Mio 400 Instruction Manual
User Manual
Cyclo™ 400/600 Series
Welcome
Contents
Thank you for purchasing this Mio. Please read this manual carefully
before using your Mio for the first time. Keep this manual in a safe place
and use as your first point of reference.
Important information for using the manual
It is important to understand the terms and typographical conventions
used in this manual.
Bold — Components or items displayed on screen, including buttons,
headings, field names and options.
Italics — Indicates the name of a screen.
Disclaimer
Not all models are available in all regions.
Depending on the specific model purchased, the colour and look of your
device and accessories may not exactly match the graphics shown in
this document.
Mio operates a policy of ongoing development. Mio reserves the right
to make changes and improvements to any of the products described
in this document without prior notice. Mio does not warrant that this
document is error-free. The screenshots and other presentations shown
in this manual may differ from the actual screens and presentations
generated by the actual product. All such differences are minor and the
actual product will deliver the described functionality as presented in this
User Manual in all material respects.
Copyright
© MiTAC International Corp. Mio is either a registered trademark or
trademark of MiTAC International Corporation and is used under licence
by Mio Technology Limited. All rights reserved.
All other trademarks and registrations are the property of their respective
owners.
ANT+™
subsidiaries.
Revision: R00
(5/2017)
is a trademark of Dynastream Innovations Inc. or its
Welcome..............................................................................................2
Knowing your device ...........................................................................4
Accessories ....................................................................................4
Getting started .....................................................................................5
Charging the battery .......................................................................5
Performing the initial start-up .........................................................5
Connecting your device to the computer ........................................6
Installing the device .............................................................................6
Mounting the device on your bike...................................................6
Installing the sensors on your bike (Cyclo 405 HC) .......................7
Installing the sensors on your bike (Cyclo 605 HC) .......................7
Putting on the heart rate monitor ....................................................8
Operating basics .................................................................................9
Using the POWER button...............................................................9
Using the touch screen.................................................................10
Main menu....................................................................................10
Keyboard screen .......................................................................... 11
Managing data on the device ............................................................12
CycloAgent ...................................................................................12
Viewing Dashboard screens ..............................................................13
Starting navigation .............................................................................14
Using the Navigate wizard............................................................14
Navigating to Home ......................................................................14
Finding the location by Address ...................................................15
Searching for a POI ......................................................................15
Tracks ...........................................................................................15
Searching for a location from the map screen..............................16
Using live segments .....................................................................16
Navigating to your Favourite ........................................................16
Searching for a location using GPS coordinates ..........................17
Other navigating options ..............................................................17
Surprise Me .......................................................................................18
Loop .............................................................................................18
2
A to B (Address, POI, Favourite, or Point on map).......................18
Workout mode ...................................................................................20
Workout by Distance ....................................................................20
Workout by Time ..........................................................................20
Workout by Calories .....................................................................21
Workout by HR Zone ....................................................................21
Workout by Power Zone ...............................................................21
Indoor training mode ....................................................................22
Using the lap feature .........................................................................23
Viewing the History ............................................................................23
Viewing the summary of recorded data ........................................23
Using WIFI .........................................................................................24
Pairing with your smartphone ............................................................25
Notifications of incoming calls and text messages .......................26
Customising your device ...................................................................26
Profiles .........................................................................................27
Routing .........................................................................................27
Dashboard ....................................................................................27
Sensors ........................................................................................28
WIFI Sync .....................................................................................28
Phone ...........................................................................................28
Where Am I...................................................................................28
Manage ........................................................................................29
Shimano Di2 .................................................................................29
Lap ...............................................................................................29
Maps.............................................................................................29
Define Zones ................................................................................30
System .........................................................................................30
Product Info ..................................................................................32
For more information .........................................................................32
Online support ..............................................................................32
Caring for your Mio .......................................................................32
Resetting the device .....................................................................33
Troubleshooting ............................................................................33
What is GPS? ...............................................................................33
IPX7..............................................................................................34
Safety precautions........................................................................34
Regulatory information .................................................................35
End user license agreement.........................................................35
3
Knowing your device
Status indicator
❶
Glows in amber: battery charging
•
Glows in green: battery full
•
Flashes in g reen: w hen the backl ight is
•
turned off.
