MINEW TECHNOLOGIES MS50SF3 User Manual

1

Version

2.2

Released Date

2017-5-4

MODEL NO/DESCRIPTION

PRODUCT NAME: BLUETOOTH MODULE MS50SF3

Model:MS50SF3

产 品 规 格 书

PRODUCT SPECIFICATION

SHENZHEN MINEW TECHNOLOGIES CO LTD

2

Minew Technologies

1.Description

MS50SF3 is designed using Nordic nRF52832 patch Bluetooth 4.2 module.
It is a cost-effective, low-power system-on-a-chip (Soc) solution for
Bluetooth low-power applications that reduces the cost of building
network nodes. It has an ARM core Cortex-M4F RF transceiver, MCU has
faster speed, the kernel running speed of 64MHz, it can achieve more
powerful computing power and floating-point computing technology, can
achieve very complex algorithm. 512KB FLASH program space, 64KB RAM
and other powerful supporting resources. It is suitable for low-power
systems, ultra-low sleep current and low power consumption during
operation.

Front Back

URL：www.minewtech.com Tel：[phone] Email: [e-mail]

3

Minew Technologies

2. Features

 Bluetooth low power compatible technology
 Support for remote applications
 Accurate Received Signal Intensity Detection (RSSI)
 Complies with CE (European) and FCC (US) certification standards
 Contains high-performance ARM Cortex-M4F
 with AES security protocol processor

3. Application areas

- Low power Bluetooth system

- Mobile accessories

- Sports and fitness equipment

- Consumer electronics

- Human interface device

- health and medical care

4. Mechanical size (Unit: mm)

URL：www.minewtech.com Tel：[phone] Email: [e-mail]
