Perfect Protection For Rack-Mount Systems
The PRO-RT Series is a value-priced, yet feature-rich
UPS incorporating line-interactive technology that preserves
battery power by providing voltage regulation during
brownouts or voltage sags. The PRO-RT Series can be
used to support servers, telecom or VoIP systems, security
systems, plus many other applications.
An LCD display provides visual notication of power
status, including input voltage, frequency, percent of battery
charge, estimated runtime, plus many other conditions.
Versatile Communications
Each PRO-RT model includes Minuteman’s SentryPlus®
power management and diagnostic software. When installed
on a workstation or server, the user gains complete control
over monitoring and managing the UPS using a convenient
web browser-based interface. The SentryPlus software
communicates via a built-in USB port or through a RS-232
connector on the UPS. In addition, managing the UPS within
a Network Management System (NMS) is easy with the
installation of an optional SNMP card.
Designed for versatility, the PRO-RT models can be
mounted in a standard rack using the included rackmount
ears. These ears can also be attached to the unit to allow it
to stand as a tower. An optional kit is available for mounting
the unit to a wall.
High-end Features - Budget Friendly Price
The PRO-RT oers many features normally found on
higher priced models, including an LCD status display which
shows the following:
• Input / Output voltage and frequency
Monitor the status of your utility power
• UPS and battery mode / status
Eliminate guesswork with straightforward display of the
unit's status
• Load capacity
Load indicator shows how much electrical load is
being placed on the unit
• Estimated runtime based on
connected load
Find out how much backup time
remains during a blackout right on
the unit
PRO-RT™ Series Line-Interactive UPS
PRO1000RT, PRO1500RT, PRO1000RTNC, PRO1500RTNC
Capacity
Small
Applications
In addition to the LCD display, the PRO-RT also oers:
• Rack/tower installation
(2U rack height) or wall mounting with optional kit
• Minuteman SentryPlus Software
SentryPlus auto-shutdown and monitoring software is
included with every unit.
• RS-232 and USB Communications
No special USB drivers are required for USB communications. Both units are automatically recognized by
Microsoft® Windows® as HID-compliant devices –
similar to a mouse or a keyboard.
• SNMP compatible
Each PRO-RT unit can be managed on a network with
the addition of an optional SNMP management card.
NC models feature pre-installed netwrok card.
• Fax/Modem/Network Line Protection
The PRO-RT UPS provides a low cost means of
protecting fax/modem/network lines.
• RoHS Compliant
All PRO-RT products are manufactured using non-hazardous*
materials making them safer for
the environment and a greenfriendly addition to any data
center.
• Warranty
Each PRO-RT UPS
system is covered by
a three-year parts and
labor warranty and
$100,000 Minuteman
Platinum Protection
Plan® (U.S.A. and
Canada
Midsize Enterprise level
VoIP SystemsNetwork/Server IP/Analog Phone & Security
*Excludes lead acid batteries
Para Systems, Inc. | Minuteman Power Technologies
1455 LeMay Drive | Carrollton, Texas 75007 | 972.446.7363 | 800.238.7272
www.minutemanups.com | www.sizemyups.com
Minuteman® PRO-RT™ Series Line-Interactive UPS Specifications
NC models include pre-installed network card
Model Number PRO1000RT / PRO1000RTNC PRO1500RT / PRO1500RTNC
VA Rating 1000VA 1500VA
Max Output Power 700Watts 1050Watts
Output Receptacles (6) NEMA 5-15R Battery & surge
(2) NEMA 5-15R Surge only
Input Connection 10 ft. Power cord with NEMA 5-15P
Input (non-battery operation)
Voltage Range 90 to 150VAC
Frequency Range 50/60Hz ±5Hz, auto-sensing
AC Leakage Current <1.0mA at full rated non-linear load
Input Protection Resettable circuit breaker
Output (non-battery operation)
Voltage Range 104 to 132VAC
Frequency 50/60Hz ±5Hz
Eciency (AC-AC) >90% at full rated non-linear load
Output (battery operation)
Voltage 120VAC
Voltage Regulation Nominal ±5% until low battery warning
Frequency 50/60Hz, ±0.5Hz (unless synchronized to utility)
Wave Form Simulated sine wave
Typical Transfer Time 6-10 ms (max 10ms)
Overload Capacity 110% for 10 seconds, 120% shutdown immediately
Protection Over-current, short-circuit protected, and latching shutdown
Estimated Runtimes - Full /Half Load 5 min. / 16 min. 5 min. / 17 min.
Battery System
Hot Swappable Battery Yes
Internal Battery Module BM0043 BM0044
DC Leakage Current <30uA (±10uA) with no AC applied and the unit in the o position
Battery Type Sealed, non-spillable, maintenance-free, valve-regulated lead acid
Surge Protection
Surge Energy rating 1140 joules
Surge Current Capacity 6500 Amps total
Surge Response Time 0-ns (instantaneous) normal mode; <5ns common mode
Certifications
Agency Approvals cTUVus (conforms to UL1778, CSA 22.2 standards), CE
EMI/RFI Filtering FCC Part 15 Class B, EN5022, EN61000-6-1, EN61000-6-3, EN61000-4-5
Environmental
Temperature : Operating (Storage) 0º to +40ºC / +32º to +104ºF (-15º to +45ºC / +5º to 113ºF)
Humidity: Operating & Storage 0 to 95% non condensing
Elevation: Operating (Storage) 0 to +3,000 m / 0 to +10,000 ft (0 to +15,000 m / 0 to +50,000 ft)
Physical
Weight: Lbs/Kgs 35.1 / 15.9 43.0 / 19.5
Dimensions (H x W x D): Inch/mm 3.5” x 17.3” x 15.7” / 89 x 440 x 398
(6) NEMA 5-15R Battery & surge
(2) NEMA 5-15R Surge only
PRO-RT Series Features
1
5
3
4
6 7
© Copyright 2016, Para Systems, Inc. Product specications are subject to change without notice. Minuteman and Minuteman
Platinum Protection Plan are registered trademarks and PRO-RT and SentryPlus are trademarks of Para Systems, Inc.
8
1455 LeMay Drive | Carrollton, Texas 75007 | 972.446.7363 | 800.238.7272
1 LCD Status Display
2 Rack/Tower Convertible Mounts
3 USB and RS-232 Ports
2
4 Phone/Fax/Network Port
5 SNMP Accessory Panel
6 Six (6) Battery & Surge Outlets
7 Two (2) Surge-only Outlets
8 10 ft. Input Power Cord
Para Systems, Inc. | Minuteman Power Technologies
www.minutemanups.com | www.sizemyups.com
PN-34000406 - 10-16