Touch screen
❷
POWER button
❸
Press and hold to turn your device on and
•
off.
Press to adjust backlight.
•
START/STOP button
❹
Starts or stops recording.
•
LAP button
❺
Starts a new lap.
•
Bike mount socket
❻
For the device mount.
•
Speaker
❼
Micro-USB connector
❽
Connects to the charger or USB cable.
•
Accessories
Your device comes with the following accessories. To use your device
on a bike, ensure you use the specific bike mount kit that came with
your device. Mio may provide optional accessories for specific models.
Please visit Mio website (www.mio.com) for information.
• Power adapter*
• USB cable
• Bike mount kit
• Heart rate belt** (ANT+™ sensor)
• Speed and cadence sensor kit** (ANT+™ sensor)
*Cyclo 605 series only
**May be sold separately and used for Cyclo 405/605 HC only. For Cyclo 605 HC, the
sensors will enter Sleep mode after 15 minutes of inactivity, and wake up automatically
and transfer data to your device after 20 seconds of activities.
Note: Depending on the specific model purchased, the colour and look of your device
and accessories may not exactly match the graphics shown in this document.
Note: This device is ANT+ certified. Visit www.thisisant.com/directory for a list of
compatible products and apps.
Note: Do not operate the device while driving or riding a bike. Using this product does
not change the requirement for a driver or a bike rider to take full responsibility for his or
her behaviour.
4
Getting started
Charging the battery
Your device has an internal battery that may not be fully charged when
you purchase it. You should charge the battery for at least 8 hours before
you start using it for the very first time.
To charge the battery:
• Via the computer
Connect your device to the computer by using the provided USB
cable. For more information, see "Connecting your device to the
computer" in this section.
• Using a mains power socket (Cyclo 605 HC only)
Connect your device to the power adapter by using the USB cable.
Plug the mains power charger into the power socket.
Note: It is recommended to use the supplied power adapter (selected models only; may
be sold separately) for a shorter charging time.
CAUTION:
For optimal performance of the lithium battery, note the following:
• Do not charge the battery where the temperature is high (e.g. in direct sunlight).
• Failure to follow the battery usage instructions could cause damage to your device,
battery and even bodily injury or property damage and will void the warranty.
• When storing the product for a long period of time, charge the battery to 50% –
80% capacity to prevent excess discharge.
Performing the initial start-up
1. Mount the device and accessories on to your bike. For more
information, see the “Installing the device” section.
2. Press and hold the POWER button for 3 seconds to turn your device
on.
3 SEC
3. Follow the prompts to personalise your device, including:
• Select your preferred language.
• Set the date and time.
• Set the units format.
• Create your user profile.
Note: You can change these settings while using the device by tapping Main menu
> Settings.
4. Activate the map.
5
Enter the Startup Key (which is printed on the bottom of the box) and
then tap OK to unlock your device. You will only have to do this the
first time you use the device.
5. Once your device is turned on, it will search for satellite signals
automatically. This may take several seconds depending on the
location.
When GPS is fixed, the GPS signal icon (
the GPS status.
Note: Depending on your device model, it will also automatically scan and pair the
accessories (for heart rate monitor and cadence/speed sensor only) with the device.
You can also scan the accessories manually while using the device by tapping Main
menu > Settings > Sensors.
) on the screen indicates
Connecting your device to the computer
1. Turn on the computer.
2. Turn on your device.
3. Connect the Micro-USB end of the USB cable to the back of your
device and the other end to a USB port on your computer.
4. Select the desired connection type from the pop-up message window:
• Connect to PC: Your device will be recognised as two external
mass-storage drives: Mio_system and Mio_data. You can use
Windows File Explorer to copy/move the files from the computer
to your device. A USB Connection screen appears to prevent you
from using your device.
DONOTdeleteanylesthatarepre-installedonthedevice.
Deletingthelescancausethedevicetocrash.Mioisnot
responsibleforproductqualitycausedbyledeletion.
• Charge only: You will be able to continue using your device with
the battery in charging mode via the computer.
Installing the device
Mounting the device on your bike
The bike mount kit includes two types of rubber pads, allowing you to
attach the bike mount to your bike securely.
1. Selecttherubberpadthatbesttsthehandlebarsonyourbikeand
then attach it using the two plastic straps.
