MINOX BL 8x56, BL 13x56 and BL 15x56

Lightweight and powerful classic hunting binoculars

Pr o d u c t In f o r m at I o n

The successful MINOX BL binocular series
has now been extended to include three new
models with enormous light-gathering power.
These perfect companions for game and nature
observation in moonlight or twilight conditions
are low in weight, with uncompromising quality
and are available at an attractive price. In spite
of their extreme twilight performance the MINOX
BL 8x56, BL 13x56 und BL 15x56 each weigh
just over 1000 grams. All three are ideal tools
for nature and game observation and set a new
standard in this segment.

The BL series is distinguished by a particularly
lightweight design. The special properties of
the innovative polycarbonate material provides
a light and sturdy binocular body. With their

Technical Data

Magnification
Front lens diameter
Exit pupil
Field of view

at 1,000 m

Close distance 29.5 ft / 9.0 m 23.0 ft / 7.0 m 23.0 ft / 7.0 m
Eye relief
Diopter adjustment ± 3 dpt ± 3 dpt ± 3 dpt
Geom. twilight number 49.0 18.6 13.9
Operating temperature 14° up to 122° F

Waterproof, down to 16.4 ft / 5 m 16.4 ft / 5 m
Height x Width x Depth 6.65 x 5.7 x 2.59 in.

Weight, approx. 36.9 oz / 1,040 g 38.1 oz / 1,080 g 38.1 oz / 1,080 g

Order number 62165 62166 62036

at 1,000 yds

BL 8x56 BR BL 13x56 BR BL 15x56 BR

8 x

2.20 inch / 56.0 mm 2.20 inch / 56.0 mm 2.20 inch / 56.0 mm

0.28 inch / 7.0 mm
326 ft / 6.2°

108 m / m 6.2°

0.82 inch / 20.8 mm

-10° up to +50° C

196 x 145 x 66 mm

ergonomic design and rubber armoring the 56
mm BL binoculars are good and reliable to hold.
The smooth operation of the new metal focusing
wheel with rubber ribs is quick to adjust and fea­tures a finger-felt marking for the infinite setting.
By feeling the actual setting the user can quickly
focus on the game in view, even in deep twilight.
With resting forearms also the models with 13x
and 15x magnification can also be moved quickly
and steadily. As an alternative, a tripod can be
used that is attached to the tripod thread via a
quick-action adapter.

The powerful optical system of the BL
binoculars has multi-coated lens elements
that guarantee highest optical performance
and neutral color rendition of the subject

13 x 15 x

0.175 inch / 4.3 mm 0.15 inch / 3.7 mm
263 ft / 5°

88 m / 5°

0.56 inch / 15.2 mm 0.69 inch / 17.4 mm

14° up to 122° F

-10° up to +45° C

6.65 x 5.7 x 2.59 in.
196 x 145 x 66 mm

234.5 ft / 4.1°

71.5 m / 4.1°

14° up to 122° F

-10° up to +45° C

6.65 x 5.7 x 2.59 in.
196 x 145 x 66 mm

in view. Thanks to the roof prisms with phase
correction coating the user enjoys an image with
excellent detail rendition and also high contrast
in all light conditions. A nitrogen filling on the
inside of the binoculars prevents fogging of the
glass surfaces even with severe temperature fluc­tuations and also provides permanent protection
against corrosion. With the extended eye relief
the entire field of view can be enjoyed without
vignetting, even when wearing glasses. Twist­type retractable rubber eyecups with individual
click stops are another convenient feature.

The scope of delivery of

the BL binoculars also

includes a wide Neo-

prene strap as well as

an ever-ready case.

MINOX GmbH

Walter-Zapp-Str. 4
D- 35578 Wetzlar, Germany
Tel.: [phone] / 917-0
Fax: [phone] / 917-612
E-mail: [e-mail]

www.minox.com

Design, features, supply and price are subject to change. Product information order number: 99343 (e)(d) 10/10/AX/S
