues: see Section 3.4.6 “L1 Cache instruction timing”.

3.3.2 The “sync” instruction in 74K™ family cores

If you want to be sure that some other agent in the system sees a pair of transactions to uncached memory in the order of the instructions that caused them, you should put a sync instruction between the instructions. Other MIPS32/64-

compliant CPUs may reorder loads and stores even more; portable code should use sync7.

But sometimes it’s useful to know more precisely what sync does on a particular core. On 74K sync:

• Stalls graduation (preventing any later load/store from graduating and becoming externally visible) until all pending reads, cached writes and OCP writes are completed — that is, until the FSB and WBB are empty;

• In some systems the CPU will also generate a synchronizing transaction on the OCP system interface if

Conﬁg7[ES] bit is set

. Not all systems do this. See Section B.2.1 “The Config7 register” for more details.

7. Note that sync is described as only working on “uncached pages or cacheable pages marked as coherent”. But sync also acts as a synchronization barrier to the effects produced by routine cache-manipulation instructions - hit-writeback and hitinvalidate.

31 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.4 Caches

A new set of lightweight SYNC instructions have been introduced. As compared to the completion barrier, the ordering barrier is a lighter-weight operation as it does not require the speciﬁed instructions before the SYNC to be already completed. Instead it only requires that those speciﬁed instructions which are subsequent to the SYNC in the instruction stream are never re-ordered for processing ahead of the speciﬁed instructions which are before the SYNC in the instruction stream. This potentially reduces how many cycles the barrier instruction must stall before it completes.

Because the core processes loads and stores in order, ordering barriers are much lighter weight. Details about the set of supported lightweight SYNC instructions can be found in the Software User’s Reference Manual

3.3.3 Write gathering and “write buffer ﬂushing” in 74K™ family cores

We mentioned above that writes to the system (whether uncached writes or cache write-backs) are performed somewhat lazily, the write being held in the WBB queue until a convenient moment. That can have two system-visible effects:

• Writes can happen later than you think. Your write will happen before the next uncached read or write, but that’s

all you know. And your write might still be posted somewhere in a system controller, unless you know your system is built to prevent it. Sometimes it’s better to code a dummy uncached read from a nearby location (which will “ﬂush out” buffered writes on pretty much any system).

• If your cache is conﬁgured for write-through, then cached writes to locations in the same “cache line”-sized

chunk of memory may be gathered - stored together in the WBB, and then dealt with by a single “wider” OCP write than the one you originally coded. Sometimes, this is what you want. When it isn’t, put a your successive writes. Regular uncached writes are never merged, but special “uncached accelerated” writes may be — see Section 3.4.3 below.

sync between

3.4 Caches

Most of the time caches just work and are invisible to software... though your programs would go twenty times slower without them. But this section is about when caches aren’t invisible any more.

Like most modern MIPS CPUs, the 74K core has separate primary I- and D-caches. They are virtually-indexed and physically-tagged, so you may need to deal with cache aliases, see Section 3.4.9, "Cache aliases". The design pro- vides for 16Kbyte, 32Kbyte or 64Kbyte caches; but the largest of those are likely to come with some speed penalty. The 74K core’s primary caches are 4-way set associative.

Your 74K core can optionally be built with a L2 (level 2 or secondary) cache. see section below for details.

But don’t hard-wire any of this information into your software. Instead, probe the Conﬁg1 register deﬁned by

[MIPS32] (and described in ) to determine the shape and size of the L1 and any L2 cache.

3.4.1 The L2 cache option

The L2 cache is an option available to your SoC builder. Basic facts and ﬁgures:

• The L2 cache is attached to the core’s standard 64-bit OCP system interface, and when you ﬁt it everything else

is attached to the core through the L2 cache, which has a system-side interface for that purpose. The core-side

8. This will be a read with the signal OC_MReqInfo[3] set. Handling of this transaction is system dependent, but a typical system controller will ﬂush any external write buffers and complete all pending transactions before telling the CPU that the transaction is completed. Ask your system integrator how it works in your SoC.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 32

Memory map, caching, reads, writes and translation

interface is enhanced and augmented to support cache instructions targeted at the L2, and to carry back performance counter information and so on.

• The L2 ‘s size can be 128Kbytes, 256Kbytes, 512Kbytes or 1Mbyte. However, there are options which allow the

SoC builder to have one or more of the ways of the cache memory array visible as normal system memory instead. There’s very little in this manual about that option. — see “MIPS® PDtrace™ Interface and Trace

Control Block Specification”, MIPS Technologies document MD00439. Current revision is 4.30: you need revision 4 or greater to get multithreading trace information. [L2CACHE].

• The L2 cache is indexed and tagged with the physical address, so is unaffected by cache aliases.

• Cache lines are either 32 bytes long (matching the L1 caches) or 64 bytes. The L2 cache’s memories are accessed

256 bits at a time internally, though it has 64-bit interfaces.

• It can be conﬁgured with 4-way or 8-way set-associative organization. In a 4-way cache the line replacement pol-

icy is “least recently used” (LRU); true LRU is impractical for an 8-way set associative cache, so something simpler (a “pseudo-LRU”) is used.

• The cache has an option for error detection and correction. 1-bit data errors can be corrected and all 2-bit errors

detected with an 8-bit-per-doubleword ECC ﬁeld. Check bits are provided on cache tags, too. If your L2 has ECC ﬁtted, ErrCtl[L2P] will be writable — see Section 3.4.17 “ErrCtl register” for details.

• The cache is write-back but does not allocate a line on a write miss (write miss data is just sent directly to the sys-

tem memory). It is write-through for memory regions which request that policy -- see Section

3.4.2 “Cacheability options” for details.

• The L2 cache can run synchronously to the CPU core, but (particularly for memory arrays larger than

256Kbytes) would typically then be the critical path for timing. It will more often use a 1:2 or 2:3 clock ratio. The L2’s far-side OCP interface may run at any of a wide range of ratios from the L2 clock down.

• In an effort to keep everything going the cache manages multiple outstanding transactions (it can handle as many

as 15 outstanding misses). Misses are resolved and responses sent as they happen, not in the order of presentation.

• Latency: the L2 logic allows the memory access to be pipelined, a reasonable choice for larger or slower arrays:

ask your SoC builder. The L2 delivers hit data in a burst of four 64-bit doublewords. The ﬁrst doubleword appears after 9 or 10 L2 clocks (10 for pipelined-array systems) and the rest of the burst follows on consecutive clocks. Added to this is some extra time taken for the original L1 miss to be discovered, synchronizing to the L2 clock, and returning the data to the CPU: typically, add 5 CPU clocks.

An L2 miss is slightly more expensive than an L1 miss from the same memory, since we don’t start the memory access until we’ve discovered that the data isn’t in the L2. The L2 memory interface can be conﬁgured to be 64bit or 256-bit wide. An L2 miss will deliver miss data to the CPU core in burst of four 64-bit doublewords .Because the CPU connects to the rest of the system through the L2 cache, it also adds 4 L2 cycles to the latency of all transactions which bypass the L2.

• The L2 cache requires software management, and you can apply the same cache instructions to it as to the L1 D-

cache.

3.4.2 Cacheability options

Any read or write made by the 74K core will be cacheable or not according to the virtual memory map. For addresses translated by the TLB the cacheability is determined by the TLB entry; the key ﬁeld appears as EntryLo[C]. Table 3.3

33 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.4 Caches

shows the code values used in EntryLo[C] - the same codes are used in the Conﬁg entries used to set the behavior of regions with ﬁxed mappings (the latter are described in Table 3.2.)

Some of the undeﬁned cacheability code values are reserved for use in cache-coherent systems.

Table 3.3 Cache Code Values

Code Cached? How it Writes Notes

0 cached write-through An unusual choice for a high-speed CPU, probably only for debug 2 uncached 3 cached writeback All normal cacheable areas 7 uncached “Uncached Accel-

erated”

Unusual and interesting mode for high-bandwidth write-only hardware; see

Section 3.4.3, "Uncached accelerated writes". Such writes just bypass the L2

cache, if there is one.

3.4.3 Uncached accelerated writes

The 74K core permits memory regions to be marked as “uncached accelerated”. This type of region is useful to hardware which is “write only” - perhaps video frame buffers, or some other hardware stream. Sequential word stores in such regions are gathered into cache-line-sized chunks, before being written with a single burst cycle on the CPU interface.

Such regions are uncached for read, and partial-word or out-of-sequence writes have “unpredictable” effects - don’t do them. The burst write is normally performed when software writes to the last location in the memory block or does an uncached-accelerated write to some other block; but it can also be triggered by a sync instruction, a pref nudge, a matching load or any exception. If the block is not completely written by the time it’s pushed out, it will be written using a series of doubleword or smaller write cycles over the 74K core’s 64-bit memory interface.

If you have an L2 cache, regions marked as “uncached accelerated” are L2-uncached.

3.4.4 The cache instruction and software cache management

The 74K core’s caches are not fully “coherent” and require OS intervention at times. The cache instruction is the building block of such OS interventions, and is required for correct handling of DMA data and for cache initialization. Historically, the cache instruction also had a role when writing instructions (unless the programmer takes some action, those instructions may only be in the D-cache whereas you need them to be fetched through the I-cache when the time comes). But where possible use synci for that purpose, as described in Section 3.4.8 “Cache management

when writing instructions - the “synci” instruction”.

A cache operation instruction is written cache op,addr where addr is just an address format, written as for a load/ store instruction. Cache operations are privileged and can only run in kernel mode (synci works in user mode, though). Generally we’re not showing you instruction encodings in this book (you have software tools for that stuff) but in this case it’s probably necessary, so take a look at Figure 3.1.

31 26 25 21 20 18 17 16 15 0

cache base op offset

47 register what to do which cache

Figure 3.1 Fields in the encoding of a cache instruction

Programming the MIPS32® 74K™ Core Family, Revision 02.14 34

Memory map, caching, reads, writes and translation

The op ﬁeld packs together a 2-bit ﬁeld which selects which cache to work on:

0 L1 I-cache 1 L1 D-cache 2 reserved for L3 cache 3 L2 cache

and then adds a 3-bit ﬁeld which encodes a command to be carried out on the line the instruction selects.

Before we list out the individual commands in Table 3.4; the cache commands come in three ﬂavors which differ in how they pick the cache entry (the “cache line”) they will work on:

• Hit-type cache operation: presents an address (just like a load/store), which is looked up in the cache. If this loca-

tion is in the cache (it “hits”) the cache operation is carried out on the enclosing line. If this location is not in the cache, nothing happens.

• Address-type cache operation: presents an address of some memory data, which is processed just like a cached

access - if the cache was previously invalid the data is fetched from memory.

• Index-type cache operation: as many low bits of the address as are required are used to select the byte within the

cache line, then the cache line address inside one of the four cache ways, and then the way. You have to know the size of your cache (discoverable from the Conﬁg1-2 registers, see ) to know exactly where the ﬁeld boundaries are, but your address is used something like this:

31 5 4 0

Unused Way1-0 Index byte-within-line

Beware:the MIPS32 speciﬁcation leaves CPU designers to choose whether to derive the index from the virtual or physical address. Don’t leave it to chance: with index-type operations use a kseg0 address, so that the virtual and physical address are the same (at least apart from some high bits which certainly won’t affect any cache index). This also avoids a potential pitfall related to cache aliases.

The L1 caches are 4-way set-associative, so data from any given address has four possible cache locations - same index, different value of the “Way1-0” bits as above.

Don’t deﬁne your own C names for cache manipulation operation codes, at least not if you can use a standard header ﬁle from MIPS Technologies on open-source terms: see [m32c0 h].

3.4.5 Cache instructions and CP0 cache tag/data registers

MIPS Technologies’cores use different CP0 registers for cache operations targeted at different caches. That’s already quite confusing, but to make it more interesting these registers have somehow got different names — those used here

35 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Table 3.4 Operations on a cache line available with the cache instruction

Value Command What it does

0 Index invalidate Sets the line to “invalid”. If it’s a D-cache or L2 cache line which is valid and

“dirty” (has been written by CPU since fetched from memory), then write the contents back to memory ﬁrst. This is the best and simplest way to invalidate an Icache when initializing the CPU - though if your cache is parity-protected, you also need to ﬁll it with good-parity data, see Fill below. This instruction is not suitable for initializing caches, where it might cause random write-backs: see the Index Store Tag type below.

1 Index Load Tag Read the cache line tag bits and addressed doubleword data into the TagLo etc

registers (see Table 3.1 for names). Operation for diagnostics and geeks only.

2 Index Store Tag Set the cache tag from the TagLo registers.

To initialize a writable cache from an unknown state, set the TagLo registers to zero and then do this to each line.

3 Index Store Data Write cache-line data. Not commonly used for caches, but it is used for manage-

ment of scratchpad RAM regions described in Section 3.6 “Scratchpad memory/

SPRAM”.

4 Hit invalidate hit-type invalidate - do not writeback the data even if dirty. May cause data loss

unless you know the line is not dirty. Certain CPUs implementaspecial form of the I-side hitinvalidate,wheremultiple searches are donetoensurethat any line matching the effective physical addressis invalidated(even if it doesn’tmatchthe supplied virtual address for page color)— see Section 3.4.9 “Cache aliases” below.

5 Sorry, different meanings for code “5” on L1 I-cache.

Writeback invalidate On the L1D-cache or L2 cache: (hit-type operation) invalidate the line but only

after writing it back, if dirty. This is the recommended way of invalidating a writable line in a running cache.

Fill On an L1 I-cache: (address-type operation) ﬁll a suitable cache line from the data

at the supplied address - it will be selected just as if you were processing an Icache miss at this address. Used to initialize an I-cache line’s data ﬁeld, which should be done when setting up the CPU when the cache is parity protected.

6 Hit writeback If the line is dirty, write it back to memory but leave it valid in the cache. Used in

a running system where you want to ensure that data is pushed into memory for access by a DMA device or other CPU.

7 Fetch and Lock An address-type operation. Get the addressed data into the same line as would be

used on a regular cached reference (if the data wasn’t already cached that might involve writing back the previous occupant of the cache line). Then lock the line. Locked lines are not replaced on a cache miss. It stays locked until explicitly invalidated with a cache An attempt to lock the last entry available at some particular index fails silently.

3.4 Caches

Programming the MIPS32® 74K™ Core Family, Revision 02.14 36

Memory map, caching, reads, writes and translation

and in C header ﬁles. I hope Table 3.1 helps. In the rest of this document we’ll either use the full software name or (quite often) just talk of TagLo without qualiﬁcation.:

Table 3.1 Caches and their CP0 cache tag/data registers

Cache CP0 Registers CP0 number

L1 I-cache

L1 D-cache

L2 cache

1. In past versions ofthismanualL23TagLowas known as

“STagLo”, and so on. But this name is more mnemonic.

ITagLo 28.0

ITagHi 29.0 IDataLo 28.1 IDtataHi 29.1 DTagLo 28.2

DTagHi 29.2

DDataLo 28.3

L23TagLo L23DataLo 28.5 L23DataHi 29.5

28.4

3.4.6 L1 Cache instruction timing

Most CP0 instructions are used rarely, in code which is not timing-critical. But an OS which has to manage caches around I/O operations or otherwise may have to sit in a tight loop issuing hundreds of cache operations at a time, so performance can be important. Firstly, any D-side cache instruction will check the FSB queue (as described in

Section 3.3 “Reads, writes and synchronization”) for potentially matching entries. The “potential match” check uses

the cache index, and avoids taking any action for most irrelevant FSB activity. But on a potential match the cacheop waits (stalling the memory pipeline) while any pending cache reﬁlls happen, and while any dirty lines evicted from the cache are sent out at least to the CPU’s write buffer. Typically, this will not take more than a few clocks, and will only need to be done once for a stream of cacheops.

In the 74K core, the whole cacheop is executed in the memory pipeline, after the cache instruction graduates. All

cache instructions except for “index load...” run through graduation without delay — and in particular, any stream of

hit-type operations which miss in the cache can run 1-per-clock.

A younger instruction which has run ahead of the cacheop is checked while it waits for graduation; if it might run incorrectly because of an incomplete cacheop, the younger instruction is cancelled and the whole execution unit backed off so it can be re-issued from scratch (an EU “replay” — expensive but infrequent).

3.4.7 L2 cache instruction timing

The L2 cache run synchronously with the CPU but at a conﬁgurable clock ratio. The L2 operations will be signiﬁcantly slower than L1 versions even at the same clock ratio. Exactly how slow is dependent on the performance of the memory blocks used to build your L2 cache and the L2 clock ratio.

3.4.8 Cache management when writing instructions - the “synci” instruction

The synci instruction (new to the MIPS32 Release 2 update) provides a clean mechanism - available to user-level code, not just at kernel privilege level - for ensuring that instructions you’ve just written are correctly presented for

37 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.4 Caches

execution (it combines a D-cache writeback with an I-cache invalidate). You should use it in preference to the traditional alternative of a D-cache writeback followed by an I-cache invalidate.

synci does nothing to an L2 cache — the L2 cache is uniﬁed, and there’s no need to do anything special there to

make data visible for instruction fetch.

3.4.9 Cache aliases

The 74K has L1 caches which are virtually indexed but physically tagged. Since it’s quite routine to have multiple virtual mappings of the same physical data, it’s possible for such a cache to end up with two copies of the same data. That becomes troublesome:

• When you want to write the data: if a line is stored in two places, you’ll only update one of them and some data will be lost (at least, there’s a 50% chance it will be lost!) This is obviously disastrous: systems generally work hard to avoid aliases in the D-cache.

• When you want to invalidate the line in the cache: there’s a danger you might invalidate one copy but not the other. This (more subtle) problem can affect the I-cache too.

It can be worked around. There’s no problem for different virtual mappings which generate the same cache index; those lines will all compete for the 4 ways at that index, and then be correctly identiﬁed through the physical tag.

The 74K CPU’s smallest page size is 4Kbytes, that’s 2

bytes. The paged memory translation means that the low 12 bits of a virtual address is always reproduced in the physical address. Since a 16Kbyte, 4-way set-associative, cache gets its index from the low 12 bits of the address, the 16Kbyte cache is alias-free. In general, you can’t get aliases if each cache “way” is no larger than the page size.

In 32Kbyte and 64Kbyte caches, one or two top bits used for the index are not necessarily the same as the corresponding bits of the physical address, and aliases are possible. The value of the one or two critical virtual address bits is sometimes called the page color.

It’spossiblefor software to avoidaliasesif it can ensure that where multiple virtual mappings to a physical page exist, they all have the same color. An OS can do that by enforcing virtual-memory alignment rules (to at least a 16Kbyte boundary) for shareable regions. It turns out this is practicable over a large range of OS activities: sharing code and libraries, and deliberate interprocess shared memory. It is not so easy to do in other circumstances, particularly when

pages to be mapped start their life as buffers for some disk or network operation9...

So the 74K contains logic to make a 32Kbyte or 64Kbyte D-cache alias-free (effectively one or two index bits are from the physical address, and used late in the cache access process to maintain performance). This logic is a build option, and Conﬁg7[AR] ﬂag should read 1 if your was built to have an alias-free D-cache.

A 32Kbyte or 64Kbyte I-cache is subject to aliases. It’s not immediately obvious why this matters; you certainly can’t end up losing writes, as you might in an alias-prone D-cache. But I-cache aliases can lead to unexpected events when you deliberately invalidate some cache content using the cache instruction. An invalidation directed at one virtual address translated to a particular physical line may leave an undesirable valid copy of the same physical data indexed by a virtual alias of a different color. To solve this, some 74K s are built to strengthen hit-type I-cache invalidate instructions (those include hit-type cache instructions and the synci instruction), so as to guarantee that no copy of the addressed physical line remains in the cache. This facility is available if the Conﬁg7[IAR] bit reads 1; but if it’s

9. There’sa fairamount of rather ugly code in the MIPS Linux kernel to work around aliases. D-cache aliases (in particular) are dealt with at the cost of quite a large number of extra invalidate operations.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 38

Memory map, caching, reads, writes and translation

available but your software doesn’t need it, you can restore “legacy” behavior by setting Conﬁg7[IVA] to 1. Refer to

Section B.2.1 “The Config7 register” for details.

The MIPS Technology supplied L2 cache (if conﬁgured) is physically indexed and physically tagged, so does not suffer from aliases.

3.4.10 Cache locking

[MIPS32] provides for a mechanism to lock a cache line so it can’t be replaced. This avoids cache misses on one par-

ticular piece of data, at the cost of reducing overall cache efﬁciency.

Caution: in complex software systems it is hard to be sure that cache locking provides any overall beneﬁt - most often,

it won’t. You should probably only use locking after careful measurements have shown it to be effective for your application.

Lock a line using a cache FetchAndLock (it will not in fact re-fetch a line which is already in the cache). Unlock it using any kind of relevant cache “invalidate” instruction

- but note that synci won’t do the job, and should not

be used on data/instruction locations which are cache-locked.

3.4.11 Cache initialization and tag/data registers

The cache tag and data registers — listed in Table 3.1 above — are used for staging tag information being read from or written to the cache. [MIPS32] declares that the contents of these registers is implementation dependent, so they need some words here.

The “I-” registers are used for the I-cache and the “D-” registers for the D-cache11. Some other MIPS CPUs use the same staging register(s) for all caches, and even simple initialization software written for such CPUs is not portable to the 74K core.

