MINEX GW-15 Operating Manual

1

WINKIE DRILL MANUAL

WINKIE DRILL…..…………………………………………………………….9

DESCRIPTION OF WINKIE DRILL…………………………………….10

APPLICATIONS………………………………………………………..11

LIMITATIONS…………………………………………………………..11

COMPONENTS OF THE WINKIE DRILL…….......................11

BRIEF HISTORY OF DIAMOND DRILLING……..………….…11

TECHNICAL INFORMATION…………………………………………….13
DRILLING PROCEDURE..………………………………………….13

TROUBLE INDICATORS.....................................................14

ROTATIONAL SPEED VERSUS LINEAL TRAVEL.…….…….15
WATER REQUIREMENTS FOR DIAMOND DRILLING.……16

UNIPRESS……………………………………………………..……….16

METHODS OF ANCHORING DRILL………………..……………16

WINKIE DRILLING TOOLS……………………………………………….17

ADAPTERS.........................................................................20

OPERATING INSTRUCTIONS FOR YOUR WINKIE...................21

WINKIE CARE AND MAINTENANCE…………………………………23

ENGINE MAINTENANCE..........................................................23

FUEL MIX AND BREAK IN………………………………………25

WINKIE DRILL PARTS LIST…………………………………………….26

OPERATING INSTRUCTIONS FOR 10 HP ENGINE……………..39

2

WINKIE DRILL ASSEMBLY PARTS MANUAL

WINKIE DRILL

GW-15

WHEN ORDERING PARTS PLEASE GIVE:

1. Model of Drill

2. Serial Number of Drill

3. Part Name

4. Catalogue Reference Number

5. Quantity Required

6. When ordering parts for engines, pumps, winch,
etc., always include the PART NAME and the
NAMEPLATE READING of the unit

7. Shipping Instructions

NOTE: All prices F.O.B.

3

WINKIE DRILL ASSEMBLY PARTS MANUAL

WINKIE: THE MOST OUTSTANDING BUY IN ITS FIELD:

–

Meet a pint-size powerhouse, driller’s drill, ready to rewrit e y our footage cos ts with its ni ne (9)
outstanding fe atures.

Lower Maint enance

minimizing the moving parts, and having only three precision machined analoy castings in the drill itself.

Maintenance costs are reduced over the conventional core drill, resulting from

Lower Movin g Costs – Setup and moving costs are very low. Savings may be made with carrying the

Winkie Drill to the site, in lieu of building roads.

Lower Labor C osts – Labor cost may be cut by 50% through using only one man to operate the Winkie.

Save by not building roads for the portable carry-in-hand Winkie.

Lower Fuel Costs – Fuel consumption under full load is approximately 3 to 4 gallons per drilling shift.
Lower Diamond Bit Costs – Dynamic balance in this drill means less rod vibration; thus, less drill rod and

corebarrel wear, and most important, LESS DIAMOND BIT COST.

High R.P.M. –

a greater daily footage. It is recognized that diamond wear is reduced as speed of rotation approaches 700
RPM, above 700 RPM, and up to Winkie speed of 2000 RPM.

High Speed bit rotation plays a very important role in reducing bit cost, in addition to yielding

Less Handli ng of Tools – The overhead principle drive on the Winkie allows as great as 3 foot runs without

rechecking on the drill rod. Compare chucking time of 36 inch strokes for the Winkie, against conventional
drills with 24 inch strokes.

Less Water Required –

Experience –

Plus these added fe at ures –

No experienced Diamond Drill Operator is required. A minimum of instruction is required.

Drilling with the minimum water requirements is the best policy with the Winkie.

Full 10 H.P. 2 cycle gasoline engine. 6000 RPM.

Torque resolving safety clutch.
Built-in water swivel with adjustable packed type water seal.
Vacuum carburetion system to allow continued operation of the engine at any conceivable angle.
Circular holding ring (for protection of the unit and complete selection of gripping areas.)
Hardened spur gears for quieter, smoother and longer operation.
Water-cooled gear box.
Recess mounted bearings designed with a safety factor of “3”.
Unipress mechanical pull down pressure feed.

4

WINKIE DRILL ASSEMBLY PARTS MANUAL

DESCRIPTION OF WINKIE DRILL

APPLICATIONS

1. Exploration –

2. Probing –

3. Highway Sampling –

4. Masonry Drilling –

5. Grout Holes –

6. Marine Blast Hole Drilling –

7. Underwater Drilling –

Limitations

COMPONENTS OF THE WINKIE DRILL

1. Engine –

The Winkie drill is a lightweight portable core drill. The drill was designed to recover 1” cores to a depth of
450’. In some formations, cores up to 2 1/8” diameter can be recovered to lesser depths. A lightweight water
pump is used to circulate water to remove the cuttings and to cool the bit. Diamond core bits specially
designed or selected are used to cut the rock. In some softer overburdens, drag bits can be used to put the
hole down to solid material.

The principal applications of the Winkie are:

by public utilities, industrial plants, refineries, maintenance work, etc.

completed, a series of holes can be drilled to produce cores showing the effectiveness of the grout.

direct drive the drill can be operated from an inexpensive boat or raft.

