Minelab SOVEREIGN GT user guide

MINELAB

S

OVEREIGN

GT

Contact Details:

Minelab USA
871 Grier Drive, Suite B1
Las Vegas, Nevada 89119
UNITED STATES OF AMERICA
email: [e-mail]
tel: [phone]

www.minelab.com

Minelab Electronics Pty Ltd
PO Box 537 Torrensville Plaza
South Australia 5031
AUSTRALIA
email: [e-mail]
tel: [phone]

Minelab International Limited
Laragh, Bandon
Co. Cork
IRELAND
email: [e-mail]
tel: [phone]

MINELAB

User Manual

© 2005 Minelab Electronics Pty Ltd

This document contains proprietary information that is protected by copyright. Apart from any use as

permitted under the Copyright Act 1968, no part may be reproduced by any process without written

permission from Minelab Electronics Pty Ltd, 118 Hayward Avenue, Torrensville, SA 5031, Australia.

Notice:The words ‘Sovereign’, ‘Broad Band Spectrum’ & ‘BBS’ are all trademarks of Minelab Pty Ltd.

WARNING.This document contains Minelab Electronics Pty Ltd rights, technical data or restricted

rights data, or both. Patents and trademarks apply.

FCC Compliance

NOTE:

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:

Disclaimer

The Minelab metal detector discussed in this operating manual has been expressly designed and

manufactured as a quality hobbyist metal detector and is recommended for use in coin, treasure and

general metal detection in non-hazardous environments. This metal detector has not been designed

for use as a mine detector or as a live munitions detection tool.

Please read the operating manual prior to using your new detector.

Warranty and Service

There is a two-year parts and labour warranty for the electronic control box of the

Sovereign GT

Note: Please return the enclosed warranty card, correctly filled out, to your dealer
or direct to Minelab Electronics. This will assist Minelab to service your needs
promptly.

The Minelab warranty does not cover damage caused by accident, misuse, neglect,
alteration, modifications, or unauthorised service.

. Conditions apply; Please refer to the Warranty Card for further details.

•

Re-orient or relocate the receiving antenna of the radio or television.

•

Increase the separation between the equipment and receiver.

•

Consult your local dealer or an experienced radio/TV technician for help.

EC Conformity

NOTE:

This product complies with the essential requirements of EMC Directive 89/336/EEC.

Working for a Cleaner,
Greener Future

Disclaimer:

For Consumers within the European Union:
Do not dispose of this equipment in general
household waste.

The crossed out wheeled bin indicated
on this equipment is an indicator that
this unit should not be disposed of in
general household waste, but recycled
in compliance with local government
regulations or environmental requirements.

Please dispose of this equipment via a
recycling service or centre, or by returning
the unit to the respective Minelab or Halcro
outlet as appropriate for your unit. This will
enable the equipment to be disposed of in
an environmentally safe manner.

Disposal of unwanted electronic equipment
in landfi lled waste may contribute to
adverse long term environmental effect
due to the leaching of contaminating and
toxic substances contained within some
electronic equipment.

The Minelab metal detector discussed
in this operating manual has been
expressly designed and manufactured
as a quality hobbyist metal detector
and is recommended for use in coin,
treasure and general metal detection in
non-hazardous environments. This metal
detector has not been designed for use
as a mine detector or as a live munitions
detection tool.

Please note:

Since there may be a variety of options
available for this detector, equipment
may vary according to the Model or
items ordered with your detector. Certain
descriptions and illustrations may also
differ (in this manual) from the exact Model
that you purchased. In addition, Minelab
reserves the right to respond to ongoing
technical progress by introducing changes
in design, equipment and technical
features at any time.

THIS DEVICE COMPLIES WITH
PART 15 OF THE FCC RULES

Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.

Item Number: 4901 - 0051
Revision: 1.1

table of contents

www.minelab.com

1. INTRODUCTION 3

2. BBS TECHNOLOGY 4

3. LIST OF PARTS 6

4. ACCESSORIES 6

5. ASSEMBLING THE DETECTOR 7

5.1. Lower Shaft Assembly 7

5.2. Armrest / Upper Shaft Assembly 7

5.3. Completing the Shaft Assembly 8

5.4. Shaft Mount the Control Box 8

5.5. Hipmounting/Chest Mount 9

6. BATTERIES 10

6.1. Installation of NiMH Battery Pack 10

6.2. Installation of Alkaline Batteries 10

6.3. Low Battery Warning and NiMH Recharging 11

6.4. Using your NiMH Chargers 11

p1

table of contents

www.minelab.com

1. Introducing the Sovereign GT

www.minelab.com

7. CONTROL PANEL 12

7.1. Quickstart Operating Instructions 12

7.2. Volume Control and On/Off Switch 13

7.3. Sensitivity Control 14

7.4. Threshold Control 15

7.5. Disct/All Metal Switch 16

7.6. Discrimination Control 17

7.7. Notch Variable Control 19

7.8. Ground Balance Switch 20

7.9. Noise Cancel 22

7.10. Audio Output 22

8. DIGITAL TARGET IDENTIFICATION METER 23

9. PRACTISING THE CONTROLS 26

10. TREASURE HUNTING TIPS 27

11. ENVIRONMENTAL CONCERNS 28

12. DETECTOR CARE 29

13. TROUBLESHOOTING 30

13. SPECIFICATIONS 31

14. WARRANTY & SERVICE Service Repair Form 32

1. Introduction

Congratulations on purchasing Minelab’s Sovereign GT detector. The Sovereign GT metal
detector has been designed for general purpose detecting with features to suit the coin and
treasure hunter plus automatic ground balance for the gold fields.

The Sovereign GT detector uses Minelab’s unique

technology,

multiple frequencies.

The benefits of multiple frequency technology are numerous and include increased depth,
greater sensitivity to non-ferrous metal objects, increased accuracy in discrimination and
increased accuracy in target identification. Add to this, Minelab’s automatic ground balance
and the Sovereign GT becomes a very versatile, all-purpose detector.

The Sovereign GT is designed to locate valuable metal objects in high trash areas and in
areas of extreme salt or mineralisation, conditions commonly encountered by gold and
treasure hunters around the world. When using a single or dual-frequency detector under
these conditions, a detectorist may experience a significant loss of detection depth and
discrimination accuracy. However, the Sovereign GT, with its BBS technology and automatic
ground balance, compensates for interference from these ground conditions and enables you
to penetrate deeply and discriminate accurately at full depth.

The Sovereign GT is simple to operate, having very few controls that require adjustment after
they have been set. The extremely advanced, yet simple-to-use, discrimination features
enable you to accurately select only the types of metal objects that you want to find and to
ignore those that you consider junk. The variable signal tone responses enable you to
accurately identify the object found before you recover it.

If you have any questions or comments regarding the Sovereign GT or any other Minelab
product, then please feel free to contact us via your local Authorised Minelab Dealer or write
to us direct.

which enables the Sovereign GT to automatically transmit simultaneously in

Minelab Electronics wish you every success in your treasure hunting.

