1. UNIT DESCRIPTION
This is a free-standing, all-wooden heating unit that works on the
convection principle. Since the unit fully uses the laws of physics in
the area of thermodynamics, it represents one of the most effi cient
means of interior heating.
BENEFITS OF FREE-STANDING CONVECTORS:
high output,
silent operation,
no need for other energies except water,
low hot water consumption,
short response time,
design,
minimal operation and maintenance requirements.
.
Individual positions in the table correspond to Figure No. 1.
3. TECHNICAL PARAMETERS
Figure 1: COMPONENTS OF CONVECTOR LP
1. WOODEN CONVECTOR BODY – the all-wooden convector body is a
design feature and it covers the heat exchanger.
2. CONVECTOR GRILLE - design element protecting the convector
outlet. Must not be covered!!!
3. EXCHANGER - copper pipes with pressed-on aluminum fi ns through
which the heating water fl ows.
4. STRAIGHT BALL VALVE - enables water supply shut off.
5. SCREW FITTING - a valve that controls / adjusts heating water fl ow.
6. HOSE 41mm – the bellows hose is a stainless hose intended for
fi tting the connection to the convector exchanger.
7. HOSE 65mm.
8. SEALING - seals joints between valves, hoses, and exchangers
(KLEGERSIL C4400). MINIB, s.r.o. recommends this sealing as an
optimum sealing solution, as other materials (rubber, NBR, silicon)
do not have suffi cient tightness upon suffi cient tightening and because they are deformed by tightening forces.
9. DOWEL - for screw fi xing.
10. WOOD SCREW - for convector fi xing to the fl oor.
11. TEMPLATE - for marking the positions of the inlet and return pipes
and for marking the convector fi xing holes on the fl oor.
2. PACKAGE CONTENT
PACKAGE CONTENT Position Quantity
Convector
All-wooden body 1 1
All-wooden grille 2 1
Exchanger 3 1
Accessories
Ball valve - straight, ½“ 4 1
Screw fi tting - angular, ½“ 5 1
Hose G1/2“ – 41 mm 6 1
Hose G1/2“ – 65 mm 7 1
Sealing KLIGERSIL C4400 8 4
Dowel No. 10 *) 9 2-3
Wood screw 6x50 *) 10 2-3
Template DP 11 1
*) 3 pcs. for lengths of 1500 and 2000mm
2. PACKAGE CONTENT
installation manuals - DP convector
53
4. BEFORE INSTALLATION
Select the correct convector position - see paragraph 4.1.
4.1 Convector Position
The free-standing MINIB DP convector is intended for fl oor installation. Place the convector so that it does not disturb the overall aesthetic
appearance of the room. MINIB, s.r.o. recommends leaving 50-150 mm
between the convector and the wall - Figure 2. Never cover the top grille
- this would result in fl ow reduction and a considerable decrease in the
convector's output.
5. INSTALLATION
Free-standing DP convectors are intended for fl oor installation. Before you start, please read the following instructions.
For fl oor installation, plan the exact positions of the heating water
pipes. The convector body (wooden) should be used for the exact
position determination.
Mount the free-standing convector with the mounting accessories
supplied by MINIB, s.r.o.
The heat exchanger must be connected to the distribution pipes with
the supplied stainless steel hoses.
A correctly installed convector is horizontally supported along its entire length.
usage: dry premises,
maximum operating pressure: 1.0 MPa,
maximum operating temperature: 95 °C,
operating medium: water. The use of other media is prohibited.
Water may not be mixed with other substances, such as non-freeze liquids!
environment: interiors with temperatures between +5°C and +40°C.
DP convector - installation manuals
Figure 2
Figure 3:
Adjust the convector to the required position. Mark the position of the
DP convector body legs.
Figure 4: Mark the inlet pipe, return pipe, and fi xing screw positions using the
template. For pipe installation, use either the right or left leg of the DP con-
vector - never the central one.
Figure 5: Drill holes for convector body mounting and prepare the inlet and
return pipes in the fl oor.
Figure 6: Insert dowels in holes. Remove grille and convector exchanger. Fit the
convector body on the pipes and dowels. Screw the convector body to the fl oor.
54
8. OPTIONALES ACCESSORIES
Thermostatic valve - angular, ½”
Screw fi tting - angular, ½”
Ball valve - straight, ½”
Ivar thermostatic head
Heimeier thermostatic head
Bellows hose ½” - ½” 65 mm
Bellows hose ½ - ½ 41 mm
7. UNIT DEAERATION
Deaerate the unit by deaerating the valve opening during fi rst use.
In free-standing convectors, the deaerating valve is located by the
water inlet on the heat exchanger fi tting.
6. CONNECTION OF FITTINGS
Connect the fi ttings with the supplied standard accessories.
Connect individual inlet and outlet valves. The ball valve (standard
supply) is connected to the water inlet for shutting off the water supply. The screw fi tting is installed on the outlet pipe. Sealing must be
used in all joints. Use the supplied fl exible stainless hoses (bellows
hoses) for heat exchanger connection. Connect fi ttings as shown in
Figure 9.
Stainless hoses are designed for the maximum pressure of 1.0 MPa.
Hoses must not be stretched, compressed, or otherwise deformed.
Media inlet: the ball valve (standard supply) is connected to the water inlet.
Outlet (return pipe): the screw fi tting is always connected to the return pipe.
installation manuals - DP convector
Figure 8: Insert the grille.
Figure 9: Connection of fi ttings to DP body
Figure 10: Deaerating valve
Figure 7: Install the heat exchanger and connect the fi ttings - see paragraph 6.
Check installation tightness.