Remember, the Winkie Drill is the smallest and lightest weight patented gear shift drill of its type on the
world market.

The Winkie drill cannot be used to produce cores in gravel, sand or silty clay formations. It is not designed to
compete against jack hammers for production drilling. Its principal application is where cores are primary
and hole is secondary. However, in some cases, such as drilling holes for parking meters, the hole can be
drilled to required diameters. With jack hammers, a rough hole by comparison is drilled. As you see the
Winkie work, more ideas for its application will be uncovered.

The drill itself consists of 3 assemblies: (1) Engine (2) Transmission (3) Unipress

vacuum carburetor system allows drilling “up” holes or at any angle. The engine is mounted with its drive
shaft vertical so that it drives directly into the transmission.

10 HP, 2 cycle, air cooled gasoline engine. Easy starting with a nylon cord recoil type starter. A

core samples desired for mines and quarries.

to find depth to rock for foundation or other testing.

concrete cores recovered for testing pavement.

cutting holes through reinforced concrete, brick; for conduits, pipes, etc. used

drilling holes for the purpose of grout injection. After the grouting has been

in certain applications, due to its portability and principal overhead

5

WINKIE DRILL ASSEMBLY PARTS MANUAL

2. Transmission Assembly –

3. Unipress –

4. Water System –

BRIEF HISTORY OF DIAMOND DRILLING

engine shaft, through a splined connection, drives the centrifugal clutch. As the engine speed is increased
past 900 RPM, the clutch shoes are thrown out and engage the clutch drum which rotates the input shaft to
the gear box. If the engine speed should be reduced to lower than 900 RPM, the springs on the clutch shoe
will pull the shoes away from the inner drum surface and, of course, power to the drill rods is removed.

exertion. Fatigue of the operator is reduced by 50% or more, contributing to more economical operation.

cuttings, cool the bit, and to keep the core from sticking. For this purpose, an engine-pump unit complete
with hoses and water by-pass system is offered.

The pump is a JKS – BRONCO “8” – 7/8 stroke 1 ½” bore – two piston progressing cavity positive
displacement 8.2 U.S. GPM at 400 PSI. Since the pump runs constantly with the engine, a pressure valve
relieves pressure on the pump, if for any reason, the bit or rods become clogged.

A ¾” x 20’ 4-ply pressure hose with fittings and shut-off valve, and a 1” x 15’ 3-ply suction hose with fittings,
foot valve and strainer are part of the water system unit.

Of course, a water supply is necessary. For Masonry drilling, city water is convenient. For field work, it may
be necessary to use a water tank or drum for the water. If the formation is solid enough, it may be
convenient to recirculate the water from the hole to the tank. In this case a “T” joint on top of the casing is
required to direct the water to the tank.

The Winkie Unipress enables the operator to exert a steady pressure with a minimum of

Circulating water through the drill rods down to the bit is required to wash out

The transmission contains the clutch, gear box and water swivel. The

Modern Diamond Drilling dates back to the year 1862 when a Swiss named Jean Rudolphe gave birth to the
idea of mounting diamonds in the periphery of a tube to cut cylindrical core of rock. Even before this time,
recorded history shows that as far back as 2000 B.C., the ancient Egyptians were using tubular drills to
assist in building their pyramids.

The first steam-powered drill was built in 1862-63. By 1870, steam drills with RPM as high as 360 and 5 to 7
horsepower were being used. Through the years, marked improvements have been made in Diamond Drills
and their accessories, paralleling the ever-increasing need for rock sampling in hard formations.

The introduction of the Winkie Drill was a major step in Diamond Drill development . It offers, for the first
time, portability with Winkie drilling capacities, presently associated with drills ten times the Winkie’s
weight. But the Winkie costs only a fraction of other drills.

To get better core recovery in soft formation, it is a known fact in the Diamond Drilling Industry that larger
diameter holes have to be drilled. However, the Winkie Type Drill, with its high RPM and faster penetration

6

WINKIE DRILL ASSEMBLY PARTS MANUAL

TECHNICAL INFORMATION

DRILLING PROCEDURE

Starting the Drill Hole

Starting on Rock Surfaces:

using less circulating water, has proven to be the first in various fields to get a larger percentage of core
recovery, drilling smaller diameter holes than the conventional drill.

For instance, on one drilling project using conventional Diamond Drills, the core recovery in the coal seam
was practically nil using double tube core barrels. The Winkie Drill was used on the same project with a
single tube core barrel. It recovered 29 ¾” of coal cores from a 32” seam.

The standard Diamond Bit sizes used are the following:

**IEW - 5 (1.5” hole – 1” core)
**AW - 34 (1.89” hole – 1.32” core

The mining series Thin Wall Diamond Bit allows faster penetration and uses less water to carry up the
cuttings. The automatic safety clutch on the Winkie Drill permits the use of thin wall bits to be run with a
minimum supply of water without the worry of burning an expensive Diamond Bit.

First of all, drill must be securely anchored.