Broad Band Spectrum (BBS)

p2

Please Note:

Since there may be a range of options available in this
model of detector, equipment may vary according to
the product number or the country of purchase.
Certain descriptions and illustrations may differ
(in this manual) from the exact model that you have
purchased. Minelab reserves the right to respond to
ongoing technical progress by introducing changes in
design, equipment and technical features at any time.

p3

1. introducing the Sovereign GT

www.minelab.com

www.minelab.com

2.

BBS Technology

When developing BBS technology, Minelab’s scientists first looked at
technology that was already available in the market and identified its
limitations in field use. Discussions with seasoned treasure hunters
from around the world identified a number of common problems
facing detector operators including :

• Loss of detection depth in mineralised ground.

• Inaccurate target identification beyond 5 or 6 inches.

• Inability to detect good targets in close proximity to iron trash.

• Erratic operation when searching salt-water beaches.

Most detectors on the market operate on a single (or dual)
frequency. Although this technology has served the industry well
for years, Minelab’s scientists found that a frequency that worked
well in one area would often offer only marginal performance
when used in another location. Ground mineralization, trash
content, and target size all had an effect on how well a
detector transmitting a single frequency would operate.

The BBS circuit automatically transmits a number of
frequencies simultaneously; a feature which is unique to
Minelab metal detectors. Ranging from 1.5 to 25.5 kHz in

1.5 kHz increments, the signal received from the coil is
analysed and information is relayed to the operator via
the speaker, headphone, and meter (if attached).
Through the use of so many frequencies, the
Sovereign GT
accurately identify valuable targets in variable
ground and high trash areas.

is designed to locate and

The Sovereign GT combines Minelab’s unique multiple frequency BBS technology with
automatic ground balance and improved signal processing to give:

•

Greater detecting depth.

•

Consistent sensitivity over a wide range of targets.

•

Good target identification & discrimination of trash.

•

Operation in mineralised ground.

Therefore, the treasure hunter is more likely to detect targets normally missed by other
detectors.

One of the major overall benefits of BBS technology is that although it automatically
operates at so many frequencies, all at the same time, it is actually easier to use than most
of its competitors. Because it is microprocessor controlled, all you need do is set the
threshold, discrimination and volume, and the rest is done for you automatically.

Most coin detectors do not work well on saltwater beaches, and Pulse Induction detectors
designed for beach use have very little or no Discrimination ability. The Sovereign GT not only
performs flawlessly on a saltwater beach, whilst discriminating targets with amazing
accuracy, it also has a true ground balancing all-metal mode that allows operators to find very
low conductive items such as gold nuggets, and ferrous based relics in mineralised soils.

A BBS detector will penetrate deeply, discriminate accurately and can be used in a variety of
ground conditions. The bottom line is that when using a Minelab detector such as the
Sovereign GT with its BBS technology, you will find good targets, more often.

Essentially, when using a
with BBS technology, it is like swinging a

number of single-frequency detectors at
the same time. Because BBS operates in
a number of frequencies that no other
detector does, BBS detectors such

Sovereign GT

as the
broad range of objects that no
other individual detector
has the ability to find.

p4

Sovereign GT

can find a

p5

2. list of parts

www.minelab.com

5. assembling the detector

www.minelab.com

3. List of Parts

The box in which the Sovereign GT is shipped should contain the following items.
Please check that all of these items are in the box:

• Control Box

• 10" or 8” Round Tornado coil (inc. skid plate attached)

• 2-Piece Shaft Assembly (inc. Fiberglass lower shaft)

• Black Aluminium Armrest (inc. nuts & bolts) (2 part)

• Arm Rest Neoprene Cover

• Arm Rest Strap (2 part)

• Rear Control Box Bracket

• Battery Pack

TM

• Velcro

• Teardrop Washers (2)

• Nylon Nuts and Bolts

• Warranty Card

• Instruction Manual

Note: There may be variations to the items included in different countries so if you believe there may

be something missing, check with your dealer/supplier that it is standard issue.

Straps (2 pair)

- See note

4. Accessories

The following accessories are available to further improve your machine.

• Digital Target Identification Meter

• Alkaline Battery Holder ( holds 8 x ‘AA’ Batteries)

• NiMH rechargeable battery

• Mains Charger (240v/230v or 110v)

• 12V NiMH Vehicle Charger

• Headphones

• Hipmount Bag with Raincoat Protective Cover for Control Box

• Meter Protective Cover & hipmount Bag

• Padded Detector Transport Bag

• Minelab Padded Sleeveless Jacket

• Blue Minelab Polo Shirt

• Blue Minelab Cap

For further information on these and other Minelab products call your nearest

Authorised Minelab dealer.

5. Assembling the Detector

Please follow these instructions to assemble the Sovereign GT. Refer to the
drawings to identify parts and how they are positioned. Please contact your
Minelab dealer for further instructions should any difficulties arise.

5.1.Lower Shaft Assembly

a) Remove the tape on the lower fiberglass tube (3) that is

holding the black teardrop washers (12) in place.

Note: Ensure the washers do not fall out after removing the tape.
b) Remove the black nylon wing nut (11), and bolt (10) from

the coil (1).
c) With the teardrop washers in place, push the lower tube (3)

into the coil bracket so that the holes line up.
Note: Ensure that the black nylon spring clip near the top of

the fibreglass tube is pointing toward the rear of the coil.
d) Push the black nylon bolt (10) through the holes in the

bracket on the coil from the cable entry side and tighten
the wing nut (11) by hand.

Figure 1 - The coil and

lower shaft assembly

5.2.Armrest/Upper Straight Shaft Assembly

Note: In some countries the Sovereign GT is issued with an S-bend upper shaft and in

other countries it will have a straight shaft.
a) Slide the handle (5) onto the upper end of the upper shaft (4)

and push it on about a foot.

b) Place the two arm rest halves (6) on either side of the upper
shaft (4) and ensure that the bolt holes are aligned.

c) Slide the nylon bolts (10) through the bolt holes
and screw the nylon wing nuts (11) onto the bolts
with a couple of turns (do not tighten).

d) Slide the plastic control box bracket (9) into
the runners of the arm rest (6) & tighten the nylon
wing nuts by hand.

e) Attach the arm rest straps (8) using the
press studs on both sides of the arm rest.

f) Push the arm rest straps through the slots
in the arm rest cover (7) and push the cover
over the arm rest.

g) Position your arm into the arm rest and slide the
handle (5) along the shaft into a comfortable position.
Tighten the two screws in the base of the handle with a
small screwdriver.

Figure 2 - Armrest/upper

shaft assembly

p6

If your detector is supplied with the S-bend shaft, assembly will be identical except that you
will not have to assemble the separate handle

p7

www.minelab.com

www.minelab.com

5.3.Completing the Shaft Assembly

a) Slide the lower shaft assembly (3) into the Aluminium upper shaft (4).