2. Align the latch on the back of the device with the slot on the bike
mount, and then rotate the device clockwise to lock the device to the
bike mount.
You can choose to mount the device on the handlebar or on the stem.
See the following figure for the examples of mounting the device.
6
3. To remove the device from the bike mount, rotate it counterclockwise.
Installing the sensors on your bike (Cyclo 405 HC)
1. Follow the instruction below to install the cadence/speed sensor kit
on your bike.
3 – 5 mm
3 – 5 mm
2. Ensure that the magnets are aligned with the sensing area on the
sensors.
3. When done, you can manually pair the sensor with your device by
tapping Main menu > Settings > Sensors > Cadence/Speed.
The cadence sensor contains a replaceable CR2032 battery. Follow the
instructions below to replace the battery:
1. Locate the battery cover on the back of the sensor, and then twist the
cover anticlockwise (e.g. by using a coin) to remove the cover and
battery.
2. Insert the new battery into the battery chamber and replace the cover.
3. Twist the cover clockwise (e.g. by using a coin) to close the cover.
Installing the sensors on your bike (Cyclo 605 HC)
1. Follow the instruction below to install the cadence/speed sensor kit
on your bike.
• Speed sensor
1 2 3 4
7
• Cadence sensor
1 2 3 4
2. When done, you can manually pair the sensor with your device
by tapping Main menu > Settings > Sensors > Speed sensor /
Cadence sensor.
The speed/cadence sensor contains a replaceable CR2032 battery.
Follow the instructions below to replace the battery:
1. Locate the battery cover on the back of the sensor, and then twist the
cover anticlockwise (e.g. by using a coin) to remove the cover and
battery.
2. Insert the new battery into the battery chamber and replace the cover.
3. Twist the cover clockwise (e.g. by using a coin) to close the cover.
Putting on the heart rate monitor
Note: Please note the heart rate monitor is not a medical device and its readings are
not a substitute for obtaining measurements that require medical precision. It is strongly
recommended to consult a doctor if you have a pacemaker or other implemented
devices before using the heart rate monitor.
1. Before using the heart rate monitor, wet the contacts on the back of
the chest strap.
Note: If possible, you can also use an electrolyte gel (usually available in local
sports stores) to ensure good contact.
2. Adjust the elastic strap so it’s snug while you are putting it on. Ensure
that you can take a good deep breath after putting on the strap.
3. Follow the instructions below to wrap the strap around your back, and
then secure it on the other side with the buckle.
Putting on the heart rate monitor is like wearing a belt around your
lower chest.
4. When done, you can manually pair the monitor with your device by
tapping Main menu > Settings > Sensors > Heart rate.
The heart rate monitor contains a replaceable CR2032 battery. Follow
the instructions below to replace the battery:
8
1. Locate the battery cover on the back of the monitor, and then twist
the cover anticlockwise (e.g. by using a coin) to remove the cover
and battery.
2. Insert the new battery into the battery chamber and replace the cover.
3. Twist the cover clockwise (e.g. by using a coin) to close the cover.
Operating basics
Using the POWER button
• Turning on the device
Press and hold the POWER button for 3 seconds to turn on your
device.
3 SEC
• Turning off the backlight
You can set the device to turn off the backlight automatically to
reduce the battery consumption: Main menu > Settings > System >
Screen > Backlight Timer.
Resume using the device to
• Turning off the device
Press and hold the POWER button for 3 seconds to pop up the
Power Off/Cancel screen. Choose Power Off to turn off the device or
Cancel to continue operating the device.
turn on the backlight.
9
3 SEC
Your device will automatically turn off after 10 minutes (by default) of
inactivity.
be turned off if you do not make a selection.
Note: You can change the auto power off setting by tapping Main menu > Settings
> System > Screen > Auto Power Off Timer.
• Navigating through the screens
While the device is turned on and you are navigating through the
menu screens, tap
Using the touch screen
To operate your device, touch the screen with your finger. You can
perform the following actions:
• Tap
Quick touch the screen once to open menus or select on-screen
button/option.
• Drag
While navigating on the map, tap and hold on the screen without
releasing your finger to move the map to the desired position.
• Slide
Depending on your model, drag your finger vertically or horizontally
across the screen.
• Drag to the left/right to switch to another menu screen.