Before getting into the details, note that it’s a strong convention that you can write all-zeros to both TagLo registers and then use cache IndexStoreTag to initialize a cache entry to a legitimate (but empty) state. Your cache initialization software should rely on that, not on the details of the registers.

Only diagnostic and test software will need to know details; but Figure 3.2 shows all the ﬁelds (there’s no “D”-fordirty bit in 74K cores, where access to the dirty bits is done separately,see Section B.3.1 “Different views of ITagLo/

DTagLo”:

Figure 3.2 Fields in the TagLo Registers

31 121110987654 21 0

PTagLo U 0 V E L 0 P1 P0

The cache tag registers ITagLo and DTagLo can be used in special modes, controlled by bits in the ErrCtl register, where the register layout changes completely. Set ErrCtl[SPR] for access to SPRAM control ﬁelds, as described in

Figure 3.8 and its notes below. Set ErrCtl[WST] or ErrCtl[DYT] for diagnostic-only access to the “way select” or “dirty

bit” sections of the cache control memory, as described in Section B.3.1 “Different views of ITagLo/DTagLo”. But let’s look at the standard ﬁelds ﬁrst:

10. It’s possible to lock and unlock lines by manipulating values in the TagLo register and then using a cacheIndex_Load_Tag instruction... but highly non-portable and likely to cause trouble. Probably for diagnostics only.

11. Some documentation just numbers the TagLo registers, starting from 0 and in the same order as their CP0 numbering: see

Table 3.1 in this chapter.

39 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.4 Caches

PTagLo

: the cache address tag - a physical address because the 74K core’s caches are physically tagged. It holds bits

31–12 of the physical address - the low 12 bits of the address are implied by the position of the data in the cache.

×: a ﬁeld not described for the 74K core but which might not always read zero.

V: 1 when this cache line is valid.

E: always 0

L: 1 when this cache line is locked, see Section 3.4.10, "Cache locking".

P0: parity bit for tag ﬁelds other than the TagLo[D] bit, which is actually held separately in the "way-select" RAM.

When you use the TagLo register to write a cache tag with cache IndexStoreTag the TagLo[P]: bit is generally not used - instead the hardware puts together your other ﬁelds and ensures it writes correct parity. However, it is possible to force parity to exactly this value by ﬁrst setting ErrCtl[PO].

3.4.12 L23TagLo Regiser

This register in the 74K core is implemented to support access to external L2 cache tags via cache instructions. The deﬁnition of the ﬁelds of this 32 bit register are deﬁned by the SoC designer. Refer to the section on L2 Transactions

in the document ““MIPS32® 74K tion on using this register.

CoreTrade

Processor core Family Integrator’s Guide, MD00499” for further informa-

Figure 3.3 L23TagLo Register Format

31 0

DATA

3.4.13 L23DataLo Register

On 74K family cores, test software can read or write cache data using a cache index load/store data instruction. Which word of the cache line is transferred depends on the low address fed to the cache instruction.

Figure 3.4 L23DataLo Register Format

31 0

DATA

Table 3.5 L23DataLo Register Field Description

Fields

Description

DATA 31:0 Low-order data read from the cache data array. R/W Undeﬁned

Read /

Write Reset StateName Bit(s)

3.4.14 L23DataHi Register

Programming the MIPS32® 74K™ Core Family, Revision 02.14 40

Memory map, caching, reads, writes and translation

Figure 3.5 L23DataHi Register Format

31 0

DATA

Table 3.6 L23DataHi Register Field Description

Fields

Description

DATA 31:0 High-order data read from the cache data array. R/W Undeﬁned

Read /

Write Reset StateName Bit(s)

3.4.15 TagLo registers in special modes

The usual TagLo register ﬁelds are a view of the underlying cache tags. But load-tag/store tag cacheops act differently in special modes activated by setting bits in ErrCtl (see Section 3.4.17 “ErrCtl register” for details):

• When ErrCtl[SPR] is set, the L1 TagLo registers are used to conﬁgure scratchpad memory, if ﬁtted. That’s

described in Section 3.6 “Scratchpad memory/SPRAM” below, where you’ll ﬁnd a ﬁeld diagram for the TagLo registers in that mode.

• When ErrCtl[WST] or ErrCtl[DYT] is set, the tag registers are used to provide diagnostic/test software with direct

read-write access to the “way select RAM” or “dirty RAM” respectively — parts of the cache array. This is highly CPU-dependent and is described in Section B.3 “Registers for Cache Diagnostics”.

3.4.16 Parity error exception handling and the CacheErr register

The 74K core does not check parity on data (or control ﬁelds) from the external interface - so this section really is just about parity protection in the cache. It’s a build-time option, selected by your system integrator, whether to include check bits in the cache and logic to monitor them.

At a system level, a cache parity exception is usually fatal - though recovery might be possible sometimes, when it is useful to know that the exception is taken in “error mode” (that is, Status[ERL] is set), the restart address is in

ErrorEPC and you can return from the exception with an eret — it uses ErrorEPC when Status[ERL] is set.

But mainly, diagnostic-code authors will probably ﬁnd the CacheErr register’s extra information useful.

Figure 3.6 Fields in the CacheErr Register

31 30 29 28 27 26 25 24 23 22 21 19 18 17 16 0

ER EC ED ET ES EE EB EF SP EW Way DR 0

ER: was the error on an I-fetch (0) or on data (1)? Applicable only to L1 cache errors.

EC: in L1 cache (0) or L2-or-higher cache (1)?

ED,ET: 1 for error in data ﬁeld/tag ﬁeld respectively.

ES: Error source, Not Supported.

EE: Error external, Not Supported.

41 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Index

3.4 Caches

: 1 if data and instruction-fetch error reported on same instruction, which is unrecoverable. If so, the rest of the regis-

ter reports on the instruction-fetch error.

On an L2 error: 1 if an error occurred in more than one of the cache's memory arrays if EC is also set— the hardware manual [SUM] renames this ﬁeld as CacheErr[EM]. The rest of the register can only reﬂect information about one of the errors: it shows tag errors as highest priority, then data, then way-select.

EF: unrecoverable (fatal) error (other than the EB type above). Some parity errors can be ﬁxed by invalidating the cache

line and relying on good data from memory. But if this bit is set, all is lost... It’s one of the following:

1. Line being displaced from cache (“victim”) has a tag parity error, so we don’t know whether to write it back, or whether the writeback location (which needs a correct tag) would be correct.

2. The victim’s tag indicates it has been written by the CPU since it was obtained from memory (the line is “dirty” and needs a write-back), but it has a data parity error.

3. Writeback store miss and CacheErr[EW] error.

4. At least one more cache parity error happened concurrently with or after this one, but before we reached the relative safety of the cache parity error exception handler.

If the EC bit is set this bit is referring to the errors in L2 (external) cache.

SP: error affecting a scratchpad RAM access, see Section 3.6, "Scratchpad memory/SPRAM" below.

: parity error on the “dirty” (cache modiﬁed) or way-selection bits. This means loss of LRU information, which —

most of the time — is recoverable.

Way: the way-number of the cache entry where the error occurred. Caution: for the L1 caches (which are no more than

4-way set associative) this is a two-bit ﬁeld. But an L2 cache might be more highly set-associative, and then this ﬁeld grows down. In particular, MIPS’ (possibly 8-way set associative) L2 cache uses a 3-bit Way ﬁeld as shown.

DR: A 1 bit indicates that the reported error affected the cache line "dirty" bits.

Index: the index (within the cache way) of the cache entry where the error occurred... except that the low bits are not

meaningful. The index is aligned as if it’s a byte address, which is good because that’s what Index-type cache instructions need. It resolves the failing doubleword for a data error, or just the failing line for a tag error. We’ve shown a 14-bit ﬁeld, because that’s large enough to provide the index for the 74K core’slargest conﬁgurable (4 ways by 16KB) L1 cache option.

Two other ﬁelds are related to the processing of cache errors. Other implementations have laid claim to all of the bits in this register, so these bits were relegated to the ErrCtl register. The FE and SE bits in that register are used to detect nested cache errors and are described in the next section.

If you want to study this error further, you’ll probably use an index-type cache instruction to read out the tags and/ or data. The cache instruction’s “index” needs the way-number bits added to CacheErr[Index]’s contents; see Figure

3.1 and its notes above for how to do that.

3.4.17 ErrCtl register

This register has two distinct roles. It contains “mode bits” which provide different views of the TagLo registers when they’re used for access to internal memory arrays and cache diagnostics. But it also controls parity protection of the caches (if it was conﬁgured in your core in the ﬁrst place).

Programming the MIPS32® 74K™ Core Family, Revision 02.14 42

Memory map, caching, reads, writes and translation

Figure 3.7 Fields in the ErrCtl Register

31 30 29 28 27 26 25 24 23 22 21 20 19 18 12 11 4 3 0

PE PO WST SPR PCO ITC LBE WABE L2P PCD DYT SE FE 0 PI PD

00 0 0 0 0 0 0 0 0

Two ﬁelds are ‘overﬂow’ from the CacheErr register and relate to the error state:

FE/SE: Used to detect nested errors. FE (FirstError) is set on any cache error. SE (Second Error) is set when an error is

seen and FE is set. Software should clear FE once it has logged enough error information that taking a second error will not be fatal.

The rest of the ﬁelds can be summarized as such: running software should set just the parity enable (PE) bit to enable cache parity checking as required, and leave it zero otherwise. The ﬁelds are as follows:

PE: 1 to enable cache parity checking. Hard-wired to zero if parity isn’t implemented.

PO: (parity overwrite) - set 1 to set the parity bit regardless of parity computation, which is only for diagnostic/test pur-

poses.

After setting this bit you can use cache IndexStoreTag to set the cache data parity to the value currently in

ErrCtl[PI] (for I-cache) or ErrCtl[PD] (for D-cache), while the tag parity is forcefully set from TagLo[P].

WST: test mode for cache IndexLoadTag/cache IndexStoreTag instructions, which then read/write the

cache’s internal "way-selection RAM" instead of the cache tags.

SPR: when set, index-type cache instructions work on the scratchpad/SPRAM, if ﬁtted - see Section 3.6, "Scratchpad

memory/SPRAM".

PI/PD: parity bits being read/written to caches (I- and D-cache respectively).

LBE, WABE: ﬁeld indicating whether a bus error (the last one, if there’s been more than one) was triggered by a load or

a write-allocate respectively: see below. Where both a load and write-allocate are waiting on the same cache-line reﬁll, both could be set. These bits are “sticky”, remaining set until explicitly written zero.

L2P: Controls ECC checking of an L2 cache, if it's ﬁtted and has that capability.

For backward-compatibility,you only set L2P when you want to make a different error-checking choice at the L1 and L2 levels. So L2 error checking is enabled if ErrCtl[PE,L2P] == 01 or ErrCtl[PE,L2P] == 10.

PCD: when set 1, cache StoreData does not update I-cache precode bits, nor their parity. This is for deep diagnostic

only.

DYT: set 1 to arrange that cache load/store data operations work on the “dirty array” — the slice of cache memory

which holds the “dirty” bits.

3.5 Bus error exception

The CPU’s“OCP” hardware interface rules permit a slave device attached to the system interface to signal back when something has gone wrong with a read. This should not be used to report a read parity error; if parity is checked externally,itwould haveto be reported through an interrupt. Typicallyabuserror means that some subsystem has failed to respond. Bus errors are not signalled on an OCP write cycle, and (if they were) the 74K core ignores them.

43 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Instruction bus error exceptions are precise (when the exception happens EPC always points to the instruction where fetch failed). But a data-side bus error is usually caused by a load, and the (non-blocking) load which caused it may havehappened a long time before the busy cycle ﬁnishes and the error is signalled. So a bus error exception caused by a load or store is imprecise; EPC does not necessarily (or even usually) point to the instruction causing the memory read..

If software knows that a particular read might encounter a bus error - typically it’s some kind of probe - it should be careful to stall and wait for the load value immediately, by reading the value into a register, and make sure it can handle a bus error at that point.

There is an obscure corner case. The 74K core’s D-cache is “write-allocate”: so a write which misses in the cache will trigger a read, to ﬁll the cache line ready to receive the new data. If you’re unlucky enough to get a bus error on that read-for-reﬁll, the bus error will be associated with a store. After a bus error you can look at ErrCtl[LBE]/ErrCtl[WABE] to see whether the error was caused by a load or write-allocate.

3.6 Scratchpad memory/SPRAM

The 74K core (like most of MIPS Technologies’ cores) can be equipped with modestly-sized high speed on-chip data memory, called scratchpad RAM or SPRAM. SPRAM is connected to a cache interface, alongside the I- and/or Dcache, so is available separately for the I- and D-side (ISPRAM and DSPRAM).

3.6 Scratchpad memory/SPRAM

MIPS Technologies provide the interface on which users can build many types and sizes of SPRAM. We also provide a “reference design” for both ISPRAM andDSPRAM, which is what is described here. If you keep the programming interface the same as the reference design, you’re more likely to be able to ﬁnd software support. The reference design allows for on-chip memories of up to 1Mbytes in size.

There are two possible motives for incorporating SPRAM:

• Dedicated high-speed memory: SPRAM runs with cache timing (multi-cycle SPRAM is supported for some other MIPS Technologies cores, but not on 74K cores).

SPRAM can be made larger than the maximum cache size.

Even for smaller sizes, it is possible to envisage applications where some particularly heavily-used piece of data is well-served by being permanently installed in SPRAM. Possible, but unusual. In most cases heavily-used data will be handled well by the D-cache, and until you really know otherwise it’s better for the SoC designer to maximize cache (compatible with his/her frequency needs.)

But there’s another more compelling use for a modest-size SPRAM:

• “DMA” accessible to external masters on the OCP interface: the SPRAM can be conﬁgured to be accessible from an OCP interface. OCP masters will see it just as a chunk of memory which can be read or written.

Because SPRAM stands in for the cache, data passed through the SPRAM in this way doesn’t require any software cache management. This makes it spectacularly efﬁcient as a staging area for communicating with complex I/O devices: a great way to implement “push” style I/O (that is where the device writes incoming data close to the CPU).

SPRAM must be located somewhere within the physical address map of the CPU, and is usually accessed through some “cached” region of memory (uncached region accesses to scratchpad work with the 74K reference design, but may not do so on other implementations - better to access it through cacheable regions). It’s usually better to put it in

Programming the MIPS32® 74K™ Core Family, Revision 02.14 44

Memory map, caching, reads, writes and translation

the ﬁrst 512Mbytes of physical space, because then it will be accessible through the simple kseg0 “cached, unmapped” region - with no need to set up speciﬁc TLB entries.

Because the SPRAM is close to the cache, it inherits some bits of cache housekeeping. In particular the cache instruction and the cache tag CP0 registers are used to provide a way for software to probe for and establish the size

of SPRAM12.

Probing for SPRAM conﬁguration

The presence of scratchpad RAM in your core is indicated by a “1” bit in one or both of the CP0 Conﬁg[ISP,DSP] reg- ister ﬂags described in . The MIPS Technologies reference design requires that you can query the size of and adjust the location of scratchpad RAM through “cache tags”.

To access the SPRAM “tags” (where the conﬁguration information is to be found) ﬁrst set the ErrCtl[SPR] bit (see

Section 3.4.17 “ErrCtl register”).

Now a cache Index_Load_Tag_D, KSEG0_BASE+013instruction fetches half the conﬁguration information into DTagLo, and a cache Index_Load_Tag, KSEG0_BASE+8 gets the other half (the “8” steps to the next feasible tag location - an artefact of the 64-bit width of the cache interface.) The corresponding operations directed at the primary I-cache read the halves of the I-side scratchpad tag, this time into ITagLo. The “tag” for I-side and D-side SPRAM appears in TagLo ﬁelds as shown in Figure 3.8.

Figure 3.8 SPRAM (scratchpad RAM) conﬁguration information in TagLo

31 12 11 8 7 6 5 4 1 0

addr == 0 base address[31:12] 0 En 0 addr == 8 size of region in bytes/4KB 0 En 0

Where:

• base address[31:12]: the high-order bits of the physical base address of this chunk of SPRAM;

• En: enable the SPRAM. From power-up this bit is zero, and until you set it to 1 the SPRAM is invisible. The En bit is also visible in the second (size) conﬁguration word — it can even be written there, but it’s not a good idea to write the size word other than for far-out diagnostics;

• size of region in bytes/4KB: the number of page-size chunks of data mapped. If you take the whole 32 bits, it returns the size in bytes (but it will always be a multiple of 4KB).

In some MIPS cores using this sort of tag setup there could be multiple scratchpad regions indicated by two or more of these tag pairs. But the reference design provided with the 74K core can only have one I-side and one D-side region.

You can load software into the ISPRAM using cacheops. Each pair of instructions to be loaded are put in the registers

IDataHi/IDataLo, and then you use a cache Index_Store_Data_I at the appropriate index. The two data regis-

ters work together to do a 64-bit transfer. Note that the 74K core’s instruction memory really is 128 bits wide, so you’ll need two cacheops to fully write a speciﬁc index. For a CPU conﬁgured big-endian the ﬁrst instruction in sequence is loaded into IDataHi, but for a CPU conﬁgured little-endian the ﬁrst instruction is loaded into IDataLo.

12. What follows is a hardware convention which SoC designers are not compelled to follow; but MIPS Technologies recommends designers to do SPRAM this way to ease software porting.

13. The instructions are written as if using C “#define” names from [m32c0 h]

45 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Don’t forget to set ErrCtl[SPR] back to zero when you’re done.

3.7 Common Device Memory Map

In order to preserve the limited CP0 register address space, many new architectural enhancements, particularly those requiring severalregisters,willbe memory mapped, that is, accessed by uncached load and store instructions. In order to avoid creating dozens of memory regions to be managed, the common device memory map (CDMM) was created to group them into one region. A single physical address region, up to 32KB, is deﬁned for CDMM. The address of this region is programmable via the CDMMBase CP0 register shown in Figure 3-9.

Having this region physically addressed enables some additional access controls. On a core with a TLB, the region would typically be located in the ﬁrst 256MB, allowing direct kseg1 access. However, if user or supervisor access was desired, TLB mappings could be established to map a useg address to the same region. On FMT based cores, it might be mapped to a kseg1 address if user access was not needed, or to a useg/kuseg address if it was.

The block of addresses is further broken up into 64-byte Device Register Blocks(DRB). A ‘device’ (feature requiring memory mapped accesses), can use from 1-63 DRBs - up to 4KB of addressable registers. The ﬁrst 64 bits of the ﬁrst DRB associated with a device is allocated for an Access Control and Status Register (of which only 32 are in use currently). The ACSR provides information about the device - ID, version, and size - and also contains control bits that can enable user and supervisor read and/or write access to the device. This register is shown in Figure 3.10

3.7 Common Device Memory Map

CDMM devices are packed into the lowest available DRBs. Starting with 0 (or 1 if

CDMMBase[CI] ==1), software

should read the ACSR, determining both the current device type as well as the starting location for the next device. Iterating through this process will create a map of all devices which you would presumably store in a more convienent format.

The ﬁrst device that has been deﬁned in CDMM is the Fast Debug Channel which is described in Section

8.1.10 “Fast Debug Channel”. This device is a UART-like communication channel that utilizes the EJTAG pins for

off-chip access. The UART is a natural ﬁt for a memory mapped device, although many types of devices can be envisioned.

Figure 3-9 Fields in the CDMMBase Register

31 11 10 9 8 0

CDMM_UPPER_ADDR EN CI CDMMSize

Where:

CDMM_UPPER_ADDR:: This field contains the upper bits of the base physical address of the CDMM region. This field

is shifted by 4b, so that bits 31..11 correspond to PA bits 35..15. Unimplemented physical address bits such as 35..32 in many cores will be tied to 0.

EN: Enables CDMM. When this bit is cleared, loads and stores to the CDMM region will go to memory. This bit resets

to 0 to avoid stepping on other things in the system address map.

CI: Indicates that the first 64-byte device register block is reserved for additional CDMM information and is not a nor-

mal device. This extra information hasn’t been dreamed up yet, so this field should just be treated as reserved.

CDMMSize: This field indicates how many 64-byte device register blocks are in the CDMM region. (0 means 1 DRB

and so forth)

Programming the MIPS32® 74K™ Core Family, Revision 02.14 46

Memory map, caching, reads, writes and translation

Each device within the CDMM begins with an Access Control and Status Register which gives information about the device and also provides a means for giving user and supervisor programs access to the rest of the device. The

FDACSR is shown in Figure 3.10.

Figure 3.10 Fields in the Access Control and Status (ACSR) Register

31 24232221 1615 1211 43210

DevID zero DevSize DevRev zero Uw Ur Sw Sr

Where:

DevID: (read only) indicates the device ID.

DevSize: (read only) indicates how many additional 64B blocks this device uses

DevRev: (read only) Revision number of the device.

Uw/Ur: control whether write and reads, respectively, from user programs are allowed to access the device registers. If 0,

reads will return 0 and writes will be dropped.

Sw/Sr: Same idea as Uw/Ur, but for supervisor access

3.8 The TLB and translation

The TLB is the key piece of hardware which MIPS architecture CPUs have for memory management. It’s a hardware array, and for maintenance you access ﬁelds by their index. For memory translation, it’s a real content-addressed memory, whose input is a virtual page address together with the “address space identiﬁer” from EntryHi[ASID]. The table also stores a physical address plus “cacheability” attributes, which becomes the output of the translation lookup.