Note: The black plastic locking nut (13) may need to be loosened to position

the lower shaft assembly correctly.

b) Set the length of the shaft by locking the black nylon spring clip into one of
the holes provided, then tighten the plastic
locking nut by hand.

Figure 4 - Completing the

shaft assembly

5.4.Shaft Mount the Control Box

a) Position the control box so that the recess in the control box (2) is aligned with the leading edge

of the mounting clip (9). Push the forward section
of the control box upwards until the trigger ‘clicks’,
indicating that the control box is secured.

b) Firmly wind the cable around the shaft until it
reaches the control box.

Note: Leave enough slack at the bottom of the cable
near the coil to adjust the coil position without straining
the coil cable.

c) Connect the coil connector (14) to the plug on the
rear of the control box (2).

TM

d) Use Velcro
in the correct position on the shaft maintaining
slack at coil and control box.

Note: Weather Protection - The hipmount bag
(available as an accessory item) is designed so
that it can be used to weatherproof your control box
while you are detecting in inclement weather. The hipmount bag is designed to protect the control
box while still on the shaft as well as in the hipmount configuration.

tabs (15) to secure the cable

Figure 5 – Mounting the

control box on the shaft

5.5.Hipmounting/Chestmount

Hipmounting is an alternative to mounting the

Figure 6 – Hipmounting

the control box

detector on the shaft and significantly reduces
physical strain, enabling longer search time without
undue fatigue. A hipmount bag is available as an
accessory item for this purpose.

a) Check that there are charged batteries in the control box.

b) Place the control box into the hipmount bag with its

control panel facing outwards (see figure 6).

c) Place the hipmount bag in your preferred working
configuration. The hipmount bag can be worn on a waist belt
or over the shoulder.

Note: If mounting the hipmount bag on the chest, a belt can
be threaded through the belt loop and around your chest to
hold the bag in position.

d) Wind enough cable from around the shaft so that it
reaches across to the control box and allows enough
freedom for a full sweep of the coil.

Note: Leave enough slack at the bottom of the cable near
the coil to adjust the coil position without straining the coil
cable.

TM

e) Use Velcro
base of the shaft and where the cable leaves the shaft.

f) Take the excess loose coil cable and wind it through the
belt bracket of the hipmount bag prior to connecting onto the
control box (see figure 7).

g) Connect the coil connector (14) to the socket on the rear of the control box and tighten the
locking nut.

tabs to secure the cable in position at the

Figure 7 – Hipmounting

the control box

The control box is positioned into the hipmount bag with the slot for the mounting bracket positioned
at the back. The velcroed panel is then wrapped across the top of the stem.

p8

p9

6. batteries

www.minelab.com

www.minelab.com

6. Batteries

Yo ur

Sovereign GT
rechargeable NiMH battery pack. A mains charger and/or 12 volt car charger are also available to
recharge the NiMH batteries wherever you are. These accessory items are available from your
authorised Minelab Dealer.

can be powered by either Alkaline batteries (8 x AA) or the Minelab

6.1.Installation of NiMH Battery Pack

a) Ensure your NiMH pack is fully charged.

b) Place the base of the battery pack at the rear of the battery

compartment (A). Push the front edge of the battery pack into
position (B). The two battery clips will "click" into position to hold
the battery pack in place (see figure 9).

Note: The NiMH battery pack is
factory sealed and does not open.

Figure 8 – Installing the

battery pack

6.2.Installation of Alkaline Batteries

The 12 Volt Alkaline battery pack is made to hold 8 ‘AA’ alkaline batteries. These can be used as
your day-to-day pack or as a back-up if you are using NiMH batteries.

a) Ensure the detector is switched "Off" before opening
the battery compartment.

b) Remove the battery pack housing from the
control box by pushing down on the tabs.

6.3.Low Battery Warning and NiMH Recharging

When the batteries are reaching the point at which they will no longer power the detector properly,

Sovereign GT

the
30 seconds. Shortly after this, the threshold will increase to a loud continuous signal that cannot
be reduced by the threshold control. When this tone is heard, it is recommended that the
NiMH battery pack be recharged or alkaline batteries be replaced.

The NiMH battery pack can be recharged using either the mains-powered charger or a
12V charger that can be plugged into the cigarette lighter of your vehicle. (both available
as accessories)

Caution: Check the mains charger voltage. Only use the appropriate mains charger for the
country you are in.

will emit a distinct sharp “pip” from the speaker, approximately every

6.4.Using your NiMH Chargers

Plug the charger into the socket on the rechargeable NiMH battery pack, and plug the charger into
the power source and then switch the power source on. The car charger has a red light that
indicates that it has power. A green light will appear on the battery pack during charging.
A completely flat battery will take approximately 12-14 hours to fully charge. The green light on the
battery pack will fade/dim once it is charged fully. A fully charged NiMH pack will give between
15 and 20 hours detecting time, depending on the number of targets found and the level of
threshold used.

c) Slide open the lid on the battery pack.

d) Place 8 “AA” alkaline batteries (17) into the base of the

alkaline pack (16). Ensure they are aligned as shown in
figure 10 and as indicated inside the compartment.

e) Slide the battery lid closed.

f) Place the base of the battery pack at the rear of the

battery compartment (A). Push the front edge of the
battery pack firmly into position (B). The two battery clips
will “click” into position to securely hold your battery
pack in place (see figure 8).

Caution: Good quality alkaline batteries will power the
Using headphones will extend battery life further. Good quality alkaline batteries should always be
used instead of standard carbon batteries. Alkaline batteries should be removed from the
detector if it is to be stored for extended periods to avoid damage caused by leaking batteries.

p10

Sovereign GT

Figure 9 – Installing

Alkaline Batteries.

for about 10 to 15 hours.

Figure 10 - Car and mains

battery chargers

p11

7. control panel

www.minelab.com

7. control panel

www.minelab.com

7. Control Panel

This section gives detailed
descriptions of the

’s controls and functionality.

GT
It is important that this section is
read carefully as it will provide
all the information required to
set and adjust these controls.
It may be beneficial to refer back
to this section in the future.

Figure 11 - The Sovereign GT

Control Panel

Sovereign

7.1.Quickstart Operating Instructions

To start detecting as soon as possible, here are some Quickstart settings that you can use.

Quick Operating Instructions

Disc Mode

a) Install charged batteries.

All Metals Mode

a) Install charged battery pack.

b) Set the Mode switch to All Metals.

c) Turn the

d) Turn the Threshold control in a clockwise direction until the tone becomes "just" audible.

e) Set the Sensitivity control to Auto .

f) Put the Ground Balance switch into Track and ground balance the detector by raising and

lowering the coil from 2 – 15cm above the ground until the threshold becomes stable.

Note: : Disc. and Notch controls are disabled when the detector is in the All Metal mode.

Once you are familiar with all of the controls, you will gain greater performance and
versatility by setting the controls to suit the needs of the area being detected.

