AC-DC REGULATED SWITCHING POWER ADAPTER SPECIFICATION
MODEL NO. MW3R15GS ISSUE DATE 2008-11-21
CUSTOMER REF. NO.
INPUT
INPUT VOLTAGE 100 to 240 Vac
INPUT FREQUENCY 50/ 60 Hz
NO LOAD POWER CONSUMPTION 0.3 W
INPUT FULL LOAD CURRENT(at 100 Vac) 0.35 A
INPUT POWER 23.7W Max
OUTPUT
LIGHT LOAD OUTPUT VOLTAGE 3/4.5/5/6/7.5/9/12 V dc ±10%
FULL LOAD OUTPUT VOLTAGE 3/4.5/5/6/7.5/9/12V dc ±10%
MIN LOAD OUTPUT CURRENT 0 A
MAX LOAD OUTPU T CU R RENT 1.5 A
NOISE TEST BANDWIDTH 20MHz Each output bypasse d by a 10uF electrolytic capacitor par allel with a 0.1uF ceramic capacitor to GND
LINE R EGULATION 0.5 % Input 90 to 264 Vac output loaded at full load
SETUP,RISE,HOLD UPTIME 200ms,30ms,17ms/115Vac; 200ms,20ms,80ms/230Vac
OVERALL PERFORMANCE
TOTAL OUTPUT POWER 18 W Max
EFFICIENCY COMPLIED with CEC-400-2006-002-REV1 Efficiency level Table U2 Requirement.
PROTECTION
■ OVER CURRENT PROTECTION ■ SHORT CIRCUIT PROTE CTION
■ OVER VOLTAGE PROTECTION ■ L.P.S (Limits for power s ource)
■ OVER POWER PROTECTION □ AUTOMATIC THERMAL PROTECTION
HI-POT
INPUT TO OUTPUT
INPUT TO CASE
OUTPUT TO CASE
ISOLATION RESISTANCE
APPLIANCE
ENVIRONMENTAL
OPERATING TE MPERATURE 0 to 25
STORGE TEMPERATURE -20 to 60
OPERATING HUMIDITY 20%-85% RH. NON-CONDENSING
STORGE HUMIDITY 10%-90% RH. NON-CONDENSING
SAFFTY STANDARDS
SAFETY STANDARDS GS
EMC STANDARDS CE
3000Vac 5 mA 50/60 Hz
3000Vac 5 mA 50/60Hz
1500 Vac 5 mA 50/60Hz
100 M Ohms I/P-O/P I/P/Enclosure
□ ■ □
CLASS
RELIABILITY
MTBF 50000 H ours m in
BURN-IN 4 Hours 25,full load,220Vac,50Hz
Minwa Electronics Co.,Ltd
Minwa China (Huizhou) Electronics Co.,Ltd
Page:1/2
AC-DC REGULATED SWITCHING POWER ADAPTER SPECIFICATION
MODEL NO. MW3R15GS ISSUE DATE 2008-11-21
CUSTOMER REF. NO.
MECHANICAL SPECIFICATION
DIMEMSION
WEIGHT 145g MAX exclude packing
INPUT CORD
INPUT PLUG
OUTPUT CORD
OUTPUT PLUG
OUTPUT CONNECTOR
APPEARANCE & DIMENSIONS
82 mm(L)*51 mm(W)* 73.2mm(H)
EU
APPROVE: AUDITING: CONNER:
