Mini-Box PicoPSU-120 Quick Installation Guide

picoPSU-120

12V, 120Watt ATX Power Supply

Quick Installation Guide

Version 1.0b

P/N picoPSU-120

Mini-Box.com ATX DC-DC Converter Series

Introduction

The picoPSU-120 is a small yet powerful and fully compliant ATX
power supply designed to power a wide variety of motherboard from a
single 12V regulated power source.

The PICOPSU-120 is the only snap power supply solution for general
purpose motherboards. Compatible with an entire range of mini-ITX,
UATX or full size ATX motherboards the picoPSU-120 provides cool,
silent power for system. The PICOPSU-120 has many advantages
over a regular power supply:

-Smallest ATX PSU to date

-100% silent operation

-Low heat dissipation with efficiency over 95%

-Plugs directly into the motherboard’s power connector, no cable mess

Quick installation Instructions

The PICOPSU-120 has been specifically designed for the Mini-ITX
form factor, thus eliminating the need for ATX power cables. It is also
1U compliant – height will not exceed 1U formfactor.

1) After the picoPSU module was ‘snapped in’, hook the hard drive
power or floppy power to your floppy/hard drives. If more hard drives or
floppy connectors are needed, use a HDD/floppy “Y” splitter cable.

2) Connect a 12 VDC power adapter (or any 12V source) to the DC-to­DC connector, center pin / white wire is positive (+).

3) Turn on the PC using the motherboard ON/OFF switch