Sovereign GT

On by turning the Volume control to about 3-o’clock.

b) Set the Mode switch to Disc. Iron Mask /OFF.

c) Set the Ground Balance switch to Pinpoint.

d) Turn the

e) Set the Threshold / Silent search switch to Threshold.

f) Turn the Threshold control in a clockwise direction until the tone becomes "just" audible.

g) Set the Sensitivity control to Auto.

h) Set the Disc control to the 3rd dot.

i) Set the Notch control to zero until you better understand its appropriate settings.

j) You can now start searching.

p12

Sovereign GT

On by turning the Volume control to approximately 3-o’clock.

7.2.Volume Control and On/Off Switch

This control, located at the bottom left of the control panel, is used to adjust a target’s signal
volume in addition to switching the

When in the fully anti-clockwise position, the
clockwise, will "click" the
direction will increase the volume of the target signals. At the most clockwise position, the volume
will be set at the "maximum" position. Minelab recommends this position for most circumstances.
However users should be aware that when using headphones, if a large target is detected close
to the surface, the resulting loud signal may cause some hearing discomfort; in areas like this a
lower volume should be selected.

Sovereign GT

Sovereign GT

On or Off.

Sovereign GT

On. Continuing to turn this control in a clockwise

is turned Off. Turning the control

p13

www.minelab.com

7.3.Sensitivity Control

The Sensitivity control, located at the bottom of the control panel, allows
the level of sensitivity to be adjusted to suit the conditions in which you are detecting.
It is often thought of in terms of a depth control and it is, to a point, but more
importantly it also makes the unit more or less sensitive to interference caused by
ground “mineralisation”, and electromagnetic fields.

At the most anti-clockwise position, this control “clicks” into the Auto position. In this setting the Sovereign GT
will automatically adjust the level of sensitivity to the most stable level under the prevailing conditions.
Beginners should operate the unit in Auto, until they become more competent in its operation.

Turning the control clockwise will “click” the Sovereign GT out of the Auto setting into manual sensitivity.
As this control continues to be turned in a clockwise direction the level of sensitivity will be reduced. At the most
clockwise position, the Sovereign GT is set at "minimum" sensitivity.

Experienced operators, when detecting in wet sand at the beach, should set the Sensitivity control out of Auto
and slowly turn the control clockwise until minimal false signalling is experienced. This will give the maximum
sensitivity while maintaining a smooth threshold. In general, the more moist the beach sand, the more clockwise
the knob must be turned.

When operating the Sovereign GT in heavily mineralised ground, the operator should again reduce the
sensitivity until the ground balance is able to cope with the mineralisation.

NOTE: Often a sensitivity setting that gives a smooth threshold is preferable to a high sensitivity that causes
undue noise or instability that makes it difficult to hear subtle target signals. Detecting with a smooth threshold
will often mean that you are able to hear targets to a greater depth than with a noisy threshold.

The incidence of false signalling is minimized if the operator concentrates on sweeping the coil as parallel to
the ground surface as possible. In summary, for greatest detection depth:

• Keep the coil sweep as parallel to the ground as possible.

• Turn the sensitivity knob as anti-clockwise as possible, (within the manual region) so that minimal false
signals occurs.

• This setting will need to be altered, depending on the mineralization or sand moisture level.

Advanced users operating inland, can operate the unit in either Auto or in Manual. In more mineralised soils,
a reduced Manual setting is recommended. Note that “hot rocks”, “Roman Pennies” or some ancient
red/orange/brown pottery or tiles may cause the unit to respond as if the targets are ferrous. This is not a false
signal, but the correct response, and indicates that the unit is set at a relatively high sensitivity. It is also
highly recommended that a very slow sweep of the coil, across the ground, will reduce false signals.

If detecting non-ferrous items in a high trash area, a beginner may prefer to use Auto sensitivity and Disc – Iron
Mask / Off (see chapter 7.5.1) as this setting will provide a smoother operation, and keep “broken” or “chopped”
signals to a minimum.

Advanced users operating in non-mineralised soils or areas of high trash concentration should set the
sensitivity control out of Auto and into the variable Manual region. The control should be set as anti-clockwise
as possible (out of Auto and into the variable manual region), so that minimal false signalling occurs.
This setting will depend on the degree of soil mineralisation and metal junk concentration and may need to be
altered as the environment changes.

p14

Ideally, this control should be set to a position where the threshold tone is just audible. At this level, the
presence of small or deep targets will be more easily recognised. Turning the Threshold control in a
clockwise direction will increase the threshold level. At the most clockwise setting, the threshold is at
its maximum.

A threshold level that is too high will mask out the small or deep targets, while a “silent” or non-audible
threshold may not allow the small change in threshold tone created by small or deep targets to be heard.

also change. After the target signal is heard, the threshold “hum” will return in a pitch similar to the pitch of
the signal. When the target signal is nulled due to discrimination or notching, the threshold will again return
in the higher or lower pitch of the target conductivity.

For example, if you are searching in the Discriminate mode and you have just detected a coin, the threshold
will remain at the tone of the coin signal, but when you pass over a junk target such as a nail, the Audio will
NULL (go silent) over the nail, and the threshold, when it returns, will drop to a lower tone. This can be a
useful feature, as unlike other detectors using Silent Search discrimination modes, you still ignore the junk
targets, but you know when you have passed over them and can estimate the conductivity that they have.
( see 7.6 Discrimination & Notch descriptions)

The other advantage of the threshold-based Discriminate mode is that on occasions, the only thing that may
alert you to the presence of a very deep target is a change in threshold pitch. This is a common occurrence
in very junky sites, or if you are sweeping faster than normal.

However, for new users of BBS technology, this may initially be a little confusing so, to simplify things a
little, Minelab have added a Silent Search discriminate mode option to the Sovereign GT. In this mode,
targets will still produce different tones based on conductivity, but you will not hear the changes in threshold
tone, or the Nulling of discriminated objects. A slightly faster sweep speed is also possible, which makes the
Silent Search mode ideal in areas of low target concentrations, such as the beach, where ground coverage
is just as important as recovering the really deep targets. If a rich pocket or area is located, the operator can
select the Threshold mode and slow down their sweep to ensure all targets are recovered.

To operate in Silent Search mode, you need to start with the switch in Threshold position and, using the
Threshold control, lower the level until it is just audible as you would if you were searching with Threshold.
Once you have this level of threshold, flick the switch to Silent Search. The threshold will now disappear but
a faint target signal will still sound.

NOTE: If you were to have the threshold level set too low before going into Silent Search, you could find that
the very soft target signals may not be audible. If your threshold level is too loud before
switching into silent search, the threshold will become softer but still audible

7. control panel

www.minelab.com

7.

4

.

Threshold Control

Located at the bottom right of the control panel, the Threshold control allows for
adjustment of the background hum. This background “threshold” or “hum” aids in the
location of targets.
Small targets or large, deep targets may not produce a distinct target signal but rather
cause only a slight change in the threshold tone.

7.

4.1

Silent Search/Threshold

When in the discriminate mode, the Sovereign GT will vary the tone of an audio signal
depending on the conductivity of the target; ie. a highly conductive target will produce a high
pitched tone, while a less conductive item (such as foil) will produce a lower pitched tone.
The advantage of the Sovereign GT over other detectors is that the tone of the threshold will

.

p15

www.minelab.com www.minelab.com

7.5.Disc/All Metal Switch

This switch is located in the top centre of the control panel and is used to
select All Metal or Disc. (Discriminate) with Iron Mask, or Disc. without Iron
Mask mode.

In All Metal mode the

objects. In this mode the Disc and Notch controls will have no effect and the
Sovereign GT
conjunction with Fixed & Tracking ground balance, especially when searching for gold nuggets or
other targets in mineralised soils. It is also the required setting when searching for ferrous targets
such as relics.

In Disc. mode, the Disc and Notch controls become active and can be used in combination to ignore
various unwanted metal objects.

Metal objects fall into two broad categories:- ferrous and non-ferrous. A magnet can be used to
determine if an object is a ferrous or non-ferrous metal; ferrous metals are attracted to a magnet
while non-ferrous are not.

Note: All Metal mode is also the pinpointing mode. To pinpoint, if you have been detecting in Disc,
switch up to All Metal and have the ground balance switch in Pinpoint (see 7.8.3 pinpointing).

In Disc. mode the detector will null or cancel target signals made from unwanted metals. The degree
of discrimination is set by using the Disc and Notch control knobs. When the Disc/All Metal Switch
is in Disc position and with Disc and Notch control at minimum, the
ferrous metals and signal on all non-ferrous targets. As the Disc control is increased (turned
clockwise) some non-ferrous metals will be cancelled and as the control is increased further, more
non-ferrous metals will be cancelled.

In addition, when in Disc mode, the target signals from non-ferrous objects will vary in tone
depending upon their level of conductivity. Effectively, this allows general identification of the type of
object detected before recovering it from the ground. For example, a US quarter or Australian
$1 coin will produce a high pitch signal, whereas aluminium foil will produce a low pitched signal.
Pull-tabs, rings, and other coins will produce various intermediate tones, depending upon the
object’s conductivity. The higher an object’s conductivity, the higher the signal tone will be.

Also, provided the Threshold / Silent search switch is in the Threshold position, when the
Sovereign GT
momentarily disappear then return again at a pitch similar to the ignored signal. A ferrous object will
cause the returning threshold pitch to be much lower than normal, while a pull-tab that is being
ignored will cause it to be higher than normal.

If the
overloaded by a substantially large piece of metal close to the coil. Raise the coil a few inches above
the ground and pass it over the area again to check the target. By lifting the coil away from the
ground, it enables the

Note: If a target signal seems to have "blanked", but the threshold hasn’t changed to a different
tone (assuming the threshold switch is selected) it may in fact be a very deep target on the edge
of the detection depth. Digging down an inch or two will get the coil closer and will enable it to
be identified.

p16

will respond in the same way to all types of metal. All Metal mode should be used in

rejects a ferrous or a non-ferrous object, the background threshold tone will

Sovereign GT

produces a high-pitched, rapidly pulsing sound, the detector is being

Sovereign GT

Sovereign GT

to accurately analyse the object detected.

will detect both ferrous and non-ferrous

Sovereign GT

will cancel all

7.

5.1.

Iron Mask On/Off

A fundamental problem for most conventional detectors is the inability to recognize a
valuable target when it is located near a ferrous item. This is a particular problem in areas
heavily littered with trash, which is common on old relic sites.

Sovereign GT

The
between a non-ferrous target and iron trash, recognizing the non-ferrous target and
providing an audio signal.

With Iron Mask / On, the search depth is also a little greater and non-ferrous targets may
be located more reliably amongst ferrous trash. However, with Iron Mask /On, the
detector may give the occasional "beep" on large ferrous targets and the threshold
may not be quite as stable. For this reason, beginners may prefer to detect with Iron
Mask / Off. Also, when discriminating in mineralised soil, Iron Mask / Off may be the
preferred mode.

, using Iron Mask / On is particularly good at making the distinction

7.6.Discrimination Control

The Disc (Discriminate) control is located at the top left-hand side of the control panel
and is used when in Disc. Mode to "discriminate" or "ignore" unwanted non-ferrous
metal targets. If the Disc control is set to the most anti-clockwise position (ensure the
Notch control is also set to this position), then ferrous metals will be "ignored" and the
Sovereign GT
may produce short "pops" or "clicks". On the other hand, non-ferrous targets will be
"accepted" and elicit a clear "signal beep".

Typical ferrous objects encountered by treasure hunters are nails, screws, washers, bits
of wire, etc. These objects are generally not considered to be of value, so it is a distinct
advantage to be able to ignore them while detecting. Objects that will cause the
Sovereign GT
as aluminium foil, most jewellery, pull-tabs, coins, bottle tops, gold, silver, brass, etc.

Not all of these non-ferrous objects are considered valuable. Therefore, by using the
Disc control, the
ferrous objects while still locating most valuable targets. The Disc control is a one-turn
potentiometer, continuously variable with numerous graduations as a guide for the
setting of the control. Turning the Disc control clockwise will increase the
"discrimination" level, and non-ferrous objects of lower conductivity will be ignored.

will not produce a "signal beep" for them, however large ferrous objects

to produce a "signal beep" will be non-ferrous metals, including such items

Sovereign GT

can be adjusted to ignore some of the less valuable non-

p17

www.minelab.com

www.minelab.com

7.6.Discrimination Control – Continued

The

Sovereign GT
and based upon the Disc control setting, will either ignore or accept the object. The most effective way
to demonstrate this is to consider a number of objects, all of varying conductivity, placed in order of
conductivity on the ground. (see figure 12).

Turn the Disc control further clockwise and objects of greater conductivity will be ignored. If the Disc
control is set to ignore the pull-tab, this will mean that all objects having a similar or lower conductivity
than the pull-tab will be ignored, while objects of higher conductivity will still be accepted (see figure 13).

Figure 13 shows some common objects and where the Disc control would have to be set to ignore them.
As a general rule, the two objects treasure hunters most commonly wish to ignore are aluminium foil and
pull-tabs. As can be seen in Figure 13, both of these objects cover a significant range on the Disc
control. The conductivities of objects that the user wishes to accept or ignore often overlap, so - setting the
Disc control to ignore both foil and pull-tabs will also ignore a large amount of valuable non-ferrous objects
including some coins, rings, and other jewellery which have conductivity levels between these junk items.

uses the electrical conductivity of the object to determine the type of metal detected,

Figure 12 - Target conductivity

Figure 13- Discriminating targets based on conductivity

sets a continuous band of discrimination, whereas the Notch selects a short segment of discrimination which
can be moved up or down the scale of conductivity.

