2 List of Parts
3 Assembly
3 Connecting the Coil
3 Shaft Assembly
4 Armrest Assembly
4 Connecting the Control Box
4 Disconnecting the Control Box
5 Coil Cable Assembly
5 Inserting Batteries
Contents
1
6 X‑TERRA 705 Keypad
7 X‑TERRA 705 LCD
8 X‑TERRA 305/505 Keypad
9 X‑TERRA 305/505 LCD
10 Specications
10 X-TERRA Series Specification
11 X-TERRA Model Features
4901-0269-1
2
List of Parts
Coil
Skidplate (fitted to coil)
Lower shaft
Middle shaft
Upper shaft
Armrest
Stand
Control box
Control box screw
Rubber washers (× 2)
Plastic wing nut
Plastic bolt
Armrest screw
Armrest strap
Velcro tabs (× 2)
Warranty card
Instruction manual
Connecting the Coil
Insert the two rubber washers into the lower
shaft yoke.
Slide the yoke into the yoke bracket on top
of the coil.
Insert the plastic bolt through the yoke
and the yoke bracket.
Fasten with the plastic wing-nut, being
careful not to damage the thread of the bolt
by over-tightening.
The coil cable is directly wired into the coil
and is not removable.
Assembly
3
Shaft Assembly
Loosen twistlocks by rotating them
counter-clockwise.
Insert lower shaft into the middle shaft.
Attach the middle shaft to the upper shaft.
Once shafts are assembled, lock their
position by rotating the twistlocks clockwise.
The upper shaft assembly has two springloaded pins to strengthen the joint, one on
each side of the shaft.
4
Assembly
Armrest Assembly
Place the armrest onto the top of the
upper shaft.
Insert the screw through the stand, upper
shaft and armrest, then tighten the screw.
Thread the armrest strap through both slots
in the armrest.
Connecting the Control Box
With the LCD facing up, push the control box
onto the end of the handle.
The X-TERRA is designed to be used in either
the left or right hand.
Insert the screw provided into the hole and
tighten using a phillips-head screwdriver.
Disconnecting the Control Box
Hold the detector firmly, grasp the control
box and pull it away from the handle.
Remember to remove the screw before
attempting to disconnect the control box.