The hardware TLB is relatively small, conﬁgurable with 16, 32, 48 or 64 entries (read Conﬁg1[MMUSize] for the number conﬁgured for your core). Each entry can map a 2-page-size virtual region to a pair of physical pages. Entries can map different size pages, too.

System software maintains the TLB as a cache of a much larger number of possible translations. An attempt to use a mapped-space address for which no translation is in the hardware TLB invokes a special exception handler which is carefully crafted to ﬁnd and load the right entry as quickly as possible. Read on for a summary of all the ﬁelds and how it gets used; but the OS ramiﬁcations are far too extensive to cover here; for a better description in context see

[SEEMIPSRUN]:, and for full details of the architectural speciﬁcation see [MIPS32].

3.8.1 A TLB entry

Let’s start with a sketch of a TLB entry. For MIPS32 cores, that consists of a virtual address portion to match against and two output sections, something like Figure 3.11 - which also shows which TLB ﬁelds are carried in which CP0 registers.

47 Programming the MIPS32® 74K™ Core Family, Revision 02.14

Figure 3.11 Fields in a 74K™ core TLB entry

EntryHi EntryHi

3.8 The TLB and translation

VPN2 PageMask ASID G PFN

PageMask EntryLo1 EntryLo0

Flags

C D V C D V

PFN

Flags

Some points to make about the TLB entry:

• The input-side virtual address ﬁelds (to the left) have the ﬁelds necessary to match an incoming address against

this entry. “VPN” is (by OS tradition) a “virtual page number” - the high bits of the program (virtual) address.

“VPN2” is used to remind you that this address is for a double-page-size virtual region which will map to a pair of physical pages...

• The right-hand side (physical) ﬁelds are the information used to output a translation. There are a pair of outputs

for each input-match, and which of them is used is determined by the highest within-match address bit. So in standard form (when we’re using 4Kbyte pages) each entry translates an 8Kbyte region of virtual address, but we can map each 4Kbyte page onto any physical address (with any permission ﬂag bits).

• The size of the input region is conﬁgurable because the “PageMask” determines how many incoming address bits

to match. The 74K core allows page sizes of 4Kbytes, 16Kbytes and going on in powers of 4 up to 256Mbytes. That’s expressed by the legal values of PageMask, shown below.

• The “ASID” ﬁeld extends the virtual address with an 8-bit, OS-assigned memory-space identiﬁer so that transla-

tions for multiple different applications can co-exist in the TLB (in Linux, for example, each application has different code and data lying in the same virtual address region).

• The “G” (global) bit is not quite sure whether it’s on the input or output side - there’s only one, but it can be read

and written through either of EntryLo0-1. When set, it causes addresses to match regardless of their ASID value, thus deﬁning a part of the address space which will be shared by all applications. For example, Linux applications share some “kseg2” space used for kernel extensions.

3.8.2 Live translation and micro-TLBs

When you’re really tuning out the last cycle, you need to know that in the 74K core the I-side translation is done by a little table local to the instruction fetch unit, and called the ITLB (sometimes “micro-TLB” or “uTLB”). There are only 4 entries in the ITLB, and it is functionally invisible to software: it’s automatically reﬁlled from the main TLB (in this context it’s often called the joint TLB or JTLB) when required, and automatically cleared whenever the TLB is updated. It costs six extra clocks to reﬁll the ITLB for any access whose translation is not already present. In 74K family cores (unlike other cores from MIPS Technologies) there is no D-side micro-TLB — D-side translation uses the main TLB directly. uTLB entries can only map 4KB and 16KB pages (main TLB entries can handle a whole range of sizes from 4KB to 256MB). When the uTLB is reloaded a translation marked for a size other than 4KB or 16KB is down-converted as required.

3.8.3 Reading and writing TLB entries: Index, Random and Wired

Two CP0 registers work as simple indexes into the TLB array for programming: Index and Random. The oddlynamed Wired controls Random’s behavior.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 48

Memory map, caching, reads, writes and translation

Of these: Index determines which TLB entry is accessed by tlbwi. It’s also used for the result of a tlbp (the instruction you use to see whether a particular address would be successfully translated by the CPU). Index only implements enough bits to index the TLB, however big that is; but a tlbp which fails to ﬁnd a match for the speciﬁed virtual address sets bit 31 of Index (it’s easy to test for).

Random is implemented as a full CPU clock-rate downcounter. It won’t decrement below the value of Wired (when it

gets there it bounces off and starts again at the highest legal index). In practice, when used inside the TLB reﬁll exception handler, it delivers a random index into the TLB somewhere between the value of Wired and the top.

Wired can therefore be set to reserve some TLB entries from random replacement - a good place for an OS to keep

translations which must never cause a TLB translation-not-present exception.Previously,a tlbwr instructionwould simply write to the TLB entry that the Random register currently indicated. The core has been enhanced with a feature (whose presence is indicated by Conﬁg6

= 1) to put a little more brains behind selecting a TLB entry to be

NMRUP

replaced. A table of the most recently used TLB entries is maintained and the core attempts to avoid selecting one of those. This avoids replacing often used pages and has been shown to reduce the number of TLB misses in most cases. Certain workloads, particularly those accessing data sequentially where the working set just exceeds the mappable capacity of the non-wired TLB entries, may beneﬁt from having a more random replacement where you sometimes get lucky and ﬁnd a long unused page not yet replaced. For those applications, this function can be disabled by setting

Conﬁg6

= 1, but you are probably better off leaving it alone.

NMRUD

3.8.4 Reading and writing TLB entries - EntryLo0-1, EntryHi and PageMask registers

The TLB is accessed through staging registers which between them represent all the ﬁelds in each TLB entry; they’re called EntryHi, PageMask and EntryLo0-1. The ﬁelds from EntryHi and PageMask are shown in Figure 3.12.

Figure 3.12 Fields in the EntryHi and PageMask registers

31 29 28 13 12 8 7 0

EntryHi

PageMask

0 Mask 0

VPN2 0 ASID

All these ﬁelds act as staging posts for entries being written to or read from the TLB. But some of them are more magic than that...

EntryHi[VPN2]: is the page-pair address to be matched by the entry this reads/writes - see above.

However, on a TLB-related exception VPN2 is automagically set to the virtual address we were trying to translate when we got the exception. If - as is most often the case - the outcome of the exception handler is to ﬁnd and install a translation to that address, VPN2 (and generally the whole of EntryHi) will turn out to already have the right values in it.

EntryHi[ASID]: does double-duty. It is used to stage data to and from the TLB, but in normal running software it’s also

the source of the current "ASID" value, used to extend the virtual address to make sure you only get translations for the current process.

49 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.8 The TLB and translation

PageMask[Mask]

: acts as a kind of backward mask, in that a 1 bit means "don’t compare this address bit when matching

this address". However, only a restricted range of PageMask values are legal (that’s with "1"s ﬁlling the

PageMask[Mask] ﬁeld from low bits upward, two at a time):

PageMask Size of each output page PageMask Size of each output page 0x0000.0000 4Kbytes 0x007F.E000 4Mbytes 0x0000.6000 16Kbytes 0x01FF.E000 16Mbytes 0x0001.E000 64Kbytes 0x07FF.E000 64Mbytes 0x0007.E000 256Kbytes 0x1FFF.E000 256Mbytes 0x001F.E000 1Mbyte

Note that the uTLBs handle only 4Kbyte and 16Kbyte page sizes; other page sizes are down-converted to 4Kbyte or 16Kbyte as they are referenced. For other page sizes this may cause an unexpectedly high rate of uTLB misses, which could be noticeable in unusual circumstances.

Then moving our attention to the output side, the two EntryLo0-1 are identical in format as shown in Figure 3.13.

Figure 3.13 Fields in the EntryLo0-1 registers

31 30 29 6 5 3 2 1 0

0 PFN C D V G

In EntryLo0-1:

PFN: the "physical frame number" - traditional OS name for the high-order bits of the physical address. 24 bits of PFN

together with 12 bits of in-page address make up a 36-bit physical address; but the 74K core has a 32-bit physical address bus, and does not implement the four highest bits (which always read back as zero).

C: a code indicating how to cache data in this page - pages can be marked uncacheable and various ﬂavours of cache-

able. The codes here are shared with those used in CP0 registers for the cacheability of ﬁxed address regions: see

Table 3.3 in Section 3.4.2, "Cacheability options" on page 33 .

D: the "dirty" ﬂag. In hardware terms it’s just a write-enable (when it’s 0 you can’t do a store using addresses translated

here, you’ll get an exception instead). However, software can use it to track pages which have been written to; when you ﬁrst map a page you leave this bit clear, and then a ﬁrst write causes an exception which you note somewhere in the OS’ memory management tables (and of course remember to set the bit).

V: the "valid" ﬂag. You’d think it doesn’t make much sense - why load an entry if it’s not valid? But this is very helpful

so you can make just one of a pair of pages valid.

G: the "global" bit. This really belongs to the input side, and there aren’t really two independent values for it. So you

should always make sure you set EntryLo0[G] and EntryLo1[G} the same.

3.8.5 TLB initialization and duplicate entries

TLB entries come up to random values on power-up, and must be initialized by hardware before use. Generally,early bootstrap software should go through setting each entry to a harmless “invalid” value.

Since the TLB is a fully-associative array and entries are written by index, it’spossible to load duplicate entries - two or more entries which match the same virtual address/ASID. In older MIPS CPUs it was essential to avoid duplicate entries - even duplicate entries where all the entries are marked “invalid”. Some designs could even suffer hardware

Programming the MIPS32® 74K™ Core Family, Revision 02.14 50

Memory map, caching, reads, writes and translation

damage from duplicates. Because of the need to avoid duplicates, even initialization code ought to use a different virtual address for each invalid entry; it’s common practice to use “kseg0” virtual addresses for the initial all-invalid entries.

Most MIPS Technologies cores protect themselves and you by taking a “machine check” exception if a TLB update would have created a duplicate entry Some earlier MIPS Technologiescores suffer a machine check even if duplicate entries are both invalid. That can happen when initializing. For example, when an OS is initializing the TLB it may well re-use the same entries as already exist - perhaps the ROM monitor already initialized the TLB, and (derived from the same source code) happened to use the same dummy addresses. If you do that, your second initialization run will cause a machine check exception. The solution is for the initializing routine to check the TLB for a matching entry (using the tlbp instruction) before each update.

For portability you should probably include the probe step in initialization routines: it’s not essential on the 74K core, where we repeat that the machine check exception doesn’t happen.

3.8.6 TLB exception handlers — BadVaddr, Context, and ContextConﬁg registers

These three registers are provided mainly to simplify TLB reﬁll handlers.

BadVAddr is a plain 32-bit register which holds the virtual address which caused the last address-related exception,

and is read-only. It is set for the following exception types only: Address error (AdEL or AdES), TLB/XTLB Reﬁll, TLB Invalid (TLBL, TLBS) and TLB Modiﬁed (for more on exception codes in Cause[ExcCode], see the notes to

Table B.5.)

Context contains the useful mix of pre-programmed and borrowed-from-BadVAddr bits shown in Figure 3.14.

Figure 3.14 Fields in the Context register when Conﬁg3

31 23 22 43 0

PTEBase BadVPN2 0

Context[PTEBase,BadVPN2]: the PTEBase ﬁeld is just software-writable and readable, with no hardware effect.

=0 and Conﬁg3SM=0

CTXTC

The PTEBase ﬁeld is for use by the operating system and is normally written with a value that allows the operating system to use the Context Register as a pointer into the current PTE array in memory.The ﬁeld has no direct hardware effect. The BadVPN2 ﬁeld is written by hardware on a TLB exception. It contains bits VA

of the virtual address

31..13

that caused the exception.

In a preferred scheme for software management of page tables, PTEBase can be set to the base address of a (suitably aligned) page table in memory; then the BadVPN2 number (see below) comes from the virtual address associated with the exception—-it’s just bits from BadVAddr, repackaged. In this case the virtual address bits are shifted such that each ascending 8Kbyte translation unit generates another step through a page table (assuming that each entry is 2 x 32-bit words in size — reasonable since you need to store at least the two candidate EntryLo0-1 values in it).

An OS which can accept a page table in this format can contrive that in the time-critical simple TLB reﬁll exception,

Context automagically points to the right page table entry for the new translation.

This is a great idea, but modern OS’ tend not to use it — the demands of portability mean it’s too much of a stretch to bend the page table information to ﬁt this model.

51 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.8 The TLB and translation

If Conﬁg3

=0 and Conﬁg3SM=0, then the Context register is organized in such a way that the operating system

CTXTC

can directly reference a 16-byte structure in memory that describes the mapping. For PTE structures of other sizes, the content of this register can be used by the TLB reﬁll handler after appropriate shifting and masking.

If Conﬁg3 VA

31..13

of the virtual address to be written into the BadVPN2 ﬁeld of the Context register. The PTEBase ﬁeld is writ-

=0 and Conﬁg3SM=0 then a TLB exception (TLB Reﬁll, TLB Invalid,or TLB Modiﬁed) causes bits

CTXTC

ten and used by the operating system.

BadVPN2 ﬁeld of the Context register is not deﬁned after an address error exception and this ﬁeld may be modi-

The ﬁed by hardware during the address error exception sequence.

Figure 3.14 shows the format of the Context Register when Conﬁg3

Conﬁg3

=1 or Conﬁg3SM=1 then the pointer implemented by the Context register can point to any power-of-

CTXTC

=0 and Conﬁg3SM =0.

CTXTC

two-sized PTE structure within memory.This allows the TLB reﬁll handler to use the pointer without additional shifting and masking steps. Depending on the value in the ContextConﬁg register, it may point to an 8-byte pair of 32-bit PTEs within a single-level page table scheme, or to a ﬁrst level page directory entry in a two-level lookup scheme.

If Conﬁg3

=1 or Conﬁg3SM=1 then the a TLB exception (Reﬁll, Invalid,or Modiﬁed) causes bits VA

CTXTC

X+9:Y+9

be written to a variable range of bits “(X-1):Y” of the Context register, where this range corresponds to the contiguous range of set bits in the ContextConﬁg register. Bits 31:X are R/W to software, and are unaffected by the exception. Bits Y-1:0 will always read as 0. If X = 23 and Y = 4, i.e. bits 22:4 are set in ContextConﬁg, the behavior is identical to the standard MIPS32 Context register (bits 22:4 are ﬁlled with VA

). Although the ﬁelds have been made vari-

31:13

able in size and interpretation, the MIPS32 nomenclature is retained. Bits 31:X are referred to as the PTEBase ﬁeld, and bits X-1:Y are referred to as BadVPN2.

The value of the Context register is UNPREDICTABLE following a modiﬁcation of the contents of the

ContextConﬁg register.

Figure 3.15 shows the format of the Context Register when Conﬁg3

Figure 3.15 Fields in the Context register when Conﬁg3

31 X X-1 Y Y-1 0

PTEBase BadVPN2 0

=1 or Conﬁg3SM =1.

CTXTC

=1 or Conﬁg3SM=1

CTXTC

The ContextConﬁg register deﬁnes the bits of the Context register into which the high order bits of the virtual address causing a TLB exception will be written, and how many bits of that virtual address will be extracted. Bits above the selected of the Context register are R/W to software and serve as the PTEBase ﬁeld. Bits below the selected ﬁeld of the Context register will read as zeroes.

The ﬁeld to contain the virtual address index is deﬁned by a single block of contiguous non-zero bits within the

ContextConﬁg register’s VirtualIndex ﬁeld. Any zero bits to the right of the least signiﬁcant one bit cause the corre-

sponding Context register bits to read as zero. Any zero bits to the left of the most signiﬁcant one bit cause the corresponding Context register bits to be R/W to software and unaffected by TLB exceptions.

A value of all ones in the ContextConﬁg register means that the full 32 bits of the faulting virtual address will be copied into the context register, making it duplicate the BadVAddr register. A value of all zeroes means that the full 32 bits of the Context register are R/W for software and unaffected by TLB exceptions.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 52

Memory map, caching, reads, writes and translation

The ContextConﬁg register is optional and its existence is denoted by the Conﬁg3

or Conﬁg3SMregister ﬁelds.

CTXTC

Figure 3.16 shows the formats of the ContextConﬁg Register.

Figure 3.16 Fields in the ContextConﬁg register

31 0

VirtualIndex

VirtualIndex is a mask of 0 to 32 contiguous 1 bits that cause the corresponding bits of the Context register to be writ-

ten with the high-order bits of the virtual address causing a TLB exception. Behavior of the processor is UNDEFINED if non-contiguous 1 bits are written into the register ﬁeld.

It is permissible to implement a subset of the ContextConﬁg register, in which some number of bits are read-only and set to one or zero as appropriate. It is possible for software to determine which bits are implemented by alternately writing all zeroes and all ones to the register, and reading back the resulting values. Table 3.7 describes some useful

ContextConﬁg values.

Table 3.7 Recommended ContextConﬁg Values

Page Table

Value

0x00000000007ffff0 Single Level 4K 64 bits/page REQUIRED 0x00000000003ffff8 Single Level 4K 32 bits/page RECOMMENDED 0x00000000007ffff8 Single Level 2K 32 bits/page RECOMMENDED

0x0000000000fffff8 Single Level 1K 32 bits/page RECOMMENDED

Organization Page Size PTE Size Compliance

53 Programming the MIPS32® 74K™ Core Family, Revision 02.14

3.8 The TLB and translation

Programming the MIPS32® 74K™ Core Family, Revision 02.14 54

Chapter 4

Programming the 74K™ core in user mode

This chapter is not very long, because in user mode one MIPS32-compliant CPU looks much like another. But not everything — sections include:

• Section 4.1, "User-mode accessible “Hardware registers”"

• Section 4.2, "Prefetching data": how it works.

• Section 4.3, "Using “synci” when writing instructions": writing instructions without needing to use privileged cache management instructions.

• Section 4.4, "The multiplier": multiply, multiply/accumulate and divide timings.

• Section 4.5, "Tuning software for the 74K‘ family pipeline": for determined programmers, and for compiler writers. It includes information about the timing of the DSP ASE instructions.

• Section 4.6 “Tuning floating-point”: the ﬂoating-point unit often runs at half speed, and some of its interactions (particularly about potential exceptions) are complicated. This section offers some guidance about the timing issues you’ll encounter.

4.1 User-mode accessible “Hardware registers”

The 74K core complies with Revision 2 of the MIPS32 speciﬁcation, which introduces hardware registers; CPU- dependent registers which are readable by unprivileged user space programs, usually to share information which is worth making accessible to programs without the overhead of a system call.

The hardware registers provide useful information about the hardware, even to unprivileged (user-mode) software, and are readable with the rdhwr instruction. [MIPS32] deﬁnes four registers so far. The OS can control access to each register individually, through a bitmask in the CP0 register HWREna - (set bit 0 to enable register 0 etc).

HWREna is cleared to all-zeroes on reset, so software has to explicitly enable user access — see Section 5.6 “The

HWREna register - Control user rdhwr access”. Privileged code can access any hardware register.

The ﬁve standard registers are:

• CPUNum (0): Number of the CPU on which the program is currently running. This comes directly from the coprocessor 0 EBase[CPUNum] ﬁeld.

• SYNCI_Step (1): the effective size of an L1 cache line14; this is now important to user programs because they can now do things to the caches using the synci instruction to make instructions you’ve written visible for execution. Then SYNCI_Step tells you the “step size” - the address increment between successive synci’s required to cover all the instructions in a range.

14. Strictly, it’s the lesser of the I-cache and D-cache line size, but it’s most unusual to make them different.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 55

If SYNCI_Step returns zero, that means that your hardware ensures that your caches are instruction/data coherent, and you don’t need to use synci at all.

• CC (2): user-mode read-only access to the CP0 Count register, for high-resolution counting. Which wouldn’t be much good without.

• CCRes (3): which tells you how fast Count counts. It’s a divider from the pipeline clock — if the rdhwr instruction reads a value of “2”, then Count increments every 2 cycles, at half the pipeline clock rate.For 74K family cores that is precisely what you will read.

• UL (30): user-mode read-only access to the CP0 UserLocal register.Thisregistercan be used to provide a thread identiﬁer to user-mode programs. See Section C.4.2 “The UserLocal register” for more details

4.2 Prefetching data

MIPS32 CPUs are being increasingly used for computations which feature loops accessing large arrays, and the runtime is often dominated by cache misses.

4.2 Prefetching data

These are excellent candidates for using the CPUs other state. In a well-optimized loop with prefetch, data for the next iteration can be fetched into the cache in parallel with computation for the last iteration.

It’s a pretty major principle that pref should have no software-visible effect other than to make things go faster.

pref is logically a no-op

The pref instruction comes with various possible “hints” which allow the program to express its best guess about the likely fate of the cache line. In 74K family cores the “load” and “store” variants of the hints do the same thing; but it makes good sense to use the hint which matches your program’sintention - you might one day port it to a CPU where it makes a difference, and it can’t do any harm.

The 74K core acts on hints as summarized in Table 4.1.

pref instruction, which gets data into the cache without affecting the

4.3 Using “synci” when writing instructions

The synci instruction (introduced with Revision 2 of the MIPS32 architecture speciﬁcation, [MIPS32]) ensures that instructions written by a program (necessarily through the D-cache, if you’re running cached) get written back from the D-cache and corresponding I-cache locations invalidated, so that any future execution at the address will reliably execute the new instructions. synci takes an address argument, and it takes effect on a whole enclosing cache-line sized piece of memory.User-level programs can discover the cache line size because it’savailable in a “hardware registers” accessed by rdhwr, as described in Section 4.1, "User-mode accessible “Hardware registers”" above.