Note: The Notch control will only be active, if set to a higher or more clockwise level than the Disc control.

As the Notch control is turned further clockwise, objects with a conductivity, within the width of its band, will
be ignored. Turning the Notch control to ignore the pull-tab will mean that only non-ferrous objects having a
similar conductivity to the pull-tab will be ignored while all other non-ferrous objects of different conductivity
are still accepted.

Note, in Figure 15 the ferrous objects are being ignored due to the Disc. setting on zero.

When using the Notch and Disc controls in combination, most unwanted objects can be successfully ignored
(see Figure 15). Turning the Notch control to ignore the pull-tab and the Disc control to ignore the aluminium
foil will set up the Sovereign GT to ignore most pull-tabs and aluminium foil while still detecting most valuable
non-ferrous objects (see figure 16).

Note: Different pull-tabs may require a slight movement of the Notch setting. Obviously, if the amount of
pull-tabs is not numerous, then you may decide to leave the notch at minimum, which removes the risk of
discriminating a valuable object.

7.7.Notch Variable Control

Located on the centre left of the control panel, the Notch control is used in combination with
the Disc control to discriminate against, or ignore, certain metal objects. As with the Disc
control, this is continuously variable and features numerous graduations as a guide to
setting the control.

The main difference between the Notch and Discrimination controls is that Discrimination

Figure 15 - Ignoring targets using the Notch control

Example: If hunting for thin rings of white gold, with the Disc
control set to position 4 (see figure 14), some types of aluminium
foil will also be detected. To avoid old pull tabs, but detect brass
buttons and copper coins, the Disc control would need be set
higher (approximately at number 13).

At this setting most fine white gold rings, foil, and some yellow
gold rings will also be ignored. With experience, setting the Disc
control to ignore most unwanted targets (in combination with the
Notch control) will become second nature and you will develop a
preferred setting for different sites.

Figure 14- Disc control

p18

Figure 16 - Ignoring targets using the Disc and Notch controls

TIP: It is very important that you recognize the conductivity level of common coins, jewellery and trash targets
so that you know what items will be accepted or rejected at various levels. We recommend that you read and
follow Chapter 9 - Practising the Controls to be familiar with common targets in your area.

NOTE: If operating with Threshold, the operator will hear that a target has been discriminated or notched out
by the threshold going null (silent) and can determine if it was discriminated or notched by the tone of the
returning threshold ie: if the threshold returns in a deep tone, the object was discriminated and if the
threshold returns in a higher pitch it was notched out.

p19

www.minelab.com www.minelab.com

7.8.Ground Balance switch ( Track/Fix/Pinpoint )

When operating in Disc mode, the
compensate for ground effects and the Track / Fix / Pinpoint function is disabled.

When operating in All Metals, Minelab’s world-renowned Automatic ground
balance is operating to overcome the effects of variable, mineralized soils. This automatic ground
balance means that the
mineralised soils, as well as coin & treasure hunting in parks, fields or the beach.

Track position, continuously analyses the ground and resets the ground balance to compensate
for changes in the mineral content. This position is ideal for areas where the ground mineralization
is changing rapidly.

Fixed position, holds the ground balance at the last setting found while in Tracking and is suited
to areas where the ground mineralisation is more constant. Fixed position will often give slightly
more depth than Track.

Tip: If the Track Mode is unsuccessful at ground balancing in heavily mineralized ground, the
operator should reduce the sensitivity setting and slow down the sweep speed.

Note: In most ground the Sovereign GT will ground balance to a slightly positive level (audio level
rises when the coil is lowered to the ground). This is to ensure maximum depth, and will help to
reduce signals from large hotrocks close to the surface.

Sovereign GT

can be used for gold prospecting or relic hunting in

Sovereign GT

uses digital filtering to

7.

8.1.

To ground balance in mineralized soils

When in the All Metal mode, place the switch into Track and raise and lower the coil between
2 – 15cm above the ground. As the detector compensates for the ground minerals that are
present, the threshold will begin to stabilize, producing the same steady tone as you raise and
lower the coil. Depending on the mineralisation of the soil, this may take a number of pumps of
the coil. It is important that during ground balancing, your coil is positioned parallel to the ground
and that there is no metal in the ground or close to the coil. If you cannot achieve a ground
balance, try again a few feet away in case there is a metal target under your first location or reduce
the sensitivity. Once you have achieved ground balance, switch into Fixed and start
detecting. If the area you are searching is variable mineralisation, you will need to periodically
switch back to Track to reground balance. In areas of highly variable ground, you can stay in Track
mode to search.

Note Be aware that if searching in Track, it is possible, with repeated sweeps across a target, to
track out a weak signal, therefore, always switch to Pinpoint or Fixed to recover the target.

7.

8.2.

To ground balance in non-mineralized soils

If you wish to search in the All Metal mode on a saltwater beach, a better method to ground
balance is to start with the sensitivity in Auto and select the Track position. Begin detecting as per
normal and after you have covered about 10m of ground, switch into the Fixed position. If the
detector remains stable, you can switch out of Auto sensitivity and select a manual setting. This
method will ensure maximum stability and depth on most beaches. If the All Metal mode is too
erratic, then switch to Disc, with Iron Mask / On and the Disc & Notch both on minimum.

7.

8.3.

P/Point (pinpoint)

target once found. Pinpoint gives a short signal as the coil passes over the target, which can assist
in knowing exactly where to dig your hole.

As you pass repeatedly across the target, you will notice that the target signal becomes shorter
and sometimes weaker with repeated passes. This will help you locate the exact position of the
target under the coil. If you need to repeat the process, switch out of Pinpoint into Tracking and
then back to Pinpoint again.

is a specialized position for pinpointing the location of a

p20

Note: You should not search in Pinpoint as the ground balance is disabled and the detector can
become erratic.

TIP: If you are searching in Disc. and want to locate the position of the target, you can switch into
All Metal and use the Pinpoint mode. When operating in Disc. the Pinpoint is disabled until you
switch into All Metal.

p21

www.minelab.com

8. digital target indication meter

www.minelab.com

7.9.Noise Cancel

When detecting in some areas, the threshold may become chattery or
unstable. This is often caused by electricity or radio transmission and
most commonly of all, other detectors. The noise cancel switch on the
Sovereign GT
which will often overcome this effect.

If detecting in pairs or a group, or when you experience instability due to interference,
switch to the other band to see if this overcomes the problem.

The selection of Band 1 or Band 2 doesn’t affect the performance, strength or sensitivity
of the detector. Its only purpose is to stabilise and lessen the effects of external
interference.

Note: If there is no interference in the area, the operator is unlikely to notice any
difference between Band 1 and Band 2.

7.

10.

