MINDKOO MK-BE02 User Manual

Lightweight In-Ear Bluetooth Earbuds

MK-BE02

User Guide

1

EN

Thanks for using our headsets. This headset
equipped with Bluetooth 4.1, and it also has
extraordinary noise cancellation function,
providing excellent sound quality. Please
read the instructions carefully before using
the product.

2

3

Function Operation

Power on

Press and hold the MFB key for 3 seconds

Press and hold the MFB key for 3.5 seconds

Press and hold the MFB key for 6.5 seconds

Short press the MFB key once

Short press the MFB key once

Press and hold the MFB key for 1 second

Double press the MFB key

Short press the MFB key once

Short press the MFB key

Short press vol-/vol+ key to adjust volume,
long press to switch tracks

Power off

In pairing mode

Answering Call

End call

Reject call

To Redial the last number
called

To terminate current call

To pause/play

Tuning volumes/Previous
track/Next track

4

The micro USB charging port

1. 1-2 hours (fully charged)

2. The headset performs better with full battery.

3. Battery :3.7V 100mAh polymer lithium battery. Input:DC5V/1A

Volume button

1. Volume+ /- (A level of volume changes when the button got press
once)

LED Indicator

1. During charging (the red light indicates the device is charging; blue light
shows the battery has been fully charged）

2. When battery power is insufficient (the red light flashes twice with voice
prompt）

Steps to pair the Bluetooth headset to
cell phone

1. Under the state of power off, press and hold the MFB key on the device
for 6 seconds until the LED indicator flashes between red and blue, the
device is now appearing to be searched. (Ensure to hear the voice
indication then headset is able to be searched by other Bluetooth devices)

2. Turn on the Bluetooth on mobile phone and hit to search Bluetooth
devices. The headset model code would appear in search.

3. Click the headset model to connect. If the connection is successful, the
indicator on the headset would flash blue light.

4. Input the password: 0000 (default password is 0000)

Congratulations, your headset is now successfully connected, please enjoy
your music and calls.

1 for 2 multi-points function connection steps

1. When the Bluetooth headset is turned off, long press the MFB key for

5

about 6 seconds until the headset indicator flashes red and blue, it shows
that the device is now under the search pairing state.

2. Turn on the Bluetooth function on mobile phone #1 and find the
headset name in the search, select the headset to complete the
connection.

3. Switch off the Bluetooth function on mobile phone #1 and long press
the MFB key on headset until the red light of indicator is on, the headset is
now shut down.

4. Turn on the Bluetooth headset again and start the searching and paring
state.

5. Turn on the Bluetooth function on mobile phone #2 and find the
headset name in the search, select the headset to complete the
connection.

6. Now you can turn on the Bluetooth function on mobile phone #1 and
reconnect it to the headset. So you can use your headset on both of your
mobile phones.

Keep your Bluetooth headset close to your phone. The block-free distance
between the headset and your mobile is 10 meters, the sound quality
might decrease or even break if beyond this distance.

Explanation of headset re-connection:

1. Your Bluetooth headset would automatically try to reconnect the last
connection.

2. If your Bluetooth headset does not reconnect, please press the MFB key
the device once or manually go through the Bluetooth menu on your
mobile phone to reconnect the device.

Restore factory settings

1. Press and hold the MFB key for 3 seconds during charging until the
indicator flash red and blue 3 times the device is then restore the default
settings.

6

Frequently asked questions:

1. Mobile phone can’t find the Bluetooth headset

Solutions:

①Make sure that the headset is on. (See if the indicator is flashing
between Red and Blue)
②If the headset is remained unseen in the searching list, please restart
both your phone and the headset.

Note:

Please complete the pairing procedure within 2 minutes after the
Bluetooth headset enters the pairing mode, otherwise the headset would
turn off itself after 2 minutes.

2. Disconnect frequently or hearing noise while using headset.

Solutions:

①Problems could be caused due to low battery, please recharge your
device as soon as possible.
②Problems appear because the connection between headset and mobile
is obstructed, please put the mobile phone and the headset together and
keep them in the same direction, and don’t cover the Bluetooth by hand.

3. The Bluetooth device is connected to mobile, but you can’t hear music.

Solutions:

① Mono Bluetooth headset cannot be used to listen to music unless it is
matched with Nokia mobile phone.
② Check your Bluetooth setting, and change the sound path to
hands-free mode.
③ Some cell phones require 2 more steps in player to setup connection:
Select the connected Bluetooth device on the speaker icon and then click
OK.
④ Some mobile phones don’t equip with the Bluetooth stereo module. In
that case, you can check the functionality of your headset by connecting

7

the device with other mobile phones that in-built with the Bluetooth stereo
module to find out whether the headset is working.

4. How to connect Bluetooth earphone to your computer?
Answer：If your PC comes with a Bluetooth function, you can start to
search the on-state headset after installing the correct driver.
If your PC does not compact with Bluetooth, you will need to download
and install the Bluetooth adapter software (IVT) to be able to use
Bluetooth on your PC. Computers with XP system can identify Bluetooth
adapter and it does not need driver, whilst the XP built-in adapter can only
transfer files but not audio signal, so you will need to install the IVT
software from the CD to enable audio transmission.

5.How long can the devices part from each other while using?
Answer：The sensing distance between Bluetooth earphone and mobile
phone or adapter is 10 M. Within that range, the connection stays sturdily
when there is no obstruction between devices. But there will be light noise
or distortions on calls if the devices are set apart outside the sensing
range.

6. What is the pairing password for the Bluetooth headset?
Answer：The default Bluetooth pairing password is 0000. Most phones fill
that password automatically, but you might need to manually enter the
password in some cases.

7.The indicator on the headset shows no red light during charging?
Possible reason: The device has not been powered for a long time.
Solution: Keep the device on charging for 30 minutes, the red light should
reappear on the indicator.
Caution: Over charging or put the headset within enclosed environments
like within a car, the battery life and capacity would be reduced.

NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions,may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to
which the
receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help

Changes or modifications not expressly approved by the party responsible
for compliance
could void the user's authority to operate the equipment.
This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may
cause undesired operation.

MANUFACTURER

MINDKOO ELECTRONIC TECHNOLOGY CO.,LTD

16/F KOWLOON BLDG 555 NATHAN RD MONGKOK KLN

HONG KONG. 999077

CONTACT US:

Made in China

FCC ID:2AKL2-LAEJ2