Since synci is modifying the program’s own instruction stream, it’s inherently an “instruction hazard”: so when you’veﬁnishedwriting your instructions and issued the last synci, you should then use a jr.hb or equivalentto call the new instructions — see Section 5.1 “Hazard barrier instructions”.

15. This isn’t quite true any more; pref with the “PrepareForStore” hint can zero out some data which wasn’t previously zero.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 56

Programming the 74K™ core in user mode

Table 4.1 Hints for “pref” instructions

Hint What happens in the 74K core Why would you use it?

No Name

0 load Read the cache line into the D-cache if 1 store

4 load_streamed Fetch data, but always use cache way 5 store_streamed

6 load_retained Fetch data, but never use cache way 7 store_retained

25 writeback_invalidate/

nudge

30 PrepareForStore If the line is not in the cache, create a

31 PrepareForStoreNZ As type 30 above, except that the line is

not present.

zero - so a large sequence of “streamed” prefetches willonlyever useaquarter of the cache.

zero. That means if you do a mixture of “streamed” and “retained” operations, they will not displace each other from the cache.

If the line is in the cache, invalidate it (writing it back ﬁrst if it was dirty). Otherwise do nothing. However (with the 74K core only): if this line is in a region marked for “uncached accelerated write” behavior, then write-back this line.

cache line - but instead of reading it from memory, ﬁll it with zeroes and mark it as “dirty”. If the line is already in the cache do nothing - this operationcannotberelied upon to zero the line.

not ﬁlled with zeroes.

When you expect to read the data soon. Use “store” hint if you also expect to modify it.

For data you expect to process sequentially,andcan affordtodiscard from the cache once processed

For data you expect to use more than once, and which may be subject to competition from “streamed” data.

When you know you’ve ﬁnished with the data, and want to make sure it loses in any future competition for cache resources.

When you know you will overwrite the whole line, so reading the old data from memory is unnecessary. A recycled line is zero-ﬁlled only because its former contents could have belonged to a sensitive application allowing them to be visible to the new owner would be a security breach.

Yields the highest possible performance when you’re going to overwrite the whole line. However, this is at the cost of a security leak: a user-mode application which uses this prefetch can (somewhat randomly) obtain a view of kernel or other-process memory data it should not be able to see. An OS can make this instruction safe (same as pref 30 above) bykeepingConﬁg7[FPFS] zero — see Figure B.3 and notes.

4.4 The multiplier

As is traditional with MIPS CPUs, the integer multiplier is a semi-detached unit with its own pipeline. All MIPS32 CPUs implement:

• mult/multu:a32×32 multiply of two GPRs (signed and unsigned versions) with a 64-bit result delivered in the multiply unit’s pseudo-registers hi and lo (readable only using the special instructions mfhi and mflo, which are interlocked and stall until the result is available).

• madd, maddu, msub, msubu: multiply/accumulate instructions collecting their result in hi/lo.

• mul/mulu: simple 3-operand multiply as a single instruction.

57 Programming the MIPS32® 74K™ Core Family, Revision 02.14

4.5 Tuning software for the 74K™ family pipeline

• div/divu: divide - the quotient goes into lo and the remainder into hi.

Many of the most powerful instructions in the MIPS DSP ASE are variants of multiply or multiply-accumulate operations, and are described in Chapter 9, “The MIPS32® DSP ASE” on page 121Chapter 7, “The MIPS32® DSP ASE”

on page 87. The DSP ASE also provides three additional “accumulators” which behave like the hi/lo pair).

No multiply/divide operation ever produces an exception - even divide-by-zerois silent - so compilers typically insert explicit check code where it’s required.

The 74K core multiplier is high performance and pipelined; multiply/accumulate instructions can run at a rate of 1 per clock, but a 32×32 3-operand multiply takes six clocks longer than a simple ALU operation. Divides use a bit-perclock algorithm, which is short-cut for smaller dividends. Multiply/divide instructions are generally slow enough that it is difﬁcult to arrange programs so that their results will be ready when needed.

4.5 Tuning software for the 74K™ family pipeline

This section is addressed to low-level programmers who are tuning software by hand and to those working on efﬁcient compilers or code translators.

74K family cores have a complex out-of-order pipeline, which makes ﬁne-grain instruction interactions very difﬁcult to summarize. See Section 1.4 “A brief guide to the 74K‘ core implementation” for a reasonably accurate picture of the basic pipeline, from which you will be able to foresee some effects. We hope that a later version of this manual may be able to be more helpful, but with a complex out-of-order CPU like this one you will always get more insight from running code on a real CPU or a cycle-accurate simulator.

4.5.1 Cache delays and mitigating their effect

In a typical 74K CPU implementation a cache miss which has to be reﬁlled from DRAM memory (in the very next chip on the board) will be delayed by a period of time long enough to run 50-200 instructions. A miss or uncached read (perhaps of a device register) may easily be several times slower. These really are important!

Because these delays are so large, there’s not a lot you can do to help a cache-missing program make progress. But every little bit helps. The 74K core has non-blocking loads, so if you can move your load instruction producer away from its consumer, you won’t start paying for your memory delay until you try to run the consuming instruction.

Compilers and programmers ﬁnd it difﬁcult to move fragments of algorithm backwards like this, so the architecture also provides prefetch instructions (which fetch designated data into the D-cache, but do nothing else). Because they’refree of most side-effects it’s easier to issue prefetches very early.Any loop which walks predictably through a large array is a candidate for prefetch instructions, which are conveniently placed within one iteration to prefetch data for the next.

The pref PrepareForStore prefetch saves a cache reﬁll read, for cache lines which you intend to overwrite in their entirety. Read more about prefetch in Section 4.2, "Prefetching data" above.

Tuning data-intensive common functions

Bulk operations like bcopy() and bzero() will beneﬁt from CPU-speciﬁc tuning. To get excellent performance for in-cache data, it’s only necessary to reorganize the software enough to cover the address-to-store and load-to-use delays. But to get the loop to achieve the best performance when cache missing, you probably want to use some prefetches. MIPS Technologies may have example code of such functions — ask.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 58

Programming the 74K™ core in user mode

4.5.2 Branch delay slot

It’s a feature of the MIPS architecture that it always attempts to execute the instruction immediately following a branch. The rationale for this is that it’s extremely difﬁcult to fetch the branch target quickly enough to avoid a delay, so the extra instruction runs “for free”...

Most of the time, the compiler deals well with this single delay slot. MIPS low-level programmers ﬁnd it odd at ﬁrst, but you get used to it!

4.6 Tuning ﬂoating-point

It seemed to make more sense to put this information into the FPU chapter: read from Section 6.5 “FPU pipeline and

instruction timing”.

59 Programming the MIPS32® 74K™ Core Family, Revision 02.14

4.7 Branch misprediction delays

In a long-pipeline design like this, branches would be expensive if you waited until the branch was executed before fetching any more instructions. See Section 1.4 “A brief guide to the 74K‘ core implementation” for what is done about this: but the upshot is that where the fetch logic can’t compute the target address, or guesses wrong, that’sgoing to cost 12 or more lost cycles (since when we’re not blocked on a cache miss we hope to average substantially more than one instruction per clock, that’sworse than it sounds). It does depend what sort of branch: the conditional branch which closes a tight loop will almost always be predicted correctly after the ﬁrst time around.

However, too many branches in too short a period of time can overwhelm the ability of the instruction fetch logic to keep ahead with its predictions, evenif the predictions are almost always right. Three empty cycles occur between the deliveryof the branch delay slot instruction and the ﬁrst instruction(s) from the branch target location. Where branchy code can be replaced by conditional moves or tight loops “unrolled” a little to get at least 6-8 instructions between branches, you’ll get signiﬁcant beneﬁts.

The branch-likely instructions deprecated by the MIPS32 architecture document are predicted just like any other branch. Misprediction of branch-likelies costs an extra cycle or two, because the branch and the delay slot instruction needs to be re-executed after a mispredict. Branch-likely instructions sometimes improve the performance of small loops on 74K family cores, but they set problems for the designers of complex CPUs, and may one day disappear from the standard. Good compilers for the MIPS32 architecture should provide an option to avoid these instructions.

4.7 Branch misprediction delays

4.8 Load delayed by (unrelated) recent store

Load instructions are handled within the execution unit (the AGEN pipeline) with “standard” timing, just so long as they hit in the cache. When a load misses (or, handled the same way, turns out to be uncached) then a dependent operation which has already been issued will have to be replayed if the dependent instruction has been dispatched. That generates long delays, but you already know about that. If the dependent instruction has not been dispatched at all then it will wait in the DDQ until the load data becomes available.

However, store instructions are graduated before they are completed — which sounds problematic, but in fact you can’t afford to let instructions write the cache (or commit a write to real memory) until they graduate and cease to be speculative.

This presents a problem. A programmer may write code which stores a value in memory, then immediately loads the same value. The CPU pipeline detects circumstances where instructions are dependent for register values, but cannot go doing the same for addresses. The load can get the right data from an incomplete store as a side-effect of checking whether the data we want might be in the FSB (the “ﬁll/store buffer”) attached to the D-cache: see Section

3.3.1 “Read/write ordering and cache/memory data queues in the 74K‘ core” for more information. The store data

can also be in intermediate stages/queues before being written into the FSB. Any data that matches stores in such intermediate queues will also be bypassed back to the pipeline as if the load hit in the cache.

4.9 Minimum load-miss penalty

74K family cores will typically run at high frequencies, so any load which misses in the L1 D-cache is likely to be substantially delayed, waiting for the memory data to come back. However, if you ever use the core with a very fast memory, it’s worth observing that even a fast-serviced miss is still a serious event. If an instruction which consumes the loaded data issues before we’re sure the load missed (and most of the time the consumer will only be a few places behind in instruction sequence, and will have issued), then that instruction will have to be re-executed by stopping execution and starting again on the consuming instruction. That means it has to be re-fetched from the I-cache, and involves a delay of 15 cycles or so.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 60

4.10 Data dependency delays

The 74K core’s out-of-order pipeline does a very good job of running dependent instructions as soon as possible, in hardware. So to some extent it makes it unnecessary to manage data delays by moving instructions around in the program sequence (and if you feel you should try, it makes it tricky to predict the effect of your tuning). Ideally, you should use an instrumented real CPU or cycle-accurate simulator to get insight into detailed tuning effects.

Compilers might reasonably try to schedule code to create more opportunities for dual-issue and so that instructions might be issued at full speed despite dependencies, but should rarely do so if the cost is signiﬁcant — the hardware is already gaining much of this advantage within its out-of-order window (think of it as looking 7-15 instructions ahead in the program sequence), and compiler scheduling will not be worth many extra instructions or signiﬁcant code bloat unless it reaches beyond such a window. Loop unrolling will often help, but local scheduling will be unlikely to make a lot of difference.

We’ve attempted to tabulate all possible producer/consumer delays affecting user-level code (we’re not discussing CP0 registers here), but excluding ﬂoating point (which is in the next section). These are just ﬁxed delays, of course: if a load misses in the cache, that’s different (and there are notes about it, above).

The MIPS instruction set is efﬁcient for short pipelines because, most of the time, dependent instructions can be run nose-to-tail, just one clock apart, without extra delay. Even in the more sophisticated 74K family CPUs, most dependent instructions can run just two clocks apart. Each register has a “standard” place in the pipeline where the producer should deliver its value and another place in the pipeline where the consumer picks it up: where those places are 1 cycle apart, the dependent instructions to run in successive cycles. Producer/consumer delays happen when either the producer is late delivering a result to the register (a “lazy producer”), or the consumer insists on obtaining its operand early (an “eager consumer”). If a lazy producer feeds an eager consumer, the delays add up.

Most of these delays are hidden by out-of-order execution. Moreover, non-dependent ALU and AGEN instructions may be issued simultaneously, so sometimes even a delay of zero cycles is painful.

Different register classes are read/written in different “standard” pipeline slots, so it’simportant to be clear what class of registers is involved in any of these delays. For non-ﬂoating-point user-level code, there are just three:

• General purpose registers (“GPR”).

• The multiply unit’s DSP ASE (“ACC”).

The MIPS architecture encourages implementations to provide integer multiply and divide operations in a separately-pipelined unit (see Section 4.4 “The multiplier”), and in 74K family cores this unit is capable of doing multiply-accumulate operations at a rate of one per clock. No multiply unit operation ever causes an exception, which makes the longer multiply-unit pipeline rather invisible. It shows up in late delivery of GPR values by those few multiply-unit instructions which deliver GPR results.

• The ﬁelds of the DSPControl register, used for condition codes and exceptional conditions resulting from DSP ASE operations.

So that gives us two tables: Table 4.2 for our eager consumers, and Table 4.3 for the producers (we’ve listed even the non-lazy producers, since there aren’t very many of them).

hi/lo pair together with the three additional multiply-unit accumulators deﬁned by the MIPS

61 Programming the MIPS32® 74K™ Core Family, Revision 02.14

4.10 Data dependency delays

Table 4.2 Register → eager consumer delays

Reg → Eager consumer Del Applies when...

GPR → load/store 1 the GPR value is an address operand. Store data is

not needed early.

ACC → multiply instructions 3 the ACC value came from any multiply instruction

which saturates the accumulator value.

ACC → DSP instructions which extract selected

bits from an accumulator:

extp...,

extr... etc.

DSP instructions which write a shifted value back to the accumulator:

mthlip,

shilo, shilov.

3 Always

Programming the MIPS32® 74K™ Core Family, Revision 02.14 62

Table 4.3 Producer → register delays

Lazy producer → Reg Del Applies when...

All bitwise logical instructions, including

immediate versions

lui

addu rd,rs,$0 (add zero, aka mov)

sll with shift amount 8 or less

srl with shift amount 25 or more

set-on-condition (slt, slti, sltiu,

sltu)

seb, seh

add, addu, addi, addiu

Any other ALU instruction

Non-multiply DSP ASE instructions which

don’t saturate.

DSP “ALU” instructions (which neither

read nor write an accumulator, nor do a

multiplication), but do saturate.

Conditional move movn, movz → GPR 3 Run in the AGEN pipeline. They create trouble

Any load → GPR 2 That’s a cached load which hits, of course.

sc (store conditional) → GPR 8 The GPR is receiving the success/failure code. The

Integer multiply instructions producing a

GPR result (mul, mulu etc).

Instructions reading accumulators and

writing GPR (e.g.

mflo).

div /divu → ACC 10-20 dividend 255 or less

These instructions only are “not lazy”: their result can be used in the next cycle by any ALU instruc-

→ GPR

→ GPR 2 Always

→ GPR

tion. Note that addu rd,rs,$0 is used for mov.Results from add, addi, addi and addiu are

available to consumers in ALU pipe with 0 delay. Consumers in AGEN pipe will see a delay of 1.

2-beat ALU for all but the simplest operations

because theyimplicitlyhave three registeroperands (the “no-move” case is handled by reading the original value of the destination register and writing it back) — but in 74K cores an instruction may only use two read ports in the register ﬁle. So a conditional move instruction is issued in two consecutive clock phases: one to do the move, one to fetch the original value and write it back again. That makes sure that the right value is available in the CB entry and the pipeline by-passes.

instruction which consumes this code is not issued until the store has graduatedandbeenacted on. The delay could be longer if there is work queued up in the load/store pipe, but in the normal ll/sc busy loop the dependency on the ll load will have left the pipe idle.

Always (because the multiply unit pipeline is longer than the integer unit’s).

10-50 dividend 256 or more

63 Programming the MIPS32® 74K™ Core Family, Revision 02.14

4.10 Data dependency delays

How to use the tables

Suppose we’ve got an instruction sequence like this one:

addiu $a0, $a0, 8 lw $t0, 0($a0) # [1] lw $t1, 4($a0) addu $t2, $t0, $t1# [2] mul $v0, $t2, $t3 sw $v0, 0($a1) # [3]

Then a look at the tables should help us discover whether any instructions will be held up. Look at the dependencies where an instruction is dependent on its predecessor:

[1] The lw will be held up by two clocks. One clock because addiu takes 2 clocks to produce its result, and another

because its GPR address operand $a0 was computed by the immediately preceding instruction (see the “load/store address” box of Table 4.2.) The second lw will be OK.

[2] The addu will be two clocks late, because the load data from the preceding lw arrives late in the GPR

$t1 (see the

“load” box of Table 4.3.)

[3] The sw will be 6 clocks late starting while it waits for a result from the multiply pipe (the “multiply” box of Table

4.3.)

These can be additive. In the pointer-chasing sequence:

lw $t1, 0($t0) lw $t2, 0($t1)

The second load will be held up three clocks: two because of the late delivery of load data in $t1 (“load” box of

Table 4.3), plus another because that data is required to form the address (“load/store address” box of Table 4.2.)

Delays caused by dependencies on DSPControl ﬁelds

Some DSP ASE instructions are dependent because they produce and consume values kept in ﬁelds of the

DSPControl register. However, the most performance-critical of these dependencies are “by-passed” to make sure no

delay will occur - those are the dependencies between:

addsc cmp.x wrdsp

→ DSPControl[c] → → DSPControl[ccond] → → DSPControl[pos,scount] →

addwc pick.x insv

But other dependencies passed in DSPControl may cause delays; in particular the DSPControl[ouflag] bits set by various kinds of overﬂow are not ready for a succeeding rddsp instruction. The access is interlocked, and will lead to a delay of up to three clocks. We don’t expect that to be a problem (but if you know different, please get in touch with MIPS Technologies).

4.10.1 More complicated dependencies

There can be delays which are dependent on the dynamic allocation of resources inside the CPU. In general you can’t really ﬁgure out how much these matter by doing a static code analysis, and we earnestly advise you to get some kind of high-visibility cycle-accurate simulator or trace equipment.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 64

4.11 Advice on tuning instruction sequences (particularly DSP)

DSP algorithm functions are often the subject of intense tuning. There is some speciﬁc and helpful advice (with examples) included in the white paper [DSPWP] published by MIPS Technologies.

But you need to know the basic latencies of instructions as executed by the 74K core (that is, how many cycles later can a dependent instruction be issued). For these purposes there are four classes of instructions:

• A group of specially-simple ALU instructions run in one cycle. This includes bitwise logical instructions, (an alias for addu with $0), shifts up to 8 positions down or up, test-and-set instructions, and sign-extend instructions. See the list at the top of Table 4.3.

• Simple DSP ASE operations (no multiply, no saturation) have 2-cycle latency, the same as most regular MIPS32 arithmetic.

• Non-multiply DSP instructions which feature saturation or rounding have 3-cycle latency.

• Special DSP multiply operations (or any other access to the multiply unit accumulators): these have timings like standard multiply and multiply-accumulate instructions, so they’re in with the multiply operations under the next heading.

• Instruction dependencies relating to different ﬁelds in the DSPControl register are tracked separately, and efﬁciently,as if they were separate registers. But any rddsp or wrdsp instruction which reads/writes multiple ﬁelds at once is dependent on multiple ﬁelds, and that can’t be tracked through the CB system. Such a rddsp is not issued until all predecessors have graduated, and such a wrdsp must graduate before its successors can issue. You can often avoid this by using the “masked” versions of these instructions to read or write only the ﬁeld you’re particularly interested in.

4.12 Multiply/divide unit and timings

As is traditional with MIPS CPUs, the integer multiplier is a semi-detached unit with its own pipeline. All MIPS32 CPUs implement:

mov

• mult/multu: multiply two 32-bit numbers from GPRs (signed and unsigned versions) with a 64-bit result delivered in the multiply unit’s accumulator. The accumulator was traditionally seen as pseudo-registers hi and lo, readable only using the special instructions mfhi and mflo.Operations into the accumulator do not hold up the main CPU and run independently, but mfhi/mflo are interlocked and delay execution as required until the result is available.

• madd, maddu, msub, msubu: multiply/accumulate instructions collecting their result in the accumulator.

• mul/mulu: simple 3-operand multiply as a single instruction.

• div/divu: divide - the quotient goes into lo and the remainder into hi.

Many of the most powerful instructions in the MIPS DSP ASE are variants of multiply or multiply-accumulate operations, and are described in Chapter 7, “The MIPS32® DSP ASE” on page 87. The DSP ASE also provides three additional “accumulators” which behave like the hi/lo pair: the now four accumulators are called ac0-3). When we talk about the “multiply/divide” group of instructions we include any instruction which reads or writes any accumulator.

65 Programming the MIPS32® 74K™ Core Family, Revision 02.14

4.12 Multiply/divide unit and timings

No multiply/divide operation ever produces an exception - even divide-by-zero is silent — compilers typically insert explicit check code where it’s required.

Timing varies. Multiply-accumulate instructions (there are many different ﬂavors of MAC in the DSP ASE) have been pipelined and tuned to achieve a 1-instruction-per-clock repeat rate, even for sequences of instructions targeting the same accumulator. But because that requires a relatively long pipeline, multiply/divide unit instructions which produce a result in a GP register are relatively “slow”: for example, an instruction consuming the register value from a mflo will not be issued until at least 7 cycles after the mflo.

Divides are much slower again. All the timings are summarized in Table 4.3.