Audio Output

The

Sovereign GT
target signals. It is however recommended to use headphones as these will allow the
operator to hear faint targets better and cut out environmental noise such as traffic,
others talking or the wind.
The audio output of the
via a 1/4" stereo headphone jack. When a pair of headphones is plugged in, the
loudspeaker is disconnected.
Headphones are recommended for serious treasure hunting for several reasons: they are
more sensitive to slight target signals than the loudspeaker and their use will increase
battery life. The socket will accept most stereo headphones with a 1/4" jack. If your
headphones have a "Stereo/Mono" switch, set it to "Stereo". Minelab recommends
headphones to be between 32 and 100 Ohms.

has a built in speaker so that the operator can hear the threshold and

Sovereign GT

allows the operator to select a different search band,

is available through either the in-built speaker or

8. Digital Target Indication Meter

The Digital Target meter has been designed to aid in the identification of metal targets before their
recovery. It provides a digital display of the target ID tones produced by the
detector, and connects between the search coil and the control box without requiring any
modification to the detector’s electronics.

The meter has no negative effect upon the operation or overall performance of the detector;

Note:

it simply provides easier target recognition. It is also very useful for people with poor hearing.

(available as accessory)

Sovereign GT

8.1.Installation of Meter

a) Plug the coil connector (14) into the socket (19) on rear of the meter box (19), winding the excess

cable around the shaft as close to the meter and away from the coil as possible.

b) Plug the meter cable connector (20) into the control box (2) plug, winding the excess cable
around the upper shaft (4) (see figure 17).

c) If hipmounting the control box, secure the meter cable to the shaft of the detector using the

TM

straps provided.

Velcro

d) Loop the meter cable twice through the belt loop of the hipmount bag before connecting it to
the control box. This reduces any stresses placed on the meter cable caused by hipmounting and
reduces the possibility of failure of the cable. The meter requires no batteries.

Figure 17 - Installing

the meter

p22

p23

www.minelab.com www.minelab.com

8.2.Calibration of Meter

Before using the Digital Target Meter, it is necessary to calibrate it as follows:

a) Set the Calibration control knob (situated to the rear of the meter) to the center position
of its range.

b) Place the detector in a stationary position with the coil flat on the ground.

c) Set the Sensitivity control on the Control box to Auto (extreme anti-clockwise).

d) If the threshold is varying because of electrical interference, adjust Sensitivity clockwise

towards minimum until a constant threshold is present.

e) Slowly pass a common coin across the coil and finely adjust the Calibration control to
the nearest number, divisible by 5 [e.g. US quarter -set to 170 , AUS 20c - set to 165.]

f) Slowly pass additional coins and other common targets across the coil and record the
results on the target recognition table shown on page 25.

This table will become an excellent guide when used in conjunction with the Digital Target
Indicator until the various target responses become familiar. This meter should not be
solely relied upon for discrimination. It is important to use the other features of the
Sovereign GT

Be aware that some similar objects may vary in Target Indication readings because of
changes in composition. For example, gold rings will produce different readings
depending upon the purity of the gold and the size of the band. Coins minted in different
years may have different alloy combinations and so the reading will differ. The Target
Indication readings will also be influenced by an object’s orientation, the length of time it
has been buried in the ground and different ground conditions.

to aid in the process of discrimination.

Target Recognition Table

Object Type Reading

US quarter non-ferrous 170

AUS 20c non-ferrous 165

p24

p25

9. practising the controls

www.minelab.com

10. treasure hunting tips

www.minelab.com

9. Practising the Controls

Take some time to become familiar with how the

a)

Gather a collection of different metal objects such as a rusted nail, pull-tab, brass button,

aluminium foil, various coins, and some gold and silver jewellery.

b)

Take the detector outside, away from known electromagnetic devices or metal objects. Lay the

various objects out on an area of ground known to be void of other metal objects.

c)

Switch the

d

) Turn the Disc and Notch controls to their most anti-clockwise positions.

e)

Turn the Sensitivity control to "maximum", the most anti-clockwise position without clicking into
Auto. If excessive interference is heard, turn the Sensitivity control clockwise until the threshold tone is
stable.

f)

Pass the coil across the test objects one at a time. The

non-ferrous objects and ignore the ferrous objects.

g)

Take note that as the coil passes over the ferrous nail, the threshold tone disappears. As the

threshold returns it will have a lower than normal pitch, indicating that the object ignored was ferrous.

h)

Passing the coil over different non-ferrous objects will produce different signal tones. Objects with
high conductivity, such as those of silver or copper, will produce a high-pitched signal tone while
objects with lower conductivity, such as aluminium foil, will produce a low-pitched signal tone. With
experience it will be possible to use the signal pitch from an object to accurately determine the type of
object discovered before recovering it from the ground.

i)

Turn the Disc control progressively clockwise in small steps and pass the coil over the objects. Take
note of when certain objects are rejected; this will enable more accurate discrimination of these objects
in the field.

j)

Turn the Disc control to the position where it ignores the pull-tab. Passing the coil over objects with
lower conductivity (such as the aluminium foil) will not produce a signal. Take note of the threshold tone
as it disappears, then returns again. It should return at a slightly different pitch than normal. This
indicates that the

k)

Turn the Disc control back to the most anti-clockwise position.

l)

Progressively turn the Notch control in a clockwise direction, again passing the coil over the test
objects. The Notch control enables the detector to ignore a small number of objects with similar
conductivity while still detecting other valuable non-ferrous objects, even if they are of
lower conductivity.

m)

Turn the Notch control to ignore the pull-tab. Objects with similar conductivity to the pull-tab will be
ignored. Pass the coil over the aluminium foil and the
not be possible using the Disc control.

n)

Turn the Disc control to ignore the aluminium foil. The

of objects most commonly unwanted by treasure hunters.

Sovereign GT

Sovereign GT

On and select Disc. Mode.

ignored a non-ferrous object.

Sovereign GT

Sovereign GT

Sovereign GT

responds to various metal objects.

Sovereign GT

will produce a signal. This would

should "beep" on the

is now set to ignore the types

10. Treasure Hunting Tips

The

Sovereign GT
its Tornado coil is kept in close proximity to the
ground. Inexperienced operators should practice
maintaining a constant coil height at the
extremity of each swing; maintaining contact with
the ground will make this easier. This is important,
as variation in coil height at the end of each swing
can cause confusing sounds and will reduce
detection depth.

NOTE: Each sweep of the coil should overlap the
last one. This will ensure good ground coverage.
Keeping the Tornado coil in contact with the
ground will increase detection depth and improve
the audio response to small objects.

will perform at its best when

Figure 18 - Sweeping

the coil

10.1.Pinpointing the Target

When the approximate location of the target has been determined, move the coil slowly over the
target. The audio signal will increase in volume while moving towards the target and decrease in
volume as the coil is passed away from it. The signal will be loudest when the coil is directly over the
target. Quite often the detector will be producing its maximum volume for a broad area over the
target. This generally indicates that the target is near the surface or is quite large.

To receive a sharper, more precise signal over the target, it may also be beneficial to switch to the
All Metals and Pinpoint modes as this will produce a narrow response to the target. (see p.

The open design of the Tornado coil makes it easy to mark the ground directly above the target to
aid recovery.

