MINEW TECHNOLOGIES T3 Users manual

MiniBeacon_T3
TEL: +86-755-2103 8160
EMAIL: sales@minewtech.com
URL: www.minewtech.com
Mini
Model
Description
T3-9001A
204940001, sticker beacon, round shape, white, includes 1pc CR2016 coin battery and gift package box, RoHS
Mini
Model: T3
Model:
Beacon
Beacon
Datasheet
Datasheet
V1.00
V1.
MiniBeacon_T3
TEL: +86-755-2103 8160
EMAIL: sales@minewtech.com
URL: www.minewtech.com
The sticker iBeacon T3 is a very small iBeacon with ARM core chipset and leverage BLE 4.0 technology.
- Programmed MiniBeacon standard firmware
- Included 1pc CR2016 coin battery replaceable
- The max. 50 meters advertising distance
- Small size, user-friendly and portable
- Easy to print the logo on the center of top case;
CERTIFICATIONS
- iBeacon MFi License (iBC-14-00582)
- CE Regulations (Included EN300328/301489/60950/62479)
SPECIFICATION
T3 MiniBeacon Image 1
Compatibility
- Supported iOS 7.0+ and Android 4.3+ system;
- Compatible with Apple iBeaconTMstandard;
- Compatible with all Bluetooth 4.0 (BLE) devices;

Replaceable battery and Battery Level

- Replaceable coin battery;
- Easy to get the real-time battery level notification;

Soft-reboot

- Reboot the device via command without anytools;

OTA and J-Link

- Supported upgrade via Over-The-Air;
- Reserved J-Link port on theboard for programming;

Connection Mode

- Advertising mode, non-connectable;
- Configuration mode, connectable;

Configurable Parameters

- UUID, Major, Minor, Device Name, Password etc.
- Special Configuration APP;

Transmission Power Levels

- 8 adjustable levels, range from 0 to 7
- Transmission power range: -30dBm to +4dBm;

Security

- 8 characters password (Lock/Unlock parameters);
- Broadcast the encrypted data if needed;
- AES HW encryption

Mounting

- 3M branded adhesive for direct mounting to wall;
The standard MiniBeacon firmware has been programmed into the device. It is designed for the commercial advertising, indoor location-based service and personal electronic sticker. Sticker beacon T3 broadcasts 2.4GHz radio signals at regular and adjustable intervals. Sticker beacon T3 can be heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile apps.

FEATURES

TURN ON i9

Please DO take out the battery sheet from T3 sticker beacon before using.
MiniBeacon_T3
TEL: +86-755-2103 8160
EMAIL: sales@minewtech.com
URL: www.minewtech.com
ONFIGURABLE PARAMETERS
Characteristic
Item
Default Settings
0xFFF1
UUID
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
0xFFF2
Major
0
0xFFF3
Minor00xFFF4
Measured Power
-59 (0xC5)
0xFFF5
Transmission Power
6 (0dBm)
0xFFF6
Change Password
minew123 (Must be 8 characters)
0xFFF7
Broadcasting Interval
9(900mS)
0xFFF8
Serial ID
Random (Unique serial ID for beacon)
0xFFF9
iBeacon Name
MiniBeacon_ (the maximum 12 characters)
0xFFFE
Connection Mode
0 (connectable, configuration mode)
0xFFFF
Soft Reboot
minew123 (it is same as the value of Change Password)
Item
Value
Remarks
Case Color
white
Other colors can be customized
Battery Model
1 x CR2016
1pc CR2016 coin battery, 3.0V
Operation Voltage
1.8-3.6V
DC
Transmission Circuit
9.5mA (Max.)
Tested at 0dBm transmission power
Transmission Range
50 meters
Maximum
Antenna
50ohm
On board / PCB Antenna
Accessories
Double adhesive
1pc, high-strength, 3M brand;
Net Weight
5.0g
With battery
Size
31.0*30*5.5 mm
Null
Item
Version
File Name
Updated Date
Datasheet
V1.0
T3_MiniBeacon Datasheet_1.0.pdf
21stFeb,2019
Instruction
V2.03
Instructions_MiniBeacon_V2.03.pdf
25thMay, 2015
SDK
V3.1
Android Reference Source Code; iOS Reference Source Code;
18thJune, 2017
APP Tools
V2.0
BeaconSET
23rdMay, 2017
ELECTRONIC PARAMETERS
TECHNICAL SUPPORT
* Minew sales team will send you these documents after the sample arrived.
MiniBeacon_T3
TEL: +86-755-2103 8160
EMAIL: sales@minewtech.com
URL: www.minewtech.com

APPDENDIX

1. J-LINK Programmer Kit;
2. Over-the-Air Function;
Please contact Minew sales team to ask more related information if needed.

DECLARATION

The contents of this datasheet are subject to change without prior notice for further improvement. Minew team reserves the right to explain all the termsof this datasheet. <END>
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be
installed and operated with minimum 20cm distance between the radiator your body: Use
only
the supp
lied antenna.