What that means is that in an instruction sequence like:

mult $1, $2 mflo $3 addu $2, $3, 1

The mflo will be issued 4 cycles after the mult, and the addu will go at least 2 cycles after the mflo. The execution unit may (or may not) be able to ﬁnd other instructions to keep it busy, but each trip through that code sequence will take a minimum of 9 cycles.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 66

Chapter 5

Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture

[MIPS32] tells you how to write OS code which is portable across all compliant CPUs. Most OS code should be

CPU-independent, and we won’t tell you how to write it here. But release 2 of the MIPS32 Speciﬁcation [MIPS32] introduced a few new optional features which are not yet well known, so are worth describing here:

• A better way of managing software-visible pipeline and hardware delays associated with CP0 programming in

Section 5.1, "Hazard barrier instructions".

• New interrupt facilities described in Section 5.2, "MIPS32® Architecture Release 2 - enhanced interrupt

system(s)";

• That led on to Section 5.3.1 “Summary of exception entry points”: where do exceptions go, and what options are available?

• The ability to use one or more extra sets of registers (“shadow sets”) to reduce context-saving overhead in interrupt handlers, in Section 5.4, "Shadow registers".

• How to get at any power-saving features, in Section 5.5, "Saving Power"

• How to control user-privilege access to “hardware registers”, in Section 5.6 “The HWREna register - Control

user rdhwr access”.

5.1 Hazard barrier instructions

When privileged “CP0” instructions change the machine state, you can get unexpected behavior if an effect is deferred out of its normal instruction sequence. But that can happen because the relevant control register only gets written some way down the pipeline, or because the changes it makes are sensed by other instructions early in their pipeline sequence: this is called a CP0 hazard.

Your 74K family core offers you the option of removing many CP0 hazards by setting the Conﬁg7[IHB] option bit as described in the notes to Table B.3. But you might be better off sticking to the rules described in [MIPS32], so your code will run on any compliant CPU: it may be best to see this feature as the way to rescue legacy code.

It’s possible to get hazards in user mode code too, and many of the instructions described here are not solely for kernel-privilege code. But they’re most often met around CP0 read/writes, so they found their way to this chapter.

Traditionally, MIPS CPUs left the kernel/low-level software engineer with the job of designing sequences which are guaranteed to run correctly, usually by padding the dangerous operation with enough nop or ssnop instructions.

From Release 2 of the MIPS32 speciﬁcation this is replaced by explicit hazard barrier instructions. If you execute a hazard barrier between the instruction which makes the change (the “producer”) and the instruction which is sensitive to it (the “consumer”), you are guaranteed that the change will be seen as complete. Hazards can appear when the pro-

Programming the MIPS32® 74K™ Core Family, Revision 02.14 67

5.2 MIPS32® Architecture Release 2 - enhanced interrupt system(s)

ducer affects even the instruction fetch of the consumer - that’s an “instruction hazard” - or only affecting the operation of the consuming instruction (an “execution hazard”). Hazard barriers come in two strengths: ehb deals only with execution hazards, while eret, jr.hb and jalr.hb are barriers to both kinds of hazard.

In most implementations the strong hazard barrier instructions are quite costly, often discarding most or all of the pipeline contents: they should not be used indiscriminately.For efﬁciency you should use the weaker ehb where it is enough. Since some implementations work by holding up execution of all instructions after the barrier, it’s preferable to place the barrier just before the consumer, not just after the producer.

For example you might be updating a TLB entry:

mtc0 Index, t0 # other stuff, if there’s stuff to do ehb tlbwi jr.hb ra

The ehb makes sure that the change to Index has been made before you attempt to write the TLB entry,whichis ﬁne. But updating the TLB might affect how instructions are fetched in mapped space, so you should not return to code which might be running in mapped space until you’ve cleared the “instruction hazard”. That’s dealt with by the jr.hb.

The unconditional hardware interlock between an mtco and an mfco instruction has been removed. An ehb instruction is now required between an MTC0 and a MFC0 instruction type only when there is a CP0 register dependency. This optimization reduces the stall cycles incurred by software TLB reﬁll exception handlers when accessing exception and TLB-related state, The reduction in overhead of handling TLB reﬁll exceptions has a signiﬁcant impact on system performance. For more information, refer to the description of the sync instruction in the 74K™ Software User’s Manual .

Porting software to use the new instructions

If you know your software will only ever run on a MIPS32 Release 2 or higher CPU, then that’s great. But to maintain software which has to continue running on older CPUs:

• ehb is a no-op: on all previous CPUs. So you can substitute an ehb for the last no-op in your sequence of “enough no-ops”, and your software is now safe on all future CPUs which are compliant with Release 2.

• jr.hb and jalr.hb: are decoded as plain jump-register and call-by-register instructions on earlier CPUs. Again, pro- vided you already had enough no-ops for your worst-case older CPU, your system should now be safe on Release 2 and higher CPUs.

5.2 MIPS32® Architecture Release 2 - enhanced interrupt system(s)

The features for handling interrupts include:

• Vectored Interrupt (VI) mode offers multiple entry points (one for each of the interrupt sources), instead of the single general exception entry point.

External Interrupt Controller (EIC) mode goes further, and reinterprets the six core interrupt input signals as a

64-value ﬁeld - potentially 63 distinguished interrupts each with their own entry point (the zero code, of course, is reserved to mean “no interrupt active”).

Programming the MIPS32® 74K™ Core Family, Revision 02.14 68

Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture

Both these modes need to be explicitly enabled by setting bits in the Config3 register; if you don’t do that, the CPU behaves just as the original (release 1) MIPS32 speciﬁcation required.

• Shadow registers - alternate sets of registers, often reserved for interrupt handlers, are described in Section 5.4,

"Shadow registers". Interrupt handlers using shadow registers avoid the overhead of saving and restoring user

GPR values.

• The Cause[TI], Cause[FDCI],and Cause[PCI] bits (see Section B.1.3.1 “The Cause register”) provide a direct indication of pending interrupts from the on-core timer, fast debug channel, and performance counter subsystems (these interrupts are potentially shared with other interrupt inputs, and it previously required system-speciﬁc programming to discover the source of the interrupt and handle it appropriately).

The new interrupt options are enabled by the IntCtl register, whose ﬁelds are shown in Figure 5.1.

Figure 5.1 Fields in the IntCtl Register

31 29 28 26 25 10 9 5 4 0

IPTI IPPCI IPFDCI 0 VS 0

XX X 0 0

IntCtl[IPTI,IPPCI,IPFDCI]: IPTI, IPPCI, and IPFDCI are read-only 3-bit ﬁelds, telling you how internal timer, perfor-

mance counter, and fast debug channel interrupts are wired up. They are relevant in non-vectored and simple-vectored ("VI") interrupt modes, but not if you’re using an EIC interrupt controller.

Read this ﬁeld to get the number of the Cause[IPnn] where the corresponding interrupt is seen. Because

Cause[IP1-0] are software interrupt bits, unconnected to any input, legal values for IntCtl[IPTI], IntCtl[IPPCI] , and IntCtl[IPFDCI] are between 2 and 7.

The timer, performance counter, and fast debug channel interrupt signals are taken out to the core interface and the SoC designer connects them back to one of the core’s interrupt inputs. The SoC designer is supposed to hard-wire some core inputs which show up as the IntCtl[IPTI,IPPCI,IPFDCI] ﬁelds to match.

IntCtl[VS]: is writable to give you software control of the vector spacing; if the value in VS is VS, you will get a spac-

ing of 32 × 2

(VS-1)

bytes.

Only values of 1, 2, 4, 8 and 16 work (to give spacings of 32, 64, 128, 256, and 512 bytes respectively). A value of zero gives a zero spacing, so all interrupts arrive at the same address — the legacy behavior.

5.2.1 Traditional MIPS® interrupt signalling and priority

Before we discuss the new features, we should remind you what was there already. On traditional MIPS systems the CPU takes an interrupt exception on any cycle where one of the eight possible interrupt sources visible in Cause[IP] is active, enabled by the corresponding enable bit in Status[IM], and not otherwise inhibited. When that happens control is passed to the general exception handler (see Table 5.1 for exception entry point addresses), and is recognized by the “interrupt” value in Cause[ExcCode]. All interrupt are equal in the hardware, and the hardware does nothing special if two or more interrupts are active and enabled simultaneously. All priority decisions are down to the software.

Six of the interrupt sources are hardware signals brought into the CPU, while the other two are “software interrupts” taking whatever value is written to them in the Cause register.

69 Programming the MIPS32® 74K™ Core Family, Revision 02.14

5.2 MIPS32® Architecture Release 2 - enhanced interrupt system(s)

The original MIPS32 speciﬁcation adds an option to this. If you set the Cause[IV] bit, the same priority-blind interrupt handling happens but control is passed to an interrupt exception entry point which is separate from the general exception handler.

5.2.2 VI mode - multiple entry points, interrupt signalling and priority

The traditional interrupt system ﬁts with a RISC philosophy (it leaves all interrupt priority policy to software). It’s also OK with complex operating systems, which commonly have a single piece of code which does the housekeeping associated with interrupts prior to calling an individual device-interrupt handler.

A single entry point doesn’t ﬁt so well with embedded systems using very low-level interrupt handlers to perform small near-the-hardware tasks. So Release 2 of the MIPS32 architecture adds “VI interrupt mode” where interrupts are despatched to one of eight possible entry points. To make this happen:

1. Config3[VInt] must be set, to indicate that your core has the vectored-interrupts feature - but all cores in the 74K family have it;

2. You write

Cause[IV] = 1 to request that interrupts use the special interrupt entry point; and:

3. You set IntCtl[VS] non-zero, setting the spacing between successive interrupt entry points.

Then interrupt exceptions will go to one of eight distinct entry points. The bit-number in Cause[IP] corresponding to the highest-numbered active interrupt becomes the “vector number” in the range 0-7. The vector number is multiplied by the “spacing” implied by the OS-written ﬁeld IntCtl[VS] (see above) to generate an offset. This offset is then added to the special interrupt entry point (already an offset of 0x200 from the value deﬁned in EBase) to produce the entry point to be used.

If multiple interrupts are active and enabled, the entry point will be the one associated with the higher-numbered interrupt: in VI mode interrupts are no longer all equal, and the hardware now has some role in interrupt “priority”.

5.2.3 External Interrupt Controller (EIC) mode

Embedded systems have lots of interrupts, typically far exceeding the six input signals traditionally available. Most systems have an external interrupt controller to allow these interrupts to be masked and selected. If your interrupt controller is “EIC compatible” and you use these features, then you get 63 distinct interrupt entry points.

To do this the same six hardware signals used in traditional and VI modes are redeﬁned as a bus with 64 possible values16: 0 means “no interrupt” and 1-63 represent distinct interrupts. That’s “EIC interrupt mode”, and you’re in EIC

mode if you would be in VI mode (see previous section) and additionally the Conﬁg3[VEIC] bit is set. EIC mode is a little deceptive: the programming interface hardly seems to change, but the meaning of ﬁelds change quite a bit.

Firstly,oncethe interrupt bits are grouped the interrupt mask bits in Status[IM] can’t just be bitwise enables any more. Instead this ﬁeld (strictly, the 6 high order bits of this ﬁeld, excluding the mask bits for the software interrupts) is recycled to become a 6-bit Status[IPL] (“interrupt priority level”) ﬁeld. Most of the time (when running application code, or even normal kernel code) Status[IPL] will be zero; the CPU takes an interrupt exception when the interrupt controller presents a number higher than the current value of Status[IPL] on its “bus” and interrupts are not otherwise inhibited.

16. The resulting system will be familiar to anyone who’s used a Motorola 68000 family device (or further back, a DEC PDP/11 or any of its successors).

Programming the MIPS32® 74K™ Core Family, Revision 02.14 70

Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture

As before, the interrupt handler will see the interrupt request number in Cause[IP] bits - see Section B.1.3.1 “The

Cause register”; the six MS of those bits are now relabelled as Cause[RIPL] (“requested IPL”). In EIC mode the soft-

ware interrupt bits are not used in interrupt selection or prioritization: see below. But there’s an important difference;

Cause[RIPL] holds a snapshot of the value presented to the CPU when it decided to take the interrupt, whereas the old Cause[IP] bits simply reﬂected the real-time state of the input signals

When an exception is triggered the new IPL - as captured in Cause[RIPL] - is used directly as the interrupt number; it’s multiplied by the interrupt spacing implied by IntCtl[RS] and added to the special interrupt entry point, as described in the previous section. Cause[RIPL] retains its value until the CPU next takes any exception.

Software interrupts: the two bits in Cause[IP1-0] are still writable, but now become real signals which are fed out of the CPU core, and in most cases will become inputs - presumably low-priority ones - to the EIC-compliant interrupt controller.

In EIC mode the usual association of the internal timer, performance-counter overﬂow, and fast debug channel interrupts with individual bits of Cause[IP] is lost. These interrupts are turned into output signals from the core, and will themselves become inputs to the interrupt controller. Ask your system integrator how they are wired.

5.3 Exception Entry Points

Early versions of the MIPS architecture had a rather simple exception system, with a small number of architectureﬁxed entry points.

But there were already complications. When a CPU starts up main memory is typically random and the MIPS caches are unusable until initialized; so MIPS CPUs start up in uncached ROMmemory space and the exception entry points are all there for a while (in fact, for so long as Status[BEV] is set); these “ROM entry points” are clustered near the

top of kseg1, corresponding to 0x1FC0.0000 physical18, which must decode as ROM.

ROM is slow and rigid; handlers for some exceptions are performance-critical, and OS’ want to handle exceptions without relying on ROM code. So once the OS boots up it’s essential to be able to redirect OS-handled exceptions into cached locations mapped to main memory (what exceptions are not OS-handled? well, there are no alternate entry points for system reset, NMI, and EJTAG debug).

So when Status[BEV] is ﬂipped to zero, OS-relevant exception entry points are moved to the bottom of kseg0, starting from 0 in the physical map. The cache error exception is an exception... it would be silly to respond to a cache error by transferring control to a cached location, so the cache error entry point is physically close to all the others, but always mapped through the uncached “kseg1” region.

In MIPS CPUs prior to the MIPS32 architecture (with a few infrequent special cases) only common TLB miss exceptions got their own entry point; interrupts and all other OS-handled exceptions were all funneled through a single “general” exception entry point.

The MIPS32® architecture: interrupts get their own entry point

Embedded systems often make heavy use of interrupts and the OS may be less centralized; so MIPS32 CPUs allow you to redirect all interrupts to a new “special interrupt” entry point; you just set a new bit in the Cause register,

Cause[IV] — see Section B.1.3 “Exception control: Cause and EPC registers”.

17. Since the incoming IPL can change at any time - depending on the priority views of the interrupt controller - this is essential if the handler is going to know which interrupt it’s servicing.

18. Even this address can be changed by a brave and determined SoC integrator, see the note on RBASE in Section

5.3.1 “Summary of exception entry points”.

71 Programming the MIPS32® 74K™ Core Family, Revision 02.14

5.3 Exception Entry Points

Release 2: relocate all the exception entry points with EBase

The new-with-release 2 EBase register does two vital jobs: one is to allow software to know which CPU it’s running on and the other is to relocate the exception entry points. It is primarily supplied for multi-CPU systems (or with a MIPS MT CPU, for systems using multiple VPEs).

The latter is necessary because CPUs sharing a memory map (as SMP CPUs often do) have their exception entry points in kseg0. By setting EBase differently on each CPU, you can give them distinct exception handlers.

Figure 5.2 Fields in the EBase Register

31 30 29 12 11 10 9 0

10 VA 0 CPUNum

EBase[VA]: the base address for the exception vectors, adjustable to a resolution of 4Kbytes. See the exception entry

points table for how that moves all the exception entry points. The top two address bits are ﬁxed to “10”, which

means that the base address is constrained to being somewhere in the “unmapped” kseg0/kseg1 memory regions. By setting EBase on any CPU and/or VPE of a multiprocessor and/or multithreading system to a unique value, that

CPU can have its own unique exception handlers. Write this ﬁeld only when Status[BEV] is set, so that any unexpected exception will be handled through the ROM

entry points (otherwise you would be changing the exception address under your own feet, and the results of that are undeﬁned).

EBase[CPUNum]: On single-threaded CPUs this is just a single "CPU number" ﬁeld (set by the core interface bus

SI_CPUNum, which the SoC designer will tie to some suitable value).

5.3.1 Summary of exception entry points

The incremental growth of exception entry points has left no one place where all the entry points are summarized; so here’s Table 5.1. But ﬁrst:

BASE is 0x8000.0000, as it will be where the software, ignoring the EBase register, leaves it at its power-on value —

that’s also compatible with older MIPS CPUs. Otherwise BASE is the 4Kbyte-aligned address found in EBase after you ignore the low 12 bits...

RBASE is the ROM/reset entry point base, usually 0xBFC0.0000. However, 74K family cores can be conﬁgured to

use a different base address by ﬁxing some input signals to the core. Speciﬁcally, if the core is wired with

SI_UseExceptionBase asserted, then RBASE bits 29-12 will be set by the values of the inputs SI_ExceptionBase[29:12] (the two high bits will be “10” to select the kseg0/kseg1 regions, and the low 12 bits are

always zero). Relocating RBASE is strictly not compliant with the MIPS32 speciﬁcation and may break all sorts of useful pieces of software, so it’s not to be done lightly.

DebugVectorAddr is an alternative entry point for debug exceptions. It is speciﬁed via a drseg memory mapped register

of the same name and enabled through the Debug Control Register. The probe handler still takes precedence, but this is higher priority than the regular ROM entry points.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 72

Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture

Table 5.1 All Exception entry points

Memory region Entry point Exceptions handled here

EJTAG probe-mapped 0xFF20.0200 EJTAG debug, when mapped to “probe” memory.

Alternate Debug Vector DebugVectorAddr EJTAG debug, not probe, relocated, DCR[RDVec]==1

ROM-only entry points RBASE+0x0480 EJTAG debug,when using normal ROMmemory.DCR[RDVec]==1

RBASE+0x0000 Post-reset and NMI entry point.

ROM entry points (when

Status[BEV]==1)

“RAM” entry points

(Status[BEV]==0)

RBASE+0x0200 Simple TLB Reﬁll (Status[EXL]==0). RBASE+0x0300 Cache Error. Note that regardless of any relocation of RBASE (see

above) the cache error entry point is always forced into kseg1.

RBASE+0x0400 Interrupt special (Cause[IV]==1). RBASE+0x0380 All others

BASE+0x100 Cache error - in RAM. but always through uncached kseg1 window. BASE+0x000 Simple TLB Reﬁll (Status[EXL]==0). BASE+0x200 Interrupt special (Cause[IV]==1).

BASE+0x200+... multiple interrupt entry points - seven more in “VI” mode, 63 in

“EIC” mode; see Section 5.2, "MIPS32® Architecture Release 2 -

enhanced interrupt system(s)".

BASE+0x180 All others

5.4 Shadow registers

In hardware terms, shadow registers are deceptively simple: just add one or more extra copies of the register ﬁle. If you can automatically change register set on an exception, the exception handler will run with its own context, and without the overhead of saving and restoring the register values belonging to the interrupted program. On to the details...

MIPS shadow registers come as one or more extra complete set of 32 general purpose registers. The CPU only changes register sets on an exception or when returning from an exception with eret.

Selecting shadow sets - SRSCtl

The shadow set selectors are in the SRSCtl register, shown in Figure 5.3.

Figure 5.3 Fields in the SRSCtl Register

313029 2625 2221 18171615 1211109 6543 0

0 HSS 0 EICSS 0 ESS 0 PSS 0 CSS

SRSCtl[HSS]: the highest-numbered register set available on this CPU (i.e. the number of available register sets minus

one.) If it reads zero, your CPU has just one set of GPR registers and no shadow-set facility.

SRSCtl[EICSS]: In EIC mode, the external interrupt controller proposes a shadow register set number with each

requested interrupt (nonzero IPL). When the CPU takes an interrupt, the externally-supplied set number determines the next set and is made visible here in SRSCtl[EICSS] until the next interrupt.

The CPU is in EIC mode if Conﬁg3[VEIC] (indicating the hardware is EIC-compliant), and software has set

Cause[IV] to enable vectored interrupts. There’s more about EIC mode in Section 5.2.3 “External Interrupt

Controller (EIC) mode”.

73 Programming the MIPS32® 74K™ Core Family, Revision 02.14

5.4 Shadow registers

If the CPU is not in EIC mode, this ﬁeld reads zero. In VI mode (no external interrupt controller, Conﬁg3[VInt] reads 1 and Cause[IV] has been set 1) the core sees only

eight possible interrupt numbers; the SRSMap register contains eight 4-bit ﬁelds deﬁning the register set to use for each of the eight interrupt levels.

If you are remaining with “classic” interrupt mode (Cause[IV] is zero), it’s still possible to use one shadow set for all exception handlers — including interrupt handlers — by setting SRSCtl[ESS] non-zero.

SRSCtl[ESS]: this writable ﬁeld is the software-selected register set to be used for "all other" exceptions; that’s other

than an interrupt in VI or EIC mode (both have their own special ways of selecting a register set). Unpredictable things will happen if you set ESS to a non-existent register set number (ie, if you set it higher than the

value in SRSCtl[HSS].

SRSCtl[CSS,PSS]: CSS is the register set currently in use, and is a read-only ﬁeld. It’s set on any exception, replaced

by the value in SRSCtl[PSS] on an eret.

PSS is the "previous" register set, which will be used following the next eret. It’s writable, allowing the OS to dis-

patch code in a new register set; load this value and then execute an eret. If you write a larger number than the total number of implemented register sets the result is unpredictable.