• Drag to the top/bottom to scroll up/down a list.
Note: Not all slide gestures are applicable to all screens.
The Power Off/Cancel screen
to return to the previous screen.
will pop up and the device will
Unlocking the screen
Your device will automatically lock the screen after 30 seconds (by default)
of inactivity. When the screen is locked, press the POWER button briefly
to unlock the screen.
Note: You can change the screen lock setting by tapping Main menu > Settings >
System > Screen > Screen Lock Timer.
Main menu
The Main menu is your starting place for various tasks, providing quick
access to applications and settings. Tap a button to start a task or open
another menu.
No. Description
The Dashboard displays the view of functions, including the navigation and
❶
training screens.
Your trip/training can be saved in the history records. When your ride
❷
is finished, you can check the history data such as date/time, distance,
speed, altitude, etc.
10
No. Description
You can set workouts by entering your goals, such as by distance, by time,
❸
or by calories.
Start to plan your route by selecting the locations, such as home, address,
❹
tracks, POI, etc.
Based on distance or time, the device will plan 3 routes for you to choose
❺
from.
There are various customisation options available to enhance your riding
❻
experience. You can customise the system settings, user profiles and
more.
System icons
Various System icons in the title bar at the top of the screen provide the
status information of your device. Depending on your settings, the icons
may be different to provide various information of your device. Please
note that these icons will not be always displayed during your trip/
training.
❶ ❷ ❺❻❼❸❹ ❽ ❾ ❿ ⓫⓬
No. Icon Description
Time display Displays the current time.
❶
The device will automatically set the correct time
basedonthecurrentGPSxes.
User profile
❷
/ / : Bike (city bike/mountain bike/
race bike) navigation mode enabled.
: Running navigation mode enabled.
: Indoor training mode enabled (navigating
function of the device will be disabled).
No. Icon Description
Heart rate sensor Depending on your model, the icon will display when
❸
Cadence sensor*
❹
Speed sensor*
❺
Power sensor*
❻
Trainer*
❼
Di2 sensor*
❽
Recording status
❾
the sensor is paired with the device.
• The icon is not displayed when not activated in the
Sensors setting.
• The icon is greyed out when activated, but not
paired with the device.
• The icon is white when the connection is made, or
blinking when the pairing is in progress.
: The device is recording your trip/training.
: Recording has been paused.
Bluetooth status* When the Bluetooth function is enabled:
❿
: No phone is connected. The icon flashes when a
connection is being made.
: A phone is connected.
: There are missed calls or new text messages on
the connected phone.
GPS signal The GPS signal icon indicates the GPS status.
⓫
A bar shows the strength of the GPS signal being
received; the more bars the stronger the signal.
Battery status The Battery icon indicates the remaining battery
⓬
power.
Keyboard screen
The Keyboard screen will display when you are required to enter text,
such as when searching for a street name. Search results will be listed
in matching order, with the closest matches appearing on the screen.
The Keyboard screen can display with various layouts depending on the
information you need to enter.
Example: entering the street name while searching for an address
11
Numeric keypadABC keyboard
Tap to switch between the ABC keyboard and Numeric keypad.
How do I enter characters/numbers?
• Tap the keys to enter letters or numbers.
The keyboard features the “Predictive text” technology that allows
addresses to be searched easily and quickly. As you enter a letter
of an address, your device will compare all possible combinations
against the maps.
• Tap
• When done, tap
Changing the keyboard layout
The device supports Russian, Bulgarian, and Greek keyboard for local
users. You can enable (or disable) the desired keyboard from Main
menu > Settings > System > Keyboard.
to delete the character.
.
Managing data on the device
CycloAgent
CycloAgent™ is a tool for synchronising data between your CycloTM
device and the MioShareTM website, and for managing and updating your
Cyclo device via your computer.
Note: Make sure that you have an active Internet connection for this feature. Please
make sure of the stable Internet connection and bandwidth for the possible large file of
the map update.
Visit the MioShare website (http://www.mioshare.com/help) to download
CycloAgent.
For the detailed information on using CycloAgent, refer to the
CycloAgent documentation.
Sharing your experience on the Internet
By using MioShare, you can easily share your experiences with other
cyclists around the world through the Internet when your device is
connected to the computer. For more information, visit: http://mioshare.
com/
12
Loading...
