MM-3
9
Dynamic Microphone
Key Features
Technical Specifications
Fitted with interchangeable MU-39 supercardioid capsule module.
Unique shock absorber design for low handling or touch noise.
The exterior multi-layer metal grille protects the capsule to prevent impact and pop noise.
Focuses on the main sound source and minimizes background noise and feedback.
Soft and mellow sound quality; Rich high and low-frequency presence.
Sustains high SPL without distortion.
Capsule MU-39 Dynamic (interchangeable)
Housing Die-cast zinc alloy
Polar Pattern Supercardioid
Sensitivity -54 dBV / Pa (0 dB=1 V Open-circuit voltage)
Frequency Response 50 Hz – 18 kHz
Output Impedance 400 Ω ± 30%
Dimensions (Ø × L) 51 × 204 mm / 2 × 8 "
Weight Approx. 363 g / 12.8 oz
MIPRO Electronics Co., Ltd
Headquarters: 814 Pei-kang Road, Chiayi, 60096, Taiwan
Tel: +886.5.238.0809 | Fax: +886.5.238.0803
www.mipro.com.tw | [email protected]
Specifications subject to change without notice. SS016/05