You can get at the values of registers in the previous set using rdpgpr and wrpgpr. Just a note: SRSCtl[PSS] and SRSCtl[CSS] are not updated by all exceptions, but only those which write a new

return address to EPC (or equivalently, those occasions where the exception level bit Status[EXL] goes from zero to one). Exceptions where EPC is not written include:

• Exceptions occurring with Status[EXL] already set;

• Cache error exceptions, where the return address is loaded into ErrorEPC;

• EJTAG debug exceptions, where the return address is loaded into DEPC.

How new shadow sets get selected on an interrupt

In EIC mode, the external interrupt controller proposes a shadow register set number with each requested interrupt (nonzero IPL). When the CPU takes an interrupt, the externally-supplied set number determines the next set and is made visible in SRSCtl[EICSS] until the next interrupt.

In VI mode (no external interrupt controller) the core sees only eight possible interrupt numbers; the SRSMap register contains eight 4-bit ﬁelds, deﬁning the register set to use for each of the eight interrupt levels, as shown in Figure 5.4.

Figure 5.4 Fields in the SRSMap Register

31 28 27 24 23 20 19 16 15 12 11 8 7 4 3 0

SSV7 SSV6 SSV5 SSV4 SSV3 SSV2 SSV1 SSV0

00000000

In SRSMap, each of the SSV7-0 ﬁelds has the shadow set number to be used when handling the interrupt for the corresponding Cause[IP7-0] bit. A zero shadow set number means not to use a shadow set. A number than the highest valid set (as found in SRSCtl[HSS]) has unpredictable results: don’t do that.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 74

Kernel-mode (OS) programming and Release 2 of the MIPS32® Architecture

If you are remaining with “classic” interrupt mode, it’s still possible to use one shadow set for all exception handlers

- including interrupt handlers - by setting SRSCtl[ESS] non-zero.

In “EIC” interrupt mode, this register has no effect and the shadow set number to be used is determined by an input bus from the interrupt controller.

Software support for shadow registers

Shadow registers work “as if by magic” for short interrupt routines which run entirely in exception mode (that is, with

Status[EXL] set). The shadow registers are not just efﬁcient because there’s no need to save user registers; the shadow

registers can also be used to hold contextual information for one or more interrupt routines which uses a particular shadow set. For more ambitious interrupt nesting schemes, software must save and stack copies of SRSCtl[PSS] alongside its copies of EPC; and it’s entirely up to the software to determine when an interrupt handler can just go ahead and use a register set, and when it needs to save values on entry and restore them on exit. That’s at least as difﬁcult as it sounds: shadow sets are probably best used purely for very low-level, high-speed handlers.

5.5 Saving Power

There are basically just a couple of facilities:

In some cores — distinguished by having Conﬁg7[WII] set to 1 — a wait condition will be terminated by an active interrupt signal, even if that signal is prevented from causing an interrupt by Status[IE] being clear. It’s not immediately obvious why that behavior is useful, but it avoids a tricky race condition for an OS which uses a

wait instruction in its idle loop. For programming details consult and Section B.2.1 “The Config7 register”.

• The Status[RP] bit: this doesn’t do anything inside the core, but its state is made available at the core interface as

SI_RP. Logic outside the core is encouraged to use this to control any logic which trades off power for speed -

most often, that will be slowing the master clock input to the CPU.

5.6 The HWREna register - Control user rdhwr access

HWREna allows the OS to control which (if any) hardwareregisters are readable in user mode using rdhwr: see also

Section 4.1 “User-mode accessible “Hardware registers””.

The low four bits (3-0) relate to the four registers required by the MIPS32 standard. The two high bits (31-30) are available for implementation-dependent use.

The whole register is cleared to zero on reset, so that no hardware register is accessible without positive OS clearance.

Figure 5.5 Fields in the HWREna Register

31 30 29 28 4 3 2 1 0

Impl UL 0 CCRes CC SYNCI_Step CPUNum

00 0 0 0 0

HWREna[Impl]: Read 0. If there were any implementation-dependent hardware registers, you could control access to

them here. Currently, no 74K family core has any such extra registers.

HWREna[UL]: Set this bit 1 to permit user programs to obtain the value of the UserLocal CP0 register through

rdhwr $29.

75 Programming the MIPS32® 74K™ Core Family, Revision 02.14

5.6 The HWREna register - Control user rdhwr access

HWREna[CCRes]: Set this bit 1 so a user-mode rdhwr 3 can determine whether Count runs at the full clock rate or

some divisor.

HWREna[CC]: Set this bit 1 so a user-mode rdhwr 2 can read out the value of the Count register. HWREna[SYNCI_Step]: Set this bit 1 so a user-mode rdhwr 1 can read out the cache line size (actually, the smaller

of the L1 I-cache line size and D-cache line size). That line size determines the step between successive uses of the

synci instruction, which does the cache manipulation necessary to ensure that the CPU can correctly execute

instructions which you just wrote.

HWREna[CPUNum]: Set this bit 1 so a user-mode rdhwr 0 reads out the CPU ID number, as found in

EBase[CPUNum].

Programming the MIPS32® 74K™ Core Family, Revision 02.14 76

Chapter 6

Floating point unit

The 74Kf™ member of the 74K family has a hardware ﬂoating point unit (FPU). This:

• Is a 64-bit FPU: with instructions working on both 64-bit and 32-bit ﬂoating point numbers, whose formats are

compatible with the “double precision” and “single precision” recommendations of [IEEE754].

• Is compatible with the MIPS64 Architecture: implements the ﬂoating point instruction set deﬁned in

[MIPS64V2]; because the 74K family integer core is a 32-bit processor, a couple of additional instructions

mfhc1 and mthc1 are available to help pack and unpack 64-bit values when copying data between integer and FP registers - see Section C.3 “FPU changes in Release 2 of the MIPS32® Architecture” or for full details

[MIPS32].

• Usually runs at half or two-thirds of the integer core’s clock rate: the design is tested to work with the FPU run-

ning at the core speed, but in likely processes the FPU will then limit the achievable frequency of the whole core. You can query the Conﬁg7[FPR,FPR1] ﬁelds in Section B.2.1 “The Config7 register” to check which option is used on your CPU.

• Can run without an exception handler: the FPU offers a range of options to handle very large and very small

numbers in hardware. With the 74K core full IEEE754 compliance does require that some operand/operation combinations be trapped and emulated, but high performance and good accuracy are available with settings which get the hardware to do everything - see Section 6.4.2, "FPU “unimplemented” exceptions (and how to

avoid them)".

• Omits “paired single” and MIPS-3D extensions: those are primarily aimed at 3D graphics, and are described as

optional in [MIPS64V2].

• Uses an autonomous 7-stage pipeline: all data transfers are interlocked, so the programmer is never aware of the

pipeline. Compiler writers and daemon subroutine tuners do need to know: there’s timing information in Section

6.5, "FPU pipeline and instruction timing".

• Has limited dual issue: the FPU has two parallel pipelines, and under optimum conditions can issue two instruc-

tions simultaneously. One handles all arithmetic operations, the other deals with loads, stores and data transfers to/from integer registers.

6.1 Data representation

If you’d like to read up on ﬂoating point in general you might like to read [SEEMIPSRUN]:. But it’s probably useful to remind you (in Figure 6.1) what 32-bit and 64-bit ﬂoating point numbers on MIPS architecture CPUs look like.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 77

Figure 6.1 How ﬂoating point numbers are stored in a register

6.2 Basic instruction set

float

2431

1623 815 07

mantissasign exp

double

5663

323940474855 16232431 815 07

mantissasign exp

Just to remind you:

• sign: FP numbers are positive numbers with a separate sign bit; “1” denotes a negative number.

• mantissa: represents a binary number. But this is a ﬂoating point number, so the units depend on:

• exp: the exponent.

When 32-bit data is held in a 64-bit register, the high 32 bits are don’t care.

The MIPS Architecture’s 32-bit and 64-bit ﬂoating point formats are compatible with the deﬁnitions of “single precision” and “double precision” in [IEEE754].

FP registers can also hold simple 2s-complement signed integers too, just like the same number held in the integer registers. That happens whenever you load integer data, or convert to an integer data type.

Floating point data in memory is endianness-dependent, in just the same way as integer data is; the higher bit-numbered bytes shown in Figure 6.1 will be at the lowest memory location when the core is conﬁgured big-endian, and the highest memory location when the core is little-endian.

6.2 Basic instruction set

Whenever it makes sense to do so, FP instructions exist in a version for each data type. In assembler that’s denoted by a sufﬁx of:

There’s a good readable summary of the ﬂoating point instruction set in [SEEMIPSRUN]:, and you can ﬁnd the ﬁne technical details in [MIPS64V2].

As a one-minute guide: the FPU provides basic arithmetic (add, multiply, subtract, divide and square root). It’s all register-to-register (like the integer unit). It’s written “destination ﬁrst” like integer instructions; sometimes that’s unexpected in that cvt.d.s is a “convert from single to double”. It has a set of multiply/add instructions which work on four registers: madd a,b,c,d does

a = c*d + b

.s single-precision .d double-precision .w 32-bit integer (“word”) .l 64-bit integer

Programming the MIPS32® 74K™ Core Family, Revision 02.14 78

Floating point unit

as a single operation. There are a rich set of conversion operations. A bewildering variety of compare instructions record their results in any one of eight condition ﬂags, and there are branch and conditional-move instructions which test those ﬂags.

You won’t ﬁnd any higher-level functions: no exponential, log, sine or cosine. This is a RISC instruction set, you’re expected to get library functions for those things.

6.3 Floating point loads and stores

FP data does not normally pass through the integer registers; the FPU has its own load and store instructions. The FPU is conceptually a replaceable tenant of coprocessor 1: while arithmetic FP operations get recognizable names like add.d, the load/store instructions will be found under names like ldc1 in [MIPS64V2] and other formal documentation. In assembler code, you’ll more often use mnemonics like l.d which you’ll ﬁnd will work just ﬁne.

Because FP-intensive programs are often dealing with one- or two-dimensional arrays of values, the FPU gets special load/store instructions where the address is formed by adding two registers; they’re called ldxc1 etc. In assembler you just use the l.d mnemonic with an appropriate address syntax, and all will be well.

6.4 Setting up the FPU and the FPU control registers

There’s a fair amount of state which you set up to change the way the FPU works; this is controlled by ﬁelds in the FPU control registers, described here.

6.4.1 IEEE options

[IEEE754] deﬁnes ﬁve classes of exceptional result. For each class the programmer can select whether to get an

IEEE-deﬁned “exceptional result” or to be interrupted. Exceptional results are sometimes just normal numbers but where precision has been lost, but also can be an inﬁnity or NaN (“not-a-number”) value.

Control over the interrupt-or-not options is done through the FCSR[Enable] ﬁeld (or more cleanly through FENR, the same control bits more conveniently presented); see Table 6.1 below.

It’s overwhelmingly popular to keep FENR zero and thus never generate an IEEE exception; see Section 6.5, "FPU

pipeline and instruction timing" for why this is a particularly good idea if you want the best performance.

6.4.2 FPU “unimplemented” exceptions (and how to avoid them)

It’s a long-standing feature of the MIPS Architecture that FPU hardware need not support every corner-case of the IEEE standard. But to ensure proper IEEE compatibility to the software system, an FPU which can’t manage to generate the correct value in every case must detect a combination of operation and operands it can’t do right. It then takes an unimplemented exception, which the OS should catch and arrange to software-emulate the offending instruction.

The 74K core’s FPU will handle everything IEEE can throw at it, except for tiny numbers: it can’t use or produce non-zero values which are too small for the standard (“normalized”) representation19.

19. IEEE754 deﬁnes an alternative “denormalized” representation for these numbers.

79 Programming the MIPS32® 74K™ Core Family, Revision 02.14

6.4 Setting up the FPU and the FPU control registers

Here you get a choice: you can either conﬁgure the CPU to depart from IEEE perfection (see the description of the

FCSR[FS,FO,FN] bits in the notes to Section 6.1, "FPU (co-processor 1) control registers"), or provide a software

emulator and resign yourself to a small number of “unimplemented” exceptions.

6.4.3 FPU control register maps

There are ﬁve FP control registers:

Table 6.1 FPU (co-processor 1) control registers

Conventional CP1 ctrl Description

Name reg num

FCSR 31 Extensive control register - the only FPU control register on histori-

cal MIPS CPUs. Contains all the control bits. But in practice some of them are more conveniently accessed through FCCR, FEXR and FENR below.

FIR 0 FP implementation register: read-only information about the capa-

bility of this FPU.

FCCR 25 Convenient partial views of FCSR are better structured, and allow FEXR 26 FENR 28

you to update ﬁelds without interfering with the operation of independent bits.

FCCR has FP condition codes, FEXR contains IEEE exceptional-

condition information (cause and ﬂag bits) you read, and FENR is IEEE exceptional-condition enables you write.

The FP implementation (FIR) register

Figure 6.2 shows the ﬁelds in FIR and the read-only values they always have for 74K family FPUs:

Figure 6.2 Fields in the FIR register

31 25 24 23 22 21 20 19 18 17 16 15 8 7 0

0 FC 0 F64 L W 3D PS D S Processor ID Revision

1 1 1 1 0 0 1 1 0x97 whatever

The ﬁelds have the following meanings:

• FC: “full convert range”: the hardware will complete any conversion operation without running out of bits and

causing an “unimplemented” exception.

• F64/L/W/D/S: this is a 64-bit ﬂoating point unit and implements 64-bit integer (“L”), 32-bit integer (“W”), 64-bit

FP double (“D”) and 32-bit FP single (“S”) operations.

• 3D: does not implement the MIPS-3D ASE.

• PS: does not implement the paired-single instructions described in [MIPS64V2]

• Processor ID/Revision: major and minor revisions of the FPU - as is usual with revisions it’s very useful to print

these out from a verbose sign-on message, and rarely a good idea to have software behave differently according to the values.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 80

Floating point unit

The FP control/status registers (FCSR, FCCR, FEXR, FENR)

Figure 6.3 shows all these registers and their bits

31 25 24 23 22 21 20 18 17 16 12 11 8 7 6 3 2 1 0

FCSR FCC7-1 FS FCC0 FO FN 0 E Cause Enables Flags RM

FCCR 0 FCC7-0

FEXR 0 E Cause 0 Flags 0

FENR 0 Enables 0 FS RM

Figure 6.3 Floating point control/status register and alternate views

Where:

FCC7-0: the ﬂoating point condition codes: set by compare instructions, tested by appropriate branch and conditional

move instructions.

FS/FO/FN: options to avoid "unimplemented" exceptions when handling tiny ("denormalized") numbers20.Theydoso

at the cost of IEEE compatibility, by replacing the very small number with either zero or with the nearest nonzero quantity with a normalized representation.

The FO (“flush override”) bit causes all tiny operand and result values to be replaced. The FS (“flush to zero”) bit causes all tiny operand and result values to be replaced, but additionally does the same

substitution for any tiny intermediate value in a multiply-add instruction. This is provided both for legacy reasons, and in case you don’t like the idea that the result of a multiply/add can change according to whether you use the fused instruction or a separate multiply and add.

The FN bit (“flush to nearest”) bit causes all result values to be replaced with somewhat better accuracy than you

usually get with FS: the result is either zero or a smallest-normalized-number, whichever is closer. Without FN set you can only replace your tiny number with a nonzero result if the “RP” or “RM” rounding modes (round towards more positive, round towards more negative) are in effect.

For full IEEE-compatibility you must set FCSR[FS,FO,FN] == [0,0,0]. To get the best performance compatible with a guarantee of no “unimplemented” exceptions, set FCSR[FS,FO,FN]

== [1,1,1].

Just occasionally for legacy applications developed with older MIPS CPUs which did not have the FO and FN options,

you might set FCSR[FS,FO,FN] == [1,0,0].

E: (often shown in documents as part of the Cause array) is a status bit indicating that the last FP instruction caused an

"unimplemented" exception, as discussed in Section 6.4.2, "FPU “unimplemented” exceptions (and how to avoid

them)".

20. See [SEEMIPSRUN]: for an explanation of “normalized” and “denormalized”.

81 Programming the MIPS32® 74K™ Core Family, Revision 02.14

6.5 FPU pipeline and instruction timing

Cause/Enables/Flags: each of these ﬁelds is broken up into ﬁve bits, each representing an IEEE-recognized class of

exceptional results21 which can be individually treated either by interrupting the computation, or substituting an IEEE-deﬁned exceptional value. So each ﬁeld contains:

bit number 4 3 2 1 0

ﬁeld V Z O U I

The bits are V for invalid operation (e.g. square root of -1), Z for divide-by-zero, O for overflow (a number too large

to represent), U for underflow (a number too small to represent) and I for inexact - even 1/3 is inexact in binary.

Then the:

– Enables ﬁeld is "write 1 to take a MIPS exception if this condition occurs" - rarely done. With the IEEE

exception-catcher disabled, the hardware/emulator together will provide a suitable exceptional result.

– Cause ﬁeld records what if any conditions occurred in the last-executed FP instruction. Because that’s often

too transient, the

– Flags ﬁeld remembers all and any conditions which happened since it was last written to zero by software.

RM: is the rounding mode, as required by IEEE:

RM Meaning

0 Round to nearest - RN

If the result is exactly half-way between the nearest values, pick the one whose

mantissa bit0 is zero. 1 Round toward zero - RZ 2 Round towards plus inﬁnity - RP

“Round up” (but unambiguous about what you do about negative numbers). 3 Round towards minus inﬁnity - RM

6.5 FPU pipeline and instruction timing

This is not so simple. The ﬂoating point unit (FPU) has its own pipeline. More often than not, the FPU uses a slower clock rate than the integer core - a full-speed FPU is a build option, but in that case the FPU will usually limit the clock rate which your design can reach. For 74K family cores, the FPU will commonly be built with a two-thirds clock. You can ﬁnd how your core is set up by looking at the Conﬁg7[FPR1-0] bits, deﬁned in the notes to Figure

B.3

Nonetheless, this is a powerful 64-bit ﬂoating point unit which can deliver very good performance. The FPU pipeline is shown in Figure 6.4.

21. Sorry about the ugly wording. The IEEE standard talks of “exceptions” which makes more sense but gets mixed up with MIPS “exceptions”, and they’re not the same thing.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 82

6.5 FPU pipeline and instruction timing

6.5.1 FPU register dependency delays

Any FPU instruction must go through pipeline stages from M1 through A2 before it produces a result, which can then (as shown by the “bypass” lines in the pipeline diagram) be used by a dependent instruction reaching the M1 stage. If you want to keep the FPU pipeline full, that means it’s enough to have three non-dependent instructions between the consumer and producer of an FP value. However, there’s no guarantee that all the FP pipeline slots will be ﬁlled, and then three intervening instructions will be excessive. Good compilers should try to schedule FP instructions, but not at unreasonable cost.

6.5.2 Delays caused by long-latency instructions looping in the M1 stage

Instructions which take only one clock in M1 go through the pipeline smoothly and can be completed one per FPU clock period. Instructions which take longer in M1 always prevent the next instruction from starting in the next clock, regardless of any data dependency. Those long-latency instructions - double-precision multiplies and all division and square root operations - are listed in Table 6.2. An instruction which runs for 2 cycles in M1 holds up the FPU pipeline for one clock and so on - and of course the cycle counts are for FPU cycles.

Table 6.2 Long-latency FP instructions

Operand Instruction type Instructions Cycles in M1

Double-precision (64-bit) Any multiplication

Single-precision (32-bit) Reciprocal

divide, square-root

reciprocal square root

Double-precision (64-bit) Reciprocal

divide, square-root

reciprocal square root

mul.d,madd.d, msub.d,nmadd.d, nmsub.d

recip.s

div.s,sqrt.s

rsqrt.s recip.d

div.d,sqrt.d

rsqrt.d

2 10 14 14 21 29 31

6.5.3 Delays on FP load and store instructions

FP store instructions graduate from the main pipeline (subject to dependencies and freedom from address exceptions), and then wait in a special queue until FP data is delivered. The store data will be signiﬁcantly delayed compared to an integer store instruction: but unless some other instruction reads the target cache line, the program will probably not see much delay.

FP load instructions in the main pipeline are treated like integer loads; an FP load which hits in the cache can be completed in the main pipeline. The load data is passed from D-cache into the FPU pipeline, and you should see no more than the usual FP producer-consumer delay from load to use. FPU load instructions which miss are processed in the memory pipeline. FP loads are non-blocking too, so it will be the consuming instruction (if any) which is delayed.

6.5.4 Delays when main pipeline waits for FPU to decide not to take an exception

The MIPS architecture requires FP exceptions to be “precise”, which (in particular) means that no instruction after the FP instruction causing the exception may do anything software-visible. That means that an FP instruction in the main pipeline may not be committed, nor leave the main pipeline, until the FPU can either report the exception, or conﬁrm that the instruction will not cause an exception.

Floating point instructions cause exceptions not only because a user program has requested the system to trap IEEE exceptional conditions (which is unusual) but also because the hardware is not capable of generating or accepting very small (“denormalized”) numbers in accordance with the IEEE standards. The latter (“unimplemented”) exception is used to call up a software emulator to patch up some rare cases. But the main pipeline must be stalled until the

Programming the MIPS32® 74K™ Core Family, Revision 02.14 84

Floating point unit

FP hardware can rule out an exception, and that leads to a delay on every non-trivial FP operation. With a half-rate FPU, this stall will most likely be 6-7 clocks.

