MINEW TECHNOLOGIES E2 User Manual

Minew Technologies

E2 MaxBeacon

Datasheet V1.0

BBeeaaccoonn // iiBBeeaaccoonn // M

DDaattaasshheeeett VV11..0

MiinniiBBeeaaccoonn

0

Model Description

E2-B

E2-W

TEL: [phone] FAX: [phone] EMAIL: [e-mail] URL: www.minewtech.com

Rectangle shape, black waterproof case with 3M adhesive sticker and screws ,
CE&FCC certified module including 4 x AA batteries and packaging box, RoHS

Rectangle shape, white waterproof case with 3M adhesive sticker and screws ,
CE&FCC certified module including 4 x AA batteries and packaging box, RoHS

Page 1

Minew Technologies

E2 MaxBeacon

The robust MaxBeacon E2 is an enterprise-level iBeacon with ARM core chipset nRF51822 and leverage BLE

4.0 technology; it has a strong & waterproof case, accurate hardware and robust firmware. It is designed for
the commercial advertising and indoor location-based service.
Minew Beacons broadcast 2.4GHz radio signals at regular and adjustable intervals. MiniBeacon can be
heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile apps.

Datasheet V1.0

FEATURES

- Programmed MiniBeacon standard firmware

- Powered by 4pcs AA batteries, alkaline

- Omni-directional PCB antenna

- The max. 200 meters advertising distance

- Waterproof IP65

- Ultra-low power consumption chipset nRF51822 with ARM core

CERTIFICATIONS

- iBeacon MFi License (iBC-14-00582)

- FCC Regulation (FCC Part 15.)

- CE Regulations (Included EN300328/301489/60950/62479)

SPECIFICATION

Compatibility

Configurable Parameters

E2 MaxBeacon

Image 1

- Supported iOS 7.0+ and Android 4.3+ system;

- Compatible with Apple iBeaconTM standard;

- Compatible with all Bluetooth 4.0 (BLE) devices;

Long Battery Lifetime and Battery Level

- More than 5 years, with the default settings;

- LED will be flashing when battery low;

- Easy to get the real-time battery level notification;

Soft-reboot

- Reboot the device via command without any tools;

OTA and J-Link

- Supported upgrade via Over-The-Air;

- Reserved J-Link port on the board for programming;

Connection Mode

- Advertising mode, non-connectable;

- Configuration mode, connectable;

- UUID, Major, Minor, Device Name, Password etc.

- Special Configuration APP;

Transmission Power Levels

- 8 adjustable levels, range from 0 to 7

- Transmission power range: -30dBm to +4dBm;

Long Range

- The max. Range 200 meters in the open space;

- The range depends on the physical environment;

Security

- 8 characters password (Lock/Unlock parameters);

- Broadcast the encrypted data if needed;

- AES HW encryption

Mounting

- 3M branded adhesive for direct mounting to wall;

TEL: [phone] FAX: [phone] EMAIL: [e-mail] URL: www.minewtech.com

Page 2

Minew Technologies

E2 MaxBeacon

TECHNICAL SUPPORT

Datasheet V1.0

Item Version

Datasheet V1.0 E2_MiniBeacon Datasheet_1.0.pdf 1st March, 2016
Instruction V2.03 Instructions_MiniBeacon_V2.03.pdf 25th May, 2015

SDK V1.0

APP Tools V2.0 iBeaconCFG; iBeaconDFU; 3rd March, 2015

* Minew sales team will send you these documents after the sample arrived.

Android Reference Source Code;
iOS Reference Source Code;

File Name

Updated Date

28th February, 2015

CONFIGURABLE PARAMETERS

Characteristic

0xFFF1 UUID
0xFFF2 Major

0xFFF3 Minor

0xFFF4 Measured Power

0xFFF5 Transmission Power

Item

E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
0
0

-59 (0xC5)

6 (0dBm)

Default Settings

0xFFF6 Change Password

0xFFF7 Broadcasting Interval

0xFFF8 Serial ID

0xFFF9 iBeacon Name

0xFFFE Connection Mode

0xFFFF Soft Reboot

minew123 (Must be 8 characters)

5(500mS)

Random (Unique serial ID for beacon)

MiniBeacon_ (the maximum 14 characters)

0 (connectable, configuration mode)

minew123 (it is same as the value of Change Password)

ELECTRONIC PARAMETERS

Item Value Remarks

Case Color Black, white Other colors can be customized
Battery Model 4 x AA (LR6) 4pcs Alkaline battery, 2500mAh, 3.0V
Operation Voltage 1.8-3.6V DC
Transmission Circuit 10.5mA (Max.) Tested at 0dBm transmission power
Transmission Range 200 meters Maximum
Antenna 50ohm On board / PCB Antenna

Accessories

Double adhesive

Screws 2pcs screws and 2pcs plastic holders

1pc, high-strength, 3M brand;

Net Weight 65.0g Without battery and package box
Size 72 x 72 x 23MM Null

TEL: [phone] FAX: [phone] EMAIL: [e-mail] URL: www.minewtech.com

Page 3

Mine

APPDENDIX

w Technologies

ea

B

ax

M

E2

Datasheet V1.0

con

1. J-LINK Programmer Kit;

2. Over-the-Air Function;

Please contact Minew sales team to ask more related information if needed.

DECLARATION

The contents of this datasheet are subject to change without prior notice for further improvement. Minew
team reserves the right to explain all the terms of this datasheet.

FCC Statement

This equipment has been tested and found to comply

pursuant to Part 15 of the FCC Rules. T

protection against harmful interference in a re

uses and can radiate radio frequency energy and,

the instructions, may cause harmful interference

no guarantee that interference will not occur in

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-- Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:(1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interf

Changes or modifications not expressly approv

could void the user's authority to operate the equipment.

This equipment should be installed and operated with minimum distance 20cm between the radiator &

your body.

hese limits are designed to provide reasonable

sidential installation. This equipment generates

erence that may cause undesired operation.

with the limits for a Class B digital device,

if not installed and used in accordance with

to radio communications. However, there is

a particular installation. If this equipment does

ed by the party responsible for compliance