Figure 19

Pinpointing the target

21)

p26

p27

10. treasure hunting tips

www.minelab.com

12. detector care

www.minelab.com

11.2.Recovering the Object

Once the target has been pinpointed, clear the surface of loose material (twigs, leaves, etc…)
and check again for the signal. If there is no signal then the target is amongst the surface
material. In this case search the surface material until the target is located.

If the target is still in the ground, recheck using the pinpoint mode. For lawned areas, cut a grass
plug in a horse-shoe shape leaving one corner attached, then bend the sod back. If you have
pinpointed properly your find should be in the middle of the exposed hole. If not, the use of a probe
can assist in locating the find exactly and minimize soil disturbance.

If you cannot see the target, but are confident it is still in the hole, remove some soil and place it
on a plastic sheet next to the hole. This will enable you to pour back the dirt and leave the
surrounding area clean after taking out your find.

Place the coil flat on the ground next to you and gradually remove handfuls of soil from the
plastic sheet and pass these over the coil. Keep repeating this procedure until you hear and
recover your target. Be sure to recheck the hole and surrounding soil, as several coins can
sometimes be found in one hole.

Pour back the loose soil and carefully tread the sod down to its original appearance. This will
maintain the pristine nature of your site and help to ensure future access for everyone enjoying this
great pastime.

Please note: Dig carefully so as not to gouge or scratch the target, which may be valuable or
unique. Be sure to remove any rings or watches from your hands before passing soil across the
coil. You may get conflicting signal responses from metal items on or close to you.

Once again, always remember to refill holes.

11. Environmental Concerns

Firstly, it should be pointed out that treasure hunting with a metal detector is the most
environmentally friendly way to recover coins, rings, and other treasure items. However, it is
important to leave an area searched in the same condition you found it.

When searching parklands or properties where the grassland or lawn is sensitive to
disturbance, always use special tools to enable the recovery of targets without digging large holes.
This retains the surface "plug" of grass and soil to be returned undisturbed.

All holes that have been dug must be properly refilled. Not only is it environmentally
unacceptable to not fill in holes, it is also dangerous.

The use of headphones when detecting will also reduce external noise, sometimes an annoyance
for other operators in the area.

Take away and properly dispose of any junk that is found or produced, such as nails, tin cans, or
flat batteries. Leaving an area "scarred" can result in action being taken to prevent the use of metal
detectors, which will spoil this fascinating hobby.

12. Detector Care

The

Sovereign GT
durable housing. Taking proper care of the detector is mostly common sense.

• Do not leave alkaline batteries in the control box when the detector is not in use for any
period exceeding two weeks.

Damage caused by leaking batteries can be severe and will void the warranty through
negligence.

• If temperatures are very high, do not leave the detector in the sun for longer than
necessary. Covering it when not in use will help protect it. Try to avoid leaving it in a closed trunk

or in a car sitting in sunlight.

• While the coil of the detector is designed to be waterproof, the control box is quite susceptible
to water intrusion. Always protect it when using the detector in rain or on the beach where salt
spray is prevalent. Using the accessory hipmount bag to protect the control box will assist this
in most weather.

• Never allow the box to come into contact with gasoline or other oil-based liquids.

• Keep the detector clean and dry and avoid getting sand and grit into the shafts or the

tightening nuts. Do not use solvents to clean the detector; use a damp cloth with mild
soap detergent.

• Flat or faulty batteries cause many problems with detectors. Ensure that only quality alkaline
batteries are used, and that they are replaced when the low-battery warning signal is heard
through the headphones or speaker.

• Ensure that the coil cable is in good condition and not subject to undue stress. Do not undo or
loosen the coil connector at the base of the cable where it enters the coil. This should always be
firmly tight.

is a high-quality electronic instrument, finely engineered and packaged in a

p28

p29

13. troubleshooting

www.minelab.com

14. specifications

www.minelab.com

Fault Solution

No Sound – Check batteries and battery connections.

– Check headphones and their connection.

Erratic Noises – Check battery charge and battery connections.

– Ensure coil connector is tightened firmly.
– Reduce the Sensitivity by turning clockwise or

return to the Auto position.
– Switch Noise Cancel switch to other Band.
– Check headphones and their connection.
– Check for sand or grit between coil cover and coil.

No Target Response – Ensure the detector is turned On.

– Check battery charge and battery connections.
– Check coil connection.
– Check headphones and their connection.
– Check Disc and Notch settings.

In the unfortunate circumstance that the detector needs to be returned to Minelab for service,
please fill out the Minelab Service Repair Form (on page 33, or a photocopy of the same) and
enclose it with the detector.

Please supply as much detail about the fault as possible as this will assist our service engineers
to rectify the problem quickly and efficiently.

p30

14. Specifications

These specifications are subject to change without notice.

eatures:

F

Length Maximum 55in (1400mm)

Minimum 38in (965mm)

Weight Control Box* 20.3oz (568gms)

Tornado 1000 coil 23oz (654gms)
Technology Broad Band Spectrum (BBS)
Transmit Frequency 17 frequencies (1.5 ...25.5khz)
Ground Balance Automatic Ground Tracking
Arm Rest Aluminium with Neoprene cover & strap
Battery System** Alkaline (8 x 1.5V AA) or

NiMH battery pack (12V; 1000mAH)
Mains Charger** 110v (USA);230V (EU); 240V (AUS)
Vehicle Charger** 12V Cigarette Lighter plug
Target ID Meter** Digital
Audio Loudspeaker & 1/4 inch headphone jack

Controls:

On/Off Volume 1 turn pot
Sensitivity 1 turn pot
Threshold 1 turn pot
Discrimination level adjust 1 turn pot
Notch filter 1 turn pot
All Metal/Disc with Iron Mask On
/Disc with Iron Mask Off 3 pos. switch
Threshold/Silent Search 2 pos. switch
Ground Track/Fixed/Pin Point 3 pos. switch
Noise Cancel 2 pos. switch

Accessories:

Tornado 800 Slimline coil 8 inch Double-D waterproof
Tornado 1000 Slimline coil 10 inch Double-D waterproof
Alkaline Battery pack 8 x 1.5v (AA)
NiMH Battery Pack 12V, 1000mAH
Car Charger 12V Cigarette Lighter Plug
Hip Mount Bag with viewing window & shoulder strap
Rain Cover/Meter Bag with viewing window
Carry Bag Protective transport bag
Headphones 32 ohms

Warranty:

Control Box 2 years
Coil 2 years

* Excluding batteries ** Optional accessories

Note: Minelab reserves the right to make changes without notice and offer different configurations in different countries.

p31

15. warranty and service

www.minelab.com

Minelab Service Repair Form

Today’s Date:

Detector Model: Serial No.:

Purchased From:

Purchase Date:

Parts being returned:

Description of Fault:

Owner’s Name:

Address:

Phone: Day ( ) Home ( )

Fax: ( ) Email:

p32