Software which can tolerate some deviation from IEEE precision can avoid these delays by opting to replace all denormalized inputs and results by zero - controlled by the FCSR[FS,FO,FN]register bits described in Section 6.1,

"FPU (co-processor 1) control registers" and its notes. If you have also disabled all IEEE traps, you get no possibility

of FP exceptions and no extra main pipeline delay.

6.5.5 Delays when main pipeline waits for FPU to accept an instruction

FP instructions are queued (some queues are shared with other co-processors, if ﬁtted) for transmission to the FPU hardware. If that queue (which has 8 entries) ﬁlls up, the CPU will be unable to issue more FP instructions — and since FP instructions are issued in-order, that will quickly clog up the CPU

6.5.6 Delays on mfc1/mtc1 instructions

mtc1 goes down the main pipe and gets its GP register data just like any other instruction (from the register ﬁle, a completion buffer or a by-pass): then it passes it across to the FPU. In the FPU pipeline, the mtc1 looks like an FP load which hits: the data is sent to the FP unit a predictable number of cycles after it is issued

mfc1 (in the FPU pipeline) resembles a FP store. The FP data is sent back the same FPU-to-EU data path as is used in a store, but then written into the CB which belongs to the integer AGEN pipeline’s version of the same mfc1 instruction. The timing is awkward because you have to ﬁnd a free completion buffer write port. Once the data is in the CB, the mfc1 is a candidate for graduation. Since the FPU pipeline is long and it usually runs slower than the integer pipeline, the effective latency of mfc1 can be high. A program will run faster if the mfc1 can be placed 10-15 instruction positions ahead of its consumer.

6.5.7 Delays caused by dependency on FPU status register ﬁelds

The conditional branch instructions bc1f/bc1t and the conditional moves movf/movt execute in the main pipeline, but test a FP condition bit generated by the various FPU compare instructions.

bc1f/bc1t (like other conditional branches) are executed speculatively in the execution unit. FP condition values are not passed through CBs, so the check for a mispredict is not made until the branch instruction tries to graduate. That means that mispredicted FP branches are a couple of cycles more expensive than regular mispredictions.

MIPS recommends that you don’t use the “branch likely” (bc1fl/bc1tl) versions of these instructions in new code.

6.5.8 Slower operation in MIPS I™ compatibility mode

Historic 32-bit MIPS CPUs had only 16 “even-numbered” ﬂoating point registers usable for arithmetic, with oddnumbered registers working together with them to let you load, store and transfer double-precision (64-bit) values. Software written for those old CPUs is incompatible with the full modern FPU, so there’s a compatibility bit provided in Status[FR] - set zero to use MIPS I compatible code. This comes at the cost of slower repeat rates for FP instructions, because in compatibility mode not all the bypasses shown in the pipeline diagram above are active.

85 Programming the MIPS32® 74K™ Core Family, Revision 02.14

6.5 FPU pipeline and instruction timing

Programming the MIPS32® 74K™ Core Family, Revision 02.14 86

Chapter 7

The MIPS32® DSP ASE

The MIPS DSP ASE is provided to accelerate a large range of DSP algorithms. Youcan get most programming information from this chapter. There’s more detail in the formal DSP ASE speciﬁcation [MIPSDSP], but expect to read through lots of material aimed at hardware implementors. You may also ﬁnd [DSPWP] useful for tips and examples of converting DSP algorithms for the DSP ASE.

Different target applications generally need different data size and precision:

• 32-bit data: audio (non-hand-held) decoding/encoding - a wide range of “hi-ﬁ” standards for consumer audio or television sound.

Raw audio data (as found on CD) is 16-bit; but if you do your processing in 16 bits you lose precision beyond what is acceptable for hi-ﬁ.

• 16-bit data: digital voice for telephony. International telephony code/decode standards include G.723.1 (8Ksample/s, 5-6Kbit/s data rate, 37ms delay), G.729 (8Kbit/s, 15ms delay) and G.726 (16-40Kbit/s, computationally simpler and higher quality, good for carrying analogue modem tones). Application-speciﬁc ﬁlters are used for echo cancellation, noise cancellation, and channel equalization.

Also used for soft modems and much general “DSP” work (ﬁlters, correlation, convolution);lo-ﬁ devices use 16 bits for audio.

• 8-bit data: processing of printer images, JPEG (still) images and video data.

7.1 Features provided by the MIPS® DSP ASE

Those target applications can beneﬁt from unconventional architecture features because they rely on:

• Fixed-point fractional data types: It is not yet economical (in terms of either chip size or power budget) to use ﬂoating point calculations in these contexts. DSP applications use ﬁxed-point fractions. Such a fraction is just a signed integer, but understood to represent that integer divided by some power of two. A 32-bit fractional format

where the implicit divisor is 216(65536) would be referred to as a Q15.16 format; that’s because there are 16 bits devoted to fractional precision and 15 bits to the whole number range (the highest bit does duty as a sign bit and isn’t counted).

With this notation Q31.0 is a conventional signed integer, and Q0.31 is a fraction representing numbers between

-1 and 1 (well, nearly 1). It turns out that Q0.31 is the most popular 32-bit format for DSP applications, since it won’t overﬂow when multiplied (except in the corner case where -1×-1 leads to the just-too-large value 1). Q0.31 is often abbreviated to Q31.

The DSP ASE provides support for Q31 and Q15 (signed 16-bit) fractions.

• Saturating arithmetic: It’s not practicable to build in overﬂow checks to DSP algorithms - they need to be too fast. Clever algorithms may be built to be overﬂow-proof; but not all can be. Often the least worst thing to do

Programming the MIPS32® 74K™ Core Family, Revision 02.14 87

7.2 The DSP ASE control register

when a calculation overﬂows is to make the result the most positive or most negative representable value. Arithmetic which does that is called saturating - and quite a lot of operations in the DSP ASE saturate (in many cases there are saturating and non-saturating versions of what is otherwise the same instruction).

• Multiplying fractions: if you multiply two Q31 fractions by re-using a full-precision integer multiplier, then you’ll get a 64-bit result which consists of a Q62 result with (in the very highest bit) a second copy of the sign bit. This is a bit peculiar, so it’s more useful if you always do a left-shift-by-1 on this value, producing a Q63 format (a more natural way to use 64 bits). Q15 multiplies which generate a Q31 value have to do the shift-left too. That’s what all the mulq... instructions do.

• Rounding: some fractional operations implicitly discard less signiﬁcant bits. But you get a better approximation if you bump the truncated result by one when the discarded bits represent more than a half of the value of a 1 in the new LS position. That’s what we mean by rounding in this chapter.

• Multiply-accumulate sequences with choice of four accumulators: (with ﬁxed-point types, sometimes saturating).

The 74K already has quite a slick integer multiply-accumulate operation, but it’s not so efﬁcient when used for fractional and saturating operations.

The sequences are made more usable by having four 64-bit result/accumulator registers - (the old MIPS multiply divide unit has just one, accessible as the hi/lo registers). The new ac0 is the old hi/lo, for backward compatibility.

• Beneﬁt from “SIMD” operations.: Many DSP calculations are a good match for “Single Instruction Multiple Data” or vector operations, where the same arithmetic operation is applied in parallel to several sets of operands.

In the MIPS DSP ASE, some operations are SIMD type - two 16-bit operations or four 8-bit operations are carried out in parallel on operands packed into a single 32-bit general-purpose register. Instructions operating on vectors can be recognized because the name includes.ph (paired-half, usually signed, often fractional) or.qb (quad-byte, always unsigned, only occasionally fractional).

The DSP ASE hardware involves an extensive re-work of the normal integer multiply/divide unit. As mentioned above it has four 64-bit accumulators (not just one) and a new control register, described immediately below.

7.2 The DSP ASE control register

This is a part of the user-mode programming model for the DSP ASE, and is a 32-bit value read and written with the rddsp/wrdsp instructions. It holds state information for some DSP sequences.

Figure 7.1 Fields in the DSPControl Register

31 28 27 24 23 16 15 14 13 12 7 6 5 0

0 ccond ouﬂag 0 EFI c scount 0 pos

In Figure 7.1:

ccond: condition bits set by compare instructions (there have to be four to report on compares between vector types).

"Compare" operations on scalars or vectors of length two only touch the lower-numbered bits. DSPControl bits 31:28 are used for more ccond bits in 64-bit machines.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 88

The MIPS32® DSP ASE

ouflag

: one of these bits may be set when a result overflows (whether or not the result is saturated depends on the instruction - the flag is set in either case). The "ou" stands for "overflow/underflow" - "underflow" is used here for a value which is negative but with excessive absolute value.

Any overﬂowed/underﬂowed result produced by any DSP ASE instruction sets a ouflag bit, except for addsc/ addwc and shilo/shilov.

The 6 bits are set according to the destination of the operation which overﬂowed, and the kind of operation it was:

Bit No Overﬂowed destination/instruction

16-19 Destination register is a multiply unit accumulator:

separate bits are respectively for accumulators 0-3. 20 Add/subtract. 21 Multiplication of some kind. 22 Shift left or conversion to smaller type 23 Accumulator shift-then-extract

EFI: set by any of the accumulator-to-register bitfield extract instructions extp, extpv, extpdp,orextpdp. It’s set

to 1 if and only if the instruction finds there are insufficient bits to extract. That is, if DSPControl[pos] - which is supposed to mark the highest-numbered bit of the field we’re extracting - is less than the size value specified by the instruction.

c: Carry bit for 32-bit add/carry instructions addsc and addwc.

scount, pos: Fields for use by "variable" bitfield insert and extract instructions, such as insv (the normal MIPS32

ins/ext instructions have the field size and position hard-coded in the instruction).

scount speciﬁes the size of the bit ﬁeld to be inserted, while pos speciﬁes the insert position.

Caution: in all inserts (following the lead of the standard MIPS32 insert/extract instructions) pos is set to the lowest bit number in the ﬁeld. But in the DSP ASE extract-from-accumulator instructions (extp, extpv, ext- pdp and extpdpv), pos identiﬁes the highest-numbered bit in the ﬁeld.

The latter two (“dp”) instructions post-decrement pos (by the bitﬁeld length size), to help software which is unpacking a series of bitﬁelds from a dense data structure.

The mthlip instruction will increment the pos value by 32 after copying the value of lo to hi.

7.2.1 DSP accumulators

Whereas a standard MIPS32 architecture CPU has just one 64-bit multiply unit accumulator (accessible as hi/lo), the DSP ASE provides three 64-bit accumulators. Instructions accessing the extra accumulators specify a 2-bit ﬁeld as 03 (0 selects the original accumulator).

7.3 Software detection of the DSP ASE

You can ﬁnd out if your core supports the DSP ASE by testing the Config3[DDSP] bit (see notes to Figure 2.4).

Then you need to enable use of instructions from the MIPS DSP ASE by setting Status[MX] to 1.

89 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.4 DSP instructions

The DSP instruction set is nothing like the regular and orthogonal MIPS32 instruction set. It’s a collection of specialcase instructions, in many cases aimed at the known hot-spots of important algorithms.

We’ll summarize the instructions under headings, but then list all of them in Section 7.2, "DSP instructions in

alphabetical order", an alphabetically-ordered list which provides a terse but usually-sufﬁcient description of what

each instruction does.

7.4.1 Hints in instruction names

An instruction’s name may have some sufﬁxes which are often informative:

q: generally means it treats operands as fractions (which isn’t important for adds and subtracts, but is important for

multiplications and convert operations);

_s: usually means the full-precision result is saturated to the size of the destination; _sa is used for instructions which

saturate intermediate results before accumulating; and r: denotes rounding (see above);

.w,.ph,.qb: suggest the operation is dealing with 32-bit, paired-half or quad-byte values respectively. Where there

are two of these (as in macq_s.w.phl) the first one suggests the type of the result, and the second the type of the operand(s).

v: (in a shift instruction) suggests that the shift amount is defined in a register, rather than being encoded in a field of

the instruction.

To help you get your arms around this collection of instructions we’ll group them by likely usage - guided by the type of the result performed, with an eye to the application. The multiplication instructions are more tricky: most of them have multiple uses. We’ve sorted them by the most obvious use (likely also the most common). The classiﬁcation we’ve chosen divides them into:

• Arithmetic - 64-bit

• Arithmetic - saturating and/or SIMD Types

• Bit-shifts - saturating and/or SIMD types

• Comparison and "conditional-move" operations on SIMD types - includes pick instructions.

• Conversions to and from SIMD types

• Multiplication - SIMD types with result in GP register

• Multiply Q15s from paired-half and accumulate

• Load with register+register address

• DSPControl register access

• Accumulator access instructions

• Dot products and building blocks for complex multiplication - includes full-word (Q31) multiply-accumulate

• Other DSP ASE instructions - everything else...

Programming the MIPS32® 74K™ Core Family, Revision 02.14 90

The MIPS32® DSP ASE

7.4.2 Arithmetic - 64-bit

addsc/addwc generate and use a carry bit, for efﬁcient 64-bit add.

7.4.3 Arithmetic - saturating and/or SIMD Types

• 32-bit signed saturating arithmetic: addq_s.w, subq_s.w and absq_s.w.

• Paired-half and quad-byte SIMD arithmetic: perform the same operation simultaneously on both 16-bit halves or all four 8-bit bytes of a 32-bit register. The “q” in the instruction mnemonic for the PH operations here is cosmetic: Q15 and signed 16-bit integer add/subtract operations are bit-identical - Q15 only behaves very differently when converted or multiplied.

The paired half operations are: addq.ph/addq_s.ph, subq.ph/subq_s.ph and absq_s.ph.

The quad-byte operations (all unsigned) are: addu.qb/addu_s.qb, subu.qb/subu_s.qb.

• Sum of quad-byte vector: raddu.w.qb does an unsigned sum of the four bytes found in a register, zero extends the result and delivers it as a 32-bit value.

7.4.4 Bit-shifts - saturating and/or SIMD types

All shifts can either have a shift amount encoded in the instruction, or - indicated by a trailing “v” in the instruction name - provided as a register operand. PH and 32-bit shifts have optional forms which saturate the result.

• 32-bit signed shifts: include a saturating version of shift left, shll_s.w; and an auto-rounded shift right (just the “arithmetic”, sign-propagating form): shra_r.w. Recall from above that rounding can be imagined as pre- adding a half to the least signiﬁcant surviving bit.

• Paired-half and quad-byte SIMD shifts: shll.ph/shllv.ph/shll_s.ph/shllv_s are as above. For PH only there’s a shift-right-arithmetic instruction (“arithmetic” means it propagates the sign bit downward) shra.ph, which has a variant which rounds the result shra_r.ph.

The quad-byte shifts are unsigned and don’t round or saturate: shll.qb/shllv.qb, shrl.qb/shrlv.qb.

7.4.5 Comparison and “conditional-move” operations on SIMD types

The “cmp” operations simultaneously compare and set ﬂags for two or four values packed in a vector (with equality, less-than and less-than-or-equal tests). For PH that’scmp.eq.ph, cmp.lt.ph and cmp.le.ph. The result is left in the two LS bits of DSPControl[ccond].

For quad-byte values cmpu.eq.qb, cmpu.lt.qb and cmpu.le.qb simultaneously compare and set ﬂags for four bytes in DSPControl[ccond] - the ﬂag relating to the bytes found in the low-order bits of the source register is in the lowest-numbered bit (and so on). There’s an alternative set of instructions cmpgu.eq.qb, cmpgu.lt.qb and

cmpgu.le.qb which leave the 4-bit result in a speciﬁed general-purpose register.

pick.ph uses the two LS bits of DSPControl[ccond] (usually the outcome of a paired-half compare instruction, see

above) to determine whether corresponding halves of the result should come from the ﬁrst or second source register. Among other things, this can implement a paired-half conditional move. You can reversetheorder of your conditional inputs to do a move dependent on the complementary condition, too.

pick.qb does the same for QB types, this time using four bits of DSPControl[ccond].

91 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.4 DSP instructions

7.4.6 Conversions to and from SIMD types

Conversion operations from larger to smaller fractional types have names which start “precrq...” for “precision reduction, fractional”. Conversion operations from smaller to larger have names which start “prece...” for “preci- sion expansion”.

• Form vector from high/low parts of two other paired-half values: packrl.ph makes a paired-half vector from two half vectors, swapping the position of each sub-vector. It can be used to acquire a properly formed sub-vector from a non-aligned data stream.

• One Q15 from a paired-half to a Q31 value: preceq.w.phl/preceq.w.phr select respectively the “left” (high bit numbered) or “right” (low bit numbered) Q15 value from a paired-half register, and load it into the result register as a Q31 (that is, it’s put in the high 16 bits and the low 15 bits are zeroed).

• Two bytes from a quad-byte to paired-half: precequ.ph.qbl/precequ.ph.qbr picks two bytes from either the “left” (high bit numbered) or “right” (low bit numbered) halves of a quad-byte value, and unpacks to a pair of Q15 fractions.

precequ.ph.qbla does the same, except that it picks two “alternate” bytes from bits 31-24 and 15-8, while precequ.ph.qbra picks bytes from bits 23-16 and 7-0.

Similar instructions without the q - preceu.ph.qbl, preceu.ph.qbr, preceu.ph.qbla” and preceu.ph.qbra - work on the same register ﬁelds, but treat the quantities as integers, so the 16-bit results get

their low bits set.

• 2×Q31 to a paired-half: both operands and result are assumed to be signed fractions, so precrq.ph.w just takes the high halves of the two source operands and packs them into a paired-half; precrq_rs.ph.w rounds and saturates the results to Q15.

• 2×paired-half to quad-byte: you need two source registers to provide four paired-half values, of course. This is a fractional operation, so it’s the low bits of the 16-bit fractions which are discarded.

precrq.qb.ph treats the paired-half operands as unsigned fractions, retaining just the 8 high bits of each 16bit component.

precrqu_s.qb.ph treats the paired-half operands as Q15 signed fractions and both rounds and saturates the result (in particular, a negativeQ15fractionproduces a zero byte, since zero is the lowest representable quantity).

• Replicate immediate or register value to paired-half: in repl.ph the value to be replicated is a 10-bit signed immediate value (that’s in the range -512 ≤ x ≤ 511) which is sign-extended to 16 bits, whereas in replv.ph the value - assumed to be already a Q15 value - is in a register.

• Replicate single value to quad-byte: there’s both a register-to-register form replv.qb and an immediate form repl.qb.

7.4.7 Multiplication - SIMD types with result in GP register

When a multiply’s destination is a general-purpose register, the operation is still done in the multiply unit, and you should expect it to overwrite the hi/lo registers (otherwise known as ac0.)

• 8-bit×16-bit 2-way SIMD multiplication: muleu_s.ph.qbl/muleu_s.ph.qbr picks the “left” (high bit numbered) or “right” (low bit numbered) pair of byte values from one source register and a pair of 16-bit values

Programming the MIPS32® 74K™ Core Family, Revision 02.14 92

The MIPS32® DSP ASE

from the other. Two unsigned integer multiplications are done at once, the results unsigned-saturated and delivered to the two 16-bit halves of the destination.

The asymmetric use of the source operands is not a bit like a Q15 operation. But 8×16 multiplies are heavily used in imaging and video processing (JPEG image encode/decode, for example).

• Paired-half SIMD multiplication: mulq_rs.ph multiplies two Q15s at once and delivers it to a paired-half value i n a general-purpose register, with rounding and saturation.

• Multiply half-PH operands to a Q31 result: muleq_s.w.phl/muleq_s.w.phr pick the “left”/”right” Q15 value respectively from each operand, multiply and store a Q31 value.

“Precision-doubling” multiplications like this can overﬂow, but only in the extreme case where you multiply 1×-1, and can’t represent 1 exactly.

7.4.8 Multiply Q15s from paired-half and accumulate

maq_s.w.phl/maq_s.w.phr picks either the left/high or right/low Q15 value from each operand, multiplies them to Q31 and accumulates to a Q32.31 result. The multiply is saturated only when it’s -1×-1.

maq_sa.w.phl/maq_sa.w.phr differ in that the ﬁnal result is saturated to a Q31 value held in the low half of the accumulator (required by some ITU voice encoding standards).

7.4.9 Load with register + register address

Previously available only for ﬂoating point data22: lwx for 32-bit loads, lhx for 16-bit loads (sign-extended) and lbux for 8-bit loads, zero-extended.

7.4.10 DSPControl register access

wrdsp rs,mask sets DSPControl ﬁelds, but only those ﬁelds which are enabled by a 1 bit in the 6-bit mask.

rddsp reads DSPControl into a GPR; but again it takes a mask ﬁeld. Bitﬁelds in the GPR corresponding to

DSPControl ﬁelds which are not enabled will be set all-zero.

The mask bits tie up with ﬁelds like this:

Table 7.1 Mask bits for instructions accessing the DSPControl register

Mask Bit DSPControl ﬁeld

0 pos 1 scount 2 c 3 ouflag 4 ccond 5 EFI

22. Well, an integer instruction is also included in the MIPS SmartMIPS™ ASE.

93 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.4 DSP instructions

7.4.11 Accumulator access instructions

• Historical instructions which now access new accumulators: the familiar mfhi/mflo/mthi/mtlo instructions now take an optional extra accumulator-number parameter.

• Shift and move to general register: extr.w/extr_r.w/extr_rs.w gets a 32-bit ﬁeld from an accumulator (starting at bit 0 up to 31) and puts the value in a general purpose register. At your option you can specify rounding and signed 32-bit saturation.

extrv.w/extrv_r.w/extrv_rs.w do the same but specify the ﬁeld’s starting bit number with a register.