A. Use a short core barrel ranging between 1-1/2” to 2’ often termed the starting barrel. This barrel is a single
or double tube barrel. Drill the starting barrel at least 4” to 6” into the rock.

B. If using a whole stone straight wall bit (a bit without a core spring), dry block. Dry blocking with
impregnated bit will significantly reduce bit life.

1. Shut off the water supply and

2. Run the drill at half throttle, at the same time applying pressure to bit.

The machine will automatically stop when the bit has dry blocked (wedged the core in the face of the bit
with rock dust). With a core spring, the bit may be drawn off the bottom and the core will remain in the
barrel in the event the core may be left in the hole, a core fisher with springs is attached to the core barrel
to fish the lost core. Do not rotate the core fisher.

7

WINKIE DRILL ASSEMBLY PARTS MANUAL

Starting with Soil Overburden:

TROUBLE INDICATORS

Blocked Bit

Blocked Core Barrel

I. The soil must be stabilized either by casing or drilling mud preceding the initiation of core drilling.

Casing may be either drilled into the soil or driven until it is well seated into the rock.

II. Assuming casing has been advanced to rock surface; the casing must be well cleaned out to free it of

all foreign matter (mud, gravel, etc.) except water. This is accomplished by a chopping and washing or
fishtailing procedure.

A tungsten carbide drag bit, adapted directly to the drill rods, can be used to put down a pilot hole with the
WINKIE, and give the operator an estimate on the depth of overburden and amount of casing required to case
the whole to solid formation. After a solid formation with the drag bit, adapt the diamond or tungsten carbide
casing shoe to the casing and repeat the same operation, as when drilling with drag bit, but use the casing
and rotate it down the pilot hole made with the drag bit. When this performance is completed, adapt the core
barrel with diamond and reaming shell to drill rods and start coring.

It is also possible to adapt the diamond or tungsten carbide casing shoe to the casing and rotate the casing
into solid formation without a pilot hole. When solid formation is encountered, just leave the casing in the
hole as the core barrel will pass through the casing shoe.

If core recovery is required in soft shale formation, a tungsten carbide core bit can be used as well as a large
stone diamond bit. It is not possible to take a core in clay, sand or gravel, and never attempt to use a
diamond bit in the above formations as it will wear and destroy any expensive diamond bit.

III. Now, lower the tools to the bottom of the hole in this order:

(Bottom to top)

A. Diamond bit and reaming shell
B. Core Barrel
C. Drill rod or rods

IV. Connect the Winkie to top of the drill rods and follow the drilling procedure as outlined in steps A, B and

C in the discussion proceeding on starting on rock surfaces.

The drill engine automatically slows down, indicating that the core barrel should be withdrawn and the core
emptied.

A. A blocked bit usually shows itself by first a refusal to penetrate and secondly a bumping of the tools as
they rotate, commonly called a “kick”.

8

WINKIE DRILL ASSEMBLY PARTS MANUAL

Continued Blocking of the Bit

Causes of Vibration

ROTATIONAL SPEED VERSUS LINEAL TRAVEL

NOTE:

Always keep very close record of measurements.

One of the best methods to gauge the rate of penetration is to mark the drill rods with driller’s chalk.

When the drill rod rotates, these rings will disappear below the collar of the hole as the bit
penetrates.

This is important to your logging procedure.

NOTE:
causing a decrease in core recovery and excessive wear on the diamond bit.

A. Check to see that a free flow of water is reaching the bit. Often times the drill rods are obstructed with
clay, gravel, etc. Also check your diamond bit for inside gauge. It is possible the used bit may cut a larger
diameter core than the core barrel will admit.

B. Possibly an insufficient water pressure is being used. Refer to the pumping chart to establish volumes for
various size drill holes. In order to attain these volumes, a positive pressure must be maintained.

C. Dented or bent inner tube may cause blocking.

1. Lack of rod grease.

2. Excessive feed rate or pressure.

3. Drilling over or grinding core.

4. Incorrect water pressure and volumes.

5. Bent rod drills.

6. Incorrect size of rods, and core barrels in relation to the size of the hole.

7. Drill bits too dull.

Do Not confuse RPM with the actual lineal travel of a diamond. A diamond on the outside cutting edge of an
EW (1-1/2” dia.) bit at 1000 RPM travels 393 feet per minute. An AW (1-1/8” dia.) bit has a peripheral speed of
491 feet per minute. A BW (2-3/8” dia.) bit has a peripheral speed of 622 feet per minute. A 6-1/2” dia. bit has
a peripheral speed of 1636 feet per minute. When the diamond bit is not in use, protect it and do not use it as
you would a pipe wrench; it is valuable and will serve you better if used properly. Never drop your rods on the
bottom of the drill hole; this will damage your bit.

When changing from old to new bits, use caution in lowering the rods in the hole, and it is a good practice to
ream the last to or three inches, just in case the old bit lost some gauge which would cause a new bit to get
wedged and also damage outside stones. Never wrench your drill rods down a tight hole. This is bound to
damage your outside diamonds.

If drilling is continued when the core barrel is blocked, it ordinarily results in grinding of core, in turn,

(Not necessarily in order of importance)
