Instruction manual
BL 8x33 HD
BL 8 x44 HD · BL 10 x44 HD
BL 8 x52 HD · BL 10 x52 HD
BL 8 x56 HD
Operating parts
1. Eyepieces with adjustable eyecups
2. Diopter compensation
3. Central drive
4. Collapsible tubes
5. Lens
6. Tripod adapter (Cover screw)
With these binoculars from MINOX you have chosen a product of highest optical quality and mechanical precision.
The MINOX BL-HD binoculars were developed, engineered
and assembled in Germany, giving them the "Made in
Germany" seal of approval.
These instructions are to help you benefit from the full performance spectrum of your MINOX binoculars.
We wish you much pleasure and enjoyment
with your new MINOX BL-HD binoculars!
Introduction
1
2
3
4
65
Adjustments
Ideal for people wearing glasses
To ensure that people wearing glasses also have an optimal
field of view MINOX binoculars are fitted with rotating
eyecups.
For use without wearing glasses
Those who do not wear glasses must turn the eyecups at
both eyepieces in counterclockwise direction until they
engage in the extended position. The binoculars are now
set at the correct distance to the eyes.
For use with glasses
Those who wear glasses must leave the rotating eyecups on
both eyepieces in the original position (as delivered) or, if
necessary, turn the eyecups in clockwise direction until they
noticeably engage. In this setting you can enjoy the entire
field of view without disturbing interference at the edges.
The right distance between the eyes
(inter-pupillary distance)
Look into the eyepieces of your binoculars and adjust the
angle of the hinged tubes until you have a singular circular
viewing field from both fields of view.
Focusing
For pin-sharp definition you must adjust the optics of the
binoculars to your individual eye vision. To do this, please
proceed as follows:
(a) First get a far-off, fixed object into view. With closed
right eye turn the central focusing until the object in
view has optimal sharpness for your left eye.
(b) Next you must get the same object in view again with
your left eye closed and turn the adjusting ring on the
right eyepiece until the object has optimal sharpness
for your right eye.
(c) Your MINOX binoculars are now set to the individual
vision of both eyes.
(d) For the observation of different objects at varying
distances you will always have to adjust the focusing. To
do this, please now just use the central focusing.
Caution:
Do not use binoculars to look into the sun, this could lead
to eye injuries.
Attaching a tripod
Tips on how to care
For shake-free viewing we recommend the use of a tripod,
especially for high-power magnification. For this purpose,
use the MINOX tripod adapter which is available as an
optional accessory (Order no. 69727). Remove the cover
screw (6) on the bottom of the binoculars and attach the
MINOX tripod adapter in its place. Keep the cover screw
(6) in a safe place and replace it after removing the tripod
adapter.
Soiling impairs the brightness of your MINOX binoculars.
We therefore recommend always removing fingerprints,
dust and other forms of soiling on the surfaces of the lens
and eyepieces using a soft hair brush or the special MINOX
Lens-Cleaner (Order number. 99605).
On the left eyepiece you will find the factory number. It
is important that you make a note of this number for the
event of loss.
Technical data BL 8x33 HD BL 8x44 HD BL 10x44 HD
Magnification 8 x 8 x 10 x
Front lens diameter 1.30 in. / 33 mm 1.73 in. / 44 mm 1.73 in. / 44 mm
Exit pupil 0.16 in. / 4.1 mm 0.22 in. / 5.5 mm 0.17 in. / 4.4 mm
Field of view 410 ft at 1,000 yds / 8.0°
140 m at 1,000 m / 8.0°
421 ft at 1,000 yds / 7.8°
136 m at 1,000 m / 7.8°
342 ft at 1,000 yds / 6.5°
114 m at 1,000 m / 6.5°
Eye relief 0.69 in. / 17.5 mm 0.77 in. / 19.5 mm 0.67 in. / 17.0 mm
Close distance 8.20 ft / 2.5 m 8.20 ft / 2.5 m 8.20 ft / 2.5 m
Diopter adjustment ± 4 dpt ± 4 dpt ± 4 dpt
Operating temperature 14° up to 122° F
-10° up to +50° C
14° up to 122° F
-10° up to +50° C
14° up to 122° F
-10° up to +50° C
Waterproof yes, up to 16.4 ft / 5 m yes, up to 16.4 ft / 5 m yes, up to 16.4 ft / 5 m
Height x Width x Depth 5.11 x 5.43 x 1.77 in.
130 x 138 x 45 mm
5.23 x 5.9 x 2.08 in.
133 x 150 x 53 mm
5.23 x 5.9 x 2.08 in.
133 x 150 x 53 mm
Weight approx. 22.9 oz / 650 g 26.1 oz / 740 g 26.1 oz / 740 g
BL 8x52 HD BL 10x52 HD BL 8x 56 HD
8 x 10 x 8 x
2.04 in. / 52 mm 2.04 in. / 52 mm 2.2 in. / 56 mm
0.26 in. / 6.5 mm 0.20 in. / 5.2 mm 0.28 in. / 7 mm
342 ft at 1,000 yds / 6.5°
114 m at 1,000 m / 6.5°
342 ft at 1,000 yds / 6.5°
114 m at 1,000 m / 6.5°
378 ft at 1,000 yds / 7.2°
126 m auf 1.000m / 7,2°
0.86 in. / 22.0 mm 0.71 in. / 18.0 mm 0.78 in. / 20.0 mm
11.5 ft / 3.5 m 11.5 ft / 3.5 m 11.5 ft / 3.5 m
± 4 dpt ± 4 dpt ± 4 dpt
14° up to 122° F
-10° up to +50° C
14° up to 122° F
-10° up to +50° C
14° up to 122° F
-10° up to +50° C
yes, up to 16.4 ft / 5 m yes, up to 16.4 ft / 5 m yes, up to 16.4 ft / 5 m
5.7 x 7.08 x 2.56
145 x 180 x 65 mm
5.7 x 7.08 x 2.56
145 x 180 x 65 mm
7.7 x 6.3 x 2.8 in.
195 x 160 x 70 mm
33.5 oz / 950 g 33.5 oz / 950 g 44 oz. / 1.250 g