• Extract bitﬁeld from accumulator: extp/extpv takes a bitﬁeld (up to 32 bits) from an accumulator and moves it to a GPR. The length of the ﬁeld can be an immediate value or from a register. The position of the ﬁeld is determined by DSPControl[pos], which holds the bit number of the most signiﬁcant bit.

extpdp/extpdpv do the same, but also auto-decrement DSPControl[pos] to the bit-number just below the ﬁeld you extracted.

• Accumulator rearrangement: shilo/shilov has a signed shift value between -32 and +31, where positive numbers shift right, and negative ones shift left. The “v” version, as usual, takes the shift value from a register. The right shift is a “logical” type so the result is zero extended.

• Fill accumulator pushing low half to high: mthlip moves the low half of the accumulator to the high half, then writes the GPR value in the low half. Generally used to bring 32 more bits from a bitstream into the accumulator for parsing by the various ext... instructions.

7.4.12 Dot products and building blocks for complex multiplication

In 2-dimensional vector math (or in any doubled-up step of a multiply-accumulate sequence which has been optimized for 2-way SIMD) you’re often interested in the dot product of two vectors:

v[0]*w[0] + v[1]*w[1]

In many cases you take the dot product of a series of vectors and add it up, too.

Some algorithms use complex numbers, represented by 2D vectors. Complex numbers use i to stand for “the square root of -1”, and a vector [a,b] is interpreted as a+ib (mathematicians leave out the multiply sign and use single- letter variables, habits which would not be appreciated in C programming!) Complex multiplication just follows the rules of multiplying out sums, remembering that i*i = -1, so:

(a + ib)*(c + id) = (a*c - b*d) + i(a*d + b*c)

Or in vector format:

[a, b] * [c, d] = [a*c - b*d, a*d + b*c]

The ﬁrst element of the result (the “real component”) is like a dot product but with a subtraction, and the second (the “imaginary component”) is like a dot product but with the vectors crossed.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 94

The MIPS32® DSP ASE

• Q15 dot product from paired-half,and accumulate: dpaq_s.w.ph does a SIMD multiply of the Q15 halves of the operands, then adds the results and saturates to form a Q31 fraction, which is accumulated into a Q32.31 fraction in the accumulator.

dpsq_s.w.ph does the same but subtracts the dot product from the accumulator.

For the imaginary component of a complex multiply, ﬁrst swap the Q15 numbers in one of the register operands with a rot (bit-rotate) instruction.

For the real component of a complex Q15 multiply, you have the difference-of-products instruction mulsaq_s.w.ph, which parallel-multiplies both Q15 halves of the PH operands, then computes the difference of the two results and leaves it in an accumulator in Q32.31 format (beware: this does not accumulate the result).

• 16-bit integer dot-product from paired-half, and accumulate: dpau.h.qbl/dpau.h.qbr picks two QB val- ues from each source register, parallel-multiplies the corresponding pairs to integer 16-bit values, adds them together and then adds the whole lot into an accumulator. dpsu.h.qbl/dpsu.h.qbr do the same sum-ofproducts, but the result is then subtracted from the accumulator. In both cases, note this is integer (not fractional) arithmetic.

• Q31 saturated multiply-accumulate: is the nearest thing you can get to a dot-product for Q31 values. dpaq_sa.l.w does a Q31 multiplication and saturates to produce a Q63 result, which is added to the accumulator and saturated again. dpsq_sa.l.w does the same, except that the multiply result is subtracted from the accumulator (again, useful for the real component of a complex number).

7.4.13 Other DSP ASE instructions

• Branch on DSPControl ﬁeld: bposge32 branches if DSPControl[pos]≥ 32.

Typically the test is for “is it time to load another 32 bits of data from the bitstream yet?”.

• Circular buffer index update: modsub takes an operand which packs both a maximum index value and an index step, and uses it to decrement a “buffer index” by the step value, but arranging to step from zero to the provided maximum.

• Bitﬁeld insert with variable size/position: insv is a bit-insert instruction. It acts like the MIPS32 standard instruction ins except that the position and size of the inserted ﬁeld are speciﬁed not as immediates inside the instruction, but are obtained from DSPControl[pos] (which should be set to the lowest numbered bit of the ﬁeld you want) and DSPControl[scount] respectively.

• Bit-order reversal: bitrev reverses the bits in the low 16 bits of the register. The high half of the destination is zero.

The bit-reverse operation is a computationally crucial step in buffer management for FFT algorithms, and a 16bit operation supports up to a 32K-point FFT, which is much more than enough. A full 32-bit reversal would be expensive and slow.

7.5 Macros and typedefs for DSP instructions

It’suseful to be able to use fragments of C code to describe what some instructions do. To do that, we need to be able to refer to fractional types, saturation and vectors. Here are the deﬁnitions we’re using23:

95 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.6 Almost Alphabetically-ordered table of DSP ASE instructions

typedef long long int64; typedef int int32;

/* accumulator type */ typedef signed long long q32_31;

typedef signed int q31;

#define MAX31 0x7FFFFFFF #define MIN31 -(1<<31) #define SAT31(x) (x > MAX31 ? MAX31: x < MIN31 ? MIN31: x)

typedef signed short q15; #define MAX15 0x7FFF #define MIN15 -(1<<15) #define SAT15(x) (x > MAX15 ? MAX15: x < MIN15 ? MIN15: x)

typedef unsigned char u8; #define MAXUBYTE 255 #define SATUBYTE(x) (x > MAXUBYTE ? MAXUBYTE: x < 0 ? 0: x)

/* fields in the vector types are specified by relative bit position, but C definitions are in memory order, so these definitions need to be endianness-dependent */

#ifdef BIG_ENDIAN typedef struct{ q15 h1, h0; } ph;

typedef struct{ u8 b3, b2, b1, b0; } qb; #else typedef struct{ q15 h0, h1; } ph;

typedef struct{ u8 b0, b1, b2, b3; } qb; #endif

7.6 Almost Alphabetically-ordered table of DSP ASE instructions

Table 7.2 DSP instructions in alphabetical order

Instruction Description

absq_s.w rd,rt Q31/signed integer absolute value with saturation addq.ph rd,rs,rt 2×SIMD Q15 addition, without and with saturation of the result

addq_s.ph rd,rs,rt addq_s.w rd,rs,rt Q31/signed integer addition with saturation

23. This page needs more work, and I hope it will be improved in a future version of the manual.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 96

The MIPS32® DSP ASE

Table 7.2 DSP instructions in alphabetical order

Instruction Description

addsc rd,rs,rt Add setting carry, then add with carry.Thecarry bit is kept in DSPControl[c]. So to add

addwc rd,rs,rt

addu.qb rd,rs,rt 4×SIMD QBYTE addition, without and with SATUBYTE saturation.

addu_s.qb rd,rs,rt bitrev rd,rt Delivers the bit-reversal of the low 16 bits of the input (result has high half zero).

bposge32 offset Branch if DSPControl[pos]>=32. Like most branch instruction, it has a 16-bit “PC-rel-

cmp.eq.ph rs,rt Signed compare of both halves of twopaired-half(“PH”)values. Results are written into

cmp.le.ph rs,rt

cmp.lt.ph rs,rt cmpgu.eq.qb rd,rs,rt Unsigned simultaneous compare of all four bytes in quad-byte values. The four result

cmpgu.le.qb rd,rs,rt

cmpgu.lt.qb rd,rs,rt cmpu.eq.qb rs,rt Unsigned simultaneous compare of all four bytes in quad-byte values. The four result

cmpu.le.qb rs,rt

cmpu.lt.qb rs,rt dpaq_s.w.ph ac,rs,rt “Dot product and accumulate”, with Q31 saturation of each multiply result:

dpaq_sa.l.w ac,rs,rt Q31 saturated multiply-accumulate dpau.h.qbl qb rs, rt;

dpau.h.qbr Then for the lower bit-numbered bytes:

dpsq_s.w.ph ac,rs,rt Paired-half fractional “dot product and subtract from accumulator”

dpsq_sa.l.w ac,rs,rt Q31 saturated fractional-multiply, then subtract from accumulator:

dpsu.h.qbl ac,rs,rt qb rs,rt;

dpsu.h.qbr ac,rs,rt qb rs,rt;

extp rt,ac,size Extract bitﬁeld from an accumulator to register. The length of the ﬁeld (number of bits)

extpdp rt,ac,size

extpdpv rt,ac,rs

extpv rt,ac,rs

the 64-bit values inregistersyhi/ylo,zhi/zlo to produce a 64-bit valueinxhi/xlo,just do:

addsc xlo, ylo, zlo; addwc xhi, yhi, zhi

ative” target encoding.

DSPControl[ccond1-0] for high and low halves respectively (1 for true, 0 for false).

A signed compare works for both Q15 or signed 16-bit values.

bits are written into the four LS bits of general register rd.

bits are written into register DSPControl[cond3-0].

ph rs,rt; ac += SAT31(rs.h0*rt.h0 + rs.h1*rt.h1);

The accumulator is effectively used as a Q32.31 fraction.

ac += rs.b3*rt.b3 + rs.b2*rt.b2;

Dot-product and accumulate of quad-byte values ("l" for left, because these are the higher bit-numbered bytes in the 32-bit register). Not a fractional computation, just unsigned 8-bit integers.

qb rs, rt; ac += rs.b1*rt.b1 + rs.b0*rt.b0;

ph rs, rt; q32_31 ac; ac -= SAT31(rs.h1*rt.h1 + rs.h0*rt.h0);

q31 rs, rt; q32_31 ac; ac -= SAT31(rs*rt);

QB format dot-product and subtract from accumulator. This is an integer(not fractional) multiplication andcomesin “left” and “right” (higher/lower-bit numbered pair)versions:

ac -= rs.b3*rt.b3 + rs.b2*rt.b2;

ac -= rs.b1*rt.b1 + rs.b0*rt.b0;

can be an immediate constant or can be provided by a second source register (in the v variants). The ﬁeld position, though, comes from DSPControl[pos], which marks the highestnumbered bit of the ﬁeld (note that the MIPS32 standard bitﬁeld extract instructions specify the lowest bit number in the ﬁeld). In the dp variants like extpdp/extpdpv,

DSPControl[pos] is auto-decremented by the length of the ﬁeld extracted, which is use-

ful when unpacking the accumulator into a series of ﬁelds.

97 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.6 Almost Alphabetically-ordered table of DSP ASE instructions

Table 7.2 DSP instructions in alphabetical order

Instruction Description

extr.w rt,ac,shift Extracts a bit ﬁeld from an accumulator into a general purpose register. The LS bit of the

extr_r.w rt,ac,shift

extr_rs.w rt,ac,shift

extrv.w rt,ac,rs

extrv_r.w rt,ac,rs

extrv_rs.w rt,ac,rs

extr_s.h rt,ac,shift Obtain a right-shifted value from an accumulator and form a signed 16-bit saturated

extrv_s.h rt,ac,rs insv rt,rs The bitﬁeld insert in the standard MIPS32 instruction set is ins rt,rs,pos,size,

lbux rd,index(base) Load operations with register+register address formation. lbux is a load byte and zero

lhx rd,index(base)

lwx rd, index(base) maq_s.w.phl ac,rs,rt Non-SIMD Q15 multiply-accumulate, with operands coming from either the “left”

maq_s.w.phr ac,rs,rt

maq_sa.w.phl ac,rs,rt

maq_sa.w.phr ac,rs,rt mfhi rd, ac Legacy instruction, which now works on new accumulators (if you provide a second

mflo rd, ac

modsub rd,rs,rt Circular buffer index update. rt packs both the decrement amount (low 8 bits) and the

mthi rs, ac Legacyinstruction working on new accumulators. Movesdata from rd to the high half of

mthlip rs, ac Movesthe low half of the accumulator to the high half, then writes the GPR value in the

mtlo rs, ac Legacyinstructionworkingonnewaccumulators.Moves data from rd to the low half of

muleq_s.w.phl rd,rs,rt Multiply selected Q15 values from “left”/“right” (higher/lower numbered bits) of rd/rs

muleq_s.w.phr rd,rs,rt

muleu_s.ph.qbl rd,rs,rt A 2×SIMD 16-bit×8-bit multiplication.

muleu_s.ph.qbr rd,rs,rt

mulq_rs.ph rd,rs,rt 2×SIMD Q15 multiplication to two Q15 results. Result in general purpose register, hi/lo

extracted ﬁeld can start anywhere from bit zero to 31 of the accumulator:

int64 ac; unsigned int rt; rt = (ac >> shift) & 0xFFFFFFFF;

At option you can specify rounding (_r names):

int64 ac; unsigned int rt; rt = ((ac + 1<<(shift-1)) >> shift) & 0xFFFFFFFF;

and signed 32-bit saturation of the result (_s/_rs names). The extrv... variants specify the shift amount (still limited to 31 positions) with a register.

result.

and the position and size must be constants (encoded as immediates in the instruction itself). This instructionpermitstheposition and size to be calculated bytheprogram, and then supplied as DSPControl[pos] and DSPControl[scount] respectively. In this case DSPControl[pos] must be set to the lowest numbered bit in the ﬁeld to be inserted: yes, that’s different from the extp... instructions.

extend, lhx loads half-word and sign-extends, and lwx loads a whole word. The full address must be naturally aligned for the data type.

(higher bit number) or “right” (lower bit number) half of each of the operand registers. In all versions the Q15 multiplication is saturated to a Q31 results. The “_sa” variants saturates the add result in the accumulator to a Q31, too.

nonzero argument). Copies high/low half (respectively) of accumulator to rd.

highest index (high 24 bits), then this instruction calculates:

rd = (rs == 0) ? ((unsigned) rt >> 8): rs - (rt & 0xFF);

an accumulator.

low half.

an accumulator.

to a Q31 result in a general purpose register, Q31-saturating. Like all multiplies which target general purpose registers, it may well use the multiply unit and overwrite hi/lo, also known as ac0.

muleu_s.ph.qbl does something like:

rd = ((LL_B(rs)*LEFT_H(rt)) << 16) | ((LR_B(rs)*RIGHT_H(rt));

Note that the multiplications are unsigned integer multiplications, and each half of the result is unsigned-16-bit-saturated. The asymmetric source operands are quite unusual, and note this is not a fractional computation. muleu_s.ph.qbr is the same but picks the RL and RR (low bit numbered) byte values from rs.

or ac0 may be overwritten.

Programming the MIPS32® 74K™ Core Family, Revision 02.14 98

The MIPS32® DSP ASE

Table 7.2 DSP instructions in alphabetical order

Instruction Description

mulsaq_s.w.ph ac,rs,rt ac += (LEFT_H(rs)*LEFT_H(rt)) -

(RIGHT_H(rs)*RIGHT_H(rt));

The multiplications are done to Q31 values, saturated if they overﬂow (which is only possible when -1¥-1 makes +1). The accumulator is really a Q32.31 value, so is unlikely to overﬂow; no overﬂow check is done on the accumulation.

packrl.ph rd,rs,rt pack a “right” and “left” half from different registers, ie

rd = (((rs & 0xFFFF) << 16) | (rt >> 16) & 0xFFFF);

pick.ph rd,rs,rt Like a 2-way SIMD conditional move:

ph rd,rs,rt; rd.l = DSPControl[ccond1] ? rs.l: rt.l; rd.r = DSPControl[ccond0] ? rs.r: rt.r;

pick.qb rd,rs,rt Kind of a 4-way SIMD conditional move:

qb rd,rs,rt; rd.ll = DSPControl[ccond3] ? rs.ll: rt.ll; rd.lr = DSPControl[ccond2] ? rs.lr: rt.lr; rd.rl = DSPControl[ccond1] ? rs.rl: rt.rl; rd.rr = DSPControl[ccond0] ? rs.rr: rt.rr;

preceq.w.phl rd,rt Convert a Q15 value (either left/high or right/low half of rt) to a Q31 value in rd.

preceq.w.phr rd,rt

precequ.ph.qbl rd,rt Simultaneously convert two unsigned8-bitfractions from rt to Q15 and load intothetwo

precequ.ph.qbla rd,rt

precequ.ph.qbr rd,rt

precequ.ph.qbra rd,rt

preceu.ph.qbl rd,rt Zero-extend two unsigned byte values from rt to unsigned 16-bit and load into the two

preceu.ph.qbla rd,rt

preceu.ph.qbr rd,rt

preceu.ph.qbra rd,rt

precrq.ph.w rd,rs,rt precrq.ph.w makesapaired-Q15value by taking the MS bitsoftheQ31values in rs

precrq_rs.ph.w rd,rs,rt

precrq.qb.ph rd,rs,rt Form a quad-byte value from two paired-halves. We use the upper 8 bits of each half-

precrqu_s.qb.ph Does the same, but each conversion is rounded and saturated to an unsigned byte. Note

precrqu_s.qb.ph rd,rs,rt

raddu.w.qb rd,rs Set rd to the unsigned 32-bit integer sum of the four unsigned bytes in rs. rddsp rt,mask Read the contents of the DSPControl register into rt, but zeroing out any ﬁelds for

repl.ph rd,imm Replicate the same signed value into the two halves of a PH value in rd; the value is

replv.ph rd,rt

repl.qb rd,imm Replicate the same 8-bit value into all four parts of a QB value in rd; the value can come

replv.qb rd,rt shilo ac,shift Do a right or left shift (use a negative value for a left shift) of a 64-bit accumulator. The

shilov ac,rs

halves of rd.

precequ.ph.qbl uses rt.ll/rt.lr; precequ.ph.qbla uses rt.ll/rt.rl; precequ.ph.qbr uses rt.rl/rt.rr; and precequ.ph.qbra uses rt.lr/rt.rr.

halves of rd.

preceu.ph.qbl uses rt.ll/rt.lr; preceu.ph.qbla uses rt.ll/rt.rl; preceu.ph.qbr uses rt.rl/rt.rr; and preceu.ph.qbra uses rt.lr/rt.rr.

and rt, like this:

rd = (rs & 0xFFFF0000) | ((rt>>16) & 0xFFFF);

precrq_rs.ph.w is the same, but rounds and Q15-saturates both half-results.

word value, as if we were converting an unsigned 16-bit fraction to an unsigned 8-bit fraction. In C: rd = (rs & 0xFF000000) | (rs<<8 & 0xFF0000) |

(rt>>16 & 0xFF00) | (rt>>8 & 0xFF);

in particular that a negative Q15 quantity yields a zero byte, since zero is the smallest representable value.

which the appropriate mask bit is zeroed, see Figure 7.1 above.

either provided as an immediate whose range is limited between -512 and +511 (repl.ph) or from the rt register (replv.ph).

from an immediate constant, or the rt register of the replv.qb instruction.

right shift is “logical”, bringing in zeroes into the high bits. shilo takes a constant shift amount, while shilov get the shift amount from rs. The shift amount may be no more than 31 right or 32 left.

99 Programming the MIPS32® 74K™ Core Family, Revision 02.14

7.7 DSP ASE instruction timing

Table 7.2 DSP instructions in alphabetical order

Instruction Description

shll.ph rd, rt, sa 2×SIMD (paired-half) shift left. The “v” versions take the shift amount from a register,

shllv.ph rd, rt, rs

shll_s.ph rd, rt, sa

shllv_s.ph rd, rt, rs shll.qb rd, rt, sa 4×SIMD quad-byte shift left, with shift-amount-in-register and saturating (to an

shllv.qb rd, rt, rs shll_s.w rd, rt, sa Signed 32-bit shift left with saturation, with shift-amount-in-register shllv_s option.

shllv_s.w rd, rt, rs shra.ph rd, rt, sa 2×SIMD paired-half shift-right arithmetic (“arithmetic” because the vacated high bits of

shra_r.ph rd, rt, sa

shrav.ph rd, rt, rs

shrav_r.ph rd, rt, rs

shra_r.w rd, rt, sa 32-bit signed/arithmetic shift right with rounding, see the bullet on rounding.

shrav_r.w rd, rt, rs shrl.qb rd, rt, sa 4×SIMD shift right logical (“logical” means that the vacated high bits are ﬁlled with

shrlv.qb rd, rt, rs

subq.ph rd,rs,rt 2×SIMD subtraction. subq_s.ph saturates its results to a signed 16-bit range.

subq_s.ph rd,rs,rt subq_s.w rd,rs,rt 32-bit saturating subtraction. subu.qb rd,rs,rt 4×SIMD quad-byte subtraction. Since quad-bytes are treated as unsigned, the saturating

subu_s.qb rd,rs,rt

wrdsp rt,mask Write the DSPControl register with data from rt, but leaving unchanged any ﬁelds for

and the “_s” versions saturate the result to a signed 16-bit range.

unsigned 8-bit result) versions.

the value are replaced by copies of the input bit 16, the sign bit) - thus performing a correct division by a power of two of a signed number. As usual the shra_v variant has the shift amount speciﬁed in a register. The _r versions round the result ﬁrst (see the bullet on rounding above).

zero, appropriate since the byte quantities in a quad-byte are usually treated as unsigned.)

variant subu_s.qb works to an unsigned byte range.

which the appropriate mask bit is zeroed, see Figure 7.1 above.

7.7 DSP ASE instruction timing

Most DSP ASE operations are pipelined, and instructions can often be issued at the maximum CPU rate, but getting results back into the general-purpose register ﬁle takes a few clocks. The timings are generally fairly similar to those for the standard multiply instructions, and are listed - together with delays for the standard instruction set - in Section

6.6.2, "Data dependency delays classified".
